ceiling mount
1-800-BUY-HIFI – www.nilesaudio.com
Designer Aesthetics
Audiophile Performance
Installation Ease
CM8
High Denition loudspeakers are optimal for advanced home theaters and primary listening rooms.
8” Interlaced glass ber woofer cone and an advanced IMPACT tweeter provide the ultimate in
performance and musicality.
HIGH DEFINITION LOUDSPEAKER SPECIFICATIONS SHEET
■ Designer Aesthetics Magnetically attached
MicroThinTM speaker grilles ensure a clean, virtually
invisible appearance that blends with the room’s
aesthetics. Optional square grilles provide added
design exibility.
■ Superior Sound Quality Precision tuned and voiced
xed woofer ceiling-mount loudspeakers provide
graduated performance for all types of applications.
Whether you are listening to background talk radio or
a complete orchestra, Niles CM series delivers optimal
performance and reliability.
■ Installation Ease Three patent-pending spring
tensioned mounting clamps permit quick installation
and compensate for uneven mounting surfaces and
varied environmental conditions. Weather-resistant
construction enables installation in moist areas, such
as bathrooms or outdoors under eaves.
■ Install With Confidence The best-built loudspeakers
deserve the best protection—the Niles Lifetime Limited
Warranty.
FEATURES AND BENEFITS
8" 2-way left/center/right
ceiling-Mount louDSPeaKer
LIFETIME
LIMITED WARRANTY
4 3/4” (12.1 cm) Depth
11 3/8 (28.9 cm)
Frame Outer
Diameter
9-3/4" (24.8 cm)
Hole Cutout
9-3/4” (24.8 cm)
Hole Cutout
RELATED PRODUCTS
SG8C
8" Square Loudspeaker Grille
Stock Number: FG01646
NCB8C
8" New Construction Bracket
Stock Number: FG01648
CM7SD
7” Shallow Depth
CM7PR
7” Performance
CM7MP
7” Multi Purpose
CM7HD
7” High Denition
CM7FX
7” Surround Effects
CM8MP
8” Multi Purpose
CM8PR
8” Performance
CM8HD
8” High Denition
CM8SI
8” Stereo Input
CM7SI
7” Stereo Input
CM7BG
7” Background
CM4PR
3.5” Performance
1-800-BUY-HIFI – www.nilesaudio.com
©2011 The AVC Group, LLC. All Rights Reserved. Niles, the Niles logo and Blending High Fidelity and Architecture are registered trademarks of The AVC Group, LLC. MicroThin is a trademark of The
AVC Group, LLC. All other trademarks are the property of their respective owners. We reserve the right to change features, descriptions, and/or specifications at any time without notice. CS0327A
2-WAY CEILING-MOUNT LOUDSPEAKERS
CM8HD
8” 2-Way Left/Center/Right
High Definition Ceiling-Mount
Loudspeaker
For advanced home theaters and
primary listening rooms
Packaged Individually with
Round MicroThin™ Grille
Stock Number
FG01663
F E ATUR ES
■ 8” IMPACT (Improved Aluminum Ceramic Technology) woofer cone with
curvilinear prole and extended pole provides natural, at response
■ 1” nano-coated IMPACT dome tweeter utilizes a vapor deposited coating to
move any ringing frequencies outside the range of hearing for ultra-detailed high
frequencies
■ Butyl rubber surround damps resonance and provides exceptional durability
■ Proprietary bridge-mounted tweeter pivot mechanism focuses the high
frequency sound in any direction up to 20° without diffraction
■ Three-position tweeter level control for precise matching to room acoustics
■ Magnetically attached, rust-resistant grille covers install quickly and provide a
low prole look
■ Weather resistant construction reduces installation limitations and provides
unique solutions in moist environments like bathrooms or outdoors under eaves
■ Patent-pending spring tensioned mounting clamps permit quick installation and
compensate for uneven mounting surfaces and varied environmental conditions
SpEcIFIcATIoNS
■ Frequency Response: 48Hz to 21kHz +/-3dB
■ Impedance: 8 ohm nominal; 6 ohm minimum
■ Recommended Amplier Power: 10 to 160 Watts
DImENSIoNS
■ Frame Dimensions: 11 3/8 inches (28.9 cm)
■ Hole cutout dimensions: 9 3/4 inches (24.8 cm)
■ Depth behind ceiling (5/8” drywall): 4 1/8” (10.5 cm)
■ Shipping Weight: 6.7 lbs (3 kg)
WARRANTY: Lifetime Limited
