Model DR6050 User Guide

Compact Disc Recorder

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within

an equilateral triangle, is intended to alert the user

to the presence of uninsulated “dangerous voltage”

within the product’s enclosure that may be of suffi-

cient magnitude to constitute a risk of electric shock

to persons.

The exclamation point within an equilateral triangle

is intended to alert the user to the presence of

important operating and maintenance (servicing)

instructions in the literature accompanying the

product.

CAUTION:

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE

OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION:

POUR ÉVITER LES CHOCS ÉLECTRIQUES,

INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE

CORRESPON DANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

LASER SAFETY

This unit employs a LASER. Only a qualified service person should remove the cover or attempt to service this

device, due to possible eye injury.

CAUTION-USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURE OTHER THAN

THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

NOTE:

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential instal-

lation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interfer-

ence will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television recep-

tion, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interfer-

ence by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and re-

ceiver.

– Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician

for help.

NOTE:Changes or modifications may cause this unit to fail

to comply with Part 15 of the FCC Rules and may void the

user's authority to operate the equipment.

This Class B digital apparatus meets all

requirements of the Canadian Interference-

Causing Equipment Regulations.

Cet appareil numérique de la Classe B respecte

toutes les exigences du Règlement sur le materiel

brouilleur du Canada.

INPORTANT SAFETY

INSTRUCTIONS

READ BEFORE OPERATING EQUIPMENT

This product was designed and manufactured to meet strict

quality and safety standards. There are, however, some instal-

lation and operation precautions which you should be particu-

larly aware of.

1. Read Instructions — All the safety and operating instruc-

tions should be read before the appliance is operated.

2. Retain Instructions — The safety and operating instruc-

tions should be retained for future reference.

3. Heed Warnings — All warnings on the appliance and in

the operating instructions should be adhered to.

4. Follow Instructions — All operating and use instructions

should be followed.

5. Water and Moisture — The appliance should not be used

near water — for example, near a bathtub, wash-bowl,

kitchen sink, laundry tub, in a wet basement, or near a

swimming pool, etc.

6. Carts and Stands — The appliance should be used only

with a cart or stand that is recommended by the manufac-

turer.

7. An appliance and cart combination should be moved with

care. Quick stops, excessive force, and uneven surfaces

may cause the appliance and cart combination to over-

turn.

8. Wall or Ceiling Mounting — The appliance should be

mounted to a wall or ceiling only as recommended by the

manufacturer.

9. Ventilation — The appliance should be situated so that its

location or position does not interfere with its proper venti-

lation. For example, the appliance should not be situated

on a bed, sofa, rug, or similar surface that may block the

ventilation openings; or, placed in a built-in installation,

such as a bookcase or cabinet that may impede the flow of

air through the ventilation openings.

10. Heat — The appliance should be situated away from heat

sources such as radiators, heat registers, stoves, or other

appliances (including amplifiers) that produce heat.

11. Power Sources — The appliance should be connected to

a power supply only of the type described in the operating

12. Grounding or Polarization — The precautions that should

be taken so that the grounding or polarization means of an

appliance is not defeated.

AC POLARIZED PLUG

13. Power-Cord Protection — Power-supply cords should be

routed so that they are not likely to be walked on or pinched

by items placed upon or against them, paying particular at-

tention to cords at plugs, convenience receptacles, and the

point where they exit from the appliance.

14. Cleaning — The appliance should be cleaned only as rec-

ommended by the manufacturer.

15. Nonuse Periods — The power cord of the appliance should

be unplugged from the outlet when left unused for a long

period of time.

16. Object and Liquid Entry — Care should be taken so that

objects do not fall and liquids are not spilled into the enclo-

sure through openings.

17. Damage Requiring Service — The appliance should be

serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged;

B. Objects have fallen, or liquid has spilled into the appli-

ance; or

C. The appliance has been exposed to rain; or

D. The appliance does not appear to operate normally or

exhibits a marked change in performance; or

E. The appliance has been dropped, or the enclosure

damaged.

18. Servicing — The user should not attempt to service the

appliance beyond that described in the operating instruc-

tions. All other servicing should be referred to qualified ser-

vice personnel.

iii

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER

ON/OFF

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

INTERNALEXTERNAL

INPUT

ANALOG IN/OUT

OUTPUT OUTPUT

CDR/CD

DIGITAL IN/OUT

INPUT CDR/CD CD

OPTICALCOAXIAL CONTROL

REMOTE

INPUT OUTPUT

CDR/CD CD

OUT

STANDBY

AC IN

1 234 5 6 78910111213141516 1718192021

27 26 25 2423 22

28 29 30 31 32 33 34 35363738 39 40

CONTROLS AND CONNECTIONS

Player front

Player back

Display

Remote control

41 42 43 44 45 46 47

53545556575859

MENU/

STORE CANCEL/

DELETE

987

654

321

RANDOMPROG.REPEAT

TRACK

INCR.

REMOTE CONTROLLER

RC6050DR

SCAN

CDR

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

DISPLAY SPACE SCROLL

FUNCTION

ENTER

ENGLISH

TABLE OF CONTENTS

CONTROLS AND CONNECTIONS............... iii

Player front...........................................................iii

Player back ..........................................................iii

Remote control.....................................................iii

Display .................................................................iii

INTRODUCTION............................................. 1

Unpacking ............................................................ 1

Setup.................................................................... 1

Conpact discs ...................................................... 1

Maintenance ........................................................ 2

CONTROLS AND CONNECTIONS................ 3

INSTALLATION .............................................. 5

The following options are available: ..................... 5

Analog connections.............................................. 5

Digital Coaxial connections .................................. 5

Digital Optical connections................................... 6

D-BUS CONNECTION.................................... 6

Remote control cable connections ....................... 6

USING THE RECORDER ............................... 7

Switching ON and OFF ........................................ 7

Using the remote control ...................................... 7

Inserting discs ...................................................... 7

RECORDING .................................................. 8

Remarks about recording .................................... 8

Recording modes ................................................. 8

RECORDING (FROM INTERNAL CD-DECK) .......

Double speed recording ....................................... 9

Normal speed recording .................................... 10

RECORDING (FROM EXTERNAL SOURCE) .....

Manual start recording ....................................... 11

CD-SYNC........................................................... 12

FINALIZING/UNFINALIZING........................ 13

Finalizing CD-R & CD-RW discs ........................ 13

Unfializing CD-RW discs .................................... 13

ERASING ...................................................... 14

Erasing ............................................................... 14

Erasing one or more tracks from the end........... 14

Erasing the entire disc ....................................... 14

PLAYING....................................................... 15

Playing a 2-disc-changer (Changer mode) ........ 15

Playing CDs on Deck 1 and/or Deck 2 (DJ mode) ......

Selecting a track ................................................ 16

Scan play ........................................................... 16

Search................................................................ 16

Random play ...................................................... 16

Repeat play ........................................................ 16

PROGRAMMING .......................................... 17

Programmed play............................................... 17

MENU MODE ................................................ 18

MENU MODE can set up: .................................. 18

Text settings ....................................................... 18

Recording settings ............................................. 19

DISPLAY ....................................................... 20

General .............................................................. 20

Recording........................................................... 20

Play .................................................................... 20

Others ................................................................ 20

Menu messages................................................. 21

OTHER INFORMATIONS ............................. 21

Fixing problems.................................................. 21

Diagnostic Program ........................................... 22

ABOUT TEXT................................................ 23

ENGLISH

Recordable

Congratulations on the acquisition of your CD-Recorder. This

CD-Recorder now enables you to record, play and erase your

own audio Compact Discs. Naturally the recorder can also be

used to play all pre-recorded CDs.

With the exception of legal restrictions pertaining to copying,

you can now create your own high-quality audio recordings on

CD. The discs used to record must bear the logos shown be-

low. Copyright fees have been paid on these discs in some

countries. Recording on other types of discs (e.g. CD-R for pro-

fessional recordings) is not possible.

There are two types of recordable AUDIO discs:

CD-R(W) discs have a compatibility to play/record on the CD-

Recorders based on the ORENGE BOOK Part II/III. But the

discs might not be able to be played/recorded properly depend-

ing on the combinations of the discs and CD-Recorders.

1 CD Recordable Audio (record once):

Fully recorded and subsequently finalized audio CD-R discs

can be played on all CD players and recorders that are suit-

able for CD-R discs. A CD-R disc can be recognized by the

following logo:

2 CD ReWritable Audio (multiple recording):

Recorded and finalized audio CD-RW discs can be played

on all CD players and recorders that are suitable for CD-RW

discs. An increasing number of players and recorders will be

suitable for these discs in the future. A CD-RW disc can be

recognized by the following logo:

The CD-R(W)disc for ‘DIGITAL AUDIO’ can be both recording

and playing on this CD-Recorder. In addition, this CD-Re-

corder can play the CD-R(W) disc for ‘PROFESSIONAL RE-

CORDING’, but cannot record it.

Once you start using the recorder, you will discover how easy it

is to ‘make’ your own CDs. Nevertheless, we recommend that

you use an erasable (CD-RW) digital audio disc on your first

attempt, while following the instructions given here.

Attention!

Recordings may only be made for personal use.

It is forbidden to copy material protected by copyright, in-

cluding computer programs, films, television and audio

recordings. This appliance may not be used for applica-

tions of this type.

Note:

Some CD players can not play the finalized CD-R(W) discs be-

cause of the low reflectivity of such discs.

Because of laser power differences, some DVD players cannot

play the finalized CD-R(W) discs.

Read the text carefully and keep the instructions close at hand

so that you can refer to them if necessary.

INTRODUCTION

ReWritable

Unpacking

First check the contents of the packaging. It should contain the

following:

- CD-Recorder DR6050

- Remote control with batteries packaged separately

- Audio cables (2 - with red and white plugs)

- Remote control cable (with orange plugs)

- Instructions

- Guarantee

If one of these components is missing, please inform your sup-

plier immediately. Save the packaging material it may come in

handy if you move the appliance.

Setup

- Place the recorder on a strong, vibration-free surface.

- Do not use the recorder under extremely damp condi-

tions.

- If the recorder is placed in a cabinet, make sure that a

2.5 cm space remains free on all sides of the recorder

for proper ventilation.

Attention!

If the appliance is not used or operated in accordance with

the instructions, this may result in exposure to dangerous

radiation or other risks.

Only authorized technicians are allowed to open the appli-

ance casing or to perform repairs or maintenance.

Compact discs

The glossy side shining like a rainbow is the front side of the

disc, and the side on which the label is printed is the back.

Unlike conventional turntables for playing analog discs, the

DR6050 reads the information recorded on the disc from under-

neath without contacting it using a beam of laser light. There-

fore, the performance of a compact disc will not degrade like

conventional analog records.

Handle discs carefully so as not to damage or scratch the

front side.

To protect the disc, avoid placing it in the following loca-

tions:

- In direct sunlight or near a source of heat like a heater.

- In a place which is damp or dirty.

- In a place which could be exposed to rain, such as near

a window.

Always keep the disc surface clean.

Up to six billion data units are recorded on the front side of the

disc. When cleaning the disc surface, always be sure to use a

special compact disc cleaner and wipe as shown below.

ENGLISH

•Do not use conventional record cleaner for analog records,

as this will adversely affect the disc surface.

Store discs properly by placing them in their disc cases.

•Do not attach a piece of paper or sticker on the label side of

disc. When a disc has a piece of plastic tape or rental CD

label with paste protruded from the edge or when a disc has

a trace of such a sticky object, do not attempt to play the disc.

If such a disc is played on the CD player, impossibility of tak-

ing out the disc or other malfunction may result.

•Write only on the printed side of a CD-R or CD-RW, and only

with a soft felt-tipped pen.

•Do not use a disc with a special shape.

Do not attempt to play a disc with a special shape such as a

heart-shaped disc or octagonal disc. Otherwise the equip-

ment malfunction may result.

Maintenance

Clean the CD-Recorder with a soft, slightly dampened lint-free

cloth. Do not use any cleaning agents as they may have a cor-

rosive effect.

Do not expose the CD-Recorder, batteries or CDs to humidity,

rain, sand or excessive heat (caused by heating equipment or

direct sunlight).

If the CD-Recorder cannot read CDs correctly use a commonly

available cleaning CD to clean the lens before taking the CD

player to be repaired. Other cleaning methods may destroy the

lens. Always keep the tray closed to avoid dust on the lens.

The lenses may cloud over when the CD-Recorder is suddenly

moved from cold to warm surroundings. It is not possible to play

a CD then. Leave the CD-Recorder in a warm environment until

the moisture evaporates.

INTRODUCTION

Recordable

ReWritable

SOURCE

REC TYPE

OPEN/CLOSE

OPEN/

ERASEFINALIZE

POWER

ON/OFF

PLAY/PAUSE

STOP

REC

CDR

CD RECORDER DR6050

PLAY/PAUSE

STOP

CDDJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETE

STORE/MENU

PHONES

ENGLISH

Controls on the front

CD-Recorder

(1) POWER ON/OFF ...........

turns the CD-Recorder ON and OFF

(2) Standby indicator

(3) Disc tray (Deck1) .......... records CD-R(W) and plays CD

and CD-R(W)

(4) 0 REC (ord)...................

starts recording, finalizing, erasing

(5) 9 STOP .......................... stops/clears a program

(6) 2/; PLAY/PAUSE .......... starts play/interrupts play or re-

cording

(7) CDR ............................... selects CDR display/keys (left

side)

(8) CDR INDICATOR

(9) / OPEN/CLOSE ............ opens/closes disc tray

(11) REC (ord) TYPE ............ selects recording modes

(12) SOURCE ........................ selects external input source

(13) ERASE ........................... selects erasing mode

(14) FINALIZE ....................... selects finalize mode General

General

(10) Q................................ - searches backward

- cursor control in Menu/Prog. re-

view mode

(15) R................................ - searches forward

- cursor control in Menu/Prog. re-

view mode

(16) Display .......................... information screen

(17) DJ MODE ....................... separate play of CD-Recorder

and CD player

(18) STORE/MENU ............... -enters Menu mode

- stores Menu settings

(19) – EASY JOG +............... - previous/next track (Play and

Program mode)

- recording level control (recording)

- selects settings (menu on)

PUSH/ENTER ................ - plays selected tracks

(push) ............................ - selects settings in Menu mode

- programs track numbers

(20) CANCEL/DELETE ......... - deletes tracks from a program

- deletes text in Menu mode

- returns to a higher level in the

(21) PHONES ........................ socket for headphones

unavailable to adjust the volume

CD player

(22) Disc tray (Deck2) .......... plays CD and CD-R(W)

(23) 2/; PLAY/PAUSE .......... starts play/interrupts play

(24) 9 STOP .......................... stops/clears a program

(25) CD INDICATOR

(26) CD .................................. selects CD display/keys

(27) / OPEN/CLOSE ............ opens/closes disc tray

Note:

- When provided on the remote control, you can also use the

corresponding buttons, after selecting the CD-Recorder or

CD Player by pressing

CDR

(73) or

(84).

- Some buttons are only on the remote control.

Connections at the back

(28) ANALOG INPUT ............ connects to the line output of an

amplifier (left and right)

(29)

ANALOG OUTPUT CDR / CD

... connects to the line input of an

amplifier (left and right)

(30) ANALOG OUTPUT CD..

connects CD player deck to the line

input of an amplifier (left and right)

CONTROLS AND CONNECTIONS

(31) DIGITAL INPUT ............. connects to the digital coaxial

output of an external CD player

(32)

DIGITAL OUTPUT CDR / CD

....

connects to the digital coaxial input

of e.g. amplifier or recording device

(33) DIGITAL OUTPUT CD ... connects CD player deck to the

digital coaxial input of e.g. ampli-

fier or recording device

(34) OPTICAL INPUT............ connects to the digital optical

output of an external CD player

(35)

OPTICAL OUTPUT CDR / CD

... connects to the digital optical in-

put of e.g. amplifier or recording

device

(36)

OPTICAL OUTPUT CD

... connects CD player deck to the

digital optical input of e.g. ampli-

fier or recording device

(37)

REMOTE CONTROL OUT

..... connects to a remote control in-

put on the Marantz amplifier

(38)

REMOTE CONTROL IN

.... connects to a remote control out-

put on the Marantz amplifier

(39)

REMOTE CONTROL SWITCH

(40) AC POWER CABLE

DISPLAY indications

(41) REM/REC TIME ............. remaining recording time / re-

cording time

(42) TRACK........................... track number

(43) ............................... balance (lights during balance

adjustment)

(44) TOTAL REM

TRACK TIME ................. total or remaining time of disc or

track

(45) STEP .............................. indicates the number of tracks in

a program

(46) 20 + ................................ disc or program contains more

than 20 tracks

(47) Track Number ............... tracks on a discs or in a program

track in play

(48) PROGRAM .................... flashes during programming/

lights in program mode

(49) RANDOM ALL ............... plays tracks in random order

(50) SCAN ............................. lights up when the first 10 sec-

onds of each track are played.

(51) REPEAT TRACK/ALL ... lights up when a track/ complete

disc (or program) is repeated.

(52) ................................... CD player selected

(53) CD .................................. CD inserted (a pre-recorded CD

or finalized CD-R or CD-RW

disc)

(54) ................. changer mode selected

(55)

(DJ MODE SELECT)

..... DJ mode selected

(56) L/R ................................. record/play level bar. Indicates

the audio signal level.

(57) 1 DUBBING ................... lights during recording from the

internal CD

(58) 2..................................... lights during play

(59) R (W) .............................. unfinalized CD-R(W) disc in-

serted

(60) 0.................................... lights during recording

(61) ;..................................... pause function active

(62) .......................... optical input I selected for exter-

nal recording

(63) .................. analog input selected for external

recording

........................ analog recording

(64) MANUAL........................ lights up when auto track mode is

turned off

ENGLISH

(65) SYNC ............................. automatic or synchronized start

of external recording

(66) ........................ digital input I selected for external

recording

REMOTE CONTROL

Remote control commands

(67) STANDBY ................. switches to Standby/On/Off

(68) TRACK INCR. (ement) .. increases track numbers during

recording

(69) SCAN ............................. plays the first 10 seconds of each

track

(70) REPEAT......................... repeat play(All, program or track)

(71)

Number/alphabet keys 0 - 9 ..

- selects a track by number

- selects character for text input

(72) DISPLAY........................ selects display information/text

(73) CDR ............................... selects CD-Recorder

(74) 2..................................... starts CD-R(W) play

(75) S................................ previous track (Play and Pro-

gram mode)

(76) Q................................ - searches backward

- cursor control in Menu/Prog. re-

view mode

(77) ;.....................................

interrupts CD-R(W) play/record-

ing

(78) MENU/STORE ............... - enters Menu mode

- stores Menu settings

(79) ENTER ........................... - selects settings in Menu mode

- programs track numbers

- starts playback of selected

track

(80) CANCEL/DELETE ......... - deletes tracks from a program

- deletes text in Menu mode

- returns to a higher level in the

(81) R................................ - searches forward

- cursor control in Menu/Prog. re-

view mode

(82) 9..................................... stops CD-R(W) and clears a pro-

gram

(83) T................................ next track (Play and Program

mode)

(84) CD .................................. selects CD player

(85) SCROLL ........................ activates scrolling of text over the

display

(86) PROG. (ram).................. opens/closes program memory

(87) RANDOM ....................... plays CD-R(W) or program in

random order

ENGLISH

INSTALLATION

Digital Coaxial connections

For recording and playing, connect (using the suitable coaxial

cable, available from your supplier) the CD-Recorder to a dig-

ital amplifier or other equipments based on the diagram below:

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER ON/OFF

PLAY/PAUSESTOP

REC CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

OUTPUT INPUT INPUT

OUTPUT

COAXIAL

INPUT CDR/CD CD

456

1For an external recording, connect the cable r between

the DIGITAL INPUT-socket on the CD-Recorder and the

DIGITAL OUTPUT-socket of an external amplifier or CD

player.

2For playback, connect cable t between the DIGITAL CDR/

CD OUTPUT-socket on the CD-Recorder and the DIG-

ITAL INPUT-socket of an amplifier e.g. CD or AUX.

3For DJ-Mode playback (See page 15), connect cable y be-

tween the DIGITAL CD OUTPUT-socket on the CD-Re-

corder and the DIGITAL INPUT-socket of an amplifier e.g.

CD or AUX.

- DJ-Mode playback is the function that the deck 1 and

the deck 2 on this CD-Recorder can play the songs

separately at the same time.

This CD-Recorder can be used to record directly or through a

(pre-) amplifier from any digital or analog audio source.

In addition, the appliance can be used as a regular CD player.

Read how to connect the CD-Recorder based on the possibili-

ties your other audio equipment offers.

Please refer to the operating instructions for your other audio

equipment first.

The following options are available:

- analog connections

- digital coaxial connections

- digital optical connections

Analog connections

For recording and playing, connect (using the enclosed cable

with red and white plugs) the CD-Recorder to an amplifier (pref-

erably the CD-Recorder or TAPE connection) based on the dia-

gram below:

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER ON/OFF

PLAY/PAUSESTOP

REC CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

OUTPUT

INPUT

ANALOG IN/OUT

OUTPUTCD

CDR/CD

1For recording, connect cable q between the ANALOG IN-

PUT-sockets on the CD-Recorder and the CD LINE- or

TAPE OUTPUT-sockets of an amplifier.

2For playback, connect cable w between the ANALOG

CDR/CD OUTPUT-sockets on the CD-Recorder and the

ANALOG INPUT-sockets of an amplifier e.g. TAPE IN, CD

or AUX.

3For DJ-Mode playback (See page 15), connect cable e be-

tween the ANALOG CD OUTPUT-sockets on the CD-Re-

corder and the ANALOG INPUT sockets of an amplifier

e.g. TAPE IN, CD or AUX.

- DJ-Mode playback is the function that the deck 1 and

the deck 2 on this CD-Recorder can play the songs

separately at the same time.

Note:

Never use the PHONE input.

Amplifier 1 Amplifier 2

ENGLISH

INSTALLATION D-BUS CONNECTION

Digital Optical connections

For recording and playing, connect (using the suitable fiber-op-

tic cable, available from your supplier) the CD-Recorder to a

digital amplifier or other equipments based on the diagram be-

low. Before connection the cables, remove the dust caps from

the digital optical connections. We recommend that you save

the caps.

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER ON/OFF

PLAY/PAUSESTOP

REC CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

OUTPUT INPUT INPUT

OPTICAL

INPUT OUTPUT

CDR/CD CD

789

1For external recording, connect a fiber-optic cable u be-

tween the DIGITAL OPTICAL INPUT of the CD-Recorder

and the DIGITAL OPTICAL OUTPUT of an external ampli-

fier or CD player.

2For playback, connect cable i between the OPTICAL CD/

CDR OUTPUT-socket on the CD-Recorder and the DIG-

ITAL OPTICAL INPUT-socket of an amplifier e.g. CD or

AUX.

3For DJ-Mode playback (See page 15), connect a fiber-optic

cable o between the OPTICAL CD OUTPUT-socket on

the CD-Recorder and the DIGITAL OPTICAL INPUT-

socket of an amplifier e.g. CD or AUX.

- DJ-Mode playback is the function that the deck 1 and the

deck 2 on this CD-Recorder can play the songs separately at

the same time.

Note:

For playback, the digital coaxial outputs or analog outputs of

the CD Player and CD-Recorder should be connected to an

amplifier

Remote control cable connections

By connecting DR6050 to the Marantz amplifier using a D-BUS

remote control cable 0, you can operate the operations of

DR6050 from the remote control of the amplifier. Set the re-

mote control selector to ‘EXTERNAL’.

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER ON/OFF

PLAY/PAUSESTOP

REC CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

INTERNALEXTERNAL

CONTROL

REMOTE

OUT

REMOTE

CONTROL

OUT

Note:

When you don’t use the D-BUS connection, ALWAYS set the

remote control selector to ‘INTERNAL’.

Amplifier 1 Amplifier 2

Marantz Amplifier

ENGLISH

USING THE RECORDER

The numbers between parentheses refer to the fold-out.

Inserting discs

1 Press //

OPEN/CLOSE

to open the disc tray.

➔ lights up.

2 Insert a CD, CD-R or CD-RW in the appropriate recess in

the tray, label side up.

3 Press //

OPEN/CLOSE

to close the tray.

➔ lights up, followed by and the dis-

play will show the type of disc you inserted.

•If a CD-R(W) is finalized it will show CD on the display.

•If CD-text is available the TITLE/ARTIST will scroll by.

Note:

-Only Audio CDs will be accepted. If a non-audio disc is

inserted, the display shows .

CD-Recorder deck only

- For recording it is important that the blank disc is completely

free from dust particles or scratches. (see Compact Discs

page 1).

- If you insert a blank or partly-recorded CD-R or unfinalized

CD-RW, the CD-Recorder will calibrate the disc for optimum

recording. During this process the display will first show

and then the number of audio tracks.

Calibration can take up to 25 seconds.

Switching ON and OFF

1 Connect the power cord into the mains.

AC IN

2 Press the

POWER ON/OFF

(1) button on the front of the

CD-Recorder to turn it on or off.

Recordable

ReWritable

OPEN/

POWER

ON/OFF

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

STANDBY

Using the remote control

1 Open the battery compartment cover.

2 Insert 2 batteries (AA, LR-6 or UM-3; as supplied) as

shown.

3 Replace the cover.

Note:

- We recommend you use 2 batteries of the same type and

condition.

- Always point the remote control directly towards the re-

corder and make sure there.

This remote control can switch “STANDBY ON/OFF” but can-

not switch “POWER ON/OFF” the CD-Recorder.

Batteries contain chemical substances, so they should be

disposed of properly.

ENGLISH

RECORDING

The numbers between parentheses refer to the fold-out.

Remarks about recording

You will soon discover how easy it is to make your own CDs.

Nevertheless, it is advisable to use a CD-RW disc for your first

try. We will describe:

- Digital recording (fast or normal recording).

- Recording from external CD player:

- Digital

- Digital (synchronized start with external CD player)

- Analog

•If the disc is a CD-RW and is already finalized you must

unfinalize it first.

•The recording procedure is the same for CD-Rs and CD-

RWs.

•If the disc already contains recordings, the CD-Recorder will

automatically search for the end of the last track, so that re-

cording can start from there.

•There must be at least 7 seconds of recording time left

on the disc, otherwise you will not be able to enter record

standby mode. then lights up.

•If the display indicates , no digital re-

cording can be made of the source material. Recording will

not start.

•The Serial Copy Management System (SCMS) only al-

lows digital recording under specific conditions:

- This means that it is not possible to make a digital copy

from a digital copy.

- Analog recording is always possible !

- The number of recordings from the original is unlimited.

CDR,

DAT

CD CDR,

DAT

CDR,

DAT

CDR,

DAT

CDR,

DAT

CDR,

DAT

CDR,

DAT

CDR,

DAT

Can be recorded.

Cannot be recorded.

O :

X :

•A maximum of 99 tracks can be recorded on a disc. Minimum

allowable track length is 4 seconds.

•Recordings from DAT or DCC players will not always stop

automatically.

Important:

If you want to play the recorded CD-R disc on any regular

CD player, it must first be finalized. (See FINALIZING/

UNFINALIZING.)

Finalized CD-RW discs play only on CD-RW compatible CD

players.

The CD-Recorder records the text memory simultaneously

when using the internal CD-deck. Some discs are prohib-

ited to copy the text memory. If such a disc is copied, no

text memory will be recorded.

Recording modes

Your recorder offers several recording modes.

For recording from internal CD-deck:

- (double speed recording) - fast recording

of a disc or programmed tracks.

- (normal speed recording) - listening to a

recording while making it.

- (double speed recording and auto-finalize) - fast

recording of a disc or programmed tracks. Recording will be

finalized automatically.

Warning:

No more recording possible after finalizing CDR disc!

For recording from external sources:

- (CD-SYNC recording) - to make an au-

tomatic recording of an external source simply by starting the

source.

- (manual start recording) - to start a

manual recording from an external source.

Some remarks on recording:

- During double speed recording, the original recording quality

will be maintained.

- When Auto track is on (default setting), track numbers will

automatically be increased during recording.

- By programming tracks first, a compilation can be recorded.

- If a finalized CD rewritable disc is inserted in the CD-Re-

corder, and will be dis-

played when the

REC TYPE

(11) is pressed. If

PUSH EN-

TER

(19) is pressed, the disc will be unfinalized.

- When you copy a special disc such as HDCD or DTS, you

have to

•set the sampling frequency at 44.1kHz.

•use the digital connection.

•set the digital rec-volume of the CD-Recorder at 0 dB.

- When you copy the tracks from a DAT recorded by different

sampling frequencies, noise might be recorded in the disc.

Please set a sampling frequency for every track in a DAT.

- This CD-Recorder can record about 17 seconds of a pause

time, which decreases the time count just before music start

in a track on the display. If you record a track including more

than 17-seconds-pause time by digital recording, the pause

time will be recorded the different length of time from original.

However, the entire track time will not be changed and be

able to listen to the music as same as original.

Note:

If during recording appears, the track will be

recorded as analog, at normal speed. All other tracks will be

copied normally (at double speed).

Digital Digital

Analog

ENGLISH

eTo start recording press 00

REC

(4).

➔The display shows the real remaining time for the se-

lected recording. High speed recording starts.

lights continuously.

•To check the elapsed recording time, press

DISPLAY

(72).

This can be done during recording.

•Recording will stop automatically.

Note:

Copy prohibited tracks will be copied analog.

is displayed.

rTo stop recording manually, press 99

STOP

(5, 24, 82).

➔ goes out and recording stops.

•If 9

STOP

(5, 24,82) was pressed within 3 seconds after 0

REC

(4), no recording will take place.

•After recording, the display shows for several sec-

onds. The Total time indications can differ slightly. However,

no music information is lost.

Note:

- In this Recording mode, the Pause function is not operative.

Important:

If you want to play the recorded CD-R(W) disc on any regu-

lar CD player, it must first be finalized. (See FINALIZING/

UNFINALIZNG page 13).

There is a chance that the sound will be distorted if the

recording level is set at a value that exceeds 0 dB for dig-

ital sound sources and -12dB for analog sound sources.

The factory settings at the time of shipping are 0 dB for

digital sound sources and -12dB for analog sound

sources.

Finalized CD-RW discs play only on CD-RW compatible CD

players.

RECORDING (FROM INTERNAL CD-DECK)

The numbers between parentheses refer to the fold-out.

MENU/

STORE CANCEL/

DELETE

987

654

321

RANDOMPROG.REPEATSCAN

CDR

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

DISPLAY SPACE SCROLL

FUNCTION

ENTER

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER

ON/OFF

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

STANDBY

er w

Double speed recording

Using internal CD player.

•During double speed recording the sound is not audible.

qMake sure that the recording disc is absolutely free of

scratches and dust particles.

wTo choose the type of recording, press

REC TYPE

(11).

once: to select if you wish to make a

fast recording of a disc or programmed tracks.

three times: to select if you wish to make a

fast recording of a disc or programmed tracks

and to automatically finalize the recording.

Also see ‘FINALIZING CD-R & CD-RW’ discs

on page 17.

The label starts blinking. After 3 seconds

the display shows the remaining CD-R(W) recording

time on the left and total time of source on the right.

(every 2 seconds is displayed.)

Both selection indicators are lit.

•Press

PROG

(86) on the remote control to select one or

more tracks for recording (see PROGRAMMING):

- rotate the

EASY JOG

(19) key to the required track

number, then press

PUSH

ENTER

(19).

or: - directly select the track number via the

10-keypad

(71)

on the remote control, then press

ENTER

(79).

ENGLISH

RECORDING (FROM INTERNAL CD-DECK)

The numbers between parentheses refer to the fold-out.

MENU/

STORE CANCEL/

DELETE

987

654

321

RANDOMPROG.REPEATSCAN

CDR

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

DISPLAY SPACE SCROLL

FUNCTION

ENTER

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER

ON/OFF

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

STANDBY

er w

Note:

Copy prohibited tracks will be copied analog.

is displayed.

rTo stop recording, press 99

STOP

(5, 24, 82).

➔ goes out and recording stops.

•If 9

STOP

(5, 24, 82) was pressed within 3 seconds after 0

REC

(4), no recording will take place.

•After recording, the display shows for several sec-

onds. The Total time indications can differ slightly. However,

no music information is lost.

Note:

In this recording mode, the Pause function is not operative.

Important:

If you want to play the recorded CDR disc on any regular

CD player, it must first be finalized. (See FINALIZING/

UNFINALIZING page 13.)

There is a chance that the sound will be distorted if the

recording level is set at a value that exceeds 0 dB for dig-

ital sound sources and -12dB for analog sound sources.

The factory settings at the time of shipping are 0 dB for

digital sound sources and -12dB for analog sound

sources.

Finalized CD-RW discs play only on CD-RW compatible CD

players.

Normal speed recording

Using the internal CD player.

During the normal speed recording, you can listen to the re-

cording while you are making it.

qMake sure that the recording disc is absolutely free of

scratches and dust particles.

wFor recording, press

REC TYPE

(11) twice.

•The label starts blinking. After 3 seconds the

display shows the remaining CD-R(W) recording time on the

left and total time of source on the right. (every 2 seconds

is displayed) Both selection indicators

are lit.

•Press

PROG

(86) on the remote control to select one or

more tracks for recording (see PROGRAMMING page 21):

- rotate the

EASY JOG

(19) key to the required track

number, then press

PUSH ENTER

(19).

or: - directly select the track number via the

10-keypad

(71)

on the remote control, then press

ENTER

(79).

eTo start recording, press 00

REC

(4).

➔ lights continuously and the selected track

or program is copied at normal speed. The recording

time left will appear.

•To check the elapsed recording time, press

DISPLAY

(72) on

the remote control. This can be done during recording.

•Recording will stop automatically.

ENGLISH

•If message also flashes, the dig-

ital connection is incorrect.

tSet the optimal recording level on the CD-Recorder.

qPlay the source first to set the optimal recording level on

the CD-Recorder.

wRotate the

EASY JOG

(19) key until, on the Record/Play

Level bar, all the blue segments are alight, but the red seg-

ments do not light continuously during the loudest passages.

DIGITAL RECORDING : +6dB ~ –63dB

ANALOG RECORDING : 0dB ~ –63dB

eStop the source.

yTo start recording, press 00

REC

(4) on the CD-Recorder

and immediately start the source (from Stop-mode).

The track number and recording time left appear on the display.

•To record a 3-second silence at the start of a track,

press 2/;

PLAY/PAUSE

(6) on the CD-Recorder be-

fore starting the source.

•To check the elapsed recording time, press

DISPLAY

(72) on the CD-Recorder. (This can also be done dur-

ing the recording.)

uTo stop recording, press 99

STOP

(5, 82) on the CD-Re-

corder.

•If 9

STOP

(5, 82) was pressed within 3 seconds after

REC

(4), no recording will take place.

•To interrupt recording, press 2/;

PLAY/PAUSE

(6) on

the CD-Recorder. Press 0

REC

(4) to resume.

After recording the display will show for sev-

eral seconds.

Important:

If you want to play the recorded CDR disc on any regular

CD player, it must first be finalized. (See FINALIZING/

UNFINALIZING page 13.)

There is a chance that the sound will be distorted if the re-

cording level is set at a value that exceeds 0 dB for digital

sound sources and -12dB for analog sound sources. The

factory settings at the time of shipping are 0 dB for digital

sound sources and -12dB for analog sound sources.

Finalized CD-RW discs play only on CD-RW compatible CD players.

RECORDING (FROM EXTERNAL SOURCE)

The numbers between parentheses refer to the fold-out.

MENU/

STORE CANCEL/

DELETE

987

654

321

CDR

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

DISPLAY SPACE SCROLL

FUNCTION

ENTER

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER

ON/OFF

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

STANDBY

yu t

Manual start recording

Manual recording from external CD player.

qMake sure the disc is absolutely free of scratches and

dust particles.

wConnect the cable from an ertnal CD player to the CD-

Recorder. (see INSTALLATION page 5 and 6.)

ePress

SOURCE

(12) repeatedly until the selected exter-

nal source appears on the display (depending on the

connection used):

➔ , or lights up and

, or appears on

the display.

About Auto Track increment

•When Auto Track is ON (default setting), track numbers

will automatically be increased during recording.

•To switch off the Auto Track function you have to enter

MENU MODE.

If you wish to increase track numbers manually, press

TRACK INCR(ement) on the remote control. For further

instructions see MENU MODE.

ON (AUTO): The track increments are automatically

taken over from the digital source material

or after 2.7 seconds silence during analog

recording.

OFF (MANUAL): Track numbers can be incremented

manually by pressing

TRACK INCR

(68) (ement) on the remote control.

(Minimum track length is 4 sec.)

•Track numbers cannot be changed after recording.

Note:

Auto track works only with Consumer Sources with a digital output

signal according to the IEC 958 (consumer part) audio standard.

rWith the recorder stopped, press

REC TYPE

(11) five

times to enter the Manual Record standby mode.

➔The display shows .

ENGLISH

RECORDING (FROM EXTERNAL SOURCE)

The numbers between parentheses refer to the fold-out.

MENU/

STORE CANCEL/

DELETE

987

654

321

CDR

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

DISPLAY SPACE SCROLL

FUNCTION

ENTER

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER

ON/OFF

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

STANDBY

• To check the elapsed recording time, press

DISPLAY

(72). (This can also be done during recording)

• The recorder stops automatically.

yTo stop recording manually, press 99

STOP

(5) on the

CD-Recorder.

• If 9

STOP

(5) was pressed within 3 seconds after press-

ing

PLAY

on the selected source, no recording will take

place.

• To interrupt recording, press 2/;

PLAY/PAUSE

(6) on

the CD-Recorder.

To resume, press 0

REC

(4) on the CD-Recorder.

After recording the display will show for sev-

eral seconds.

Note:

- Recordings from DAT, DCC or analog sources will only stop

after 20 seconds silence.

- With , recordings from DAT, DCC or

recordings made analogously will stop after 20 seconds si-

lence. With , the auto stop mode is

disabled.

Important:

If you want to play the recorded CD-R disc on any regular

CD player, it must first be finalized. See finalizing discs.

There is a chance that the sound will be distorted if the

recording level is set at a value that exceeds 0 dB for dig-

ital sound sources and -12dB for analog sound sources.

The factory settings at the time of shipping are 0 dB for

digital sound sources and -12dB for analog sound

sources.

Finalized CD-RW discs play only on CD-RW compatible CD

players.

CD-SYNC

Autostart recording from external CD player CD-SYNC.

The CD-SYNC feature enables you to make fast and easy re-

cordings of a CD. Track increments are automatically detected

from the source material. Track increments cannot be added

manually. In analog source material a silence of 2.7 seconds or

more is automatically detected as a track increment.

qMake sure the disc is absolutely free of scratches and

dust particles.

wConnect the cable from an external CD player to the CD-

Recorder. (see INSTALLATION page 5 and 6.)

ePress

SOURCE

(12) repeatedly until the selected

source, appears on the display (depending on the digital

connection used):

➔ , or lights up and

, or appears on the

display.

rWith the CD-Recorder stopped, press

REC TYPE

(11)

four times: if you wish to record a complete disc or pro-

gram.

➔ start to flash and the display shows

• If message also flashes, the digital

connection is incorrect.

tTo start recording, press

PLAY

on the selected source.

➔The CD-Recorder automatically starts to record. The re-

cording time left appears on the display.

• If or blinks, the digital connecetion is incor-

rect.

• If, however, you start the source during a track, CD-

SYNC recording starts at the beginning of the next track

or after 2.7 seconds of silence in analog recordings.

ENGLISH

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER

ON/OFF

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

STOP

STANDBY

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

PLAY/PAUSE

CDR

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

q wq

FINALIZING/UNFINALIZING

The numbers between parentheses refer to the fold-out.

Finalizing CD-R & CD-RW discs

Finalizing is a simple procedure, necessary to:

- be able to play the recorded CD-R(W) disc on a CD

PLAYER.

- avoid further unwanted recordings on a disc.

- avoid erasure of tracks on a CD-RW.

Auto finalizing

Auto finalizing is possible when using the record-

ing function.

Manual finalizing

qMake sure the disc (in the CD-Recorder) is absolutely

free of scratches and dust particles.

wWith the recorder stopped press

FINALIZE

(14).

➔The display shows and

ePress 00

REC

(4).

➔ and the approximate finalization time

appears on the display.

The display counts down through the finalization.

On completion, the total number of tracks and the total

time recorded appears on the display.

For CD-R(W), changes to CD on display.

Finalizing will take at least 2 - 4 minutes.

Note:

During finalization, the CD-Recorder accepts no operating

commands.

Unfializing CD-RW discs

For CD-RW discs only.

If you want to make more recordings (or erasures of tracks) on

a finalized disc you must unfinalize it first. The Table of Con-

tents (TOC) will be removed.

qWith the CD-Recorder stopped, press

REC TYPE

(11) or

ERASE

(13).

➔ and will appear on

the display.

wPress

PUSH ENTER

(19).

➔The disc will now be unfinalized and can be recorded on

again.

Note:

- Unfinalizing will take approximately 1.5 minutes.

- When unfinalizing a CD-RW disc with text on it available, this

text will be transferred to the CD-Recorder memory. It may

occur that the text memory is full. The message

/ will be displayed.

You will now have to erase text, stored for other discs, or

finalize another disc in order to obtain memory space.

ENGLISH

ERASING

The numbers between parentheses refer to the fold-out.

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER

ON/OFF

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

STOP

STANDBY

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

q we

Erasing

For unfinalized CD-RW discs only.

You can erase:

- one or more tracks from the end,

- the entire disc.

Erasing one or more tracks from the end

qPress

ERASE

(13) once.

➔The display shows the number of tracks and their total

playing time. and

lights up.

• If the disc is finalized, CD appears on the display after

inserting a CD-RW in the recorder. The recorder will ask

you to confirm unfinalizing first. Confirm by pressing the

PUSH ENTER

(19) key or

ENTER

(79) on the remote

control.

wSelect the track(s) you wish to erase by turning the

EASY JOG

(19) key to the left and confirm by pressing

this key.

➔The selected track numbers start blinking on the track

bar.

➔The display shows the remaining number of tracks and

the remaining playing time after erasing the selected

track(s).

ePress 00

REC

(4).

➔The display shows the total countdown time and

appears on the display.

➔After the selected track(s) have erased, the display

shows the remaining tracks and their total playing time.

Erasing the entire disc

qPress

ERASE

(13) twice.

➔The display shows the number of tracks and their total

playing time. and

light up.

• If the disc is finalized, CD appears on the display after

inserting a CD-RW in the recorder. The recorder will ask

you to confirm unfinalizing first. Confirm by pressing the

PUSH ENTER

(19) key or

ENTER

(79) on the remote

control.

wPress 00

REC

(4).

➔The display shows the total countdown time and

appears on the display. The complete disc will be

erased.

Erasure of a complete disc may take up to 15 seconds.

ENGLISH

PLAYING

The numbers between parentheses refer to the fold-out.

MENU/

STORE CANCEL/

DELETE

987

654

321

CDR

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

DISPLAY SPACE SCROLL

FUNCTION

ENTER

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER ON/OFF

PLAY/PAUSESTOP

REC CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

STANDBY

e w q

Playing a 2-disc-changer (Changer mode)

Your CD-Recorder is able to play the two decks sequentially.

qSelect Changer mode using the

DJ MODE

(17).

➔ appears on the display and

lights up.

wOn the deck you want to play, press 22

2/;;

;;

;

PLAY/PAUSE

(6, 23) to start CD play.

➔The track number and track time of the track in play ap-

pear on the display.

➔The second disk will not be played back until the first

disk has finished no matter whether playback is run from

deck one or deck two. The playback procedure will be

automatically ended once playback of the second disk

has been completed.

•Press

DISPLAY

(72) once, twice or three times to see:

➔remaining track time, total remaining time, text infor-

mation (see MENU MODE page 18).

•To interrupt play temporarily, press 2/;

PLAY/PAUSE

(6, 23) again.

➔; lights on the display.

•To continue play, press 2/;

PLAY/PAUSE

(6, 23) again.

eTo stop play, press 99

STOP

(5, 24).

➔The number of tracks and the total playing time appear

on the display.

Note:

DISPLAY

(72) button is only on the remote control.

Playing CDs on Deck 1 and/or Deck 2 (DJ mode)

With this double deck it is possible to play the CD-Recorder

deck and/or the CD player deck individually (at the same time).

In this case the extra CD output must also be connected to an

amplifier.

qSelect DJ mode using the

DJ MODE

(17).

➔ appears on the display and lights up.

wOn the deck you want to play, press 22

2/;;

;;

;

PLAY/PAUSE

(6, 23) to start CD play.

➔2 lights up and the track number and track time of the

track in play appear on the display.

•Press

DISPLAY

(72) once, twice or three times to see:

➔remaining track time, total remaining time, text infor-

mation (see MENU MODE page 18).

If you want to see this information about the other

deck, press

CDR

(26) or

(7).

•To interrupt play temporarily, press 2/;

PLAY/PAUSE

(6, 23) again.

➔; lights on the display.

•To continue play, press 2/;

PLAY/PAUSE

(6, 23) again.

eTo stop play, press 99

STOP

(5, 24, 82).

➔The number of tracks and the total playing time appear

on the display.

ENGLISH

PLAYING

The numbers between parentheses refer to the fold-out.

MENU/

STORE CANCEL/

DELETE

987

654

321

REMOTE CONTROLLER

RC6050DR

CDR

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

DISPLAY SPACE SCROLL

FUNCTION

ENTER

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

PLAY/PAUSESTOP

CDR

D RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

wq q

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

PLAY/PAUSESTOP

CDR

ER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

w w qw

EX: Selecting a track when CD play is stopped

qPress 22

2/; ;

; ;

;

PLAY/PAUSE

(6, 23).

wHold down QQ

Q (10, 76) or RR

R (15, 81).

➔The player first searches backwards or forwards at 10

times normal speed with sound at low volume, then

goes to 50 times normal speed with sound muted.

eRelease the button at the desired passage.

➔Play starts at the desired passage.

Note:

During Random, Repeat Track or Programmed play, search is

restricted to within the track being played at the time.

Random play

qPress

RANDOM

(87) before or during CD play to start

play.

➔The tracks on the CD (or program if set) play in random

order.

wPress

RANDOM

(87) again to stop play.

Note:

RANDOM is also cleared if you open the disc tray.

- RANDOM button is only on the remote control.

Repeat play

qPress

REPEAT

(70) one or more times during CD play.

➔When REPEAT TRACK lights up, the current track

plays repeatedly. When REPEAT ALL lights up, the all

tracks or programmed tracks play repeatedly.

wTo return to normal play, press

REPEAT

(70) one or

more times until:

➔The REPEAT label disappears from the display.

Note:

- Repeat is also cleared if you open the disc tray.

REPEAT

(70) button is only on the remote control.

Selecting a track

Selecting a track during play

qOn the DR6050 recorder.

Turn the

EASY JOG

(19) key until the required track

number appears on the display.

➔Play skips to the beginning of the selected track.

wOn the remote control <i>.

Select

CDR

(73) or

(84) and key in the required track

number using the

NUMERICAL

(71) keys. For 2-digit

track numbers, press the keys in rapid succession. For

tracks on the other disc, first press

(84) or

CDR

(73)

as applicable.

➔Play skips to the beginning of the selected track.

eOn the remote control <ii>.

Press SS

S (75) or TT

T (83) one or more times.

➔Play skips to the beginning of the previous or subse-

quent tracks, including tracks on other disc. (Changer

mode only.)

Selecting a track when CD play is stopped

qOn the DR6050 recorder.

qTurn the

EASY JOG

(19) key until the required track

number appears on the display.

wPress

PUSH ENTER

(19) to confirm or press 2/;

PLAY/

PAUSE

(6, 23) to start playing.

wOn the remote control <i>.

qSelect

CDR

(73) or

(84) and key in the required track

number using the

NUMERICAL

(71) keys. For 2-digit

track numbers, press the keys in rapid succession. Play

starts.

eOn the remote control <ii>.

qBriefly press S (75) or T (83) one or more times.

wStart playback by pressing 2 (74) or

ENTER

(79).

Scan play

qTo start scan play, press

SCAN

(69) on the remote con-

trol.

- It plays the first 10 seconds of each track.

- It automatically stops after playing all tracks.

wTo stop playing, press 99

9 (82).

- The SCAN level disappears from the display.

EX: Search

ENGLISH

Programming for recording

qPress

REC TYPE

(11) to select the required recording

mode (see ‘RECORDING’).

wCompile your program as described in “programming

for playback”.

•Only tracks from the disc in the CD player can be stored.

ePress 00

REC

(4) to start recording.

Note:

- To review the program, press

PROG

(86), followed by Q

(10, 76) or R (15, 81) with the CD player or CD-Recorder

in stop mode.

- To add more tracks to the program, repeat steps q to t.

- If you try to store more than 99 tracks, ap-

pears on the display.

PROG

(86) button is only on the remote control.

Clearing a program

qPress 99

STOP

(5, 24, 82) if necessary to stop pro-

grammed play.

wPress 99

STOP

(5, 24, 82) again to clear the program.

➔PROGRAM disappears from the display.

•The program is also cleared if you open the disc tray.

Erasing a track from a program

qIn Stop mode press

PROG

(86) on the remote control to

enter Program mode.

wUse QQ

Q (10, 76) or RR

R (15, 81) to select the track from

which to delete.

➔The track number and program step will be shown on

the display.

ePress

CANCEL/DELETE

(20, 80) to erase the track from

the program.

➔The remaining program steps and the playing time of the

program will be displayed.

PROGRAMMING

The numbers between parentheses refer to the fold-out.

Programmed play

•You can program up to 99 tracks to play in any desired se-

quence.

•Tracks can be programmed more than once.

•A program for playback can be made from both the disc in

the recorder and the disc in the player. A program for record-

ing can only be made from the disc in the player (CD deck).

Programming for playback

qSelect Changer mode or DJ mode using the

DJ MODE

(17).

➔ or appears on the display.

wPress

CDR

(7) or

(26) to select the required deck.

➔Selected key lights up.

ePress

PROG

(86) on the remote control to enter Pro-

gram mode.

➔

PROGRAM flashes and appears on the display.

Select the required track numbers by turning the

EASY

JOG

(19) key left or right and store by pressing

PUSH EN-

TER

(19).

or:

Key in a track number with the

NUMBER

(71). For 2-digit

numbers, press the keys in rapid succession.

➔The track will be stored in the program.

➔The track number, total program time and the number of

programmed tracks (steps) are displayed.

tRepeat step ee

e to rr

r for all tracks to be programmed.

yPress

STOP

(5, 82) or

PROG

(86) on the remote control

to end programming.

➔PROGRAM lights continuously.

uPress 22

2/;;

;;

;

PLAY/PAUSE

(6, 23) to start programmed

play.

ENGLISH

MENU MODE

The numbers between parentheses refer to the fold-out.

Note:

- A maximum of 60 characters can be stored per item.

- With the Q (10, 76) R (15, 81) keys you can move to a

required cursor position.

- With the

CANCEL/DELETE

(20, 80) you can delete a character.

iPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to store the characters and move to the next

cursor position.

oPress

STORE/MENU

(18, 78) to store a name you have

entered and return to the submenu or 9 9

9 9

STOP

(5) to

exit.

Note:

- By pressing the

PUSH ENTER

(19) or

ENTER

(79) on the

remote control without selecting a character first, you can in-

sert a space between characters.

- When an artist’s name has been stored for a certain track,

the name will automatically be copied for the next track. The

name can be confirmed by pressing

STORE/MENU

(18, 78)

or a new name can be entered as described above.

Erasing names

qIn stop mode, select

CDR

(7).

wPress

STORE/MENU

(18, 78) on the deck or the remote

control to enter Menu mode.

eRotate

EASY JOG

(19) to select the submenu TEXT

ERASE.

appears on the display.

rPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to confirm.

tRotate

EASY JOG

(19) to select the required option in

the submenu: All Text, CD Title, CD Artist, Track 1 Title,

Track 1 Artist, etc.

yPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to confirm.

The display will ask you to reconfirm your selection.

uPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to reconfirm.

iPress

STORE/MENU

(18, 78) to return to the submenu

or 9 9

9 9

STOP

(5, 82) to exit.

MENU/

STORE CANCEL/

DELETE

987

654

321

CDR

ABC DEF GHI

JKL MN OPQ

RST UVW XYZ

DISPLAY SPACE SCROLL

FUNCTION

ENTER

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER

ON/OFF

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

PLAY/PAUSESTOP

CD DJ MODE

EASY JOG

PUSH ENTER

CANCEL/DELETESTORE/MENU

PHONES

STANDBY

ert

yui

EX: Storing names of Text settings

MENU MODE can set up:

•Text setting ................. adding erasing the CD text

•Recording setting ....... Auto track increment ON/OFF and

adjustment of the right-left-volume

balance adjustment during the re-

cording

•All settings (except Balance) made in Menu mode will be

stored in the deck’s memory and can be called up and

changed at any time.

Note:

Text can only be edited for unfinalized discs. (finalized CD-RW

discs must be unfinalized first)

Text settings

The TEXT submenus allows you to enter text information on the

CD-R(W); for example the CD titles, the artist names, the track

names and so on. During the playback, the TEXT will be ap-

peared on the display.

Storing names

qIn Stop mode, select

CDR

(7, 73).

wPress

STORE/MENU

(18, 78) on the deck or the remote

control to enter Menu mode.

TEXT EDIT appears on the display.

eRotate

EASY JOG

(19) to select the

submenus.

rPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to confirm.

Rotate

EASY JOG

(19) to select the required option in the

submenu: CD Artist, CD Title, Track 1 Artist, Track 1 Title,

etc.

yPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to confirm.

uSelect the characters by rotating the

EASY JOG

(19) or

by pressing the corresponding numeric/alphabet key

on the remote control.

ENGLISH

MENU MODE

The numbers between parentheses refer to the fold-out.

Text Memory Review/Erase Text Memory

The input text data of the disc is once saved in the text memory

until finalizing the disc. When the text memory is full,

will appear on the display and unable to add

more text data. If you want to add more text data, you have to

finalize the text data for each disc in order to obtain memory

space or erase the entire memory following the operation below.

qIn Stop mode, select

CDR

(7).

wPress

STORE/MENU

(18, 78) on the deck or the remote

control to enter Menu mode.

eRotate

EASY JOG

(19) to select the MEMORY VIEW

submenu.

appears on the display.

rPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to confirm.

tSelect the disc you wish to erase.

yPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to confirm.

appears on the display.

uPress the

PUSH ENTER

(19) or

ENTER

(79) on the re-

mote control to confirm the erasure of the text for that

particular disc.

iPress

STORE/MENU

(18, 78) to return to the submenu

or 9 9

9 9

STOP

(5) to exit.

Note:

- If there are no discs in the memory, the message

appears on the display.

-/ may also appear when

unfinalizing a CD-RW disc for which text was stored (see

‘UNFINALIZING CD-RW discs’ page 13.). The same

action(s) should be taken in order to obtain memory space.

Recording settings

•When Auto Track is ON, track numbers will automatically be

increase during the recording.

•You can adjust the right and left volume balance during the

recording.

Auto track increment

qIn Stop mode, select

CDR

(7).

wPress

STORE/MENU

(18, 78) on the deck or the remote

control to enter Menu mode.

eRotate

EASY JOG

(19) to select the AUTO TRACK

submenu.

appears on the display.

rPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to confirm.

tSelect Auto track or by rotating

EASY JOG

(19).

yPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to confirm.

•When is selected, track numbers will be automati-

cally incremented during recording.

•When is selected, you can number the recorded

tracks yourself. The track number is increased by press-

ing the

TRACK INCR.

(68) on the remote.

uPress

STORE/MENU

(18, 78) to store settings and re-

turn to the submenu or 9 9

9 9

STOP

(5, 82) to exit.

Balance (Only active in Record/Standby mode)

qPress

STORE/MENU

(18, 78) on the deck or the remote

control to enter Menu mode.

wRotate

EASY JOG

(19) to select the SET BALANCE

submenu.

appears on the display.

ePress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to confirm.

➔ and appear on the display.

rAdjust the internal and external recording balance by

turning the

EASY JOG

(19).

tPress

PUSH ENTER

(19) or

ENTER

(79) on the remote

control to confirm.

yPress

STORE/MENU

(18, 78) to store settings.

Note:

The balance setting will not be stored.

ENGLISH

DISPLAY

Messages, as listed and explained here, may appear on the

display for your guidance.

General

......................... reading disc information

................................. during tray opening

............................... during tray closing

......................... no disc inserted, disc unreadable or

disc inserted upside down

................... program full

.............. insert disc or insert disc in correct

way

................. inserted disc is no audio CD

.............. unfinalized CD-R(W) disc

................ indicates the amount of text

memory used for unfinalized discs

Recording

................................. - when 9 STOP is pressed during

recording

- when 9 STOP is pressed during

recording the first 4 seconds of a

track

............................ updating disc contents

.................... no more recording possible

.................... digital coaxial input 1 selected

......................... digital optical input selected

........................... analog input selected

........... no digital recording can be made of

the external source

........... when opening the tray with an

unfinalized disc inserted (in the

CD-Recorder)

.............. High Speed recording selected

................ Listen Speed recording selected

......................... High Speed Recording and Auto Fi-

nalize function selected

........... Synchronised start of recording

from external source selected

.............. Manual start of recording from ex-

ternal source selected

............................ level is being adjusted

........... time left on CD-R(W) disc is not

enough for proposed recording

................. copy prohibited track found during

recording. Track will be copied

analog (Copy Protection Regula-

tions).

.............. when erasing one or more tracks

................. when erasing a disc

.............. when finalizing a disc

.............. when REC is pressed while no dig-

ital source is detected

.............. time countdown when erasing a

track or a disc

................. time countdown when finalizing a

disc

........... to start manual recording, finalizing

or erasing

........... to start synchronised recording

from a source

.................. when trying to record on a finalized

CD-R(W) or a prerecorded CD

................. when trying to record on a

finalized CD-RW

.............. when a professional source is con-

nected

...................... when Text copy is available

........... when Text copy is unavailable

Play

........... CD changer-mode selected

......................... DJ- mode selected when recording

keys are pressed in DJ-mode

......................... program mode selected

.............. will be followed by album title

.............. will be followed by track title

........... will be followed by artist name

........... will be followed by track artist name

...................... when unfinalized CD-R(W) disc is

inserted in CD deck

Others

.............. when the recorder enters a data

track during recording

........... laser power calibration performed

96 times, finalize disc

........... during laser power calibration for

unfinalized discs

........... during disc recovering after power

failure

................... OPC failure during OPC procedure

(OPC = Optimum Power Calibra-

tion)

........... recording error in menu mode

................. when trying to record on or finalize

a recovered disc

.............. when text memory is full. To add a

CD to the list, first finalize or erase

another disc from the list.

ENGLISH

Fixing problems

If you think your CD-Recorder is defective, it is wise to read this

list first. Maybe you forgot a simple step.

Warning!

Under no circumstances should you attempt to repair the

CD-recorder yourself as this will invalidate the guarantee.

No power

•ensure that the

POWER ON/OFF

(1) button is on: the

CD-Recorder is in standby mode, press any button to

activate it

•ensure that the power cord is plugged in correctly

•switch the recorder OFF and then immediately back ON

Auto track does not work

•check if auto track is selected

•check if there are 2.7 seconds silence in between the

tracks (analog recording only)

•check if the source is consumer source with the digital

output according to IEC audio standard

•source is DVD disc (no track information)

No sound

•check the audio connections

•if using an amplifier, try using a different source

Amplifier sound is distorted

•check that the CD-Recorder analog output is not con-

nected to the amplifier PHONE input.

Play will not start

•ensure that the label of the CD is facing up

•clean the disc

•check that the disc is not defective by trying another disc

Remote control does not work

•point the remote control directly at the CD-Recorder

•check the batteries and replace if necessary

•select the right source first

•set the remote control selector to ‘INTERNAL’

Will not record

•clean the disc

•check if CD-R(W) is an unfinalised disc

•check that the disc is recordable and replace if neces-

sary

•the disc is not an audio disc ( )

•wrong input source chosen. Input label flashing

( )

•

text memory full ( / ).

When a CD-RW has to be unfinalised for recording.

Erase text for other disc(s) or finalise other disc(s) to

obtain memory space.

Recording is distorted

•make sure the recording level was not too high

20 second pause between recordings

•see ‘RECORDING (from external source)’ CD SYNC

DISPLAY OTHER INFORMATIONS

Menu messages

...................... when attempting to edit text for a

disc which has no tracks

................... when entering Text Edit mode

.................... when editing or erasing an artist

name

...................... when editing or erasing a title

............... when editing or erasing an artist

name per track

................. when editing or erasing a title per

track

................. when entering Text Erase mode

...................... when entering All Text mode

...................... when confirmation for erasing has

to be given with ENTER key

........... when confirmation for erasing has

to be given with ENTER key

........... when waiting for confirmation when

erasing a disc

.............. when selecting text review per

unfinalized disc in memory

........... when REVIEW is selected while no

text is in memory

............... when selecting auto track incre-

ment ON or OFF

...................................... Auto Track increment on

.................................... Auto Track increment off

.............. when selecting BALANCE

......................... no text stored for disc

ENGLISH

Recordable

ReWritable

SOURCEREC TYPE

OPEN/ CLOSE

OPEN/

ERASE FINALIZE

POWER

ON/OFF

PLAY/PAUSESTOP

REC

CDR

CD RECORDER DR6050

STOP

STANDBY

wqwe w

Player does not react

•use the

POWER ON/OFF

(1) button on the front of the

Player to switch it off and back on

on display

•a power failure has occurred during recording the CD-

Recorder is attempting to repair the disc

•If then appears on the display, the disc

cannot be recorded further, and cannot be finalised. But

it can still be played on the CD-Recorder or another CD-

Recorder.

•on a CD-R(W) disc, the track being recorded is lost, but

further recording and finalisation can still be done

OTHER INFORMATIONS

Diagnostic Program

If the malfunction continues, perform the Diagnostic Program:

1 Switch the recorder off using the

POWER ON/OFF

(1).

2 Simultaneously press the R (18) and Q (16) and switch

the recorder back on using the

POWER ON/OFF

(1).

➔The display will now indicate ‘’.

➔After a few minutes, the message will change to

‘ ’ or ‘ ’.

➔If the message appears, your recorder is defec-

tive and needs to be repaired. Consult your supplier or

call the Marantz Consumer Line to find the nearest serv-

ice centre. The number of the Consumer Line can be

found in the guarantee booklet.

➔If the ‘’ message appears, there is no clear

defect and the malfunction may be a result of misinter-

pretation of the user instructions, an inappropriate disc,

a mechanical defect or an incorrect connection. To

solve this problem, carefully read the user instructions

once again; you can also contact your supplier.

➔If you cannot solve the problem, go to the nearest serv-

ice centre.

3 Switch off the recorder using the

POWER ON/OFF

(1) to

exit from the Diagnostic Program.

ENGLISH

ABOUT TEXT

The input text data is saved in the text memory until the disc is

finalized. Therefore, the data is not written in the CD-R(W) disc

before finalizing the disc.

JAZZ 2 CLASSIC

POPS

JAZZ 2

CLASSIC

Finalizing the disc transfers the text data from the text memory

to the disc.

CLASSIC

POPS

JAZZ 2

Unfinalizing the disc transfers the text data from the disc to the

text memory.

ReWritable

MY BEST

CLASSIC

POPS

When the text memory is full, appears on the

display and you cannot add more text data.

In this case, you need to make more space in text memory. You

can either finalize one or more disc(s) to transfer the text data

to each disc, or erase (part of) the text data in the text memory.

Note:

When the text memory is full depends on the amount of the

input text data per disc and the number of discs.

Typically the text memory can store for 50 discs of the text data

consisting of 60 characters of an artist name or title for 20

tracks.

ENGLISH

TECHNICAL SPECIFICATIONS

GENERAL

System .................................................................................................. Compact disc digital audio

Number of channels ............................................................................... 2 (stereo)

Applicable discs ..................................................................................... CD, CD-R (digital audio), CD-RW (digital audio)

Power Requirement ............................................................................... AC 120 V 60 Hz

Power Consumption .............................................................................. 20W

Operating Temperature ......................................................................... 41 - 95 °F (5 - 35 °C)

Dimension (MAX)

Width ............................................................................................. 17-3/8 inches (440 mm)

Height ............................................................................................ 3-7/16 inches (87 mm)

Depth ............................................................................................. 12-1/2 inches (317 mm)

Weight ........................................................................................... 9.7 lbs (4.4 Kg)

AUDIO

Frequency Response ............................................................................ 20 Hz - 20 kHz

Playback S/N ......................................................................................... 100 dB

Playback Dynamic Range ...................................................................... 96 dB

Playback Total Harmonic Distortion ....................................................... 0.003 %

Recording S/N ....................................................................................... 90 dB

Recording Dynamic Range .................................................................... 92 dB

Recording Total Harmonic Distortion ..................................................... 0.006 %

Digital Coaxial Output ............................................................................ 0.5 V (p-p)/75 Ω

Line Output Voltage ............................................................................... 2 V RMS

Digital Optical Output ............................................................................. - 20 dB

Headphones .......................................................................................... 0 - 5 Vrms/ 8 - 2000 Ω

Recording values for line input

Digital Coaxial Input (automatic sample rate conversion) ....................... 32 - 48 kHz

Digital Optical Input (automatic sample rate conversion)........................ 32 - 48 kHz

Analog Input .......................................................................................... 600 mVrms/ 50 kΩ

Specifications subject to change without prior notice.

is a registered trademark.

Printed in Japan

COUNTRY COMPANY ADDRESS

ALGERIE Azur 2000 8, Lotissement Ben Hatadi, Alger, Algerie

ARMENIA NGYIG Ltd. 47 A/75 St. Lalaiants, 375000 Yerevan, Armenia

AUSTRALIA Jamo Australia Pty. Ltd., 24 Lionel Road, Mt. Waverley, VIC 3149, Australia

AUSTRIA Huber & Prohaska GmbH Taborstraße 95 / Ladestraße 1, Gebäude Hangartner, A-1200 Wien, Austria

BAHREIN Ambassador Stores P.O. Box 237,141, Government Avenue, Manama,Bahrein

BANGLADESH Target 1078, Ramjoy Mohanja Lane Asadgonj, Chittagong 4000, Bangladesh

BELGIUM Van der Heyden Audio N.V. Brusselbaan 278, 9320 Erembodegem, Belgium

BULGARIA Ariescommerce GmbH Makedonia Blvd. 16, 1606 Sofia, Bulgaria

CANADA Lenbrook Industries Limited 633 Granite Court, Pickering, Ontario

CHINA

Guang Chang Audio International Co., Ltd.

No.38 Yushan Road, ShiQiao, Pan Yu, Guang Dong, China

CYPRUS Empire Hifi systems Ltd. P.O. Box 5604, Nicosia, Cyprus

CZECH REPUBLIC Audio International Sokolska 41, 67902 Rajecko, OKR,Blansko, Czech Republic

DENMARK Audio Nord Dali Allé 1, 9610 Noerager, Denmark

DUBAI V.V.& SONS P.O. Box 105, Dubai, U.A.E.

EGYPT Solimco 9, El Attibaa St. Doki, Cairo, Egypt

ESTONIA HiFi Club Estonia Ehte 4, 90503 Haapsalu, Estonia

F.Y.R.O.M. T.P. KODI ul.Cedomir Kantargiev 21a, Skopje, Former Yugoslavian Republic of Macedonija

FINLAND Audio Nord Uudenmaankatu 4-6, Helsinki SF-00120, Finland

FRANCE Marantz France A division of Marantz Europe B.V., P.O. Box 301, 92 156 Suresnes Cedex, France

GERMANY Marantz Deutschland Hakenbusch 3, 49078 Osnabrück, Germany

GREECE Adamco S.A. 188, Hippocratous Street, 11471 Athens, Greece

HEADQUARTERS EUROPE: Marantz Europe B.V. Building SFF-2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands

HONG KONG Marantz Asia Ltd. Unit 1706, Metroplaza II, 223 Hing Fong Road, Kwai Fong, N.T., Kowloon, Hong Kong

HUNGARY Infovox Ltd. Terez Krt.31, 1067 Budapest, Hungary

ICELAND ID Electronics Ltd. Armula 38, 108 Reykjavik, Iceland

INDIA NOVA Audio Private 8,Punam Co-op.Society 29/30 Road#5, Union Park MUMBAI 400052, India

IRAN Home Co. 5th floor no 878 Philips Building Enghelab ave, P.O. 11365/7844 Tehran, Iran

IRELAND Marantz Ireland Clonskeagh, Dublin 14, Ireland

ISRAEL Elmor Ltd. 52 Heh Beiyar Street, Kikar Hamedina, Tel Aviv, Israel

ITALY Marantz Italy Via Casati 23, 20052 Monza (Milano), Italy, Servizio Consumatori 1678-20026, Numero Verde

IVORY COAST Hifivoir B.P. 2428, Abidjan 01, Ivory Coast

JAPAN Marantz Japan Inc. 35-1 Sagami Ohno 7-Chome, Sagamihara-shi, Kanagawa 228-8505, Japan

KOREA Mk Enterprises Ltd. 121-210, 2F Shinhan Bldg., 247-17 Seokyo-dong, Mapo-ku, Seoul, Korea

KUWAIT alAlamiah Electronics Intl. P.O. Box 8196, Salmiah 22052, Kuwait

LATVIA Ace Ltd. 61, LacPlesa Str., Riga LV 1011, Latvia

LEBANON AZ Electronics S.A., 1, P.O. Box 11 2833, Beirut, Lebanon

LITHUANIA Accapella Ltd. Ausros, Vartu G/5, Pasazo SKG., 2001 Vilnius, Lithuania

MALAYSIA Wo Kee Hong Electronics Sdn. Bhd. 102 Jalan SS 21/35, Damansara Utama, 47400 Petaling Jaya, Selangordarul Ehsan, Malaysia

MALTA Doneo Co Ltd. 78 The Strand, Sliema SLM07, Malta

MAURITIUS SKR Electronics Ltd. P.O. Box 685, Bell Village, Port Louis, Mauritius

MILITARY MARKET EUROPE PASCO GmbH PO BOX 1280, Sandhausen 69200, Germany

NETHERLANDS Marantz Domestic Sales

A division of Marantz Europe B.V., Building SFF2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands

NEW ZEALAND Wildash Audio Systems 14 Malvern Road, Mt. Albert, Auckland, New Zealand

NORWAY Audio Nord Sandkerveien 64, Oslo 0483, Norway

OMAN Mustafa & Jawad Trading CO. P.O. Box 1918, Ruwi, Oman

POLAND Philips Polska Sp. z.o.o. Al.Jerozolimskie 195b, 02 222 Warszawa, Poland

PORTUGAL Corel2 Comércio de Electrónica Lda., Av. Luís Bívar, No 85 A, 1050 Lisboa, Portugal

PROFESSIONAL EUROPE Marantz Professional Products Kingsbridge House, Padbury Oaks, 575-583 Bath Road, Longford, Middlesex UB7 0EH, U.K.

PROFESSIONAL U.S.A. Marantz Professional Products Distributed by: Superscope Technologies Inc., 1000 Corporate Blvd. Ste.D, Aurora, Illino

QATAR Almana & Partners W.W.L. P.O. Box 49, Doha, Qatar

REUNION Vision + 180 Rue du Marechal Leclerc, 97400 Saint Denis, Ile de la Reunion

ROMANIA Nova Music Entertainment 5, Zagazului Str. Bl.1G,apt.18, sector 1,Bucharest, Romania

RUSSIA Absolute Audio 7/2, Montazhnaya Street, 107497 Moscow, Russia

SAUDI ARABIA Adawlia Univ. Electr. Apl P.O. Box 2154, Alkhobar 31952, Saudi Arabia

SINGAPORE Forward Marketing (S) Pte. Ltd. Wo Kee Hong Centre, 29 Leng Kee Road, Singapore 159099, Singapore

SLOVAKIA Bis Audio s.r.o. Nam. SNP 10, 96001 Zvolem, Slovakia

SLOVENIA Bofex Smartinska 152, HALA V/3, 61000 Ljubljana, Slovenia

SOUTH AFRICA Coherent Imports (PTY) Ltd. P.O. Box 1614, Alberton, 1450, South Africa

SPAIN Marantz Spain Martinez Villergas 2, Apartado 2065, Madrid 28027, Spain

SRI LANKA The listening Room Mezzanine Floor, The Landmark 385, Galle Road, Colombo - 3, Sri Lanka

SWEDEN Audio Nord Almedalsvagen 4, Gotenborg 402-23, Sweden

SWITZERLAND Sound Company AG Postfach, 8010 Zürich, Switzerland

SYRIA Hamzeh & Partners Hafez Ibrahim Str. No 117, Damascus Shalan, Syria

TAHITI Covecolor Av. Prince Hinoi, Cours de l'union sacré, P.O. Box 2334, Papeete, Tahiti

TAIWAN Pai-Yuing Co. Ltd. 6th No 148 Sung Kiang Road, Taipei 10429, Taiwan R.O.C.

THAILAND MRZ Standard Co. Ltd. 746-750 Mahachai Road, Wangburapa, Bangkok 10200, Thailand

TUNESIA Societe EDEVIG 40, Avenue du Golfe Arabe, El Menzah, 1004, Tunesia

TURKEY Türk Philips Ticaret A.S. Yukari Dudullu Organize sanayi Bolgesi, 2.Cadde no.28, 81260 Umraniye-Istanbul, Turkey

U.K. Marantz Hifi UK Ltd. Kingsbridge House, Padbury Oaks, 575-583 Bath Road, Longford, Middlesex UB7 0EH, U.K.

U.S.A. Marantz America Inc. 440 Medinah Road, Roselle, IL 60172, U.S.A.

YUGOSLAVIA ITM Company Omladinskih Brigada 86, 11070 Belgrade, Yugoslavia

EXPORT Marantz Domestic Sales

A division of Marantz Europe BV,Building SFF2, P.O. Box 80002, 5600 JB Eindhoven, TheThe Netherlands

www.marantz.com

00/07 MIT 386K851250

Marantz Dr6050 Users Manual DR6050U Cover 1 4

DR6050 c_dr6050_man

DR6050 to the manual 2af7c0f7-603f-43f7-860e-90bfd6246d8a

Navigation menu

Versions of this User Manual:

Views

Navigation
