4K Ultra HD Matrixes
4K Ultra HD 600 MHz Matrixes with HDR and Audio De-Embedder
EXT-UHD-88
EXT-UHD600A-88
GEF-UHD-89-HBT2
4K Ultra HD 8x8 Matrix for HDMI
4K Ultra HD 600 MHz 8x8 Matrix
with HDR and Audio De-Embedder
4K Ultra HD 8x9 Matrix for HDMI
§Routes eight 4K sources to eight 4K displays
§Supports resolutions up to 4K Cinema-DCI (4096 x
2160 up to 60 Hz, 4:4:4), 4K Ultra HD (3860 x 2160 up
to 60 Hz, 4:4:4) with HDR, 1080p Full HD, and WUXGA
(1920x1200)
§Supports HDCP 2.2 and 1.4
§Supports HDR (High Dynamic Range) 10-bit Deep Color
at 4K 60 Hz 4:2:0 and 4K 24 Hz 4:4:4
§Built-in Audio De-Embedders break out 2 channel
analog, 2 channel PCM, and up to 5.1 channels of
Bitstream audio from each HDMI output, allowing the
audio content to be sent to external amplifiers and
music distribution systems for added impact.
§Routes eight 4K sources to nine displays
§Supports resolutions up to 4K Cinema-DCI, 4K
Ultra HD, 1080p Full HD, and 1920x1200 WUXGA
§HDCP 2.2 and 1.4 compliant
§Extends HDMI, Ethernet, RS-232 & 2-way IR up
to 330 feet
§3D pass-through
§Lip Sync pass-through
§Power Over HDBaseT (POH) powers receivers over
link cables
§IR from viewing locations to sources can be
routed along with or independent from video path
§IR remote control
§Supports up to 7.1 channels of LPCM and HBR (High
Bit Rate) digital audio including Dolby Atmos®, Dolby®
TrueHD, DTS:X™, and DTS-HD Master Audio™
§Easy-to-read, super-bright OLED front panel display
indicates routing status and IP settings
§Gefen Syner-G™ software simplifies initial IP
configuration and EDID Management
§EDID Management for rapid integration of source and
displays
§Advanced EDID Management for rapid integration
of sources and displays
§RS-232 Serial interface for use with an
automation control system
§IP control via Telnet, UDP, and the built-in web
server interface
§Gefen Syner-G™ software's Discovery and Show-
Me features simplify initial IP configuration
§Field-updatable firmware via web server interface
§Can be placed on a shelf or mounted in a
standard 19-inch wide rack
EXT-UHD600A-44
4K Ultra HD 600 MHz 4x4 Matrix
with HDR and Audio De-Embedder
§Routes four 4K sources to four 4K displays
§Supports resolutions up to 4K Cinema-DCI (4096 x
2160 up to 60 Hz, 4:4:4), 4K Ultra HD (3860 x 2160 up
to 60 Hz, 4:4:4) with HDR, 1080p Full HD, and WUXGA
(1920x1200)
§Supports HDCP 2.2 and 1.4
§Supports HDR (High Dynamic Range) 10-bit Deep Color
at 4K 60 Hz 4:2:0 and 4K 24 Hz 4:4:4
§Built-in Audio De-Embedders break out 2 channel
analog, 2 channel PCM, and up to 5.1 channels of
Bitstream audio from each HDMI output, allowing the
audio content to be sent to external amplifiers and
music distribution systems for added impact.
§4 independent scalers allow upscaling from 1080p to
4K on two outputs and downscaling from 4K to 1080p
on the other two, maximizing compatibility in a mixed-
resolution display system
§2 USB power ports for use with sources requiring a
USB power supply.
§Long Reach Power (LRP) provides 500 mA at 5V on pin
18 of HDMI outputs 1 and 2. Enables select extender
devices to be powered through their HDMI input port
§Supports up to 7.1 channels of LPCM and HBR (High
Bit Rate) digital audio including Dolby Atmos®, Dolby®
TrueHD, DTS:X™ and DTS-HD Master Audio™
§Gefen Syner-G™ software simplifies initial IP
configuration and EDID Management
§EDID Management for rapid integration of source and
displays
§Routes eight 4K Ultra HD sources to eight displays
§Supports resolutions up to 4K Cinema (DCI), 4K
Ultra HD, 1080p Full HD and 1920x1200 (WUXGA)
§HDCP 2.2 & HDCP 1.4 compliant
§Supports 12-bit Deep Color (up to 1080p HD)
§3DTV & Lip Sync pass-through
§Push button controls for Routing and Status
§Advanced EDID Management for rapid integration
§of sources and displays
§RS-232 Serial interface for remote control using a
computer or automation control system
§Supports LPCM 7.1, Dolby® TrueHD, Dolby Digital®
Plus, and DTS-HD® Master Audio™
§Supports the use of DVI sources and DVI
displays with HDMI-to-DVI adapters (not
included)
§IP control via Telnet, UDP, and the built-in web
server interface
§IR remote control
§Gefen Syner-G™ software's Discovery
and Show-Me features simplify initial IP
configuration
§Field-upgradeable firmware via web server
interface
§Can be placed on a shelf or mounted in a
standard 19-inch wide rack
NEW
NEW
3
ToolBox 4K Ultra HD Matrixes
GTB-HD4K2K-848-BLK
4K Ultra HD 8x8 Matrix for HDMI
§Routes eight 4K Ultra HD sources to eight displays
§Supports resolutions up to 4K Cinema (DCI), 4K
Ultra HD, 1080p Full HD and 1920x1200 (WUXGA)
§HDMI 2.0 & HDCP 1.4 compliant
§Supports 12-bit Deep Color (up to 1080p HD)
§3DTV & Lip Sync pass-through
§Push button controls for Routing and Status
§Advanced EDID Management
§Supports LPCM 7.1, Dolby® TrueHD, Dolby Digital®
§Field-upgradeable firmware via web
server interface
§Plus, and DTS-HD® Master Audio™
§Supports the use of DVI sources and DVI displays
with HDMI-to-DVI adapters (not included)
§RS-232 Serial interface for remote control using
a computer or automation control system
§IP control via Telnet, UDP, and the built-in web
server interface
§IR remote control
§Gefen Syner-G™ software's Discovery and Show-
Me features simplify initial IP configuration
§Surface-mountable
GTB-HD4K2K-442-BLK
4x2 Matrix for HDMI 4Kx2K
§Routes four Ultra HD sources to two
Ultra HD displays
§Supports resolutions up to Ultra HD 4K,
4K Cinema (DCI) and 1080p Full HD
§HDMI 2.0 & HDCP 1.4 compliant
§Supports 12-bit Deep Color
§3DTV & Lip Sync pass-through
§Push button controls for Routing, FST Modes,
Audio, and EDID management
§FST Technology speeds up HDCP authentication
§Advanced EDID Management
Supports LPCM 7.1, Dolby® TrueHD, Dolby Digital®
Plus, and DTS-HD® Master Audio™
§Supports the use of DVI sources and DVI displays
with HDMI-to-DVI adapters (not included)
§RS-232 Serial interface for remote control using
a computer or automation control system
§IP control via Telnet, UDP, and the built-in web
server interface
§IR remote control
§Field-upgradeable firmware via Mini-USB &
IP ports
§Locking Power Supply
§Surface-mountable
GTB-HD4K2K-642-BLK
6x2 Matrix for HDMI 4Kx2K
§Routes six Ultra HD sources to two
Ultra HD displays
§Supports resolutions up to Ultra HD 4K,
4K Cinema
§(DCI) and 1080p Full HD
§HDMI 2.0 & HDCP 1.4 compliant
§Supports 12-bit Deep Color
§3DTV & Lip Sync pass-through
§Push button controls for Routing, FST Modes,
Audio, and EDID management
§FST Technology speeds up HDCP authentication
§IP control via Telnet, UDP, and the built-in web
server interface
§Advanced EDID Management Supports LPCM 7.1,
Dolby® TrueHD, Dolby Digital® Plus, and DTS-
HD® Master Audio™
§Supports the use of DVI sources and DVI displays
with HDMI-to-DVI adapters (not included)
§RS-232 Serial interface for remote control using
a computer or automation control system
§IR remote control
§Field-upgradeable firmware via Mini-USB &
IP ports
§Locking Power Supply
§Surface-mountable
GTB-HD4K2K-444-BLK
4x4 Matrix for HDMI 4Kx2K
§Routes four Ultra HD sources to four
Ultra HD displays
§Supports resolutions up to Ultra HD 4K,
4K Cinema
§(DCI) and 1080p Full HD
§HDMI 2.0 & HDCP 1.4 compliant
§Supports 12-bit Deep Color (up to 1080 HD)
§3DTV & Lip Sync pass-through
§Push button controls for Routing, FST Modes,
Audio, and EDID management
§FST Technology speeds up HDCP authentication
§IP control via Telnet, UDP, and the built-in web
server interface
§Advanced EDID Management Supports LPCM 7.1,
Dolby® TrueHD, Dolby Digital® Plus, and DTS-
HD® Master Audio™
§Supports the use of DVI sources and DVI displays
with HDMI-to-DVI adapters (not included)
§RS-232 Serial interface for remote control using
a computer or automation control system
§IR remote control
§Field-upgradeable firmware via Mini-USB &
IP ports
§Locking Power Supply
§Surface-mountable
4
ToolBox 4K Ultra HD Splitters
ToolBox 4K Ultra HD Switchers
GTB-HD4K2K-441-BLK
4x1 Switcher for HDMI 4Kx2K
§Switches between four Ultra Hi-Def sources to
one Ultra HD display
§Supports resolutions up to Ultra HD 4K, 4K
Cinema (DCI) and 1080p Full HD
§HDMI 2.0 & HDCP 1.4 Compliant
§Supports 12-bit Deep Color (up to 1080p Full HD)
§3DTV & Lip Sync pass-through
§Push button control for routing sources to display
§Supports LPCM 7.1, Dolby® TrueHD, Dolby Digital®
Plus, and DTS-HD® Master Audio™
§Supports the use of DVI sources and DVI displays
with HDMI-to-DVI adapters (not included)
§RS-232 Serial interface for remote control using
a computer or automation control system
§IP control via Telnet, UDP, and the built-in web
server interface
§IR remote control
§IR Extender port allows the unit to be mounted in
a hidden location
§Field-upgradeable firmware via Mini-USB and
IP ports
§Locking Power Supply
§Surface-mountable
GTB-HD4K2K-142C-BLK
4K Ultra HD 1:2 Splitter for HDMI
§Specifically designed to support 10 layers of
splitting/cascading in large video distribution and
signage applications, supporting hundreds
of displays
§Simultaneously displays any Ultra Hi-Def source
on up to two Ultra HD displays
§Supports resolutions up to Ultra HD 4K, 4K
Cinema (DCI) and 1080p Full HD
§HDMI 2.0 & HDCP 1.4 Compliant
§Supports 12-bit Deep Color (up to 1080p Full HD)
§3DTV & Lip Sync pass-through
§FST Technology speeds up HDCP authentication
§Fast and Slow FST Modes
§Advanced EDID Management for rapid integration
of source and displays
§Supports LPCM 7.1, Dolby® TrueHD, Dolby
Digital® Plus, and DTS-HD Master Audio™
§Supports the use of DVI sources and DVI displays
with HDMI-to-DVI adapters (not included)
§Field-upgradeable firmware using Mini-USB port
§Locking Power Supply
§Surface-mountable
GTB-HD4K2K-148C-BLK
4K Ultra HD 1:8 Splitter for HDMI
§Specifically designed to support 10 layers of
splitting/cascading in large video distribution and
signage applications, supporting hundreds
of displays
§Simultaneously displays any Ultra Hi-Def source
on up to eight Ultra HD displays
§Supports resolutions up to Ultra HD 4K, 4K
Cinema (DCI) and 1080p Full HD
§HDMI 2.0 & HDCP 1.4 Compliant
§Supports 12-bit Deep Color (up to 1080p Full HD)
§3DTV & Lip Sync pass-through
§FST Technology speeds up HDCP authentication
§Fast and Slow FST Modes
§Advanced EDID Management for rapid integration
of source and displays
§Supports LPCM 7.1, Dolby® TrueHD, Dolby
Digital® Plus, and DTS-HD Master Audio™
§Supports the use of DVI sources and DVI displays
with HDMI-to-DVI adapters (not included)
§Field-upgradeable firmware using Mini-USB port
§Locking Power Supply
§Surface-mountable
GTB-HD4K2K-144C-BLK
4K Ultra HD 1:4 Splitter for HDMI
§Specifically designed to support 10 layers of
splitting/cascading in large video distribution and
signage applications, supporting hundreds of
displays
§Specifically designed to support 10 layers of
splitting/cascading in large video distribution and
signage applications, supporting hundreds
of displays
§Supports resolutions up to 4K DCI (4096 x 2160
at 24 and 30 Hz), 4K Ultra HD (3860 x 2160 at
60 Hz, 4:2:0 color space),1080p Full HD, and
1920x1200 WUXGA
§Supports 12-bit Deep Color at 1080p
§HDMI 2.0 and HDCP 1.4 compliant
§3DTV pass-through
§Lip Sync pass-through
§FST Technology speeds up HDCP
authentication process
§EDID Management and Audio Mode selectors for
rapid integration of source and displays
§Supports LPCM 7.1, Dolby® TrueHD, Dolby
Digital® Plus, and DTS-HD Master Audio™
§Supports the use of DVI sources and DVI displays
with HDMI-to-DVI adapters (not included)
§Field-upgradeable firmware using Mini-USB port
§Locking Power Supply
§Surface-mountable
5
4K Ultra HD 600 MHz Splitters with HDR
EXT-UHD600-12
EXT-UHD600A-12-DS
Ultra HD 600MHz 1:2 Splitter
for HDMI w/HDR
4K Ultra HD 600 MHz 1:2
Scalerw/ EDID Detective and
Audio De-Embedder
§Simultaneously displays an Ultra Hi-Def source on
up to two Ultra HD displays
§Specifically designed to support multiple layers
of splitting/cascading in large video distribution &
signage applications, supporting hundreds
of displays
§Supports resolutions up to 4K DCI-Cinema (4096
x 2160 at 60 Hz, 4:4:4 color space), 4K Ultra HD
(3860 x 2160 at 60Hz, 4:4:4 color space), 1080p
Full HD, and 1920x1200 WUXGA
§Supports HDR (High Dynamic Range) 10-bit Deep
Color at 4K 4:4:4
§Supports 18.2 Gbps bandwidth and 600 MHz
TMDS clock
§Splits a 4K 600 MHz source to two displays, 4K
600 MHz or 1080p
§Maximum Video Resolutions/Timing:
§Pass-through
§4096 x 2160 (Cinema-DCI) up to 60 Hz, up
to 4:4:4, 8-bit
§3860 x 2160 (4K Ultra HD with HDR) up to
60 Hz, up to 4:4:4, 8-bit
§Supports 12-bit Deep Color at 1080p 4:4:4
§3DTV pass-through
§Lip Sync pass-through
§EDID Management and Audio Mode selectors for rapid
integration of source and displays
§Supports LPCM 7.1, Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™
§Supports the use of DVI sources and DVI displays with
HDMI-to-DVI adapters (not included)
§Advanced EDID Management via USB, using the Gefen
Syner-G™ software
§HDCP 2.2 and 1.4 compliant
§3DTV pass-through
§CEC pass-through
§Lip Sync pass-through
§Supports the use of DVI sources and DVI displays up
to 1080p Full HD and WUXGA (1920x1200), with Gefen
CAB-DVI2HDMI-LCK DVI-to-HDMI cables (not included)
§Two independent scalers allow upscaling from 1080p
to 4K on one of the outputs and downscaling from 4K
to 1080p on the other
§Built-in Audio-De-Embedder breaks out digital and
analog audio from the HDMI signal for use with
outboard amplifiers or added impact
§Built-in Full-Featured 4K 600 MHz Advanced EDID
Detective with Gefen Syner-G™ interface
§Field-updatable firmware via Gefen Syner-G™
§Locking power connector
§Surface mountable
§Plug & Play – no configuration or set-up required for
most applications
§Compact enclosure is easy to install and can be hidden
away
EXT-UHD600-18
Ultra HD 600MHz 1:8 Splitter for
HDMI w/HDR
§Simultaneously displays an Ultra Hi-Def source on
up to eight Ultra HD displays
§Specifically designed to support multiple layers
of splitting/cascading in large video distribution &
signage applications, supporting hundreds
of displays
§Supports resolutions up to 4K DCI-Cinema (4096
x 2160 at 60 Hz, 4:4:4 color space), 4K Ultra HD
(3860 x 2160 at 60Hz, 4:4:4 color space), 1080p
Full HD, and 1920x1200 WUXGA
§Supports HDR (High Dynamic Range) 10-bit Deep
Color at 4K 4:4:4
§Supports 12-bit Deep Color at 1080p 4:4:4
§3DTV pass-through
§Lip Sync pass-through
§EDID Management and Audio Mode selectors for rapid
integration of source and displays
§Supports LPCM 7.1, Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™
§Supports the use of DVI sources and DVI displays with
HDMI-to-DVI adapters (not included)
§Advanced EDID Management via USB, using the Gefen
Syner-G™ software
§HDCP 2.2 and 1.4 compliant
EXT-UHD600-14
Ultra HD 600MHz 1:4 Splitter for
HDMI w/HDR
§Simultaneously displays an Ultra Hi-Def source on
up to four Ultra HD displays
§Specifically designed to support multiple layers
of splitting/cascading in large video distribution &
signage applications, supporting hundreds
of displays
§Supports resolutions up to 4K DCI-Cinema (4096
x 2160 at 60 Hz, 4:4:4 color space), 4K Ultra HD
(3860 x 2160 at 60Hz, 4:4:4 color space), 1080p
Full HD, and 1920x1200 WUXGA
§Supports HDR (High Dynamic Range) 10-bit Deep
Color at 4K 4:4:4
§Supports 12-bit Deep Color at 1080p 4:4:4
§3DTV pass-through
§Lip Sync pass-through
§EDID Management and Audio Mode selectors for rapid
integration of source and displays
§Supports LPCM 7.1, Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™
§Supports the use of DVI sources and DVI displays with
HDMI-to-DVI adapters (not included)
§Advanced EDID Management via USB, using the Gefen
Syner-G™ software
§HDCP 2.2 and 1.4 compliant
§1080p up to 60 Hz, up to 4:4:4, up to 12-bit
§1920 x 1200 (WUXGA) up to 60 Hz
§Scalers operational:
§3860 x 2160 up to 60 Hz, up to 4:4:4, 8-bit
§1080p up to 60 Hz, up to 4:4:4, 8-bit
§Supported Audio formats:
§HDMI pass-thru: Up to 8 channels of HBR,
Bitstream, & LPCM
§Analog Out: 2 ch (from PCM)
§Digital Out: 2 ch PCM & up to 5.1 ch Bitstream
§HDMI Features Supported:
§HDMI 2.0 (full bandwidth to 18.2 Gbps/600 MHz)
§HDR-10 (High Dynamic Range) 10-bit color at 4K
60 Hz 4:2:0 and 4K 24 Hz 4:4:4
§Dolby Vision™ HDR
§HDCP 2.2 and 1.4
§12-bit Deep Color (at 1080p)
§Uncompressed LPCM digital audio (up to 7.1
channels) pass-through
§HBR (High Bit Rate) digital audio (up to 7.1
channels), including Dolby Atmos®, Dolby®
TrueHD, DTS:X™, and DTS-HD Master Audio™,
pass-through
NEW
6
Tx
2x1 4K Scaler Switcher
Auto VGA
HDMI
12V DCLine In VGA In
HDMI In IR Out
RS232
IR In/Ext
Tx G Rx
Power
Volume
Input Menu
EXT-UHDV-HBTLS-TX
4K Ultra HD Multi-Format 2x1 HDBaseT™ Sender
w/ Scaler, Auto-Switching & POH
▲
▼
EXT-UHDV-HBTLS-TX
4K Ultra HD Multi-Format 2x1 HDBaseT™ Sender w/ Scaler, Auto-Switching & POH
Firmware
HDBaseT™ Out
Multi-Format Extenders over CAT-5
EXT-UHDV-HBTLS-TX
4K Ultra HD Multi-Format 2x1
HDBaseT™ Sender w/ Scaler,
Auto-Switching, and POH
NEW
EXT-UHD600-41
4K Ultra HD 600MHz 4x1 Switcher
§Routes up to four Ultra Hi-Def sources to one Ultra
HD display
§Supports resolutions up to 4K Cinema-DCI (4096 x
2160 up to 60 Hz, 4:4:4), 4K Ultra HD (3860 x 2160
up to 60 Hz, 4:4:4) with HDR, 1080p Full HD, and
WUXGA (1920x1200)
§Supports HDCP 2.2 and 1.4
§Supports HDR (High Dynamic Range) 10-bit Deep
Color at 4K 60 Hz 4:2:0 and 4K 24 Hz 4:4:4
§Supports 12-bit Deep Color at 1080p 4:4:4
§3DTV pass-through
§Lip Sync pass-through
§Advanced EDID and HDCP Management via Web
Server Interface for rapid integration of sources and
display
§Supports up to 7.1 channels of LPCM and HBR
(High Bit Rate) digital audio including Dolby Atmos®,
Dolby® TrueHD, DTS:X™ and DTS-HD Master Audio™
§Supports the use of DVI sources and DVI displays
up to 1080p Full HD and 1920x1200 (WUXGA), with
HDMI-to-DVI adapters (not included)
§Configurable Automatic Input Switching selects the
most recent connected or powered-up source
§Front panel push-button input selector routes one of
the 4 connected sources to the display, or “Blocks”
(turns off) the input
§RS-232 Serial interface for use with an automation
control system
§IP control via Telnet, UDP, and the built-in web server
interface
§IR remote control
§Small surface-mountable IR Extender module allows
the switcher to be hidden away behind the display or in
the equipment closet
§Gefen Syner-G™ software’s Discovery and Show-Me
features simplify initial IP configuration
§In-field firmware update via web server interface
§Long Reach Power (LRP) provides 500 mA at 5V on pin
18 of HDMI output. Enables select extender devices to
be powered through their HDMI input port
§Locking power connector ensures reliable operation
§Low-profile surface-mountable enclosure can be
surface mounted, placed on a shelf, or hidden away
behind the display
4K Ultra HD 600 MHz Switchers with HDR
§Auto-Switch 4K HDMI and VGA (with scaler
support).
§Extend HDMI, VGA, analog audio, RS-232, &
Bi-Directional IR over a single CAT-5e:
§4K Ultra HD (3840 x 2160 @ 60 Hz, 4:2:0), up to
130 feet/40 meters (8-bit color)
§4K Ultra HD (3840 x 2160 @ 30 Hz, 4:4:4), up to
130 feet/40 meters (8-bit color)
§4K Cinema (DCI) (4096 x 2160 @ 24 or 30 Hz
4:4:4), up to 130 feet/40 meters (8-bit color)
§1080p Full HD or 1920x1200 (WUXGA) (60 Hz), up
to 230 feet/70 meters (up to 12-bit Deep Color)
§Supports 300 MHz TMDS Clock and data
throughput of up to 10.2 Gbps
§VGA scaling up to 1920 x 1200 with picture
adjustments
§HDMI Features Supported:
§HDMI 2.0
§HDCP 2.2 and 1.4
§12-bit Deep Color
§LPCM 7.1, Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™ pass-
through
§3DTV pass-through
§CEC pass-through
§Lip Sync pass-through
Recommended Receiver:
EXT-UHDA-HBTL-RX
§Automatic or user switching of HDMI and VGA inputs
§Analog L/R audio input for VGA
§Built-in volume control with mute
§Intuitive and powerful On Screen Display (OSD)
§RS-232 control
§RS-232 extension
§IR control using EXT-RMT-EXTIRN IR Extender
(available separately)
§IR extension from Sender to Receiver and from Receiver
to Sender
§Bi-Directional Power over HDBaseT™ (POH) provides
power to the Sender or a compatible Receiver unit over
the link cable - only one side will need external power
§Uses Gefen’s implementation of HDBaseT™ technology
with enhanced features
§Advanced EDID Management
§Field-updateable firmware via mini-USB port
§Locking power connector
§Small, low-profile enclosure is surface mountable and
can be hidden away
7
Link
HDCP
Reset
Input
Power
VGA In
VGA
Audio In
HDMI
HDMI In
EXT-UHDV-WP-HBTLS-TX
Auto
Firmware
HDBaseT™
Out
In
Out
+12V
+12V
GND
GND
RS-232 Tx
Rx
EXT-UHDV-WP-HBTLS-TX
Link
HDCP
Reset
Input
Power
VGA In
VGA
Audio In
HDMI
HDMI In
EXT-UHDV-WP-HBTLS-TX
Auto
Firmware
HDBaseT™
Out
In
Out
+12V
+12V
GND
GND
RS-232 Tx
Rx
EXT-UHDV-WP-HBTLS-TX
4K Ultra HD HDBaseT™ Receiver
w/ Audio De-Embedder and POH
EXT-UHDA-HBTL-RX
EXT-UHDA-HBTL-RX
Power
Tx G Rx
Link HDCP
Prog 1 Prog 2
RS-232 Pass-Thru
RS-232
IR In/Ext IR Out HDMI Out
Audio Out
Line Coax Optical HDBaseT™ In 12V DC
Multi-Format Extenders over CAT-5
EXT-UHDV-WP-HBTLS-TX
EXT-UHDA-HBTL-RX
4K Ultra HD Multi-Format 2x1
HDBaseT™ Wall-Plate Sender
w/ Scaler, Auto-Switching, and POH
4K Ultra HD HDBaseT™ Receiver
w/ Audio De-Embedder and POH
NEW
NEW
Recommended Receiver:
EXT-UHDA-HBTL-RX
Recommended Senders:
EXT-UHDV-HBTLS-TX &
EXT-UHDV-WP-HBTLS-TX
§Auto-Switch 4K HDMI and VGA (with scaler support)
§Extend HDMI, VGA, analog audio, and RS-232 over
a single CAT-5e:
§4K Ultra HD (3840 x 2160 @ 60 Hz, 4:2:0), up to
130 feet/40 meters (8-bit color)
§4K Ultra HD (3840 x 2160 @ 30 Hz, 4:4:4), up to
130 feet/40 meters (8-bit color)
§4K Cinema (DCI) (4096 x 2160 @ 24 or 30 Hz
4:4:4), up to 130 feet/40 meters (8-bit color)
§1080p Full HD or 1920x1200 (WUXGA) (60 Hz), up
to 230 feet/70 meters (up to 12-bit Deep Color)
§Supports 300 MHz TMDS Clock and data
throughput of up to 10.2 Gbps
§VGA scaling up to 1920 x 1200 with picture
adjustments
§HDMI Features Supported:
§HDMI 2.0
§HDCP 1.4
§12-bit Deep Color
§LPCM 7.1, Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™ pass-
through
§Extend HDMI, RS-232, & Bi-Directional IR over a
single CAT-5e:
§4K Ultra HD (3840 x 2160 @ 60 Hz, 4:2:0), up to
130 feet/40 meters (8-bit color)
§4K Ultra HD (3840 x 2160 @ 30 Hz, 4:4:4), up to
130 feet/40 meters (8-bit color)
§4K Cinema (DCI) (4096 x 2160 @ 24 or 30 Hz
4:4:4), up to 130 feet/40 meters (8-bit color)
§1080p Full HD or 1920x1200 (WUXGA) (60 Hz), up
to 230 feet/70 meters (up to 12-bit Deep Color)
§Supports 300 MHz TMDS Clock and data
throughput of up to 10.2 Gbps
§HDMI Features Supported:
§HDMI 2.0
§HDCP 2.2 and 1.4
§12-bit Deep Color
§LPCM 7.1, Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™ pass-
through
§3DTV pass-through
§CEC pass-through
§Lip Sync pass-through
§Automatic or user switching of HDMI and VGA
inputs
§Analog L/R audio input for VGA
§RS-232 control
§RS-232 extension
§Power over HDBaseT™ (POH) provides power to
the Sender from a compatible Receiver unit over
the link cable
§Sender can also be locally powered using the
2-pin Phoenix connector in back panel
§Uses Gefen’s implementation of HDBaseT™
technology with enhanced features
§Advanced EDID Management
§Field-updateable firmware via mini-USB port
§North American standard 2-gang wall-plate form
factor
§White trim plate included
§Works with most standard North American wall-
plate trim plates
§3DTV pass-through
§CEC pass-through
§Lip Sync pass-through
§Analog stereo and optical digital audio breakouts
§RS-232 control of compatible sender
§RS-232 extension
§IR extension from Sender to Receiver and from
Receiver to Sender
§Bi-Directional Power over HDBaseT™ (POH)
provides power to the Receiver or a compatible
Sender unit over the link cable - only one side will
need external power
§Uses Gefen’s implementation of HDBaseT™
technology with enhanced features
§Field-updateable firmware via mini-USB port
§Locking power connector
§Small, low-profile enclosure is surface mountable
and can be hidden away
8
GTB-UHD600-HBT
GTB-UHD600-HBTL
4K Ultra HD 600 MHz HDBaseT™
Extender w/ HDR, RS-232, 2-way IR,
and POL
4K Ultra HD 600 MHz HDBaseT™
Extender w/ HDR, 2-way IR, and POL
NEW
NEW
HDMI Extenders over CAT-5
§Supports 18.2 Gbps bandwidth and 600 MHz
TMDS clock
§Extends HDMI, RS-232, & Bi-Directional IR over a
single CAT-5e/CAT-6A:
§4K Ultra HD (3840 x 2160 to 60 Hz, 4:4:4), up
to 264 feet/80 meters (8-bit color)
§4K Cinema (DCI) (4096 x 2160 to 60 Hz 4:4:4),
up to 264 feet/80 meters (8-bit color)
§1080p Full HD (60 Hz) and WUXGA (1920 x
1200 to 60 Hz), up to 330 feet/100 meters (up
to 12-bit Deep Color)
§HDMI Features Supported:
§HDMI 2.0 (full bandwidth to 18 Gbps/600 MHz)
§HDR (High Dynamic Range) 10-bit Deep Color
at 4K 60 Hz 4:2:0 and 4K 24 Hz 4:4:4
§HDCP 2.2 and 1.4
§12-bit Deep Color (at 1080p)
§Uncompressed LPCM digital audio up to 7.1
channels
§HBR (High Bit Rate) digital audio up to 7.1
channels, including Dolby Atmos®, Dolby®
TrueHD, DTS:X™, and DTS-HD Master Audio™
§3DTV pass-through
§CEC pass-through
§Lip Sync pass-through
§Supports 18.2 Gbps bandwidth and 600 MHz
TMDS clock
§Extends HDMI & Bi-Directional IR over a single
CAT-5e/CAT-6A:
§4K Ultra HD (3840 x 2160 to 60 Hz, 4:4:4), up
to 132 feet/40 meters (8-bit color)
§4K Cinema (DCI) (4096 x 2160 to 60 Hz 4:4:4),
up to 132 feet/40 meters (8-bit color)
§1080p Full HD (60 Hz) and WUXGA (1920 x
1200 to 60 Hz), up to 200 feet/60 meters (up to
12-bit Deep Color)
§HDMI Features Supported:
§HDMI 2.0 (full bandwidth to 18 Gbps/600 MHz)
§HDR (High Dynamic Range) 10-bit color at 4K
60 Hz 4:2:0 and 4K 24 Hz 4:4:4
§HDCP 2.2 and 1.4
§12-bit Deep Color (at 1080p)
§Uncompressed LPCM digital audio up to 7.1
channels
§HBR (High Bit Rate) digital audio up to 7.1
channels, including Dolby Atmos®, Dolby®
TrueHD, DTS:X™, and DTS-HD Master Audio™
§3DTV pass-through
§CEC pass-through
§Lip Sync pass-through
§Supports the use of DVI sources and DVI displays
up to 1080p Full HD and WUXGA (1920x1200),
with Gefen CAB-DVI2HDMI-LCK DVI-to-HDMI
cables (not included)
§RS-232 2-way link between Sender and Receiver
§IR extension from Sender to Receiver and from
Receiver to Sender
§Gefen’s Bi-Directional POL provides power to the
Sender or the Receiver unit over the link cable -
only one side will need external power
§Uses Gefen’s implementation of HDBaseT™
technology with proprietary algorithms and
enhanced features
§Advanced EDID Management
§Firmware updatable via RS-232
§Locking power connector
§Surface mountable
§Plug & Play – no configuration or set-up required
for most applications
§Compact enclosures are easy to install and can
be hidden away
§Supports the use of DVI sources and DVI displays
up to 1080p Full HD and WUXGA (1920x1200),
with Gefen CAB-DVI2HDMI-LCK DVI-to-HDMI
cables (not included)
§Gefen’s Bi-Directional POL provides power to the
Sender or the Receiver unit over the link cable -
only one side will need external power
§Uses Gefen’s implementation of HDBaseT™
technology with proprietary algorithms and
enhanced features
§Advanced EDID Management
§Firmware updatable via external Gefen Syner-G™
port
§Locking power connector
§Surface mountable
§Plug & Play – no configuration or set-up required
for most applications
§Compact enclosures are easy to install and can
be hidden away
9
HDMI Extenders over CAT-5
EXT-UHD-CAT5-ELRPOL
GTB-HDBT-POL-BLK
Extender for HDMI with POL
§Extends 4K Ultra HD and Bi-Directional IR up to
130 feet over a single CAT-5e cable (8-bit color)
§Extends 4K Ultra HD (DCI) and Bi-Directional IR up
to 130 feet over a single CAT-5e or CAT-6 cable
§Extends HDMI at 1080p Full HD and Bi-Directional
IR up to 230 feet over a single CAT-6 cable, or up
to 198 feet over CAT-5e cable
§Bi-Directional IR extension
§Gefen POL feature provides power to the Receiver
unit over the CAT-5e
§Uses HDBaseT™ technology
§Locking power connector
§Easy surface mounting
GTB-UHD-HBT
GTB-UHD-HBTL
4K Ultra HD HDBaseT™ Extender
w/ RS-232, 2-way IR and POL
4K Ultra HD HDBaseT™ Extender
w/ 2-way IR and POL
§Extends HDMI, RS-232, & 2-way IR over a single
CAT-5e/CAT-6A*:
§4K Ultra HD and 4K DCI-Cinema (60 Hz, 4:2:0
or 24/30 Hz, 4:4:4), up to 330 feet/100 meters
(8-bit color)
§1080p Full HD (60 Hz), up to 330 feet/100
meters (up to 12-bit Deep Color)
§1080p Full HD (60 Hz), up to 495 feet/150
meters (8-bit color)
§Supports HDMI 2.0, HDCP 2.2 and 1.4, 12-bit
Deep Color (1080p), 3DTV pass-through, CEC
pass-through, and Lip Sync pass-through
§Extends HDMI & 2-way IR over a single CAT-5e/
CAT-6A*:
§4K Ultra HD and 4K DCI-Cinema (60 Hz, 4:2:0
or 24/30 Hz, 4:4:4), up to 130 feet/40 meters
(8-bit
§color)
§1080p Full HD (60 Hz), up to 230 feet/70
meters (up to 12-bit Deep Color)
§Supports HDMI 2.0, HDCP 2.2 and 1.4, 12-bit
Deep Color (1080p), 3DTV pass-through, CEC
pass-through, and Lip Sync pass-through
§LPCM 7.1, Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™ pass-
through
§Uses Gefen’s implementation of HDBaseT™
technology with enhanced features
§IR extension from Sender to Receiver and from
Receiver to Sender
§Gefen Bi-Directional POL feature provides power
to the Sender or the Receiver unit over the link
cable - only one side will need external power
§Advanced EDID Management
§LPCM 7.1, Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™ pass-
through
§Uses Gefen’s implementation of HDBaseT™
technology with enhanced features
§IR extension from Sender to Receiver and from
Receiver to Sender
§Gefen Bi-Directional POL feature provides power
to the Sender or the Receiver unit over the link
cable - only one side will need external power
§Advanced EDID Management
4K Ultra HD HDBaseT™ Extender
w/ Ethernet, RS-232, 2-way IR
and POL
§Extends HDMI, Ethernet, RS-232, & 2-way IR over
a single CAT-5e/CAT-6A*:
§4K Ultra HD and 4K DCI-Cinema (60 Hz, 4:2:0
or 24/30 Hz, 4:4:4), up to 330 feet/100 meters
(8-bit color)
§1080p Full HD (60 Hz), up to 330 feet/100
meters (up to 12-bit Deep Color)
§1080p Full HD (60 Hz), up to 495 feet/150
meters (8-bit color)
§Supports HDMI 2.0, HDCP 2.2 and 1.4, 12-bit
Deep Color (1080p), 3DTV pass-through, CEC
pass-through, and Lip Sync pass-through
§LPCM 7.1, Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™ pass-
through
§Uses Gefen’s implementation of HDBaseT™
technology with enhanced features
§IR extension from Sender to Receiver and from
Receiver to Sender
§Gefen Bi-Directional POL feature provides power
to the Sender or the Receiver unit over the link
cable - only one side will need external power
§Advanced EDID Management
* This product supports sources up to 4K 300 MHz (60 Hz 4:2:0 or 30 Hz 4:4:4). It is not
compatible with sources that are capable of HDR or 4K 600 MHz (60 Hz 4:4:4).
NEW
NEW
10
HDMI Extenders over CAT-5
GTB-UHD-HBT2
EXT-HDKVM-ELR
EXT-UHDA-HBT2
4K Ultra HD HDBaseT 2.0 Extender
§Extends HDMI, Ethernet, RS-232, 2-way IR &
2-way Audio over a single CAT-5e
§Extends 4K Ultra HD video up to 330 feet
§Extends 1080p video up to 495 feet
§Supports HDMI 2.0, HDCP 2.2 and 1.4
§IR extension from Sender to Receiver and from
Receiver to Sender
§TOSLINK® Optical Digital Audio extension from
Receiver to Sender
§Analog L/R Stereo Audio extension from Sender
to Receiver
§Bi-Directional POH (Power Over HDBaseT™)
feature provides power to the Sender or the
Receiver unit over the link cable - only one side
needs external power
§Advanced EDID Management via Gefen
Syner-G™ software
§Link Quality Monitoring via Gefen
Syner-G™ software
§In-field firmware update via USB, using Gefen
Syner-G™ software
§Locking power connector
§Low profile, surface-mountable enclosures
4K Ultra HD HDBaseT 2.0 Extender
HD KVM ELR Extender over
one CAT-5
§Extends HDMI, RS-232 & 2-way IR over a
single CAT-5e
§Extends 4K Ultra HD video up to 330 feet
§Extends 1080p video up to 495 feet
§Supports HDMI 2.0, HDCP 2.2 and 1.4
§IR extension from Sender to Receiver and from
Receiver to Sender
§POH (Power Over HDBaseT™) feature provides
power to the Receiver unit over the link cable -
only the Sender unit needs external power
§Extends HDMI and USB over a single CAT-5e up to
330 feet/100 meters:
§Supported resolutions include:
§4K Ultra HD (3840 x 2160 @ 60Hz, 4:2:0 or
30Hz, 4:4:4)
§4K Cinema (DCI) (4096 x 2160 @ 24 or 30Hz
4:4:4)
§1080p Full HD
§Supports HDMI 2.0, HDCP 1.4 compliant, 12-bit
Deep Color (at 1080p), 3DTV pass-through, CEC
pass-through, and Lip Sync pass-through
§Advanced EDID Management via Gefen
Syner-G™ software
§Link Quality Monitoring via Gefen
Syner-G™ software
§In-field firmware update via USB, using Gefen
Syner-G™ software
§Locking power connector
§Low profile, surface-mountable enclosures
§LPCM 7.1 audio, Dolby® TrueHD, Dolby Digital®
Plus, and DTS-HD® Master Audio™ pass-through
§Supports up to 30 Mbps when using USB 2.0
§Backward-compatible with USB 1.1
§EDID management for rapid integration of source
and display devices
§Uses Gefen’s implementation of HDBaseT™
technology with enhanced features
§Locking power supplies
§1U tall, half-rack width enclosures are rack-
mountable using EXT-RACK-1U-GRY
11
DVI Extenders Over CAT-5
EXT-DVIKA-HBT2
EXT-DVI-1CAT5-SR
EXT-DVI-1CAT5-ELR
DVI KVM HDBaseT 2.0 Exender
HDBaseT™ Lite DVI Extender over
one CAT5
HDBaseT™ DVI Extender over
one CAT5
§Extends DVI, USB, RS-232 & 2-way Audio over a
single CAT-5e Cable
§Extends 1080p Full HD up to 495 feet
§Extends 1920x1200 (WUXGA) up to 495 feet
§Extends HDMI, USB, RS-232, and 2-way Audio
over a single CAT-5e
§Extends 4K Ultra HD video up to 330 feet
§Extends 1080p Full HD up to 495 feet
§Extends 1920x1200 (WUXGA) up to 495 feet
§Supports HDMI 2.0, HDCP 2.2 and 1.4
§Analog L/R Stereo Audio extension from Sender to
Receiver and from Receiver to Sender
§Receiver audio input accommodates a microphone
or a line level audio source
§Extends DVI up to 230 feet (70 meters) over one
CAT-6A cable
§Extends DVI up to 200 feet (60 meters) over one
CAT-5e cable
§Supports resolutions up to 1920 x 1200 (WUXGA)
§EDID management for rapid integration of source
and display
§Extends DVI up to 495 feet (150 meters) over one
CAT-5e cable
§Supports resolutions up to 1080p Full HD and
1920 x 1200 (WUXGA)
§EDID management for rapid integration of source
and display
§Enable/Disable switches for HPD pass-through
§Power-Save (Green Mode) selector switch
§POH (Power Over HDBaseT™) feature provides
power to Sender unit over the link cable - only
the Receiver needs external power
§Advanced EDID Management via Gefen Syner-G™
software
§Link Quality Monitoring via Gefen Syner-G™
software
§In-field firmware update via USB, using Gefen
Syner-G™ software
§Locking power connector
§1U tall, half-rack width enclosures are rack-
mountable using EXT-RACK-1U-GRY
§HDCP compliant
§Uses Gefen’s implementation of HDBaseT™
technology with enhanced features
§Locking power supplies
§Surface-mountable
§150m/100m range selector switch configures
the extender for maximum range (150 meters) or
maximum bandwidth
§HDCP compliant
§Uses Gefen’s implementation of HDBaseT™
technology with enhanced features
§Locking power supplies
§Surface-mountable
12
4K HDMI Extenders Over Fiber
4K DisplayPort™ Extenders Over Fiber
EXT-HDRS2IR-4K2K-1FO
EXT-UHD600-1SC
4K Ultra HD Extender over one
Fiber w/ RS-232 and 2-way IR
4K 600 MHz HDMI Extender over
one SC-terminated Fiber
§Extends HDMI, RS-232, and Bi-Directional IR over
a single strand fiber-optic cable
§Extends 4K Ultra HD (3840 x 2160 @ 60Hz, 4:2:0,
or 30Hz, 4:4:4) up to:
§3300 feet (1000 meters) over 50/125um
OM3e/OM4 fiber
§500 feet (150 meters) over 50/125um (OM3)
fiber
§165 feet (50 meters) over 62.5/125um (OM1)
fiber
§Extends 1080p Full HD (1920 x 1080 @ 60Hz)
up to:
§6600 feet (2000 meters) over 50/125um
OM3e/OM4 fiber
§1000 feet (300 meters) over 50/125um (OM3)
fiber
§330 feet (100 meters) over 62.5/125um (OM1)
fiber
§Supports 18.2 Gbps bandwidth and 600 MHz
TMDS clock
§Extension up to 200m (660 feet) over one
SC-terminated multi-mode OM3 or better
(50/125um) fiber-optic cable
§Supports resolutions up to 4K Cinema-DCI (4096
x 2160 up to 60 Hz, 4:4:4), 4K Ultra HD (3860 x
2160 up to 60 Hz, 4:4:4) with HDR, 1080p Full HD,
and WUXGA (1920x1200)
§Supports HDCP 2.2 and 1.4
§Supports HDR (High Dynamic Range) 10-bit Deep
Color at 4K 60 Hz 4:2:0 and 4K 24 Hz 4:4:4
§Supports 12-bit Deep Color at 1080p Full HD (60
Hz 4:4:4)
§3DTV pass-through
§Lip Sync pass-through
§Supports uncompressed LPCM digital audio up to
7.1 channels
§Supports HDMI 2.0, HDCP 1.4 compliant, 12-bit
Deep Color (at 1080p), 3DTV pass-through, and
Lip Sync pass-through
§LPCM 7.1 audio, Dolby® TrueHD, and DTS-HD
Master Audio™ pass-thru
§Auto Virtual EDID
§Automatic calibration based on the type and
length of fiber optic cable
§Full duplex RS-232 up to 115200 baud
§Firmware upgradable via USB
§Inherently immune to electromagnetic
interference (EMI)
§Locking power supplies
§Surface-mountable
§Supports up to 7.1 channels of HBR (High Bit
Rate) digital audio including Dolby Atmos®,
Dolby® TrueHD, DTS:X™, and DTS-HD Master
Audio™
§Supports the use of DVI sources and DVI displays
up to 1080p Full HD and WUXGA (1920x1200),
with Gefen CAB-DVI2HDMI-LCK DVI-to-HDMI
cables (not included)
§Sturdy metal construction of the enclosures help
provide immunity against
§Electro-Magnetic Interference (EMI) and radiated
noise (RFI).
§Plug & Play – no configuration or set-up required
for most applications
§Compact enclosures are easy to install and can
be hidden away
EXT-DP-4K600-1SC
DisplayPort™ 1.2 Extender over one
SC-Terminated Fiber Optic Cable
§Supports Full-Bandwidth 4K 60 Hz 4:4:4
(600 MHz)
§Fully compliant with DisplayPort 1.2 standard
§Supports WQUXGA (4K; 3840x2400), 4K Ultra
HD (3840 x 2160), and 4K Cinema - DCI (4096 x
2160) at 60Hz, 4:4:4
§Extension up to 200m (660 feet) over one
(1) SC-terminated multi-mode OM3 or better
(50/125um) optic cable
§Supports DisplayPort Auxiliary/l²C channel
§Supports DisplayPort Multi-stream technology
§Compact enclosures are easy to install and can be
hidden away.
§Sturdy metal construction of the enclosures
help provide further immunity against Electro-
Magnetic Interference (EMI) and radiated noise
(RFI).
§Plug & Play – no configuration or set-up required
for most applications
§EQ switches on Sender & Receiver ensure
compatibility with most sources & displays
§Medical Safety (EN 60601-1) & EMC Compliant
(EN 60601-1-2) when used with two EXT-
PS52AU-M-1.3-6-AL power supplies (available
separately)
§HDCP 2.2, HDCP 1.4, and DPCP compliant
NEW
13
AV Over IP
EXT-UHDKA-LANS-TX
EXT-UHDKA-LANS-RX
GEN 2.0
4K Ultra HD HDMI KVM over IP
§Extends HDMI, USB, RS-232, 2-way analog audio,
and IR, using a Gigabit Local Area Network
§Independent video, USB, RS-232, IR, and audio
routing (future firmware update)
§Backward-compatible with first generation Gefen
AV over IP products
§Supports input resolutions up to 4K 60Hz 4:2:0
§Supports output resolutions up to 4K 30Hz 4:4:4
§Supported HDMI Features:
§HDR
§HDCP 2.2 and 1.4
§Deep Color
§Lip-Sync
§Uncompressed LPCM digital audio up to 7.1
channels
§Up to 7.1 channels of HBR (High Bit Rate) digital
audio including Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™
§When used with Gefen DVI-to-HDMI cables (not
included), supports the use of DVI sources and
DVI displays up to 1080p Full HD and 1920x1200
(WUXGA)
§Video output on Sender unit for local monitoring
of the source
§KM Emulation feature facilitates real-time,
simultaneous Keyboard and Mouse control of each
source from all connected workstations
§Integrated scaler ensures maximum compatibility
and best possible viewing experience with
different contents and displays
§Built-in video wall controller accommodates any
number of rows and columns up to 16x16
§Built-in Audio De-Embedder on Receiver breaks
out 2 channel analog, 2 channel PCM, and up to
5.1 channels of Bitstream audio from the HDMI
signal, allowing the audio content to be sent to
external amplifiers and music distribution systems
for added impact
§MFU (Mass-Firmware-Update), quick and
automated configuration, and enhanced control
capabilities and system security when used with
the Gefen EXT-CU-LAN Matrix Controller
§Enhanced API for added functionality with third-
party control systems
§Built-in web interface, Telnet, and UDP
§Compatible with the Gefen Keyboard Switching
Controller software, available for download at
www.gefen.com
§Supports 39,900 Senders and a combination
of over 65,000 Sender and Receiver units,
depending on the network bandwidth and number
of ports on your network switch
§Two USB 2.0 ports with data rates up to 480
Mbps and backward-compatibility with USB 1.1
§Two USB 1.1 ports with KM Emulation, for use
with Human Interface Devices (H.I.D.)
§802.3af standard Power-over-Ethernet allows the
new Sender and Receiver units to be powered
through a standard PoE-enabled IP network
switch, without the need for external power
supplies
§Two-port Gigabit Ethernet switch built into the
Receiver unit
§Mode switch on Sender for sharpness or motion-
optimization of image
§Field-updatable firmware via EXT-CU-LAN
controller or the built-in web server interface
§Locking power supply connectors
§Half-rack width Sender and Receiver enclosures
are rack-mountable using EXT-RACK-1U-GRY
§Sender and Receiver can also be surface-
mounted using the included L-brackets
§Low profile Receiver enclosure features an IR
Extender port and can be hidden away behind
the display
NEW
14
AV Over IP
EXT-DVIKA-LANS-TX
EXT-DVIKA-LANS-RX
GEN 2.0
4K Ultra HD DVI KVM over IP
NEW
§Extends DVI, USB, RS-232, 2-way analog audio,
and IR, using a Gigabit Local Area Network
§Independent video, USB, RS-232, IR, and audio
routing (future firmware update)
§Backward-compatible with first generation Gefen
AV over IP products
§Supports input and output resolutions up to 1920
x 1200 (WUXGA) and 1080p Full HD
§Video output on Sender unit for local monitoring
of the source
§KM Emulation feature facilitates real-time,
simultaneous Keyboard and Mouse control of each
source from all connected workstations
§Integrated scaler ensures maximum compatibility
and best possible viewing experience with
different contents and displays
§Built-in video wall controller accommodates any
number of rows and columns up to 16x16
§Built-in Audio De-Embedder on Receiver breaks
out 2 channel analog, 2 channel PCM, and up to
5.1 channels of Bitstream audio from the HDMI
signal, allowing the audio content to be sent to
external amplifiers and music distribution systems
for added impact
§MFU (Mass-Firmware-Update), quick and
automated configuration, and enhanced control
capabilities and system security when used with
the Gefen EXT-CU-LAN Matrix Controller
§Enhanced API for added functionality with third-
party control systems
§Built-in web interface, Telnet, and UDP
§Compatible with the Gefen Keyboard Switching
Controller software, available for download at
www.gefen.com
§Supports 39,900 Senders and a combination
of over 65,000 Sender and Receiver units,
depending on the network bandwidth and number
of ports on your network switch
§Two USB 2.0 ports with data rates up to 480
Mbps and backward-compatibility with USB 1.1
§Two USB 1.1 ports with KM Emulation, for use
with Human Interface Devices (H.I.D.)
§802.3af standard Power-over-Ethernet allows the
new Sender and Receiver units to be powered
through a standard PoE-enabled IP network
switch, without the need for external power
supplies
§Two-port Gigabit Ethernet switch built into the
Receiver unit
§Mode switch on Sender for sharpness or motion-
optimization of image
§Field-updatable firmware via EXT-CU-LAN
controller or the built-in web server interface
§Locking power supply connectors
§Half-rack width Sender and Receiver enclosures
are rack-mountable using EXT-RACK-1U-GRY
§Sender and Receiver can also be surface-
mounted using the included L-brackets
§Low profile Receiver enclosure features an IR
Extender port and can be hidden away behind
the display
15
EXT-DPKA-LANS-TX
EXT-DPKA-LANS-RX
GEN 2.0
4K DisplayPort™ KVM over IP
AV Over IP
§Extends DisplayPort™, USB, RS-232, 2-way
analog audio, and IR, using a Gigabit Local Area
Network
§Independent video, USB, RS-232, IR, and audio
routing (future firmware update)
§Backward-compatible with first generation Gefen
AV over IP products
§Supports input resolutions up to 4K 60Hz 4:2:0
§Supports output resolutions up to 4K 30Hz 4:4:4
§Supports HDCP 2.2 and 1.4
§KM Emulation feature facilitates real-time,
simultaneous Keyboard and Mouse control of each
source from all connected workstations
§Integrated scaler ensures maximum compatibility
and best possible viewing experience with
different contents and displays
§Built-in video wall controller accommodates any
number of rows and columns up to 16x16
§Built-in Audio De-Embedder on Receiver breaks
out 2 channel analog, 2 channel PCM, and up to
5.1 channels of Bitstream audio from the HDMI
signal, allowing the audio content to be sent to
external amplifiers and music distribution systems
for added impact
§MFU (Mass-Firmware-Update), quick and
automated configuration, and enhanced control
capabilities and system security when used with
the Gefen EXT-CU-LAN Matrix Controller
§Enhanced API for added functionality with third-
party control systems
§Built-in web interface, Telnet, and UDP
§Compatible with the Gefen Keyboard Switching
Controller software, available for download at
www.gefen.com
§Supports 39,900 Senders and a combination
of over 65,000 Sender and Receiver units,
depending on the network bandwidth and number
of ports on your network switch
§Two USB 2.0 ports with data rates up to 480
Mbps and backward-compatibility with USB 1.1
§Two USB 1.1 ports with KM Emulation, for use
with Human Interface Devices (H.I.D.)
§802.3af standard Power-over-Ethernet allows the
new Sender and Receiver units to be powered
through a standard PoE-enabled IP network
switch, without the need for external power
supplies
§Two-port Gigabit Ethernet switch built into the
Receiver unit
§Mode switch on Sender for sharpness or motion-
optimization of image
§Field-updatable firmware via EXT-CU-LAN
controller or the built-in web server interface
§Locking power supply connectors
§Half-rack width Sender and Receiver enclosures
are rack-mountable using EXT-RACK-1U-GRY
§Sender and Receiver can also be surface-
mounted using the included L-brackets
§Low profile Receiver enclosure features an IR
Extender port and can be hidden away behind
the display
NEW
16
AV Over IP
EXT-VGAKA-LANS-TX
EXT-VGAKA-LANS-RX
GEN 2.0
VGA KVM over IP
§Extends VGA, USB, RS-232, 2-way analog audio,
and IR, using a Gigabit Local Area Network
§Independent video, USB, RS-232, IR, and audio
routing (future firmware update)
§Backward-compatible with first generation Gefen
AV over IP products
§Supports input and output resolutions up to 1920
x 1200 (WUXGA) and 1080p Full HD
§Video output on Sender unit for local monitoring
of the source
§KM Emulation feature facilitates real-time,
simultaneous Keyboard and Mouse control of each
source from all connected workstations
§Integrated scaler ensures maximum compatibility
and best possible viewing experience with
different contents and displays
§Built-in video wall controller accommodates any
number of rows and columns up to 16x16
§MFU (Mass-Firmware-Update), quick and
automated configuration, and enhanced control
capabilities and system security when used with
the Gefen EXT-CU-LAN Matrix Controller
§Enhanced API for added functionality with third-
party control systems
§Built-in web interface, Telnet, and UDP
§Compatible with the Gefen Keyboard Switching
Controller software, available for download at
www.gefen.com
§Supports 39,900 Senders and a combination
of over 65,000 Sender and Receiver units,
depending on the network bandwidth and number
of ports on your network switch
§Two USB 2.0 ports with data rates up to 480
Mbps and backward-compatibility with USB 1.1
§Two USB 1.1 ports with KM Emulation, for use
with Human Interface Devices (H.I.D.)
§802.3af standard Power-over-Ethernet allows the
new Sender and Receiver units to be powered
through a standard PoE-enabled IP network
switch, without the need for external power
supplies
§Two-port Gigabit Ethernet switch built into the
Receiver unit
§Mode switch on Sender for sharpness or motion-
optimization of image
§Field-updatable firmware via EXT-CU-LAN
controller or the built-in web server interface
§Locking power supply connectors
§Half-rack width Sender and Receiver enclosures
are rack-mountable using EXT-RACK-1U-GRY
§Sender and Receiver can also be surface-
mounted using the included L-brackets
§Low profile Receiver enclosure features an IR
Extender port and can be hidden away behind
the display
EXT-UHDV-KA-LANS-TX
EXT-UHDV-KA-LANS-RX
GEN 2.0
4K Ultra HD HDMI and
VGA KVM over IP
§Extends HDMI, VGA, USB, RS-232, bi-directional
stereo analog audio, and IR over IP, using a
Gigabit Local Area Network
§Independent video, RS-232, IR, and audio routing
(future firmware update)
§Supports input resolutions up to 4K 60Hz 4:2:0
on HDMI and up to 1920x1200, 60 Hz on VGA
(WUXGA).
§Supports output resolutions up to 4K 30Hz 4:4:4
on HDMI and up to 1920x1200 60 Hz or 1080p
Full HD on VGA
§Supported HDMI Features:
§HDR
§HDCP 2.2 and 1.4
§Deep Color
§Lip-Sync pass-through
§Supports uncompressed LPCM digital audio up to
7.1 channels
§Supports up to 7.1 channels of HBR (High Bit
Rate) digital audio including Dolby Atmos®, Dolby®
TrueHD, DTS:X™, and DTS-HD Master Audio™
§When used with Gefen DVI-to-HDMI cables (not
included), supports the use of DVI sources and
DVI displays up to 1080p Full HD and 1920x1200
(WUXGA)
§Built-in video wall controller accommodates any
number of rows and columns up to 16x16
§Quick mass-firmware-update, automated
configuration, and enhanced control capabilities
and system security when used with the Gefen
EXT-CU-LAN Matrix Controller
§Built-in web interface, Telnet, and UDP
§Compatible with the Gefen Keyboard Switching
Controller software, available for download at
www.gefen.com
§Supports 39,900 Senders and a combination
of just over 65,000 Sender and Receiver units,
depending on the network bandwidth and number
of ports on your network switch
§Two USB 2.0 ports with data rates up to 480
Mbps and backward-compatibility with USB 1.1
§Two USB 1.1 ports for use with Human Interface
Devices (H.I.D.)
§PoE (Power over Ethernet) allows the new Sender
and Receiver units to be powered through a
standard PoE-enabled IP network switch, without
the need for external power supplies
§Three-port Gigabit Ethernet switch built into the
Receiver unit
§Mode switch on Sender for sharpness or motion
optimization of image
§Field-updatable firmware via EXT-CU-LAN
controller or the built-in web server interface
§Locking power supply connectors
§Half-rack width Sender and Receiver enclosures
are rack-mountable using EXT-RACK-1U-GRY
§Sender and Receiver can also be surface-
mounted using the included L-brackets
§Low profile Receiver enclosure features an IR
Extender port and can be hidden away behind
the display
NEW
17
EXT-ADA-LAN-TX
EXT-ADA-LAN-RX
GEN 2.0
Digital and Analog Audio over IP
§Extends digital and analog audio, RS-232, and IR,
using a Gigabit Local Area Network
§Independent audio, RS-232, and IR routing (future
firmware update)
§Backward-compatible with first generation Gefen
AV over IP products
§Distributes L/R analog, 2 channel PCM, and up to
5.1 channels of Bitstream audio
§Coaxial and Optical (TOSLINK®) S/PDIF Digital
Audio Inputs and Outputs
§MFU (Mass-Firmware-Update), quick and
automated configuration, and enhanced control
capabilities and system security when used with
the Gefen EXT-CU-LAN Matrix Controller
§Enhanced API for added functionality with third-
party control systems
§Built-in web interface, Telnet, and UDP
§Compatible with the Gefen Keyboard Switching
Controller software, available for download at
www.gefen.com
§Supports 39,900 Senders and a combination
of over 65,000 Sender and Receiver units,
depending on the network bandwidth and number
of ports on your network switch
§802.3af standard Power-over-Ethernet allows the
new Sender and Receiver units to be powered
through a standard PoE-enabled IP network
switch, without the need for external power
supplies
§Two-port Gigabit Ethernet switch built into the
Receiver unit
§Field-updatable firmware via EXT-CU-LAN
controller or the built-in web server interface
§Locking power supply connectors
§Low-profile, half-rack width Sender and Receiver
enclosures are rack-mountable using EXT-RACK-
1U-GRY
§Sender and Receiver can also be surface-
mounted using the included L-brackets
§Low profile Receiver enclosure features an IR
Extender port and can be hidden away behind
the display
AV Over IP
EXT-UHD-LANS-TX
EXT-UHD-LANS-RX
GEN 2.0
4K Ultra HD HDMI over IP
§Extends HDMI, RS-232, analog audio, and IR,
using a Gigabit Local Area Network
§Independent video, RS-232, IR, and audio routing
(future firmware update)
§Backward-compatible with first generation Gefen
AV over IP products
§Supports input resolutions up to 4K 60Hz 4:2:0
§Supports output resolutions up to 4K 30Hz 4:4:4
§Supported HDMI Features:
§HDR
§HDCP 2.2 and 1.4
§Deep Color
§Lip-Sync
§Uncompressed LPCM digital audio up to 7.1
channels
§Up to 7.1 channels of HBR (High Bit Rate) digital
audio including Dolby Atmos®, Dolby® TrueHD,
DTS:X™, and DTS-HD Master Audio™
§When used with Gefen DVI-to-HDMI cables (not
included), supports the use of DVI sources and
DVI displays up to 1080p Full HD and 1920x1200
(WUXGA)
§Integrated scaler ensures maximum compatibility
and best possible viewing experience with
different contents and displays
§Built-in video wall controller accommodates any
number of rows and columns up to 16x16
§Built-in Audio De-Embedder on Receiver breaks
out 2 channel analog, 2 channel PCM, and up to
5.1 channels of Bitstream audio from the HDMI
signal, allowing the audio content to be sent to
external amplifiers and music distribution systems
for added impact
§MFU (Mass-Firmware-Update), quick and
automated configuration, and enhanced control
capabilities and system security when used with
the Gefen EXT-CU-LAN Matrix Controller
§Enhanced API for added functionality with third-
party control systems
§Built-in web interface, Telnet, and UDP
§Compatible with the Gefen Keyboard Switching
Controller software, available for download at
www.gefen.com
§Supports 39,900 Senders and a combination
of over 65,000 Sender and Receiver units,
depending on the network bandwidth and number
of ports on your network switch
§802.3af standard Power-over-Ethernet allows the
new Sender and Receiver units to be powered
through a standard PoE-enabled IP network
switch, without the need for external power
supplies
§Two-port Gigabit Ethernet switch built into the
Receiver unit
§Mode switch on Sender for sharpness or motion-
optimization of image
§Field-updatable firmware via EXT-CU-LAN
controller or the built-in web server interface
§Locking power supply connectors
§Low-profile, half-rack width Sender and Receiver
enclosures are rack-mountable using EXT-RACK-
1U-GRY
§Sender and Receiver can also be surface-
mounted using the included L-brackets
§Low profile Receiver enclosure features an IR
Extender port and can be hidden away behind
the display
NEW
NEW
18
AV Over IP
EXT-CU-LAN
Matrix Controller
§Detects, configures, and controls all Gefen Video
and KVM over IP products
§Built-in web server allows access from any web-
enabled device, including phones, tablets, and
PCs
§Two Ethernet ports with independent IP and
MAC Addresses allow segregation of Video/KVM
LAN and control LAN, and help provide separate
security layers for administrators and end-users
§Seamless integration with Gefen Syner-G™
software allows for quick installation and
configuration on a network
§Automatic assignment of IP addresses for all
Gefen Video and KVM over IP devices on
a network
§Front panel control push-buttons/display,
handheld IR remote, and web server interface
allow easy and convenient end-user operation
§Automation control system interface via Telnet
and UDP
§POE (Power Over Ethernet) on LAN 1 port
eliminates the need for an external power supply
§Password-protected independent user and
administrative access
§Easy to read 2 line/20 characters per line Liquid
Crystal Display
§System Configuration Upload/Download function
§Plug-and-Play installation with little to no set-up
§Locking power supply connector
§2U tall rack-mountable enclosure, detachable
rack ears included
§Slanted front panel for ergonomic push-button
access and display visibility when placed on a
table
EXT-HD2IRS-LAN
HDMI Over IP w/RS-232 &
Bi-Directional IR
Transmitter & Receiver
§Extends HDMI, RS-232, and bi-directional IR over
IP, using a Gigabit Local Network
§Supports resolutions up to 1080p Full HD and
1920x1200 (WUXGA)
§Built-in web interface facilitates intuitive set up
and operation
§Any of the Senders within a network can be
accessed by any Receiver unit via a web browser
on a mobile device or computer, or by using the
Gefen KVM/Video over IP Keyboard Switching
Controller software (available for download at
www.gefen.com)
§Mode Selector function in web interface for
sharpness or motion optimization of image
§Versatile IR In/Ext ports work with powered Gefen
IR extenders and electrical IR from automation
control devices
§Field-upgradable firmware via web server
interface
§Locking power supply connectors
§RS-232 3.5mm mini-stereo-jack-to-DB-9
adaptors included
§Surface mountable
§Supports a total of just over 65,000 Sender
and Receiver units, depending on the network
bandwidth and number of ports on your
network switch
EXT-HDKVM-LAN
HD KVM Over IP
Transmitter & Receiver
§Extends HDMI, USB, RS-232, bi-directional stereo
analog audio, and IR over IP, using a Gigabit Local
Area Network
§Supports resolutions up to 1080p Full HD and
1920 x 1200 (WUXGA)
§Supported HDMI Features:
§HDCP
§Deep Color
§LPCM 7.1 audio, Dolby® TrueHD, and
DTS-HD® Master Audio™
§Lip-Sync pass-through
§Built-in web interface facilitates intuitive set up
and operation
§Any of the Senders within a network can be
accessed by any Receiver unit via a web browser
on a mobile device or computer, or by using the
Gefen Keyboard Switching Controller software
(available for download at (www.gefen.com)
§Supports a total of just over 65,000 Sender and
Receiver units, depending on the network band
width and number of ports on your
network switch
§USB 2.0 data rates up to 480 Mbps and
backward-compatibility with USB 1.1
§Three-port Gigabit Ethernet switch built into the
Receiver unit
§Mode button on Sender for sharpness or motion
optimization of image
§Field-upgradeable firmware via web
server interface
§Locking power supply connectors
§1U tall, half-rack width enclosures are rack-
mountable using EXT-RACK-1U-GRY
19
AV Over IP
EXT-DVIKVM-LAN
EXT-DVIKVM-LAN-L
DVI KVM Over IP
Transmitter & Receiver
DVI KVM over IP
w/ Local DVI Output
§Extends DVI, USB, RS-232, bi-directional stereo
analog audio, and IR over IP, using a Gigabit Local
Area Network
§Any combination of HDMI, DVI, and VGA Senders
and Receivers can be used together to create a
"Virtual Matrix"
§Supports resolutions up to 1080p Full HD and
1920 x 1200 (WUXGA)
§Supports 2 USB devices at Receiver side, with
500mA current capability per port, USB 2.0
data rates up to 480 Mbps, and backward-
compatibility with USB 1.1
§Any of the Senders within a network can be
accessed by any Receiver unit via a web browser
on a mobile device or computer, or by using the
Gefen Keyboard Switching Controller software
(available for download at www.gefen.com)
§Extends DVI, USB, RS-232, and stereo analog
audio over IP, using a Gigabit Local Area Network
Any combination of HDMI, DVI, and VGA Senders
and Receivers can be used together to create a
"Virtual Matrix"
§Any combination of HDMI, DVI, and VGA Senders
and Receivers can be used together to create a
"Virtual Matrix"
§Supports resolutions up to 1080p Full HD and
1920 x 1200 (WUXGA)
§Supports a local DVI monitor at Sender side
§Supports 4 USB devices at Receiver side, with
500mA current capability per port, USB 2.0
data rates up to 480 Mbps, and backward-
compatibility with USB 1.1
§Any of the Senders within a network can be
accessed by any Receiver unit via a web browser
on a mobile device or computer, or by using the
Gefen Keyboard Switching Controller software
(available for download at www.gefen.com)
§Supports a total of just over 65,000 Sender and
Receiver units, depending on the network band
width and number of ports on your
network switch
§Three-port Ethernet switch built into the
Receiver unit
§Switch/USB button facilitates scrolling between
multiple Senders and accessing a USB host
computer from multiple Receivers
§Mode button on Sender for sharpness or motion
optimization of image
§Easy-to-use web server interface for quick
system set-up, operation, and firmware upgrade
§Locking power supply connectors
§1U tall, half-rack width enclosures are rack-
mountable using EXT-RACK-1U-GRY
§Surface mounting brackets included
§Supports a total of just over 65,000 Sender
and Receiver units, depending on the network
bandwidth and number of ports on your network
switch
§Three-port Ethernet switch built into the Receiver
unit
§+ and - / Select buttons on Receiver unit allow
selection of multiple Senders
§USB button on Receiver unit allows multiple
Receivers to access a USB host computer
§Mode button on Sender for sharpness or motion
optimization of image
§Easy-to-use web server interface for quick
system set-up and firmware upgrade
§Locking power supply connectors
§1U tall, half-rack width enclosures are rack-
mountable using EXT-RACK-1U
§Surface mounting brackets included
EXT-VGAKVM-LAN
VGA KVM Over IP
Transmitter & Receiver
§Extends VGA, USB, RS-232, bi-directional stereo
analog audio, and IR over IP, using a Gigabit Local
Area Network
§Any combination of HDMI, DVI, and VGA Senders
and Receivers can be used
§Supports resolutions up to 1920x1200 (WUXGA)
§Built-in Web interface for each Sender and
Receiver unit provides intuitive control of
all features
§Any of the Senders within a network can be
accessed by any Receiver unit via a web browser
on a mobile device or computer, or by using the
Gefen Keyboard Switching Controller software
(available for download at www.gefen.com)
§Supports a total of just over 65,000 Sender and
Receiver units, depending on the network band-
width and number of ports on your network switch
§USB 2.0 data rates up to 480 Mbps and
backward-compatibility with USB 1.1
§Three-port Gigabit Ethernet switch built into the
Receiver unit
§Switch between all available Sender units using
the built-in Web interface
§Mode button on Sender for sharpness or motion
optimization of image
§Field-upgradeable firmware via web
server interface
§Locking power supply connectors
§1U tall, half-rack width enclosures are rack-
mountable using EXT-RACK-1U-GRY
§Surface mounting brackets included
Also available:
DVI KVM Over IP w/ Local Ouput
SKU: EX T-DVI
Wireless HDMI
20
EXT-WHD-1080P-SR
Wireless Extender for HDMI 5GHz
Short Range
§Wireless extension of HDMI up to 33 feet
§Supports resolutions up to 1080p Full HD, up to
7.1 channels of LPCM digital audio, and up to 5.1
channels of Dolby® and DTS® formats
§Transmits through obstacles – does not require
line-of-sight
§Uncompressed High Definition A/V from source
to display
§Less than 1 frame latency
§AES 128 Encryption
§Compatible with legacy DVI displays
§Includes Sender & Receiver Units
§Handheld IR remote for easy setup and operation
§Firmware update via Mini-USB port
§WHDI 1.0, FCC Part 15, IC, and ETSI-compliant
§Up to eight Sender units can be accessed by a
Receiver, one at a time, using its handheld
remote control
§Additional Sender units available separately
EXT-WHD-1080P-LR
Wireless Extender for HDMI 5GHz
Long Range
GTV-WHD-60G
§Wireless extension of HDMI up to 100 feet
§Supports resolutions up to 1080p Full HD, up to
7.1 channels of LPCM digital audio, and up to 5.1
channels of Dolby® and DTS® formats
§Transmits through obstacles – does not require
line-of-sight
§Long Range 5GHz performance makes it ideal for
multi-room use
§IR Back Channel for source control with carrier
frequency selector
§Uncompressed High Definition A/V from source
to display
§Less than 1 frame latency
§AES 128 Encryption
§Compatible with legacy DVI displays
§Includes Sender & Receiver Units
§Handheld IR remote for easy setup and operation
§Firmware update via Mini-USB port
§WHDI 1.0, FCC Part 15, IC, and ETSI-compliant
§Up to eight Sender units can be accessed by a
Receiver, one at a time, using its handheld
remote control
§Additional Sender units available separately
Wireless Extender for HDMI 60GHz
§Wireless extension of HDMI up to 33 feet
§Supports resolutions up to 1080p Full HD
§Uncompressed High Definition A/V from source
to display
§Near zero latency (less than one frame)
§Specifically designed for in-room operation only
§Operates in the uncluttered 60GHz frequency
region, minimizing the chances of interference
from household devices such as cordless phones
or WiFi equipment
§Field upgradable via USB port
USB, RS-232, and Audio Extenders
21
EXT-USB2.0-SR
USB 2.0 SR Extender
over one CAT-5
§Extends USB 2.0 peripherals up to 165ft (50m)
away from a computer
§Supports USB 1.1 and 2.0
§Uses industry-standard CAT-5e or better cable
§Supports all major operating systems -- Windows,
macOS and Linux
§True plug-and-play, 100% hardware solution with
no drivers required
§Can support the full 480 Mbps speed of USB 2.0
§Receiver supports a powered USB connection up
to 2A at 5V
§Sturdy metal construction of the enclosures
help provide immunity against Electro-Magnetic
Interference (EMI) and radiated noise (RFI)
§Compact enclosures are easy to install and can
be hidden away
GTB-USB2.0-4LR-BLK
USB 2.0 LR 4-Port Extender
§Extends USB 2.0 up to 330 feet
§Supports 480 Mbps using USB 2.0
§Backward-compatible with USB 1.1 devices
§Receiver supports up to four (4) USB devices
§Uses industry-standard CAT-5, CAT-5e, or CAT-6 cable
EXT-USB2.0-LR
USB 2.0 Extender
§Operate USB 2.0 peripherals up to 330ft from
a computer
§Supports low and high-speed USB
§Uses industry-standard CAT5, CAT5e, or
CAT6 cable
§Supports all major operating systems – Windows,
Mac OS X and Linux
EXT-RS232
RS232 Extender
§Extends any RS-232 compliant device up to 1000 feet from the computer
§Supports the full 9-pin RS-232 standard with a maximum data transfer rate of
115,200 baud
§Perfect for digital signage applications
§Only one CAT-5e cable required for extension
§Power only required on Sender unit
EXT-DIGAUD-141
Digital Audio Extender
§Extends any S/PDIF and TOSLINK® digital audio device up to 330 feet from the
source
§Supports multichannel digital audio like Dolby® Digital 5.1, DTS, and Dolby® TrueHD
§Supplies clear digital audio over long distances as if connected locally
§Streamlines audio installations by allowing source devices to be located in off-site
or unseen rack
§One CAT-5e cable used for extension
§Audio is transmitted digitally for zero signal loss
EXT-AUD-1000
Audio Extender
§Extends any unbalanced analog audio device up
to 1000 feet from the source
§One CAT-5e cable used for extension
§Bidirectional transmission for speaker and mic
§Plug-and-Play
§Works with PC and Mac computers
§Locking Power Connectors
§True plug-and-play, 100% hardware solution with
no drivers required
§Operates at full 480 Mbps speed when running in
USB 2.0 mode
§Receiver supports up to 2 USB powered
connections at 500 mA each
NEW
Presentation Switchers
22
EXT-4K300A-MF-41-HBTLS
EXT-4K600A-MF-51-HBTLS
4K Ultra HD Multi-Format 4x1
Scaler/Switcher w/ Auto-Switching
& HDBaseT™ Output
4K Ultra HD Multi-Format 5x1
Scaler/Switcher w/ Auto-Switching
& HDBaseT™ Output
§Inputs:
§1x HDMI
§1x DisplayPort™
§1x DVI
§1x VGA
§Outputs:
§1x HDMI
§1x HDBaseT™
§1x L/R Analog
§HDMI and DisplayPort™ inputs support up to 300
MHz TMDS clock and 10.2 Gbps data throughput
§VGA and DVI feature scaling up to 1920 x 1200
with picture adjustment capabilities
§Inputs:
§3x HDMI
§1x DisplayPort™
§1x VGA
§5x L/R Analog
§1x Mic or Line Level Balanced with 48V Phantom
Power
§Outputs:
§1x HDMI
§1x HDBaseT™
§1x L/R Analog
§Independent video and audio switching
§Supports up to 600 MHz TMDS clock and 18 Gbps
data throughput
§HDMI and DisplayPort™ inputs support up to 4K
60 Hz 4:4:4
§Scaling on all inputs to 3840 x 2160 30 Hz 4:4:4
with picture adjustment capabilities
§Balanced and single-ended microphone support
with audio ducking feature
§HDBaseT™ extension up to 130 feet/40m at 4K
and 230 feet/70m at 1080p
§RS-232 and IR pass-through and unit control
§Analog audio breakout
§Dry contact for input switching
§Advanced EDID Management
§Field-updateable firmware via USB port
§Locking power connector
§Power over HDBaseT™ (POH) provides power to
the Sender from a compatible Receiver unit over
the link cable
§Low-profile shelf-top or surface-mountable
enclosure
4K Ultra HD Multi-Format 4x1 Scaler w/ Auto-Switching & HDBaseT™ Output
Off On
EXT-4K300A-MF-41-HBTLS
POH
EXT-4K300A-MF-41-HBTLS
Firmware
4K Ultra HD Multi-Format 4x1 Scaler
w/ Auto-Switching & HDBaseT™ Output
HDBaseT™ Out
4K Ultra HD Multi-Format 5x1 Scaler w/ Auto-Switching & HDBaseT™ Output
DisplayPort™
Power Auto VGAIR HDMI
HDMI HDMI
1234 5
EXT-4K600A-MF-51-HBTLS
EXT-4K600A-MF-51-HBTLS
§Switchable 48V Phantom Power for microphone
§Switchable Mic/Line Balanced Input
§HDBaseT™ extension range up to 130 feet/40m
at 4K and 230 feet/70m at 1080p
§Control options include the front panel, handheld
IR remote, IR, RS-232, Telnet, UDP, and web
server interface
§RS-232 and IR pass-through and unit control
§Analog audio breakout
§Discrete contact closures for input switching
§Advanced EDID Management
§Field-updateable firmware via USB port
§Locking power connector
§Power over HDBaseT™ (POH) provides power to
the Sender from a compatible Receiver unit over
the link cable
§1U tall shelf-top or surface-mountable enclosure
EXT-MFP
Multi-Format Presentation Switcher
§Independent and configurable video routing for
HDMI, DVI, VGA, DisplayPort, Compostite,
and audio
§Supports input and output resolutions up to 1080p
§Full HD & 1920 x 1200 (WUXGA)
§HDCP compliant
§HDMI, DisplayPort, DVI, VGA, and Composite
Video inputs
§DisplayPort input is compatible with Mac and
PC computers
§TOSLINK® optical digital, S/PDIF coaxial digital,
and two analog L/R audio inputs
§Each audio source can be independently assigned
to any video source
§Audio sources can be temporarily switched away
from their assigned video sources
§On-screen display (OSD) menu and web server
interface allow easy set-up & control
§IP control via Telnet, UDP, and web
server interface
§RS-232 Serial interface for use with an
automation control system
§Independent IR control of up to four units in
proximity, using distinct command sets
§Password-protected user and
administrative access
§Advanced EDID Management for rapid integration
of sources and dispays
§Assignable input naming
§System Configuration Upload/Download function
§Plug-and-Play installation with little to no set-up
§Locking power supply connector
§Rack-mountable using EXT-RACK-1U-GRY
(available separately)
§Surface-mountable using the included L-brackets
NEW
NEW
23
Converters & Scalers
GTV-COMPSVID-2-HDMIS
EXT-VGA-DVI-SC
EXT-VGAA-HD-SC
EXT-DVI-2-VGAN
Composite to HDMI Scaler
VGA to DVI Scaler/Converter
VGA & Audio to HD Scaler/Converter
DVI to VGA Converter
§Inputs S-Video or Composite Video at 480i or
576i resolutions
§Outputs HDMI video at resolutions of up to 1080p
§Input resolution is automatically detected while
the output resolution and refresh rate can be
selected via the on-screen display (OSD) menu
system and front panel push-buttons
§Converts and scales VGA to DVI
§Input resolutions up to 1920 x 1200 (WUXGA)
§Output resolutions up to 1080p60 and 1920 x
1200 (WUXGA)
§On-screen display (OSD) menu allows easy set-up
and control
§Aspect Ratio Control: Full Screen, Panoramic,
Letter/Pillar, Extract/Crop
§USB port for use with Gefen Syner-G™
§Converts and scales VGA and L/R analog audio
to HDMI
§Input resolutions up to 1920 x 1200 (WUXGA)
§Output resolutions up to 1080p60 and 1920 x
1200 (WUXGA)
§On-screen display (OSD) menu allows easy set-up
and control
§Aspect Ratio Control: Full Screen, Panoramic,
Letter/Pillar, Extract/Crop
§Test Pattern Generator for quick
system configuration
§48MB frame buffer for frame rate conversion
§Scales Composite Video and S-Video to HDMI
with embedded audio
§Supports video output resolutions for computer
equipment at up to 1920x1200
§Test Pattern Generator for quick system
configuration
§Gefen Syner-G™ simplifies in-field firmware
updates and advanced EDID management
including custom input timings
§Wide power supply operating range
(6V to 24V DC)
§Locking power supply connector
§Surface mountable
§Embeds 2-channel analog stereo audio in
HDMI signal
§Gefen Syner-G™ simplifies in-field firmware
updates and advanced EDID management
including custom input timings
§USB port for use with Gefen Syner-G™
§Wide power supply operating range
(6V to 24V DC)
§Locking power supply connector
§Surface mountable
§Enables DVI source to be displayed on VGA
monitor or projector
§Supports resolutions up to 1920x1200
§EDID Management for rapid integration of source
and display
§Built-in EDID switch allows choice between local
EDID and external EDID
24
Converters & Scalers
EXT-3G-HD-C
EXT-HD-3G-C
EXT-HDVGA-3G-SC
HDMI to 3GSDI Converter
3GSDI to HDMI Converter
HDMI & VGA & Audio to 3GSDI
Converter
§Converts SDI to HDMI resolutions up to 1080p60
§Output resolutions up to 1080p Full HD
§HDMI (YCbCr 4:4:4) or DVI (RGB 4:4:4)
output modes
§Supports up to 10 bit color on input and output
§Converts up to 1920 x 1200 (WUXGA) & 1080p
Full HD
§Output resolutions up to 1080p Full HD
§HDMI (YCbCr 4:4:4) or DVI (RGB 4:4:4)
output modes
§Converts and scales HDMI and VGA and L/R
analog audio to SDI
§Supports resolutions up to 1920x1200
§Aspect Ratio Control: Full Screen, Panoramic,
Letter/Pillar, Extract/Crop
§Up to LPCM 7.1 audio support
§Mini USB port for use with Gefen Syner-G™
§Wide power supply operating range
(6V to 24V DC)
§Supports HDMI 12 bit color and SDI 10-bit color
§Up to LPCM 7.1 audio support
§Mini USB port for use with Gefen Syner-G™
§Wide power supply operating range
(6V to 24V DC)
§Test Pattern Generator for system configuration
§Gefen Syner-G™ simplifies in-field firmware
updates and advanced EDID management
including custom input timings
25
Audio Converters
GTV-DIGAUD-2-AAUD
Digital Audio to Analog Adapter
§Converts S/PDIF or TOSLink digital audio signals
to analog L/R audio
§Digital interpolation filter and digital to analog
converter (DAC)
§Accepts uncompressed digital audio as input
§Samples at 32, 44.1, 48 and 96 KHz
§2-channel LPCM (Linear Pulse Code Modulation)
§24-bit S/PDIF incoming bitstream on left and
right channels
§Compact and easy to install
GTV-AAUD-2-DIGAUD
Analog to Digital Audio Adapter
§Converts analog L/R signals to digital S/PDIF
or TOSLink
§Compact and easy to install
§Simple to Operate
§Supports 48 kHz output sampling frequency
§Coaxial and optical output ports
§Right and Left RCA Stereo input ports
§Supports optical cable run of up to 5 meters
(15 feet)
§Signal To Noise Ratio: >90dB (20Hz-20kHz A
weight filter)
§THD+N < 0.01% at 1kHz at reference level
§Frequency Response: < +/- 0.5dB 20Hz-20kHz
GTV-DD-2-AA
Digital Audio Decoder
§Converts S/PDIF or TOSLINK digital audio to L/R
analog audio
§Digital interpolation filter and digital to analog
converter (DAC)
§Supports up to 6 channels (up to 5.1 Surround) of
audio encoded in Dolby Digital
§Auto samples at frequencies of 32, 44.1, 48 KHz
§24-bit incoming bitstream on left and
right channels
§Allows listening to digital audio sources on legacy
analog sound systems
§Compact and easy to install
GTV-DIGAUDT-141
Digital Audio Translator
§Compact size and easy to install
§Supports amplification of audio signal and extends
distance for both output formats
§Supports two-way conversion: Coaxial to
TOSLINK, or TOSLINK to Coaxial
§Supports input audio signal from two channels up
to 5.1 channels.
§Select one input and send audio to both coax and
TOSLINK outputs simultaneously
26
EDID Detectives
EXT-HD-EDIDPN
EXT-HDBOOST-141
EXT-DVI-EDIDP
HDMI Detective Plus
Booster for HDMI with EDID
Detective
DVI Detective Plus
§Supports resolutions up to 1080p Full HD and
1920x1200 (WUXGA)
§USB port for advanced programming of features
such as EDID management
§Configurable EDID using Gefen Syner-G™ software
suite, downloadable from Gefen website
§DDC Re-clocking
§Records the EDID from a display
§Extends copper HDMI cables up to 115 feet at 4K
Ultra HD and 4K Cinema (DCI)
§Extends copper HDMI cables up to 150 feet at
1080p Full HD Supported resolutions include 4K
Ultra HD, 4K Cinema, 1080p Full HD, and 2048 x
1536 (QXGA)
§USB port for advanced programming of features
such as video equalization, pre-emphasis, and
EDID management
§Configurable EDID using Gefen Syner-G™ software
suite, downloadable from Gefen website
§Supports resolutions up to 1920x1200, 2K, and
3840x2400 (Dual Link)
§Quick and easy way to store EDID information
from any DVI display
§Provides a virtual EDID to maintain active monitor
status when switching away from a source
§HDCP pass-through
§6 pre-programmed EDID profiles
§6 user-programmable EDID banks for copying/
uploading EDIDs
§Selectable HDCP pass-through
§Field updatable firmware via USB port
§Compact and portable
§DDC Re-clocking
§EQ adjustment for best results with varying cable
types and lengths
§Can record the EDID from a display
§6 pre-programmed EDID profiles
§6 user-programmable EDID banks for copying/
uploading EDIDs
§Selectable HDCP pass-through
§Field updatable firmware via USB port
§Compact and portable
§Records the EDID from a display
§5 pre-programmed EDID profiles
§EDID write protection switch
§No power is required after initial programming
§Compact and portable
27
Seamless and Multiview Switchers
and Video Wall Controllers
EXT-HD-VWC-144
EXT-UHD600A-MVSL-41
EXT-UHD600A-VWC-14
HD Video Wall Controller
4K Ultra HD 600 MHz 4x1
Multiview Seamless Switcher
w/ Audio De-Embedder
4K Ultra HD 600 MHz Video Wall
Controller w/ Audio De-Embedder
§Create a 2x2 video wall from any Hi-Def source,
using four HDTV displays
§Split and scale a single Hi-Def source to
four displays
§Input and Output resolutions up to 1080p Full HD
and 1920x1200 (WUXGA)
§HDCP compliant
§Advanced Bezel Compensation feature provides
compatibility with virtually any screen frame
width, and allows for accurate display of
the image
§Controllable via front panel, IR, IP (web server
interface, Telnet, and UDP), and RS-232
§Create a 2x2 video wall from a 4K Ultra HD 600
MHz source, using four HD displays
§Input resolution up to 4K Ultra HD 600 MHz (60
Hz, 4:4:4)
§Output resolution (per display) up to 1080p Full
HD
§HDCP 2.2 and 1.4 compliant
§Advanced Bezel Compensation feature provides
compatibility with virtually any screen frame
width, and allows for accurate display of the
§Built-in Audio De-Embedder breaks out 2 channel
analog audio from the HDMI signal, allowing the
audio content to be sent to external amplifiers and
music distribution systems for added impact
§Seamless switcher scales and sizes each of the
four inputs, and outputs them one at a time or as
windows on a single display
§Input resolution (per input) up to 1080p Full HD
§Output resolution up to 4K Ultra HD 600 MHz (60
Hz, 4:4:4)
§HDCP 1.4 compliant
§Seamless switching ensures no switching delay
and no picture loss during transitions
§Default pre-configured Multiview window
arrangements can be accessed via front panel
preset push-buttons and all other available
interfaces
§Custom user-configurable Multiview window
layouts can be accessed via front panel preset
push-buttons and all other available interfaces
§User-selectable playback of HDMI audio content
from any of the four inputs
§Easy to use on-screen Graphical User Interface
§Advanced web server interface using an external
computer
§Handheld IR remote control
§Field-upgradeable firmware via web server
interface
§USB port
(reserved for future product enhancements)
§Locking power supply connector
§1U tall rack-mountable enclosure, rack ears
included
§Controllable via front panel, IR, IP (web server
interface, Telnet, and UDP), and RS-232
§Enhanced API for added functionality with third-
party control systems
§Easy to use on-screen Graphical User Interface
(GUI)
§Advanced web server interface using an external
computer
§Handheld IR remote control
§Field-updateable firmware via mini-USB port and
Gefen Syner-G™ software
§Locking power supply connector
§1U tall rack-mountable enclosure, rack ears
included
§Built-in Audio De-Embedder breaks out 2 channel
analog audio from the HDMI signal, allowing the
audio content to be sent to external amplifiers
and music distribution systems for added impact
§Controllable via front panel controls, IR, IP (web
server interface, Telnet, and UDP), and RS-232
§Enhanced API for added functionality with third-
party control systems
§Easy to use on-screen Graphical User Interface
(GUI) and web server interface
§Handheld IR remote control and IR Extender input
on back panel
§Field-updateable firmware via mini-USB port and
Gefen Syner-G™ software
§Locking power supply connector
§1U tall rack-mountable enclosure, rack ears
included
28
Seamless and Multiview Switchers
and Video Wall Controllers
EXT-HD-SL-444
EXT-HD-MVSL-441
4x4 Seamless Matrix for HDMI
Multiview Seamless Switcher
§Seamless matrix scales each of its four inputs,
and routes them to any or all of the four outputs
without frame loss
§Input and Output resolutions up to 1080p Full HD
and 1920x1200 (WUXGA)
§HDCP compliant
§Seamless switching ensures no switching delay
and no picture loss during transitions
§Ten user-configurable routing presets can be
accessed via front panel push-buttons
§Controllable via front panel controls, IR, IP (web
server interface, Telnet, and UDP), and RS-232
§Seamless switcher scales and sizes each of the
four inputs, and outputs them one at a time or as
windows on a single display
§Input and Output resolutions up to 1080p Full HD
and 1920x1200 (WUXGA)
§HDCP compliant
§Seamless switching ensures no switching delay
and no picture loss during transitions
§Default pre-configured Multiview window
arrangements can be accessed via five front panel
preset push-buttons
§Custom user-configurable Multiview window
layouts can be accessed via five front panel
preset push-buttons
§Locking power supply connector
§Easy to use on-screen Graphical User Interface
(GUI)
§Handheld IR remote control and IR Extender input
on back panel
§Field-upgradable firmware via web server
interface
§USB port (reserved for future product
enhancements)
§Locking power supply connector
§1U tall rack-mountable enclosure, rack ears
included
§User-selectable playback of HDMI audio content
from any of the four inputs
§Controllable via front panel controls, IR, IP (web
server interface, Telnet, and UDP), and RS-232
§Easy to use on-screen Graphical User Interface
(GUI) and web server interface
§Handheld IR remote control and IR Extender input
on back panel
§Field-upgradable firmware via web server
interface
§USB port (reserved for future product
enhancements)
§1U tall rack-mountable enclosure, rack ears
included
www.gefen.com
1950 Camino Vida Roble, Suite 150, Carlsbad, CA 92008
800.472.5555 or 707.283.5900
©2018 Nortek Security & Control. All rights reserved.
Gefen
®
is a registered trademark of Nortek Security & Control.
All trademarks are the property of their respective owners.
All features, specifications, hardware, packaging, and
documentation are subject to change without notice.
Rev A - 01/2018
