Model CDR510 User Guide

CD Recorder/CD Player

ecordabl

CLASS 1 LASER PRODUCT

LOUKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

- 2 -

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL

The lightning flash with arrowhead symbol, within

an equilateral triangle, is intended to alert the user

to the presence of uninsulated "dangerous voltage"

within the product's enclosure that may be of

sufficient magnitude to constitute a risk of electric

shock to persons.

The exclamation point within an equilateral triangle

is intended to alert the user to the presence of

important operating and maintenance (servicing)

instructions in the literature accompanying the

appliance.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

LASER SAFETY

This unit employs lasers. Only a qualified service person

should remove the cover or attempt to service this device, due

to possible eye injury.

CAUTION

USE OF CONTROLS OR ADJUSTMENTS

OR PERFORMANCE OF PROCEDURE

OTHER THAN THOSE SPECIFIED HEREIN

MAY RESULT IN HAZARDOUS RADIATION

EXPOSURE.

Warnings and Cautions

NOTE TO CATV SYSTEM INSTALLER:

This reminder is provided to call the CATV (Cable-

TV) system installer's attention to Article 820-40 of

the NEC, which provides guidelines for proper ground-

ing and, in particular, specifies that the cable ground

shall be connected to the grounding system of the

building, as close to the point of cable entry as

practical.

NEC - NATIONAL ELECTRICAL CODE

ANTENNA

LEAD IN

WIRE

GROUND

CLAMP

ANTENNA

DISCHARGE

UNIT

(NEC SECTION

810-20)

GROUNDING

CONDUCTORS

(NEC SECTION

810-21)

ELECTRIC

SERVICE

EQUIPMENT

GROUND CLAMPS POWER SERVICE

GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

NOTE:

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful in-

terference in a residential installation. This equipment

generates, uses and can radiate radio frequency en-

ergy and, if not installed and used in accordance with

the instructions, may cause harmful interference to

radio communications. However, there is no guaran-

tee that interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception, which can

be determined by turning the equipment off and on,

the user is encouraged to try to correct the interfer-

ence by one or more of the following measures:

• Re-orient or relocate the receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is con-

nected.

• Consult the dealer or an experienced radio/TV

technician for help.

NOTE: Changes or modifications may cause this

unit to fail to comply with Part 15 of the FCC Rules

and may void the user's authority to operate the

equipment.

This Class B digital apparatus complies

with Canadian ICES-003.

Cet appareil numérique de la Classe B est

conforme á la norme NMB-003 du Canada.

FIGURE 1

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE, ANSI/NFPA 70

- 3 -

Do not expose the equipment to rain or moisture.

Do not remove the cover from the equipment.

Do not insert anything into the equipment through

the ventilation holes.

Do not handle the mains lead with wet hands.

Do not cover the ventilation with any items such

as tablecloths, newspapers, curtains, etc.

No open flame sources, such as lighted candles,

should be placed on the equipment.

When disposing of used batteries, please comply

with governmental regulations or environmental

public instruction's rules that apply in your country

or area.

WARNINGS

CE marking (only EU version)

This product is in conformity with the EMC

directive and low-voltage directive.

Equipment mains working system

This product complies with household power and

safety requirements in your area. CDR510 can be

Recording and play back of any material may

require consent. For further information refer to

the following US ordinances:

• Copyright act of 1956

• Dramatic and Musical Performance Act 1958

• Performers Protection Acts 1963 and 1972

• any subsequent statutory enactments and

orders

Precautions - installation

• Do not expose the CDR510 to excessive heat,

excessive cold, rain, moisture, or dust this may

cause damage to the unit.

• If a foreign object or water does enter the unit,

contact your nearest dealer or service center.

• All players produce some heat during operation and

this heat must be allowed to dissipate freely. Do not

close any ventilation openings and be sure there is

adequate ventilation space behind, beside and

above the player so air is allowed to circulate freely

around the unit.

• Be sure ventilation holes are not covered.

• Prevent extra heat from reaching the unit. Never put

the CDR510 in direct sunlight or near a heat

source.

• Do not expose the CDR510 to electrostatic dis-

charges.

• Do not place heavy objects on the unit.

• Be sure the CDR510 is placed on a vibration-free

surface.

Precautions - connection

• Unplug the power cord from the AC outlet or turn off

the POWER switch before making any connection.

• Connect one cable at a time observing the 'input'

and 'output' labeling. This will avoid any cross

connections between channels and signal inputs

and outputs.

• Insert plugs securely. An incomplete connection

may result in noise.

• Before connecting other audio or video equipment

to the CDR510, please read their owner's manuals.

CE marking

English

This product is in conformity with the EMC directive and low-voltage directive.

Français

Cet appareil est cnforme á la directive EMC et á la de directive sur les basses tensions.

Deutsch

Dieses Greät entspricht den EMC-Richtlinien und den Richtlinien für Niederspannungsgeräte.

Nederlands

Dit apparaat voldoet aan de EMC-richtlijnene en de richtlijnen vooor apparatuur met laag voltage.

Italiano

Quest' unitá è conforme alle diretive EMC ed alla direttiva sulle basse tensioni.

Português

Esta unidade está em conformidade com as directivas EMC e as directivas de baixa voltagem.

Español

Esta unidad estáde acuerdo con las normas EMC y las relacionadas con baja tensión.

MARANTZ EUROPE B.V.

5600 EINDHOVEN

THE NETHERLANDS

SI DICHIARA CHE L'APPARECCHIO SINTO-AMPLIFACATORE SR-39 RISPONDE ALLE PRESCRIZIONI DELL'ART.

2 COMMA 1 DEL D.M. 28 AGOSTO 1995 N° 548.

FATTO A EINDHOVEN, IL 1/1/1997.

"Este aparato lleva elementos antiparasitarios necesarios para cumplir con ls limites que se estableren en el Anexo

V del Reglamento sobre Pertubaciones Radioelectricas e Interferencias aprobado en el Real Decreto 138/1989.

(B.O.E. de 9 Febrero 1989)."

WARNINGS FOR LASER RADIATION

CAUTION: INVISIBLE LASER RADIATION WHEN OPEN, DO NOT STARE INTO BEAM.

DANGER: INVISIBLE LASER RADIATION WHEN OPENT, AVOID DIRECT EXPOSURE TO BEAM.

VAROI: AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTINANAYMÄTTÖMÄALLE

LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.

VARNING! OSYNLIGH LASERSTÄLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRREN ÄR URKOPPLAD.

BETRAKTA EJ STRALEN.

- 4 -

- 5 -

Important Safety Instructions

READ BEFORE OPERATING EQUIPMENT

This product was designed and manufactured to meet strict quality

and safety standards. There are, however, some installation and

operation precautions which you should be particularly aware of.

1. Read Instructions – All the safety and operating instructions

should be read before the product is operated.

2. Retain Instructions – The safety and operating instructions

should be retained for future reference.

3. Heed Warnings – All warnings on the product and in the

operating instructions should be adhered to.

4. Follow Instructions – All operating and use instructions should

be followed.

5. Cleaning – Unplug this product from the wall outlet before

cleaning. Do not use liquid or aerosol cleaners. Use a damp

cloth for cleaning.

6. Attachments – Do not use attachments not recommended by

the product manufacturer as they may cause hazards.

7. Water and Moisture – Do not use this product near water–for

example, near a bath tub, wash bowl, kitchen sink, laundry tub,

swimming pool, in a wet basement, and the like.

8. Accessories – Do not place this product on an unstable cart,

stand, tripod, bracket, or table. The product may fall, causing

serious injury to a child or adult, and serious damage to the

product. Use only with a cart, stand, tripod, bracket or table

recommended by the manufacturer, or sold with the product.

Any mounting of the product should follow the manufacturer's

instructions, and should use a mounting accessory

recommended by the manufacturer.

9. A product and cart combination

should be moved with care. Quick

stops, excessive force, and

uneven surfaces may cause the

product and cart combination to

overturn.

10. Ventilation – Slots and openings in

the cabinet are provided for

ventilation and to ensure reliable

operation of the product and to

protect it from overheating. These

openings must not be blocked or covered. The openings should

never be blocked by placing the product on a bed, sofa, rug, or

other similar surface. This product should not be placed in a

built-in installation such as a bookcase or rack unless proper

ventilation is provided or the manufacturer's instructions have

been adhered to.

11. Power Sources – This product should be operated only from the

type of power source indicated on the marking label. If you are

not sure of the type of power supply to your home, consult your

product dealer or local power company. For products intended

to operate from battery power or other sources, refer to the

operating instructions.

12. Power Cord Protection – Power supply cords should be routed

so that they are not likely to be walked on or pinched by items

placed upon or against them, paying particular attention to

cords at plugs, convenience receptacles, and the point where

they exit from the product.

the service technician has used a replacement plug specified

by the manufacturer that has the same overload protection as

the original plug.

15. Outdoor Antenna Grounding – If an outside antenna or cable

system is connected to the product, be sure the antenna or

cable system is grounded so as to provide some protection

against voltage surges and built-up static charges. Article 810

of the National Electrical Code, ANSI/NFPA 70, provides

information with regard to proper grounding of the mast and

supporting structure, grounding of the lead-in wire to an

antenna discharge unit, size of grounding conductors, location

of antenna-discharge unit, connection to grounding electrodes,

and requirements for the grounding electrode. See Figure 1.

16. Lightning – Lightning – Unplug the unit from the wall outlet and

disconnect the antenna or cable system for added protection

during a lightning storm or when it is left unattended and

unused for long periods of time. This will prevent damage to the

product due to lightning and power line surges.

17. Power Lines – An outside antenna system should not be

located in the vicinity of overhead power lines or other electric

light or power circuits, or where it can fall into such power lines

or circuits. When installing an outside antenna system, extreme

care should be taken to keep from touching such power lines or

circuits as contact with them might be fatal.

18. Overloading – Do not overload wall outlets, extension cords, or

integral convenience receptacles as this can result in a risk of

fire or electric shock.

19. Object and Liquid Entry – Never push objects of any kind into

this product through openings as they may touch dangerous

voltage points or short-out parts that could result in a fire or

electric shock. Never spill liquid of any kind on the product.

20. Servicing – Do not attempt to service this product yourself as

opening or removing covers may expose you to dangerous

voltage or other hazards. Refer all servicing to qualified service

personnel.

21. Damage Requiring Service – Unplug this product from the wall

outlet and refer servicing to qualified service personnel under

the following conditions:

a. When the power supply cord or plug is damaged.

b. If liquid has been spilled, or objects have fallen into the product.

c. If the product has been exposed to rain or water.

d. If the product does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions, as an improper

adjustment of other controls may result in damage and will often

require extensive work by a qualified technician to restore the

product to its normal operation.

e. If the product has been dropped or damaged in any way, and

f. When the product exhibits a distinct change in performance –

this indicates a need for service.

22. Replacement Parts – When replacement parts are required, be

sure the service technician has used replacement parts

specified by the manufacturer or have the same characteristics

as the original part. Unauthorized substitutions may result in

fire, electric shock, or other hazards.

23. Safety Check – Upon completion of any service or repairs to

this product, ask the service technician to perform safety

checks to determine that the product is in proper operating

condition.

24. Wall or Ceiling Mounting – The product should be mounted to a

wall or ceiling only as recommended by the manufacturer.

25. Heat – The product should be situated away from heat sources

such as radiators, heat registers, stoves, or other products

(including amplifiers) that produce heat.

13. Grounding or Polarization –

This product may be equipped

with a grounded polarized

alternating-current line plug (a

plug having one blade wider

than the other and a ground

prong). This plug will fit into the

power outlet only one way.

This is a safety feature. If you

are unable to insert the plug

fully into the outlet,contact

your electrician to replace your obsolete outlet. Do not defeat

the safety purpose of the polarized plug.

14. Protective Attachment Plug – The product is equipped with an

attachment plug having overload protection. This is a safety

feature. See Instruction Manual for replacement or resetting of

protective device. If replacement of the plug is required, be sure

Table of Contents

- 6 -

Topic page

Warnings and Cautions ........................................2

Important Safety Instructions ................................5

Table of Contents .................................................6

Introduction ..........................................................7

Features ...............................................................8

Package contents .................................................9

Remote batteries ..................................................9

Connections (basic) ..............................................9

How to Play back................................................ 10

Play back features ....................................... 11

How to Record....................................................12

To record from the CD drive .........................12

To record from an external source ...............13

Notes regarding recording ...........................14

Controls and Displays front

1 IR (remote control sensor) ..........................15

2 CDR drive (disc tray) ..................................15

3 CDR open button ...................................15

4 CDR button ................................................ 15

5 PLAY MODE button....................................15

6 CD button ...................................................15

7 CD open button .....................................15

8 MP3 indicator ............................................. 15

9 PITCH indicator ..........................................15

10 CD drive .....................................................16

11 POWER button ...........................................16

12 Record button ........................................16

ONE TOUCH RECORD .....................................16

13 Stop button ............................................16

14 Play/Pause button ...............................16

15 ERASE button ............................................16

16 REC MODE button .....................................16

17 MENU/STORE button ............................... 16

18 REC LEVEL/SELECT control ..................... 17

19 TIME button ................................................18

20 TEXT button ...............................................18

21 PROG button ..............................................18

22 FINAL button ..............................................18

23 INPUT button..............................................18

24 CANCL/DELETE button .............................19

25 Reverse button ....................................19

26 Forward button ....................................19

27 Stop button ............................................19

28 Play/Pause button ...............................19

29 HEADPHONE jack .....................................19

30 LEVEL control ............................................19

Display ...............................................................20

1 Alphanumeric display .................................20

2 REM label ...................................................20

3 REC label ...................................................20

4 TIME label ..................................................20

5 TRACK label .............................................. 20

6 TOTAL label................................................ 20

7 REM label ...................................................20

8 TRACK label .............................................. 20

9 TIME label ..................................................20

10 STEP label ................................................. 20

11 PROGRAM label ........................................20

Topic page

12 RANDOM label ...........................................20

13 REPEAT label .............................................20

14 ALL label .................................................... 20

15 TRACK label .............................................. 20

16 SCAN label .................................................20

17 DIGI label ...................................................21

18 SYNC label .................................................21

19 MANUAL label ............................................21

20 ANALOG label ............................................21

21 OPTI label ..................................................21

22 Large CDR box ..........................................21

23 Small CDR box ........................................... 21

24 Recording icon .......................................21

25 Pause icon .............................................21

26 Play icon ................................................21

27 CD-RW label ..............................................21

28 Track numbers ...........................................21

29 Dubbing label .........................................21

30 Level meter ................................................22

31 CHANGER mode indicator .................22

32 Large CD box .............................................22

33 Small CD box .............................................22

34 Pause icon .............................................22

35 Play icon ................................................22

36 CD-RW label ..............................................22

Controls and Connections rear

1 CD ANALOG OUT jacks.............................22

2 CD DIG OUT jack .......................................22

3 BALANCED IN

ANALOG XLR Inputs L & R ........................22

4 TRIM R & L.................................................23

5 ANALOG IN / OUT jacks ............................23

6 INPUT SELECT switch ............................... 23

7 RS-232C connector ....................................24

8 DIGITAL IN & OUT connectors (SPDIF) .....24

9 DIGITAL IN connector (optical) ...................24

10 EXT / INT (IR) switch ..................................24

11 REMOTE (RC5) IN/OUT jacks ................... 24

12 AC IN..........................................................25

Remote control (IR)*

1 TRAY OPEN/CLOSE button .................25

2Standby power button ................................25

3DOOR OPEN/CLOSE button .....................25

4 REPEAT button ..........................................25

5 PROG button ..............................................25

6 RANDOM button ........................................25

7 Alphanumeric keypad .................................26

8 DISPLAY button .........................................26

9 CDR button ................................................26

10 MENU button ..............................................26

11 Track Skip backward button ................26

12 Fast backward search button ...............26

13 SCROLL button ..........................................26

14 PAUSE button ........................................26

15 Stop button ............................................26

*Controls in italics do not function on the CDR510.

(table of contents continues)

- 7 -

Table of Contents continued

Topic page

16 CD button ...................................................26

17 Track skip forward button ....................26

18 CANCEL button .......................................... 26

19 Fast forward search button .................26

20 Play button ............................................26

21 REC button ............................................27

22 TR. INCR. button ....................................... 27

23 SCAN button ..............................................27

24 DIMMER button ..........................................27

25 REC TYPE button ......................................27

26 SOURCE button .........................................27

27 ENTER button ............................................27

MENU mode .......................................................28

Menu Settings Chart.......................................28

TEXT EDIT .....................................................29

TEXT ERASE .................................................30

TEXT VIEW ....................................................30

AUTO TRACK ................................................ 31

Silence gap ................................................31

AUTO STOP ...................................................32

Menu exceptions ............................................32

REC BALANCE ..............................................33

TEXT ON/OFF................................................ 33

SRC................................................................34

COPY protection ............................................35

PITCH ............................................................36

PITCH ON/OFF ..............................................36

AUTO CUE .....................................................37

AUTO CUE LEVEL .........................................37

PLAY MODE ...................................................38

SINGLE PLAY ................................................38

END WARNING .............................................39

Recording modes ...............................................40

REC EXT DISC,

REC EXT MAN, MINUTE TRACK ..................40

RECORD FAST, REC LISTEN,

REC MP3 DISC, MAKE CD ...........................41

MP3 ...................................................................42

AUTO MP3 LOAD .......................................... 42

MP3 LOAD .....................................................43

How to record MP3.........................................43

MP3 Album/file structure ................................44

MP3 FILE PLAYBACK.................................... 44

How to PROGRAM tracks ..................................45

To program for recording ................................45

Finalizing ............................................................46

Unfinalizing .........................................................47

How to unfinalize, erase a track,

or erase a CD-RW disc ..................................47

DISPLAY messages ...........................................48

About Compact Discs .........................................49

RS-232C control .................................................51

RC-5 codes ........................................................53

Troubleshooting ..................................................54

Specifications .....................................................55

LIMITED WARRANTY ........................................56

Introduction

The CDR510 CD Recorder/CD Player is a professional

CD Recorder and a professional CD Player in the

same unit. The CD Recorder and CD Player can be

operated as independent devices. That saves you

space and you don't have to have two units. The

CDR510 can also operate combined, with intercon-

nects between the CD Recorder and CD Player that

provide functions not available with separate units,

such as the ability to copy CDs at 2X speed.

Independent operation is called DUAL MODE.

DUAL MODE provides the convenience of having both

a CD Recorder and a CD Player in one rack mount-

able unit. You can play a CD in the CD drive and

independently record or play a CD in the CDR drive.

You can choose CHANGER MODE. When one drive

completes playing a CD the other drive automatically

starts play back. You can program the order of play

back tracks from CDs in either or both drives.

In CHANGER MODE you can record from the CD

drive to the CDR drive. The interconnection of the two

drives in the same unit permits double speed analog or

digital copying.

For CD recording you can:

• record on CD-R or CD-RW discs

• record any of the playing options

• record and listen from the CD drive

• record at 2X speed from the CD drive

• record using analog (RCA or XLR), or digital

sources including optical or RCA coaxial connec-

tions

For CD playing you can:

• cue to music (start at the beginning of the audio

and adjust the auto cue point)

• single track play

• A-B repeat

• adjust play back pitch

• connect to an amplifier/speaker system

• connect to an external mixer or recording device

Features

The CDR510 incorporates a suite of professional

features for audio input, audio output, loop out, remote

control, recording modes, finalizing, CD-Text entry and

play back, automatic track incrementing, minute track

incrementing, play back track selection: single track,

scan play, programmed play, random play, and repeat

play.

Audio input (CDR drive)

• balanced XLR L and R inputs

• analog RCA line level

• digital RCA (SPDIF)

• digital optical (fiber-optic cable)

Audio output (CD drive)

• analog RCA line level

• digital RCA (SPDIF)

Audio output (CDR drive)

• analog RCA line level

• digital RCA (SPDIF)

• loop out digital RCA (SPDIF) (cascade recording)

Remote control (CDR drive and CD drive)

• full featured IR remote control

• RC-5 via RCA jacks, input and output

• RS-232C for external control

Recording modes

(CDR drive recording from the CD drive)

• RECORD FAST - double speed recording

• REC LISTEN - 1X recording enables listening to a

recording while making it.

• MAKE CD - double speed recording with auto-

matic finalizing

• REC MP3 DISC - same as REC LISTEN when

recording data from an MP3 disc to a CD audio

disc

(CDR drive recording from external sources)

• REC EXT DISC - automatically record an external

source by starting the source (SYNC recording)

• REC EXT MAN - manually start recording from an

external source (manual start recording)

• MINUTE TRACK - automatically start a new track

every minute (enables easy play back search of a

recording session)

• ONE TOUCH RECORD - The last selected

recording mode is remembered even after power

off. You can begin recording in the last selected

record mode simply by pressing the Record button

on the CDR510 or IR Remote.

- 8 -

Finalizing/erasing

• finalizing can be automatic (MAKE CD) or manual

• the CDR drive or CD drive can play an unfinalized

disc

• a CD-RW disc can be unfinalized

• a CD-RW disc can be erased either the entire disc

or one or more tracks from the end

CD-Text

• CD-Text can be read and displayed by either drive

• CD-Text can be entered on the CDR drive

• in some recording modes, CD-Text on a source is

automatically recorded

Track incrementing

The CDR drive can be set to automatically increment a

track:

• based on the input signal

• based on a silence gap

• every minute

• or track incrementing can be done manually during

recording by pressing the TR. INC. button on the

IR remote or the Record button on the CDR510

or the IR Remote

Play back – CDR and CD drives

• Standard audio CDs

• CD-R or CD-RW discs

• unfinalized CD-R or CD-RW discs

• CD drive only, finalized MP3 data discs

Play back track selection

• Single track: one track plays and the CDR510

stops at the beginning of the next track

• Scan Play: plays the first 10 seconds of each track

• Programmed play: plays tracks according to a

programmed order you preset

• Random play: all tracks on both drives are ran-

domly played

• Repeat play: the current track or all tracks are

repeated

- 9 -

Package contents

CDR510 unit

Infrared remote

control

Power cord

Audio cables (2)

3' 3" (100 cm)

AA batteries (2)

Remote batteries

Press and lift at arrow to open the Infrared remote

control battery compartment.

Install two AA

batteries.

Replace compart-

ment cover.

TRAY

DOOR REPEAT PROG. RANDOM

OPEN/CLOSE

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

SPACE

DISPLAY SCROLL

CDR CD

CANCEL

TR. INCR. REC REC TYPE SOURCE

SCAN DIMMER ENTER

REMOTE CONTROLLER

RC2100DR

RC-5 remote cable

3' (90 cm)

Connections (basic)

2 3 1

Rack mount or install on a table or other flat, stable,

surface.

1 Plug in to 110

VAC power

CDR

GROUND

ANALOG

IN OUT

INPUT

SELECT

BALANCED

R - TRIM - L

0+22 0+22

(REF=+16dBu/0dBFS)

HOT(+)

COLD(-)

RS232C

ANALOG DIG

OUT OUT

IN OUT

LOOP

OUT

DIGITAL

(SPDIF)

SERIAL NO.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,

AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE

RECRIVED, INCLUDING INTERFERENCE THAT MAY CAUSE

UNDESIRED OPERATION.

INT.(IR)

EXT.

OUT

REMOTE

(RC5)

MODEL NO. CDR510/U1B

AC120V 60HZ 0.5A

MARANTZ AMERICA INC.

1100 MAPLEWOOD DRIVE

ITASCA, IL 60143

COMPLIES WITH FDA RADIATION PERMORMANCE

STANDARDS, 21CFR SUBCHAPTER J

MANUFACTURED

WARNING: SHOCK HAZARD - DO NOT OPEN

AVIS : RISQUE DE CHOC ÉLECTRIQUIE - NE PAS OUVRIR.

MML

AC IN

RISK OF ELECTRIC SHOCK

DO NOT OPEN

MADE IN JAPAN

US LISTED

AUDIO SYSTEM

69FM

CAUTION

FACTORY CODE

NO 4300

Connect to other equipment

2 Connect CD player to analog equipment for

playing (or recording on an external device).

Connect a supplied Right

and Left RCA audio cable

to CD ANALOG OUT and

then connect to the input

of a preamplifier, receiver,

or other recording device.

ANALOG DIG

OUT OUT

INPUT

Amp, Mixer/Pre-Amp, CD-R, etc.

3 Connect CDR recorder to analog equipment for

playing or recording.

Connect two supplied Right and Left RCA audio cables

to CDR ANALOG IN and OUT and then connect to the

input and output of one or two pre-amplifiers, receiv-

ers, CD-R's or other external units.

INPUT

Amp, Mixer/Pre-Amp, DAT, CD-R, etc.

ANALOG

IN OUT

OUTPUT

Amp, Mixer/Pre-Amp, DAT, CD-R, etc.

Other available connection options:

• Balanced analog connections (XLR) page 23

• Digital Coaxial connections (RCA) page 24

• Digital cascade connections (RCA) page 24

• Digital optical connection page 24

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

How to Play back

CHANGER mode

The CHANGER mode is the default play

mode of the CDR510. The CD drive and CDR

drive work as one for playing two CDs, selecting

tracks, and programming track play back

sequence. A program can switch between drives.

Only one of the drives can play back at a time.

Both drives output to the CDR output jacks. The

CD drive is also output to the CDR ANALOG

OUT jacks and the CDR DIG OUT jack.

To select CHANGER mode

Press and release the PLAY MODE button so

CHANGER MODE is displayed momentarily and

then CHANGER remains in the display.

Example

display

Press and release Play/Pause on the drive

you want to play.

Example

display

The track number (a) and track time played,

counting up (b) on the selected drive are

displayed.

In CHANGER mode all the tracks on the

drive will be played, then play back will

automatically switch to the other drive, and play

it. When both CDs have been played, play back

will automatically stop.

DUAL mode

In Dual mode the CD drive and CDR drive work

independently of each other. Both drives can play

back at the same time and are output to separate

jacks. Dual mode can therefore be used to play

back two discs to two separate locations in a DJ-

type mixing application.

To select Dual mode

Press and release the PLAY MODE button so

DUAL MODE is displayed momentarily.

Press and release Play/Pause on the drive

you want to play.

Example

display

Example

display

The track number (a) and track time played,

counting up (b) on the selected drive are

displayed.

In Dual mode all the tracks on the selected drive

will be played, then play back will automatically

stop. While the selected drive is being played,

you can switch to the other drive and play it at

the same time. The CDR drive can be used to

record while the CD drive is in play back.

The display returns to drive information.

PLAY MODECDR CD

CD - R

ANALOG

3214

CD - R

ANALOG

3214

TOTAL

CHANGER

CD - R

ANALOG

3214

CHANGER

a b

PLAY MODECDR CD

CD - R

ANALOG

3214

CD - R

ANALOG

3214

TOTAL

CD - R

ANALOG

3214

a b

- 10 -

Play back features

Brief instructions of play back features.

See indicated pages for full instructions about the

feature.

•To Pause

Push and release Play/Pause on the

current drive to pause play back. Push and

release Play/Pause again to resume.

•To Stop

Push and release any Stop button to stop.

•To display times

During play back push and release the TIME

button to tab through available time displays.

See page 18.

•To program play back

From stop, push and release the PROG button,

then turn the REC LEVEL/SELECT control to

choose a track, then push and release the

REC LEVEL/SELECT control to enter that

track in the program. When complete push and

release the PROG button.

In CHANGER mode you can program

tracks in any order from either drive.

See page 45.

•To search

During play back, push and hold or .

Search begins at low speed, sampling sound at

low volume, then switches to high speed with

volume muted.

See page 19.

•To scan

CHANGER mode only.

In scan the first 10 seconds of each track is

played. The CDR510 automatically stops after

all tracks on both discs are scanned. From

stop, push and release the SCAN button on the

IR remote. Push and release the SCAN button

or the Play/Pause button on the current

drive to exit scan and continue play back. Or

push and release a Stop button to exit scan.

See page 27.

•Random play

CHANGER mode only.

During stop or play back push and release the

RANDOM button on the IR remote. All tracks or

programmed tracks on the discs in both drives

will be randomly played. When all tracks have

been played, play back automatically stops.

During random play, to return to normal CD

play back, push and release the RANDOM

button.

See page 25.

•Repeat play

During play back push and release the

REPEAT button on the IR remote. REPEAT

TRACK appears on the display. The current

track will repeat endlessly.

Push and release the REPEAT button on the

IR remote a second time. REPEAT ALL

appears on the display. The current disc will

repeat endlessly.

Push and release the REPEAT button on the

IR remote a third time to exit repeat play.

See page 25.

•Random and Repeat play combined

If Random and Repeat ALL are combined

tracks are played randomly until all tracks

have been played. Then tracks are re-

randomized and play continues.

•A-B repeat

Dual mode only, CD drive only.

During play back push and release the REC

LEVEL / SELECT control to select the starting

(A) point. REPEAT A- appears in the display.

Push and release the REC LEVEL / SELECT

control to select the ending (B) point. REPEAT

A-B appears in the display. Push and release

the REC LEVEL / SELECT control to exit A-B

repeat.

•MP3 play back

CD drive only.

MP3 play back requires loading additional

instructions into the CDR510 memory. This

takes about 10 seconds and takes place on

power up if menu item AUTO MP3LOAD is

ON, and on loading an MP3 disc if AUTO

MP3LOAD is OFF. The MP3 indicator is lit

while an MP3 disc is recognized in the CD

drive.

Instead of tracks and track time information

the display shows Albums and file information.

See page 44.

- 11 -

- 12 -

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

2 1 3

7 9 6 5 4

How to Record

• Recording takes place on the CDR drive

only.

• The recording procedure is the same for CD-

R and CD-RW discs.

• Use discs compatible with a 1X write speed.

See page 49.

• If the disc already contains recordings, the

CDR510 will automatically locate the end of

the last recorded track and start from there.

• Tracks from the CD drive can be

programmed for recording. See page 45.

• Recorded CDs must be finalized before

being playable on a regular CD player.

See page 46.

Internal REC modes

There are four recording modes for recording

from the CD drive.

The CDR510 must be in CHANGER mode

for internal recording.

RECORD FAST – double speed recording of a

disc or programmed tracks.

REC LISTEN – listening to a recording while

making it.

MAKE CD – double speed recording with

automatic finalizing.

REC MP3 DISC – listening to an MP3 disc while

recording 80 (or 74) minutes of the disc to

audio format on a standard CD disc.

See page 40 for more details about Recording

modes.

4. If programmed tracks are to be recorded do

the programming. See page 45.

5. If desired, adjust menu settings for AUTO

TRACK, see page 31, AUTO STOP, see page

32, or COPY protection, see page 35. Most

commonly, AUTO TRACK and AUTO STOP

should be set to ON.

6. Push and release the REC MODE button to

tab through Recording mode choices.

7. When correct, push and release the REC

button .

8. When done check or add CD Text.

See page 29.

9. Except for MAKE CD, finalize the disc. See

page 46.

To record from the CD drive:

1. Push and release the PLAY MODE button to

select CHANGER mode.

2. Place a recordable CD-R or CD-RW disc in

the CDR drive.

3. Place the CD to be recorded from in the CD

drive.

- 13 -

External REC modes

There are three recording modes for external

recording.

REC EXT DISC – Sync recording, recording

from an external source by starting the

source.

REC EXT MAN – recording from an external

source by manually starting recording.

MINUTE TRACK – automatically start a new

track every minute.

See page 40 for more details about Recording

modes.

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

1 9 5

7 8 10 3 4 6

To record from an external source:

1. Place a recordable CD-R or CD-RW disc in

the CDR drive.

2. Connect the external source to the

appropriate input jacks.

CDR

GROUND

ANALOG

IN OUT

INPUT

SELECT

BALANCED

R - TRIM - L

0+22 0+22

(REF=+16dBu/0dBFS)

HOT(+)

COLD(-)

RS232C

ANALOG DIG

OUT OUT

IN OUT

LOOP

OUT

DIGITAL

(SPDIF)

SERIAL NO.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,

AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE

RECRIVED, INCLUDING INTERFERENCE THAT MAY CAUSE

UNDESIRED OPERATION.

INT.(IR)

EXT.

OUT

REMOTE

(RC5)

MODEL NO. CDR510/U1B

AC120V 60HZ 0.5A

MARANTZ AMERICA INC.

1100 MAPLEWOOD DRIVE

ITASCA, IL 60143

COMPLIES WITH FDA RADIATION PERMORMANCE

STANDARDS, 21CFR SUBCHAPTER J

MANUFACTURED

WARNING: SHOCK HAZARD - DO NOT OPEN

AVIS : RISQUE DE CHOC ÉLECTRIQUIE - NE PAS OUVRIR.

MML

AC IN

RISK OF ELECTRIC SHOCK

DO NOT OPEN

MADE IN JAPAN

US LISTED

AUDIO SYSTEM

69FM

CAUTION

FACTORY CODE

NO 4300

CDR

GROUND

ANALOG

IN OUT

INPUT

SELECT

BALANCED

R - TRIM - L

0+22 0+22

(REF=+16dBu/0dBFS)

HOT(+)

COLD(-)

IN OUT

LOOP

OUT

DIGITAL

(SPDIF)

balanced

XLR

jacks

ANALOG

IN jacks

optical

DIGITAL

Digital sources can be input through the

optical DIGITAL IN connector, see page 24, or

the DIGITAL IN (RCA) connector, see page

24.

Analog sources can be input through the

BALANCED IN (XLR connectors) see page

22, or ANALOG IN (RCA jacks) see page 23.

3. Select the corresponding input by pushing

and releasing the INPUT SELECT button.

4. If desired, adjust menu settings for AUTO

TRACK, see page 31, AUTO STOP, see page

32, or COPY protection, see page 35.

5. Push and release the REC MODE button to

tab through Recording mode choices.

When correct:

If desired, adjust the Balance, see page 33.

6. If desired, adjust the Recording level by

turning the REC LEVEL/SELECT control.

When desired adjustments are made, start

the source (REC EXT DISC) or push and

release the REC button (REC EXT MAN, or

MINUTE TRACK).

During recording:

If desired, adjust the Recording level by

turning the REC LEVEL/SELECT control (6),

8. Press and release the CDR drive Play/Pause

button to pause,

9. or any Stop button to stop.

When done check or add CD Text.

See page 29.

10. Finalize the disc. See page 46.

DIGITAL IN

(RCA)

- 14 -

Notes regarding Recording

CD Text

• Discs copied from the CD drive in RECORD

FAST or MAKE CD will have the same CD

Text information as the source.

• MP3 Albums copied from the CD drive in

REC MP3 DISC will automatically have

track title information copied to CD Text

track titles.

• CD Text information is not copied from

external sources.

• CD Text information can be manually

added.

• You can edit CD Text information of the

previous track while recording the next

track.

• CD Text is cleared if the CDR drive is

opened.

See TEXT EDIT page 29.

Copy protection

• Because this is a professional CD recorder

copy protected CDs can be copied.

• The CDR510 allows you to set the copy

protection of recorded discs.

See page 35.

Additional Recording Information

• There must be at least 7 seconds of

recording time left on the CD or DOES NOT

FIT will be displayed.

• A maximum of 99 tracks can be recorded on

a disc. Minimum track length is 4 seconds.

• Recordings from DAT or DCC players will

not always stop automatically.

• The CDR510 can perform SRC (Sample Rate

Conversion) on an incoming digital signal.

See page 34.

- 15 -

Controls and Displays front

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

1 2 3 4 5 6 7 8 9

Note: Set the REMOTE EXT. / INT(IR) on the

back of the unit to INT(IR) to enable the IR re-

mote control.

2. CDR drive (disc tray)

In this manual the left drive is referred to as the

CDR drive. Press and release the button (3) to

open or close the CDR drive.

The CDR drive is used for recording and play

back and can record CD-R and CD-RW discs.

The CDR drive can play back unfinalized discs.

Record

able

Recordable

3. CDR open button

Press and release to open or

close the CDR drive.

CDR

4. CDR button

Press and release to select the

CDR drive. When selected the

display, center controls and remote

control buttons refer to the CDR

drive.

ANALOG

CD - R

TOTAL

Example display

shows large box (a)

indicating CDR drive

is selected.

a b c

In this example, small box (b) indicates a CD-R

disc is in the CDR drive. Small box (c) indicates a

CD disc is in the CD drive.

5. PLAY MODE button

Press and release to toggle be-

tween CHANGER MODE and

DUAL MODE.

PLAY MODE

When CHANGER

MODE is selected

CHANGER is

displayed.

ANALOG

CD - R

TOTAL

CHANGER

CHANGER MODE:

The CDR drive and CD drive work together as

one.

When in CHANGER MODE only one drive can

play back at a time. Both the CDR drive and CD

drive are output to the CDR output jacks. The CD

drive is also output to the CD jacks.

DUAL MODE:

The CDR drive and CD drive operate indepen-

dently.

Both the CDR drive and CD drive can play back

at the same time to separate CDR and CD output

jacks.

6. CD button

Press and release to select the

CD drive. When CD is selected

the display, center controls and remote control

buttons refer to the CD drive.

Example display

shows large box (a)

indicating CD drive is

selected.

ANALOG

CD - R

TOTAL

CHANGER

7. CD open button

Press and release to open or

close the CD drive.

8. MP3 indicator

Green indicator is lit and steady

when a CD with MP3 files is

detected.

ANALOG

CD - R

CHANGER

Example display

shows 27 MP3 tracks

in Album 1.

1. IR (Remote control sensor)

Sensor for the supplied wireless

infrared remote control.

9. PITCH indicator

Green indicator is lit and steady

when pitch has been adjusted

using the PITCH menu.

PITCH

Pitch adjustments remain even when discs are

changed or the CDR510 is powered off.

- 16 -

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

a 10

In this manual the right drive is referred to as the

CD drive. Press and release the button (a) to

open or close the CDR drive.

The CD drive is used for play back and can play

CD-R and CD-RW discs.

11. POWER button

Record

able

Digital Audio

11 12 13 14

Press and release to turn

power to the CDR510 On or

Off. The display is lit when

power is On.

12. Record button (red)

Press and release to begin

recording, finalizing or eras-

ing.

POWER

ERASE

REC LEVEL / SELECT

PUSH ENTER

FINAL INPUT

MODE MENU/

STORE TIME TEXT PROG

ALBUM

REC

CANCL/

DELETE

15 16 17

13. Stop button (white)

Press and release to stop record-

ing or play back in the CDR drive.

14. Play/Pause button

(green)

When at stop, press and release

begin play back in the CDR drive.

During play back, press and release to pause

play back. When play back is paused, press and

release to resume play back.

During recording, press and release to pause

recording. When recording is paused, press and

release to resume recording.

15. ERASE button

When at stop, press and release to

select Erasing mode.

ERASE

The CDR510 must detect a CD-RW disc with at

least one track on it in the CDR drive. "ERASE

TRACK" and "PRESS RECORD" alternate in the

display. If you press the Record button the last

track on the CD-RW disc will be erased.

Press the Stop button to cancel.

16. REC MODE button

When at stop and in CHANGER

mode, press and release to tab

REC

MODE

through the Recording Modes: RECORD FAST,

REC LISTEN, MAKE CD, REC EXT DISC, REC

EXT MAN, and MINUTE TRACK.

In DUAL mode the Recording Modes are: REC

EXT DISC, REC EXT MAN, and MINUTE

TRACK.

17. MENU/STORE button

Push and release to enter Menu

mode, exit Menu mode and Store

menu changes.

To make a menu change:

1. Push and release MENU/STORE button to

enter Menu mode.

2. Turn the REC LEVEL/SELECT control to

advance through the menu choices.

3. When the menu choice you want to change is

displayed, push and release the REC LEVEL/

SELECT control to enter that choice.

4. Then turn the REC LEVEL/SELECT control to

adjust or change the menu setting.

MENU/

STORE

10. CD drive (disc tray)

During recording push and release the Record

button to increment the track.

ONE TOUCH RECORD

The last selected Record mode is remembered

even after power off. This enables you to engage

record simply by pressing the Record button .

After pressing the Record button , the CDR510

will briefly display the Record mode, for example

MINUTE TRACK, then display WAIT, then begin

recording. The entire automated process takes

abut 5 seconds.

Press and release to exit a program.

Press and release to exit an operation and

switch to the CDR drive.

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

ERASE

REC LEVEL / SELECT

PUSH ENTER

FINAL INPUT

MODE MENU/

STORE TIME TEXT PROG

ALBUM

REC

CANCL/

DELETE

REC LEVEL / SELECT

PUSH ENTER

ANALOG

CD - R

CHANGER

16151413121110986543217

ANALOG

CD - R

CHANGER

ANALOG

CD - R

SYNC

5432

- 17 -

5. When the desired setting is displayed,

push and release the REC LEVEL/SE-

LECT control to confirm the new menu

setting.

6. Push and release the MENU/STORE

button to exit menu mode and write setting

changes.

With the CDR drive selected and a recordable

disc in the drive, the Menu choices are: TEXT

EDIT, TEXT ERASE, TEXT VIEW, AUTO

TRACK, AUTO STOP, TEXT ON/OFF, SRC,

and COPY. The CD Text Menu choices are

unavailable when there is no disc in the drive.

With the CD drive selected and an MP3 disc

inserted, the Menu choices are: PITCH,

PITCH ON/OFF, AUTO MP3LOAD, TEXT ON/

OFF, AUTO CUE, CUE LEVEL, PLAY MODE,

SINGLE PLAY, and END WARNING.

The pitch Menu choices are unavailable if

there is no disc in the drive. The MP3 LOAD

choice, in addition to the AUTO MP3LOAD

choice is available when MP3 software has

not been loaded.

18. REC LEVEL/SELECT

control

This is a main control which

changes function depending

on the state of the CDR510

Turn to:

• select the track (play and program mode)

• adjust recording level (recording)

• toggle or tab through settings (menu mode)

Example

display

a. The CDR drive is selected.

b. The CDR510 is in CHANGER mode.

c. Track 2 is flashing indicating it is selected.

d. Track 2 is displayed indicating it is selected.

e. There are 16 tracks on the disc in the CDR

drive.

When the REC LEVEL / SELECT control is turned

so a track beyond 16 (in this example) is selected

the drive selection is automatically changed to the

CD drive.

a b

c d e

Example

display

In this example the disc in the CD drive has MP3

files on it.

f. Turning the REC LEVEL / SELECT control will

select files in ALbum 1.

In record mode:

Turn to set or adjust the record level.

Example

display

Push and release to:

• start play back at the selected track

• program track number

• select displayed setting (menu mode)

When at stop, in CHANGER mode, with CDs

available for play back in both drives: turn to

select the track on the selected drive.

This setting is remembered, even after power

off, you do not have to do anything to confirm or

store it.

- 18 -

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

ERASE

REC LEVEL / SELECT

PUSH ENTER

FINAL INPUT

MODE MENU/

STORE TIME TEXT PROG

ALBUM

REC

CANCL/

DELETE

19 20 21

ANALOG

CD - R

5432

TIME

ANALOG

CD - R

SYNC

5432

TOTAL REM

TEXT

18. REC LEVEL/SELECT control continued

During CD text edit:

Turn to select the alphanumeric character, when

correct push to enter that character and advance

to the next character.

Example

display

The available characters are:

19. TIME button

During record push and release

to toggle between the total

Example

display

recording

TOTAL REM

Example

display

play back

20. TEXT button

In play back mode push and

release to display CD Text.

If present, "ALBUM TITLE" then the text of the

Album title will scroll across the display. Then, if

present, "TRACK TITLE" and the text of the Track

title will scroll across the display. The Track title

will remain on the display while the track is

playing.

If no text is present "NO TEXT" will be displayed

for a couple of seconds.

To record a space enter an underline.

21. PROG button

From stop in CHANGER or DUAL

MODE, push and release to enter

Program mode. See page 45.

PROG

Example

display

ANALOG

CD - R

PROGRAM

remaining disc time and the time recorded on the

current track.

During play back push and release to tab be-

tween the time played on the current track count-

ing up, time remaining on the current track count-

ing down (REM), total time remaining on the disc

Total remaining time on the

disc counting down.

counting down (TOTAL REM), and total time

played on the disc counting up (TOTAL).

ANALOG

CD - R CD

86547

CHANGER

TOTAL

22 23

22. FINAL button

From Stop, push and release to

select Finalize mode.

FINAL

CD - R

19181716151413121110986543217 20

DIG

The display "FINALIZE

CD" alternates with

"PRESS RECORD".

See page 46.

23. INPUT button

From Stop, push and release to

tab through the input selections for

recording.

The input choices are ANALOG, DIGITAL I, or

OPTICAL. The input choice is always displayed.

INPUT

- 19 -

Example

displays

19181716151413121110986543217 20

ANALOG

19181716151413121110986543217 20

DIG

19181716151413121110986543217 20

OPT

When OPTICAL is selected the input for record-

ing is from the DIGITAL (SPDIF) optical IN con-

nection on the rear of the CDR510.

When DIGITAL is selected the input for recording

is from the DIGITAL (SPDIF) RCA IN jack on the

rear of the CDR510.

When ANALOG is selected the input for recording

is from either the ANALOG L and R IN RCA jacks

or the BALANCED IN XLR jacks on the rear of

the CDR510, depending on the setting of the

INPUT SELECT switch on the rear of the

CDR510.

24. CANCL/DELETE button

Press and release to cancel or

delete items in several modes of

operation.

CANCL

DELETE

• delete tracks from a program

• text in CD Text edit

• return to a higher level when in Menu mode.

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

ERASE

REC LEVEL / SELECT

PUSH ENTER

FINAL INPUT

MODE MENU/

STORE TIME TEXT PROG

ALBUM

REC

CANCL/

DELETE

24 25 26

25. Reverse button

During play back, push and hold to

Fast reverse. Fast reverse is at

low speed for the first 4 seconds with audio

sampling, then automatically switches to silent

high speed.

26. Forward button

During play back, push and hold to

Fast forward. Fast forward is at low speed for the

first 4 seconds with audio sampling, then auto-

matically switches to silent high speed.

ALBUM

25, 26. ALBUM buttons

When an MP3 disc with

multiple albums is in the CD

drive, and at stop, press and release the Forward

button to advance to the next album, or the

Reverse button to reverse to the previous

album.

27 28 29 30

27. Stop button (white)

Press and release to stop

recording or play back in the

CD drive.

During play back, press and release to pause

play back. When play back is paused, press and

release to resume play back.

28. Play/Pause button

(green)

When at stop, press and

release begin play back in

the CD drive.

Press and release to exit a program.

Press and release to exit an operation and switch

to the CD drive.

29. HEADPHONE jack

Plug stereo headphones in here.

Adjust headphone volume with the

LEVEL control.

30. LEVEL control

Turn to adjust the volume of

headphones connected to the

HEADPHONE jack.

HEADPHONE

LEVEL

input choice

remains in

display

- 20 -

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

SYNC

MANUAL

ANALOG

DIG

OPT

CD - RW

DUBBING CHANGER

PROGRAM

RANDOM

REPEAT

ALL

TRACK

SCAN

STEP

19181716151413121110986543217 20

REM REC TIME TRACK TOTAL RE M TRACK TIME

CD - RW

Display

1. Alphanumeric

display.

2 3 4 5 6 7 8 9 10 11

Displays a variety of information including

remaining recording time, menu settings,

etc. Time for the CDR drive is displayed to

the left (below labels 2-4). Time for the CD

drive is displayed to the right (below labels

7-10).

2. REM label

The REM label appears with other labels

to indicate that the CDR drive time dis-

played is REMaining time.

3. REC label

The REC label appears with other labels

to indicate that the displayed CDR drive

time is RECording time.

4. TIME label

The TIME label appears with other labels

to indicate that the display is TIME for the

CDR drive.

5. TRACK label

The TRACK label appears with other

labels to indicate that the displayed CDR

drive time is TRACK time.

6. TOTAL label

The TOTAL label appears by itself or with

other labels to indicate that the CDR drive

or CD drive time displayed is total time.

7. REM label

The REM label appears with other labels

to indicate that the CD drive time dis-

played is REMaining time.

REM

REC

TIME

TRACK

TOTAL

8. TRACK label

The TRACK label appears with other

labels to indicate that the displayed CD

drive time is TRACK time.

9. TIME label

The TIME label appears with other

labels to indicate that the display is

TIME for the CD drive.

10. STEP label

The STEP label appears during pro-

gramming above the program step

number.

11. PROGRAM label

The PROGRAM label flashes during

programming and is steady when in

program mode.

12. RANDOM label

The RANDOM label appears during

RANDOM play. Tracks are played in

random order. See RANDOM button on

the IR remote.

13. REPEAT label

The REPEAT label appears during

REPEAT play. When the REPEAT

button on the IR remote is pressed you

can toggle between REPEAT ALL and

REPEAT TRACK. See REPEAT play

back.

14. ALL label

The ALL label appears associated with

the REPEAT label (13).

15. TRACK label

The TRACK label appears associated

with the REPEAT label (13).

16. SCAN label

The SCAN label appears during SCAN

play. See SCAN button on the IR

remote.

REM

TIME

TRACK

STEP

PROGRAM

RANDOM

REPEAT

ALL

TRACK

SCAN

- 21 -

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

SYNC

MANUAL

ANALOG

DIG

OPT

CD - RW

DUBBING CHANGER

PROGRAM

RANDOM

REPEAT

ALL

TRACK

SCAN

STEP

19181716151413121110986543217 20

REM REC TIME TRACK TOTAL RE M TRACK TIME

CD - RW

20 21 28 29

17. DIGI label

The DIGI label is displayed when the

CDR DIGITAL (SPDIF) IN jack is selected

for recording input. If flashing in record

standby, the digital data is not being

received correctly. Check connections and

settings on the source and CDR510.

The arrow is also displayed during

recording from the CDR DIGITAL (SPDIF)

IN jack.

18. SYNC label

The SYNC label (indicating Synchronized

recording) is displayed when the REC

EXT DISC is selected as the recording

mode. Start the external source to begin

recording.

19. MANUAL label

The MANUAL label (indicating manual

start recording) is displayed when the

REC EXT MAN is selected as the record-

ing mode. Start the external source and

recording at the same time.

20. ANALOG label

The ANALOG label is displayed when the

CDR BALANCED IN or the CDR ANA-

for recording.

DIG

SYNC

MANUAL

ANALOG

The arrow is also displayed

during recording from the

CDR BALANCED IN or the

CDR ANALOG IN inputs.

OPT

21. OPTI label

The OPTI label is displayed when the

CDR optical IN connection is selected as

the source for recording. If flashing in

record standby, the digital data is not

being received correctly. Check connec-

tions and settings on the source and

CDR510.

The arrow is also displayed when record-

ing and the CDR optical IN connection is

the source.

22. Large CDR box

OPT

CD - RW

25 26

27 The large CDR box is lit when the CDR

drive is selected.

23. Small CDR box

The small CDR box is lit when a disc is

recognized in the CDR drive.

24. Recording icon

The Recording icon is lit during record-

ing.

25. Pause icon

The Pause icon is lit when the CDR

drive is paused in recording or play back.

26. Play icon

The Play icon is lit when the CDR drive

is recording or in play back.

27. CD-RW label

CD-RW, CD-R, or CD is displayed de-

pending on the type of disc in the CDR

drive.

28. Track numbers

Track numbers available are displayed for

the selected drive. + is displayed if there

are more than 20 tracks.

CD-RW

29. DUBBING label

DUBBING is lit while recording from

the CD drive to the CDR drive.

19181716151413121110986543217 20

DUBBIN

SYNC

MANUAL

ANALOG

DIG

OPT

CD - RW

DUBBING CHANGER

PROGRAM

RANDOM

REPEAT

ALL

TRACK

SCAN

STEP

19181716151413121110986543217 20

REM REC TIME TRACK TOTAL RE M TRACK TIME

CD - RW

30 31

34 35

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

CD - RW

30. Level meter

Lit rectangles provide a visual display of

R and L levels during play back or

recording. The right-most four bars are

red to indicate an over level condition.

31. CHANGER mode indicator

Lit when in CHANGER mode.

32. Large CD box

The large CD box is lit when the CD

drive is selected.

33. Small CD box

The small CD box is lit when a disc is

recognized in the CD drive.

34. Pause icon

The Pause icon is lit when the play

back is paused on the CD drive.

35. Play icon

The Play icon is lit when the CD drive

is in play back.

36. CD-RW label

CD-RW, CD-R, or CD is displayed

depending on the type of disc in the CD

drive.

CHANGER

CD-RW

- 22 -

Controls and Connections rear

CD drive outputs

CDR

GROUND

ANALOG

IN OUT

INPUT

SELECT

BALANCED

R - TRIM - L

0+22 0+22

(REF=+16dBu/0dBFS)

HOT(+)

COLD(-)

RS232C

ANALOG DIG

OUT OUT

IN OUT

LOOP

OUT

DIGITAL

(SPDIF)

SERIAL NO.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,

AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE

RECRIVED, INCLUDING INTERFERENCE THAT MAY CAUSE

UNDESIRED OPERATION.

INT.(IR)

EXT.

OUT

REMOTE

(RC5)

MODEL NO. CDR510/U1B

AC120V 60HZ 0.5A

MARANTZ AMERICA INC.

1100 MAPLEWOOD DRIVE

ITASCA, IL 60143

COMPLIES WITH FDA RADIATION PERMORMANCE

STANDARDS, 21CFR SUBCHAPTER J

MANUFACTURED

WARNING: SHOCK HAZARD - DO NOT OPEN

AVIS : RISQUE DE CHOC ÉLECTRIQUIE - NE PAS OUVRIR.

MML

AC IN

RISK OF ELECTRIC SHOCK

DO NOT OPEN

MADE IN JAPAN

US LISTED

AUDIO SYSTEM

69FM

CAUTION

FACTORY CODE

NO 4300

ANALOG DIG

OUT OUT

ANALOG DIG

OUT OUT

1. CD ANALOG OUT jacks

Plug L and R RCA jacks in here

to connect to the Line level

input jacks of an external pre-

amplifier, mixer or other audio

device. This output is always on

when there is play back on the

CD drive.

2. CD DIG OUT jack

Plug a Digital audio cable with

RCA jacks in here to connect to

the digital input jack of an

external audio device. This

output is always on when there

is play back on the CD drive.

ANALOG DIG

OUT OUT

CDR

GROUND

ANALOG

IN OUT

INPUT

SELECT

BALANCED

R - TRIM - L

0+22 0+22

(REF=+16dBu/0dBFS)

HOT(+)

COLD(-)

3. BALANCED IN

ANALOG XLR inputs, L & R

XLR connectors are available for balanced*

analog input.

*A professional XLR cable set is well shielded to

avoid picking up noise and is 'balanced,' has 600

ohms impedance.

CDR

GROUND

BALANCED

HOT(+)

COLD(-)

231231

- 23 -

CDR

GROUND

ANALOG

IN OUT

INPUT

SELECT

BALANCED

R - TRIM - L

0+22 0+22

(REF=+16dBu/0dBFS)

HOT(+)

COLD(-)

RS232C

ANALOG DIG

OUT OUT

IN OUT

LOOP

OUT

DIGITAL

(SPDIF)

SERIAL NO.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,

AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE

RECRIVED, INCLUDING INTERFERENCE THAT MAY CAUSE

UNDESIRED OPERATION.

INT.(IR)

EXT.

OUT

REMOTE

(RC5)

MODEL NO. CDR510/U1B

AC120V 60HZ 0.5A

MARANTZ AMERICA INC.

1100 MAPLEWOOD DRIVE

ITASCA, IL 60143

COMPLIES WITH FDA RADIATION PERMORMANCE

STANDARDS, 21CFR SUBCHAPTER J

MANUFACTURED

WARNING: SHOCK HAZARD - DO NOT OPEN

AVIS : RISQUE DE CHOC ÉLECTRIQUIE - NE PAS OUVRIR.

MML

AC IN

RISK OF ELECTRIC SHOCK

DO NOT OPEN

MADE IN JAPAN

US LISTED

AUDIO SYSTEM

69FM

CAUTION

FACTORY CODE

NO 4300

CDR

GROUND

ANALOG

IN OUT

INPUT

SELECT

BALANCED

R - TRIM - L

0+22 0+22

(REF=+16dBu/0dBFS)

HOT(+)

COLD(-)

3. BALANCED IN (continued)

The three pin XLR connection permits trimming,

adjusting the input level. See TRIM (4).

The INPUT SELECT SWITCH (6) on the rear of

the CDR510 must be to the left to select the

BALANCED IN inputs. ANALOG must also be

selected by pressing and releasing the INPUT

button on the front of the CDR510 so ANALOG is

displayed.

ANALOG

CD - R

TOTAL

CHANGER

Example

display

ANALOG

The pin out for the XLR jacks is printed on the

CDR510 for easy reference:

Pin 1 ground,

Pin 2 HOT +,

Pin 3 COLD -.

4. TRIM R & L

You can use a small screw-

driver to adjust the TRIM of

the XLR L & R inputs.

R - TRIM - L

0+22 0+22

(REF=+16dBu/0dBFS

)

The TRIM is factory preset at +16 dBu with an

adjustment range from 0 to +22 dBu.

Some professionals prefer to first set the TRIM

using a meter and to do a fine adjustment by

listening for distortion and watching the level

meters on the CDR510.

ANALOG

IN OUT

5. ANALOG IN / OUT

jacks

RCA jacks for line level

input and output to the

CDR drive.

L & R ANALOG IN jacks

Plug L and R RCA jacks in here to connect to the

Line level output jacks of an external pre-ampli-

fier, mixer or other audio device.

The INPUT SELECT SWITCH (6) on the rear of

the CDR510 must be to the left to select the

BALANCED IN inputs. ANALOG must also be

selected by pressing and releasing the INPUT

button on the front of the CDR510 so ANALOG

is displayed.

Example

display

L & R ANALOG OUT jacks

Plug L and R RCA jacks in here to connect to the

Line level input jacks of an external pre-amplifier,

mixer or other audio device. This output is always

on when there is play back on the CDR drive.

ANALOG

CD - R

TOTAL

CHANGER

ANALOG

6. INPUT SELECT switch

This switch selects between

the BALANCED IN (XLR)

jacks and the ANALOG IN

(RCA) jacks for analog input

for recording on the CDR

drive.

INPUT

SELECT

ANALOG must also be selected by pressing and

releasing the INPUT button on the front of the

CDR510 so ANALOG is displayed.

CDR

GROUND

ANALOG

IN OUT

INPUT

SELECT

BALANCED

R - TRIM - L

0+22 0+22

(REF=+16dBu/0dBFS)

HOT(+)

COLD(-)

RS232C

ANALOG DIG

OUT OUT

IN OUT

LOOP

OUT

DIGITAL

(SPDIF)

SERIAL NO.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,

AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE

RECRIVED, INCLUDING INTERFERENCE THAT MAY CAUSE

UNDESIRED OPERATION.

INT.(IR)

EXT.

OUT

REMOTE

(RC5)

MODEL NO. CDR510/U1B

AC120V 60HZ 0.5A

MARANTZ AMERICA INC.

1100 MAPLEWOOD DRIVE

ITASCA, IL 60143

COMPLIES WITH FDA RADIATION PERMORMANCE

STANDARDS, 21CFR SUBCHAPTER J

MANUFACTURED

WARNING: SHOCK HAZARD - DO NOT OPEN

AVIS : RISQUE DE CHOC ÉLECTRIQUIE - NE PAS OUVRIR.

MML

AC IN

RISK OF ELECTRIC SHOCK

DO NOT OPEN

MADE IN JAPAN

US LISTED

AUDIO SYSTEM

69FM

CAUTION

FACTORY CODE

NO 4300

7. RS-232C connector

Using serial communication, a

host device can control the

CDR510.

7 8 9 10 11

- 24 -

RS232C

• The RS-232C host can control functions of

the CDR510 externally.

• The CDR510 automatically transmits status

data when status is changed.

• The CDR510 will respond to a status request

by transmitting the associated status data.

See RS-232C control for details.

IN OUT

LOOP

OUT

DIGITAL

(SPDIF)

8. DIGITAL IN & OUT

connectors (SPDIF)

Digital audio cable with

RCA jacks can be used

for input and output.

Optical cable can be

used for input.

DIGITAL IN jack (RCA)

Connect a digital audio cable with RCA jacks

from an external device providing SPDIF digital

output. To record from this input DIGITAL must be

selected by pressing and releasing the INPUT

button on the front of the CDR510 so DIGI is

displayed.

Example

display

DIGI

CD - R

TOTAL

CHANGER

OPT

To avoid interference and noise, do not use the

DIGITAL IN (RCA) jack and the DIGITAL IN

(optical) connector at the same time.

DIGITAL LOOP OUT jack (RCA)

Connect a digital audio cable with RCA jacks to

an external device accepting a SPDIF digital

input. This connection will pass an input digital

signal as long as the CDR510 is powered on,

even if the CDR510 is not recording or in play-

back.

DIGITAL OUT jack (RCA)

Connect a digital audio cable with RCA jacks to an

external device accepting a SPDIF digital input.

This connection will pass a digital signal when the

CDR510 is recording, when the CDR drive is in

playback, and in CHANGER mode when the CD

drive is in playback.

9. DIGITAL IN connector

(optical)

Remove the dust cover and

plug a digital optical cable in

here.

To record from this input OPTICAL must be

selected by pressing and releasing the INPUT

button on the front of the CDR510 so OPTI is

displayed.

Example

display

OPTI

CD - R

TOTAL

CHANGER

OPT

To avoid interference and noise, do not use the

DIGITAL IN (RCA) jack and the DIGITAL IN

(optical) connector at the same time.

OUT

REMOTE

(RC5)

INT.(IR)

EXT.

INT.(IR)

EXT.

10. EXT / INT (IR) switch

Switch to select between the INT

(IR), internal infrared, remote

control, left switch position, and the EXT, external

(RC5) remote control, right switch position.

IR Remote control model RC2100 DR is sup-

plied.

Note:

When the RC-5 is not used, leave the switch in

the INT (IR) position. If desirable, for example in

a professional studio, to disable the IR receiver,

leave the switch in the EXT position.

11. REMOTE (RC5) IN / OUT

jacks (RCA)

Use the supplied cable to connect

the IN jack to a remote control

generator.

- 25 -

CDR

GROUND

ANALOG

IN OUT

INPUT

SELECT

BALANCED

R - TRIM - L

0+22 0+22

(REF=+16dBu/0dBFS)

HOT(+)

COLD(-)

RS232C

ANALOG DIG

OUT OUT

IN OUT

LOOP

OUT

DIGITAL

(SPDIF)

SERIAL NO.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,

AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE

RECRIVED, INCLUDING INTERFERENCE THAT MAY CAUSE

UNDESIRED OPERATION.

INT.(IR)

EXT.

OUT

REMOTE

(RC5)

MODEL NO. CDR510/U1B

AC120V 60HZ 0.5A

MARANTZ AMERICA INC.

1100 MAPLEWOOD DRIVE

ITASCA, IL 60143

COMPLIES WITH FDA RADIATION PERMORMANCE

STANDARDS, 21CFR SUBCHAPTER J

MANUFACTURED

WARNING: SHOCK HAZARD - DO NOT OPEN

AVIS : RISQUE DE CHOC ÉLECTRIQUIE - NE PAS OUVRIR.

MML

AC IN

RISK OF ELECTRIC SHOCK

DO NOT OPEN

MADE IN JAPAN

US LISTED

AUDIO SYSTEM

69FM

CAUTION

FACTORY CODE

NO 4300

a 12

12. AC IN

Plug one end of the supplied

power cord in here and the other

into an AC outlet.

AC IN

Remote control (IR)

The supplied infrared remote control permits

most functions of the CDR510 to be controlled

remotely.

The REMOTE EXT / INT (IR) switch (a) on the

back of the CDR510 must be at INT (left position)

for the infrared remote to work.

See Remote batteries on page 9 for installing or

changing the remote batteries.

Most of the controls on the remote work identi-

cally to the control on the unit. The page number

describing identical functioning unit controls is

given below.

Further instruction is supplied for controls that are

on the remote only or that function differently

from controls on the unit.

TRAY

DOOR REPEAT PROG. RANDOM

OPEN/CLOSE

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

SPACE

DISPLAY SCROLL

CDR CD

CANCEL

TR. INCR. REC REC TYPE SOURCE

SCAN DIMMER ENTER

REMOTE CONTROLLER

RC2100DR

1 2

1. TRAY OPEN/CLOSE

button

Push and release to open

or close the currently

selected disc drive tray.

TRAY OPEN/CLOSE

2. Standby

power button

Not used.

DOOR

OPEN/CLOSE

3. DOOR OPEN/CLOSE

button

Not used.

4. REPEAT button

In playback in either drive push and

release to enter Repeat playback.

REPEAT

After the first press the currently playing track is

repeated. The display says REPEAT TRACK.

Example

display

After the second press the currently playing disc

is repeated. The display says REPEAT ALL.

Example

display

The third press cancels Repeat playback.

CD - R CD

DIG

REPEAT

TRACK

171615141312111098654327

CD - R CD

DIG

REPEAT

ALL

17161514131211109865437

REPEAT ALL

REPEAT TRACK

5. PROG. button

Works the same as the PROG

button, see page 13.

6. RANDOM button

In playback, in CHANGER mode

only, push and release to enter

RANDOM playback.

PROG.

RANDOM

Tracks are played at random, from either drive,

for playback. Playback will randomly switch

drives, putting the other drive in Play pause.

Example

display

After a track is played it is removed from being

randomly chosen again until all tracks on both

drives have been played. Playback then auto-

matically stops.

If RANDOM and REPEAT ALL are combined

tracks are played randomly until all tracks have

been played. Then tracks are re-randomized and

play continues.

CD - R CD

DIG

1716151312111086537

RANDOM

CHANGER

RANDOM

Track 12 is playing. Tracks 4, 9 and 14 have

been randomly played on the CD drive.

- 26 -

TRAY

DOOR REPEAT PROG. RANDOM

OPEN/CLOSE

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

SPACE

DISPLAY SCROLL

CDR CD

CANCEL

TR. INCR. REC REC TYPE SOURCE

SCAN DIMMER ENTER

REMOTE CONTROLLER

RC2100DR

7. Alphanumeric keypad

Performs some of the

functions of the REC

LEVEL / SELECT control.

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

SPACE

In Playback and Program modes push and release a

number button to select the track. Then push the

REC LEVEL / SELECT control on the unit or ENTER

on the remote to enter the selection.

When entering CD Text push a number button once to

select the first of the three letters, twice for the second

and three times for the third. Push the REC LEVEL /

SELECT control on the unit or ENTER on the remote

to enter the selected number.

DISPLAY

8. DISPLAY button

Works the same as the TIME button

on the CDR510. See page 18.

9. CDR button

Works the same as the CDR button on

the CDR510. See page 15.

10. MENU button

Works the same as the MENU/STORE

button on the CDR510. See page 16.

11. Track Skip backward button

Press and release during Play or Play

pause to skip backward to the begin-

CDR

ning of the current track. Push and release twice or

more to skip backward to previous tracks.

12. Fast backward search button

Works the same as the Reverse

button on the CDR510. See page

19.

13. SCROLL button

Works the same as the TEXT button

on the CDR510. See page 18.

SCROLL

16. CD button

Works the same as the CD button

on the CDR510. See page 15.

17. Track Skip forward button

Press and release during Play or

Play pause to skip forward to the

beginning of the next track.

18. CANCEL button

Works the same as the CANCL /

DELETE button on the CDR510.

See page 19.

19. Fast forward search button

Works the same as the Forward

button on the CDR510. See

page 19.

20. Play button

Push and release to start playback

on the currently selected drive.

CANCEL

TRAY

DOOR REPEAT PROG. RANDOM

OPEN/CLOSE

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

SPACE

DISPLAY SCROLL

CDR CD

CANCEL

TR. INCR. REC REC TYPE SOURCE

SCAN DIMMER ENTER

REMOTE CONTROLLER

RC2100DR

14. PAUSE button

Push and release to Pause record-

ing or playback on the currently

selected drive.

15. Stop button

Push and release to Stop recording

or playback on the currently selected

drive.

- 27 -

TRAY

DOOR REPEAT PROG. RANDOM

OPEN/CLOSE

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

SPACE

DISPLAY SCROLL

CDR CD

CANCEL

TR. INCR. REC REC TYPE SOURCE

SCAN DIMMER ENTER

REMOTE CONTROLLER

RC2100DR

21. REC button

Works the same

as the Record

REC

TR. INCR.

SCAN

Example

display

CD - R CD

CHANGER

ANALOG

SCAN

19181716151413121110986547

SCAN

Press and release again to exit scan. Play will con-

tinue from the currently selected track.

24. DIMMER button

Not used.

25. REC TYPE button

Not used.

26. SOURCE button

Works the same as the INPUT

button on the CDR510. See page

18.

27. ENTER button

Works the same as pushing and

releasing the REC LEVEL / SELECT

control on the CDR510. See page

17.

DIMMER

REC TYPE

SOURCE

button on the CDR510.

See page 16.

22. TR. INCR.

button

Press and

release during

recording to increment the track. The track number is

increased by one, but no break or sound is introduced

into the recording.

Not available in MINUTE TRACK record mode.

23. SCAN button

Remote only. In CHANGER

mode in Playback and at Stop, press

and release to scan, play the first 10

seconds of each track.

ENTER

MENU mode

MENU mode permits advanced settings for

recording CDs and CD Text handling.

Menu parameters are available for setting when

appropriate. The chart below lists the drives and

modes when the Menu item is available.

Menu Settings Chart

CDR drive

items

TEXT EDIT

TEXT ERASE

TEXT VIEW

AUTO TRACK

AUTO STOP

REC BALANCE

TEXT ON/OFF

SRC ON/OFF

COPY

CD drive

items

PITCH

PITCH ON/OFF

MP3 LOAD

AUTO MP3 LOAD

TEXT ON/OFF

AUTO CUE ON/OFF

CUE LEVEL

PLAY MODE

SINGLE PLAY

END WARNING

(Stop mode)

√

CHANGER

mode

√**

√***

√

CD-R/RW

(Stop mode)

√

√*

√

DUAL

mode

√**

√***

√

Factory

default

L:0 R:0

Factory

default

OFF

-40dB

PLAY

OFF

15 sec

Is setting

remembered?

yes

Is setting

remembered?

yes

See

Page

See

Page

*Only available when recoding an external analog signal, or REC MP3 DISC.

**Not available when the disc is not loaded.

***Not available when a CD-DA disc is loaded.

The chart also lists the default setting applied by

the factory, and if the setting is remembered if the

CDR510 is powered off and back on again.

'See Page' lists the page number for detailed

instructions on the menu item.

- 28 -

Example

display

push and release the MENU/STORE button.

ANALOG

TOTAL

CD - R CD

Example

display

TEXT EDIT is displayed as a menu choice.

2. Push and release the REC LEVEL / SELECT

control to accept the TEXT EDIT menu choice.

ANALOG

CD - R CD

Example

display

ALBUM TITLE is displayed.

ANALOG

CD - R CD

To make a menu change:

1. Push and release MENU/STORE button to

enter Menu mode.

2. Turn the REC LEVEL/SELECT control to

advance through the menu choices.

3. When the menu choice you want to change

is displayed, push and release the REC

LEVEL/SELECT control to enter that choice.

4. Then turn the REC LEVEL/SELECT control

to adjust or change the menu setting.

5. When the desired setting is displayed, push

and release the REC LEVEL/SELECT

control to confirm the new menu setting.

The display returns to the menu choice.

6. Push and release the MENU/STORE button

to exit menu mode.

TEXT EDIT (How to edit CD Text)

1. With the CDR drive selected and an unfinal-

ized CD-R or CD-RW detected in the CDR

drive,

3. Push and release the REC LEVEL / SELECT

control to accept the ALBUM TITLE menu

choice. 'A' flashing is displayed.

Example

display

ANALOG

CD - R CD

4. Turn the REC LEVEL / SELECT control to

select the first character of your album title.

Example

display

ANALOG

CD - R CD

RANALOG

CD - R CD

The available characters are.

To enter a space select the underline.

A maximum of 60 characters can be entered

per title.

5. When correct, push and release the REC

LEVEL / SELECT control to accept the charac-

ter. The next character space will be flashing.

Example

display

6. When your album title is complete and

correct,

push and release the MENU/STORE button to

store. The display returns to the ALBUM

TITLE menu choice.

RANALOG

CD - R CD

ANALOG

CD - R CD

Example

display

Example

display

7. Turn the REC LEVEL / SELECT switch to

another menu choice or press and release

the CANCL/DELETE button to exit menu

mode.

CD Text information is not retained if the CDR10

is turned off, or if the unfinalized disc is removed

from the CDR drive.

- 29 -

- 30 -

TEXT ERASE (How to erase CD Text)

1. With the CDR drive selected and an unfinal-

ized CD that includes CD Text detected in the

CDR drive, push and release the MENU/

STORE button.

2. Turn the REC LEVEL/SELECT control so

TEXT ERASE is displayed.

ANALOG

CD - R CD

ANALOG

CD - R CD

ANALOG

CD - R CD

3. Push and release the REC LEVEL/SELECT

control. ALL TEXT is displayed.

4. Turn the REC LEVEL/SELECT control to tab

through ALL TEXT, ALBUM TITLE, TITLE

TRACK 1, TITLE TRACK 2, . . . and back to

ALL TEXT.

5. When the display indicates your desired

choice for erasing, push and release the REC

LEVEL / SELECT control. The text to be

erased will be displayed, then ERASE OK will

be displayed.

6. Push and release the REC LEVEL/SELECT

control to erase, or the CANCL/DELETE

button to abort the erasure.

ANALOG

TOTAL

CD - R CD

push and release the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control so

TEXT VIEW is displayed.

ANALOG

CD - R CD

4. Turn the REC LEVEL/SELECT control to tab

through ALBUM TITLE, TITLE TR 1, TITLE

TR 2, . . . until the title you want to review is

displayed.

5. Push and release the REC LEVEL/SELECT

control to display the title. A long title will scroll

across the display.

6. When done, turn the REC LEVEL/SELECT

control to switch to other menu items or press

and release the CANCL/DELETE button to exit

menu mode.

ANALOG

CD - R CD

TEXT VIEW (How to review CD Text)

TEXT VIEW lets you review the CD Text in

memory.

1. With the CDR drive selected and an unfinal-

ized CD that includes CD Text detected in

the CDR drive:

3. Push and release the REC LEVEL/SELECT

control. ALBUM TITLE is displayed.

RANALOG

CD - R CD

Track information in the audio source such as a

CD being dubbed is not recorded.

AUTO TRACK ON

When AUTO TRACK is ON and you are record-

ing from a digital source with user data (track

information from a source with a SPDIF connec-

tion) the track information is recorded.

When AUTO TRACK is ON and the digital

source does not include track ids, the CDR510

will use a silence gap to mark a track.

A track can also be incremented by pressing and

releasing the TR. INCR button on the IR remote,

incrementing the track via the RC-5 signal, or

RS-232C control, or by pressing and releasing

the Record button on the CDR510 or the REC

button on the IR remote. See table on page

32.

Silence gap

With Auto Track ON, when a (silence gap) is

detected for more than 2 seconds, the CDR510

will increment a new track when signal is

detected at the threshold levels outlined below.

AUTO TRACK ON

Track increment based on user data

of incoming signal.

Track increment based on user data

of incoming signal.

Track increment after silence gap of

2 seconds on incoming signal.

Track increment after silence gap of

2 seconds on incoming signal.

None

SOURCE

CD/MD

(with user data)

DAT/DCC

(with user data)

Unknown

(no user data)

Analog

No source

(no lock)

- 31 -

AUTO TRACK

AUTO TRACK can be either ON or OFF.

AUTO TRACK OFF

When AUTO TRACK is OFF only manual tracks

are recorded by pressing and releasing the TR.

INCR button on the IR remote, incrementing the

track via the RC-5 signal, or RS-232C control, or

by pressing and releasing the Record button on

the CDR510 or the REC button on the IR

remote.

How to turn AUTO TRACK ON or OFF

1. With the CDR drive selected push and re-

lease the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

AUTO TRACK is displayed.

ANALOG

3. Push and release the REC LEVEL/SELECT

control. ON or OFF is displayed.

4. Turn the REC LEVEL/SELECT control to

toggle between ON and OFF.

ANALOG

If AUTO STOP is also ON no more than 20 sec-

onds of silence will be recorded from an analog

source and 4 seconds from a digital source.

The chart below will help identify how a source will

be handled by the AUTO TRACK system.

5. When correct push and release the REC

LEVEL/SELECT control. AUTO TRACK is

displayed again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

Audio source signal

Analog source -40dB

silence

gap

2 sec

track x track x+1

Track increment

Digital source -80dB

- 32 -

AUTO STOP

AUTO TRACK must be ON for AUTO STOP OFF

or ON to function.

AUTO STOP OFF

When recording with AUTO STOP OFF the

CDR510 will record until stopped by pressing the

Stop button.

The benefit of AUTO STOP OFF is, for example,

when recording classical music, which could

have long passages of silence.

AUTO STOP ON

When recording with AUTO STOP ON the

CDR510 will automatically stop after a period of

silence. The silence will be recorded onto the

end of the current track.

When recording with AUTO STOP ON from an

analog source, the recording will stop after

recording 20 seconds of silence (a signal lower

than -40dB). When recording with AUTO STOP

ON from a digital source (without track and stop

data), the recording will stop after recording 4

seconds of silence (a signal lower than -80dB).

ANALOG

5. When correct push and release the REC

LEVEL/SELECT control. AUTO STOP is

displayed again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

3. Push and release the REC LEVEL/SELECT

control. ON or OFF is displayed.

4. Turn the REC LEVEL/SELECT control to

toggle between ON and OFF.

How to turn AUTO STOP ON or OFF

1. With the CDR drive selected push and

release the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

AUTO STOP is displayed.

Manual Track increment, AUTO TRACK, and AUTO STOP depending on Recording mode.

Recording

Mode

RECORD FAST

REC LISTEN

MAKE CD

REC EXT DISC

REC EXT MAN

MINUTE TRACK

Manual Track

Increment

Available

each minute

OFF

each minute

OFF

AUTO TRACK AUTO STOP

Menu exceptions

In some Recording modes some menu settings are overridden and/or manual track incrementing is not

available. For example in REC LISTEN recording mode, manual track incrementing is not available,

and AUTO STOP functions even if the menu setting is at OFF. The table below details these excep-

tions.

REC BALANCE

Balance adjustment

Balance adjustment is only available in record or

record standby mode, for example when REC

EXT DISC is selected and the CDR510 is waiting

for the external source to start.

Balance is adjustable by independently adjusting

the record level of the Left and Right channels.

The adjustment range is from 0 to -77dB in 1dB

increments.

Balance settings remain when discs are changed

or if the CDR510 is powered off.

1. When in record or record standby push and

release the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

REC BALANCE is displayed.

3. Push and release the REC LEVEL/SELECT

control. L 0 R 0 is displayed.

CD - R

SYNC

ANALOG

321

The example display indicates that the left

balance (L) is at 0, and the right balance (R)

is at 0.

4. Turn the REC LEVEL/SELECT control clock-

wise to adjust the balance to the right or

counterclockwise to adjust the balance to the

left. Maximum adjustment is 77dB.

CD - R

SYNC

ANALOG

321

Example display

right adjustment

-53dB

5. When correct push and release the REC

LEVEL/SELECT control. REC BALANCE is

displayed again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

CD - R

SYNC

ANALOG

321

TEXT ON/OFF

For those situations where it is not desirable to

display CD Text, for example if you are a DJ and

do not want to wait a couple of seconds for a long

album title to be read and scroll across the dis-

play, CD Text can be turned off.

When TEXT is ON and a CD has text, the album

title is displayed when the disc is read, when

playback begins, and when playback ends. A

track title is displayed before playback of a track

begins.

When TEXT is OFF and a CD has text, the text is

ignored.

How to turn TEXT ON or OFF

1. With the CDR drive selected push and re-

lease the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

TEXT ON/OFF is displayed.

ANALOG

3. Push and release the REC LEVEL/SELECT

control. ON or OFF is displayed.

4. Turn the REC LEVEL/SELECT control to

toggle between ON and OFF.

5. When correct push and release the REC

LEVEL/SELECT control. TEXT ON/OFF is

displayed again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

- 33 -

- 34 -

SRC

The CDR510 can perform SRC (Sample Rate

Conversion) on an incoming digital signal for

recording. The CDR510 is capable of handling

digital sources from 11 kHz up to 56 kHz.

DIG

3. Push and release the REC LEVEL/SELECT

control. ON or OFF is displayed.

4. Turn the REC LEVEL/SELECT control to

toggle between ON and OFF.

5. When correct push and release the REC

LEVEL/SELECT control. SRC is displayed

again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

The CDR510 monitors the incoming digital

signal to check if the signal is 44.1 kHz (±100

ppm). If SRC is ON or OFF and the incoming

signal meets these criteria, the CDR510

records the signal. If SRC is ON and the

incoming signal fails these criteria, the sample

rate converter is automatically turned on and

recording continues. If SRC is OFF and the

incoming signal fails these criteria, silence is

recorded.

If the recording source is a special disc such

as HDCD or DTS, you have to

• set SRC to OFF (if set to ON some data

may be lost)

• set source sampling frequency to 44.1 kHz

• use a digital connection

• set the digital recording volume (REC

LEVEL / SELECT control) of the CDR510

to 0 dB

Note

If the source has tracks recorded at differing

sample frequencies, noise might be recorded

when the sampling rate changes.

How to turn SRC ON or OFF

1. With the CDR drive selected push and

release the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

SRC is displayed.

- 35 -

COPY protection

All pre-recorded audio CDs include a digital mark

indicating the copy protection status of the disc.

This information is stored in the user data area of

the CD and is transmitted in the SPDIF format

digital output.

Analog sources do not carry copy protection.

Because the CDR510 is a professional CD

recorder, it will record from any digital source,

ignoring the copy protection setting of the source

material. The CDR510 allows you to set the level

of copy protection of each disc you record.

COPY OFF

A CD recorded with COPY OFF allows unlimited

digital copying. A consumer digital recording

device can digitally record the CD.

COPY ON

A CD recorded with COPY ON allows a single

generation digital copy for personal use. A

consumer digital recording device will be able to

digitally record the CD but the copy will have

Copy Protection set to HCO so further digital

copies cannot be made.

COPY HCO (Home Copy protected Original)

A CD recorded with COPY HCO does not allow

digital copying. A consumer digital recording

device cannot digitally copy the CD.

How to turn COPY ON, OFF or to HCO

1. With the CDR drive selected push and re-

lease the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

COPY is displayed.

3. Push and release the REC LEVEL/SELECT

control. ON, OFF or HCO is displayed.

ANALOG

CD - R CD

86543217

ANALOG

CD - R CD

86543217

4. Turn the REC LEVEL/SELECT control to tab

between ON, OFF and HCO.

5. When correct push and release the REC

LEVEL/SELECT control. COPY is displayed

again.

6. Turn the MENU/STORE button to switch to

other menu choices or press and release the

CANCL/DELETE button to exit menu mode.

- 36 -

PITCH

The playback speed (pitch) of the CD drive can

be changed up to ±12.0% in steps of 0.1%.

Default setting is 0.

Digital signals are not output when pitch control

is on.

Adjusting the pitch lets you tune the CD output to

a musical instrument, useful when practicing

because it permits adjusting the music practice

source to your instrument.

When pitch is active the green PITCH indicator

on the front of the CDR510 is lit and steady.

Pitch settings remain when discs are changed or

if the CDR510 is powered off.

There are two menu controls for pitch, PITCH

and PITCH ON/OFF.

How to adjust the PITCH (menu control)

The PITCH menu control adjusts the pitch.

1. With the CD drive selected push and release

the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

PITCH is displayed.

3. Push and release the REC LEVEL/SELECT

control. PI is displayed.

4. Turn the REC LEVEL/SELECT control to

adjust the pitch.

5. When correct push and release the REC

LEVEL/SELECT control. PITCH is displayed

again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

ANALOG

CD - RW CD

ANALOG

CD - RW CD

ANALOG

CD - RW CD

How to turn the PITCH ON or OFF

The PITCH ON/OFF menu control lets you turn

the pitch on or off without changing the pitch

adjustment when pitch is on. If you turn the pitch

adjustment off and later, if you turn the pitch

adjustment back on, the original pitch setting

remains.

1. With the CD drive selected push and release

the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

PITCH ON/OFF is displayed.

ANALOG

CD - RW CD

3. Push and release the REC LEVEL/SELECT

control. ON or OFF is displayed.

4. Turn the REC LEVEL/SELECT control to

toggle between ON and OFF.

5. When correct push and release the REC

LEVEL/SELECT control. PITCH ON/OFF is

displayed again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

Example

display

AUTO CUE (CD drive and Dual mode only)

AUTO CUE allows the CD player to advance to

the beginning of the audio within the track, rather

than start play back from the track start flag. This

minimizes the silence at the beginning of play

back. The factory default for AUTO CUE is OFF.

How loud the audio has to be before play back is

started is adjustable using AUTO CUE LEVEL.

How to turn AUTO CUE ON or OFF

1. In Dual mode, with the CD drive selected

push and release the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

AUTO CUE is displayed.

- 37 -

ANALOG L

CD - R CD

TRACK

1716151413121110986543217

3. Push and release the REC LEVEL/SELECT

control. ON or OFF is displayed.

4. Turn the REC LEVEL/SELECT control to

ANALOG L

CD - R CD

TRACK

1716151413121110986543217

toggle between ON and OFF.

5. When correct push and release the REC

LEVEL/SELECT control. AUTO CUE is

displayed again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

AUTO CUE LEVEL

The AUTO CUE LEVEL is adjustable from -35dB

to -45dB in 1dB increments. The factory default

for AUTO CUE LEVEL is -40dB.

How to adjust the AUTO CUE LEVEL

1. In Dual mode, with the CD drive selected

push and release the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

CUE LEVEL is displayed.

5. When correct push and release the REC

LEVEL/SELECT control. CUE LEVEL is

displayed again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

3. Push and release the REC LEVEL/SELECT

control. The current level is displayed.

4. Turn the REC LEVEL/SELECT control to

adjust the level.

ANALOG L

CD - R CD

TRACK

1716151413121110986543217

ANALOG L

CD - R CD

TRACK

1716151413121110986543217

PLAY MODE (CD drive and Dual mode only)

With PLAY MODE at PAUSE when you first

press the Play/Pause button on the CD

drive, or a selection is chosen with the REC

LEVEL/SELECT control, the selection is paused.

The second press starts play back. With PLAY

MODE at PLAY, play starts immediately.

How to set the PLAY MODE

1. In Dual mode, with the CD drive selected

push and release the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

PLAY MODE is displayed.

3. Push and release the REC LEVEL/SELECT

ANALOG L

CD - R CD

TRACK

1716151413121110986543217

control. PAUSE or PLAY is displayed.

4. Turn the REC LEVEL/SELECT control to

toggle between PAUSE and PLAY.

5. When correct push and release the REC

ANALOG L

CD - R CD

TRACK

1716151413121110986543217

LEVEL/SELECT control. PLAY MODE is

displayed again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

SINGLE PLAY (CD drive and Dual mode only)

SINGLE PLAY can be set to stop play after a

single track is played.

When at OFF, when a track is finished the next

track automatically begins playing.

When at STOP, when a track is completed the

CD drive is stopped as if a Stop button is

pushed.

When at RE CUE, when a track is completed the

CDR510 is paused to repeat the current track. If

AUTO CUE is on it is cued according to the

setting of AUTO CUE.

When at NEXT CUE, when a track is completed

the CDR510 is paused to begin the next track. If

AUTO CUE is on it is cued according to the

setting of AUTO CUE.

How to set SINGLE PLAY

1. In Dual mode, with the CD drive selected

push and release the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

SINGLE PLAY is displayed.

3. Push and release the REC LEVEL/SELECT

control. The current setting of SINGLE PLAY

is displayed.

ANALOG L

CD - R CD

TRACK

17161514131211109865437

4. Turn the REC LEVEL/SELECT control to tab

through STOP, OFF, RE CUE, and NEXT

CUE.

5. When correct push and release the REC

LEVEL/SELECT control. SINGLE PLAY is

displayed again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

ANALOG L

CD - R CD

TRACK

17161514131211109865437

- 38 -

- 39 -

END WARNING (CD drive and Dual mode only)

When END WARNING is on the remaining time

display flashes as the end of a track is ap-

proached during play back.

END WARNING can be set from 0 to 35 seconds

in 5 second increments.

END WARNING is off when set to 0.

Factory default setting is 15 seconds.

How to set END WARNING

1. In Dual mode, with the CD drive selected

push and release the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

END WARNING is displayed.

3. Push and release the REC LEVEL/SELECT

control. The current setting of END WARN-

ING is displayed.

4. Turn the REC LEVEL/SELECT control to tab

through 0 to 35 seconds in 5 second incre-

ments.

5. When correct push and release the REC

LEVEL/SELECT control. END WARNING is

displayed again.

6. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

ANALOG L

CD - R CD

19181716151413121110986543217 20

ANALOG L

CD - R CD

19181716151413121110986543217 20

Recording modes

When at Stop, press and release the REC MODE

button to tab through the Recording Modes:

RECORD FAST, REC LISTEN, REC MP3 DISC,

MAKE CD, REC EXT DISC, REC EXT MAN, and

MINUTE TRACK.

Only recording modes appropriate to the status of

the CDR510 are available. For example, REC

MP3 DISC is only available if an MP3 disc is

recognized in the CD drive.

Choosing the Recording mode is usually the last

step before actual recording (pressing the REC

button to begin recording). The CDR510 is set to

expect you have the disc you want to record on in

the CDR drive, chosen the audio source, made

necessary connections, and made necessary

menu adjustments. If you are not ready to

record, simply press and release a Stop button .

REC EXT DISC

Record External Disc (Sync Record) lets you

record from an analog or digital external audio

source: CD, DAT or MD (mini disc).

Recording is started by starting the external

source.

Recording from digital or analog sources will

automatically stop (AUTO STOP ON) after 20

seconds of silence.

Track information is automatically copied from the

external source and cannot be added manually.

For an analog audio source, or a source with no

subcode information, a silence of 2.7 seconds or

more automatically increments a track.

CD Text can be added after the copy is made and

before finalizing.

The recording is not automatically finalized.

REC EXT MAN

Record External Disc (Manual Record) lets you

record from an analog or digital audio source:

CD, DAT or MD (mini disc).

Recording is started manually by pressing the

Record button and immediately starting the

external source. You can also start the external

source before starting to record, for example to

manually adjust the input level.

Recording is stopped by pressing the CDR drive

Stop button .

With AUTO TRACK ON, track information is

automatically copied from an external source with

subcode information and cannot be added manu-

ally. For an analog audio source, or a source with

no subcode information, a silence of 2.7 seconds

or more automatically increments a track.

With AUTO TRACK OFF, track numbers can be

manually incremented by pressing and releasing

the TR. INCR. button on the IR remote or by

pressing and releasing the Record button on

the CDR510 or REC button on the IR remote.

CD Text can be added after the copy is made and

before finalizing.

The recording is not automatically finalized.

MINUTE TRACK

This REC mode is the same as REC EXT MAN

but automatically adds a track every minute.

During playback the Minute Tracks make finding

a particular passage easier because of the

relationship between track numbers and time. For

example, during playback select track 3 to play

approximately the 3rd minute of recording. To go

directly to the beginning of the 10th minute select

track 10, etc.

Track Recording time

# minutes:seconds

1 ........................ 0:00 - 0:59

2 ......................... 1:00-1:59

3 ......................... 2:00-2:59

80 ...................... 79:00-79:56

Note

During recording press the TIME button on the

- 40 -

CDR510 or the DISPLAY button on the remote to

display the remaining disc time.

Minute Track marks are silent. Playback across a

Minute Track does not produce any sound.

CD Text can be added after the copy is made

and before finalizing.

The recording is not automatically finalized.

RECORD FAST

RECORD FAST lets you copy the CD in the CD

drive to an unfinalized disc in the CDR drive at

2X speed. The entire CD in the CD drive is

copied. In PROGRAM mode the tracks pro-

grammed are copied.

In most cases AUTO TRACK and AUTO STOP

should be at ON so track information is recorded

as the copy is made.

CD Text can be added after the copy is made

and before finalizing.

The recording is not automatically finalized.

REC LISTEN

REC LISTEN lets you copy the CD in the CD

drive to a CD-R or CD-RW disc in the CDR drive

and listen during the copying. The HEAD-

PHONES jack, ANALOG OUT jacks, and DIG

OUT jacks are live during the recording. The

entire CD in the CD drive is copied at 1X speed.

In PROGRAM mode only the tracks programmed

are copied.

In most cases AUTO TRACK and AUTO STOP

should be at ON so track information is recorded

as the copy is made.

CD Text can be added after the copy is made

and before finalizing.

The recording is not automatically finalized.

REC MP3 DISC

This REC mode only appears when in

CHANGER mode and when an MP3 disc is

recognized in the CD drive.

- 41 -

The CDR510 does not copy an MP3 disc, it

converts the MP3 compressed data into audio

signals and records the audio in standard CDDA

format. While an MP3 disc can contain up to 8

hours of recording, a standard CD is limited to

80 or 74 minutes depending on the disc. Only

80, or 74, minutes of MP3 recording can be

copied (converted).

REC MP3 DISC converts one Album from the

MP3 disc and stops. The tracks (files) within the

Album become tracks on the copy. MP3 ID3 title

information is converted to CD Text track titles.

In most cases AUTO TRACK and AUTO STOP

should be at ON so track information is recorded

as the copy is made.

As in REC LISTEN you can listen during record-

ing. The HEADPHONES jack, ANALOG OUT

jacks, and DIG OUT jacks are live during the

recording.

CD Text can be added after the copy is made

and before finalizing.

The recording is not automatically finalized.

MAKE CD

MAKE CD copies the CD in the CD drive to a

disc in the CDR drive at 2X speed. The entire

CD in the CD drive is copied. In PROGRAM

mode the tracks programmed are copied.

In most cases AUTO TRACK and AUTO STOP

should be at ON so track information is recorded

as the copy is made.

The recording is automatically finalized.

- 42-

MP3

The CDR510 can play most discs** that include

MP3* files. The CDR510 cannot duplicate an

MP3 disc but can record audio from an MP3 disc

onto a blank CD-R or CD-RW disc, see How to

record MP3.

MP3 playback and recording

MP3 discs can be recognized in the CD drive

only. Reading an MP3 disc for playback or

recording requires additional instructions be

loaded into the memory of the CDR510. This

takes about 10 seconds.

When MP3 instructions are loaded into the

CDR510 memory depends on the setting of

AUTO MP3 LOAD. With AUTO MP3 LOAD ON,

loading MP3 instructions takes place on power

up. If you often play MP3 discs this option avoids

delay when you insert an MP3 disc. With AUTO

MP3 LOAD OFF, loading MP3 instructions does

not take place until an MP3 disc is recognized in

the CD drive or MP3 LOAD is activated. If you

rarely play MP3 discs this option speeds power

up.

* “MP3” refers to music data which has been

compressed by a file format known as “MPEG-1

Audio Layer 3.” Files with the “.mp3” or “.MP3”

extension are called MP3 files.

The ID3 tag is supported by the CDR510. ID3 is

a format that adds title information to MP3 files.

**The following technical issues can result in

MP3 incompatibility with the CDR510:

• MP3 files recorded using the packet writing

method are not compatible for playback in the

CDR510.

• Compatible MP3 sampling frequencies

include 32-48 kHz.

• Compatible bit rates allowed include 32-320

kbps.

• The type of PC, software and media used for

recording might be incompatible.

• The disc may contain too many sessions or

files.

A "session" occurs each time a recording is

made and finalized. When a CD-RW disc is

unfinalized and tracks are added it creates an

additional session on the disc. This is also

sessions) and a maximum of 20 files.

AUTO MP3 LOAD

How to turn AUTO MP3LOAD on or off

1. With the CD drive selected push and release

the MENU/STORE button.

2. Turn the REC LEVEL/SELECT control until

AUTO MP3LOAD is displayed.

ANALOG

CD - R CD

3. Push and release the REC LEVEL/SELECT

control. ON or OFF is displayed.

ANALOG

CD - R CD

4. Turn the REC LEVEL/SELECT control to

toggle between ON and OFF.

5. When correct push and release the REC

LEVEL/SELECT control. AUTO MP3LOAD is

displayed again.

6. Turn the REC LEVEL SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

applicable to CD-R discs that are recorded in

some PC applications where finalizing is not

necessary to provide multi-sessions.

Recommended: the disc contain no more

than 10 sessions, 20 Albums (including all

MP3 LOAD

MP3 LOAD lets you load MP3 instructions without

inserting an MP3 disc.

How to MP3 LOAD

1. With AUTO MP3 LOAD off, with the CD drive

selected, and with no disc* in the drive, push

and release the MENU/STORE button.

*If AUTO MP3 LOAD is on, MP3 instructions

were loaded on power up. If an MP3 disc is in

the CD drive, MP3 instructions were loaded

when the MP3 disc was recognized. If a

standard CD is in the CD drive MP3 LOAD is

not available.

CD - RW

2. Push and release the REC LEVEL/SELECT

control. MP3 LOADING is displayed as MP3

instructions are loaded.

CD - RW

ANALOG L

The level meters show the progress of MP3

instruction loading.

3. Turn the REC LEVEL/SELECT control to

switch to other menu choices or press and

release the CANCL/DELETE button to exit

menu mode.

- 43 -

How to record MP3

MP3 compressed data is converted into audio

signals and recorded in standard CD format. An

MP3 disc can contain up to 8 hours of recording

but a standard CD is limited to 80 or 74 minutes

depending on the disc. See example play se-

quence on the next page for an illustration of the

relationship between Albums (folders) and tracks

(files).

If AUTO STOP is ON, one Album from the MP3

disc recorded and then recording stops. The

tracks (files) within the MP3 Album become

tracks on the copy. MP3 ID3 title information is

converted to CD Text track titles. The Album title

is converted as the recording session closes. A

maximum of 32 characters per title is converted,

if the ID3 title is longer it is truncated.

CD - RW

DUBBING

CD - RW

DUBBING

TOTAL RE M

CD - RW

DUBBING

You can listen during recording. The HEAD-

PHONES jack, and ANALOG OUT jacks, are live

during MP3 recording. Digital output is not avail-

able during MP3 recording.

CD Text can be added after the copy is made and

before finalizing.

The recording is not automatically finalized.

1. With the MP3 disc to be converted in the CD

drive, press and release the PLAY MODE

button to select CHANGER mode.

2. With a recordable CD in the CDR drive, press

and release the REC MODE button. REC MP3

DISC will be displayed for a few seconds.

Then the display will alternate between

PRESS RECORD and the recording time

remaining on the CD-R or CD-RW in the CDR

drive.

3. If you press the Record button the first

album on the MP3 disc will be recorded. To

select a different album, press and release an

ALBUM button, or , until the desired

album is selected.

Hint:

You are in Recording pause. You can check

on what would be recorded by pressing the

ALBUM buttons, or , to select the

Album and turning the REC LEVEL/SELECT

control to select the track and the CD drive

Play/Pause button to play the file.

4. Press and release the Record button . All of

the tracks (files) in the currently selected

Album, beginning with track 1, will be re-

corded. If AUTO STOP is ON, recording will

automatically stop.

During recording, or after step 2, you can adjust

the recording level by turning the REC LEVEL/

SELECT control.

MP3 LOAD

appears.

• The dashed line with an arrow ( ) indicates the

sequence in which the MP3 albums and tracks (MP3

files in the albums) are played.

• Album 01 to Album 10

In the example shown, this CD-ROM has 10 albums

(folders) but albums 03 and 08 do not contain MP3

files and so are not played.

• AAAA01.mp3 to gggg17.mp3

In the example shown, this CD-ROM has 17 tracks

starting with track "01" and ending with track "17."

• Only those files with the ".mp3" extension are played;

files with the .wav, .jpg, .doc and other extensions are

skipped.

• Album 01 is allocated even when there are no files in

the root.

• The sequence may differ from the one that appears

on the personal computer. It may also differ

depending on the software used.

Play up to 8 hierarchical levels possible.

Example play sequence as displayed in Windows Explorer:

Album 02

Album 03

aaaa03.mp3

aaaa04.mp3

aaaa05.mp3

aaaa06.mp3

Album 04

Album 05

bbbb07.mp3

bbbb08.mp3

Album 06

dddd11.mp3

dddd12.mp3

Album 07

eeee13.mp3

eeee14.mp3

Album 08

wwww.wav

xxxx.wav

Album 09

ffff15.mp3

Album 10

gggg16.mp

gggg17.mp

AAAA01.mp3 Root

BBBB02.mp3 Album 01

RANALOG

10964217

CHANGER

Display during Stop of disc

with example files and

folders.

17 mp3 files 8 albums

albums that contain mp3 files

- 44 -

MP3 FILE PLAYBACK

Playing Albums in sequence

1. As with a music CD, place the disc recorded

using the MP3 files on the CD drive disc tray

and retract the disc tray.

2. Press the CD drive Play/Pause button .

Play now starts playing files in sequence from

the first Album on a folder-by-folder basis*

Selecting Albums and files for play back

Select the desired Album (on a folder-by-folder

basis*) and track (file*):

1. From Stop, press and release or to

tab through Albums (folders).

2. Turn the REC/LEVEL SELECT control to tab

through tracks within the selected Album.

(There is a three second time-out to Pause

cued to the selected Album and track. Press

Play to begin Play.)

3. During playback press and hold or to

fast reverse or fast forward, or

4. press and release repeatedly to step through

Albums. (There is a 3 second time-out to

Play.)

5. During playback turn the REC LEVEL/

SELECT control to step through tracks.

(There is a 3 second time-out to Play.)

*See example play sequence in the box to the

left.

The following play back features are not

available during MP3 play back:

• A-B repeat

• Program play

• End monitor

• Auto cue

• Change of time mode (TIME button)

• End warning

Random play is Album by Album not track (file)

by track.

MP3 Album/file structure

ANALOG

CD - R

PROGRAM

STEPTOTAL

1412119

c d f b

a e

ANALOG

CD - R

PROGRAM

STEPTOTAL

12119

How to PROGRAM tracks

Track sequence can be programmed for playback

or recording. From stop in CHANGER or DUAL

MODE, push and release the PROG button to

enter Program mode.

ANALOG

CD - R

PROGRAM

a b

Example

display

"PROGRAM" (a) will be displayed briefly, then

PROGRAM (b) will be flashing.

Turn the REC LEVEL/SELECT control to select

the Track to be programmed. When correct push

the REC LEVEL/SELECT control to add that

track to the program.

Example

display

In the example tracks on the CDR drive (a) are

being programmed. Five steps have been pro-

grammed (b): tracks 4, 6, 9, 11, and 12 (c) (not

necessarily in that order). Track 14 (d and e) is

selected. If Track 14 is added to the program as

step 6, the TOTAL time programmed (f) will be 24

minutes and 57 seconds.

When your program is done, press a Stop button

or the PROG button to end programming. PRO-

GRAM will be lit and steady.

Example

display

Press Play/Pause to start programmed play.

Clearing a program:

Press Stop to stop programmed play, then

press Stop again to clear the program.

To edit a program:

From Stop mode, press PROG to enter Program

mode.

Add a track to the program as above.

To erase a track from the program, turn the REC

LEVEL / SELECT control to select the track,

then press the CANCL / DELETE button. The

remaining program steps and playing time will

be displayed.

To program for recording:

Only tracks from the CD in the CD drive can be

programmed for recording.

Press the REC MODE button and select your

recording mode. Then program tracks as above.

When done, press the Record button to start

recording.

Notes:

To review a program, with PROGRAM flashing,

press the ALBUM reverse or ALBUM

forward button to tab through the program.

The display will show the track number pro-

grammed, the time contributed by that track to

the total programmed time, and the program

step.

A track can be programmed more than once.

In CHANGER Mode the program can switch

between the CD drive and CDR drive.

If you try to store more than 99 steps, "PROG

FULL" appears on the display.

- 45 -

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

ERASE

REC LEVEL / SELECT

PUSH ENTER

FINAL INPUT

MODE MENU/

STORE TIME TEXT PROG

ALBUM

REC

CANCL/

DELETE

Finalizing

Finalizing is writing the TOC (table of contents)

on a disc so a CD player can recognize the

number of tracks, their location on the disc, the

total time for each track, and CD text. A recorded

disc must be finalized to playback on a standard

CD player. Once finalized a CD-R disc can be

played on CD players that support CD-R play-

back. CD-RW discs can only be played on CD

players that support CD-RW playback. Consult

your CD player owner's manual to confirm sup-

ported formats.

Finalizing is necessary to:

• be able to play a recorded CD-R or CD-RW

disc on a standard CD player

• prevent further recording on a disc

• avoid erasing tracks on a CD-RW disc

• record CD text information onto a disc you

record

Notes:

• A finalized CD-R disc can never be recorded

onto again

• A finalized CD-RW disc can be unfinalized for

more recording

• The CDR510 can play back unfinalized CD-R

or CD-RW discs in both drives

• The MAKE CD recording mode automatically

finalizes the recorded disc

How to Finalize a CD-R or CD-RW disc:

1. Push Stop on the

CDR drive. The

display shows the

2. Push FINAL.

"FINALIZE CD"

alternates with

"PRESS RECORD".

Note:

If the disc is blank

NOT POSSIBLE is

displayed for sev-

eral seconds.

3. Push the Record

button . The timer

(a) counts down as

TOC (Table Of

Contents) is written.

When done the

display shows the

number of tracks (b)

and their total

playing time (c) of

the disc now ready

If the disc has been

finalized, FINAL-

IZED CD flashes

four times, then the previous display returns.

for playback (example shown).

CD-RW or CD-R changes to CD (d).

TOTAL

CD - R

19181716151413121110986543217 20

DIG

CD - R

19181716151413121110986543217 20

DIG

CD - R

DIG

ANALOG

CD - R

13121110986543217

CD - R

REM

DIG

19181716151413121110986543217 20

TOTAL

19181716151413121110986543217 20

DIG

b c

- 46 -

3 1

number of tracks and their total playing time

(example shown).

Unfinalizing

How to unfinalize, erase a track, or erase a

CD-RW disc

Only CD-RW discs can be erased.

If the CD-RW disc has been finalized it must first

be unfinalized before it can be erased.

With the CD-RW disc in the CDR drive and at

stop:

1. Push and release the ERASE button.

ERASE

Recorda

ble

PLAY MODE

CD RECORDER / CD PLAYER CDR510

POWER

CDR CD

FINAL

REC

MODE MENU/

STORE

INPUT CANCL/

DELETE

PUSH ENTER

REC LEVEL / SELECT

TIME TEXT PROG

ALBUM

MP3 PITCH

HEADPHONE LEVEL

010

PROFESSIONAL

ERASE

REC LEVEL / SELECT

PUSH ENTER

FINAL INPUT

MODE MENU/

STORE TIME TEXT PROG

ALBUM

REC

CANCL/

DELETE

a b

1 2

If the CD-RW disc has been finalized UNFINAL-

IZE will be displayed (if not skip to 3 below)

Example

display

alternating with PRESS ENTER.

CD - RW

ANALOG

3214

CD - RW

ANALOG

3214

2. Press and release the REC LEVEL/SELECT

control to unfinalize.

CD - RW

ANALOG

3214

REM

Example

display

During unfinalizing the time to completion counts

down (a) and UNFINAL (b) is displayed.

3. The display alternates between ERASE

TRACK

and PRESS RECORD.

CD - RW

ANALOG

3214

4. To erase the last track on the CD-RW disc

Press and release the Record button .

Note

You cannot select an early track to erase. Only

the last track on the disc can be erased, or the

entire disc.

Or press and release the ERASE button again.

The display alternates between ERASE DISC

and PRESS RECORD.

CD - RW

ANALOG

3214

5. To erase the entire CD-RW disc Press and

release the Record button .

Or press and release the CDR drive Stop button

to exit erase mode.

CD - RW

ANALOG

3214

- 47 -

CD - RW

ANALOG

3214

- 48 -

DISPLAY messages

Display messages listed below may appear for

your guidance.

ALBUM TITLE ........ followed by album title

ALL TEXT ............... entering all text display mode

ANALOG ................analog input selected

AUTO TRACK ........selecting AUTO TRACK on or

off

CHANGER MODE . control attempted during dual

mode that only applies to

changer mode

CLOSE ................... while a disc tray is closing

COPY ..................... entering copy protection

selection menu

DIGITAL I............... digital coaxial input selected

DISC ERROR......... when trying to record on, or

finalize a recovered disc (disc

is no longer usable)

DISC FULL .............no more recording possible

DOES NOT FIT ...... remaining recording time on

CD not enough for proposed

recording

DUAL MODE .......... when dual mode is selected

ERASE DISC ......... erasing a CD-RW disc

ERASE OK ............. confirmation for erasing has

to be given by pressing the

REC LEVEL / SELECT

control

ERASE TRACK ...... erasing last track on CD-RW

disc

FINALIZE CD .........finalizing a disc

FINALIZED .............trying to record on a finalized

disc

FINALIZED CD.......CD-R/RW disc has been

finalized

INITIALIZING .........during laser power calibration

for unfinalized discs

INSERT DISC ........ insert disc, or insert disc

correctly

MAKE CD ............... recording mode CD copying

with finalizing

NO DISC ................no disc in tray, disc unread-

able, or disc upside down

NO TEXT................no text stored for disc

NO TRACK.............trying to edit CD Text on a

disc that has no tracks

NOTFINALIZED .....when opening the CDR drive

with an unfinalized disc in it

OFF ........................during menu selection for

menu item to be off

ON ..........................during menu selection for

menu item to be on

OPC ERROR ......... Optimum Power Calibration

failure (CD-R/RW disc is

bad)

OPEN .....................while a disc tray is opening

or open

OPTICAL ................digital optical input selected

PRESS RECORD ..press record to start

finalizing, erasing, or record-

ing

PROGRAM.............when program mode is

selected

PROGRAM FLL .....program full

READING ............... reading disc information

REC BALANCE ...... when adjusting balance

REC EXT DISC ...... recording mode sync record

with starting external source

REC EXT MAN.......recording mode from exter-

nal source with manual start

REC LISTEN .......... recording mode CD dubbing

while listening

RECORD FAST......recording mode CD dubbing

at 2X speed

START SOURCE ... start source for sync record-

ing

TEXT EDIT .............entering text edit mode

TEXT ERASE .........entering text erase mode

TEXT VIEW ............entering text review mode

TRACK TITLE ........followed by track title

UNFINALIZE,

PRESS ENTER ..... trying to record on a finalized

CD-RW disc

UNFINALIZED........CD-R/RW disc being ejected

is not finalized

UPDATE .................updating disc contents

WAIT ...................... • when Stop is pressed

during recording

• when stop is pressed

during the first four sec-

onds of a track

WRONG DISC .......disc is not an audio CD disc

XX AL X .................mp3 files (XX) and albums

(X)

XX XX ERASE ......time countdown when

erasing a track or the entire

disc

XXXX FINAL .......... time countdown when

finalizing a disc

- XX DB ..................recording level being ad-

justed

- 49 -

About Compact Discs

There are two types of recordable discs:

CD-R (record once)

CD-R discs are only able to be recorded onto a

single time but will playback in most CD play-

ers.

CD-R discs can be recognized by the following

logos:

CD-RW (multiple recording)

CD-RW discs are able to be recorded onto

many times but will only playback in CD players

offering CD-RW compatibility. Products that

offer CD-RW compatibility are available from

Marantz Professional. Please contact your

dealer for more information on these products.

CD-RW discs can be recognized by the follow-

ing logos:

Notes:

• Some DVD players cannot playback CD-R

discs and some cannot playback CD-RW

discs because of laser power differences.

• Some CD players may be able to playback

finalized CD-RW discs.

• Some CD players can not play finalized CD-R

discs because of the low reflectivity of such

discs.

Which discs to use:

The CDR510 is able to record onto any 1X

compatible CD-R and CD-RW disc, including

discs for Consumer use and Professional (com-

puter) discs.

The CDR510 records according to the Orange

Book specification. Every CDR disc sold should

Recordabl

Recordable

be according to the Orange Book specification

and therefore compatible with the CDR510.

In practice however, the quality of the recording

depends on the match between the disc used

and the writing strategy of the recorder. At 1X

speed (stand alone audio) the match between

disc and recorder is important. Higher recording

speeds are less critical in terms of recording quality.

Consumer CD Recorders can only record on CDR

Audio discs and those discs are optimized for single

speed automatically. Professional CD Recorders can

use both Audio and Data discs. When using Data

discs, one should take care to use discs with a good

single speed compatibility.

Recording Capacity:

Discs with higher capacity than 80 minutes are out of

the Orange Book standard and may perform below

your expectations.

Compact disc care

The glossy side is the record side of the disc, and

matted (dull) side is the label side.

Handle discs carefully so as not to damage or scratch

the record side.

Avoid placing discs in the following locations:

• In direct sunlight or near a source of heat such as

a heater.

• In a place that is damp or dirty.

• In a place which could be exposed to rain, such as

near a window.

Disc cleaning

Always keep the disc surface clean. Up to six billion

data units are recorded on the record side of the disc.

When cleaning the disc surface always be sure to use

a special compact disc cleaner and wipe as shown

below.

Wipe in a radial

direction.

Do not wipe in

circumferential

direction.

- 50 -

• Do not use record cleaner, it will adversely affect

the disc surface.

• Store discs in their disc cases.

• Do not attach a piece of

paper or sticker to the label

side of the disc.

When a disc has a piece of plastic tape or rental

CD label with paste protruding from the edge or

when a disc has a trace of such as sticky object,

do not attempt to play the disc. The disc may be

impossible to take out, or another malfunction

may result.

• Write only on the printed side of a CD-R or CD-

RW disc, and only with a soft felt-tipped pen.

• Do not attempt to play a disc

with a special shape such as

an octagonal or heart shaped

disc. Equipment malfunction

may result.

- 51 -

RS-232C control

Connect a male (D-Sub 9 Pin) to female (D-Sub 9 Pin)

straight cable for RS-232C external control by host

equipment.

• The RS-232C host can control functions of the

CDR510 externally

• The CDR510 automatically transmits status data

when status is changed.

• The CDR510 will respond to status requests by

transmitting the associated status data.

Control commands:

Hand shake flow charts for control commands:

CDR510 Typical Ho

Received Command

Status Command

Host sends a command that causes a

change in CDR510 status.

Host sends a command that causes no

change in CDR510 status. For example,

Host requests Play during Playback.

Commands Requesting Status

The following Request Commands from the host are

received by the CDR510, then the status code is

transmitted to the host.

CDR510 Typical Ho

Received Command

Command CD command CDR Command

0 "@12000"+CR

1 "@12001"+CR

2"@12002"+CR

3 "@12003"+CR

4 "@12004+CR

5 "@12005+CR

6 "@12006"CR

7 "@12007"+CR

8 "@12008"+CR

9 "@12009"+CR

Display "@12011"+CR

Scroll

"@12015"+CR

Repeat "@12029"+CR

Next "@12032"+CR "@12632"+CR

Previous "@12033"+CR "@12633"+CR

"@12600"+CR

"@12601"+CR

"@12602"+CR

"@12603"+CR

"@12604"+CR

"@12607"+CR

"@12606"+CR

"@12605"+CR

"@12608"+CR

"@12609"+CR

"@12615"+CR

"@12611"+CR

"@12629"+CR

Pitch Reset "@12037"+CR

Pitch Up Start "@12038"+CR

Pitch Up Stop "@1203801"+CR

Pitch Down Start "@12039"+CR

Pitch Down Stop "@1203901"+CR

Program "@12036"+CR "@12636"+CR

AMS "@12043"+CR "@12643"+CR

Pause "@12048"+CR "@12648"+CR

Cancel/Delete "@12049"+CR "@12649"+CR

Fast Backward Start "@12050"+CR "@12650"+CR

Fast Backward Stop "@1205001"+CR

Fast Forward Start "@12052"+CR "@12652"+CR

Fast Forward Stop "@1205201"+CR

Play "@12053"+CR "@12653"+CR

Stop "@12054"+CR "@12654"+CR

"@1265001"+CR

"@1265201"+CR

Store/Menu "@12082"+CR

Enter "@12687"+CR

Select CD

Select CDR "@12663"+CR

Random "@12028"+CR "@12628"+CR

"@12682"+CR

"@12087"+CR

"@12063"+CR

Track Inc. "@126114"+CR

Open/Close "@12045"+CR "@12645"+CR

Request Command for CD Response from CD

"@120PRON"+CR

Power "@1?20POWE"+CR Power On

"@1?20TRAY"+CR "@120OPEN"+CR

"@120CLOS"+CR

Open

Toc Reading

Stop

Play

Pause

REW

"@120TOCR"+CR

"@120STOP"+CR

"@120PLAY"+CR

"@120PASE"+CR

"@120FASF"+CR

"@120FASR"+CR

Play

Mode "@1?20PLAY"+CR

Disc "@1?20DISC"+CR

No Disc

ERROR

CDDA

MP3

"@120NODI"+CR

"@120ERDI"+CR

"@120CDDI"+CR

"@120MPDI"+CR

OFF

ALL

"@120RTOF"+CR

"@120RTON"+CR

"@120RTAL"+CR

Repeat

Mode "@1?20RPTM"+CR

Track

Track Remain

Total Remain

Total Lap

"@120TTRA"+CR

"@120TTRE"+CR

"@120TREM"+CR

"@120TTLA"+CR

Time

Mode "@1?20TMOD"+CR

Album "@1?20ALBU"+CR "@120Axxx"+CR

Track "@1?20TRAC"+CR "@120Txxx"+CR

Current

Display

Time "@1?20TIME"+CR "@120Xxxx"+CR

Tray

Mode

End

Warning "@1?20WARN"+CR "@120WARN"+CR

Warning

No Warning "@120NOTW"+CR

- 52 -

Hand shake flow chart for Commands Requesting

Status:

CDR510 Typical Ho

Status Request

Command

Status Command

Status changes automatically transmitted.

The following status codes are automatically transmit-

ted to the host.

Hand shake flow chart for automatic status

data:

CDR510 Typical Ho

Status Command

RS-232C specifications:

Connector pin assignment

6 7 8 9

1 2 3 4 5

use

GND

RTS

CTS

CDR510

Not Connected

Transmit Data

Receive Data

Not Connected

Ground

Not connected

RTS receive

CTS send

Not Connected

D-Sub 9 pin

(male)

Typical Host

Not Connected

Receive Data

Transmit Data

Not Connected

Ground

Not connected

RTS send

CTS receive

Not Connected

D-Sub 9 pin

(female)

cable

connector

Physical specifications

Cable

Baud rate

Data bits

Parity bit

Stop bit

Flow control

Straight cable

9600 bps

8 bits

None

1 bit

CTS/RTS Hardware Flow

Request Command for CDR Response from CDR

"@126PRON"+CR

Power "@1?26POWE"+CR Power On

"@1?26TRAY"+CR "@126OPEN"+CR

"@126CLOS"+CR

Open

Toc Reading

Stop

Play

Pause

REW

"@126TOCR"+CR

"@126STOP"+CR

"@126PLAY"+CR

"@126PASE"+CR

"@126FASF"+CR

"@126FASR"+CR

Play

Mode "@1?26PLAY"+CR

Disc "@1?26DISC"+CR No Disc

ERROR

CDDA

"@126NODI"+CR

"@126ERDI"+CR

"@126CDDI"+CR

OFF

ALL

"@126RTOF"+CR

"@126RTON"+CR

"@126RTAL"+CR

Repeat

Mode "@1?26RPTM"+CR

Track

Track Remain

Total Remain

Total Lap

"@126TTRA"+CR

"@126TTRE"+CR

"@126TREM"+CR

"@126TTLA"+CR

Time

Mode "@1?26TMOD"+CR

Track "@1?26TRAC"+CR "@126Txxx"+CR

Current

Display

Time "@1?26TIME"+CR "@126Xxxx"+CR

Tray

Mode

Marantz Cdr510 Users Manual 1 23

CDR510 to the manual 756c553f-b3ea-493b-abec-3c7fe6900772

Navigation menu

Versions of this User Manual:

Views

Navigation
