GENERAL VIEW

TECH. SPECIFICATION

PerformanceProcessorArm11‐500MHz

Flash4GB‐RAM128MB

3.5’’LCDTFT320x480ResistiveTP

Powerinputvoltage5VDC–2Amax

GSMFrequencybandwidth850/1900

Workingtemperature‐20°C/60°C

Internalbattery1000mAh

Dimensions/Weight100x63x14mm/110g







Quick Start Guide



CHARACTERISTICS

 GPS(GlobalPositioningSystem)

 GPRSCommunication

 Bluetooth

 FMtransmitterwithcarchargerantenna

 Loudspeaker

 Microphone

 3DAccelerometer

 MicroSDcardconnector

1.Mini–USBConnecter

2.MicroSDcardlector

3.Resetbutton

4.Speaker

5.PowerbuttonwithLEDindication

6.Alertinformationbutton

7.Up/Downbutton



8.Magnetsupport

9.Metalunit

USAGE

1.Withinternalbatterypowersupply,theLEDpowerindicationbuttonis

turnedonafter15secondsandMUNICisself‐checking.

2.ForfirstswitchonMUNIC,youneedtoanswerafewquestionstosetup

itbytappingthescreen.Thedevicemayneedafewminutestodetermine

GPSposition.

3.Toplanningaroute,youjustneedtap“Navigateto”andenterthe

address.Foryoursecurity,youshouldplantheroutebeforedriving.

4.TogetthevoiceguidingormakephonecallbyMUNIC,youneedtotap

thescreenandactivetheloudspeaker,themicrowillbeactive

automatically.

5.ToplayspokeninstructionsormusicthroughaBluetoothdeviceandFM

transmitter,youhavetoconnecttheassociatedcarchargerthenactivethe

BluetoothandFMtransmitter,atthesametimeturnontheradioofyour

car.OnceyourradiofindsMUNICandtheBluetoothconnectionis

established,thesoundwillbeplayedthroughtheradioonyourcar.

6.Changingbetweendaycolorandnightcolorcanbeautomatic,orby

tappingthemenu.

7.Toturnoffthedevices,pushthepowerbuttonfor15secondsand

confirmbytappingthescreen.

For customers in the United States



Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora

ClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsare

designedtoprovidereasonableprotectionagainstharmfulinterferenceina

residentialinstallation.Thisequipmentgeneratesusesandcanradiate

radiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe

instructions,maycauseharmfulinterferencetoradiocommunications.

However,thereisnoguaranteethatinterferencewillnotoccurina

particularinstallation.Ifthisequipmentdoescauseharmfulinterferenceto

radioortelevisionreception,whichcanbedeterminedbyturningthe

equipmentoffandon,theuserisencouragedtotrytocorrectthe

interferencebyoneormoreofthefollowingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfromthatto

whichthereceiverisconnected.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjectto

thefollowingtwoconditions:

1.Thisdevicemaynotcauseharmfulinterference.

2.Thisdevicemustacceptanyinterferencereceived,includinginterference

thatmaycauseundesiredoperation.



Caution

Exposuretoradiofrequencyradiation

TocomplywithFCCRFexposurecompliancerequirements,thisdevicemust

notbeco‐locatedoroperatinginconjunctionwithanyotherantennaor

transmitter.

PleasenotetheFMonlycanworkwithassociatedcarcharger.ThisFM

functionwillbedisablewithothercarcharger.

Note

Caution:Anychangesormodificationsmadeonthesystemnotexpressly

approvedbythemanufacturercouldvoidtheuser'sauthoritytooperate

thee

ment.

INSTALLATION

1.UsingtheAlcoholwetwipetocleantheconsolewhereyoucanto

pastethemagnetsupport.

2.Pastingthe3Msideofmagnetsupportonthecleanedconsoleand

pushingitstrongly.

3.Donottouchthemagnetduring5h,soitcanbefixedverytightly.

4.PuttingtheMUNIConthemagnetsupport.

5.ConnectingtheassociatedcarchargerforFMtransmitter

NOTE.TheFMtransmitteronlycanworkwithassociatedcarcharger.

ThisFMfunctionshouldbedisablingwithothercarcharger.

RF Exposure Requirements: 47CFR§1.1307(b)

RF Radiation Exposure Limits: 47CFR§1.1310

RF Radiation Exposure Guidelines: 47CFR§2.1091

RF warning for Mobile device:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
