User Manual
CAR MULTIMEIDA SYSTEM
USER’S MANUAL
IONIQ
Please read this manual carefully before operating your set and retain it for future reference. Designs and specifica-
tions are subject to change without prior notice.
The screens shown in this manual may differ from the actual screens of the product.
The design and specification of this product may change without prior notification for product improvement.
When transferring the vehicle to another individual, include this user’s manual so that the next driver can continue its use.
Rev.2.0
ENGLISH
ESPAÑOL
Model MTXM100AE
iPod®
iPod® is a registered trademark of Apple Inc.
Bluetooth®
The Bluetooth® Wireless Technology word mark and logos are registered
trademarks owned by Bluetooth® Wireless Technology SIG, Inc.
Cortex
Cortex is the name of the ARM Processor Architecture used in the AV System.
Windows Embedded Compact 7
Windows Embedded Compact 7 is an operating system used in the AV
System.
3
Table of Contents
ENGLISH
Precautions for safety
Safety notes
6
Key Product Features
Key Product Features
8
Component Names and Functions
Head Unit
9
Steering Wheel
11
Using the System for the First Time
Turning the System On/Off
12
Turning the System ON
12
Turning the System Off
12
AV ON/OFF
12
Resetting the System
12
FM/AM
Basic Screen
13
Listening to FM/AM radio
14
Auto tuning
14
Manual tuning
14
Selecting Presets
14
Selecting Lists
14
Saving Radio Frequency
15
Saving Manually
15
Using Preset Menu
15
Scan
15
Scanning Radio Frequency
15
Scanning Preset frequency
15
Sound settings
15
USB
About USB
16
USB Music
Playing USB Music
17
Searching USB Music Files
17
Repeat
17
Shuffle
17
Scan All
17
Scan Folder
17
Album Cover
18
List
18
Sound settings
18
USB Video
Playing USB Video
19
Searching USB Video Files
19
Repeat
19
Shuffle
19
List
20
Caption
20
Display settings
20
Sound settings
20
USB Photo
Viewing USB Photo
21
Switching to menu screen or full screen
21
Searching USB Image Files
21
Rotating / Slide show
21
Using the Menu Buttons
22
Slideshow interval
22
Display settings
22
iPod® Music
About iPod®
23
Playing iPod® Music
24
Searching iPod® Music Files
24
4
Table of Contents
Using the Menu Buttons
24
Setting audiobook playback speed
24
Sound settings
24
AUX
Playing an AUX source
25
Using the Menu Buttons
25
Bluetooth® Audio
Before playing the Bluetooth® audio
26
Playing Bluetooth® audio
26
Searching Bluetooth® Audio Files
26
Using the Menu Buttons
26
Bluetooth® Wireless Technology
Before Using the Bluetooth® Handsfree
27
What is Bluetooth® Wireless Technology?
27
Precautions for Safe Driving
27
Cautions upon Connecting
Bluetooth® Phone
27
Bluetooth® Connection
When no Phones Have Been Paired
28
Pairing from the Bluetooth® Device
28
When a Phone is Already Paired
29
When your phone is connected
29
Bluetooth® Phone
Making/Answering Calls
30
Calling by Dialing a Number
30
Making a Call from Speed Dial
30
Calling through Redial
30
Answering a Call
30
Rejecting a Call
30
Operating Menus during a Call
31
Ending a Call
31
Switching Call to Bluetooth® Phone
31
Making 3 way call
31
Using the Menu Buttons
32
Contacts
32
Updating Mobile Phone Contacts
32
Making a call from contacts
32
Searching for contacts
32
Calling list
33
Viewing Calling lists
33
Favourites
33
Calling Favourites
33
Saving to Favourite
33
Deleting Favourites
34
Changing the Favourites name
34
Bluetooth® settings
34
Android Auto™
About Android Auto™
35
Precautions
35
What you need?
35
Before starting Android Auto™
36
Installing the Android Auto™ Application
36
Setting the system
36
Starting mode
36
Home Screen
37
Talk to Google
38
Return to your car’s Media screen
38
Return to the Android Auto Home screen
38
Apple CarPlay
About Apple CarPlay
39
Precautions
39
What you need?
39
5
Table of Contents
ENGLISH
Before starting Apple CarPlay
39
Setting Siri on the iPhone
39
Setting the system
39
Starting mode
40
Home Screen
40
Speak to Siri
41
Open an app
41
Return to the CarPlay Home screen
41
Return to your car’s screen
41
View additional apps
41
Return to a phone call or to turn-by-turn
directions
41
View and control the current audio source
41
Setup
Starting mode
42
Sound
42
Sound Balance
42
Variable EQ
42
Volume setting
42
Beep
43
Display
43
Brightness
43
Dimming mode
44
Bluetooth® settings
44
Bluetooth® connection
44
Ringtone
45
Change passkey
45
Changing device name
45
Auto Connection Priority
46
System
46
Language
46
Clock
46
Factory settings
47
Connectivity
47
Specification
USB MP3 Specification
48
Video and Image Specification
48
Trouble shooting
Trouble shooting
49
Limited Warranty
LIMITED WARRANTY
52
6
Precautions for safety
Safety notes
CAUTION
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with the arrowhead symbol
within an equilateral triangle is intended
to alert the user about the presence of uninsu-
lated dangerous voltage within the product’s
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral tri-
angle is intended to alert the user to
the presence of important operating and main-
tenance (servicing) instructions in the literature
accompanying the appliance.
Always operate the vehicle in a safe manner. Do
not become distracted by the vehicle while driv-
ing and always be fully aware of all driving condi-
tions. Do not change settings or any functions.
Pull over in a safe and legal manner before
attempting such operations.
To promote safety, certain functions are disabled
unless the hand brake is on.
To reduce the risk of electric shock, do not
remove the cover or back of this product. There
are no user-serviceable parts inside.
Refer servicing to qualified service personnel.
To reduce the risk of fire or electric shock, do not
expose this product to dripping or splashing
water, rain, or moisture.
When driving your vehicle, be sure to keep the
volume of the unit low enough to allow you to
hear sounds coming from the outside.
Do not drop it and avoid heavy impacts at any-
time.
The driver should not watch the monitor while
driving. If the driver watches the monitor while
driving, it may lead to carelessness and cause an
accident.
7
Precautions for safety
ENGLISH
WARNING:
•• Do not stare at the screen while driving. Staring
at the screen for prolonged periods of time
could lead to traffic accidents.
•• Do not disassemble, assemble, or modify the
AV system. Such acts could result in accidents,
fire, or electric shock.
•• Using phone features while driving may dis-
tract drivers from paying attention to traffic
conditions and result in traffic accidents.
Use phone features only after the vehicle has
been parked.
•• Heed caution not to spill water or introduce
foreign objects into the device. Such acts could
lead to smoke, fire, or product malfunction.
•• Please refrain from use if the screen is blank
or no sound can be heard as these signs may
indicate product malfunction. Continued use in
such conditions could lead to accidents (fires,
electric shock) or product malfunctions.
•• Do not touch the antenna during thunder or
lightening as such acts may lead to lightning
induced electric shock.
•• Do not stop or park in parking-restricted areas
to operate the product. Such acts could lead to
traffic accidents.
••The video screen will not operate when the
vehicle is in motion. For your safety, first park
the vehicle to watch or view the screen.
•• Some Non-video features may also not operate
when the vehicle is in motion. These features
will operate only when the vehicle has been
parked.
CAUTION:
•
•Do not keep the AV system running with the
engine stopped. Doing so may discharge the
vehicle battery. When you use the AV system,
always keep the engine running.
•
•When the driver wants to operate AV system,
first park the vehicle in a safe location and set
the parking brake.
Operating the system while driving can dis-
tract the driver and may result in a serious
accident.
•
•Do not disassemble or modify this system. If
you do, it may result in accidents, fire, or elec-
trical shock.
•
•Some states/provinces may have laws limiting
the use of video screens while driving. Use the
system only where it is legal to do so.
•
•Do not use your phone in private mode when
you are driving. You must stop at a safe loca-
tion to use it.
8
Key Product Features
Key Product Features
Button Description
Display Wide TFT-LCD Display
Provides high quality video through a Wide TFT-LCD Display using an LED Back Light.
Radio
Digital Tuner Feature
Digital Tuner using PPL method that supports memory of 20 broadcast stations for each AM and FM modes.
Radio broadcast station name
Displays broadcast station names for key locations.
Multimedia
Player
Support for various Media Formats
Support for various media formats, including Radio, MP3, USB, iPod®, AUX and Bluetooth® Audio Streaming modes.
Miscellaneous
Bluetooth® Wireless Technology
Convenient use of Bluetooth® Handsfree by using buttons within the steering wheel remote controller.
Digital Screen Control Features
Easy control of features through touch screen options.
Steering Wheel Remote Controller
Control over audio features and Bluetooth® through the steering wheel remote controller for maximum convenience.
Android Auto™
Android Auto™ brings the most useful apps from your phone to your vehicle´s screen, optimized for easy glancing and control while driving.
Apple CarPlay
CarPlay puts key iPhone apps - the ones you want to use while driving - on your car’s built-in display. With CarPlay, you can get turn-by-turn direc-
tions, make phone calls, exchange text messages, listen to music, and more.
9
Component Names and Functions
ENGLISH
Head Unit
2
3 4
1
Name Description
1 Power /
Volume
Knob
••Power on
When power is off, press to turn power on.
••Power off
When power is on, press and hold to turn power off.
••Audio off
When power is on, press to turn Audio off.
••Turn left/right to control volume.
2 Reset Resets the system.
3
HOME
Press to move to the home menu screen.
4
RADIO
••Operates FM/AM mode.
••Each time the key is pressed, mode is changed in order of
FM ▶ AM ▶ FM.
5
PHONE
Takes user to phone screen.
5
10
Component Names and Functions
Head Unit
Name Description
6
∨
SEEK
∧
TRACK
When the
∨
SEEK
,
∧
TRACK
keys are pressed shortly.
••In FM/AM mode, searches broadcast frequencies.
••In Media mode, changes the track, file or chapter.
When the
∨
SEEK
,
∧
TRACK
keys are pressed and
held.
••FM/AM mode : automatically searches broadcast fre-
quencies and channels. Once released, searches and
begins playing the next broadcast frequency.
••Media mode: rewinds or fast forwards the track or file(ex-
cept AUX).
7
MEDIA
••Operates available media (USB, iPod®, Bluetooth® Audio,
AUX).
••If the media is not connected, corresponding modes will
be disabled.
8
DISP
Turns off the screen.
9
SETUP
Displays the Setup mode.
9 Tune /
ENTER
Knob
••FM/AM mode : changes the frequency.
••MEDIA (USB/ iPod®) mode : changes the track, file or title
(except AUX).
6 7 8 9 10
11
Component Names and Functions
ENGLISH
Steering Wheel
Button Description
1 + VOL - Controls the volume.
2
∧
∨
When keys are pressed shortly.
••FM/AM mode: plays previous/next preset channel if it is
saved.
••Media mode: changes the track, file or chapter.
When keys are pressed and held.
••In FM/AM mode: changes frequencies while pressed.
Upon release, scans and receives the next frequency.
••Media mode: rewinds or fast forwards the track or file.
Button Description
3 Mutes the sound.
4
••Operates FM▶ AM ▶ Available Media (USB Music/USB
Video/iPod/Bluetooth Audio/AUX).
••If the media is not connected, corresponding modes will
be disabled.
••Press and hold the key to turn the Audio system on/off.
••When power is off, press the key to turn power back on.
5
When pressed shortly.
••When pressed in the phone screen, displays the last call.
••When pressed in the dial screen, makes a call.
••When pressed in the incoming call screen, answers the
call.
••When pressed during single call, switches call back to
mobile phone (Private).
••When pressed during 3way call, swap call.
••When pressed twice, redials the last call.
When pressed and held.
••When pressed during a Bluetooth® Handsfree call,
switches call back to mobile phone (Private).
••When pressed while calling on the mobile phone,
switches call back to Bluetooth® Handsfree (Operates
only when Bluetooth® Handsfree is connected).
••When pressed, redials the last call.
6 •
•When pressed during a call, ends the phone call.
•
•When pressed in the incoming call screen, rejects the call.
124
3
56
12
Using the System for the First Time
Turning the System On/Off
Turning the System ON
Press the engine start button. If the brakes are
not pressed, then the ACC and system will turn
on. If the brakes are pressed, then the IGN and
system will turn on and the ignition will start. In
both instances, the following safety warning will
be displayed.
Pressing the PWR key on the head unit will dis-
play the safety warning page.
Press the Agree button to display the most
recent mode.
Turning the System Off
Press the engine start button again or press and
hold the power key on the head unit to turn the
system off.
NOTE
• If the system is turned off while the Handsfree is
being used, then the call will automatically switch
back to the mobile phone.
AV ON/OFF
Press the PWR key on the head unit when the AV
is on. Press the PWR key or press the menu key
to turn on AV.
While AV is turned off, the
∨
SEEK
,
∧
TRACK
key and the TUNE / ENTER knob will be disabled.
Resetting the System
This feature is used to reset the system in the
occurrence of an unforeseen error or problem.
Press and hold the RESET key for about 1 second.
(The use of a clip or pin is recommended when
resetting the system.)
Home Screen
Press the
HOME
key ▶ Press the menu icon
you want to use.
13
FM/AM
ENGLISH
Basic ScreenBasic Screen
Button Description
1 Mode tab Press the tab to change between FM and AM mode.
2 Preset button Displays the Preset List.
3 LIST button Displays automatically updated lists.
4 MENU button Displays List, Preset, Scan, Preset scan and Sound settings
menus.
5 Back button Moves to the previous screen.
6 Frequency Displays the current frequency.
7 Preset No. Displays the current preset number.
8 Seek down Single tap: seek down.
Long tap: fast seek down.
9 Tune down
Single tap : tune down.
Long tap: tune down until the button is released and
plays the current frequency.
10 Tune up
Single tap : tune up.
Long tap: tune up until the button is released and plays
the current frequency.
11 Seek up Single tap: seek up.
Long tap: fast seek up.
12 Frequency bar Use the tap to move to the desired frequency.
13 List Displays automatically updated lists.
14 Preset Displays saved presets for user selection.
15 Scan Plays frequencies with superior reception for 3 seconds
each.
16 Preset Scan Plays frequencies saved to presets for 3 seconds and
moves to the next saved frequency.
17 Sound settings Sets sound related settings.
2 31 4 5
108 9 11
7
6
12
13
14
15
16
17
14
FM/AM
Listening to FM/AM radio
Press the
RADIO
key to change the mode in
order of FM ▶ AM ▶ FM .
Auto tuning
Press the
∨
SEEK
,
∧
TRACK
key or press the
l<<
>>l
button to automatically search for
frequencies.
Manual tuning
Turn the TUNE / ENTER knob or press the
<<
>>
button to manually select the frequency.
The stations move up and down step by step.
Press or drag the frequency bar to search for fre-
quencies that you want.
Selecting Presets
Press the
MENU
button ▶ Press the
Preset
button. From the presets, select the frequency
you want to listen to.
Selecting Lists
Press the
MENU
button
▶
Press the
List
but-
ton.
From the lists, select the frequency you want to
listen to.
FM lists are automatically updated.
AM lists are manually updated by pressing ( ).
15
FM/AM
ENGLISH
Saving Radio Frequency
Saving Manually
After selecting frequency ▶ Press the but-
ton ▶ Press the
+ Add to Preset
.
Using Preset Menu
Press and hold the preset list you want to edit.
Button Description
1 Tune listens to frequency selected.
2 Save overwrites frequency listening
to currently.
3 Delete deletes frequency.
NOTE
• Press the button ▶ Press the
MENU
button▶ Press the
Delete all
to delete entire list
of presets.
Scan
Scanning Radio Frequency
Press the
MENU
button ▶ Press the
Scan
.
Starting from the current frequency, frequencies
with superior reception are scanned for 3 sec-
onds and the previous frequency is restored.
Scanning Preset frequency
Press the
MENU
button ▶ Press the
Preset Scan
.
Plays frequencies saved to presets for 3 seconds
and moves to the next saved frequency.
NOTE
• When the scan is operating, pressing the controller will
stop the function and return to the stopped station.
Sound settings
Press the
MENU
button ▶ Press the
Sound settings
.
For details, refer to the “Sound” on the page 42.
1
2
3
16
USB
About USB
Connect the USB device after turning on the
engine. The USB device may become damaged
if it is already connected when the ignition is
turned on.
•
•Files that are not standard format files will not
be played.
•
•For MP3/WMA files, only music files with com-
pression rates between 8 Kbps ~ 320 Kbps
can be played.
•
•Heed caution to static electricity when con-
necting/disconnecting external USB devices.
•
•Encoded MP3 Players will not be recognized
when connected as an external device.
•
•When connecting an external USB device, the
device may not properly recognize the USB is
in some states.
•
•Only USB devices formatted as FAT 12/16/32
are supported, and NTFS file system is not
supported.
•
•Some USB devices may not be supported due
to compatibility issues.
•
•Avoid contact between the USB connector
with bodily parts/foreign objects.
•
•Repeated connecting/disconnecting of USB
devices within short periods of time may
result in product malfunction.
•
•Insert USB device after starting the car. If the
car is started while USB device is inserted, it
may damage USB device.
•
•The amount of time required to recognize the
external USB device may differ depending
on the type, size, or file formats stored on the
USB. Such differences in required time are not
indications of malfunction.
•
•The device may not recognize the USB device
if separately purchased USB hubs and exten-
sion cables are being used. Connect the USB
directly with the multimedia terminal of the
vehicle.
•
•When application programs are installed to
specific USBs, files may not properly play.
•
•The device may not operate normally if MP3
Players, cellular phones, digital cameras, or
other electronic devices (USB devices not rec-
ognized as portable disk drives) are connected
with the device.
•
•Charging through the USB may not work for
some mobile devices.
•
•The device may not support normal opera-
tion when using a USB memory type besides
Metal Cover Type USB Memory.
•
•The device may not support normal operation
when using formats such as HDD Type, CF, or
SD Memory.
•
•The device will not support files locked by
DRM (Digital Rights Management).
•
•USB memory sticks used by connecting an
Adaptor (SD Type or CF Type) may not be
properly recognized.
17
USB Music
ENGLISH
Playing USB Music
Once a USB is connected, USB Music mode will
operate automatically.
Press the
HOME
key ▶ Press the
Media
button ▶ Press
USB Music
button ▶Press the
Play button to play USB music.
NOTE
• If the USB is not connected, or there is no media file
in USB then the USB media button will be disabled.
Searching USB Music Files
While playing ▶ Press the
∨
SEEK
,
∧
TRACK
key or the
l<<
>>l
button to play the previ-
ous/next file.
•
•Pressing and holding the
∨
SEEK
,
∧
TRACK
key or the
l<<
>>l
button will rewind or
fast forward the current file.
•
•While the
∨
SEEK
,
∧
TRACK
key or the
l<<
>>l
button is being pressed, the track
will rewind or fast-forward at high speeds.
Once the key is released, the USB Music will
begin playing at normal speed.
NOTE
• Turn the TUNE / ENTER knob to select the previous/
next file. This key will not rewind or fast-forward the
file.
Repeat
Press the button.
Each time the button is pressed, the option is
changed from Repeat Folder( ) ▶ Repeat
One( ) ▶Off(Repeat All( )).
Shuffle
Press the button.
Each time the button is pressed, the option is
changed from Shuffle All( ) ▶ Shuffle Folder
( ) ▶ Off( ).
Scan All
Press the
MENU
button ▶ Press the
Options
▶ Press the
Scan All
to scan files within the
USB in random order.
Scan Folder
Press the
MENU
button ▶ Press the
Options
▶
Press the
Scan Folder
to search files within the
current folder.
18
USB Music
Album Cover view
Press the button ▶ Press the
<
>
button
to search desired album.
List
Press the
MENU
button ▶ Press the
List
but-
ton to display USB Music list screen.
It is possible to search by Folder, Song, Album
and Artist.
Sound settings
Press the
MENU
button ▶ Press the
Options
▶ Press the
Sound settings
.
For details, refer to the “Sound” on the page 42.
19
USB Video
ENGLISH
Playing USB Video
Once a USB is connected, USB Video mode will
operate automatically.
Press the
HOME
key ▶ Press the
MEDIA
button ▶ Press
USB Video
button ▶ Press the
Play button to play USB Video.
NOTE
• If the USB is not connected, or there is no media file
in USB then the USB media button will be disabled.
Searching USB Video Files
While playing ▶ Press the
∨
SEEK
,
∧
TRACK
key or
l<<
>>l
button to play the previous/
next file.
•
•Pressing and holding the
∨
SEEK
,
∧
TRACK
key or
l<<
>>l
button will rewind or fast
forward the current file.
•
•While the
∨
SEEK
,
∧
TRACK
key or
l<<
>>l
button is being pressed, the track will
rewind or fast-forward at high speeds. Once
the key is released, the USB Video will begin
playing at normal speed.
NOTE
• Turn the
TUNE / ENTER knob
to select the previous/
next file. This key will not rewind or fast-forward the
file.
Repeat
Press the button.
Each time the button is pressed, the option is
changed from Repeat Folder( ) ▶ Repeat
One( ) ▶Off(Repeat All( ).
Shuffle
Press the button.
Each time the button is pressed, the option is
changed from Shuffle All( ) ▶ Shuffle Folder
( ) ▶ Off( ) .
20
USB Video
List
Press the
MENU
button ▶ Press the
List
but-
ton to display USB Video list screen.
It is possible to search by Folder and Videos.
Caption
Press the
MENU
button ▶ Press the
Caption
button to display caption on USB Video screen.
Display settings
Press the
MENU
button
▶ Press the
Display settings
.
Press the
Reset
button to initialize the settings.
Press the button to set “Brightness” and
“Dimming mode”.
For details, refer to the “Display” on the page 43.
Sound settings
Press the
MENU
button
▶ Press the
Sound settings
.
For details, refer to the “Sound” on the page 42.
NOTE
• USB Video is not available while driving.
(Because of traffic regulations, videos is only available
when your vehicle is parked.)
21
USB Photo
ENGLISH
Viewing USB Photo
Press the
HOME
key ▶ Press the
Media
button ▶ Press
USB Photo
button ▶ Press the
desired photo in List screen.
NOTE
• If the USB is not connected, or there is no media file
in USB then the USB media button will be disabled.
Switching to menu screen or full
screen
Press the photo to view with full screen.
Press the photo once more to return to the
menu screen.
NOTE
• In full screen, images can be zoomed in/out by up
to 300%.
• Press to move to the List screen.
Searching USB Image Files
Press the
l<<
>>l
button or turn the
TUNE / ENTER knob to view the previous/next
image.
Press to view the list of USB photos.
Rotating / Slide show
Press the buttons to rotate image.
Press the button to view slide show.
NOTE
• Press to move to the previous screen.
22
USB Photo
Using the Menu Buttons
Press the
MENU
button to set Slide show, Slide
time and Display settings menus.
Slideshow interval
Press the
MENU
button ▶ Press the
Slide time
button.
Slide show intervals can be set at
5 sec
,
10 sec
,
20 sec
, or
30 sec
intervals.
NOTE
• Slideshow is not available while driving.
(Because of traffic regulations, image is only
available when your vehicle is parked.)
Display settings
Press the
MENU
button ▶ Press the
Display settings
button.
For details, refer to the “Display” on the page 43.
23
iPod® Music
ENGLISH
About iPod®
iPod® is a registered trademark of Apple Inc.
•
•Some iPod®s with unsupported communica-
tion protocols may not properly operate with
the system.
•
•If the iPod® malfunctions due to an iPod®
device defect, reset the iPod® and try again.
(To learn more, refer to your iPod® manual.)
•
•During ACC ON state, connecting the iPod®
through the iPod® cable (The cable that is
supplied when purchasing iPod®/iPhone
product.) will charge the iPod® through the
system.
•
•The use of genuine iPod® cables supplied
by Apple is recommended. (The use of other
products may result in noise or abnormal
operation.)
•
•Within iPhones, streaming audio and iPod®
control may occasionally conflict. If problems
persist, remove the iPhone and connect again.
•
•Use iPod® with complete synchronization
to iTunes. Unauthorized song addition may
cause abnormal operation.
•
•If iPod® and Bluetooth® are connected simul-
taneously with the same iPhone, you cannot
use Bluetooth® audio function.
•
•If iPod® touch or iPhone is used, iOS4.2 or a
later version is recommended.
24
iPod® Music
Playing iPod® Music
Once a iPod® is connected, iPod® Music mode
will operate automatically.
Press the
HOME
key ▶ Press the
Media
button ▶ Press
iPod Music
button.
•
•Press the
▶
button to play files saved within
the iPod® device.
•
•Press the
ll
button to pause the file.
NOTE
• If the iPod® is not connected, or there is no media
file in iPod® then the iPod® Music button will be
disabled.
Searching iPod® Music Files
You can play the previous or next file.
For details, refer to the page 17.
Using the Menu Buttons
Press the
MENU
button to set List and options
menus.
For details, refer to the “List” on the page 18.
Setting audiobook playback speed
Setting the playback speed only affects audio
books purchased from the iTunes store or
audible.com.
For details about iPod®, refer to the iPod® User
Guide.
Press the
MENU
button ▶ Press the
Options
▶
Press the
Audiobook
.
Sound settings
Press the
MENU
button ▶ Press the
Options
▶
Press the
Sound settings
.
For details, refer to the “Sound” on the page 42.
25
AUX
ENGLISH
Playing an AUX source
If an external device connector is connected
with the AUX terminal, then AUX mode will auto-
matically operate.
Press the
HOME
key ▶ Press the
Media
button ▶ Press the
AUX
button to play aux-
iliary device while a different source is playing.
Using the Menu Buttons
Press the
MENU
button to set Sound.
For details, refer to the “Sound” on the page 42.
26
Bluetooth® Audio
Before playing the
Bluetooth® audio
•
•Music saved in the mobile phone can be played
in the car through Bluetooth® audio streaming.
•
•Bluetooth® audio can be played only when a
Bluetooth® phone or Bluetooth® audio device
has been connected. To play Bluetooth® audio,
connect the Bluetooth® phone to the car
system. For more information on connecting
Bluetooth®, please refer to the user’s manual
Bluetooth® Connection on page 28.
•
•If Bluetooth® is disconnected while playing
Bluetooth® audio, the audio stream will be inter-
rupted.
•
•The audio streaming function may not be sup-
ported in some mobile phones. Only one func-
tion can be used at a time, either the Bluetooth®
handsfree or the Bluetooth® audio function.
For example, if you convert to the Bluetooth®
handsfree while playing Bluetooth® audio, the
music stream is interrupted.
•
•Playing music from the car is not possible when
there are no music files saved in the mobile
phone.
Playing Bluetooth® audio
Press the
HOME
key ▶ Press the
Media
button ▶ Press the
Bluetooth Audio
button.
•
•Press the
▶
button to play files saved within
the Bluetooth® phone.
•
•Press the
ll
button to pause the file.
Searching Bluetooth® audio Files
You can play the previous or next file.
For details, refer to the page 17.
NOTE
• The title/artist info may not be supported in some
mobile phones. When it is not supported, only the
symbol will be displayed.
• The play/pause feature may operate differently
depending on the mobile phone.
Using the Menu Buttons
Press the
MENU
button to set List and Sound
settings menus.
For details, refer to the “Sound” on the page 42.
27
Bluetooth® Wireless Technology
ENGLISH
Before Using the Bluetooth®
Handsfree
What is Bluetooth®
Wireless Technology?
•
•Bluetooth® Wireless Technology refers to a
short-distance wireless networking technol-
ogy which uses a 2.45GHz frequency to con-
nect various devices within a certain distance.
•
•Supported within PCs, external devices,
Bluetooth® phones, PDAs, various electronic
devices, and automotive environments,
Bluetooth® Wireless Technology to be trans-
mitted at high speeds without having to use a
connector cable.
•
•Bluetooth® Handsfree refers to a device which
allows the user to conveniently make phone
calls with Bluetooth® mobile phones through
the Multimedia system.
•
•The Bluetooth® Handsfree feature may not be
supported in some mobile phones.
Precautions for Safe Driving
•
•Bluetooth® Handsfree is a feature that enables
drivers to practice safe driving. Connecting the
head unit with a Bluetooth® phone allows the
user to conveniently make calls, receive calls,
and manage the phone book. Before using
Bluetooth® Wireless Technology, carefully read
the contents of this user’s manual.
•
•Excessive use or operations while driving may
lead to negligent driving practices and be the
cause of accidents. Do not operate the device
excessively while driving.
•
•Viewing the screen for prolonged periods of
time is dangerous and may lead to accidents.
When driving, view the screen only for short
periods of time.
Cautions upon Connecting
Bluetooth® Phone
•
•Before connecting the head unit with the
mobile phone, check to see that the mobile
phone supports Bluetooth® features.
•
•If you do not want automatic connection with
your Bluetooth® device, turn the Bluetooth®
feature off of the Bluetooth® device.
•
•Park the vehicle when connecting the head
unit with the mobile phone.
•
•Some Bluetooth® features may occasionally
not operate properly depending on the firm-
ware version of your mobile phone. If such
features can be operated after receiving a S/W
upgrade from your mobile phone manufac-
turer, unpair all devices and pair again before
use.
28
Bluetooth® Connection
When no Phones Have Been
Paired
Press the key on the steering wheel or
press the
PHONE
key ▶ Press the
OK
.
Pairing from the Bluetooth® Device
Press the
MENU
button ▶ Press the
Add New
.
From the Bluetooth® device, search for the car
name and pair the device. When searching from
the Bluetooth® device, the car name is HYUNDAI
MOTORS and the default passkey is ‘0000’.
29
Bluetooth® Connection
ENGLISH
When a Phone is Already Paired
Press the key on the steering wheel or
press the
PHONE
key ▶ Press the
OK
▶
Press the phone name to pair ▶ Press the
YES
.
NOTE
• When a Bluetooth® device is connected, a new
device cannot be paired. If you want to pair a new
phone, first disconnect the connected Bluetooth®
device.
When your phone is
connected
Press the key on the steering wheel or
press the
PHONE
key on the head unit to dis-
play the following screen.
NOTE
• Once Bluetooth® connection is successful, the
name of the connected mobile phone will be
displayed on the phone screen and Bluetooth®
handsfree functions will be ready to be operated.
• Some functions may not be supported due to
limited Bluetooth® compatibility between the car
system and mobile phone.
30
Bluetooth® Phone
Making/Answering Calls
Calling by Dialing a Number
Enter number on the Dial Pad ▶ Press the
button or the key on the steer-
ing wheel.
NOTE
• If you press the wrong number, press to
delete one digit of the entered number. Press and
hold the dial pad 0 "+" to enter a "+".
• Press the button to search phone numbers.
For detail, refer to the “Searching for contacts “ on
the page 32.
Making a Call from Speed Dial
Enter the 1 or 2 digit speed dial number with the
Dial Pad ▶ Press and hold the last number.
Calling through Redial
Press and hold the button or Press the
key on the steering wheel twice.
NOTE
• Redialing is not possible when there is no dialed
calls list.
Answering a Call
Incoming call notice ▶ Press the
button or the key on the
steering wheel.
Rejecting a Call
Incoming call notice ▶ Press the
button or the key on the
steering wheel.
31
Bluetooth® Phone
ENGLISH
Operating Menus during a
Call
Button Description
1 Ends a call.
2 Turns the Mic On/Off.
3 Switches a voice call from the car
handsfree to the mobile phone.
4 Display dial pad screen for enter-
ing ARS numbers.
5 3 Way call.
Ending a Call
While on a call ▶ Press the button or
the key on the steering wheel.
Switching Call to Bluetooth® Phone
During handsfree call ▶ Press the but-
ton or press and hold the key on the
steering wheel.
During call on mobile phone ▶ Press the
button or press and hold the
key on the steering wheel.
Making 3 way call
While on a call ▶ Press the button. ▶
Press phone number you want to make a call ▶
Press the button.
1 2 3 4 5
32
Bluetooth® Phone
Using the Menu Buttons
In Phone screen ▶ Press the
MENU
button to
use Contacts , Calling list , Favorites , Bluetooth®
settings.
Contacts
Updating Mobile Phone Contacts
Up to 5,000 mobile phone contacts can be
updated.
In Contacts screen ▶ Press the
MENU
button
▶ Press the
Update
.
The contacts are deleted and the contacts
of the connected phone is updated.
Making a call from contacts
In Contacts screen ▶ Press the contact you want
to call.
Searching for contacts
In Contacts screen ▶ Press the
MENU
button ▶
Press the
Search
▶ Enter the name ▶ Press the
OK
▶ Press the contact you want to call.
33
Bluetooth® Phone
ENGLISH
Calling list
Viewing Calling lists
In Phone screen ▶ Press the
MENU
button ▶
Press the
Calling lists
.
Press the
MENU
button on Calling list screen.
Button Description
1 All Displays all calling list.
2 Missed Displays the missed calling list.
3 Received Displays the incoming calling
list.
4 Dialed Displays the outgoing calling
list.
NOTE
• The calling list may not be saved in some mobile
phones.
Favourites
Calling Favourites
In Phone screen ▶ Press the
MENU
button ▶
Press the
Favourites
▶ Press the Favourite you
want to call.
Saving to Favourite
In Phone screen ▶ Press the
Add to favourites
button.
In Contacts screen or Calling list screen ▶ Press
and hold the contact you want to save ▶ Press
the
Save to Favourites
.
1
2
3
4
34
Bluetooth® Phone
Deleting Favourites
In Favourites screen ▶ Press the
MENU
button ▶
Press the
Delete all
▶ Press the
OK
.
In Favourites screen ▶ Press and hold the favourite
you want to delete ▶Press the
Delete
▶ Press
the
OK
.
Changing the Favourites name
In Favourites screen ▶ Press and hold the favour-
ite you want to change ▶ Press the
Rename
▶
Enter the name ▶ Press the
OK
.
Bluetooth® settings
In Phone screen ▶ Press the
MENU
button ▶
Press the
Bluetooth settings
.
For details, refer to the “Bluetooth®” on the page
44.
35
Android Auto™
ENGLISH
About Android Auto™
Android Auto™ brings the most useful apps from
your phone to your vehicle´s screen, optimized
for easy glancing and control while driving. You
will be able to control things like navigation,
maps, calls, text messages, and music, all from
your vehicle´s screen.
To learn about Android Auto™ and its features,
visit the Android website at http://www.android.
com/auto/
NOTE
• You can verify countries that support Android Auto
through the website. This feature is unavailable in
non-supported countries.
• Availability in supported countries may change
without prior notice.
Precautions
•
•Android Auto™ extends the Android platform
from your mobile phone into the car. When
users connect their handheld devices running
Android 5.0 or higher to a compatible vehicle,
the Android Auto™ user interface provides a
car-optimized Android experience on the car
screen. Users may interact with compatible
apps and services through voice actions and
the car input controls.
•
•Android Auto™ will be unavailable if the
version of communication protocol is not
supported or your mobile phone is unable to
be recognized due to a shutdown caused by a
failure or defect in the device.
•
•If you repeatedly connect and disconnect the
USB cable on the device in a short period of
time, your phone may malfunction. This can
also cause a device failure.
•
•With your mobile phone connected, Android
Auto™ will appear on the car display. Available
functions and operations may differ depend-
ing on the company model.
•
•Make sure the vehicle gear is in park and that
you have time to set up Android Auto™ before
driving and that you have time to set up
Android Auto™.
•
•Android Auto™ features may operate differ-
ently than on your phone.
•
•Message and data charges may apply when
using Android Auto™. Please check with your
mobile phone company.
•
•Android Auto™ relies on the performance of
your phone. If you experience performance
issues:
- Close all apps and then restart them
- Disconnect and then reconnect your phone
•
•Using the micro USB cable that was provided
with your phone is recommended.
Android Auto help:
support.google.com/androidauto
What you need?
1. An Android phone running Android 5.0
(Lollipop) or higher with a data plan.
2. A vehicle that’s compatible with Android
Auto™.
3. A USB cable.
36
Android Auto™
※ The screens shown in this manual may differ from the
actual screens of Android phone.
Before starting Android Auto™
Installing the Android Auto™
Application
Install Android Auto™ Application by following
below procedure.
Setting the system
Before connecting your mobile phone, check
whether Android Auto™ is set to be used in
Setup ▶
Connectivity
.
Check the
Android Auto Enabled
box ▶ Press
OK
to turn the feature on.
NOTE
• The use of Android Auto™ can generate charges
from your service provider for the use of applications
that consume data.
• Android Auto™ is a registered trademark of Google,
Inc.
• The design and the specifications of this guide is
subject to change without notice.
• The screens that are shown in this manual can be
different to the real screens of the product.
Starting mode
1. Unlock your mobile phone screen.
2. Connect your mobile phone to your vehicle
using an original USB cable.
3. Touch [Accept] to turn on notifications in
Android Auto™.
4. Updating mobile applications such as Google
Maps is recommended.
5. Review the Terms & Conditions from both your
mobile phone and vehicle’s device, and then
ACCEPT to use Android Auto™. (It is required
only the first time that the application is used.)
1. Accept screen 2. Permission for
apps
3. Permission for
mobile phone fea-
tures
※ The screens shown in this manual may differ from the
actual screens of Android phone.
37
Android Auto™
ENGLISH
NOTE
• Using the USB cable that was provided with your
phone is recommended.
• The Functionality and performance of Audio-Video
system of the vehicle may vary depending on the
brand, model, and specifications of connected
smart phones.
• Your phone might ask you to download or update
certain apps, like Google Maps.
• If you're running Android 6.0 (Marshmallow) or
higher, Bluetooth will be turned on automatically
when Android Auto™ is active.
Home Screen
No Description
1Microphone
2Navigation suggestions and recent places
3Reminders, messages, calls, and other
alerts
4Maps and navigation
5Calls and messages
6Home screen
7Music and audio
8Exit Android Auto
In smart phone
In vehicle’s device
1
4
2
3
65 7 8
38
Android Auto™
Talk to Google
1. Press the microphone [ ] button on the
display or press and hold the [ ] Call key
on your steering wheel until you hear the
beep.
2. Say commands you want to use. Then you can
do things like send or reply to a text, search
for a location, make a call, or play your music.
Return to your car’s Media
screen
Press the [ ] button on the display.
Return to the Android Auto
Home screen
Press the [ ] button on the display.
NOTE
• Wireless signal reception may vary, reception
dependent features may temporarily pause then
resume when signal strength has been regained.
39
Apple CarPlay
ENGLISH
About Apple CarPlay
•
•CarPlay puts key iPhone apps - the ones you
want to use while driving - on your vehicle’s
built-in display. With CarPlay, you can get
turn-by-turn directions, make phone calls,
exchange text messages, listen to music, and
more. Apple CarPlay is available on select
automobiles navigation systems, and works
with iPhone 5 or higher with iOS 7.1 or higher.
•
•You can operate CarPlay using your vehicle’s
built-in controls - a touchscreen, a rotary knob
controller, or both. To learn how to operate
your display, refer to the user guide that came
with your vehicle. Or just use Siri voice control
to tell CarPlay what you want. In fact, Siri often
steps in automatically to help you, depending
on the app you’re using.
•
•For more information & troubleshooting, refer to
the iPhone manual or visit the Apple website.
Precautions
•
•Apple CarPlay is unavailable if the version of
communication protocol is not supported or
your phone cannot be recognized due to a
shutdown caused by a failure or defect in the
device itself.
•
•Your phone may not be recognized if its bat-
tery is low. Charge your phone then try again.
•
•If your phone is shut down due to a defect
in the device itself, reset your phone and try
again.
•
•If you repeatedly connect and disconnect the
USB cable on the device in a short period of
time, your phone may malfunction. This can
also cause a device failure.
•
•The device recognition time may differ
depending on the device type and firmware/
OS version.
•
•When using this feature, the use of a ded-
icated cable is recommended. (Using a
non-genuine product may cause noise or
malfunction.)
•
•Apple CarPlay may not operate normally due
to mobile phone issues.
What you need?
1. An iPhone5 or higher.
2. A car that’s compatible with iPhone.
3. A Genuine USB cable from Apple.
Before starting Apple CarPlay
Setting Siri on the iPhone
Siri must be enabled on your iPhone. If Siri is
turned off, a notice will be displayed.
Go to Settings ▶ General ▶ Siri ▶ Turn on Siri.
Setting the system
Before connecting your mobile phone, check
whether Apple CarPlay is set to be used in Setup
▶
Connectivity
▶
iOS
.
Check
Apple CarPlay
.
40
Apple CarPlay
Starting mode
Connect your phone to your car using a USB
cable. The CarPlay Home screen will be displayed
automatically.
When in a different mode, press Media ▶ Apple
CarPlay.
Home Screen
No Description
1Return to a call, or to turn-by-turn
directions
2Home button
3View current audio source
4Return to your car’s Home screen
NOTE
• Map and Turn by Turn features are available only
in countries supported by Apple (check link for
information on supported countries). (http://www.
apple.com/ios/feature-availability/#applecarplayap
plecarplay)
• The position of the Home button changes
according to driver seat location.
1
2
3 4
41
Apple CarPlay
ENGLISH
Speak to Siri
Press and hold the button on the steering
wheel, or touch and hold the Home button on
the CarPlay Home screen, until Siri beeps.
Then say commands you want to use. Then you
can do things like send or reply to a text, search
for a location, make a call, or play your music.
Open an app
Tap the app on the touchscreen.
Return to the CarPlay Home
screen
Tap the Home button on the touchscreen.
Return to your car’s screen
Tap the car logo. Or press the
HOME
key or
the desired key on the device.
View additional apps
If you have more than eight apps, some apps
may appear on another page of the Home
screen. Swipe left on the touchscreen.
Return to a phone call or to
turn-by-turn directions
Tap the icon in the upper-left corner of the
touchscreen.
View and control the current
audio source
Tap Now Playing to see the current audio app.
42
Setup
Starting mode
Press the
SETUP
key to display the Setup
screen.
Sound
This menu is used to adjust the sound effects
for the whole system.
Press the
SETUP
key ▶ Press the
Sound
button.
Sound Balance
In Sound settings screen ▶ Press the
Sound Balance
▶ Set the desired sound balance.
Use the
▲
,
▼
, , and buttons to adjust
settings.
Press the
Reset
to restore sound to the center position.
Variable EQ
In Sound settings screen ▶ Press the
Variable EQ
▶ Set the desired mode.
Volume setting
In Sound settings screen ▶ Press the
Volume setting
▶ Set the desired volume.
Button Description
1 Phone Controls the volume related to
phone.
2 Start up Controls the audio volume
when starting the system.
Use the
▲
,
▼
and buttons to adjust set-
tings.
Press the
Reset
to initialize the settings.
1
2
43
Setup
ENGLISH
Beep
This menu allows you to play a beep sound
whenever you operate the touch screen.
In Sound settings screen ▶ Press the
Beep
to
turn on/off.
Display
This menu allows you to adjust the brightness
and set the dimming mode for the whole sys-
tem.
Press the
SETUP
key ▶ Press the
Display
.
Brightness
In Display settings screen ▶ Press the
Brightness
▶ Set the desired brightness.
Use the
▲
,
▼
and buttons to adjust set-
tings.
Press the
Reset
to initialize the settings.
44
Setup
Dimming mode
This menu allows you to set the brightness
according to mode changes.
In Display settings screen ▶ Press the
Dimming mode
▶ Set the desired mode.
Button Description
1 Auto
Adjusts the brightness
automatically according to sur-
rounding brightness.
2 Day Brightness level always set on
high.
3 Night Brightness level always set on
low.
Bluetooth® settings
This menu allow you to set Bluetooth® settings.
Press the
SETUP
key ▶ Press the
Bluetooth
.
Bluetooth® connection
This menu allow you to manage the Bluetooth®
device list, such as pairing, connecting or delet-
ing Bluetooth® devices.
In Bluetooth® settings screen ▶ Press the
Bluetooth connection
▶ Set the desired settings.
Press and hold the phone name to disconnect/
delete the device.
1
2
3
45
Setup
ENGLISH
Ringtone
The configured ringtone is played through the
vehicle speakers when you receive a call.
In Bluetooth® settings screen ▶ Press the
Ringtone
▶ Set the desired ringtone.
Change passkey
This feature allows you to change the passkey
used for Bluetooth® device authentication.
In Bluetooth® settings screen ▶ Press the
Change passkey
▶ Enter the passkey.
NOTE
• The default passkey is 0000.
Changing device name
In Bluetooth® settings screen ▶ Press the
Change device name
▶ Enter the name.
NOTE
• The default device name is HYUNDAI MOTORS.
46
Setup
Auto Connection Priority
The Bluetooth® device will automatically be con-
nected according to the option set when the car
ignition is turned on.
In Bluetooth® settings screen ▶ Press the
Auto Connections Priority
▶ Set the desired settings.
NOTE
• If you press
No Phone Selected
, the most recently
connected Bluetooth® phone will connect
automatically.
System
Press the
SETUP
key ▶ Press the
System
button.
Language
This menu allows you to set the language of the
system.
In System settings screen ▶ Press the
Language
▶ Press the desired language.
Clock
In System settings screen ▶ Press the
Clock
▶
Set the desired settings.
Button Description
1 Time
setting Sets the current time.
2 Format Converts the digital clock
display to 12 or 24 hours.
3 Standby
screen
Turns on/off the screen
displayed when the system
power is turned off.
4 Standby
screen
view
Sets the type of Standby
screen.
1
2
3
4
47
Setup
ENGLISH
Factory settings
This menu allows you to reset settings specified
by the user.
In System settings screen ▶ Press the
Factory settings
▶ Press the desired item ▶
Press the ▶ Press the
YES
.
Connectivity
This menu allows you to set the car connectivity
of your system.
In System settings screen ▶ Press the
Connectivity
▶ Press the desired settings.
48
Specification
USB MP3 Specification
Category Description
MP3 File Specification Response Specification: MPEG1 AUDIO
LAYER3
Recommended Bitrate and
Sampling Frequency
Response Sampling Frequency : 32, 44.1, 48
(KHz)
Response Bitrate: 32, 40, 48, 56, 64, 80, 96,
112, 128, 160, 192 ,224 ,256 ,320 (Kbps)
ID3 TAG ID3 v1.1 and ID3 v2.x TAG
Detailed Specification
•
•Max Directory Layers: 15 layers
•
•Max length of folder names and file
names: 255Bytes
•
•Characters supported for folder/file
names: English, Español and numbers
•
•Max number of files recognized from
one USB device: 5000
Video and Image Specification
Category Description
File Format AVI(DivX), MPEG
Image Format jpg, gif, bmp, png
Extensions avi, divx, mpg, mpeg, mp4, wmv
Supported Image Resolution Max 4000x3000
Supported Image File Size Max 4 Mbytes
Supported image zoom in/out Max 300%
Video Codec MPEG4-ASP, MPEG4-AVC(H.264), AVS, VP8
Video Resolution
1920 x 1080
(WMV 9: Max 8Mbps, 1280x720,
WMV 8: 640x480)
Audio Codec MP3, OGG, WMA …
(AC3 not Support)
Subtitles SMI
Unsupported files
•
•Files not compatible with supported
specifications
•
•Modified files (files with modified file
formats)
•
•Transformed files (example: AVI files
encoded with WMV video codec)
•
•Files without indexes
49
Trouble shooting
ENGLISH
1. Errors which occur during the operation or installation of the device may be mistaken as a malfunction of the actual device.
2. If you are having problems with the device, try the suggestions listed below.
3. If the problems persist, contact your dealer
Problem Possible Cause
There are small red, blue, or green dots on the
screen
Because the LCD is manufactured with technology requiring high point density, a pixel or lighting deficiency may
occur within 0.01% of total pixels.
The sound or image is not working •
•Has the Switch for the vehicle been turned to [ACC] or [ON]?
•
•Has the SYSTEM been turned OFF?
The screen is being displayed but sound is not
working
•
•Has the volume been set to a low level?
•
•Has the volume been muted?
When the power is turned on, the corners of the
screen are dark
•
•The display appearing somewhat dark after prolonged periods of use is normal with LCD panels. It is not a
malfunction.
•
•If the screen is very dark, contact your nearest dealer for assistance.
Sound is working from only one speaker Are the positions of Fader or Balance sound controls adjusted to only one side?
Sound does not work in AUX mode Are the audio connector jacks fully inserted into the AUX terminal?
The external device is not working Is the external device connected with a standard connector cable?
When turning power on, the most recent mode
screen is not displayed
Within modes that play files by reading external sources, such as USB, iPod®, or Bluetooth® streaming mode, the
most recently played mode screen prior to turning off power may not properly load.
•
•If the corresponding device is not connected, the mode operated prior to the most recent mode will operate.
•
•If the previous mode still cannot be properly played, the mode operated prior to that will operate.
50
Trouble shooting
Problem Possible Cause Countermeasure
The power does not
turn on.
The fuse is disconnected. •
•Replace with a suitable fuse.
•
•If the fuse is disconnected again, please contact your point of purchase or service center.
Device is not properly connected. Check to see that the device has been properly connected.
The system does not
play. The vehicle battery is low. Charge the battery if the problem persists, contact your point of purchase or service center.
The image colour/ tone
quality is low.
The brightness, and contrast levels are
not set properly. Properly adjust the brightness, and contrast levels through Display Setup.
Sound does not work.
The volume level is set to the lowest
level. Adjust the volume level.
The connection is not proper. Check to see that the device has been properly connected.
The device is currently fast-forwarding,
rewinding, scanning, or playing in slow
mode.
The sound will not work when the device is fast-forwarding, rewinding, scanning, or playing
in slow mode.
51
Trouble shooting
ENGLISH
Problem Possible Cause Countermeasure
The sound or image
quality is low.
Vibration is occurring from where the
conversion switch has been installed. The sound may be short circuited and the image distorted if the device vibrates.
Image colour/tone quality is low. The device will return to normal once vibrations stop.
The USB does not work
USB memory is damaged. Please use after formatting the USB into FAT 12/16/32 format.
USB memory has been contaminated. Remove any foreign substances on the contact surface of the USB memory and multimedia
terminal.
A separately purchased USB HUB is being
used. Directly connect the USB memory with the multimedia terminal on the vehicle.
A USB extension cable is being used. Directly connect the USB memory with the multimedia terminal on the vehicle.
A USB which is not a Metal Cover Type
USB Memory is being used. Use standard USB Memory.
An HDD type, CF, SD Memory is being
used. Use standard USB Memory.
There are no music files which can be
played.
Only MP3, WMA file formats are supported. Please use only the supported music file for-
mats.
The iPod® is not rec-
ognised even though it
has been connected
There are no titles which can be played. Use iTunes to download and save MP3 files into the iPod®.
The iPod® firmware version has not been
properly updated. Use iTunes to update the firmware version and reconnect the iPod® with the device.
The iPod® device does not recognise
downloads. Reset the iPod® and reconnect with the device.
31
FCC Warning
ENGLISH
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
•
•Reorient or relocate the receiving antenna.
•
•Increase the separation between the equipment and receiver.
•
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•
•Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation.
Caution: Any changes or modifications to this device not expressly approved by the party responsible for compliance could void your authority to operate the
equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum 20 cm between the radiator and your body. This transmitter must not be collocated or oper-
ating in conjunction with any other antenna or transmitter unless authorized to do so by the FCC.
