Model PD6120D User Guide

Plasma Monitor

Precautions

Please read this manual carefully before using your Marantz

plasma monitor and keep the manual handy for future

reference.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER. NO

USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

This symbol warns the user that uninsulated

voltage within the unit may have sufficient

magnitude to cause electric shock.

Therefore, it is dangerous to make any kind

of contact with any part inside of this unit.

This symbol alerts the user that important

literature concerning the operation and

maintenance of this unit has been included.

Therefore, it should be read carefully in

order to avoid any problems.

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE

THIS UNIT TO RAIN OR MOISTURE. ALSO DO NOT USE

THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD

RECEPTACLE OR OTHER OUTLETS, UNLESS THE

PRONGS CAN BE FULLY INSERTED. REFRAIN FROM

OPENING THE CABINET AS THERE ARE HIGH-VOLTAGE

COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

WARNING

This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when

the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct

the interference at his own expense.

Important Information

Warnings and Safety Precaution

The Marantz plasma monitor is designed and

manufactured to provide long, trouble-free service.

No maintenance other than cleaning is required. Use

a soft dry cloth to clean the panel. Never use

solvents such as alcohol or thinner to clean the panel

surface.

The plasma display panel consists of fine picture

elements (cells). Although Marantz produces the

plasma display panels with more than 99.99 percent

active cells, there may be some cells that do not

produce light or remain lit.

For operating safety and to avoid damage to the unit,

read carefully and observe the following instructions.

To avoid shock and fire hazards:

1. Provide adequate space for ventilation to avoid internal

heat build-up. Do not cover rear vents or install the unit

in a closed cabinet or shelves.

The unit is equipped with cooling fans. If you install

the unit in an enclosure, make sure there is adequate

space at the top of the unit to allow hot air to rise and

escape. If the monitor becomes too hot, the overheat

protector will be activated and the monitor will be turned

off. If this happens, turn off the power to the monitor and

unplug the power cord. If the room where the monitor is

installed is particularly hot, move the monitor to a cooler

location, and wait for the monitor to cool for 60 minutes.

If the problem persists, contact your Marantz dealer for

service.

2. Do not use the power cord polarized plug with extension

cords or outlets unless the prongs can be completely

inserted.

3. Do not expose the unit to water or moisture.

4. Avoid damage to the power cord, and do not attempt to

modify the power cord.

5. Unplug the unit during electrical storms or if the unit

will not be used over a long period.

6. Do not open the cabinet which has potentially dangerous

high voltage components inside. If the unit is damaged in

this way the warranty will be void. Moreover, there is a

serious risk of electric shock.

7. Do not attempt to service or repair the unit. Marantz is

not liable for any bodily harm or damage caused if

unqualified persons attempt service or open the back

cover. Refer all service to authorized Marantz Service

Centers.

NOTE:

When you connect a computer to this monitor, attach

the supplied ferrite cores. If you do not do this, this

monitor will not comform to mandatory FCC standards.

Attaching the ferrite cores:

Set the ferrite cores on both ends of the DVI cable (not

supplied), and both ends of the power cable (supplied).

Close the lid tightly until the clamps click.

Use the band to fasten the ferrite core (supplied) to the

DVI cable.

DVI cable (not supplied)

core (small) core (small)

Connector

band band

Power cable (supplied) core (large)

core (large)

To avoid damage and prolong operating life:

1. Use only with 120V 50/60Hz AC power supply.

Continued operation at line voltages greater than 120 Volts

AC will shorten the life of the unit, and might even cause

a fire hazard.

2. Handle the unit carefully when installing it and do not

drop.

3. Set the unit away from heat, excessive dust, and direct

sunlight.

4. Protect the inside of the unit from liquids and small

metal objects. In case of accident, unplug the unit and

have it serviced by an authorized Marantz Service

Center.

5. Do not hit or scratch the panel surface as this causes

flaws on the surface of the screen.

6. For correct installation and mounting it is strongly

recommended to use a trained,authorized Marantz dealer.

7. As is the case with any phosphor-based display (like a

CRT monitor, for example) light output will gradually

decrease over the life of a Plasma Display Panel.

Recommendations to avoid or minimize phosphor burn-in

Like all phosphor-based display devices and all other gas

plasma displays, plasma monitors can be susceptible to

phosphor burn under certain circumstances. Certain

operating conditions, such as the continuous display of a

static image over a prolonged period of time, can result in

phosphor burn if proper precautions are not taken. To protect

your investment in this Marantz plasma monitor, please

adhere to the following guidelines and recommendations

for minimizing the occurrence of image burn:

* Always enable and use your computer’s screen saver

function during use with a computer input source.

* Display a moving image whenever possible.

* Change the position of the menu display from time to time.

* Always power down the monitor when you are finished

using it.

If the plasma monitor is in long term use or continuous

operation take the following measures to reduce the

likelihood of phosphor burn:

* Lower the Brightness and Contrast levels as much as

possible without impairing image readability.

* Display an image with many colors and color gradations

(i.e. photographic or photo-realistic images).

* Create image content with minimal contrast between light

and dark areas, for example white characters on black

backgrounds. Use complementary or pastel color whenever

possible.

* Avoid displaying images with few colors and distinct,

sharply defined borders between colors.

Contact Marantz Service Center at 1-800-270-4533 for other

recommended procedures that will best suit your particular

application needs.

Précautions

Veuillez lire ce manuel avec attention avant d’utiliser votre

moniteur Plasma Monitor Marantz et conserver ce manuel à

portée de la main pour une consultation ultérieure.

ATTENTION

RISQUE D’ELECTROCUTION

NE PAS OUVRIR

MISE EN GARDE

AFIN DE REDUIRE LES RISQUES D’ELECTRO-

CUTION, NE PAS DEPOSER LE COUVERCLE, IL N’Y

A AUCUNE PIECE UTILISABLE A L’INTERIEUR DE

CET APPAREIL. NE CONFIER LES TRAVAUX

D’ENTRETIEN QU’A UN PERSONNEL QUALIFIE.

Ce symbole a pour but de prévenir l’utilisateur de la

présence d’une tension dangereuse, non isolée se trouvant

à l’intérieur de l’appareil. Elle est d’une intensité suffisante

pour constituer un risque d’électrocution. Eviter le contact

avec les pièces à l’intérieur de cet appareil.

Ce symbole a pour but de prévenir l’utilisateur de la

présence d’importantes instructions concernant l’entretien

et le fonctionnement de cet appareil. Par conséquent, elles

doivent être lues attentivement afin d’éviter des problèmes.

AVERTISSEMENT

AFIN DE REDUIRE LES RISQUES D’INCENDIE OU

D’ELECTROCUTION, NE PAS EXPOSER CET APPAREIL

A LA PLUIE OU A L’HUMIDITE. AUSSI, NE PAS UTILISER

LA FICHE POLARISEE AVEC UN PROLONGATEUR OU

UNE AUTRE PRISE DE COURANT SAUF SI CES LAMES

PEUVENT ETRE INSEREES A FOND. NE PAS OUVRIR

LE COFFRET, DES COMPOSANTS HAUTE TENSION SE

TROUVENT A L’INTERIEUR. LAISSER A UN

PERSONNEL QUALIFIE LE SOIN DE REPARER CET

APPAREIL.

DOC avis de conformation

Cet appareil numérigue de la classe A respecte toutes les exigences

du Réglement sur le Matériel Brouilleur du Canada.

Mises en garde et précautions de

sécurité

Le moniteur Plasma Marantz a été conçu et fabriqué

pour une utilisation fiable et durable. Il ne nécessite

aucun entretien en dehors du nettoyage. Utiliser un

chiffon doux et sec pour nettoyer la surface de l’écran.

Ne jamais utiliser de solvant comme l’alcool ou le

diluant. Le panneau à affichage plasma est constitué

de fines particules d’images ou pixels (cellules). Bien

que Marantz produise des panneaux à affichage

plasma avec plus de 99,99 % de cellules actives, il

peut y avoir des cellules qui ne produisent pas de

lumière ou qui restent allumées.

Pour des raisons de sécurité et pour éviter

d’endommager l’appareil, lire attentivement les

instructions suivantes.

Pour éviter les risques d’éléctrocution et d’incendie:

1. Laisser suffisament d’espace autour de l’appareil pour

la ventilation et éviter toute augmentation excessive de

la température interne. Ne pas couvrir les évents ou

l’installer dans un endroit trop exigu.

L’appareil est équipé de ventilateurs de refroidissement.

Si vous installez l’appareil dans un espace clos,

assurezvous qu’il y ait suffisamment d’espace au dessus

pour permettre à l’air chaud de s’élever et de s’évacuer.

Si la température du moniteur devient excessive, la

protection contre les surchauffes entrera en action et

coupera l’alimentation. Dans ce cas, éteindre l’appareil

et débrancher le câble d’alimentation. Si la température

de la pièce dans laquelle le moniteur est installé est

particulièrement excessive, déplacer l’appareil dans un

endroit plus frais et le laisser refroidir 60 minutes. Si le

problème persiste, prendre contact avec le revendeur

Marantz pour le service après-vente.

2. Ne pas utiliser la fiche polarisée du cordon d’alimentation

avec des prolongateurs ou des prises de courant, sauf si

les lames peuvent être insérées à fond.

3. Ne pas exposer à L’eau ou à l’humidité.

4. Eviter d’endommager le cordon d’alimentation, et ne pas

modifier le cordon d’alimentation.

5. Débrancher l’appareil pendant les tempêtes ou si

l’appareil n’est pas utilisé pendant une longue période.

6. Ne pas ouvrir le coffret. Des composants de haute

tension se trouvent à l’intérieur. Si l’appareil est

endommagé de cette manière, la garantie devient

caduque. De plus, il y a risque d’électrocution.

7. Ne pas essayer de réparer ou entretenir l’appareil

soimême. Marantz ne saura être tenu pour responsable

pour toute blessure ou dommage causé par des

personnes non qualifiées qui essayent de réparer ou

d’ouvrir le couvercle arrière. Confier toute réparation

à un centre de service agréé Marantz.

REMARQUE:

Lorsque vous branchez un micro-ordinateur sur ce

moniteur, fixez les noyaux en ferrites fournis. Si vous

ne le faîtes, le moniteur ne sera pas en conformité avec

les exigences des standards FCC.

Fixation des noyaux en ferrite.

Monter les tores en ferrite aux deux extrêmités du câble

DVI (non fourni) et aux deux extrêmités du câble

d’alimentation électrique (fourni).

Fermez doucement le couvercle jusqu’à ce que les crans

se clipsent.

Fixer le tore en ferrite (fourni) au câble DVI à l’aide d’un

collier.

Câble DVI (non fourni) Connecteur

noyau (petit) noyau (petit)

Collier Collier

noyau (large)

Câble d'alimentation

électrique (fourni)

noyau (large)

Pour éviter des dommages et prolonger la durée de

service de l’appareil:

1. N’utiliser qu’une source d’alimentation de 120 V 50/

60 Hz CA. Le fait d’utiliser l’appareil en continu à des

tensions de ligne supérieures à 120 Volts CA réduit sa

durée de vie et risque de provoquer un incendie.

2. Manipuler l’appareil avec soin pendant son

déplacement et ne pas le faire tomber.

3. Eloigner l’appareil des endroits chauds, très poussiéreux

et exposés en plein soleil.

4. Eviter que des liquides et des petits objets métalliques

pénètrent à l’intérieur de l’appareil. En cas d’accident,

débrancher l’appareil et le confier à un centre de service

agréé Marantz.

5. Ne pas frapper ou rayer la surface de la écran plasma,

car des défauts risquent de se produire sur la surface

de la écran plasma.

6. Pour effectuer une installation et un montage corrects,

il est recommandé de faire appel au concessionnaire

Marantz autorisé et spécialisé.

7. Comme c’est le cas pour tout affichage à base de

phosphore (comme un moniteur CRT, par exemple), la

puissance de lumière baisse graduellement au cours de

la vie du Panneau d’Affichage à Plasma.

Pour éviter le risque de combustion au phosphore, les

mesures suivantes sont recommandées :

Comme tous les appareils d’affichage à base de phosphore

et tous les autres affichages à gaz plasma, les moniteurs

Plasma peuvent être sujets à la combustion au phosphore

dans certaines circonsatnces. Certaines conditions

d’utilisation, telles que l’affichage continu d’une image

statique pour une durée prolongée, peuvent causer des

brûlures au phophore si aucune précaution n’est prise. Pour

protéger votre investissement dans ce moniteur Plasma

Marantz, veuillez suivre les directives et les recommandations

suivantes pour minimiser l’occurence de brûlure d’image :

• Assurez-vous de mettre en marche et d’utliser

l’économisateur d’écran chaque fois que c’est possible

lorsque vous l’utilisez avec une source d’entrée

d’ordinateur.

•Affichez une image en mouvement aussi souvent que

possible.

•Changer la position de l’affichage de menu de temps à autre.

•Coupez toujours l’alimentation lorsque vous avez terminé

d’utiliser la moniteur.

Si le moniteur est en usage continu ou longue durée, prenez

les mesures suivantes afin d’éviter l’occurence de

combustion au phosphore :

•Abaissez le niveau de l’image (contraste, luminosité)

autant que possible, sans faire perdre la lisibilité de

l’image.

•Affichez une image avec de nombreuses couleurs et

graduations de couleur (par ex. des images

photographiques ou photo-réalistes).

•Créez un contenu d’image avec un contraste minimal

entre les zones sombres et les zones claires, par exemple,

des caractères blancs sur un fond noir. Utilisez des

couleurs complémentaires ou pastels le plus souvent

possible.

•Évitez d’afficher des images avec peu de couleurs et des

limites nettes et clairement définies entre les couleurs.

Contactez Marantz Service Center au 1-800-270-4533 pour

d’autres procédures recommandées qui conviendront le

mieux au besoin de votre appareil.

Limited Warranty for the Marantz SLIM SERIES PLASMA MONITOR

Who is covered?

You must have proof of purchase to receive warranty service.

What is covered?

1) Warranty coverage begins the day you purchase your

Plasma Television, and continues for a period of one year.

2) Marantz America will provide in-home warranty repair.

3) Marantz America will incur all labor charges for repairs

during the warranty period.

4) Marantz America will incur all freight charges for

warranty repairs, both to Marantz and the return to the

customer.

We suggest keeping all packing materials for any

shipping that might be required.

5) All parts, including repaired and replaced parts are

covered only for the original warranty period.

When the warranty on the product expires, the warranty on

all replaced and repaired parts also expires.

What is excluded?

Your warranty does not cover:

1) Labor charges for installation or setup of the product,

cleaning, adjustment of customer controls on the product,

and installation or repair of antenna systems outside of

the product.

2) Improper installation, removal or maintenance, or failure

to follow instructions supplied with the product.

3) Reception problems caused by signal conditions from

cable or antenna systems outside the product.

4) Repair, attempted repair or modification performed by

anyone other than an authorized Marantz America service

center.

5) Any product, on which the serial number has been

defaced, modified or removed.

6) Warranty is void if purchase was made from anyone other

than an authorized Marantz dealer.

7) Warranty is void if purchased from outside The United

States of America.

8) Warranty only valid in the United States of America.

9) Damage due to lightning or power line surges, spikes

and brown outs, damages that occur during shipping or

transit, or damage which is attributed to acts of God.

10) Incidental or consequential damages resulting from the

product. (Some states do not allow the exclusion of

incidental or consequential damages, so the above ex-

clusion may not apply to you. This warranty gives you

specific legal rights, and you may also have other rights

that vary from state to state.)

11) Commercial or institutional use.

12) Any other cause which does not relate to product defect.

13) Burns or residual images upon the phosphor of the tubes.

Note: Pixel defect

Plasma is one of the most advanced technologies for

consumer products. The panel is made by high precision

technology, however some pixel defects may be found on the

Plasma display panel. We are trying our best to control the

quality in order to reduce the number of defective pixels. It is

almost impossible to have zero pixel defects, even using the

most advanced technology. This is not a problem only for

Marantz, but all Plasma manufacturers. Therefore we have

to note that the warranty does not cover the Plasma display

panel for pixel defects. We appreciate your understanding.

Before requesting service:

Please check your owner's manual before requesting service.

Adjustments of the controls and hook up guidelines discussed

there may save you a service call.

To get warranty service:

Repair must be performed by an authorized service center.

If you do not know of a Marantz authorized Plasma Television

service center, contact your dealer. If your dealer is an

authorized service center, they will arrange for repair.

If your dealer is not a Marantz authorized Plasma Television

service center, they will direct you to an authorized service

center. You can also call 1-800-270-4533 for an authorized

Marantz service center in your area.

Optimum performance:

For optimum performance and picture quality, the Plasma

monitor is only guaranteed up to 6,230 feet above see level.

Marantz America, Inc.

1100 Maplewood Drive

Itasca, IL 60143

Tel. 630-741-0300 Fax. 630-741-0301

How to Attach Options to the Plasma Monitor .... 1

Introduction ..................................................... 2

Introduction to the Plasma Monitor ............................. 2

The features you’ll enjoy include:............................... 2

Contents of the Package ........................................... 2

Options .................................................................. 2

Part Names and Function .................................. 3

Front View............................................................... 3

Rear View / Terminal Board ...................................... 4

Remote Control ........................................................ 5

Battery Installation and Replacement .......................... 6

Operating Range ..................................................... 7

Handling the remote control ...................................... 7

Installation ...................................................... 8

Connecting Your PC or Macintosh Computer ............... 9

Connections with Equipment that has a Digital Interface ...

Connecting Your Document Camera ........................... 9

Connecting Your VCR or Laser Disc Player.................. 9

Connecting Your DVD Player ..................................... 9

External Speaker Connections.................................. 10

Pin Assignments and Signal Levels

for 15 pin RGB (Analog) ......................................... 11

Pin Configuration and Signal

of the RGB 3 IN Connector (DVI Connector) .............. 11

Basic Operations ............................................. 12

POWER ................................................................ 12

To turn the unit ON and OFF: .................................... 12

VOLUME .............................................................. 12

To adjust the volume: ................................................ 12

MUTE ................................................................... 12

To cancel the sound:.................................................. 12

DISPLAY ................................................................ 12

To check the settings: ................................................. 12

DIGITAL ZOOM ..................................................... 12

AUTO ADJUST ...................................................... 12

To adjust the size or quality of the picture

automatically: ............................................................ 12

OFF TIMER ........................................................... 13

To set the off timer: ................................................... 13

To check the remaining time: ..................................... 13

To cancel the off timer ............................................... 13

WIDE Operations ............................................. 14

Watching with a wide screen (manual) .................... 14

When watching videos or digital video discs............. 14

When watching high definition video source ............. 14

Watching computer images with a wide screen ......... 15

When “PICTURE SIZE” is set to “OFF”................... 15

MULTI SCREEN Operations ............................... 16

Showing a couple of pictures on the screen

at the same time ................................................... 16

Selecting the input signals to be displayed ................. 16

Adjusting the OSM controls...................................... 16

OSM Controls ................................................. 17

Menu Operations ................................................... 17

Picture Settings Menu ............................................. 19

Adjusting the picture ................................................. 19

Setting the picture mode according to the

brightness of the room ............................................... 20

Setting the color temperature .................................... 21

Adjusting the color to the desired quality ................... 22

Reducing noise in the picture ..................................... 23

Sound Settings Menu .............................................. 24

Adjusting the treble, bass and left/right balance ........ 24

Screen Settings Menu ............................................. 25

Adjusting the Position, Size, Fine Picture,

Picture Adj ................................................................ 25

Function Settings Menu .......................................... 26

Setting the on-screen menu ....................................... 26

Adjusting the position of the menu display ................ 27

Setting the power management for computer images . 28

POWER/STANDBY indicator ................................... 29

Setting the gray level for the sides of the screen ......... 30

Setting the picture to suit the movie ........................... 30

Setting RGB3 ADJ. .................................................... 31

Reducing burn-in of the screen................................... 31

Resetting to the default values .................................... 32

Option Settings Menu ............................................. 33

Setting the allocation of the audio connectors ........... 33

Setting the BNC connectors ...................................... 33

Setting a computer image to the correct RGB

select screen ............................................................. 34

Setting high definition images to the suitable

screen size ............................................................... 35

Setting the picture size for RGB input signals ............ 36

Information Menu ................................................. 36

Checking the frequencies, polarities of input signals,

and resolution ........................................................... 36

Setting the language for the menus............................. 37

Setting the video signal format .................................. 37

External Control ............................................. 39

Table of Signals Supported .............................. 47

Supported resolution .............................................. 47

Troubleshooting ............................................. 49

Specifications ................................................. 50

Contents

(2")

1580

(62.2")

990

(39.0")

(2")

(2") 50

(2")

Wall

(2")

You can attach your optional mounts or stand to the plasma

monitor in the following way:

* Unpack the plasma monitor. (See Drawing A.)

* Take it out, put your hand in the handy-grip recess at the

rear, and move it to an appropriate place. Then attach the

optional mounts or stand. (See Drawing B.)

• This device cannot be installed on its own.

Be sure to use a stand or original mounting

unit. (Wall mount unit, Stand, etc.)

* See page 2.

• For correct installation and mounting it is

strongly recommended to use a trained,

authorized Marantz dealer.

Failure to follow correct mounting

procedures could result in damage to the

equipment or injury to the installer.

Product warranty does not cover damage

caused by improper installation.

Ventilation Requirements for

enclosure mounting

To allow heat to disperse, leave space between

surrounding objects as shown on the diagram

below when installing.

How to Attach Options to the Plasma Monitor

Drawing A

Drawing B

Introduction to the Plasma Monitor

The Plasma Monitor is a seamless blend of cutting-edge

visual technology and sophisticated design. At 61-inches,

with a 16:9 aspect ratio, the Plasma Monitor certainly

makes a big impression. However, at a mere 4.7 inches/

119 mm thin, the monitor’s sleek techno-art lines blend in

well with your environment. The Plasma Monitor’s crisp,

vivid image quality will transform data from any graphic

medium from PCs to DVD players- into art. And weighing

only 134.5 lbs/ 61 kg, it actually can be hung almost

anywhere. Marantz has made sure that a host of multimedia

resources can be easily connected and displayed as

brilliantly as intended on the Plasma Monitor.

The features you’ll enjoy include:

• 61-inch screen

• 16:9 aspect ratio

• Capsulated Color Filter (CCF) and black matrix

• The enhanced display in red uses a two-stage filtering

system where Accucrimson™ is combined with our

special CCF.

• 4.7 inch / 119 mm thin

• 134.5 lbs/ 61 kg light

• High-resolution screen: 1365768 pixels

• 160-degrees of off-axis viewing, horizontally and

vertically.

• Flicker - and warp - free display provides excellent

image geometry even in screen corners

• Not affected by magnetic fields, no color drift or edge

distortion.

• VGA, SVGA, XGA, SXGA, computer signal

compatibility

• NTSC, PAL, SECAM, composite and S-Video signal

compatibility

• 480P, 1080I, 720P and HDTV signal compatibility

• PCs, VCRs, Laser Disc and DVD player source

compatibility

• AccuBlend™ scan conversion automatically converts

VGA, SVGA and SXGA signals to the panel’s native

resolution

• Advanced Mass Area Sampling Progressive Scan

method is employed.

• RGB input (3*), Video input (3), DVD/HD input (2*),

Audio input (3), External Control input (1)

• AccuColor control system provides user selectable on-

screen color temperature settings

• New Drive Technology

• Component video input terminal for DVD, 15.75kHz

(Y, CB, CR )

• Digital broadcasting source compatibitly

• Marantz OSD menu-driven on screen control system that

makes image adjustments a snap

• Seven languages (English, German, French, Italian,

Spanish, Swedish, and Japanese)

• A handy-grip recess is provided to facilitate installation

and movement.

* You can select RGB source or Component source for

the 5BNC terminal. When selecting an RGB input, the

source is switched to the RGB input (3); when selecting

a component input, the source is switched to the DVD/

HD input (2).

Contents of the Package

 SLIM SERIES Plasma Monitor

 Power cord

 Remote control with two AAA Batteries

 User’s manual

 Safety metal fittings*

 Ferrite core (small2, large2), band

* These are fittings for fastening the unit to a wall to prevent

tipping due to external shock when using the stand (option).

Screw the safety fittings to the holes in the back of the

monitor.

Options

• Wall mount unit

• Tabletop stand

Introduction

Front View

tPower

Turns the monitor’s power on and off.

yPOWER/STANDBY indicator

When the power is on ............................. Lights green.

When the power is in the standby mode ... Lights red.

uRemote sensor window

Receives the signals from the remote control.

Part Names and Function

POWER/STANDBY

PROCEED

INPUT SELECT

DOWN UP LEFT/

RIGHT/+/EXIT

VOLUME

POWER/STANDBY

PROCEED

INPUT SELECT

DOWN UP LEFT/

RIGHT/+/EXIT

VOLUME

qPROCEED

Sets the On-Screen Menu (OSM) mode and displays

the main menu.

wVOLUME DOWN and UP

Adjusts the volume. Functions as the CURSOR (▲/

▼) buttons in the On-Screen Menu (OSM) mode.

eLEFT/– and RIGHT/+

Enlarges or reduces the image. Functions as the

CURSOR ( / ) buttons in the On-Screen Menu

(OSM) mode.

rINPUT SELECT / EXIT

Switches the input, in the following order:

→ VIDEO1 → VIDEO2 → VIDEO3→ DVD/HD

RGB/PC3 ← RGB/PC2 ← RGB/PC1←

Functions as the EXIT buttons in the On-Screen Menu

(OSM) mode.

Rear View/ Terminal Board

AAC IN

Connect the included power cord here.

BEXT SPEAKER L and R

Connect speakers here. Maintain the correct polarity.

CEXTERNAL CONTROL

This terminal is used when power ON/OFF, input

selection and AUDIO MUTE and other controls are

operated externally (by external control). See also page

39 for external control.

DREMOTE CONTROL

Connect the remote cable here.

ECONTROL LOCK

When “CONTROL LOCK” is set “ON”, the buttons

on the set’s control panel do not function.

FVIDEO1, 2, 3

Connect VCR’s, DVD’s or Laser Discs, etc. here.

GAUDIO1, AUDIO2, AUDIO3

These are audio input terminals.

The input is selectable. Set which video image to allot

them to on the menu screen.

HDVD1 / HD1

Connect DVD’s, High Definition or Laser Discs, etc.

here.

IRGB1

Inputs the analog RGB signal of personal computer,

etc.

JRGB2/ DVD2/ HD2

RGB2: Inputs the analog RGB signal.

DVD2/ HD2: Connect DVD’s, High Definition or

Laser Discs, etc. here.

KRGB3 (DVI 29pin)

Inputs a digital RGB signal (TMDS).

LHandy-Grip recess

Use the recesses (as shown) when you need to carry

the display.

EXTERNAL

CONTROL

REMOTE

CONTROL

LOCK

ON/ OFF

SPEAKERS MUST HAVE

MORE THAN 7WATT RATING

IMPEDANCE 6 OHM

RIGHT LEFT

AC IN

RGB 3

(Digital RGB)

RGB 1

R/CR/PR

L(MONO)

VIDEO 1

G/Y

VIDEO 2

VIDEO 3

CB/PB

L(MONO)

CR/PR

B/CB/PB

AUDIO 2 DVD1 /HD1AUDIO 3 AUDIO 1RGB2/DVD2 / HD2

RGB 3

(Digital RGB)

RGB 1

R/CR/PR

L(MONO)

VIDEO 1

G/Y

VIDEO 2

VIDEO 3

CB/PB

L(MONO)

CR/PR

B/CB/PB

AUDIO 2 DVD1 / HD1AUDIO 3 AUDIO 1RGB2 / DVD2 / HD2

SPEAKERS MUST HAVE

MORE THAN 7WATT RATING

IMPEDANCE 6 OHM

RIGHT LEFT

BCDE

EXTERNAL

CONTROL

REMOTE

CONTROL

LOCK

ON / OFF

AC IN

Remote Control

q POWER ON/OFF

Switches Power ON/OFF.

(This does not operate when POWER/STANDBY

indicator of the main unit is off.)

w RGB/PC

Press this button to select RGB/PC as the source.

→ RGB/PC1 → RGB/PC2 → RGB/PC3

RGB/PC can also be selected using the INPUT

SELECT button on the monitor. The input switches as

follows each time the button is pressed:

→ VIDEO1 → VIDEO2→ VIDEO3→ DVD/HD

RGB/PC3 ← RGB/PC2 ← RGB/PC1 ←

eDVD / HD

Press this button to select DVD/HD as the source.

DVD/HD can also be selected using the INPUT

SELECT button on the monitor. The input switches as

follows each time the button is pressed:

→ VIDEO1 → VIDEO2→ VIDEO3→ DVD/HD

RGB/PC3 ← RGB/PC2 ← RGB/PC1 ←

rVIDEO

Press this button to select VIDEO as the source.

→ VIDEO1 → VIDEO2 → VIDEO3

VIDEO can also be selected using the INPUT SELECT

button on the monitor. The input switches as follows

each time the button is pressed:

→ VIDEO1 → VIDEO2→ VIDEO3→ DVD/HD

RGB/PC3 ← RGB/PC2 ← RGB/PC1 ←

tPROCEED

Press this button to access the OSM controls.

Press this button during the display of the main menu

to go to the sub menu.

yCURSOR (▲ / ▼ /  / )

Use these buttons to select items or settings and to

adjust settings or switch the display patterns.

uEXIT

Press this button to exit the OSM controls in the main

menu. Press this button during the display of the sub

menu to return to the main menu.

iPOINTER

Press this button to display the pointer.

oZOOM (+ /–)

Enlarges or reduces the image.

!0 VOLUME (+ /–)

Adjusts the volume.

!1 MUTE

Mutes the sound.

!2 WIDE

The type of broadcast is detected automatically, and

the recommended wide screen is set.

!3 DISPLAY

Displays the source settings on the screen.

!4 OFF TIMER

Activates the off timer for the unit.

!5 MULTI

Press this button to select a screen mode from among

single mode, side by side, and picture in picture.

!6 SELECT

Press this button to select the active picture in a multi

screen mode.

!7 AUTO ADJUST

Press this button to adjust Fine Picture, Picture ADJ,

Position, and Contrast automatically, or to switch the

screen size to ZOOM mode automatically with the

superimposed caption displayed fully only when the

picture contains dark areas above and below the picture.

!8 Remote control signal transmitter

Transmits the remote control signals.

Battery Installation and Replacement

Insert the 2 “AAA” batteries, making sure to set them in

with the proper polarity.

1.Press and open the cover.

2.Align the batteries according to the (+) and (–) indication

inside the case.

3.Replace the cover.

Operating Range

* Use the remote control within a distance of about 7 m/

23ft. from the front of the monitor’s remote control sensor

and at horizontal and vertical angles of up to approximately

30°.

* The remote control operation may not function if the

monitor’s remote control sensor is exposed to direct

sunlight or strong artificial light, or if there is an obstacle

between the sensor and the remote control.

Handling the remote control

•Do not drop or mishandle the remote control.

•Do not get the remote control wet. If the remote control

gets wet, wipe it dry immediately.

•Avoid heat and humidity.

•When not using the remote control for a long period,

remove the batteries.

•Do not use new and old batteries together, or use different

types together.

•Do not take apart the batteries, heat them, or throw them

into a fire.

•When using the remote control in the wireless condition,

be sure to unplug the remote cable from the REMOTE

CONTROL terminal on the monitor.

POWER/STANDBY

PROCEED

INPUT SELECT

DOWN UP LEFT/

RIGHT/+/EXIT

VOLUME

30˚ 30˚

Approx.

7m/ 23ft

Installation

RGB 3

(Digital RGB)

RGB 1

R/C

L(MONO)

VIDEO 1

G/Y

VIDEO 2

VIDEO 3

L(MONO)

B/C

AUDIO 2 DVD1/ HD1AUDIO 3 AUDIO 1RGB2/DVD2/HD2

VCR or Laser Disc Player

Document Camera

DVD Player

IBM VGA or

Compatibles

Personal computer with a

digital RGB output

Signal cable

To Mini D-Sub 15 pin connector on the plasma monitor

To video inputs on

the plasma monitor

Monitor adapter for

Macintosh

Macintosh or Compatibles

(Desk top type)

Connecting Your PC or Macintosh Computer

Connecting your PC or Macintosh computer to your plasma

monitor will enable you to display your computer’s screen

image for an impressive presentation. The plasma monitor

supports the signals described on page 47.

To connect a PC, Macintosh or compatible graphics adapter,

simply:

1. Turn off the power to your plasma monitor and computer.

2. If your PC does not support XGA/SVGA/VGA you will

need to install an XGA/SVGA/VGA graphics board.

Consult your computer’s owner’s manual for your XGA/

SVGA/VGA configuration. If you need to install a new

board, see the manual that comes with your new graphics

board for installation instructions.

3. The plasma monitor provides signal compatibility up to

VESA 1600⳯1200 (UXGA). However, it is not

recommended to use this resolution due to image

readability on the monitors 1365⳯768 native pixel

resolution panel.

4. Use the signal cable to connect your PC or Macintosh

computer to the plasma monitor. For Macintosh, use the

monitor adapter to connect to your computer’s video port.

5. Turn on the plasma monitor and the computer.

6. If the plasma monitor goes blank after a period of inactivity,

it may be caused by a screen saver installed on the

computer you’ve connected to the plasma monitor.

When using a Macintosh with the plasma monitor, the

following four display standards are supported using the

Macintosh adapter :

13" fixed mode

16" fixed mode

19" fixed mode

21" fixed mode

The 19" fixed mode is recommended for the plasma monitor.

Connections with Equipment that

has a Digital Interface

Connections can be made with equipment that is equipped

with a digital interface compliant with the DVI (Digital

Visual Interface) standard.

* Use a DVI 29-pin signal cable and the ferrite cores

(supplied) when making connections to the RGB3 IN (DVI)

connector of the main unit.

Note that the RGB3 IN(DVI) terminal does not support

analog RGB input source.

Note:

1. Input TMDS signals conforming to DVI standards.

The TMDS input corresponds to 1 link.

2. To maintain display quality, use a cable with a quality

prescribed by DVI standards that is within 5 meters in length.

Connecting Your Document Camera

You can connect your plasma monitor to a document

camera. To do so, simply:

1. Turn off the power to your plasma monitor and

document camera.

2. Use a standard video cable to connect your document

camera to the Video input on your plasma monitor.

3. Turn on the plasma monitor and the document camera.

Note:

Refer to your document camera owner’s manual

for more information about your camera’s video output

requirements.

Connecting Your VCR or Laser Disc

Player

Use common RCA cables (not provided) to connect your

VCR or laser disc player to your plasma monitor. To make

these connections, simply:

1. Turn off the power to your plasma monitor and VCR

or laser disc player.

2. Connect one end of your RCA cable to the video output

connector on the back of your VCR or laser disc player,

connect the other end to the Video input on your plasma

monitor. Use standard RCA audio patch cords to

connect the audio from your VCR or laser disc player

to your plasma monitor (if your VCR or laser disc player

has this capability). Be careful to keep your right and

left channel connections correct for stereo sound.

3. Turn on the plasma monitor and the VCR or laser disc

player.

Note:

Refer to your VCR or laser disc player owner’s

manual for more information about your equipment’s video

output requirements.

Connecting Your DVD Player

You can connect your plasma monitor to a DVD player.

To do so, simply:

1. Turn off the power to your plasma monitor and DVD

player.

2. Use a standard video cable to connect your DVD player

to the Y, Cb, and Cr inputs on your plasma monitor.

Or use the DVD-player’s S-Video output. Use a

standard S-Video cable to connect to the S-Video input

on the plasma monitor.

3. Turn on the plasma monitor and the DVD player.

External Speaker Connections

External speakers may be connected to the plasma monitor

to reproduce sound from VIDEO, DVD or RGB signal

sources.

External speakers may be connected directly to the

SPEAKERS terminals or indirectly by connecting a stereo

system amplifier to the audio outputs.

CAUTION:

Unplug the plasma monitor and all

connected components before connecting external

speakers. Use only speakers with 6-ohm impedance and

a power input rating of 7 watts or more.

RGB 3

(Digital RGB)

RGB 1

R/CR/PR

L(MONO)

VIDEO 1

G/Y

VIDEO 2

VIDEO 3

CB/PB

L(MONO)

CR/PR

B/CB/PB

AUDIO 2 DVD1 /HD1AUDIO 3 AUDIO 1RGB2/DVD2 /HD2

EXTERNAL

CONTROL

REMOTE

CONTROL

LOCK

ON/ OFF

SPEAKERS MUST HAVE

MORE THAN 7WATT RATING

IMPEDANCE 6 OHM

RIGHT LEFT

AC IN

LEFTRIGHT

To connect external speakers directly to the plasma

monitor:

1. Strip the ends of the speaker wires.

2. Press down the tabs below the SPEAKERS terminals,

insert the speaker wire and release the tab to secure the

speaker wire connection:

[a] Connect the right speaker (located at right side

of the monitor when viewed from the front)

positive (+) wire to RIGHT +.

[b] Connect the right speaker negative (–) wire to

RIGHT –.

[c] Connect the left speaker negative (–) wire to

LEFT–.

[d] Connect the left speaker positive (+) wire to

LEFT+.

Pin Assignments and Signal Levels for 15 pin RGB (Analog)

Pin No.

5 4 3 2 1

15 14 13 12 11

10 9 8 7 6

RGB 3

8 25 26

27 28

Signal (Analog)

Red

Green or sync-on-green

Blue

No connection

Ground

Red ground

Green ground

Blue ground

No connection

Sync signal ground

No connection

Bi-directional DATA (SDA)

Horizontal sync or Composite sync

Vertical sync

Data clock

Pin Configuration and Signal of the RGB 3 IN Connector (DVI Connector)

The unit is equipped with a type of connector commonly

used for both analog and digital.

(Functionally, this cannot be used for an

analog input.)

(TMDS can be used for one link only.)

Pin No.

Signal (Digital)

T.M.D.S Data 2 -

T.M.D.S Data 2 +

T.M.D.S Data 2 Shield

No connection

DDC Clock

DDC Data

No connection

T.M.D.S Data 1 -

T.M.D.S Data 1 +

T.M.D.S Data 1 Shield

No connection

+5V Power

Ground

Hot Plug Detect

T.M.D.S Data 0 -

T.M.D.S Data 0 +

T.M.D.S Data 0 Shield

No connection

T.M.D.S Clock Shield

T.M.D.S Clock +

T.M.D.S Clock -

No connection

POWER

To turn the unit ON and OFF:

1. Plug the power cord into an active AC power outlet.

2. Press the POWER ON button (on the remote control)

to turn on the unit.

The monitor’s POWER/STANDBY indicator will light

up (green) when the unit is on.

3. Press the POWER OFF button (on the remote control

or the unit) to turn off the unit.

The monitor’s POWER/STANDBY indicator turns red

and the standby mode is set (only when turning off the

unit with the remote control).

VOLUME

To adjust the volume:

1. Press and hold the VOLUME button (on the remote

control or the unit) to increase to the desired level.

2. Press and hold the VOLUME button (on the remote

control or the unit) to decrease to the desired level.

MUTE

To cancel the sound:

Press the MUTE button on the remote control to cancel

the sound; press again to restore.

DISPLAY

To check the settings:

1. The screen changes each time the DISPLAY button is

pressed.

2. If the button is not pressed for approximately three

seconds, the menu turns off.

DIGITAL ZOOM

Digital zoom specifies the picture position and enlarges

the picture.

1. Press the POINTER button to display the pointer. ( )

To change the size of the picture:

Press the ZOOM+ button and enlarge the picture.

The pointer will change to resemble a magnifying

glass. (

)

A press of the ZOOM- button will reduce the picture

and return it to its original size.

To change the picture position:

Select the position with the ▲▼  buttons.

2. Press the POINTER button to delete the pointer.

AUTO ADJUST

To adjust the size or quality of the picture

automatically:

Press the AUTO ADJUST button.

Information

 AUTO ADJUST ON setting

When RGB (still picture) input

is selected ...... Fine Picture, Picture ADJ, Position,

and Contrast will be adjusted

automatically.

When RGB (motion picture),

VIDEO, or Y/Pb/Pr (component) input

is selected ...... The screen size switches to ZOOM

mode automatically with the

superimposed caption displayed fully

only when the picture contains dark

areas above and below the picture.

Basic Operations

OFF TIMER

To set the off timer:

The off timer can be set to turn the power off after 30, 60,

90 or 120 minutes.

1. Press the OFF TIMER button to start the timer at 30

minutes.

2. Press the OFF TIMER button to the desired time.

3. The timer starts when the menu turns off.

→ 30 → 60 → 90 → 120 → 0

OFF TIMER30

To check the remaining time:

1. Once the off timer has been set, press the OFF TIMER

button once.

2. The remaining time is displayed, then turns off after a

few seconds.

3. When five minutes remain the remaining time appears

until it reaches zero.

OFF TIMER28

To cancel the off timer:

1. Press the OFF TIMER button twice in a row.

2. The off timer is canceled.

OFF TIMER0

Note:

After the power is turned off with the off timer ...

A slight current is still supplied to the monitor. When you

are leaving the room or do not plan to use the system for a

long period of time, turn off the power of the monitor.

Watching with a wide screen

(manual)

With this function, you can select one of four screen sizes.

When watching videos or digital video discs

1. Press the WIDE button on the remote control.

2. Within 3 seconds ...

Press the WIDE button again.

The screen size switches as follows:

→ ZOOM → NORMAL → FULL → STADIUM

ZOOM size screen

The picture is expanded in the horizontal and vertical

direction, maintaining the original proportions.

* Use this for theater size (wide) movies, etc.

NORMAL size screen (4:3)

The normal size screen is displayed.

* The picture has the same size as video pictures with a

4 : 3 aspect ratio.

FULL size screen

The image is expanded in the horizontal direction.

* Images compressed in the horizontal direction (“squeezed

images”) are expanded in the horizontal direction and

displayed on the entire screen. (Normal images are

expanded in the horizontal direction.)

STADIUM size screen

The picture is expanded in the horizontal and vertical

directions at different ratios.

* Use this for watching normal video programs (4:3) with a

wide screen.

When watching high definition video source

1. Press the WIDE button on the remote control.

FULL size screen (16 : 9)

The full size screen is displayed.

* The picture has the same size as video pictures (16 : 9).

WIDE Operations

Watching computer images with a

wide screen

Switch to the wide screen mode to expand the 4 : 3 image

to fill the entire screen.

1. Press the WIDE button on the remote control.

2. Within 3 seconds ...

Press the WIDE button again.

The screen size switches as follows:

→ NORMAL → FULL

NORMAL size screen (4:3 or SXGA 5:4)

The picture has the same size as the normal computer

image.

FULL size screen

The image is expanded in the horizontal direction.

When wide signals are input.

FULL size screen

When “PICTURE SIZE” is set to “OFF”

The screen size switches as follows:

→ TRUE → FULL

TRUE size screen (VGA, SVGA 4:3)

The image is true resolution.

FULL size screen

The image is expanded in the horizontal and vertical

direction.

When wide signals are input.

TRUE

The image is true resolution.

FULL

Information

 Supported resolution

See page 47 for details on the display output of the

various VESA signal standards supported by the

monitor.

 “PICTURE SIZE” setting

When the setting of “PICTURE SIZE” is OFF, the size

of RGB-input pictures will be TRUE in place of

NORMAL.

 When 852 (848) dot  480 line wide VGA*

signals with a vertical frequency of 60 Hz and

horizontal frequency of 31.7 (31.0) kHz are in-

put

Select an appropriate setting for RGB SELECT mode

referring to the“Table of Signals Supported” on page

47.

*“ IBM PC/AT” and “VGA” are registered trademarks

of IBM, Inc. of the United States.

Showing a couple of pictures on the

screen at the same time

* An RGB-input picture may not be displayed in these modes,

depending on the input signal specifications.

1. Press the MULTI button to select a screen mode from

among single mode, side by side, and picture in picture.

Side by side 1

VIDEO1 RGB/PC1

Press the cursor buttons   on the remote control to

switch either side by side 1 (with ) or side by side 2

(with ).

Note:

Picture A and B on the above screen are not always of the

same height.

Side by side 2

VIDEO1 RGB/PC1

Sub screen Main screen

Picture in picture

VIDEO1

Sub

screen

Main screen

RGB/PC1

Press the cursor buttons   on the remote control to

switch the position of the sub screen.

VIDEO1

Sub

screen

Main screen

RGB/PC1

2. If you wish to switch the setting of the picture, press

the SELECT button to make the desired picture active.

Each press of the SELECT button changes the selection

of the active picture.

MULTI SCREEN Operations

VIDEO1 RGB/PC1

Selecting the input signals to be displayed

1. Press the SELECT button to make the desired picture

active.

2. Press the RGB/PC, VIDEO, or DVD/HD button.

Each press of the button changes the selection of the

input signal.

The INPUT SELECT button on the monitor can also

be used to change the selection.

Adjusting the OSM controls

1. Press the PROCEED button to display the MAIN

MENU.

2. Adjust the setting to your preference.

For details, see “OSM (On Screen Menu) Controls” on

page 17.

Note:

During multi mode, Auto Adjust does not affect the screen.

Information

 Positioning on the screen (for side by side)

Depending on the input-signal selection,

positioning of the picture is settled as follows.

Pictures displayed

on the left ........ VIDEO1, VIDEO2, VIDEO3, HD1/

DVD1/DTV1, or HD2/DVD2/

DTV2

Pictures displayed

on the right ...... RGB/PC1, RGB/PC2, RGB/PC3

 Positioning on the screen (for picture in

picture)

Pictures displayed

Main screen .... RGB/PC1, RGB/PC2, RGB/PC3

Sub screen ...... VIDEO1, VIDEO 2, VIDEO 3,

HD 1/DVD 1/DTV 1, or HD 2/

DVD 2/DTV 2

 Multi screen operations may not function

depending on the type of the RGB signals.

Menu Operations

The OSM window is displayed with respect to the

screen as shown on the diagram.

* Depending on the screen’s mode, the OSM may be

displayed differently.

In the explanation, the OSM section is shown close up.

MAIN MENU


SOUND

SCREEN

FUNCTION

OPTIONS

INFORMATION

SEL. OK EXIT

EXITPROCEED

The following describes how to use the menus and the

selected items.

1. Press the PROCEED button on the remote control to

display the MAIN MENU.

MAIN MENU


SOUND

SCREEN

FUNCTION

OPTIONS

INFORMATION

SEL. OK EXIT

EXITPROCEED

2. Press the cursor buttons ▲ ▼ on the remote control to

highlight the menu you wish to enter.

3. Press the PROCEED button on the remote control to

select a submenu or item.


CONTRAST

BRIGHTNESS

SHARPNESS

COLOR

TINT

PICTURE MODE

COLOR TEMP.

MEMORY

OFF

SEL. ADJ. RETURN

EXIT

4. Adjust the level or change the setting of the selected

item by using the cursor buttons   on the remote

control.

OSM(On Screen Menu) Controls

5. The change is stored until you adjust it again.

6. Repeat steps 2 – 5 to adjust an additional item, or press

the EXIT button on the remote control to return to the

main menu.

Note:

The main menu disappears by pressing the EXIT

button.

Main menu Sub menu Functions Default Reset

PICTURE CONTRAST Adjusts the contrast. Center Yes

BRIGHTNESS Adjusts the brightness. Center Yes

SHARPNESS Adjusts the sharpness. Center Yes

COLOR Adjusts the color. Center Yes

TINT Adjusts the tint. Center Yes

PICTURE MODE Sets the picture mode according to the VIDEO environment and MEMORY Yes

image software.

COLOR TEMP Adjusts the color temperature and white balance. 2*1Yes

NR Reduces noise visible in image. OFF Yes

Main menu Sub menu Functions Default Reset

SOUND BASS Sets the bass. Center Yes

TREBLE Sets the treble. Center Yes

BALANCE Sets the left/right balance. Center Yes

Main menu Sub menu Functions Default Reset

SCREEN V-POSITION Adjusts the vertical position. Center Yes

H-POSITION Adjusts the horizontal position. Center Yes

V-HEIGHT Adjusts the vertical size. Min Yes

H-WIDTH Adjusts the horizontal size. Min Yes

AUTO PICTURE Turn this on to have the monitor automatically adjust “FINE PICTURE” OFF*1No

and “PICTURE ADJ”.

FINE PICTURE Adjusts for flickering on the computer image. Min*1Yes

PICTURE ADJ. Adjusts for striped patterns on the computer image. Center*1Yes

Main menu Sub menu Functions Default Reset

FUNCTION OSM

Turns the on-screen menu (screen mode, etc.) off (when set to “OFF”).

ON Yes

When set to “ON”, the on-screen menu is displayed.

OSM ADJ. Adjusts the vertical and horizontal positions of the menu display. 1 Yes

POWER MGT Sets the monitor for use as an energy-saving display when used with a OFF Yes

computer.

GRAY LEVEL In case of 4 : 3, sets the luminance of both sides. 3 Yes

CINEMA MODE Sets the picture to suit the movie. ON Yes

RGB3 ADJ. Adjusts the picture when the picture input from the RGB3 input 1 Yes

terminal is distorted.

LONG LIFE Sets the picture to reduce burn-in of the display. *2Yes

RESET Resets all the settings (PICTURE, SOUND, SCREEN, FUNCTION, — —

etc.) to the factory default values.

Main menu Sub menu Functions Default Reset

OPTION AUDIO INPUT Sets the allocation of the audio connectors. *3Yes

BNC SELECT Sets the BNC connectors. RGB Yes

RGB SELECT Sets the appropriate mode for the computer image. AUTO Yes

RGB (VGA signals), VIDEO (Moving picture), WIDE (WIDE VGA) DTV.

HD SELECT

Sets the digital broadcasting (1080A,1080B) or the High Vision (1035I).

1080B No

PICTURE SIZE Sets the picture size for RGB input. ON Yes

Main menu Sub menu Functions Default Reset

INFORMATION FREQUENCY Used to check the frequency and synchronizing polarities of the signal — —

currently being inputted.

LANGUAGE Sets the language of the menus (Japanese, English, German, French, English No

Swedish, Italian or Spanish).

COLOR SYSTEM Sets the VIDEO format (AUTO1, AUTO2, PAL, PAL-M, PAL-N, PAL60, AUTO1 No

SECAM, 4.43 NTSC or 3.58 NTSC).

*1 RGB/PC only.

*2 PLE: AUTO ORBITER: OFF INVERSE: OFF

*3 AUDIO1: VIDEO1 AUDIO2: HD/DVD1 AUDIO3: RGB1

Picture Settings Menu

Adjusting the picture

The contrast, brightness, sharpness, color and tint can be

adjusted as desired.

Example: Adjusting the contrast

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “PICTURE”, then

press the PROCEED button. The “PICTURE” screen

appears.

2. Use the ▲ and ▼ buttons to select “CONTRAST”.


CONTRAST

BRIGHTNESS

SHARPNESS

COLOR

TINT

PICTURE MODE

COLOR TEMP.

MEMORY

OFF

SEL. ADJ. RETURN

EXIT

3. Use the  and  buttons to adjust the contrast.

CONTRAST

* If neither the  or  button is pressed within 5 seconds,

the current setting is set and the previous screen

reappears.

4. Once the adjustment is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Note:

If “CAN NOT ADJUST” appears ...

When trying to enter the PICTURE submenu, make sure

PICTURE MODE is set to MEMORY.

Information

 Picture adjustment screen

CONTRAST .... Changes the picture’s contrast.

BRIGHTNESS . Changes the picture’s brightness.

SHARPNESS .. Changes the picture’s sharpness.

Adjusts picture detail of VIDEO

display.

COLOR ........... Changes the color density.

TINT ................ Changes the picture’s tint. Adjust for

natural colored skin, background, etc.

 Adjusting the computer image

Only the contrast and brightness can be adjusted when

a computer signal is connected.

 Restoring the factory default settings

Select “RESET” under the “PICTURE MODE” settings.

Setting the picture mode according to the

brightness of the room

There are four picture modes that can be used effectively

according to the environment in which you are viewing

the display.

Example: Setting the “THEATER” mode

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “PICTURE”, then

press the PROCEED button.

The “PICTURE” screen appears.

2. Use the ▲ and ▼ buttons to select “PICTURE MODE”.


CONTRAST

BRIGHTNESS

SHARPNESS

COLOR

TINT

PICTURE MODE

COLOR TEMP.

MEMORY

OFF

SEL. ADJ. RETURN

EXIT

3. To set to “THEATER” ...

Use the  and  buttons to select “THEATER”.

The mode switches as follows when the  and 

buttons are pressed:

→ MEMORY ↔ THEATER ↔ NORMAL ↔ RESET ←

PICTURE MODE THEATER:

* If neither the  or  button is pressed within 5 seconds,

the current selection is set and the previous screen

reappears.

4. Once the adjustment is completed ...

Press the EXIT button to return to the main menu. To

delete the main menu, press the EXIT button once more.

Information

 Types of picture modes

MEMORY ........ The last picture adjustments are stored

here.

THEATER ........ Set this mode when watching video in

a dark room.

This mode provides darker, finer

pictures, like the screen in movie

theaters.

CONTRAST = 80% for RESET mode

BRIGHTNESS = 95% for RESET

mode

NORMAL ......... Set this mode when watching video in

a bright room.

This mode provides dynamic pictures

with distinct differences between light

and dark sections.

CONTRAST = 96% for RESET mode

RESET ............ Use this to reset the picture to the

factory default settings.

Setting the color temperature

Use this procedure to set color tone produced by the plasma

display.

Example: Setting “1”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “PICTURE”, then

press the PROCEED button.

The “PICTURE” screen appears.

2. Use the ▲ and ▼ buttons to select “COLOR TEMP.”.


CONTRAST

BRIGHTNESS

SHARPNESS

COLOR

TINT

PICTURE MODE

COLOR TEMP.

MEMORY

OFF

SEL. ADJ. RETURN

EXIT

3. Use the  and  buttons to select “1”.

The mode switches as follows when the  and 

buttons are pressed:

→ 1 ↔ 2 ↔ 3 ↔ PRO ←

* See page 22 to set “PRO”.

COLOR TEMP. 1

* If neither the  or  button is pressed within 5 seconds,

the current selection is set and the previous screen reappears.

4. Once the setting is completed...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

 Setting the color temperature

1 ...................... High (bluer)

2......................... Middle (Standard)

3 ...................... Low (redder)

 Restoring the factory default settings

Select “RESET” under the function menu. Note that this

also restores other settings to the factory defaults.

Adjusting the color to the desired quality

Use this procedure to adjust the white balance for bright

pictures and dark pictures to achieve the desired color

quality.

Example: Adjusting the “WHITE BALANCE”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “PICTURE”, then

press the PROCEED button.

The “PICTURE” screen appears.

2. Use the ▲ and ▼ buttons to select “COLOR TEMP.”.


CONTRAST

BRIGHTNESS

SHARPNESS

COLOR

TINT

PICTURE MODE

COLOR TEMP.

MEMORY

OFF

SEL. ADJ. RETURN

EXIT

3. Use the  and  buttons to select “PRO”.

The mode switches as follows when the  and 

buttons are pressed:

→ 1 ↔ 2 ↔ 3 ↔ PRO ←

PRO:COLOR TEMP.

* If neither the  or  button is pressed within 5 seconds,

the current selection is set and the previous screen reappears.

4. Press the PROCEED button.

The “WHITE BALANCE” screen appears.

5. Use the ▲ and ▼ buttons to select “RED-GAIN”.

WHITE BALANCE

GAIN

RED

GREEN

BLUE

BIAS

RED

GREEN

BLUE

SEL. ADJ. RETURN

EXIT

6. Adjust the white balance using the  and  buttons.

R-GAIN

* If neither the  or  button is pressed within 5 seconds,

the current setting is set and the previous screen reappears.

7. Once the adjustment is completed...

Press the EXIT button to return to the main menu. To

delete the main menu, press the EXIT button once more.

Information

 Adjusting the white balance

RGB-GAIN ....... White balance adjustment for signal

level

RGB-BIAS ....... White balance adjustment for black

level

 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

Reducing noise in the picture

Use these settings if the picture has noise due to poor

reception or when playing video tapes on which the picture

quality is poor.

Example: Setting “NR-3”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “PICTURE”, then

press the PROCEED button.

The “PICTURE” screen appears.

2. Use the ▲ and ▼ buttons to select “NR”.


CONTRAST

BRIGHTNESS

SHARPNESS

COLOR

TINT

PICTURE MODE

COLOR TEMP.

MEMORY

OFF

SEL. ADJ. RETURN

EXIT

3. Use the  and  buttons to select “NR-3”.

The mode switches as follows when the  and 

buttons are pressed:

→ OFF ↔ NR-1 ↔ NR-2 ↔ NR-3 ←

NR NR-3

* If neither the  or  button is pressed within 5 seconds,

the current selection is set and the previous screen

reappears.

4. Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

 NR

* “NR” stands for Noise Reduction.

* This function reduces noise in the picture.

 Types of noise reduction

There are three types of noise reduction. Each has a

different level of noise reduction.

The effect becomes stronger as the number increases

(in the order NR-1 → NR-2 → NR-3).

OFF ............... Turns the noise reduction function off.

Sound Settings Menu

Adjusting the treble, bass and left/right

balance

The treble, bass and left/right balance can be adjusted to

suit your tastes.

Example: Adjusting the bass

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “SOUND”, then

press the PROCEED button.

The “SOUND” screen appears.

2. To adjust the bass ...

Use the ▲ and ▼ buttons to select “BASS”.

SOUND

BASS

TREBLE

BALANCE

SEL. ADJ. RETURN

EXIT

3. Adjust the bass using the  and  buttons.

SOUND

BASS

TREBLE

BALANCE

SEL. ADJ. RETURN

EXIT

* If neither the  or  button is pressed within 5 seconds,

the current selection is set and the previous screen reappears.

To continue adjusting the sound ...

Repeat from step 2.

4. Once the adjustment is completed ...

Press the EXIT button to return to the main menu. To

delete the main menu, press the EXIT button once more.

Note :

If “CAN NOT ADJUST” appears...

Set “AUDIO INPUT” on the OPTION menu correctly.

Information

 Sound settings menu

BASS .............. Changes the level of low frequency

sound.

TREBLE .......... Changes the level of high frequency

sound.

BALANCE ....... Changes the balance of the left and

right channels.

 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

3. Adjust using the 䊴 and 䊳 buttons.

V–POSITION

* If neither the 䊴 or 䊳 button is pressed within 5 seconds,

the current setting is set and the previous screen

reappears.

To continue making other computer image

adjustments ...

Repeat from step 2.

4. Once all adjustments are completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 When “AUTO PICTURE” is “OFF”

SCREEN

MODE

V–POSITION

H–POSITION

V–HEIGHT

H–WIDTH

AUTO PICTURE

FINE PICTURE

PICTURE ADJ.

FULL:

OFF:

SEL. ADJ. RETURN

EXIT

When Auto Picture is off, the Fine Picture and the

Picture ADJ items are displayed so that you can adjust

them.

Screen Settings Menu

Adjusting the Position, Size, Fine Picture, Picture Adj

The position of the image can be adjusted and flickering

of the image can be corrected.

Example: Adjusting the vertical position in the normal

mode

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “SCREEN”, then

press the PROCEED button. The “SCREEN” menu

appears.

Default settings (when RGB/PC is selected)

SCREEN

MODE

V–POSITION

H–POSITION

V–HEIGHT

H–WIDTH

AUTO PICTURE

FINE PICTURE

PICTURE ADJ.

NORMAL:

OFF:

SEL. ADJ. RETURN

EXIT

* The settings on the SCREEN menu are not preset at the

factory.

To select a mode ...

Use the 䊴 and 䊳 buttons to select a mode.

The mode switches as follows when the 䊴 and 䊳

buttons are pressed:

→ NORMAL ↔ FULL ←

* The mode can also be switched by pressing the “WIDE”

button on the remote control.

2. To adjust the vertical position ...

Use the ▲ and ▼ buttons to select “V-POSITION”.

SCREEN

MODE

H–POSITION

V–HEIGHT

H–WIDTH

AUTO PICTURE

FINE PICTURE

PICTURE ADJ.

NORMAL:

OFF:

SEL. ADJ. RETURN

EXIT

V–POSITION

Information

䡵 Adjusting the Auto Picture

ON ................... The Picture ADJ and Fine Picture

adjustments are made automatically.

OFF ................. The Picture ADJ and Fine Picture

adjustments are made manually.

䡵 Adjusting the position of the image

V-POSITION ... Adjusts the vertical position of the

image.

H-POSITION ... Adjusts the horizontal position of the

image.

V-HEIGHT ....... Adjusts the vertical size of the image.

(Except for STADIUM mode)

H-WIDTH ......... Adjusts the horizontal size of the

image. (Except for STADIUM mode)

FINE PICTURE

* .. Adjusts for flickering.

PICTURE ADJ* ....

Adjusts for striped patterns on the

image.

* The Picture ADJ and Fine Picture features are available

only when the “Auto Picture” is off.

* The AUTO PICTURE, FINE PICTURE and PICTURE

ADJ. are not available for VIDEO and HD/ DVD source.

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults

except for Auto Picture.

Function Settings Menu

Setting the on-screen menu

When using the monitor for presentations, etc., the monitor

can be set so that the input source, screen mode, etc., do

not appear.

Example: Turning the on-screen menu mode off

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “FUNCTION”, then

press the PROCEED button.

The “FUNCTION” screen appears.

2. Use the ▲ and ▼ buttons to select “OSM”.

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

3. To turn the on-screen menu mode off ...

Use the 䊴 and 䊳 buttons to select “OFF”.

The mode switches as follows each time the 䊴 or 䊳

button is pressed:

ON ↔ OFF

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

4. Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 OSM modes

ON ................... The on-screen menu appears.

OFF ................. The on-screen menu does not appear.

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

Adjusting the position of the menu display

Use these operations to adjust the position of the menus

that appear on the screen.

Example: Adjusting the position of the menu display

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “FUNCTION”,

then press the PROCEED button.

The “FUNCTION” menu appears.

2. Use the ▲ and ▼ buttons to select “OSM ADJ.”

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

LONG LIFE

RGB3 ADJ.

RESET

3. To adjust the position...

Adjust using the 䊴 and 䊳 buttons.

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

LONG LIFE

RESET

RGB3 ADJ.

4. Once all adjustments are completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 Adjusting the position of the menu display

123

456

789

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

The position can be set

between 1 and 9.

Setting the power management for computer images

This energy-saving (power management) function

automatically reduces the monitor’s power consumption

if no operation is performed for a certain amount of time.

Example: Turning the power management function on

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “FUNCTION”, then

press the PROCEED button.

The “FUNCTION” screen appears.

2. Use the ▲ and ▼ buttons to select “POWER MGT”.

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

3. To turn the power management function on ...

Use the 䊴 and 䊳 buttons to select “ON”.

The mode switches as follows each time the 䊴 or 䊳

button is pressed:

ON ↔ OFF

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

4. Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 Power management function

* The power management function automatically reduces

the monitor’s power consumption if the computer’s

keyboard or mouse is not operated for a certain amount

of time. This function can be used when using the

monitor with a computer conforming to the VESA

DPMS format.

* If the computer’s power is not turned on or if the

computer and selector tuner are not properly connected,

the system is set to the off state.

* For instructions on using the computer’s power

management function, refer to the computer’s operating

instructions.

䡵 Power management settings

ON ................... In this mode the power management

function is turned on.

OFF ................. In this mode the power management

function is turned off.

䡵 Power management function and POWER/

STANDBY indicator

The POWER/STANDBY indicator indicates the status

of the power management function. See page 29 for

indicator status and description.

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

POWER/STANDBY indicator

Power management

mode

Standby

Suspend

Off

POWER/STANDBY

indicator

Green

Orange

Red

Description

Horizontal and vertical synchronizing

signals are present from the computer.

No horizontal synchronizing signals

are sent from the computer.

No vertical synchronizing signals are

sent from the computer.

No horizontal or vertical synchronizing

signals are sent from the computer.

Turning the picture back on

Picture already on.

Operate the keyboard or mouse. The

picture reappears immediately.

Operate the keyboard or mouse. The

picture reappears, but more time is

required than from the standby

mode.

Operate the keyboard or mouse. The

picture reappears, but more time is

required than from the standby mode

or suspend mode.

Power management

operating status

Not activated.

Activated.

Setting the gray level for the sides of the screen

Use this procedure to set the gray level for the parts on the

screen on which nothing is displayed when the screen is

set to the 4:3 size.

Example: Adjusting the “GRAY LEVEL”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “FUNCTION”, then

press the PROCEED button.

The “FUNCTION” screen appears.

2. Use the ▲ and ▼ buttons to select “GRAY LEVEL”.

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

3. To adjust the “GRAY LEVEL”...

Use the 䊴 and 䊳 buttons to adjust the GRAY LEVEL.

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

4. Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 GRAY LEVEL

This adjusts the brightness of the black (the gray level)

for the sides of the screen.

The standard is 0 (black). The level can be adjusted

from 0 to 15. The factory setting is 3 (dark gray).

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

Setting the picture to suit the movie

The film image is automatically discriminated and

projected in an image mode suited to the picture.

[NTSC, 480I (60Hz), 1035I (60Hz), 1080I (60Hz) only]

Example: Setting the “CINEMA MODE” to “OFF”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “FUNCTION”, then

press the PROCEED button.

The “FUNCTION” screen appears.

2. Use the ▲ and ▼ buttons to select “CINEMA MODE”.

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

3. To set the CINEMA MODE to “OFF” ...

Use the 䊴 and 䊳 buttons to select “OFF”.

The mode switches as follows each time the 䊴 or 䊳

button is pressed:

→ ON ↔ OFF ←

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

4. Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 CINEMA MODE

ON ................... Automatic discrimination of the

image and projection in cinema mode.

OFF ................... Cinema mode does not function.

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

Setting RGB3 ADJ.

When the picture input from the RGB3 input terminal is

distorted, select the most appropriate setting from among

“1”, “2”, and “3”.

Example: Setting “2”

Press the PROCEED button on the remote control to

display MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “FUNCTION”,

then press the PROCEED button.

The “FUNCTION” screen appears.

2. Use the ▲ and ▼ buttons to select “RGB3 ADJ.”.

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

3. To select “2”...

Use the 䊴 and 䊳 buttons to select “2”.

The mode switches as follows each time the 䊴 or 䊳

buton is pressed:

→ 1 ↔ 2 ↔ 3 ←

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

SEL. ADJ. RETURN

EXIT

LONG LIFE

RGB3 ADJ.

RESET

4. Once the setting is completed...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 When you adjust the RGB3 ADJ.

The position of the menu display will change. In such

a case, be sure to adjust the position.

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

Reducing burn-in of the screen

The brightness of the screen, the position of the picture,

and positive/negative mode are adjusted to reduce burn-

in of the screen.

Example: Setting “PLE” to “LOCK”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then proceed as

follows.

1. Use the ▲ and ▼ buttons to select “FUNCTION”, then

press the PROCEED button.

The “FUNCTION” screen appears.

2. Use the ▲ and ▼ buttons to select “LONG LIFE”, then

press the PROCEED button.

The “LONG LIFE” screen appears.

3. Use the ▲ and ▼ buttons to select “PLE”, then use the

䊴 and 䊳 buttons to select “LOCK”.

The mode switch changes as follows each time the 䊴

or 䊳 button is pressed:

AUTO ↔ LOCK

4. Once the setting is completed...

Press the EXIT button to return to the FUNCTION

menu.

To exit the main menu, press the EXIT button twice.

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

CINEMA MODE

OFF

1:RGB3 ADJ.

SEL. RETURN

EXIT

PROCEED

LONG LIFE

RESET

LONG LIFE

PLE

ORBITER

INVERSE

OFF

LOCK

SEL. ADJ. RETURN

EXIT

Information

䡵 PLE

AUTO .............. The brightness of the screen is

adjusted automatically to suit the

picture quality.

LOCK .............. The brightness level is set to

minimum.

䡵 ORBITER

ON ................... The picture moves around the screen

intermittently.

OFF ................. Orbiter mode does not function.

䡵 INVERSE

ON ..................... The picture is displayed alternately

between positive image and negative

image.

OFF ................. Inverse mode does not function.

WT .................. The entire screen turns white.

䡵 Restoring the factory default settings

Select “RESET” from the function menu. Note that this

also restores other settings to the factory defaults.

Resetting to the default values

Use these operations to restore all the picture adjustments,

audio settings, to the factory default values.

Refer to page 18 for items to be reset.

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “FUNCTION”, then

press the PROCEED button.

The “FUNCTION” screen appears.

2. Use the ▲ and ▼ buttons to select “RESET”, then press

the PROCEED button.

FUNCTION

OSM

OSM ADJ.

POWER MGT

GRAY LEVEL

LONG LIFE

CINEMA MODE

RESET

OFF

SEL. RETURN

EXIT

PROCEED

1:RGB3 ADJ.

The “RESET” screen appears.

3. Use the ▲ and ▼ buttons to select “RESET”, then press

the PROCEED button.

RESET

RETURN

OK RETURN

EXITPROCEED

SETTING NOW

RESET

When the “SETTING NOW” screen disappears, the

screen will be restored to the previous “RESET” mode,

then all the settings are restored to the default values.

4. Once the setting is completed ...

Press the EXIT button.

To delete the main menu, press the EXIT button once

more.

Option Settings Menu

Setting the allocation of the audio connectors

Setting the AUDIO 1, 2, and 3 connectors to the desired

input.

Example: Setting “AUDIO 1” to “VIDEO 2”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “OPTION”, then

press the PROCEED button.

The “OPTION” screen appears.

2. Use the ▲ and ▼ buttons to select “AUDIO 1”.

OPTION

AUDIO INPUT

AUDIO1

AUDIO2

AUDIO3

BNC SELECT

RGB SELECT

HD SELECT

PICTURE SIZE

VIDEO1

RGB1

RGB

AUTO

1080B

SEL. ADJ. RETURN

EXIT

HD/DVD1

3. To set the AUDIO1 to “VIDEO2”...

Use the 䊴 and 䊳 buttons to select “VIDEO2”.

The mode switches as follows each time the 䊴 or 䊳

button is pressed:

→

VIDEO1

↔

VIDEO2

↔

VIDEO3

↔

HD/DVD1

↔

RGB/PC1

↔

RGB/PC2

↔

RGB/PC3

←

OPTION

AUDIO INPUT

AUDIO1

AUDIO2

AUDIO3

BNC SELECT

RGB SELECT

HD SELECT

PICTURE SIZE

RGB

AUTO

1080B

SEL. ADJ. RETURN

EXIT

VIDEO2

RGB1

HD/DVD1

4. Once the setting is completed...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 AUDIO INPUT

A single audio input cannot be selected as the audio

channel for more than one input terminal.

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

Setting the BNC connectors

Select whether to set the input of the 5 BNC connectors to

RGB or component.

Example: Set the BNC SELECT mode to “COMP.”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “OPTION”, then

press the PROCEED button.

The “OPTION” screen appears.

2. Use the ▲ and ▼ buttons to select “BNC SELECT”.

OPTION

AUDIO INPUT

AUDIO1

AUDIO2

AUDIO3

BNC SELECT

RGB SELECT

HD SELECT

PICTURE SIZE

RGB

AUTO

1080B

SEL. ADJ. RETURN

EXIT

VIDEO1

RGB1

HD/DVD1

3. To set the BNC SELECT mode to “COMP.”...

Use the 䊴 and 䊳 buttons to select “COMP.”.

The mode switches as follows each time the 䊴 or 䊳

button is pressed:

RGB ↔ COMP.

OPTION

AUDIO INPUT

AUDIO1

AUDIO2

AUDIO3

BNC SELECT

RGB SELECT

HD SELECT

PICTURE SIZE

COMP.

AUTO

1080B

SEL. ADJ. RETURN

EXIT

VIDEO1

RGB1

HD/DVD1

4. Once the setting is completed...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 BNC SELECT

RGB ................ Uses the 5BNC terminal for RGB

input.

COMP. ............. Use the 3BNC terminal for component

input.

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

Setting a computer image to the correct RGB

select screen

With the computer image, select the RGB Select mode

for a moving image such as (video) mode, wide mode or

digital broadcast.

Example: Setting the “RGB SELECT” mode to

“MOTION ”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “OPTION”, then

press the PROCEED button.

The “OPTION” screen appears.

2. Use the ▲ and ▼ buttons to select “RGB SELECT”.

AUDIO INPUT

AUDIO1

AUDIO2

AUDIO3

BNC SELECT

RGB SELECT

HD SELECT

PICTURE SIZE

RGB

AUTO

1080B

SEL. ADJ. RETURN

EXIT

OPTION

VIDEO1

RGB1

HD/DVD1

3. To set the RGB select mode to “MOTION” ...

Use the 䊴 and 䊳 buttons to select “MOTION”.

The mode switches as follows each time the 䊴 or 䊳

button is pressed:

→ AUTO ↔ STILL ↔ MOTION ↔ WIDE1 ↔ WIDE2 ↔ DTV ←

OPTION

AUDIO INPUT

AUDIO1

AUDIO2

AUDIO3

BNC SELECT

RGB SELECT

HD SELECT

PICTURE SIZE

RGB

MOTION

1080B

SEL. ADJ. RETURN

EXIT

VIDEO1

RGB1

HD/DVD1

4. Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 RGB SELECT modes

One of these 6 modes must be selected in order to

display the following signals correctly.

AUTO .............. Select the suitable mode for the

specifications of input signals as

listed in the table “Computer input

signals supported by this system” on

page 47.

STILL .............. To display VESA standard signals.

(Use this mode for a still image from

a computer.)

MOTION .......... The video signal (from a scan

converter) will be converted to RGB

signals to make the picture more

easily viewable. (Use this mode for a

motion image from a computer.)

WIDE1 ............. When an 852 dot⳯ 480 line signal

with a horizontal frequency of

31.7kHz is input, the image may be

compressed horizontally. To prevent

this, set RGB SELECT to WIDE1.

WIDE2 ............. When an 848 dot⳯ 480 line signal

with a horizontal frequency of 31.0

kHz is input, the image may be

compressed horizontally. To prevent

this, set RGB SELECT to WIDE2.

DTV .................Set this mode when watching digital

broadcasting (480P).

See page 47 for the details of the above settings.

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

Setting high definition images to the suitable

screen size

Use this procedure to set whether the number of vertical

lines of the input high definition image is 1035 or 1080.

Example: Setting the “1080B” mode to “1035I”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “OPTION”, then

press the PROCEED button.

The “OPTION” screen appears.

2. Use the ▲ and ▼ buttons to select “HD SELECT”.

OPTION

AUDIO INPUT

AUDIO1

AUDIO2

AUDIO3

BNC SELECT

RGB SELECT

HD SELECT

PICTURE SIZE

RGB

AUTO

1080B

SEL. ADJ. RETURN

EXIT

VIDEO1

RGB1

HD/DVD1

3. To set the HD SELECT mode to “1035I” ...

Use the 䊴 and 䊳 buttons to select “1035I”.

The mode switches as follows each time the 䊴 or 䊳

button is pressed:

→1080A ↔ 1080B ↔ 1035I ←

OPTION

AUDIO INPUT

AUDIO1

AUDIO2

AUDIO3

BNC SELECT

RGB SELECT

HD SELECT

PICTURE SIZE

RGB

AUTO

1035I

SEL. ADJ. RETURN

EXIT

VIDEO1

RGB1

HD/DVD1

4. Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 HD SELECT modes

These 3 modes are not displayed in correct image

automatically.

1080A ............... Special Digital broadcasts (for

example : DTC100)

1080B ............... Standard digital broadcasts

1035I ............... Japanese “High Vision” signal format

Setting the picture size for RGB input signals

Use this procedure to switch the setting to “ON” or “OFF”.

Example: Setting the “ON” mode to “OFF”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “OPTION”, then

press the PROCEED button.

The “OPTION” screen appears.

2. Use the ▲ and ▼ buttons to select “PICTURE SIZE”.

OPTION

AUDIO INPUT

AUDIO1

AUDIO2

AUDIO3

BNC SELECT

RGB SELECT

HD SELECT

PICTURE SIZE

RGB

AUTO

1080B

SEL. ADJ. RETURN

EXIT

VIDEO1

RGB1

HD/DVD1

3. To set PICTURE SIZE mode to “OFF”...

Use the 䊴 and 䊳 buttons to select “OFF”.

The mode switches as follows when the 䊴 or 䊳 buttons

are pressed:

ON ↔ OFF

OPTION

AUDIO INPUT

AUDIO1

AUDIO2

AUDIO3

BNC SELECT

RGB SELECT

HD SELECT

PICTURE SIZE

RGB

AUTO

1080B

OFF

SEL. ADJ. RETURN

EXIT

VIDEO1

RGB1

HD/DVD1

4. Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 PICTURE SIZE

ON ..................... For RGB Input: “NORMAL” and

“FULL” can be selected for Wide-

Screen switching.

OFF ................... For RGB Input: “TRUE” and

“FULL” can be selected for Wide-

Screen switching.

䡵 Restoring the factory default settings

Select “RESET” under the function menu. Note that

this also restores other settings to the factory defaults.

Information Menu

Checking the frequencies, polarities of input

signals, and resolution

Use this function to check the frequencies and polarities

of the signals currently being input from a computer, etc.

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “INFORMATION”,

then press the PROCEED button.

The “INFORMATION” screen appears.

2. Use the ▲ and ▼ buttons to select “FREQUENCY”,

then press the PROCEED button.

INFORMATION

FREQUENCY

LANGUAGE

COLOR SYSTEM

SEL. RETURN

EXIT

PROCEED

3. The frequency is displayed.

FREQUENCY

H. FREQ

V. FREQ

H. POL

V. POL

37.5KHz

75.0Hz

NEG.

MODE

RESOLUTION

640⳯480

RETURN

EXIT

* Press the EXIT button to return to the previous screen.

4. Once you have checked the frequency ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Setting the language for the menus

The menu display can be set to one of seven languages:

Japanese, English, German, French, Swedish, Italian or

Spanish.

Example: Setting the menu display to “DEUTSCH”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “INFORMATION”,

then press the PROCEED button. The

“INFORMATION” screen appears.

2. Use the ▲ and ▼ buttons to select “LANGUAGE”,

then press the PROCEED button.

INFORMATION

FREQUENCY

LANGUAGE

COLOR SYSTEM

SEL. RETURN

EXIT

PROCEED

The “LANGUAGE” screen appears.

3. To select “ DEUTSCH ” ...

Use the 䊴 and 䊳 buttons to select “ DEUTSCH ”.

The mode switches as follows when the 䊴 and 䊳

buttons are pressed:

→ ENGLISH ↔ DEUTSCH ↔ FRANÇAIS ←

→ ↔ SVENSKA ↔ ITALIANO ↔ ESPAÑOL ←

LANGUAGE

DEUTSCH:

ADJ. RETURN

EXIT

PROCEED

4. Press the PROCEED button.

The display language is switched to Deutsch.

5. Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

Information

䡵 Language settings

ENGLISH ........ English

DEUTSCH....... German

FRANÇAIS ...... French

ESPAÑOL ....... Spanish

ITALIANO ........ Italian

SVENSKA ....... Swedish

.............. Japanese

Setting the video signal format

Use these operations to set the video signal format.

Example: Setting the video signal format to “3.58

NTSC”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “INFORMATION”,

then press the PROCEED button.

The “INFORMATION” screen appears.

2. Use the ▲ and ▼ buttons to select “COLOR SYSTEM”,

then press the PROCEED button.

INFORMATION

FREQUENCY

LANGUAGE

COLOR SYSTEM

SEL. RETURN

EXIT

PROCEED

The “COLOR SYSTEM” screen appears.

COLOR SYSTEM

AUTO1:

ADJ. RETURN

EXIT

3. To select “3.58 NTSC” ...

Use the 䊴 and 䊳 buttons to select “3.58 NTSC”.

The mode switches as follows when the 䊴 and 䊳

buttons are pressed:

→ AUTO1 ↔ AUTO2 ↔ 3.58NTSC ↔ 4.43NTSC ←

→ SECAM ↔ PAL-M ↔ PAL-N ↔ PAL60 ↔ PAL ←

COLOR SYSTEM

3.58NTSC:

ADJ. RETURN

EXIT

4. Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once

more.

The color system is set to “3.58 NTSC”.

Information

䡵 Video signal formats

Different countries use different formats for video

signals. Set to the format used in your current country.

AUTO1/2 ......... The video signals are automatically

detected and the format is set

accordingly.

AUTO1: 3.58NTSC, 4.43NTSC, PAL, SECAM,

PAL60

AUTO2: PAL-M, PAL-N, 3.58NTSC

PAL (B, G) ....... This is the standard format used

mainly in the United Kingdom and

Germany.

SECAM............. This is the standard format used

mainly in France and Russia.

4.43 NTSC,

PAL60 .............. This format is used for videos in

countries using PAL and SECAM

video signals.

3.58 NTSC ...... This is the standard format used

mainly in Japan and the United States.

PAL-M ............. This is the standard format used

mainly in Brazil.

PAL-N .............. This is the standard format used

mainly in Argentina.

External Control

Application

These specifications cover the communications control of

the plasma monitor by external equipment.

Connections

Connections are made as described below.

plasma monitor External equipment

e.g., Personal computer

1) Connector on the plasma monitor side: EXTERNAL

CONTROL connector.

Type of connector: D-Sub 9-pin male

No. Pin Name

1 No Connection

2 RXD (Receive data)

3 TXD (Transmit data)

4 DTR (DTE side ready)

5 GND

6 DSR (DCE side ready)

7 RTS (Ready to send)

8 CTS (Clear to send)

9 No Connection

234

2) Connector on the external equipment side: Serial port

(RS-232C) connector.

See the specifications of the equipment that is to be

connected for the type of connector and the pin

assignment.

3) Wiring

Use a crossed (reverse) cable.

Wire the cable so that each pair of data lines cross

between the two devices. These data line pairs are RXD

(Receive data) and TXD (Transmit data), DTR (DTE

side ready) and DSR (DCE side ready), and RTS (Ready

to send) and CTS (Clear to send).

Communication Parameters

(1) Communication system Asynchronous

(2) Interface RS-232C

(3) Baud rate 9600 bps

(4) Data length 8 bits

(5) Parity Odd

(6) Stop bit 1 bit

(7) Communication code Hex

Communication Format

Command 1

Unit ID 1

Unit ID 2

Command 2

Data length

Data

Check sum

8 bit 8 bit 8 bit 8 bit 8 bit 8 bit 8 bit 8 bit

Command 1

Command 1, along with command 2, is a number used to

distinguish each command.

In the case of ACK, when the lower order 4 bits is FH (as

in 3FH and 7FH), this indicates that the commands and

data of the supported equipment have been received. When

the lower order 4 bits is BH (as in 3BH and 7BH), this

indicates that unsupported commands and data have been

received.

Unit ID 1 and Unit ID 2

Unit ID 1 and unit ID 2 are numbers used to identify the

equipment that is to be connected.

60H is used for the plasma monitor and 80H is used for

external control equipment such as a personal computer.

1) Unit ID 1: Indicates the equipment sending the signal

2) Unit ID 2: Indicates the equipment receiving the signal

Command 2

Command 2, along with command 1, is a number used to

distinguish each command.

Check Sum (CKS), Error Processing, and ACK

1) The check sum described below and RS-232C odd

parity are used together for a check of the received data.

The check sum is the lower order 8 bits of one frame of

sent or received data comprising the sum total of

Command 1, Unit ID 1 and 2, Command 2, Data Length,

and Data.

Check Sum Example

DFH 80H 60H 47H 01H 01H 08H

Command 1 Unit ID 1 Unit ID 2 Command 2 Data Length Data Check Sum

Total 208H

▲

2) Error Processing

• When the communication interval is vacant for more

than 4 ms, thereafter a received Command 1 will be

recognized. If, at this time, meaningful data cannot

be recognized, that data will not be recognized (as

valid data).

• An ACK will not be returned unless the receive data

error, the check sum error, and the receive data are all

taken in.

Command Reference List

CMD1 CMD2 LEN

01. Power ON 9FH 4EH 00H

02. Power OFF 9FH 4FH 00H

03. Input Switch Change DFH 47H 01H

04. VOLUME Gain Data DFH 7FH 03H

05. SCREEN MODE Select DFH 51H 01H

06. AUDIO Mute On 9FH 3EH 00H

07. AUDIO Mute Off 9FH 3FH 00H

08. OSM Select DFH 58H 01H

09. Color Gain Data DFH 7FH 03H

10. TINT Gain Data DFH 7FH 03H

11. SHARPNESS Gain Data DFH 7FH 03H

12. CONTRAST Gain Data DFH 7FH 03H

13. BRIGHT Gain Data DFH 7FH 03H

14. Input MODE Request 1FH 41H 00H

15. RESET 1FH 54H 00H

16. COLOR TEMP SELECT DFH 00H 01H

17. RED Gain Data DFH 7FH 04H

18. GREEN Gain Data DFH 7FH 04H

19. BLUE Gain Data DFH 7FH 04H

20. Multi Screen Select DFH 07H 01H

21. VIDEO ADJ Request 1FH 45H 00H

22. Audio Select Set DFH 70H 02H

23. Audio Select Request 1FH 6FH 00H

24. LONG LIFE Set DFH 6BH 03H

25. Failure Mode Request 1FH 3FH 00H

01. Power ON

Function

The external control equipment switches on the power of the plasma monitor.

Transmission Data

9FH 80H 60H 4EH 00H CKS

ACK

The plasma monitor returns the following ACK when the power is switched on.

3FH 60H 80H 4EH 00H CKS

NOTE: Do not set the Power ON or Power OFF command

continuously.

02. Power OFF

Function

The external control equipment switches off the power of the plasma monitor.

Transmission Data

9FH 80H 60H 4FH 00H CKS

ACK

The plasma monitor returns the following ACK when the power is switched off.

3FH 60H 80H 4FH 00H CKS

NOTE: Do not set the Power ON or Power OFF command

continuously.

03. Input Switch Change

Function

The external control equipment switches the input of the plasma monitor.

Transmission Data

DFH 80H 60H 47H 01H DATA00 CKS

DATA00 : Input Select 01H: Video1

02H: Video2

03H: Video3

05H: HD (HD1 or DTV or DTV1)

06H: HD2 (DTV2)

07H: RGB1/PC1

08H: RGB2/PC2

0CH: RGB3/PC3

ACK

The plasma monitor returns the following ACK when the input is switched.

3FH 60H 80H 47H 00H CKS

04. VOLUME Gain Data

Function

The external control equipment changes the VOLUME gain data of the plasma

monitor.

Transmission Data

DFH 80H 60H 7FH 03H

DATA00 DATA01 DATA02 CKS

DATA00 USER SOUND Gain Flag 05H

DATA01 VOLUME Gain Flag 01H

DATA02 VOLUME Gain 00H: Step 0

0AH: Step 10 (Default)

2AH: Step 42

ACK

7FH 60H 80H 7FH 02H

DATA00 DATA01

CKS

DATA00 USER SOUND Gain Flag 05H

DATA01 VOLUME Gain Flag 01H

05. SCREEN MODE Select

Function

The external control equipment switches the screen mode of the plasma monitor.

Transmission Data

DFH 80H 60H 51H 01H DATA00 CKS

DATA00 02H : STADIUM

03H : ZOOM

04H : NORMAL

05H : FULL

06H : TRUE (REAL)

ACK

7FH 60H 80H 51H 01H DATA00 CKS

DATA00 02H : STADIUM

03H : ZOOM

04H : NORMAL

05H : FULL

06H : TRUE (REAL)

Operation

06. AUDIO Mute On

Function

The external control equipment switches on AUDIO Mute of the plasma monitor.

Transmission Data

9FH 80H 60H 3EH 00H CKS

ACK

3FH 60H 80H 3EH 00H CKS

07. AUDIO Mute Off

Function

The external control equipment switches off AUDIO Mute of the plasma monitor.

Transmission Data

9FH 80H 60H 3FH 00H CKS

ACK

3FH 60H 80H 3FH 00H CKS

08. OSM Select

Function

The external control equipment switches on or off the on-screen menu (OSM)

of the plasma monitor.

Transmission Data

DFH 80H 60H 58H 01H DATA00 CKS

DATA00 01H : On-Screen menu On

02H : On-Screen menu Off

ACK

7FH 60H 80H 58H 01H DATA00 CKS

DATA00 01H : On-Screen menu On

02H : On-Screen menu Off

On-Screen menu On/Off is equivalent to the On-screen menu On/Off

function of the convenient function settings.

*Operation is as described in the table below.

09. COLOR Gain Data

Function

The external control equipment changes the COLOR gain data of the plasma

monitor.

Transmission Data

DFH 80H 60H 7FH 03H

DATA00 DATA01 DATA02

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: COLOR Gain Flag 04H

DATA02: COLOR Gain E0H: -32

* COLOR Gain is from -22 (EAH) to

+22 (16H) only during video. FFH: -01

00H: 0

01H: +01

20H: +32

ACK

7FH 60H 80H 7FH 02H

DATA00 DATA01

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: COLOR Gain Flag 04H

10.TINT Gain Data

Function

The external control equipment changes the TINT gain data of the plasma

monitor.

Transmission Data

DFH 80H 60H 7FH 03H

DATA00 DATA01 DATA02

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: TINT Gain Flag 05H

DATA02: TINT Gain E0H: -32

* TINT Gain is from -22 (EAH) to

+22 (16H) only during video. FFH: -01

00H: 0

01H: +01

20H: +32

ACK

7FH 60H 80H 7FH 02H

DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: TINT Gain Flag 05H

On-Screen Menu (OSM)

Display of items and adjustments on the menu

When screen menu is ON

Yes Yes Yes No

Volume display, input display, and screen size display

When screen menu is OFF When screen menu is ON When screen menu is OFF

Remote control operation

Personal computer control operation No No Yes No

11. SHARPNESS Gain Data

Function

The external control equipment changes the SHARPNESS gain data of the

plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H

DATA00 DATA01 DATA02

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: SHARPNESS Gain Flag 06H

DATA02: SHARPNESS Gain F0H: -16

FFH: -01

00H: 0

01H: +01

10H:+16

ACK

7FH 60H 80H 7FH 02H

DATA00 DATA01

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: SHARPNESS Gain Flag 06H

12. CONTRAST Gain Data

Function

The external control equipment changes the CONTRAST gain data of the plasma

monitor.

Transmission Data

DFH 80H 60H 7FH 03H

DATA00 DATA01 DATA02

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: CONTRAST Gain Flag 07H

DATA02: CONTRAST Gain CCH: -52

FFH: -01

00H: 0

01H: +01

14H: +20

ACK

7FH 60H 80H 7FH 02H

DATA00 DATA01

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: CONTRAST Gain Flag 07H

13. BRIGHT Gain Data

Function

The external control equipment changes the BRIGHT gain data of the plasma

monitor.

Transmission Data

DFH 80H 60H 7FH 03H

DATA00 DATA01 DATA02

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: BRIGHT Gain Flag 08H

DATA02: BRIGHT Gain E0H: -32

FFH: -01

00H: 0

01H: +01

20H: +32

ACK

7FH 60H 80H 7FH 02H

DATA00 DATA01

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: BRIGHT Gain Flag 08H

14. Input MODE Request

Function

The display returns the current input information by the external control

equipment’ s request.

Transmission Data

1FH 80H 60H 41H 00H CKS

ACK

7FH 60H 80H 41H 01H DATA00 CKS

DATA00: Input Select

01H: Video1 02H: Video2

03H: Video3 04H: HD (HD1 or DTV or DTV1)

05H: RGB1/PC1 06H: RGB2/PC2

0AH:DVD (DVD1) 0CH:HD2 (DTV2)

0DH:DVD2 0EH:RGB3/PC3

15. RESET

Function

The external control equipment resets the user adjustment of the plasma

monitor.

Transmission Data

1FH 80H 60H 54H 00H CKS

ACK

3FH 60H 80H 54H 00H CKS

16. COLOR TEMP SELECT

Function

The external control equipment changes the COLOR TEMP of the plasma

monitor.

Transmission Data

DFH 80H 60H 00H 01H DATA00 CKS

DATA00

00H: 1

01H: 2

02H: 3

03H: PRO

ACK

7FH 60H 80H 00H 01H DATA00 CKS

DATA00:

00H: 1

01H: 2

02H: 3

03H: PRO

NOTE: Set so that at the selection of 1, 2, or 3 of COLOR TEMP

change of the following R/G/B GAIN data cannot be accepted.

17. RED Gain Data

Function

The external control equipment changes the RED Gain Data of the plasma

monitor.

Transmission Data

DFH 80H 60H 7FH 04H DATA00 to DATA03 CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: RED Gain Flag 01H

DATA02: RED Gain 1 (Bias) D8H: -40

FFH: -1

00H: 0

IEH: +30

DATA03: RED Gain 2 (Drive) D8H: -40

FFH: -1

00H: 0

IEH: +30

ACK

7FH 60H 80H 7FH 02H

DATA00 DATA01

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: RED Gain Flag 01H

18. GREEN Gain Data

Function

The external control equipment changes the GREEN Gain Data of the plasma

monitor.

Transmission Data

DFH 80H 60H 7FH 04H DATA00 to DATA03 CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: GREEN Gain Flag 02H

DATA02: GREEN Gain 1 (Bias) D8H: -40

FFH: -1

00H: 0

IEH: +30

DATA03: GREEN Gain2 (Drive) D8H: -40

FFH: -1

00H: 0

IEH: +30

ACK

7FH 60H 80H 7FH 02H

DATA00 DATA01

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: GREEN Gain Flag 02H

19. BLUE Gain Data

Function

The external control equipment changes the BLUE Gain Data of the plasma

monitor.

Transmission Data

DFH 80H 60H 7FH 04H DATA00 to DATA03 CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: BLUE Gain Flag 03H

DATA02: BLUE Gain1(Bias) D8H:-40

FFH:-1

00H: 0

IEH: +30

DATA03: BLUE Gain2(Drive) D8H: -40

FFH:-1

00H: 0

IEH:+30

ACK

7FH 60H 80H 7FH 02H

DATA00 DATA01

CKS

DATA00: USER PICTURE Gain Flag 01H

DATA01: BLUE Gain Flag 03H

20. Multi Screen Select

Function

The external control equipment selects single screen mode or multi screen

mode of the display.

Transmission Data

DFH 80H 60H 07H 01H DATA00 CKS

DATA00: Multi Screen

00: Single screen

01: Side by side 1 (Left screen bigger)

02: Side by side 2 (Left screen smaller)

03: Picture in Picture sub screen L

04: Picture in Picture sub screen R

ACK

The display returns the following ACK.

7FH 60H 80H 07H 01H DATA00 CKS

DATA00: Multi Screen

00: Single screen

01: Side by side 1 (Left screen bigger)

02: Side by side 2 (Left screen smaller)

03: Picture in Picture sub screen L

04: Picture in Picture sub screen R

When other commands (except POWER OFF) are sent while the screens are

switching with this command, the other command will be returned as “Not

Available” until screen switching is finished.

21. VIDEO ADJ Request

Function

The display returns the video adjustments information by the external control

equipment’s request.

Transmission Data

1FH 80H 60H 45H 00H CKS

ACK

7FH 60H 80H 45H 0CH DATA00 to DATA0B CKS

DATA00: RED Gain(Bias) D8H: -40

FFH: -1

00H: 0

IEH: +30

DATA01: GREEN Gain(Bias) D8H: -40

FFH: -1

00H: 0

IEH: +30

DATA02: BLUE Gain(Bias) D8H: -40

FFH: -1

00H: 0

IEH: +30

DATA03: COLOR Gain E0H: -32

* COLOR Gain is from -22 (EAH) to FFH: -01

+22 (16H) only during video. 00H: 0

01H: +01

20H: +32

DATA04: TINT Gain E0H: -32

* TINT Gain is from -22 (EAH) to FFH: -01

+22 (16H) only during video. 00H: 0

01H: +01

20H: +32

DATA05: SHARPNESS Gain F0H: -16

FFH: -01

00H: 0

01H: +01

10H: +16

DATA06: CONTRAST Gain CCH: -52

FFH: -01

00H: 0

01H: +01

14H: +20

DATA07: BRIGHT Gain E0H: -32

FFH: -01

00H: 0

01H: +01

20H: +32

DATA08: RED Gain(Drive) D8H: -40

FFH: -1

00H: 0

IEH: +30

DATA09: GREEN Gain(Drive) D8H: -40

FFH: -1

00H: 0

IEH: +30

DATA0A: BLUE Gain(Drive) D8H: -40

FFH: -1

00H: 0

IEH: +30

DATA0B: COLOR TEMP 00H: 1

01H: 2

02H: 3

03H: PRO

22. Audio Select Set

Function

The external control equipment sets combinations of audio and video inputs

for the plasma monitor.

Transmission Data

DFH 80H 60H 70H 02H

DATA00 DATA01

CKS

DATA00: AUDIO INPUT

01H: AUDIO 1

02H: AUDIO 2

03H: AUDIO 3

DATA01: VISUAL INPUT

01H: Video 1

02H: Video 2

03H: Video 3

05H: HD (HD1 or DTV or DTV1)

06H: HD2 (DTV2)

07H: RGB 1/ PC 1

08H: RGB 2/ PC 2

0CH: RGB 3/ PC 3

ACK

The plasma monitor returns the following ACK when the input is switched.

3FH 60H 80H 70H 00H CKS

* The plasma monitor returns “Not Available” when selecting the

video input same as the one set at one of the AUDIO 01 to 3.

Example:

The plasma monitor returns “Not Available” when selecting the

VIDEO1 for AUDIO2 or VIDEO3 after VIDEO1 has been set to

AUDIO1.

23. Audio Select Request

Function

The external control equipment inquires the current combinations of audio

and video inputs for the plasma monitor.

Transmission Data

1FH 80H 60H 6FH 00H CKS

ACK

The plasma monitor returns the following ACK:

7FH 60H 80H 6FH 03H

DATA00 DATA01 DATA02

CKS

DATA00: AUDIO 1

01H - 0CH: VISUAL INPUT DATA

DATA01: AUDIO 2

01H - 0CH: VISUAL INPUT DATA

DATA02: AUDIO 3

01H - 0CH: VISUAL INPUT DATA

VISUAL INPUT DATA

01H: Video 1

02H: Video 2

03H: Video 3

05H: HD (HD1 or DTV or DTV 1)

06H: HD2 (DTV2)

07H: RGB 1 /PC 1

08H: RGB 2 /PC 2

0CH: RGB 3 /PC 3

24. LONG LIFE Set

Function

The external control equipment sets the PLE, ORBITER, and INVERSE (inverse

of image brightness) of the plasma monitor.

Transmission Data

DFH 80H 60H 6BH 03H

DATA00 DATA01 DATA02

CKS

DATA00 : PLE

01H: AUTO

02H: LOCK

DATA01 : INVERSE

01H: ON

02H: OFF

03H: WHITE

DATA02 : ORBITER (PICTURE SHIFT)

01H: ON

02H: OFF

ACK

The plasma monitor returns the following ACK when setting the PLE, ORBITER,

and INVERSE (inverse of image brightness):

3FH 60H 80H 6BH 00H CKS

25. Failure Mode Request

Function

The external control equipment inquires the detection of failures of the plasma

monitor.

Transmission Data

1FH 80H 60H 3FH 00H CKS

ACK

The plasma monitor returns the following ACK:

7FH 60H 80H 3FH 02H

DATA00 DATA01

CKS

DATA00: FAILURE MODE 1

Bit 0 : PDP MODULE

0: Abnormal

1: Normal

Bit 1 : 1: fixed (backup)

Bit 2 : TEMPERATURE

0: Abnormal

1: Normal

Bit 3 : FAN

0: Abnormal

1: Normal

Bit 4 : 1: fixed (backup)

Bit 5 : 1: fixed (backup)

Bit 6 : 1: fixed (backup)

Bit 7 : 1: fixed (backup)

DATA01:FILURE MODE 2

Bit 0–7 : 1: fixed (backup)

Screen mode

Table of Signals Supported

Supported resolution

•When the screen mode is NORMAL, each signal is converted to a 1024 dots⳯768 lines signal. (Except for *2, 3, 4)

•When the screen mode is TRUE, the picture is displayed in the original resolution.

•When the screen mode is FULL, each signal is converted to a 1364 dots⳯768 lines signal. (Except for *3)

Computer input signals supported by this system

Dots ⳯ lines

640⳯400

640⳯480

848⳯480

852⳯480*1

800⳯600

1024⳯768

1152⳯864

1280⳯768

1360⳯765

1360⳯768

1376⳯768

1280⳯1024

1600⳯1200

640⳯480

832⳯624

1024⳯768

1152⳯870

1280⳯1024

1152⳯900

1280⳯1024

1024⳯768

1280⳯1024

768⳯576

640⳯480

Vertical

frequency

(Hz)

70.1

59.9

72.8

75.0

85.0

100.4

120.4

60.0

56.3

60.3

72.2

75.0

85.1

99.8

120.0

60.0

70.1

75.0

85.0

100.6

75.0

56.2

60.0

59.9

60.0

75.0

85.0

60.0

65.0

70.0

75.0

66.7

74.6

74.9

75.1

60.0

71.2

72.0

66.0

76.0

76.1

60.0

50.0

59.9

Horizontal

frequency

(kHz)

31.5

37.9

37.5

43.3

51.1

61.3

31.0

31.7

35.2

37.9

48.1

46.9

53.7

63.0

75.7

48.4

56.5

60.0

68.7

80.5

67.5

45.1

47.7

48.3

64.0

80.0

91.1

75.0

81.3

87.5

93.8

35.0

49.7

60.2

68.7

64.6

75.1

78.1

61.8

71.7

81.1

49.7

63.9

31.4

31.5

NORMAL

(4:3)

YES*2

YES

– –

YES

YES*3

YES

– –

YES*4

YES

YES*3

YES

YES*4

YES

YES*4

YES*3

YES*4

YES*7

TRUE

YES

– –

YES

– –

FULL

(16:9)

YES

YES*3

YES

YES*7

RGB

select*5

– –

STILL

– –

STILL

– –

WIDE2

WIDE1

STILL

– –

STILL

– –

STILL

– –

STILL

WIDE1

WIDE2

STILL

– –

MOTION

*Apple

Macintosh*6

Horizontal

NEG

POS

NEG

POS

NEG

POS

NEG

POS

NEG

POS

Sync on G

NEG

– –

C Sync

– –

NEG

Work Station

(EWS4800)

Work Station

(HP)

Work Station

(SUN)

Work Station

(SGI)

IDC-3000G

Signal Type

*IBM PC/AT

compatible

computers

Vertical

NEG

POS

NEG

POS

NEG

POS

NEG

POS

Sync on G

NEG

– –

C Sync

– –

NEG

Sync Polarity Presence

Horizontal

YES

– –

YES

– –

YES

Vertical

YES

– –

YES

– –

YES

PAL625P

NTSC525P

Model DVI

YES

*1 Only when using a graphic accelerator board that is capable of displaying 852⳯480.

*2 This signal is converted to a 1228 dots ⳯ 768 lines signal.

*3 The picture is displayed in the original resolution.

*4 The aspect ratio is 5:4. This signal is converted to a 960 dot⳯768 line signal.

*5 Normally the RGB select mode suite for the input signals is set automatically. If the picture is not displayed properly, set the

RGB mode prepared for the input signals listed in the table above.

*6 To connect the monitor to Macintosh computer, use the monitor adapter (D-Sub 15-pin) to your computer's video port. If

your computer has a mini D-Sub 15-pin connector, you may have to use the RGB cable.

*7 Other screen modes (ZOOM and STADIUM) are available as well.

NOTE:

•While the input signals comply with the resolution listed in the table above, you may have to adjust the position and size

of the picture or the fine picture because of errors in synchronization of your computer.

•When a 1280 dot

⳯

1024 line signal or 1600 dot

⳯

1200 line signal is input to the monitor, the picture will be

compressed.

•This monitor has a resolution of 1365 dot

⳯

768 line. It is recommended that the input signal should be XGA, wide

XGA, or equivalent.

•With digital input some signals are not accepted.

•The sync may be disturbed when a nonstandard signal other than the aforementioned is input.

•If you are connecting a composite sync signal, use the HD terminal.

*“IBM PC/AT” and “VGA” are registered trademarks of IBM, Inc. of the United States.

*“Apple Macintosh” is a registered trademark of Apple Computer, Inc. of the United States.

Symptom

Picture is disturbed.

Sound is noisy.

Remote control operates erroneously.

The remote control does not work.

Monitor’s power does not turn on

when the remote control’s power

button is pressed.

Monitor does not operate when the

remote control’s buttons are pressed.

No sound or picture is produced.

Picture appears but no sound is

produced.

Poor picture with VIDEO signal input.

Poor picture with RGB signal input.

Tint is poor or colors are weak.

Nothing appears on screen.

Part of picture is cut off or picture is

not centered.

Image is too large or too small.

Picture is unstable.

POWER/STANDBY indicator is

lighted in orange or red.

POWER/STANDBY indicator is

blinking in red.

POWER/STANDBY indicator is

blinking in green.

Checks

• Is a connected component set directly in

front or at the side of the display?

• Are the remote control’s batteries worn

out?

• Is the monitor’s power cord plugged into

a power outlet?

• Are all the monitor’s indicators off?

• Are the remote control’s batteries worn

out?

• Is the remote control pointed at the

monitor, or is there an obstacle between

the remote control and the monitor?

• Is direct sunlight or strong artificial light

shining on the monitor’s remote control

sensor?

• Are the remote control’s batteries worn

out?

• The remote cable is plugged into the

REMOTE IN terminal (Wired).

• The front panel buttons of the main unit

do not function.

• Is the monitor’s power cord plugged into a

power outlet?

• Is the volume set at the minimum?

• Is the mute mode set?

• Are the speakers properly connected?

• Is AUDIO INPUT set correctly?

•Improper control setting.

Local interference.

Cable interconnections.

Input impedance is not correct level.

• Improper control setting.

Incorrect 15 PIN connector pin

connections.

• Are the tint and colors properly adjusted?

• Is the computer’s power turned on?

• Is a source connected?

• Is the power management function in the

standby or off mode?

• Is the position adjustment appropriate?

• Is the screen size adjustment

appropriate?

• Is the computer’s resolution setting

appropriate?

• Horizontal and / or vertical sync signal is

not present when the Intelligent Power

Manager control is on.

• The temperature inside the main unit has

become too high and has activated the

protector.

——————

Remedy

• Leave some space between the display and

the connected components.

• Replace both batteries with new ones.

• Plug the monitor’s power cord into a power

outlet.

• Press the power button on the monitor to

turn on the power.

• Replace both batteries with new ones.

• Point the remote control at the monitor’s

remote control sensor when pressing

buttons, or remove the obstacle.

• Eliminate the light by closing curtains,

pointing the light in a different direction, etc.

• Replace both batteries with new ones.

• Unplung the remote cable from the monitor.

• The front panel buttons do not function

during Control Lock.

• Plug the monitor’s power cord into a power

outlet.

• Increase the volume.

•

Press the remote control’s MUTE button.

• Connect the speakers properly.

• Set AUDIO INPUT on the OPTION menu

correctly.

• Adjust picture control as needed.

Try another location for the monitor.

Be sure all connections are secure.

• Adjust picture controls as needed.

Check pin assignments and connections.

• Adjust the tint and color (under “PICTURE”).

• Turn on the computer’s power.

• Connect source to the monitor.

• Operate the computer (move the mouse,

etc.).

• Adjust the “SCREEN” properly.

• Press the “WIDE” button on the remote

control and adjust properly.

• Set to the proper resolution.

• Check the input signal.

• Promptly switch off the power of the main

unit and wait until the internal temperature

drops. See*1.

• Prompty switch off the power of the main

unit. See *2.

*1 Overheat protector

If the monitor becomes too hot, the overheat protector will be activated and the monitor will be turned off. If this happens., turn off the power to the

monitor and unplug the power cord. If the room where the monitor is installed is particularly hot, move the monitor to a cooler location and wait for the

monitor to cool for 60 minutes. If the problem persists, contact your Marantz dealer for service.

*2 In the following case, power off the monitor immediately and contact your dealer or authorized Marantz Service Center.

The monitor turns off 5 seconds after powering on and then the POWER/STANDBY indicator blinks. It indicates that the power supply circuit or, one or

more fans have been damaged.

If the picture quality is poor or there is some other problem, check the adjustments, operations, etc., before requesting service.

Troubleshooting

Specifications

Product Name SLIM SERIES Plasma Monitor

Product Code PD6120D

Screen Size 53.2"(H)⳯29.9"(V) inches

1351(H)⳯760(V) mm

diagonal 61"

Aspect Ratio 16 : 9

Resolution 1365(H)⳯768(V) pixels

Pixel Pitch 0.039"(H)⳯0.039"(V) inches

0.987(H)⳯0.987(V) mm

Color Reproduction 256 levels, 16,770,000 colors

Signals

Synchronization Range Horizontal : 15.5 to 93.8 kHz

(automatic : step scan)

Vertical : 50.0 to 120 Hz

(automatic : step scan)

Input Signals RGB, NTSC (3.58/4.43), PAL (B,G,M,N),

PAL60, SECAM, HD*1 , DVD*1 , DTV*1

Input Terminals

RGB

Visual 1 (Analog) mini D-sub 15-pin⳯1

Visual 2 (Analog) BNC (R, G, B, H/CS, V)⳯1*3

Visual 3 (Digital) DVI-I 29-pin⳯1*2

(Not compatible with analog input)

Video

Visual 1 RCA-pin⳯1

Visual 2 BNC⳯1

Visual 3 S2-Video: DIN 4-pin⳯1

DVD/HD/DTV

Visual RCA-pin (Y, PB[CB], PR[CR])*1

Audio Stereo RCA⳯3(selectable)

External Control D-sub 9-pin⳯1(RS-232C)

Sound output 7W+7W at 6 ohm

Power Supply AC120V 50/60Hz

Current Rating 6.9A (maximum)

Power Consumption 660W (typical)

Dimensions 58.3 (W)⳯35.0 (H)⳯4.7 (D) inches

1480 (W)⳯890 (H)⳯119(D) mm

Weight 134.5 lbs / 61.0 kg

Environmental Considerations

Operating Temperature 0°C to 35°C / 32°F to 95°F

Humidity 20 to 80%

Storage Temperature -10°C to 50°C / 14°F to 122°F

Humidity 10 to 90%

Front Panel User Controls Power on/off, Input source select,

Volume up/down, OSM control

Remote Control Functions

Power on/off, Input source select, OSM

control,Volume up/down, Cursor (UP,

DOWN,LEFT, RIGHT), Pointer, Zoom up/

down, Off timer, Wireless/ Wired remote

control

OSM Functions

Picture (Contrast / Brightness / Sharpness/

Color / Tint / Picture mode / Color

temperature/ Noise reductions), Sound (Bass

/ Treble/ Balance),Screen (V-Position / H-

Position/ V-Height / H-Width /Auto Picture

/ Fine picture/ Picture adjustment), Function

(OSM/ OSM adjustment/ Power

management/ Gray level/ Cinema mode/

RGB3 Adjustment, Long Life (PLE, Orbiter,

Inverse, White)/ Reset)/Option (Audio input/

BNC select/ RGBselect/ HD select/ Picture

Size), Information (Frequency / Language /

Color system)

The features and specifications may be subject to change without

notice.

*1HD/DVD/DTV input signals supported on this

system

480P (60 Hz) 480I (60 Hz)

525P (60 Hz) 525I (60 Hz)

625P (50 Hz) 625I (50 Hz)

720P (60 Hz) 1035I (60 Hz)

1080I (60 Hz)

*2It doesn’t cope with copy protection.

*3A change of DVD2/HD2 can be performed with

RGB2.

Other Features 3D motion adaptive Scan Converter

(with 2-3 pull down Converter),

Digital Zoom function

(100-300% Selectable) (Tentative),

Self Diagnosis, Anti Image Burn,

Color Temperature Select, Control Lock,

Power management, Plug and play

(DDC1, DDC2b, RGB3: DDC2b only),

Multi screen operation

Accessories Remote control with two AAA batteries,

Power cord, User’s Manual, Safety metal

fittings, Ferrite cores, Bands

Regulations UL Approved (UL 1950/ CSA 950)

DOC Canada requirements

Meets FCC class A requirements

Units are in inch

(mm)

4.7"

(119)

1.8"

(45) 2.9"

(74)

58.3" (1480)

35.0" (890)

53.9" (1380)

30.7" (790)

Printed in Japan 06/2001 MITar 02AW851210

COUNTRY COMPANY ADDRESS

ALGERIE Azur 2000 8, Lotissement Ben Hatadi, Alger, Algerie

ARMENIA NGYIG Ltd. 47 A/75 St. Lalaiants, 375000 Yerevan, Armenia

AUSTRALIA Jamo Australia Pty. Ltd., 24 Lionel Road, Mt. Waverley, VIC 3149, Australia

AUSTRIA Huber & Prohaska GmbH Taborstraße 95 / Ladestraße 1, Gebäude Hangartner, A-1200 Wien, Austria

BAHREIN Ambassador Stores P.O. Box 237,141, Government Avenue, Manama,Bahrein

BANGLADESH Target 1078, Ramjoy Mohanja Lane Asadgonj, Chittagong 4000, Bangladesh

BELGIUM Van der Heyden Audio N.V. Brusselbaan 278, 9320 Erembodegem, Belgium

BULGARIA Ariescommerce GmbH Makedonia Blvd. 16, 1606 Sofia, Bulgaria

CANADA Lenbrook Industries Limited 633 Granite Court, Pickering, Ontario

CHINA

Guang Chang Audio International Co., Ltd.

No.38 Yushan Road, ShiQiao, Pan Yu, Guang Dong, China

CYPRUS Empire Hifi systems Ltd. P.O. Box 5604, Nicosia, Cyprus

CZECH REPUBLIC Audio International Sokolska 41, 67902 Rajecko, OKR,Blansko, Czech Republic

DENMARK Audio Nord Dali Allé 1, 9610 Noerager, Denmark

DUBAI V.V.& SONS P.O. Box 105, Dubai, U.A.E.

EGYPT Solimco 9, El Attibaa St. Doki, Cairo, Egypt

ESTONIA HiFi Club Estonia Ehte 4, 90503 Haapsalu, Estonia

F.Y.R.O.M. T.P. KODI ul.Cedomir Kantargiev 21a, Skopje, Former Yugoslavian Republic of Macedonija

FINLAND Audio Nord Uudenmaankatu 4-6, Helsinki SF-00120, Finland

FRANCE Marantz France A division of Marantz Europe B.V., P.O. Box 301, 92 156 Suresnes Cedex, France

GERMANY Marantz Deutschland Hakenbusch 3, 49078 Osnabrück, Germany

GREECE Adamco S.A. 188, Hippocratous Street, 11471 Athens, Greece

HEADQUARTERS EUROPE: Marantz Europe B.V. Building SFF-2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands

HONG KONG Marantz Asia Ltd. Unit 1706, Metroplaza II, 223 Hing Fong Road, Kwai Fong, N.T., Kowloon, Hong Kong

HUNGARY Infovox Ltd. Terez Krt.31, 1067 Budapest, Hungary

ICELAND ID Electronics Ltd. Armula 38, 108 Reykjavik, Iceland

INDIA NOVA Audio Private 8,Punam Co-op.Society 29/30 Road#5, Union Park MUMBAI 400052, India

IRAN Home Co. 5th floor no 878 Philips Building Enghelab ave, P.O. 11365/7844 Tehran, Iran

IRELAND Marantz Ireland Clonskeagh, Dublin 14, Ireland

ISRAEL Elmor Ltd. 52 Heh Beiyar Street, Kikar Hamedina, Tel Aviv, Israel

ITALY Marantz Italy Via Casati 23, 20052 Monza (Milano), Italy, Servizio Consumatori 1678-20026, Numero Verde

IVORY COAST Hifivoir B.P. 2428, Abidjan 01, Ivory Coast

JAPAN Marantz Japan Inc. 35-1 Sagami Ohno 7-Chome, Sagamihara-shi, Kanagawa 228-8505, Japan

KOREA Mk Enterprises Ltd. 121-210, 2F Shinhan Bldg., 247-17 Seokyo-dong, Mapo-ku, Seoul, Korea

KUWAIT alAlamiah Electronics Intl. P.O. Box 8196, Salmiah 22052, Kuwait

LATVIA Ace Ltd. 61, LacPlesa Str., Riga LV 1011, Latvia

LEBANON AZ Electronics S.A., 1, P.O. Box 11 2833, Beirut, Lebanon

LITHUANIA Accapella Ltd. Ausros, Vartu G/5, Pasazo SKG., 2001 Vilnius, Lithuania

MALAYSIA Wo Kee Hong Electronics Sdn. Bhd. Suite 8.1, Level 8, Menara Genesis, No. 33, Jalan Sultan Ismail, 50250 Kuala Lumpur, Malaysia

MALTA Doneo Co Ltd. 78 The Strand, Sliema SLM07, Malta

MAURITIUS SKR Electronics Ltd. P.O. Box 685, Bell Village, Port Louis, Mauritius

MILITARY MARKET EUROPE PASCO GmbH PO BOX 1280, Sandhausen 69200, Germany

NETHERLANDS Marantz Domestic Sales

A division of Marantz Europe B.V., Building SFF2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands

NEW ZEALAND Wildash Audio Systems 14 Malvern Road, Mt. Albert, Auckland, New Zealand

NORWAY Audio Nord Sandkerveien 64, Oslo 0483, Norway

OMAN Mustafa & Jawad Trading CO. P.O. Box 1918, Ruwi, Oman

POLAND Philips Polska Sp. z.o.o. Al.Jerozolimskie 195b, 02 222 Warszawa, Poland

PORTUGAL Corel2 Comércio de Electrónica Lda., Av. Luís Bívar, No 85 A, 1050 Lisboa, Portugal
