43710_ User Manual_REV2
BTLE Dongle Page 1
User Manual
1.MAIN BADY
2. SETUP
a. USB Dongle Plug- in PC
b. Win8 automatically search for the driver
C. Installation is complete
d. Show “MOUS9 DONGLE”
3. ELECTRICAL CHARACTERISTICS
No Parameter Specification
1 Advanced Features Bluetooth Low Energy
2 Frequency band 2.4GHz
3 Data Rate Up to 3 Mbps
4 Demodulation mode GFSK
5 Range 10 meters in free space
6 Interface USB 2.0 (type A)
7 Antenna Printed Antenna
3. SEtUP INStRUCtIoNS
BTLE Dongle Page 2
CoNNECtING tHE MoUSE USING tHE DoNGLE
1. Plug the USB dongle into an available port
2. Turn the mouse ON
CoNNECtING to DEVICES WItH BUILt-IN BLUEtootH
SMARt
tECHNoLoGy (DoNGLE Not REqUIRED)
BLUEtootH SMARt tECHNoLoGy
Bluetooth Smart is a new, power-efficient version of Bluetooth wireless technology
and is already being used in many devices. Check with your manufacturer to see if it is
Bluetooth Smart ready. Check with your device manufacturer for support for Bluetooth
Smart mice and then follow their instructions for pairing.
TRoUBLESHootING
If your M.O.U.S.9 does not appear to be working with your device then, with it powered
on, press and hold the Magnifier and Precision Control buttons for 5 seconds until the
Blue LED starts flashing. If you wish to connect to the USB dongle then ensure that it
is connected to your computer. If you wish to connect to another device then follow
the Bluetooth pairing procedure for that device to rediscover the M.O.U.S.
FCC & IC Warning
This device complies with part 15 of the FCC Rules and Industry Canada
licence-exempt RSS standard (s).
Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2)this device must accept any interference received, including
interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void
the user’s authority to operate the equipment.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna
BTLE Dongle Page 3
or transmitter.
IC RF Exposure Statement:
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS
102 and compliance
with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and
compliance.
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce
potential radio interference
to other users, the antenna type and its gain should be so chosen that, the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication.
