Wireless Wall Control Station
Connect transmitter (X) and
wall control station (A) by using
the programming connector (B).
1
AB
CD
2
A
B
X
1.
2.
2s A1
+
X1
X1A1
Press and hold the designated transmitter button
(X1). The hand-held transmitter LED lights up.
Then press and hold the desired button (A1) on
your wireless wall control station (A). The
transmitter LED flashes and lights up steady after
2 seconds. Release both buttons – programming
is complete.
A. Wall Control Station
B. Programming Connector
C. Screws
D. Anchors
Disconnect transmitter and remove
programming connector.
Pg. 1
Package Contents
Programming
Command 133: 315 MHz
3
C
D
Ø
6 mm
Do not dispose batteries in household waste!
4
READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS
CAREFULLY:
1. Locate the wireless wall control station: within sight of door, at a
minimum height of 5 feet (1.5m) above the ground so small
children cannot reach it, and away from all moving parts of the door.
2. Never let children operate or play with door controls.
3. Always keep the moving door in sight and away from people and
objects until it is completely closed. NO ONE SHOULD CROSS THE
PATH OF THE MOVING DOOR.
4. NEVER GO UNDER A STOPPED, PARTIALLY OPEN DOOR.
Version: 6/18
Part #160947
Printed in Germany
Pg. 2
FCC Certified: This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
FCC § 15.21 (Warning Statement): Any changes or modifications
not expressly approved by the party responsible for compliance
could void the user´s authority to operate the equipment.
CNR Certified: This device complies with Industry Canada
licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Mounting
Battery Replacement
©2018 All rights reserved.
