Man and Machine MOUSE C Mouse Wireless User Manual
Man & Machine Inc. C Mouse Wireless
User manual
• Operating Manual
Part functions: (See gure A.)
1 Micro USB port: Used to charge the mouse. Cover during washing or
rinsing. Cover is located on bottom of mouse.
2 Charging cable: Used to charge the mouse.
3 USB Port cover: Used to cover the Micro USB port during washing or
cleaning.
4 Power button
5 Scroll Wheel
6
LED indicator: Red: mouse battery is charging, blinking blue: mouse is trying
to pair, solid blue: mouse is in paired mode and connected to computer.
7 USB Dongle: Plugs to a computer USB port. Allows the mouse to
connect to the computer wirelessly. The USB Dongle comes in the
mouse box with each mouse.
8 USB Port cover storage space: Keep the USB Port Cover in the storage
space when it is not used to cover micro USB port.
Installation: (See gure B.)
Plug the USB Dongle (7) into a computer USB port. Each dongle is
already paired with it’s own mouse. Turn the mouse on (4). Wait for
mouse to pair automatically.
Battery charging: (See gure A.)
Connect the charging cable (2) Micro USB connector side to the mouse
and connect the USB A connector side to a 5V USB charging device
or a powered USB computer port. The Red LED (6) will stay on while
charging. The Red LED will go off when the battery is fully charged.
Remove and store the charging cable for future use.
Pairing: (See gure A.)
The mouse is already paired with the USB dongle that comes in the
mouse box. To pair the mouse with another dongle or to repair it with
the dongle it came with: turn on the mouse by pressing the power
button (4). Press the Scroll Wheel (5) and the Right Mouse Button at the
same time to put the the mouse in pairing mode. When the mouse is in
pairing mode, the Blue LED (6) will blink. Once the mouse is paired and
connected to a PC, the Blue LED will turn solid blue (6).
If you are using this mouse in combination with a Man & Machine
wireless Its Cool keyboard or Its Cool Flat keyboard, you can use one
USB dongle to connect both devices. Once you have installed the
rst one of our devices and let it pair automatically, follow the pairing
procedure to connect the other device to the same dongle.
Approved cleaning methods
• You can wipe the product with a soft cloth that is non-abrasive such
as a microber cloth, a disinfecting wipe, a soft brush similar to a paint
brush in bristle stiffness or a sponge, but not a scourer of any sort.
• You can spray the product with soap and water or an approved
disinfectant.
• You can rinse the product with soap and water or an approved
disinfectant. Before rinsing, cover port (1) with cover (3). Make sure
cover (3) is fully inserted (See gure A).
Approved disinfectants
• Chlorine based, up to 100,000 ppm (10%) bleach content
• Alcohol based
• Glutaraldehyde based
• Phenol based
• Formaldehyde based, up to 370,000 ppm (37%) formaldehyde content
• Oxidizing, such as Hydrogen Peroxide, up to 30,000 ppm (3%) content
• Quaternary Ammonium, up to 20,000 ppm (2%) content
Restrictions
• Platform: Windows
• Each dongle is paired with it’s own mouse.
• If the sensor red light at the bottom of the mouse doesn’t come on,
charge the battery following the procedure described under “Battery
charging”.
• Only clean using the cleaning methods and disinfectants described
under “Cleaning instructions” in this manual.
• Please note that the product can not be immersed in liquid.
• Always follow the instructions provided by the cleaning product
manufacturer.
• Do not use petroleum based cleaning uids nor Acetone or abrasive
cleaning aids and products.
• Do not expose the product to temperatures below 0 ºC or above 55 °C.
• Do not use temperature or pressure sterilization.
C Mouse Wireless
A
1
3
8
4
5
6
5
2
B
USB
7
Man & Machine, Inc. (“Manufacturer”) warrants to the original
purchaser (the “Customer”) that the products it manufactures
(“Product”) shall be free from defects in materials and
workmanship at the time of shipment. Manufacturer’s sole obligation
under this Warranty shall be limited to repairing or replacing with the
same or comparable item, at its option, free of charge, any product
returned to Manufacturer freight prepaid that is deemed to have
failed under Manufacturer’s warranty. Manufacturer shall have no
obligation under this Warranty or otherwise if (1) the Product has
been damaged by abuse, negligence, accident, mishandling, lightning
or ood, or other natural disasters, (2) the Product has been affected
by normal wear and tear, (3) the Product has not been operated in
accordance with its operating instructions, (4) the Product has been
altered or repaired by anyone outside Manufacturer (5) adaptations
or accessories have been made or attached to the Product which,
in Manufacturer’s sole determination, have adversely affected its
performance, safety or reliability. If a Product should malfunction or
fail during the warranty period, contact the original place of purchase
for return options. If purchased directly from Man & Machine, Inc.,
please submit a Return Material Authorization (RMA). This form
can be located on our website at http://www.man-machine.com/
returnsreplacements/. Please complete requested information and
provide a detailed description of the problem. Returned Products
must include the RMA number clearly marked on the outside of the
package. Manufacturer will not be responsible for any unnecessary
items included with any returned Product.
...............................................................................
This warranty is the exclusive warranty for any product. Manufacturer
specically disclaims any and all other warranties of any kind, express
or implied, including any warranties of tness for a particular purpose
or of merchantability. Manufacturer shall not be liable in tort, including
negligence or strict liability, and shall have no liability at all for injury
to persons or property. Manufacturer’s liability for failure to fulll its
obligation under this limited warranty or any other liability in connection
with a product shall be limited to the amount of the purchase price
received by manufacturer for the product. The remedies stated in
this limited warranty are the customer’s exclusive remedies against
manufacturer regarding any product. Under no circumstances
shall manufacturer be liable for any indirect, incidental, special or
consequential damages, including lost prots and revenues,
inconvenience or interruptions in operations, or any other commercial
or economic losses of any kind. These limitations and disclaimers
are not made by manufacturer where prohibited by law. Some states
prohibit limitations of warranties and the customer may have additional
rights in those states.
...............................................................................
All items returned for warranty repair/replacement must be sent
freight prepaid and insured to either the original place of purchase
or to the Manufacturer, referencing a valid RMA number:
USA & OTHER COUNTRIES EUROPE
Man & Machine, Inc. Man & Machine Europe
3706 West Street Tappersweg 10c
Landover, MD 20785 2031 ET Haarlem
All warranty repairs or replacements will be returned freight prepaid
by ground service to any destination within the Continental United
States and Europe. Charges for repairs/replacements shipped back
outside this region are the responsibility of the end user.
Products must be cleaned/sanitized before returning.
Returns will not
be accepted that have not been disinfected.
USA & OTHER COUNTRIES EUROPE
1 Year limited warranty 1 Year limited warranty
For current warranty information, visit our website at
http://www.man-machine.com/warranty-statement/.
• Product warranty statement
USA:
info@mmimd.com
+1 301 341 4900
Europe:
info@mmieu.com
+31 (0) 23 5450185
UK:
info@mmieu.com
+44 (0) 1937 830680
www.man-machine.com
The Windows logo is a trademark or registered
trademark of Microsoft Corporation in the
United States and/or other countries.
Copyright Man & Machine, Inc. 2017
FCC Warning:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
o Reorient or relocate the receiving antenna.
o Increase the separation between the equipment and receiver.
o Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
o Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.
