MPOW TECHNOLOGY BMBH293B Bluetooth headset with microphone User Manual BMBH293A B2B v01 180615
MPOW TECHNOLOGY CO., LIMITED Bluetooth headset with microphone BMBH293A B2B v01 180615
15_BMBH293A UserMan
www.xmpow.com
Device and Accessories
For More Information Please Visit
Bluetooth Earphone
BMBH293A
1Instructions
2
BMBH293A Earphone
USB Charge Cable User Manual x 1
x 1
1
Next Song / Volume Up
3
Previous Song / Volume Down
5
Ear Fin
2
Micro USB Charging Port
6
Earbud
4
Ear Clip ( M Size-On Ear )
x 2 x 2 x 2
Ear Caps ( M Size-On Ear )
x 2 x 2 x 2
Next Song / Volume Up/Previous Song /
Volume Down
Press “ ” Buttons
Long Press
Short Press
Next Song
Volume Up
Press “ ” Buttons
Long Press
Short Press
Previous Song
Volume Down
Make sure the Bluetooth on the mobile device you are trying
to connect the earphones to is on.
Hold the “ ” button for 5 seconds to enter pairing mode.
The red and blue indicators will start flashing.
In your devices Bluetooth list, search for ‘MPOW X1.0’, click
on it, and your devices will pair.
The earphone will automatically power off after 5 minutes with-
out being paired to a device.
Choose “MPOW X1.0” to Connect
Range < 1M
Pairing to a Bluetooth Device
REMARK
Please make sure that the earphone is turned off before enter-
ing pairing mode.
Holding the button for 5 seconds will turn the earphone on
and enter pairing mode at the same time. If you just turn the
headphone on, it will connect to the last mobile device that
it was paired to.
Activating Voice Control / Your Devices Personal
Assistant
To activate voice control, simply hold the power button for 4
seconds, and you will hear your phone’s notification that voice
control is activated. You can now ask your personal assistant
whatever you want, from the microphone on your earphone.
1.
2.
3.
4.
Settings
Bluetooth
Bluetooth
DEVICES
MPOW X1.0 Connected
NOTE
If a call comes in while you are listening to music or stream-
ing a video, the audio / video will be paused, and you will
hear your phones ringtone through the headphone. Once
the call is ended, your entertainment will resume.
Operating the Earphone
3
Using the “ ” Buttons
Hold 3s
Hold 3s
Hold 5s
Power ON
Power OFF
Pairing Mode
Press “ ” Buttons
Short Press Answer / Hang up
Play / Pause / Answer Call / Hang Up call
Hold 1S~2S Reject an Incoming Call
/
Short Press Play / Pause
/
2
3
4
5
1
6
Charging the Earphone
Output: DC 5V
Charging
2h
0% 100%
NOTE
As with all rechargeable batteries, the charge / discharge
cycles affect the battery’s performance over time.
The earphone automatically turns OFF while charging.
You will hear a voice prompt when the battery is low, and
the red indicator will flash.
The charging temperature is 50℉-113℉.
1.
2.
3.
4.
1.
This earphone has a built-in, non-removable lithium battery.
We highly recommend that you fully charge the earphone
before the first use.
To charge, connect the charging cable to the charging port,
and then to a USB charger.
2. The light will turn red the earphone is charging.
3. Red indicator light is on all the time when charging,
and is off when fully charged. The blue indicator light
is on all the time after fully charged.
LED Behaviour
4
Work Status Indicator Light Status Voice Prompt
Power on Blinking fast in Bright
(LED) for 3 times Power on
Power off
Red indicator light is
on for 2 seconds then
all of the light off.
Power off
Pairing
Red and Bright
indicator lights flash
simultaneously
Pairing
Connected
Blue indicator light
flash once every 10
seconds
Connected
Charging
Red indicator light
is on all the time
when charging,
and is off when
fully charged. The
blue indicator light
is on all the time
after fully charged
Low battery
warning
Red indicator light
flashes 3 times Battery Low
2S
x3
x1/10S
The Bluetooth® word mark and logos are registered trade-
marks owned by Bluetooth SIG, Inc. and any use of such
marks by [ MPOW Technology，LTD ] is under license. Other
trademarks and trade names are those of their respective
owners.
Specifications
5
Operation Range
Talking Time
Playing Time
Charging Time
Charging Voltage
Standby Time
33 feet
5-6 hours
Bluetooth Standard Bluetooth 4.1
5-6 hours
2 hours
DC 5V
150 hours
NOTE
Actual play and talk times will ultimately depend on the
phone / mobile device you are using, the listening volume,
as well the frequency of the use of the different buttons
and toggling between functions.
尺寸： 60x95(mm)
材质： 128g 铜版纸 覆哑膜 双面四色印刷+专色（PANTON 2347C）
装订方式： 五折页（风琴折）
WARNING!
The product can ONLY be charged by 5V Adapter/USB Port,
otherwise it will cause heat and fire.
The BMBH293A is not a toy, please supervise your children
when using the equipment.
To avoid potential risks and protect products, please do not
charge it at a temperature lower than 50℉ or higher than
113℉.
1.
2.
3.
FCC Statement
Operation is subject to the following three conditions:
This device may not cause harmful interference.
This device must accept any interference received, includ-
ing interference that may cause undesired operation.
This device has been evaluated to meet general RF expo-
sure requirements. The device can be used in portable
exposure condition without restriction.
1.
2.
3.
NOTE
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harm-
ful interference to radio or television reception, which can
be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one
or more of the following measures
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Consult the dealer or a technician for help.
MPOW TECHNOLOGY CO.,LTD
Copyright © MPOW Inc. All rights reserved.
www.xmpow.com | support@xmpow.com
MADE IN CHINA
This device complies with Part 15 of the FCC Rules.
FCC ID: XXX-XXXXX
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
