Man and Machine BTM1A Wireless Mouse User Manual

Man & Machine Inc. Wireless Mouse

user manual

M
M
Mi
i
ig
g
gh
h
ht
t
ty
y
y
M
M
Mo
o
ou
u
us
s
se
e
e
B
B
Bl
l
lu
u
ue
e
et
t
to
o
oo
o
ot
t
th
h
h
The Mighty Mouse Bluetooth is a Bluetooth wireless water-resistant and
contaminant free mouse. This optical mouse is water-resistant (IP68 compliant)
and great for medical, industrial, marine applications or any environment where
dust, moisture or liquid is a concern. In addition to the left and right click
buttons, it has three buttons in the middle, which simulate a scroll wheel. Mighty
Mouse Bluetooth is based on wireless Bluetooth HID profile. It can be used with
PCs, Laptops, Tablet PCs, PDAs and Smartphones with built in Bluetooth HID
profile, or via USB Bluetooth bridge with driver (Bridge with driver sold
separately).
Weight:
4.75 ounces
Dimensions:
5.2” x 2.5” x 1.4”
Number of keys:
107 keys US layout
Operating Frequency:
2.4 GHz
Warranty period:
One-year limited warranty
System requirements:
Built in Bluetooth HID profile or USB
interface for wireless bridge with
driver.
Power:
3 volts (5 volts to charge)
Rechargeable Lithium-ion battery.
Charging Cable included.
THE MOUSE MUST BE CHARGED
FOR AT LEAST TWO HOURS
BEFORE 1ST USE
Pairing the Mighty Mouse Bluetooth:
For Built in Bluetooth HID PCs, Laptops, Tablet PCs and PDAs:
1
1.
.
Turn on the mouse by pressing the Power Button for three seconds (See the
picture on the right). Green light indicates mouse is on.
2
2.
.
Press the scroll up and down buttons together to enable mouse pairing mode. Blue
light blinks when the mouse is in pairing mode.
3
3.
.
Open the Bluetooth manager on your PC, Laptop or PDA and follow the instruction
for the software to pair the mouse.
4
4.
.
When pairing is complete the blue light stops blinking. The mouse
is now ready for
use.
Using a USB Bluetooth Bridge: (Bridge with driver sold separately)
1
1.
.
Turn on the mouse by pressing the Power Button for three seconds (See the
picture on the right). Green light indicates mouse is on.
2
2.
.
Press the scroll up and down buttons together to enable mouse pairing mode. Blue
light blinks when the mouse is in pairing mode.
3
3.
.
Connect your USB Bluetooth bridge to the USB port on your PC.
4
4.
.
Open the Bluetooth manager software for the bridge and follow the instruction to
pair the mouse.
5
5.
.
When pairing is complete the blue light stops blinking and it becomes solid green.
The mouse is now ready for use.
Battery status light:
Green light indicates battery power on.
Blinking blue light indicates pairing mode.
Red light indicates charging.
Blinking yellow light indicates low battery.
Cleaning Instructions :
Clean the mouse surface by wiping, brushing, spraying or dipping it. Use
only rags, sponges or soft bristle brushes.
The rubber can be cleaned with water, soap, alcohol, 10% bleach
solutions, and a variety of chemical disinfectants.
DO NOT use Petroleum based cleaners, Acetone, Over 10% bleach
solutions, Temperature or pressure sterilization, buffing pads or
scrubbing pads
Charging the mouse:
To charge the mouse, plug the charger cable to the charging port shown
below. It takes approximately 2 hours to fully charge the battery.
THESE INSTRUCTIONS AND RECOMMENDATIONS HAVE BEEN PREPARED TO ADVISE THE
PROPER METHODS FOR CLEANING YOUR PRODUCT. MAN & MACHINE, INC. OR THE LOCAL
DISTRIBUTOR CANNOT ASSUME ANY RESPONSIBILITY FOR THE APPLICATION OF THEM. IF
THERE ARE ANY QUESTIONS, PLEASE CONTACT PLACE OF PURCHASE OR MMI PRIOR TO
CLEANING. MAN & MACHINE DOES NOT CONSIDER THE MIGHTY MOUSE BLUETOOTH MOUSE
TO BE A MEDICAL MOUSE FOR INFECTION CONTROL PURPOSES DUE TO THE INABILITY TO
MECHANICALLY CLEAN ALL SURFACES AND AREAS ON THE MOUSE. ALL SPECIFICATIONS
SUBJECT TO CHANGE WITHOUT NOTICE.
You can email us at: info@mmimd.com
or call us at: (301) 341-4900
In Europe, contact +31-23-5450185
www.man-machine.com
Copyright Man & Machine, Inc. 2009
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC ID: X5DBTM1A
RF WARNING STATEMENT
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restiction.
