Magtek Incorporated DYNASTY READER

User manual

Imatrictech Confidential
Page 1 of 6
Dynasty Product Brief
Version V1.0xxxxx
Imatric, Inc Feng Lin
Fenglin@Imatrictech.com
Imatric, Room 1918, Ruicheng Guo Ji Building, NO 71
Chaoyang Road, Chaoyang District, Beijing, PRC China
Imatrictech Confidential
Page 2 of 6
Revision History
Date Version Description Author
Nov. 3rd, 2015 V1.0 Initial release Feng Lin
Confidential Information and Copyright
This document contains confidential and proprietary information. It is intended for the use of Imatric
employees and those vendors with a current “Non-disclosure Agreement” with Imatric, Inc. No part of
this publication may be copied, distributed, stored in a retrieval system, translated into any human or
computer language, transmitted in any form or by any means without the prior written consent of Imatric,
Inc.
Imatrictech Confidential
Page 4 of 6
1. Product Brief
The Imatric Dynasty Reader Creatively provides the latest commercial mobile payment solution, integrated
with the most excellent MSR ICC and CTLS functions in payment industry.
Product Description
Standard Features
Plastic Colour Black
CPU Embedded SOC 32bits RISC processor
Memory 64KB SRAM+1MB, 384KB + 4MB Flash
Display 128x64 monochrome
Capability of reading ISO7816 1/2/3 track
Magnetic card reader bi-directional swipe
ISO 7816 T=0 & T=1
100,000 Insertions
IC card reader-writer EMV Level 1&2, ISO/IEC 14443 TypeA/ TypeB
CTLS card reader EMV Level 1
Bluetooth 2.1 + EDR & Bluetooth BLE
Communication Support for iOS, Android
Imatrictech Confidential
Page 5 of 6
1 USB Type C interface for charging and communications
Physical interface 1 POGO Pin for IOS (UART/USB) and Android (UART)
Certifications EMV Level 1 & Level 2 Certified
Power 5V, 200mA (5V, 1A For Battery Charge)
Battery Fully-integrated Li-ion cell
Beeper 82db/10cm
Working temperature: 0C ~ +40C
Environmental Relative humidity: 50% ~ 90% (non-condensing)
Cables USB-USB Type C cable for recharging the battery
API Imatric MPOS API
Optional Features/Accessories
TBD
Related Certification (Certificating Ongoing)
FCC Compliance:
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including Interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the usersauthority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
Imatrictech Confidential
Page 6 of 6
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
