User Manual
For
WebGate TotalPoint Electric Utility Meter
February 19, 2007
The WebGate TotalPoint Electric Utility Meter is a standard utility meter equipped with
the muNet WebGate TotalPoint radio communication module. The meter is provided
ready to install in the appropriate meter socket. No user serviceable parts are located
interior in the device. This manual shows the basic device and its installation directly
into a meter socket, and its installation in a meter collar. A cutaway view of the meter
interior is included and identifies the basic components; this is provided only as
reference if the device is opened for the purpose of calibration or resetting of the meter
register, and not as an assembly diagram as the device is provided in a completely
assembled state.
FCC Notifications:
FCC ID U2R-TPM0100
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference and (2) this
device must accept any interference received including interference that may cause
undesired operation.
Changes or modifications not expressly approved by MU Net, Inc. could void the user’s
authority to operate this equipment.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20 centimeters between the radiator and your body.
MU Net, Inc
. 03/14/07 Page 2 of 2
Figure 1 – Meter Installed into a Meter Socket
Figure 2 – Internal View
Antenna
Radio
Display Board WebGate
Board
