Commercial
Security
Price List
Effective January 2, 2017
Master Lock offers the widest range of high quality,
customizable, security products available.
Businesses and facilities have security needs that require strong, durable products with the ability to adapt to
unique applications as well as multiple users. Master Lock continues to expand its commercial products and
services to provide customers security solutions for all security points. And, all products are backed by our
dedicated Customer Service and Sales teams.
MAKE-TO-ORDER CAPABILITY
SECURITY PRODUCTS BUILT AND KEYED TO
YOUR REQUIREMENTS
SHACKLE OPTIONS
Choose different shackle materials and
extra length shackles
KEYING FLEXIBILITY
Over 60 padlock, door hardware and
interchangeable core keyways available
Choose keying – KD, KA, MK, GMK
CHOOSE CUSTOM MARKING
Laser engraving, hard stamping and
pad printing
SERVICE PARTS
Support for dealers
EDGE® KEY CONTROL
Prevents unauthorized
duplication of keys
ADVANCED CYLINDER
TECHNOLOGY
Excellent protection against
lock bumping
1
2
3
Dept. 502
Customer Service
& Sales Support
1-800-308-9242
Over 75 dedicated and
knowledgeable employees
ready to serve you.
Online Resources
MasterLock.com
MasterLockShop.com
masterlock.net
BuildYourLock.com
MasterLockImages.com
24/7 On-Line
Ordering &
Quoting Resource*
MasterLockShop.com
Accurately enter orders,
validate key numbers
and create laser
engraved orders.
* A Master Lock account number is required
to use this system. No minimum order size.
1
TERMS OF SALE
MASTER LOCK COMPANY TERMS OF SALE – EFFECTIVE JANUARY 2017
All orders are subject to acceptance by Master Lock Company LLC, Milwaukee, Wisconsin, USA
PRICES:
All prices are stated in US dollars ($).
Orders are subject to prevailing prices on order acceptance date.
10% will be added for less than Master Carton quantities per customer
program.
MINIMUM ORDER:
US$50 on all catalog items except parts and keys.
ADDITIONS/CHANGES:
Once your order has been processed, additions, cancellations or
changes may not be accepted. A separate order may be required.
Items are subject to discontinuation without notice.
FREIGHT TERMS:
All shipments within the US and Canada are FOB destination.
Shipments to Alaska or Hawaii will be to US port of exit (Seattle or Los Angeles)
Master Lock Company will pre-pay freight charges on all orders over
US$1,000 (based on net prices) to a single destination within the
contiguous United States or Canada.
Orders destined to Alaska or Hawaii ship prepaid to the customer’s
designated freight forwarder in either Seattle or Los Angeles.
Freight charges on orders less than US$1,000 (net) will be shipped on a
Prepay & Add basis. Freight charges will be added to the customers invoice.
Master Lock Company reserves the right to select both the carrier and
mode of transport when shipping on a Prepaid or Prepay & Add basis.
Customer is responsible for any charges in excess of normal
transportation that result from services requested by the receiving party.
For an International Shipment that is a Routed-Transaction – the
Buyers [consignee’s] freight forwarder is responsible for export
 clearanceandAESling.
CLAIMS:
You must report any claims for shortages or damages for which Master
Lock Company or our freight carriers are responsible within 30 days of
receipt of merchandise.
Receivers must note visible discrepancies on the carriers copy of the
delivery receipt in order for the claim to be considered valid. Visible
discrepancies include, but are not limited to, open, torn, crushed or
water damaged cartons, piece counts that do not match the delivery
receipt, etc.
Master Lock Company uses yellow stretch-wrap. If freight is received
with stretch-wrap that is clear or any other color, it should be noted on
carriers copy of the delivery receipt.
 Concealeddamagesmustbereportedwithinvebusinessdaysof
receipt of merchandise in order to determine liability.
 Allcarriers’claimsonPrepaid(orPrepay&Add)shipmentsareledby
Master Lock Company.
RETURNED GOODS:
No merchandise may be returned without authorization from Master
Lock Company.
All returns must have a Returned Material Authorization (RMA) Number
issued by Master Lock Company Customer Care.
The RMA must be shown on all labels and correspondence with regards
to returned merchandise.
All returns must be prepaid and returned within 30 days of authorization
in order to receive credit.
A minimum 15% handling charge will be assessed on authorized
returns.
Returns received without prior authorization (RMA Code) may be
returned to the customer.
Returns will not be authorized for custom “Made To Order (MTO)”
 productsand/orproductsbuilttoaspeciccustomerrequirementsuch
as laser engraved, master keyed, or keyed alike products.
LIMITED LIFETIME WARRANTY:
If this product or any part of the product fails due to a defect in materials
or workmanship at any time during the life of the product, Master Lock
Company LLC (“Master Lock”) will repair or replace the product or
part free of charge. Simply contact Master Lock at
www.masterlock.com or 1.800.464.2088 for instructions on obtaining
repair or replacement. Canadian customers please call 1.800.227.9599.
This limited warranty applies only to defects in materials and
workmanship, and does not cover products which have been
abused, altered, damaged, misused, cut or excessively worn.
TO THE EXTENT PERMITTED BY LAW, MASTER LOCK DISCLAIMS
ALL OTHER IMPLIED OR EXPRESS WARRANTIES INCLUDING
ALL WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR
A PARTICULAR PURPOSE.
This limited warranty is your sole and exclusive remedy and MASTER
LOCK shall not be liable for any damages, whether direct, indirect,
incidental, special, consequential, exemplary, or otherwise, including
 propertydamage,lostrevenuesandlostprots,arisingoutofany
theory of recovery, including statutory, contract or tort.
 Thislimitedwarrantygivesyouspeciclegalrights,andyoumay
also have other rights which vary from state to state and province
to province.
For complete warranty details please visit www.masterlock.com.
Orders may be placed via Electronic Data Interchange (EDI), online ordering at www.masterlockshop.com, facsimile to 1-800-308-9245 or e-mail
at orders@mlock.com. Telephone orders may also be placed by calling Master Lock Company Customer Care at 1-800-308-9242 or 1-800-308-9244.
To best assure order accuracy and validate information, we reserve the right to require a hard copy of an order prior to processing a phone request.
Orderconrmationisavailableviae-mailorfax.
For convenience, online order tracking is available 24 hours a day at www.masterlock.net.
Please contact our Customer Care Team for details.
When Ordering Products, Please:
A. Indicate your customer account number, billing address (including zip code), contact name, phone and fax numbers.
B. Specify complete model number, quantity, and price.
C. Be sure to specify key number if needed.
D. Order by units listed, such as each lock or package of service parts.
E. Indicate color of lock if applicable, (i.e., 6835GRN).
F. When ordering combination locks for schools or institutions, indicate name and location address (including zip code) of end user.
G. When ordering laser engraving, indicate clearly which areas of the padlock to engrave. All engraving requests must be accompanied
by a fully completed laser layout sheet.
Customer Care Hours: Weekdays 7:30 a.m. to 5:00 p.m. Central Standard Time (C.S.T.). Orders may be faxed or emailed 24 hours a day. All orders
received weekdays by 3:00 p.m. C.S.T. will be entered the same day.
EDI
Master Lock Company is able to accept purchase orders, transmit invoices and Advance Ship Notices (ASN), and receive forecast and Point of Sale (POS) data via EDI.
Master Lock Company utilizes the ANSI X.12 standards. For more information on EDI, contact your Master Lock Company Sales or Customer Care Representative.
How To Order
2
PRICE BOOK CONTENTS
TERMS OF SALE .....................................................1
ORDERING INFORMATION .....................................1
SPEED INDEX ..........................................................3
BUMPSTOP® ADVANCED CYLINDER
TECHNOLOGY ...................................................6
Pro Series® Rekeyable Padlocks ..........................7
Hidden Shackles Padlocks .........................8
Solid Iron Shrouded Padlocks .....................9
Solid Steel Padlocks .................................10
Weather Tough® Padlocks ........................11
Solid Brass Padlocks ................................12
Solid Aluminum Padlocks ..........................13
Door Key Compatible Cylinders & Padlocks ......14
Solid Iron Shrouded Padlocks ...................15
Solid Steel Padlocks .................................16
Weather Tough® Padlocks ........................17
Solid Brass Padlocks ................................18
Interchangeable Cores & Padlocks ..................... 19
Solid Iron Shrouded Padlocks ...................20
Solid Steel Padlocks .................................21
Weather Tough® Padlocks ........................22
Solid Brass Padlocks ................................23
Pro Series® Resettable Combination Padlocks .. 24
Rekeyable Padlocks ..............................................25
Die Cast Zinc Padlocks .............................26
Laminated Steel & Brass Padlocks ...........27
Non-Rekeyable Padlocks ......................................28
Commercial Magnum Padlocks ................29
Laminated Steel & Brass Padlocks ...........30
Covered Laminated Steel Padlocks ..........34
Shrouded Laminated Steel Padlocks ........34
Vending & Meter Padlocks ........................35
Universal Pin Padlocks & Accessories .....36
Shrouded Padlocks ................................... 36
Combination Padlocks ..............................37
Warded Padlocks ...................................... 39
Economy Brass Padlocks .........................40
Python® Adjustable Locking Cables ...................41
King Pin Locks .....................................................42
SAFESPACE® Storage Security
Key Cabinets .............................................43
Lock Boxes ................................................44
Cash & Document Storage .......................45
Key Case ...................................................46
Hasps ...................................................................47
Padlock Eyes & Hasplocks .................................48
Product Displays ..................................................49
Government Locks ...............................................50
Services .................................................................51
Service Parts & Accessories ...............................52
Padlock Cylinders .....................................52
Duplicate Keys ..........................................53
Key Blanks ................................................54
Lock Lubricant ...........................................55
Service Parts .............................................56
3
SPEED INDEX
Product
Number Page
Number Shelf Pack
Quantity Master Carton
Quantity List Price
(Each)
1 32 6 24 $11.79
1KA 32 6 24 $12.84
1LF 32 6 24 $13.49
1LJ 32 6 24 $13.89
1LN 32 6 24 $17.79
1UP 36 6 24 $12.80
1UPLJ 36 6 24 $14.90
2 32 6 24 $16.14
2KA 32 6 24 $17.19
2LF 32 6 24 $17.84
2LJ 32 6 24 $18.24
2LN 32 6 24 $22.14
3 33 6 24 $10.26
3KA 33 6 24 $11.31
3LF 33 6 24 $11.96
3LH 33 6 24 $13.16
3UP 36 6 24 $11.15
3UPLF 36 6 24 $12.85
4 33 6 24 $13.79
4KA 33 6 24 $14.84
4LF 33 6 24 $15.49
4LH 33 6 24 $16.69
5 31 6 24 $14.98
5KA 31 6 24 $16.03
5LF 31 6 24 $16.68
5LJ 31 6 24 $17.08
5UP 36 6 24 $16.21
5UPLF 36 6 24 $17.91
6 31 6 24 $20.05
6KA 31 6 24 $21.10
6LF 31 6 24 $21.75
6LJ 31 6 24 $22.15
7 35 6 24 $8.16
7KA 35 6 24 $9.21
7LF 35 6 24 $9.86
7LJ 35 6 24 $10.26
8 35 6 24 $11.14
8KA 35 6 24 $12.19
8LF 35 6 24 $12.84
8LJ 35 6 24 $13.24
10D 39 4 24 $3.00
10KA 39 12 144 $3.93
11 33 6 24 $13.04
11KA 33 6 24 $14.09
11LF 33 6 24 $14.74
11LH 33 6 24 $15.94
15 30 6 24 $26.72
15KA 30 6 24 $27.77
15LH 30 6 24 $29.62
17 31 6 24 $19.77
17KA 31 6 24 $20.82
17LH 31 6 24 $22.67
21 27 6 24 $17.24
21KA 27 6 24 $18.29
21LF 27 6 24 $18.94
21LJ 27 6 24 $19.34
21LN 27 6 24 $23.24
22 39 12 72 $4.00
NOTE: Speed Index does not include all products. See individual product pages for complete listing.
Product
Number Page
Number Shelf Pack
Quantity Master Carton
Quantity List Price
(Each)
22D 39 4 24 $4.00
22KA 39 12 72 $4.90
22KALF 39 6 36 $6.60
22T 39 4 16 $7.21
24 27 6 24 $22.62
24KA 27 6 24 $23.67
24LF 27 6 24 $24.32
24LJ 27 6 24 $24.72
24LN 27 6 24 $28.62
25 27 6 24 $20.68
25KA 27 6 24 $21.73
25LF 27 6 24 $22.38
25LJ 27 6 24 $22.78
27 27 6 24 $23.62
27KA 27 6 24 $24.67
27LH 27 6 24 $26.52
31 33 6 24 $12.97
31KA 33 6 24 $14.02
31LF 33 6 24 $14.67
31LH 33 6 24 $15.87
37 34 6 24 $15.29
37KA 34 6 24 $16.34
40KADPF 36 6 36 $17.30
60 48 12 72 $3.32
60R 48 6 72 $3.75
81 32 6 24 $16.47
81KA 32 6 24 $17.52
81LF 32 6 24 $18.17
81LJ 32 6 24 $18.57
81LN 32 6 24 $22.47
82 32 6 24 $20.90
82KA 32 6 24 $21.95
82LF 32 6 24 $22.60
82LJ 32 6 24 $23.00
82LN 32 6 24 $26.90
101 27 5 20 $31.92
101KA 27 5 20 $32.97
105D 39 4 24 $3.83
105KA 39 12 72 $4.73
175 37 6 36 $22.34
175LH 37 6 36 $25.33
175LHSS 37 6 36 $29.44
176 37 6 36 $24.74
176KA 37 6 36 $25.79
176KALH 37 6 36 $28.69
176LH 37 6 36 $27.64
178BLK 37 6 36 $14.39
207D 46 4 24 $2.53
220 28 5 30 $24.88
220KA 28 5 30 $25.93
220LH 28 5 20 $27.78
230 28 5 20 $28.85
230KA 28 5 20 $29.90
230LH 28 5 20 $31.75
291 55 — 1 $87.99
311 34 6 24 $12.51
312 34 6 24 $12.51
312KA 34 6 24 $13.56
4
SPEED INDEX
Product
Number Page
Number Shelf Pack
Quantity Master Carton
Quantity List Price
(Each)
315 34 6 24 $12.51
317 34 6 24 $14.58
376 36 36 $54.78
387 42 1 $131.49
387KA 42 1 $132.54
388 42 1 $137.20
388KA 42 1 $138.25
443 35 6 24 $13.40
443KA 35 6 24 $14.45
443LE 35 6 24 $13.65
443LK 35 6 24 $16.40
450D 48 4 24 $14.22
500 39 12 72 $4.82
500D 39 4 24 $4.82
500KA 39 12 72 $5.69
500KABRK 39 12 72 $6.87
500KABRKLH 39 12 72 $9.78
500KABRKLN 39 12 72 $13.06
510D 39 4 24 $7.59
510KAD 39 4 24 $8.42
517D 39 4 24 $8.03
517KAD 39 4 24 $8.83
720DPF 47 4 24 $10.43
721DPF 47 4 24 $14.57
722DPF 47 4 24 $11.86
730 47 6 24 $10.93
731 47 6 24 $10.49
732 47 6 24 $12.29
770 47 12 $27.57
770LHC 8/47 — 6 $59.57
878 37 6 36 $15.83
975 37 6 36 $24.57
975LH 37 6 36 $27.86
1174 24 4 24 $37.10
1175 24 4 24 $26.81
1175LH 24 4 24 $30.40
1175LHSS 24 4 24 $31.07
1175LHRS 24 4 24 $30.40
1175RS 24 4 24 $26.81
1177 24 4 24 $30.32
1178 24 4 24 $15.25
1314 49 — $158.84
1315 49 — $277.68
1316 49 — $654.18
1500 38 12 72 $7.24
1500KA 38 12 72 $8.29
1500LF 38 6 36 $8.94
1500LH 38 6 36 $10.14
2001 38 6 24 $23.10
2001KA 38 6 24 $24.15
2300D 55 — 12 $5.47
2305 55 12 $10.57
2311 55 12 $13.74
3009D 39 4 16 $11.98
3630 38 25 $91.26
3630-0320 38 — $5.62
3631 38 25 $91.26
Product
Number Page
Number Shelf Pack
Quantity Master Carton
Quantity List Price
(Each)
3633LEF 38 — $17.53
3633LES 38 — $17.53
3634LEF 38 — $21.67
3634LES 38 — $21.67
3670 38 25 $91.26
3870 42 1 $140.33
3870KA 42 1 $141.38
4120 40 12 72 $2.52
4120KA 40 12 72 $3.57
4130 40 12 72 $3.77
4130KA 40 12 72 $4.82
4130KALF 40 12 72 $7.07
4130KALJ 40 12 72 $6.92
4140 40 12 72 $5.05
4140KA 40 12 72 $6.10
4140KALH 40 12 72 $9.00
4140LH 40 12 72 $7.95
4150 40 6 72 $7.58
4150KA 40 6 72 $8.63
4150KALJ 40 6 72 $10.73
4150LJ 40 6 72 $9.68
5400D 44 — 4 $39.63
5401D 45 — 4 $37.16
5406D 44 2 4 $24.53
5408D 44 4 16 $13.34
5422D 45 — 4 $42.10
5423D 45 — 4 $39.47
5424D 44 — 4 $52.83
5425D 44 — 4 $49.53
6121 11 6 24 $25.74
6121KA 11 6 24 $26.79
6121LF 11 6 24 $27.99
6121LJ 11 6 24 $28.49
6121LN 11 6 24 $31.74
6125 11 6 24 $29.87
6125KA 11 6 24 $30.92
6125LJ 11 6 24 $32.22
6127 11 6 24 $34.76
6127KA 11 6 24 $35.31
6127LH 11 6 24 $37.11
6127LJ 11 6 24 $37.21
6230 10 6 24 $32.96
6230KA 10 6 24 $34.01
6230LH 10 6 24 $36.36
6271 8 12 $33.20
6271KA 8 12 $34.25
6321 9 6 24 $35.39
6321KA 9 6 24 $36.44
6325 9 6 24 $41.87
6325KA 9 6 24 $42.92
6327 9 6 24 $48.28
6327KA 9 6 24 $49.33
6421WO series 22 6 24 $29.45
6421LFWO series 22 6 24 $31.70
6421LJWO series 22 6 24 $31.90
6421LNWO series 22 6 24 $35.45
6427WO series 22 6 24 $41.11
NOTE: Speed Index does not include all products. See individual product pages for complete listing.
5
SPEED INDEX
Product
Number Page
Number Shelf Pack
Quantity Master Carton
Quantity List Price
(Each)
6427LHWO series 22 6 24 $43.46
6427LJWO series 22 6 24 $43.56
6521WO series 20 6 24 $42.07
6527WO series 20 6 24 $58.77
6621WO series 17 6 24 $26.57
6621LFWO series 17 6 24 $28.82
6621LJWO series 17 6 24 $29.02
6621LNWO series 17 6 24 $32.57
6627WO series 17 6 24 $38.36
6627LHWO series 17 6 24 $40.71
6627LJWO series 17 6 24 $70.82
6721WO series 15 6 24 $39.18
6727WO series 15 6 24 $55.87
6830 12 6 24 $19.57
6830KA 12 6 24 $20.62
6830LF 12 6 24 $21.82
6830LT 12 6 24 $22.12
6831WO series 23 6 24 $20.70
6831LFWO series 23 6 24 $22.95
6831LTWO series 23 6 24 $23.25
6835 series 13 6 24 $13.65
6835KA series 13 6 24 $14.70
6835LF series 13 6 24 $15.90
6835LT series 13 6 24 $16.20
6840 12 6 24 $23.12
6840KA 12 6 24 $24.17
6840LF 12 6 24 $25.37
6840LJ 12 6 24 $25.57
6840LN 12 6 24 $29.12
6841WO series 23 6 24 $23.48
6841LFWO series 23 6 24 $25.73
6841LJWO series 23 6 24 $25.93
6841LNWO series 23 6 24 $29.78
6842WO series 18 6 24 $17.73
6842LFWO series 18 6 24 $19.98
6842LJWO series 18 6 24 $20.18
6842LNWO series 18 6 24 $23.73
6850 12 6 24 $26.31
6850KA 12 6 24 $27.36
6850LJ 12 6 24 $28.76
6851WO series 23 6 24 $27.78
6851LJWO series 23 6 24 $30.23
6852WO series 18 6 24 $22.24
6852LJWO series 18 6 24 $24.69
7030 10 6 24 $19.64
7030KA 10 6 24 $20.69
7030LF 10 6 24 $21.89
7030LT 10 6 24 $22.19
7031WO series 21 6 24 $21.87
7031LFWO series 21 6 24 $24.12
7031LTWO series 21 6 24 $24.42
7035 10 6 24 $37.16
7035KA 10 6 24 $38.21
7036WO series 21 6 24 $38.99
7040 10 6 24 $21.65
7040KA 10 6 24 $22.70
Product
Number Page
Number Shelf Pack
Quantity Master Carton
Quantity List Price
(Each)
7040LF 10 6 24 $23.90
7040LJ 10 6 24 $24.10
7040LN 10 6 24 $27.65
7041WO series 21 6 24 $24.23
7041LFWO series 21 6 24 $26.48
7041LJWO series 21 6 24 $26.68
7041LNWO series 21 6 24 $30.23
7042 16 6 24 $18.94
7042LJWO series 16 6 24 $21.39
7042LNWO series 16 6 24 $24.94
7045 10 6 24 $38.39
7045KA 10 6 24 $39.44
7046WO series 21 6 24 $41.85
7047WO series 16 6 24 $34.91
7050 10 6 24 $25.66
7050KA 10 6 24 $26.71
7050LJ 10 6 24 $28.11
7051WO series 21 6 24 $28.76
7051LJWO series 21 6 24 $31.21
7052WO series 16 6 24 $22.19
7052LJWO series 16 6 24 $24.64
7101D 43 4 $35.10
7113D 45 4 $14.81
7116D 43 — 10 $6.90
7120D 46 — 6 $25.18
7122D 43 — 4 $54.26
7123D 43 — 4 $90.36
7125D 43 — 4 $91.01
7126D 43 4 $147.02
7127D 43 2 $247.70
7128D 43 2 $295.97
7129 43 1 $470.15
7130 43 1 $620.46
7131D 43 — 4 $17.88
7132D 43 — 4 $36.33
7143D 45 4 $15.88
7147D 45 3 $35.10
7149D 46 2 $42.33
8413CBL6 41 — 6 $28.05
8413DPF 41 — 6 $29.85
8413KACBL6 41 — 6 $29.10
8417DPF 41 — 4 $14.39
8418DPF 41 — 4 $20.00
8418KADCAMO-TMB
41 — 4 $24.33
8419DPF 41 — 4 $20.00
8428DPS 41 — 6 $29.85
8433DAT 41 4 16 $28.70
K3630 38 — $3.99
MLLOCKSIGN
49 — $0.00
M1STS
29 6 24 $17.98
M5STS
29 6 24 $14.25
Display Boards &
Accessories 49
Government Locks 50
Service Parts 52-60
NOTE: Speed Index does not include all products. See individual product pages for complete listing.
6
Lock Bumping –
Lock Bumping has become a legitimate security threat as
information on the topic has become widely exposed in the news
media and on the internet.
In response to this threat, Master Lock Company have developed
our exclusive patent-pending BumpStop® Advanced Technology
that prevents the transfer of force from the bump key to the pins
and blocks rotation of the cylinder. With a reverse rake tapered
driver pin, high performance spring and precision tolerance
chamber, our 4, 5 and 6-pin BumpStop® products exceed the
ASTM F883-09 Standard for Grade 6 lock bumping resistance.
BumpStop® is available in a full range of American Lock padlocks and security products today!
Model Number Option: N List price adder: $1.05
For more details, see www.bumpstopsecurity.com or call your Master Lock Customer Service Representative today.
Advanced Cylinder Technology
BUMPSTOP® ADVANCED CYLINDER TECHNOLOGY
Reverse Rake
Tapered
Driver Pin
High
Performance
Spring
Precision
Cylinder
Chamber
7
High Security
– Solid Iron Shroud
Heavy steel bodies
withstand physical
attacks
Iron shroud protects
shackle from cutting
and prying
Hardened boron alloy shackles for superior cut resistance
Dual ball bearing locking mechanism resists pulling and prying
High security cylinder
5-pin & 6-pin cylinders provide tens of thousands of key changes
Spool pins are virtually impossible to pick
Rekeyable – replaceable cylinder and shackle
7045
7050
7030
770
6271
6325
6327
Pro Series® Rekeyable Padlocks
High Security – Solid Steel
Heavy case hardened steel body
Chrome rustproofing
provides longer life
Shrouded models protect
against bolt cutters
and prying
Hidden Shackle Padlocks
Ideal for vans, trucks, gates and vending
Greatest physical security - defy bolt cutters
and prying
Die cast body reinforced with anti-saw pins
(No. 6271)
High Security Hasp available for Hidden
Shackle Lock (Model 6271)
Weather Tough®
Ideal for harsh outdoor conditions
Exclusive cover protects lock from water, ice,
dirt and grime
Heavy duty steel bodies withstand physical
attacks
Keyway cover keeps out dust and dirt
Optional brass shackles available for increased
corrosion resistance
6127
6121
6850 6830
Solid Brass
Body provides extra corrosion resistance
in caustic, corrosive salty environments
Optional brass shackles
available for increased
corrosion resistance
Solid Aluminum
Brightly colored locks for easy
identification
Ideal for corrosive environment
Spark resistant
6835
8
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Pro Series® Rekeyable Padlocks — Hidden Shackle Products
Example 6271 KA WP6
$
44.05
Base Model
Description Price/ea.
6271 2-7/8in (73mm) wide Reinforced Die Cast body, Boron Shackle, A = 3/8in (9mm) dia.,
B = 1-9/32in (15mm), C = 1-23/32in (43mm) –
Shelf Pack = NA, Master Carton = 12
$
33.20
770LHC
2-7/8in (73mm) 6271 Die Cast Padlock and 770 Steel Hasp
Shelf Pack = NA, Master
Carton = 6
$59.57
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology
(Not available with WO & WCS Option or UN & KZ Option)
$1.05
Keying
Standard: Keyed Different
UN
Uncombinated
(Zero bitted cylinder & no keys)
-
Available with WP6 & WP4 options
only
–$4.00
KZ
Zero-Bitted (Not Available with WP option) $0.00
KA
Keyed Alike $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Cylinder
Standard:
6-pin W7000 cylinder
WCS Lock Body only –$5.50
W6000 5-pin W6000 cylinder $0.00
W600A 5-pin American Lock® W600A cylinder (Available as KA & KZ only) $0.00
W700A 6-pin American Lock® W700A cylinder (Available as KA & KZ only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
WP6 Edge® Key Control 6-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
K6000
W6000
Exceeds ASTM F883-09
Grade 6
9
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Pro Series® Rekeyable Padlocks — High Security – Solid Iron Shroud
Example 6327 KAMK NR W7000 LZ1 1KEY
$
55.28
Base Model
Description Price/ea.
6327 2-5/8in (67mm) wide body with Boron shackle, A = 7/16in (11mm) dia., B = 3/4in (19mm),
C = 7/8in (22mm)
$48.28
6325 2-3/8in (61mm) wide body with Boron shackle, A = 3/8in (10mm) dia., B = 3/4in (19mm),
C = 7/8in (22mm)
$41.87
6321 2-1/8in (54mm) wide body with Boron shackle, A = 5/16in (8mm) dia., B = 3/4in (19mm),
C = 7/8in (22mm)
$35.39
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology
(Not available with WO & WCS Option or UN & KZ Option)
$1.05
Keying
Standard: Keyed Different
UN
Uncombinated
(Zero bitted cylinder & no keys)
-
Available with WP6 & WP4 options
only
–$4.00
KZ
Zero-Bitted (Not Available with WP option) $0.00
KA
Keyed Alike $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
Cylinder
Standard:
5-pin W6000 cylinder
WO Lock without cylinder –$4.00
WCS Lock Body only –$5.50
W1 4-pin W1 cylinder $0.00
W15 5-pin W15 cylinder $0.00
W17 5-pin W17 cylinder $0.00
W27 5-pin W27 cylinder $0.00
W81 5-pin W81 cylinder $0.00
W7000 6-pin W7000 cylinder $0.00
W7000NISI 6-pin W7000 cylinder with Nickel Silver Key $1.00
W600A 5-pin American Lock® W600A cylinder (Available as KA & KZ only) $0.00
W700A 6-pin American Lock® W700A cylinder (Available as KA & KZ only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
WP6 Edge® Key Control 6-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
K7000
W7000
K81
W81
K27
W27
K17
W17
K15
W15
K1
W1
Exceeds ASTM F883-09
Grade 6
10
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Pro Series® Rekeyable Padlocks — Solid Steel
Example 6230 LH
$35.31
Base Model
Description Price/ea.
6230
2-1/2in (64mm) wide Round body, A = 7/16in (11mm) dia., B = 1-1/8in (29mm), C = 7/8in (22mm)
$32.96
7050
2
in
(51mm) wide body, A = 3/8
in
(9mm) dia., B = 1-1/2
in
(37mm), C = 29/32
in
(23mm)
$25.66
7040
1-3/4in (44mm) wide body, A = 5/16in (8mm) dia., B = 1-3/16in (30mm), C = 29/32in (23mm)
$21.65
7030
1-9/16in (40mm) wide body, A = 1/4in (6mm) dia., B = 1-1/16in (27mm), C = 25/32in (20mm)
$19.64
7045 1-3/4in (44mm) wide Shrouded body, A = 5/16in (8mm) dia., B = 1-3/16in (30mm),
C = 29/32in (23mm) $38.39
7035 1-9/16in (40mm) wide Shrouded body, A = 1/4in (6mm) dia., B = 1-1/16in (27mm),
C = 25/32in (20mm) $37.16
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology
(Not available with WO & WCS Option or UN & KZ Option)
$1.05
Keying
Standard: Keyed Different
UN
Uncombinated
(Zero bitted cylinder & no keys) - Available with WP6 & WP4 Options Only
–$4.00
KZ
Zero-Bitted (Not Available with WP option) $0.00
KA
Keyed Alike $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
Standard:
Boron
LF Boron, B = 1-9/16in (40mm) (7030 & 7040 option only) $2.25
LH Boron, B = 2in (51mm) (6230 option only) $2.35
LJ Boron, B = 2-7/16in (61mm) (7040 & 7050 option only) $2.45
LT Boron, B = 3in (76mm) (7030 option only) $2.55
LN Boron, B = 5-5/8in (143mm) (7040 option only) $6.00
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated
(6230, 7050, 7040 & 7030 option only)
$3.20
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
Cylinder
Standard:
5-pin W6000 cylinder
WO Lock without cylinder –$4.00
WCS Lock Body only –$5.50
W1 4-pin W1 cylinder $0.00
W15 5-pin W15 cylinder $0.00
W17 5-pin W17 cylinder $0.00
W27 5-pin W27 cylinder $0.00
W81 5-pin W81 cylinder $0.00
W7000 6-pin W7000 cylinder $0.00
W7000NISI 6-pin W7000 cylinder with Nickel Silver Key $1.00
W600A 5-pin American Lock® W600A cylinder (Available as KA & KZ only) $0.00
W700A 6-pin American Lock® W700A cylinder (Available as KA & KZ only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
WP6 Edge® Key Control 6-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Exceeds ASTM F883-09
Grade 6
K7000
W7000
K81
W81
K27
W27
K17
W17
K15
W15
K1
W1
11
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Pro Series® Rekeyable Padlocks — Weather Tough®
Example 6121 KA LF WP6
$38.84
Base Model
Description Price/ea.
6127
2-5/8in (67mm) wide body, A = 7/16in (11mm) dia., B = 1-3/8in (35mm), C = 7/8in (22mm)
$34.76
6125 2-3/8in (61mm) wide body, A = 3/8in (10mm) dia., B = 1-3/8in (35mm), C = 7/8in (22mm) $29.87
6121 2-1/8in (54mm) wide body, A = 5/16in (8mm) dia., B = 1-1/8in (29mm), C = 7/8in (22mm) $25.74
Exceeds ASTM F883-09
Grade 6
CN
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology
(Not available with WO & WCS Option or UN & KZ Option)
$1.05
Keying
Standard: Keyed Different
UN
Uncombinated
(Zero bitted cylinder & no keys) - Available with WP6 & WP4 Options Only
–$4.00
KZ
Zero-Bitted (Not Available with WP option) $0.00
KA
Keyed Alike $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
Standard:
Boron
LF Boron, B = 1-1/2in (38mm) (6121 option only) $2.25
LH Boron, B = 1-7/8in (48mm) (6127 option only) $2.35
LJ Boron, B = 2-1/2in (64mm) (6127 & 6121: B = 2-3/8in (60mm)) $2.45
LN Boron, B = 5-5/8in (143mm) (6121 option only) $6.00
BBrass, B = 1-1/2in (38mm) (6121 & 6125 option only) $2.55
BLJ Brass, B = 2-1/2in (64mm) (6121 option only) $5.00
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
HCN Heavy Duty Chain, 12in (30.5cm) Long, Zinc Plated $4.10
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
Cylinder
Standard:
5-pin W6000 cylinder
WO Lock without cylinder –$4.00
WCS Lock Body only –$5.50
W1 4-pin W1 cylinder $0.00
W15 5-pin W15 cylinder $0.00
W17 5-pin W17 cylinder $0.00
W27 5-pin W27 cylinder $0.00
W81 5-pin W81 cylinder $0.00
W7000 6-pin W7000 cylinder $0.00
W7000NISI 6-pin W7000 cylinder with Nickel Silver Key $1.00
W600A 5-pin American Lock® W600A cylinder (Available as KA & KZ only) $0.00
W700A 6-pin American Lock® W700A cylinder (Available as KA & KZ only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
WP6 Edge® Key Control 6-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Body Color
Standard: Black body.
RED
– Red;
YLW
– Yellow;
GRN
– Green;
BLU
– Blue;
ORJ
– Orange; WHT
– White (6121 option only)
$2.00
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
K7000
W7000
K81
W81
K27
W27
K17
W17
K15
W15
K1
W1
12
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Exceeds ASTM F883-09
Grade 6
Pro Series® Rekeyable Padlocks — Solid Brass
Example 6850 KA B NR LZ1
$30.91
Base Model
Description Price/ea.
6850
2
in
(51mm) wide body, A = 3/8
in
(9mm) dia., B = 1-1/2
in
(37mm), C = 29/32
in
(23mm)
$26.31
6840
1-3/4
in
(44mm) wide body, A = 5/16
in
(8mm) dia., B = 1-3/16
in
(30mm), C = 29/32
in
(23mm)
$23.12
6830
1-9/16
in
(40mm) wide body, A = 1/4
in
(6mm) dia., B = 1-1/16
in
(27mm), C = 25/32
in
(20mm)
$19.57
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology
(Not available with WO & WCS Option or UN & KZ Option)
$1.05
Keying
Standard: Keyed Different
UN
Uncombinated
(Zero bitted cylinder & no keys) - Available with WP6 & WP4 Options Only
–$4.00
KZ
Zero-Bitted (Not Available with WP option) $0.00
KA
Keyed Alike $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
Standard:
Boron
LF Boron, B = 1-9/16in (40mm) (6830 & 6840 option only) $2.25
LJ
Boron, B = 2-1/2in (64mm) (6850 option only), B = 2-7/16in (61mm) (6840 option only)
$2.45
LT Boron, B = 3in (76mm) (6830 option only) $2.55
LN Boron, B = 5-5/8in (143mm) (6840 option only) $6.00
B
Brass, B = 1-1/2in (37mm) (6850 option only), B = 1-3/16in (30mm) (6840 option only),
B = 1-1/16in (27mm) (6830 option only) $2.55
BLF Brass, B = 1-9/16in (40mm) (6830 option only) $4.80
BLJ B = 2-7/16in (61mm) (6840 option only) $5.10
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
Cylinder
Standard:
5-pin W6000 cylinder
WO Lock without cylinder –$4.00
WCS Lock Body only –$5.50
W1 4-pin W1 cylinder $0.00
W15 5-pin W15 cylinder $0.00
W17 5-pin W17 cylinder $0.00
W27 5-pin W27 cylinder $0.00
W81 5-pin W81 cylinder $0.00
W7000 6-pin W7000 cylinder $0.00
W7000NISI 6-pin W7000 cylinder with Nickel Silver Key $1.00
W600A 5-pin American Lock® W600A cylinder (Available as KA & KZ only) $0.00
W700A 6-pin American Lock® W700A cylinder (Available as KA & KZ only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
WP6 Edge® Key Control 6-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
K7000
W7000
K81
W81
K27
W27
K17
W17
K15
W15
K1
W1
13
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Exceeds ASTM F883-09
Grade 6
Pro Series® Rekeyable Padlocks — Solid Aluminum
Example 6835 LT NR W7000 RED LZ4
$20.20
Base Model
Description Price/ea.
6835 1-1/2in (38mm) wide body, A = 1/4in (6mm) dia. C = 3/4in (19mm) $13.65
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology
(Not available with WO & WCS Option or UN & KZ Option)
$1.05
Keying
Standard: Keyed Different
UN
Uncombinated
(Zero bitted cylinder & no keys) - Available with WP6 & WP4 Options Only
–$4.00
KZ
Zero-Bitted (Not Available with WP option) $0.00
KA
Keyed Alike $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
Standard:
Boron, B = 1in (25mm)
LF Boron, B = 1-1/2in (38mm) $2.25
LT Boron, B = 3in (72mm) $2.55
BBrass, B = 1in (25mm) $2.55
BLT Brass, B = 3in (72mm) $5.10
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
Cylinder
Standard:
5-pin W6000 cylinder
WO Lock without cylinder –$4.00
WCS Lock Body only –$5.50
W1 4-pin W1 cylinder $0.00
W15 5-pin W15 cylinder $0.00
W17 5-pin W17 cylinder $0.00
W27 5-pin W27 cylinder $0.00
W81 5-pin W81 cylinder $0.00
W401 6-pin Master Lock® W401 Reserved Safety Lockout cylinder $0.95
W417 6-pin Master Lock® W417 Reserved Safety Lockout cylinder, Master Keyed Only $0.95
W7000 6-pin W7000 cylinder $0.00
W7000NISI 6-pin W7000 cylinder with Nickel Silver Key $1.00
W600A 5-pin American Lock® W600A cylinder (Available as KA & KZ only) $0.00
W700A 6-pin American Lock® W700A cylinder (Available as KA & KZ only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
WP6 Edge® Key Control 6-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Lockbody Color REQUIRED
CHOICE
RED
– Red;
YLW
– Yellow;
GRN
– Green;
BLU
– Blue;
ORJ
– Orange;
BLK
– Black
$0.00
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
LZ5 Laser engraved in 5 areas $5.00
LZ6 Laser engraved in 6 areas $6.00
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
6835
XX XX
K7000
W7000
K81
W81
K27
W27
K17
W17
K15
W15
K1
W1
14
Door Key Compatible Cylinders & Padlocks
Use the same key that opens your security doors
– Improve key control • Security • Convenience • Safety
Cylinders may be ordered both as part of a complete
American Lock® Door Key Compatible padlock assembly, or
separately, keyed up and ready to plug into your system
Padlock bodies will also accept the following OEM cylinders:
Medeco® #20W20000 6-pin cylinder, Schlage® (6-pin Key-in-Knob), Assa®
(65611), Schlage® Primus® & GMS® cylinders
Same Key Opens Both
Pro Series® Door Key Compatible Padlocks
Hardened boron alloy shackles for superior cut resistance
Dual ball bearing locking mechanism resists pulling and prying
Rekeyable – replaceable cylinder and shackle
6627LH
7042
7052
6627
6621
6852 6842
6721
6727
7047
Solid Brass
Body provides extra resistance
in caustic, corrosive and salty
environments
Optional brass shackle available
for increased corrosion resistance
High Security – Solid Iron Shroud
Heavy steel bodies withstand
physical attacks
Iron shroud protects shackle
from cutting and prying
High Security – Solid Steel
Heavy case hardened steel body
Chrome rustproofing provides longer life
Shrouded models protect
against bolt cutters
and prying
Weather Tough®
Ideal for harsh outdoor conditions
Exclusive cover protects lock from
water, ice, dirt and grime
Heavy duty steel bodies withstand
physical attacks
Keyway cover keeps
out dust and dirt
Optional brass shackles
available for increased
corrosion resistance
Medeco®, Schlage®, Assa®, Schlage® Primus®, GMS®, Arrow®, Corbin®, Falcon®, Kwikset®, Lockwood®, Russwin®, Sargent®, Weiser®, Yale® are registered trademarks of their respective owners.
Cylinder Options
D13
Falcon®/
Weiser®
(composite)
D12
Kwikset®
(composite)
D04
Schlage® CD28
Schlage® P
(accepts C-L)
D03
Yale® 8
D200WP
Master Lock®
Edge® Key
Control
15
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Exceeds ASTM F883-09
Grade 6
All marks are registered trademarks
of their respective owners.
Pro Series® Door Key Compatible Cylinders & Padlocks — High Security — Solid Iron Shroud
Example 6727 D200WP 6 MK LZ1 NOKEY $82.82
D34 5 KZ $14.80
6721 WO $39.18
Base Model
Description Price/ea.
6727 2-5/8in (67mm) wide body, Boron Shackle, A = 7/16in (11mm) dia., B = 3/4in (19mm),
C = 7/8in (22mm) $55.87
6721 2-1/8in (54mm) wide body, Boron Shackle, A = 5/16in (8mm) dia., B = 3/4in (19mm),
C = 7/8in (22mm) $39.18
BumpStop® Cylinder Technology
NAnti-Bump Cylinder Technology (Available for D200WP cylinder option only.
Not available with UN option)
$1.05
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
No. of Pins
44 Pins (D200WP option only) $0.00
55 Pins (Not available with D200WP option) $0.00
66 Pins $1.70
Keying
Standard: Keyed Different
UN Uncombinated
— zero bitted cylinder without keys (D200WP option only) –$4.00
KZ Zero-Bitted (Not available with D200WP option) –$4.25
KA Keyed Alike $1.25
MK Keyed Different; Master Keyed $2.80
KAMK Keyed Alike; Master Keyed $4.05
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Cylinder
Cylinder
only with Lock Body
Cylinder
WO Lock without cylinder $0.00
WCS Lock Body only –$2.00
D200WP
Master Lock® Edge® Key Control
** $32.35 $25.45
D13 Falcon®/Weiser® (composite)* $21.90 $15.00
D12 Kwikset® (composite)* $19.05 $12.15
D04 Schlage® C$19.05 $12.15
D28 Schlage® P (accepts C-L) $19.05 $12.15
D03 Yale® 8$19.05 $12.15
*Exclusively available as 5-pin cylinder
**Exclusively available as 4 or 6-pin cylinder only
Note: 1) When ordering cylinders only, put an "A" prefix in front of the cylinder
number to assure correct cylinder drivers are provided.
2) Cylinder Only Packaging: Shelf Pack = 6, Master Carton = 24
16
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Exceeds ASTM F883-09
Grade 6
All marks are registered trademarks
of their respective owners.
Pro Series® Key-in-Knob Cylinders & Padlocks — Solid Steel
Example 7052 D12 5 KA $35.39
D01 6 $23.60
7042 LJ WO $21.39
Base Model
Description Price/ea.
7052
2
in
(51mm) wide body, A = 3/8
in
(9mm) dia., B = 1-1/2in (37mm), C = 29/32in (23mm),
Boron
$22.19
7042
1-3/4
in
(44mm) wide body, A = 5/16
in
(8mm) dia., B = 1-3/16in (30mm), C = 29/32in (23mm)
$18.94
7047
1-3/4in (44mm) Shrouded wide body, A = 5/16in (8mm) dia., B = 1-3/16in (30mm), C = 29/32in (23mm)
$34.91
BumpStop® Cylinder Technology
NAnti-Bump Cylinder Technology (Available for D200WP cylinder option only.
Not available with UN option)
$1.05
Shackle
LJ Boron, B = 2-1/2in (64mm) (7052 & 7042 Option only) $2.45
LN Boron, B = 5-5/8in (143mm) (7042 Option only) $6.00
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated
(7047 & 7042
Option
only)
$3.20
No. of Pins
44 Pins (D200WP option only) $0.00
55 Pins (Not available with D200WP option) $0.00
66 Pins $1.70
Keying
Standard: Keyed Different
UN Uncombinated
— zero bitted cylinder without keys (D200WP option only) –$4.00
KZ Zero-Bitted (Not available with D200WP option) –$4.25
KA Keyed Alike $1.25
MK Keyed Different; Master Keyed $2.80
KAMK Keyed Alike; Master Keyed $4.05
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Cylinder
Cylinder
only with Lock Body
Cylinder
WO Lock without cylinder $0.00
WCS Lock Body only –$2.00
D200WP
Master Lock® Edge® Key Control
** $32.35 $25.45
D13 Falcon®/Weiser® (composite)* $21.90 $15.00
D12 Kwikset® (composite)* $19.05 $12.15
D04 Schlage® C$19.05 $12.15
D28 Schlage® P (accepts C-L) $19.05 $12.15
D03 Yale® 8$19.05 $12.15
*Exclusively available as 5-pin cylinder
**Exclusively available as 4 or 6-pin cylinder only
Note: 1) When ordering cylinders only, put an "A" prefix in front of the cylinder
number to assure correct cylinder drivers are provided.
2) Cylinder Only Packaging: Shelf Pack = 6, Master Carton = 24
17
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Exceeds ASTM F883-09
Grade 6
CN
All marks are registered trademarks
of their respective owners.
Pro Series® Key-in-Knob Cylinders & Padlocks — Weather Tough®
Example 6627 LH D10 5 KAMK LZ1 1KEY $57.94
D01 6 $23.60
6621 WO $26.57
Base Model
Description Price/ea.
6627
2-5/8in (67mm) wide body, A = 7/16in (11mm) dia., B = 1-3/8in (35mm), C = 7/8in (22mm)
$38.36
6621 2-1/8in (54mm) wide body, A = 5/16in (8mm) dia., B = 1-1/8in (29mm), C = 7/8in (22mm) $26.57
BumpStop® Cylinder Technology
NAnti-Bump Cylinder Technology (Available for D200WP cylinder option only.
Not available with UN option)
$1.05
Shackle
Standard:
Boron
LF Boron, B = 1-1/2in (38mm) (6621 option only) $2.25
LH Boron, B = 1-7/8in (48mm) (6627 option only) $2.35
LJ Boron, B = 2-1/2in (64mm) (6627: B = 2-3/8in (60mm)) $2.45
LN Boron, B = 5-5/8in (143mm) (6621 option only) $6.00
BBrass, B = 1-1/2in (38mm) (6621 option only) $2.55
BLJ Brass, B = 2-1/2in (64mm) (6621 option only) $5.00
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
HCN Heavy Duty Chain, 12in (30.5cm) Long, Zinc Plated $4.10
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
No. of Pins
44 Pins (D200WP option only) $0.00
55 Pins (Not available with D200WP option) $0.00
66 Pins $1.70
Keying
Standard: Keyed Different
UN Uncombinated
— zero bitted cylinder without keys (D200WP option only) –$4.00
KZ Zero-Bitted (Not available with D200WP option) –$4.25
KA Keyed Alike $1.25
MK Keyed Different; Master Keyed $2.80
KAMK Keyed Alike; Master Keyed $4.05
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Cylinder
Cylinder
only with Lock Body
Cylinder
WO Lock without cylinder $0.00
WCS Lock Body only –$2.00
D200WP
Master Lock® Edge® Key Control
** $32.35 $25.45
D13 Falcon®/Weiser® (composite)* $21.90 $15.00
D12 Kwikset® (composite)* $19.05 $12.15
D04 Schlage® C$19.05 $12.15
D28 Schlage® P (accepts C-L) $19.05 $12.15
D03 Yale® 8$19.05 $12.15
*Exclusively available as 5-pin cylinder
**Exclusively available as 4 or 6-pin cylinder only
Note: 1) When ordering cylinders only, put an "A" prefix in front of the cylinder
number to assure correct cylinder drivers are provided.
2) Cylinder Only Packaging: Shelf Pack = 6, Master Carton = 24
18
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Exceeds ASTM F883-09
Grade 6
All marks are registered trademarks
of their respective owners.
Pro Series® Key-in-Knob Cylinders & Padlocks — Solid Brass
Example 6852 CN D04 6 KAMK LZ1 1KEY $44.34
D34 5 KZ $14.80
6842 LJ WO $21.07
Base Model
Description Price/ea.
6852 2in (51mm) wide body, A = 3/8in (9mm) dia., B = 1-1/2in (37mm), C = 29/32in (23mm) $22.24
6842
1-3/4in (44mm) wide body, A = 5/16in (8mm) dia., B = 1-3/16in (30mm), C = 25/32in (20mm)
$17.73
BumpStop® Cylinder Technology
NAnti-Bump Cylinder Technology (Available for D200WP cylinder option only.
Not available with UN option)
$1.05
Shackle
Standard:
Boron
LF Boron, B = 1-1/2in (38mm) (6842 option only) $2.25
LJ Boron, B = 2-1/2in (64mm) $2.45
LN Boron, B = 5-5/8in (143mm) (6842 option only) $6.00
B
Brass, B = 1-1/2in (38mm) (6852 option only), B = 1-3/16in (30mm) (6842 option only)
$2.55
BLJ Brass, B = 2-1/2in (64mm) (6842 option only) $5.00
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
No. of Pins
44 Pins (D200WP option only) $0.00
55 Pins (Not available with D200WP option) $0.00
66 Pins $1.70
Keying
Standard: Keyed Different
UN Uncombinated
— zero bitted cylinder without keys (D200WP option only) –$4.00
KZ Zero-Bitted (Not available with D200WP option) –$4.25
KA Keyed Alike $1.25
MK Keyed Different; Master Keyed $2.80
KAMK Keyed Alike; Master Keyed $4.05
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Build Your Lock
Cylinder
Cylinder
only with Lock Body
Cylinder
WO Lock without cylinder $0.00
WCS Lock Body only –$2.00
D200WP
Master Lock® Edge® Key Control
** $32.35 $25.45
D13 Falcon®/Weiser® (composite)* $21.90 $15.00
D12 Kwikset® (composite)* $19.05 $12.15
D04 Schlage® C$19.05 $12.15
D28 Schlage® P (accepts C-L) $19.05 $12.15
D03 Yale® 8$19.05 $12.15
*Exclusively available as 5-pin cylinder
**Exclusively available as 4 or 6-pin cylinder only
Note: 1) When ordering cylinders only, put an "A" prefix in front of the cylinder
number to assure correct cylinder drivers are provided.
2) Cylinder Only Packaging: Shelf Pack = 6, Master Carton = 24
Small Format Interchangeable Cores & Pro Series® Padlocks
Pro Series® Small Format Interchangeable Core Padlocks
Hardened boron alloy shackles for superior cut resistance
Dual ball bearing locking mechanism resists pulling and prying
Rekeyable — replaceable cylinder and shackle
6841 6831
Solid Brass
Body provides extra resistance in caustic, corrosive and
salty environments
Optional brass shackle available for increased
corrosion resistance 6851
Best®, Arrow®, PKS®, Arrow®, Falcon® Kaba®, Peaks®, KSP®, Lori® are registered trademarks of their respective owners.
19
6527 6521 7051 7031
7046
High Security – Solid Iron Shroud
Greatest physical security available
Heavy steel bodies withstand
physical attacks
Iron shroud protects
shackle from cutting
and prying
High Security – Solid Steel
Heavy case hardened steel body
Chrome rustproofing
provides longer life
Shrouded models protect
against bolt cutters
and prying
6427 6427LH 6421
Weather Tough®
Ideal for harsh outdoor conditions
Exclusive cover protects lock from water, ice, dirt and grime
Heavy duty steel bodies withstand physical attacks
Keyway cover keeps out dust and dirt
Optional brass shackles available for increased corrosion resistance
Padlock bodies will also accept the following standard size OEM cores: Best®, Best® PKS®,
Arrow®, Falcon®, Kaba® Peaks®, KSP® & Lori®
Cores may be ordered both as part of a complete American Lock IC padlock assembly, or
separately, keyed up and ready to plug into your system
CA CY
Interchangeable core keyways including
Best® and Standard.
20
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Pro Series® Interchangeable Cores & Padlocks — High Security — Iron Shroud
Base Model
Description Price/ea.
6527 2-5/8in (67mm) wide body, A = 7/16in (11mm) dia., B = 3/4in (19mm), C = 7/8in (22mm) $58.77
6521 2-1/8in (54mm) wide body, A = 5/16in (8mm) dia., B = 3/4in (19mm), C = 7/8in (22mm) $42.07
Note: Control Keys Sold Separately! See page 54.
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
No. of Pins
66 Pins $0.00
77 Pins $1.70
Core Finish
04 Satin Brass (Not available on 6-pin CM core) $0.00
26D Satin Chrome $0.00
Keying
Standard: Keyed Different
UN Uncombinated (no keys) –$6.50
KA Keyed Alike $1.25
MK Keyed Different; Master Keyed $2.80
KAMK Keyed Alike; Master Keyed $4.05
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
Number of Keys
1KEY 1 key per lock $0.00
3KEY 3 keys per lock $1.50
4KEY 4 keys per lock $3.00
NOKEY 0 keys per lock $0.00
Example 6527 CA 7 26D KA LZ1 3KEY $82.27
CA 7 26D KA $22.55
6521 WO $42.07
All marks are registered trademarks
of their respective owners.
Core with
Core only Lock
Body
Cores REQUIRED
CHOICE
WO Lock without cylinder $0.00
WCS Lock Body only –$2.00
CY Standard SFIC Keyway $19.60 $18.05
CA Best® Lock A Keyway $19.60 $18.05
Note: Core Only Packaging: Shelf Pack = 5, Master Carton = 20
21
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Pro Series® Interchangeable Cores & Padlocks — Solid Steel
Base Model
Description Price/ea.
7051
2in (48mm) wide body, A = 3/8in (9mm) dia., B = 1-1/2in (38mm), C = 29/32in (23mm), Boron
$28.76
7041
1-3/4in (44mm) wide body, A = 5/16in (8mm) dia., B = 1-3/16in (30mm), C = 29/32in (23mm)
$24.23
7031
1-9/16in (40mm) wide body, A = 1/4in (6mm) dia., B = 1-1/16in (27mm), C = 25/32in (20mm)
$21.87
7046 1-3/4in (44mm) wide Shrouded Steel body, A = 5/16in (8mm) dia., B = 1-3/16in (30mm),
C = 29/32in (23mm) $41.85
7036 1-9/16in (40mm) wide Shrouded Steel body, A = 1/4in (6mm) dia., B = 1-1/16in (27mm),
C = 25/32in (20mm) $38.99
Note: Control Keys Sold Separately! See page 54.
Shackle
LF Boron, B = 1-9/16in (40mm) (7031 & 7041 option only) $2.25
LJ Boron, B = 2-1/2in (64mm) (7041 & 7051 option only) $2.45
LT Boron, B = 3in (76mm) (7031 option only) $2.55
LN Boron, B = 5-5/8in (143mm) (7041 option only) $6.00
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated
(7051, 7041 & 7031 Option only)
$3.20
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
No. of Pins
66 Pins $0.00
77 Pins $1.70
Core Finish
04 Satin Brass (Not available on 6-pin CM core) $0.00
26D Satin Chrome $0.00
Keying
Standard: Keyed Different
UN Uncombinated (no keys) –$6.50
KA Keyed Alike $1.25
MK Keyed Different; Master Keyed $2.80
KAMK Keyed Alike; Master Keyed $4.05
Number of Keys
1KEY 1 key per lock $0.00
3KEY 3 keys per lock $1.50
4KEY 4 keys per lock $3.00
NOKEY 0 keys per lock $0.00
Example 7046 CX 6 26D $59.90
CB 7 04 KAMK $25.35
7051 LF WO $31.01
All marks are registered trademarks
of their respective owners.
Core with
Core only Lock
Body
Cores REQUIRED
CHOICE
WO Lock without cylinder $0.00
WCS Lock Body only –$2.00
CY Standard SFIC Keyway $19.60 $18.05
CA Best® Lock A Keyway $19.60 $18.05
Note: Core Only Packaging: Shelf Pack = 5, Master Carton = 20
22
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
CN
Pro Series® Interchangeable Cores & Padlocks — Weather Tough®
Base Model
Description Price/ea.
6427
2-5/8in (67mm) wide body, A = 7/16in (11mm) dia., B = 1-3/8in (35mm), C = 7/8in (22mm)
$41.11
6421 2-1/8in (54mm) wide body, A = 5/16in (8mm) dia., B = 1-1/8in (29mm), C = 7/8in (22mm) $29.45
Note: Control Keys Sold Separately! See page 54.
Shackle Standard: Boron, B = 1-1/8in (29mm)
LF Boron, B = 1-1/2in (38mm) (6421 Option only) $2.25
LH Boron, B = 1-7/8in (48mm) (6427 Option only) $2.35
LJ Boron, B = 2-1/2in (64mm) (6427: B = 2-3/8in (60mm)) $2.45
LN Boron, B = 5-5/8in (143mm) (6421 Option only) $6.00
BBrass, B = 1-1/2in (64mm) (6421 option only) $2.55
BLJ Brass, B = 2-1/2in (64mm) (6421 option only) $5.00
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
HCN Heavy Duty Chain, 12in (30.5cm) Long, Zinc Plated $4.10
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
No. of Pins
66 Pins $0.00
77 Pins $1.70
Core Finish
04 Satin Brass (Not available on 6-pin CM core) $0.00
26D Satin Chrome $0.00
Keying
Standard: Keyed Different
UN Uncombinated (no keys) –$6.50
KA Keyed Alike $1.25
MK Keyed Different; Master Keyed $2.80
KAMK Keyed Alike; Master Keyed $4.05
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
Number of Keys
1KEY 1 key per lock $0.00
3KEY 3 keys per lock $1.50
4KEY 4 keys per lock $3.00
NOKEY 0 keys per lock $0.00
Example 6427 LH CN CG 7 26D KA LZ2 $69.66
CD 6 04 $19.60
6421 BLJ WO $34.45
All marks are registered trademarks
of their respective owners.
Core with
Core only Lock
Body
Cores REQUIRED
CHOICE
WO Lock without cylinder $0.00
WCS Lock Body only –$2.00
CY Standard SFIC Keyway $19.60 $18.05
CA Best® Lock A Keyway $19.60 $18.05
Note: Core Only Packaging: Shelf Pack = 5, Master Carton = 20
23
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Pro Series® Interchangeable Cores & Padlocks — Solid Brass
Base Model
Description Price/ea.
6851 2in (51mm) wide body, A = 3/8in (9mm) dia., B = 1-1/2in (37mm). C = 29/32in (23mm) $27.78
6841
1-3/4in (44mm) wide body, A = 5/16in (8mm) dia., B = 1-3/16in (30mm), C = 25/32in (23mm)
$23.48
6831
1-9/16in (40mm) wide body, A = 1/4in (6mm) dia., B = 1-1/16in (27mm) C = 25/32in (20mm)
$20.70
Note: Control Keys Sold Separately! See page 54.
Shackle
LF Boron, B = 1-9/16in (40mm) (6841 & 6831 option only) $2.25
LJ
Boron, B = 2-1/2in (64mm) (6851 option only), B = 2-7/16in (61mm) (6841 option only)
$2.45
LT Boron, B = 3in (72mm) (6831 option only) $2.55
LN Boron, B = 5-5/8in (143mm) (6841 option only) $6.00
BBrass, B = 1-1/2in (37mm) (6851 option only), B = 1-3/16in (30mm) (6841 option
only), B = 1-1/16in (27mm) (6831 & option only) $2.55
BLF Brass, B = 1-9/16in (40mm) (6831 option only) $4.80
BLJ B = 2-7/16in (61mm) (6841 option only) $5.00
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
No. of Pins
66 Pins $0.00
77 Pins $1.70
Core Finish
04 Satin Brass (Not available on 6-pin CM core) $0.00
26D Satin Chrome $0.00
Keying
Standard: Keyed Different
UN Uncombinated (no keys) –$6.50
KA Keyed Alike $1.25
MK Keyed Different; Master Keyed $2.80
KAMK Keyed Alike; Master Keyed $4.05
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
Number of Keys
1KEY 1 key per lock $0.00
3KEY 3 keys per lock $1.50
4KEY 4 keys per lock $3.00
NOKEY 0 keys per lock $0.00
Example 6831 LT CN NR CA 7 04 KA $47.45
CB 6 26D $19.60
6851 LJ WO $30.23
All marks are registered trademarks
of their respective owners.
Core with
Core only Lock
Body
Cores REQUIRED
CHOICE
WO Lock without cylinder $0.00
WCS Lock Body only –$2.00
CY Standard SFIC Keyway $19.60 $18.05
CA Best® Lock A Keyway $19.60 $18.05
Note: Core Only Packaging: Shelf Pack = 5, Master Carton = 20
24
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Width
Width
Pro Series® Resettable Combination Locks
Base Model
Description Price/ea.
1174 2-1/4in (57mm) wide stainless steel body, A = 5/16in (8mm), B = 1-1/16in (27mm),
C = 1in (25mm) round stainless steel shackle, Shelf Pack = 4, Master Carton = 24 $37.10
1175 2-1/4in (57mm) wide brass body, A = 3/8in (10mm), B = 1-1/16in (27mm), C = 15/16in
(24mm) octagonal boron-carbide shackle, Shelf Pack = 4, Master Carton = 24 $26.81
1175LH 2-1/4in (57mm) wide brass body, A = 3/8in (10mm), B= 2-1/16in (53mm), C = 15/16in
(24mm) octagonal boron-carbide shackle, Shelf Pack = 4, Master Carton = 24 $30.40
1175LHSS 2-1/4in (57mm) wide brass body, A = 5/16in (8mm), B= 2-1/16in (53mm), C = 1in (25mm)
round stainless steel shackle, Shelf Pack = 4, Master Carton = 24 $31.07
1175RS 2-1/4in (57mm) wide brass body, A=5/16in (8mm), B=2-1/16in (53mm), C=1in (25mm)
round boron-carbide shackle, Shelf Pack=4, Master Carton=24 $26.81
1175LHRS 2-1/4in (57mm) wide brass body, A=5/16in (8mm), B=2-1/16in (53mm), C-1in (25mm)
round boron-carbide shackle, Shelf Pack=4, Master Carton=24 $30.40
1177
2-1/4in (57mm) wide shrouded brass body, A = 3/8in (10mm), B = 1-1/16in (27mm),
C = 15/16in (24mm) octagonal boron-carbide shackle, Shelf Pack = 4, Master Carton = 24
$30.32
1178 2-1/4in (57mm) wide die cast body, A = 3/8in (10mm), B = 1-1/16in (27mm), C = 15/16in
(24mm) octagonal boron-carbide shackle, Shelf Pack = 4, Master Carton = 24 $15.25
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
Example 1174 LZ2 $39.10
25
Rekeyable Padlocks
Quickly remove the current cylinder and either change the pins or replace the cylinder
5-pin tumbler cylinders provide more than 9,000 key changes for added pick resistance
Rekeying kit (No. 291) contains an extensive assortment of the most frequently used
components to replace or rekey cylinders
Die Cast Zinc Padlocks
Chrome-plated lock body resists corrosion
Hardened boron alloy shackle for superior cut resistance
230
25
24
101
Rekeyable Laminated Brass Padlocks
Brass bodies and cylinders provide excellent corrosion resistance
Hardened steel shackles for extra cut resistance
Optional brass shackles available for increased corrosion resistance
Rekeyable Laminated Steel Padlocks
Double locking mechanisms provide extra pry resistance
Hardened boron alloy shackles — No. 25, 27 & 101
Hardened steel shackles — No. 21
Hardened steel bottom plates for extra drill resistance
— No. 27, 25 & 21
Top & bottom bumpers for greater scratch resistance
27 21
220
26
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
K81
W81
K27
W27
K17
W17
K15
W15
K1
W1
Exceeds ASTM F883-09
Grade 6
Rekeyable Padlocks — Die Cast Zinc
Example 230 WO $24.85
Base Model
Description Price/ea.
230 2-1/2in (64mm) wide body, A = 7/16in (11mm) dia., C = 15/16in (24mm), Shelf Pack = 5,
Master Carton = 20 $28.85
220 2in (51mm) wide body, A = 7/16in (11mm) dia., C = 3/4in (19mm), Shelf Pack = 5,
Master Carton = 30 $24.88
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology
(Not available with WO & WCS Option or UN & KZ Option)
$1.05
Keying
Standard: Keyed Different
UN
Uncombinated
(Zero bitted cylinder & no keys)
-
Available with WP4 option
only
–$4.00
KZ
Zero-Bitted (Not Available with WP option) $0.00
KA
Keyed Alike $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
Standard: Boron, B = 1in (25mm)
LH Boron, B = 2in (51mm) $2.90
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Function
Standard: Non-Key Retaining
NR
Non-Removable Key $0.00
Cylinder
Standard:
5-pin W27 cylinder
WO Lock without cylinder –$4.00
WCS Lock Body only –$5.50
W1 4-pin W1 cylinder $0.00
W15 5-pin W15 cylinder $0.00
W17 5-pin W17 cylinder $0.00
W27 5-pin W27 cylinder $0.00
W81 5-pin W81 cylinder $0.00
W600A 5-pin American Lock® W600A cylinder (Available as KA & KZ only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock
1KEY
1 key per lock $0.00
3KEY
3 keys per lock $1.50
4KEY
4 keys per lock $3.00
NOKEY
0 keys per lock $0.00
27
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
No. 101
No. 24
Nos. 21,
25, 27
K27
W27
K17
W17
K15
W15
K2
W2
K1
W1
K81
W81
Exceeds ASTM F883-09
Grade 6
Rekeyable Padlocks — Laminated Steel & Brass Pin Tumbler
Example 27 KA LH $27.57
Base Model
Description Price/ea.
101 3-1/4in (83mm) wide Laminated Steel body with Boron Shackle, A = 5/16in (8mm),
B = 3in (76mm), C = 2-1/4in (57mm) Shelf Pack = 5, Master Carton = 20 $31.92
27 2in (51mm) wide Laminated Steel body with Boron Shackle, A = 7/16in (11mm),
B = 1in (25mm), C = 3/4in (19mm) $23.62
25 2in (51mm) wide Laminated Steel body with Boron Shackle, A = 3/8in (10mm),
B = 1in (25mm), C = 15/16in (24mm) $20.68
21 1-3/4in (44mm) wide Laminated Steel body with Hardened Steel Shackle,
A = 5/16in (8mm), B = 15/16in (24mm), C = 3/4in (19mm) $17.24
24 1-3/4in (44mm) wide Laminated Brass body with Hardened Steel Shackle,
A = 5/16in (8mm), B = 15/16in (24mm), C = 3/4in (19mm) $22.62
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology
(Not available with WO & WCS Option or UN & KZ Option)
$1.05
Keying
Standard: Keyed Different
UN
Uncombinated
(Zero bitted cylinder & no keys)
-
Available with WP6 & WP4 options
only
–$4.00
KZ
Zero-Bitted (Not Available with WP option) $0.00
KA
Keyed Alike $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
LF B = 1-1/2in (38mm) (21, 24 & 25 Option Only) $1.70
LH Boron, B = 2in (51mm) (27 Option Only) $2.90
LJ B = 2-1/2in (64mm) (25, 21 & 24 Option Only) $2.10
LN Hardened Steel, B = 5-3/4in (150mm) (21 & 24 Option Only) $6.00
BBrass, B = 15/16in (24mm) (24 Option Only) $2.55
BLF Brass, B = 1-1/2in (38mm) (24 Option Only) $4.20
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Cylinder
Standard:
5-pin W27 cylinder
WO Lock without cylinder –$4.00
WCS Lock Body only –$5.50
W1 4-pin W1 cylinder $0.00
W2K 4-pin W2 cylinder (Available as MK & KAMK only) $0.00
W15 5-pin W15 cylinder $0.00
W17 5-pin W17 cylinder $0.00
W27 5-pin W27 cylinder $0.00
W81 5-pin W81 cylinder $0.00
W600A 5-pin American Lock® W600A cylinder (Available as KA & KZ only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
28
Non-Rekeyable Padlocks
High Security Laminated Steel Padlocks
Hardened boron alloy shackle for superior cut resistance
Dual locking levers provide extra pry resistance
Hardened steel bottom plates for extra drill resistance
Top and bottom bumpers for greater scratch resistance
Proprietary rustproofing for longer life
5-pin tumbler cylinders provide more than
9,000 key changes for added pick
resistance – No. 15 & 17
4-pin tumbler cylinders provide
pick resistance – No. 5
Laminated Steel Padlocks
Hardened Steel shackles for extra cut resistance
5-pin tumbler cylinders provide more than
9,000 key changes for added pick
resistance – No. 81 & 31
4-pin tumbler cylinders provide pick
resistance – No. 1, 3 & 11
Non-Removable Key feature ensures
padlock is not left unlocked – No. 11
Laminated Brass Padlocks
Brass bodies and cylinders provide excellent
corrosion resistance – No. 82, 6, 2, 4
Hardened steel shackles for
extra cut resistance
Optional brass shackles available
for increased corrosion resistance
Vending and Meter Padlocks
Prevents access to vending and utility valve equipment
Removable hardened steel shackle for extra
cut resistance
Hardened steel bottom plate for extra drill resistance
Dual locking levers provide extra
pry resistance
1-9/16in (40mm) wide laminated
steel body for superior strength
4-pin tumbler cylinder helps
prevent picking
Top and bottom bumpers for
greater scratch resistance
Shrouded Shackle Padlocks
Armored shackle guard and hardened
steel shackle defies cutting
1-9/16in (40mm) wide laminated steel
body for superior strength
4-pin tumbler cylinder helps
prevent picking
General Security Laminated Steel
and Brass Padlocks
1-1/8in (29mm) wide body
Standard steel shackle
Optional brass shackles available for
increased corrosion resistance – No. 8
4-pin cylinder helps prevent picking
Proprietary rustproofing for
longer life – No. 7
Brass bodies and cylinders
provide excellent corrosion
resistance – No. 8
Covered Laminated Padlocks
for Outdoor Protection
High-tech thermoplastic shell designed to
withstand the elements
Hardened steel shackle with molded cover
Dual locking levers provide extra
pry resistance
1-9/16in (40mm) wide laminated steel
body for superior strength
4-pin tumbler cylinder helps
prevent picking
Commercial Magnum Padlocks
Stainless steel body cover for exceptional weatherability
Chrome-plated shackle for excellent rust resistance
Octagonal boron-carbide shackle is 50% harder
than hardened steel
Superiory pry resistance with dual-ball
bearing locking
4-pin tumbler cylinders provide
pick resistance
Key to match existing 4-pin
W1 systems
• Edge® Key Control available
29
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
K2
W2
Exceeds ASTM F883-09
Grade 6
Non-Rekeyable Padlocks — Commercial Magnum
Example M5 KA LF STS $17.00
Base Model
Description Price/ea.
M5 STS 2in (51mm) wide Commercial Magnum Stainless Cover with Octagonal Boron-Carbide
Shackle. A = 3/8in (10mm), C = 15/16in (24mm) $17.98
M1 STS 1-3/4in (44mm) wide Commercial Magnum Stainless Cover with Octagonal Boron-
Carbide Shackle. A = 5/16in (8mm), C = 13/16in (21mm) $14.25
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology $1.05
Keying
Standard: Keyed Different
KA
Keyed Alike $1.05
KARAN Keyed-Alike within Shelf Pack $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
Standard:
Boron, B = 1in (25mm)
LF Octagonal Boron Shackle, Boron, B = 1-1/2in (38mm) $1.70
LJ Octagonal Boron Shackle, Boron, B = 2-1/2in (64mm) $2.90
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Cylinder
Standard:
4-pin W1 cylinder
W2K 4-pin W2 Cylinder (Available with MK or KAMK option only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
30
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
K17
W17
K2
W2
K1
W1
K81
W81
K27
W27
Exceeds ASTM F883-09
Grade 6
Non-Rekeyable Padlocks — 2-1/2in Laminated Steel Pin Tumbler
Example 15 MK W81 $31.67
Base Model
Description Price/ea.
15 2-1/2in (64mm) Wide, Laminated Steel body with Hardened Boron Shackle;
A = 7/16in (11mm), C = 1-3/16in (30mm) $26.72
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology $1.05
Keying
Standard: Keyed Different
KA
Keyed Alike $1.05
KARAN Keyed-Alike within Shelf Pack $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
Standard:
Boron, B = 1-1/4in (32mm)
LH Boron, B = 2in (51mm) $2.90
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Cylinder
Standard:
5-pin W15 cylinder
W1 4-pin W1 cylinder $0.00
W2K 4-pin W2 Cylinder (Available with MK or KAMK option only) $0.00
W17 5-pin W17 cylinder $0.00
W27 5-pin W27 cylinder $0.00
W81 5-pin W81 cylinder $0.00
W600A 5-pin American Lock® W600A cylinder (Available as KA & KZ only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Build Your Lock
31
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Nos. 5 & 17
K15
W15
K2
W2
K1
W1
K81
W81
K27
W27
Exceeds ASTM F883-09
Grade 6
No. 6
Non-Rekeyable Padlocks — 2in (51mm) Laminated Steel & Brass Pin Tumbler
Example 17 KAMK $25.77
Base Model
Description Price/ea.
52in (51mm) Wide, Laminated Steel body with Hardened Boron Shackle;
A = 3/8in (10mm), B = 1in (25mm), C = 15/16in (24mm) $14.98
17 2in (51mm) Wide, Laminated Steel body with Hardened Boron Shackle;
A = 7/16in (11mm), B = 1in (25mm), C = 3/4in (19mm) $19.77
62in (51mm) Wide, Laminated Brass body with Hardened Boron Chrome Shackle,
A = 3/8in (10mm), B = 1in (25mm), C = 15/16in (24mm) $20.05
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology $1.05
Keying
Standard: Keyed Different
KA
Keyed Alike $1.05
KARAN Keyed-Alike within Shelf Pack $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
Standard:
Boron, B = 1-1/4in (32mm)
LF Boron, B = 1-1/2in (38mm) (5 & 6 Option Only) $1.70
LH Boron, B = 2in (51mm) (17 Option Only) $2.90
LJ Boron, B = 2-1/2in (64mm) (5 & 6 Option Only) $2.10
BBrass, B = 1in (25mm) (6 Option Only) $2.55
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Cylinder
Standard:
5 & 6: 4-pin W1 cylinder; 17: 5-pin W17 cylinder
W1 4-pin W1 cylinder (17 Option Only) $0.00
W2K 4-pin W2 Cylinder (Available with MK or KAMK option only) $0.00
W15 5-pin W17 cylinder (17 Option Only) $0.00
W27 5-pin W27 cylinder (17 Option Only) $0.00
W81 5-pin W81 cylinder (17 Option Only) $0.00
W600A 5-pin American Lock® W600A cylinder (17 Option Only) (Available as KA & KZ only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Build Your Lock
32
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Nos. 2 & 82
Nos. 1 & 81
K15
W15
K2
W2
K81
W81
K17
W17
Exceeds ASTM F883-09
Grade 6
Non-Rekeyable Padlocks — 1-3/4in (44mm) Laminated Steel & Brass Pin Tumbler
Example 1 KA LJ CN NOKEY $18.14
Base Model
Description Price/ea.
11-3/4in (44mm) Wide, Laminated Steel body with Hardened Steel Shackle;
A = 5/16in (8mm), B = 15/16in (24mm), C = 3/4in (19mm) $11.79
81 1-3/4in (44mm) Wide, Laminated Steel body with Hardened Steel Shackle;
A = 5/16in (8mm), B = 15/16in (24mm), C = 3/4in (19mm) $16.47
21-3/4in (44mm) Wide, Laminated Brass body with Hardened Steel Shackle;
A = 5/16in (8mm), B = 15/16in (24mm), C = 3/4in (19mm) $16.14
82 1-3/4in (44mm) Wide, Laminated Brass body with Hardened Steel Chrome Shackle;
A = 5/16in (8mm), B = 15/16in (24mm), C = 3/4in (19mm) $20.90
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology $1.05
Keying
Standard: Keyed Different
KA
Keyed Alike $1.05
KARAN Keyed-Alike within Shelf Pack $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
LF Hardened Steel, B = 1-1/2in (38mm) $1.70
LJ Hardened Steel, B = 2-1/2in (64mm) $2.10
LN Hardened Steel, B = 5-3/4in (150mm) $6.00
BBrass, B = 15/16in (24mm) (2 & 82 Option Only) $2.55
BLF Brass, B = 1-1/2in (38mm) (2 & 82 Option Only) $4.20
BLJ Brass, B = 2-1/2in (64mm) (2 & 82 Option Only) $4.60
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Cylinder
Standard:
1 & 2 Only: 4-pin W1 cylinder; 81 & 82 Only: 5-pin W81 Cylinder
W2K 4-pin W2 cylinder (Available with MK or KAMK option only) $0.00
W15 5-pin W15 cylinder (81 & 82 Option Only) $0.00
W17 5-pin W17 cylinder (81 & 82 Option Only) $0.00
W27 5-pin W27 cylinder (81 & 82 Option Only) $0.00
W600A
5-pin American Lock® W600A cylinder (81 and 82 Option Only) (Available as KA & KZ only)
$0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Build Your Lock
33
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
No. 4
Nos. 3, 11
& 31
K15
W15
K2
W2
K81
W81
K17
W17
Exceeds ASTM F883-09
Grade 6
Non-Rekeyable Padlocks — 1-9/16in (40mm) Laminated Steel & Brass Pin Tumbler
Example 3 KA LF $13.01
Base Model
Description Price/ea.
31-9/16in (40mm) Wide, Laminated Steel body with Hardened Steel Shackle;
A = 9/32in (7mm), B = 3/4in (19mm), C = 5/8in (16mm) $10.26
11
1-9/16
in
(40mm) Wide, Laminated Steel body with Hardened Steel Shackle;
Non-Removable Key; A = 9/32in (7mm), B = 3/4in (19mm), C = 5/8in (16mm) $13.04
31 1-9/16in (40mm) Wide, Laminated Steel body with Hardened Steel Shackle;
A = 9/32in (7mm), B = 3/4in (19mm), C = 5/8in (16mm) $12.97
41-9/16in (40mm) Wide, Laminated Brass body with Hardened Steel Chrome Shackle;
A = 9/32in (7mm), B = 3/4in (19mm), C = 5/8in (16mm) $13.79
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology $1.05
Keying
Standard: Keyed Different
KA
Keyed Alike $1.05
KARAN Keyed-Alike within Shelf Pack $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle
LF Hardened Steel, B = 1-1/2in (38mm) $1.70
LH Hardened Steel, B = 2in (51mm) $2.90
BBrass, B = 3/4in (19mm) (4 Option Only) $2.55
BLF Brass, B = 1-1/2in (38mm) (4 Option Only) $4.20
BLH Brass, B = 2in (51mm) (4 Option Only) $5.50
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Cylinder
Standard:
3, 4 & 11 Only 4-pin W1 cylinder; 31 Only 5-pin W-27 cylinder
W2K 4-pin W2 Cylinder (Available with MK or KAMK option only) $0.00
W15 5-pin W15 cylinder (31 Option Only) $0.00
W17 5-pin W17 cylinder (31 Option Only) $0.00
W81 5-pin W81 cylinder (31 Option Only) $0.00
W600A 5-pin American Lock® W600A cylinder (31 Option Only) (Available as KA & KZ only) $0.00
WP4 Edge™ Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Build Your Lock
34
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
®
K2
W2
K2
W2
Exceeds ASTM F883-09
Grade 6
Exceeds ASTM F833-09
Grade 6
Non-Rekeyable Padlocks — 1-9/16in (40mm) Covered Laminated Steel Pin Tumbler
Example 312 MK LH $20.36
Base Model
Description Price/ea.
311 Black Cover, 1-9/16in (40mm) Wide, Laminated Steel body, with Hardened Steel
Shackle; A = 3/8in (10mm), C = 1/2in (13mm) $12.51
312 Blue Cover, 1-9/16in (40mm) Wide, Laminated Steel body, with Hardened Steel Shackle;
A = 3/8in (10mm), C = 1/2in (13mm) $12.51
315 Yellow Cover, 1-9/16in (40mm) Wide, Laminated Steel body, with Hardened Steel
Shackle; A = 3/8in (10mm), C = 1/2in (13mm) $12.51
317 Camoflauge Cover, 1-9/16in (40mm) Wide, Laminated Steel body, with Hardened Steel
Shackle; A = 3/8in (10mm), C = 1/2in (13mm) $14.58
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology $1.05
Keying
Standard: Keyed Different
KA
Keyed Alike $1.05
KARAN Keyed-Alike within Shelf Pack $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle Standard: Hardened Steel with molded cover, B = 3/4in (19mm)
LF Hardened Steel Shackle without cover, B = 1-1/2in (38mm) $1.70
LH Hardened Steel with molded cover, B = 2in (51mm) $2.90
Cylinder
Standard:
4-pin W1 cylinder
W2K 4-pin W2 Cylinder (Available with MK or KAMK option only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Non-Rekeyable Padlocks — 1-9/16in (40mm) Shrouded Laminated Steel Pin Tumbler
Example 37 KA $16.34
Base Model
Description Price/ea.
37 1-9/16in (40mm) Wide, Laminated Steel body with Hardened Steel Shackle;
A = 9/32in - 1/2in (7mm - 13mm), B = 15/16in (24mm), C = 7/16in (11mm) $15.29
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology $1.05
Keying
Standard: Keyed Different
KA
Keyed Alike $1.05
KARAN Keyed-Alike within Shelf Pack $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Cylinder
Standard:
4-pin W1 cylinder
W2K 4-pin W2 Cylinder (Available with MK or KAMK option only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Build Your Lock
35
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
K2
W2
Exceeds ASTM F883-09
Grade 6
Non-Rekeyable Padlocks — Special Application Vending & Meter Padlocks
Example 443 MK LE $18.60
Base Model
Description Price/ea.
443 1-9/16in (40mm) Wide, Laminated Steel body with Hardened Steel Shackle;
A = 3/8in (10mm), C = 5/8in (16mm) $13.40
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology $1.05
Keying
Standard: Keyed Different
KA
Keyed Alike $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle Standard: Hardened Steel, B = 5/8in (16mm)
LE Hardened Steel, B = 7/8in (22mm) $0.25
LK Hardened Steel, B = 3-1/2in (89mm) $3.00
Cylinder
Standard:
4-pin W1 cylinder
W2K 4-pin W2 Cylinder (Available with MK or KAMK option only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
Non-Rekeyable Padlocks — 1-1/8in Laminated Steel & Brass Pin Tumbler
Example 8 B $13.69
Base Model
Description Price/ea.
71-1/8in (29mm) wide, Laminated Steel body with Steel Shackle; A = 3/16in (5mm),
C = 1/2in (13mm) - 4-pin W7 cylinder $8.16
81-1/8in (29mm) wide, Laminated Brass body with Chrome Steel Shackle;
A = 3/16in (5mm), C = 1/2in (13mm) - 4-pin W7 cylinder $11.14
Keying
Standard: Keyed Different
KA
Keyed Alike $1.05
KARAN Keyed-Alike within Shelf Pack $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Shackle Standard: Steel, B = 9/16in (14mm)
LF Steel, B = 1-1/2in (38mm) $1.70
LJ Steel, B = 2-1/2in (64mm) $2.10
BBrass, B = 9/16in (14mm) (8 Option Only) $2.55
Chain
CN #40 Sash Chain, 9in (23cm) Long, Zinc Plated $3.20
Number of Keys
Standard: 2 keys per lock Standard Keys
1KEY
1 key per lock $0.00
3KEY
3 keys per lock $1.50
4KEY
4 keys per lock $3.00
NOKEY
0 keys per lock $0.00
Build Your Lock
36
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Universal Pin Padlocks and Accessories
Standard Products
Universal Pin padlocks for keying convenience
Locks pinned to customer’s key in minutes. Operates with same key as
Master Lock Padlocks (Nos. 1-6)
Laminated steel bodies for superior strength
Hardened steel (Nos. 1 and 3) and hardened boron alloy
(No. 5) shackles
4-pin tumbler cylinders helps prevent picking
Great choice for keyed alike applications
No. 376 produces custom-pinned locks in minutes
No. 376 on-site use with Universal Pin padlocks
Universal Pin Series Padlocks and Tool
Shrouded Padlocks
No. 40 Padlocks
Commercial Boxed Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
Universal Pin Padlocks
1UP Universal Pin; 1-3/4in (44mm) wide body $12.80 6 24 5/16in 15/16
in
3/4
in
8mm 24mm 19mm
1UPLJ Universal Pin; 1-3/4in (44mm) wide body;
2-1/2in (64mm) Shackle $14.90 6 24 5/16in 2-1/2
in
3/4
in
8mm 64mm 19mm
3UP Universal Pin; 1-9/16in (40mm) wide body $11.15 6 24 9/32in 3/4
in
5/8
in
7mm 19mm 16mm
3UPLF Universal Pin; 1-9/16in (40mm) wide body;
1-1/2in (38mm) Shackle $12.85 6 24 9/32in 1-1/2in 5/8in 7mm 38mm 16mm
5UP Universal Pin; 2in (51mm) wide body $16.21 6 24 3/8in 1in 15/16in 10mm 25mm 24mm
5UPLF Universal Pin; 2in (51mm) wide body;
1-1/2in (38mm) Shackle $17.91 6 24 3/8in 1-1/2in 15/16in 10mm 38mm 24mm
Universal Pin Keying Tool)
376 Hand-held Keying Tool; Hammer required
for operation $54.78 36 NA NA NA NA NA NA
Fully shielded design minimizes shackle exposure and protects
against bolt cutter attacks
Key retaining feature ensures padlock is not left unlocked
2-3/4in (70mm) wide stainless steel body resists corrosion
Hardened steel shackle for extra cut resistance
4-pin cylinder helps prevent picking
Double deadbolt locking to guard against pulling
Retail Carded Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
40KADPF Keyed Alike; Series Packaging $17.30 6 36 3/8in 5/8in 3/4in 10mm 16mm 19mm
NOTE: WHEN ORDERING KEYED ALIKE PADLOCKS, EACH DIFFERENT KEYED ALIKE SET IS A SEPARATE LINE ITEM.
37
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Standard Products
Commercial Boxed Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
175 Set-Your-Own Combination $22.34 6 36 5/16
in
1
in
1
in
8mm 25mm 25mm
175LH
Set-Your-Own Combination; 2-1/4in (57mm)
Shackle
$25.33 6 36 5/16
in
2-1/4
in
1
in
8mm 57mm 25mm
175LHSS
Set-Your-Own Combination; 2-1/4in (57mm)
Stainless Steel Shackle
$29.44 6 36 5/16
in
2-1/4
in
1
in
8mm 57mm 25mm
176
Set-Your-Own Combination; Key Over-Ride*
$24.74 6 36 5/16
in
1
in
1
in
8mm 25mm 25mm
176KA
Set-Your-Own Combination; Key Over-Ride*;
Keyed Alike
$25.79 6 36 5/16
in
1
in
1
in
8mm 25mm 25mm
176LH
Set-Your-Own Combination; 2-1/4in (57mm)
Shackle Key Over-Ride*
$27.64 6 36 5/16
in
2-1/4
in
1
in
8mm 57mm 25mm
176KALH
Set-Your-Own Combination; 2-1/4in (57mm)
Shackle; Key Over-Ride*; Keyed Alike
$28.69 6 36 5/16
in
2-1/4
in
1
in
8mm 57mm 25mm
178BLK Set-Your-Own Combination; Black $14.39 6 36 5/16
in
1
in
1
in
8mm 25mm 25mm
878
Set-Your-Own Combination; Black Powder Coated
Zinc Body; No Combination Reset Tool Required
$15.83 6 36 5/16
in
1
in
1
in
8mm 25mm 25mm
975
Set-Your-Own Combination;
No Combination
Reset Tool Required
$24.57 6 36 5/16
in
1
in
1
in
8mm 25mm 25mm
975LH
Set-Your-Own Combination; 2-1/4in (57mm
Shackle;
No Combination Reset Tool Required
$27.86 6 36 5/16
in
2
in
1
in
8mm 51mm 25mm
Set-your-own 4-digit combination for convenience and security
Reset to any of 10,000 personalized combinations
Nos. 878 and 975 – no combination reset tool required
2in (51mm) wide solid brass case for strength and weatherability
Hardened steel shackles for cut resistance
No. 176 offers key override
No. 178BLK and 878 offers economical die cast construction
Nos. 175, 176, 178, 878 and 975 Padlocks
Combination Padlocks
Also available - Pro Series
®
Resettable Combination Locks offer increased
security, weatherability and added user conveniences, see page 25.
FRONT BACK
AREA 1 AREA 3
AREA 2 AREA 4
*Order 176 cut keys – See page 54.
Custom Marking
LZ1 Laser engraved in 1 area $1.00
LZ2 Laser engraved in 2 areas $2.00
LZ3 Laser engraved in 3 areas $3.00
LZ4 Laser engraved in 4 areas $4.00
NOTE: WHEN ORDERING COMBINATION ALIKE PADLOCKS, EACH DIFFERENT COMBINATION ALIKE SET IS A SEPARATE LINE ITEM.
38
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Standard Products
2-3/16in (55mm) wide double-armored stainless steel body
Hardened boron alloy shackle for superior cut resistance
3 times stronger than No. 1500
3-digit dialing and 1,500 combinations for maximum security
Easy-to-read black dial
No. 2001 Padlocks
World’s best selling combination lock
BlockGuard® Anti-Shim Technology withstands attempts
to violate the latch mechanism
1-7/8in (48mm) wide double-armored stainless steel body
Hardened steel shackle for extra cut resistance
Combination security for keyless convenience
3-digit dialing and 1,500 combinations for maximum security
No. 1500 Padlocks
Commercial Boxed Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
1500 Combination Different $7.24 12 72 9/32in 3/4in 13/16in 7mm 19mm 21mm
1500KA Combination Alike $8.29 12 72 9/32in 3/4in 13/16in 7mm 19mm 21mm
1500LF
Combination Different; 1-1/2in (38mm) Shackle
$8.94 6 36 9/32in 1-1/2in 13/16in 7mm 38mm 21mm
1500LH
Combination Different; 2in (51mm) Shackle
$10.14 6 36 9/32in 2in 13/16in 7mm 51mm 21mm
Combination Padlocks
NOTE: WHEN ORDERING COMBINATION ALIKE PADLOCKS, EACH DIFFERENT COMBINATION ALIKE SET IS A SEPARATE LINE ITEM.
Commercial Boxed Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
2001 Combination Different $23.10 6 24 5/16in 1in 15/16in 8mm 25mm 24mm
2001KA Combination Alike $24.15 6 24 5/16in 1in 15/16in 8mm 25mm 24mm
Multi-User Built-in Mechanical Locks
Commercial Boxed Products
Product
Number Description List Price
(Each) Master Carton
Quantity
3630
Set-your-own combination lock - for standard lift handle lockers - manual deadbolt locking, right-hand hinged door - override key sold separately
$91.26 25
3631
Set-your-own combination lock - for stadard lift handle lockers - manual deadbolt locking, left-hand hinged door - override key sold separately
$91.26 25
3670
Set-your-own combination lock - for lift handle, turn handle and single point latch/box horizontal latch lockers -
manual deadbolt locking, right-hand or left-hand hinged door - override key sold separately
$91.26 25
Options & Accessories
K3630 Supervisory override key $3.99 NA
3630-0320 Extension kit for doors with a thickness of 11/16in (17mm) to 3/4in (19mm) $5.62 NA
3633LES English/Spanish user instruction magnets $17.53 NA
3633LEF English/French user instruction magnets $17.53 NA
3634LES English/Spanish user instruction stickers $21.67 NA
3634LEF English/French user instruction stickers $21.67 NA
Set-your-own 3-digit combination
Intuitive, easy to use design
Retains current combination until re-set
39
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Standard Products
Laminated steel body for superior strength
Steel shackle provides strong cut resistance
Warded locking mechanism minimizes jamming from dirt and grime
Rustproofed for extended wear
Nos. 10, 22, 105, 500, 510 and 517 Padlocks
Warded Padlocks
Commercial Boxed Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
1in (25mm) wide, Laminated Steel Body
10D Keyed Different; Retail Carded $3.00 4 24 5/32in 7/16in 13/32in 4mm 11mm 10mm
10KA Keyed Alike $3.93 12 144 5/32in 7/16in 13/32in 4mm 11mm 10mm
1-1/8in (29mm) wide, Laminated Steel Body
105D Keyed Different; Retail Carded $3.83 4 24 3/16in 1/2in 1/2in 5mm 13mm 13mm
105KA Keyed Alike $4.73 12 72 3/16in 1/2in 1/2in 5mm 13mm 13mm
1-1/2in (38mm) wide, Laminated Steel Body
22D Keyed Different; Retail Carded $4.00 4 24 1/4in 5/8in 9/16in 6mm 16mm 14mm
22T 2-Pack of No. 22 Keyed Alike; Retail Carded $7.21 4 16 1/4in 5/8in 9/16in 6mm 16mm 14mm
22 Keyed Different $4.00 12 72 1/4in 5/8in 9/16in 6mm 16mm 14mm
22KA Keyed Alike $4.90 12 72 1/4in 5/8in 9/16in 6mm 16mm 14mm
3009D 4-Pack of No. 22 Keyed Alike; Retail Carded $11.98 4 16 1/4in 5/8in 9/16in 6mm 16mm 14mm
22KALF Keyed Alike; 1-1/2in (38mm) Shackle $6.60 6 36 1/4in 1-1/2in 9/16in 6mm 38mm 14mm
1-3/4in (44mm) wide, Laminated Steel Body
500D Keyed Different; Retail Carded $4.82 4 24 9/32in 13/16in 13/16in 7mm 21mm 21mm
500 Keyed Different $4.82 12 72 9/32in 13/16in 13/16in 7mm 21mm 21mm
500KA Keyed Alike $5.69 12 72 9/32in 13/16in 13/16in 7mm 21mm 21mm
500KABRK Keyed Alike; Breakaway Shackle $6.87 12 72 9/32in 13/16in 13/16in 7mm 21mm 21mm
500KABRKLH
2in (51mm) tall, 9/32in (7mm) diameter steel
shackle provides strong cut resistance $9.78 12 72 9/32in 2in 13/16in 7mm 51mm 21mm
500KABRKLN
5-3/4in (150mm) tall, 9/32in (7mm) diameter
steel shackle provides strong cut resistance $13.06 12 72 9/32in 5-3/4in 13/16in 7mm 150mm 21mm
1-3/4in (44mm) wide, Laminated Steel Lock with Standard Steel Adjustable Shackle
510D Keyed Different; Retail Carded $7.59 4 24 9/32in 5/8-2in 13/16in 7mm 16-51mm 21mm
510KAD Keyed Alike; Retail Carded $8.42 4 24 9/32in 5/8-2in 13/16in 7mm 16-51mm 21mm
517D Keyed Different; Retail Carded $8.03 4 24 9/32in 2-3/4in-
5-3/8in 13/16in 7mm 7-14cm 21mm
517KAD Keyed Alike; Retail Carded $8.83 4 24 9/32in 2-3/4in-
5-3/8in 13/16in 7mm 7-14cm 21mm
40
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Standard Products
Case hardened shackle resists sawing and filing
Brass body and cylinder provide extra resistance to the elements
Pin tumbler cylinder provides greater pick resistance
Nos. 4120, 4130, 4140 and 4150 Padlocks
Economy Brass Series Padlocks
Commercial Boxed Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
4120 3/4in (19mm) Keyed Different; 3-pin Tumbler $2.52 12 72 5/32in 7/16in 3/8in 4mm 11mm 9mm
4120KA Keyed Alike $3.57 12 72 5/32in 7/16in 3/8in 4mm 11mm 9mm
4130 1-1/8in (29mm) Keyed Different; 4-pin Tumbler $3.77 12 72 3/16in 9/16in 9/16in 5mm 14mm 15mm
4130KA Keyed Alike $4.82 12 72 3/16in 9/16in 9/16in 5mm 14mm 15mm
4130KALF Keyed Alike; 1-1/2in (38mm) Shackle $7.07 12 72 3/16in 1-1/2in 9/16in 5mm 38mm 15mm
4130KALJ Keyed Alike; 2-1/2in (64mm) Shackle $6.92 12 72 3/16in 2-1/2in 9/16in 5mm 64mm 15mm
4140 1-1/2in (38mm) Keyed Different; 4-pin Tumbler $5.05 12 72 1/4in 13/16in 13/16in 6mm 20mm 20mm
4140KA Keyed Alike $6.10 12 72 1/4in 13/16in 13/16in 6mm 20mm 20mm
4140LH Keyed Different;
2-1/4in (57mm) Shackle
$7.95 12 72 1/4in 2-1/4in 13/16in 6mm 57mm 20mm
4140KALH Keyed Alike;
2-1/4in (57mm) Shackle
$9.00 12 72 1/4in 2-1/4in 13/16in 6mm 57mm 20mm
4150 1-7/8in (48mm) Keyed Different; 5-pin Tumbler $7.58 6 72 9/32in 15/16in 1in 7mm 24mm 25mm
4150KA Keyed Alike $8.63 6 72 9/32in 15/16in 1in 7mm 24mm 25mm
4150LJ Keyed Different; 2-1/2in (64mm) Shackle $9.68 6 72 9/32in 2-1/2in 1in 7mm 64mm 25mm
4150KALJ Keyed Alike; 2-1/2in (64mm) Shackle $10.73 6 72 9/32in 2-1/2in 1in 7mm 64mm 25mm
41
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Build Your Lock
Python® Adjustable Locking Cable
Patented locking mechanism holds the cable tight for infinite locking positions
Weather tough aluminum alloy body, cylinder shutter and vinyl coated cable resist
rust and operate in extreme conditions
Keyed-alike convenience with the removeable, rekeyable cylinder -- key to other
Python locking cables or other Master Lock systems with the M1 keyway
Increased pick resistance with patented disk tumbler cylinder
Cut resistant, 3/8in (10mm) 100% steel braided cable
2ft (.61m) to 30ft (9.1m) lnterchangeable cables for
application flexibility
8413
Base Model
Description Price/ea.
8413
Python® Adjustable Locking Cable, A = 3/8in (10mm) - Shelf Pack = NA, Master Carton = 6
$24.02
Keying
Standard: Keyed Different
KZ Zero-Bitted $0.00
KA Keyed Alike $1.05
Cable Length
REQUIRED
CHOICE
CBLNLength of Cable (N =2 feet through 30 feet, increments of 1 foot) Ex. CBL2 - CBL30 $.75/ft
Number of Keys Standard: 2 keys per lock
1KEY 1 key per lock $0.00
3KEY 3 keys per lock $1.50
4KEY 4 keys per lock $3.00
NOKEY 0 keys per lock $0.00
Example 8413 KA CBL 24 $43.07
Retail Carded Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Cable
Length
Outside
Diameter
of Cable
Cable
Length
(Metric)
Outside
Diameter of
Cable
(Metric)
Yellow Locking Head With Black Bumper
8413DPF Keyed Different; 6ft (1.8m) x 3/8in
(10mm) Adjustable Locking Cable $29.85 6 72in (6ft) 3/8in 1.8m 10mm
8433DAT Keyed Different; 6ft (1.8m) x 3/8in
(10mm) Adjustable Locking Cable $28.70 4 16 72in (6ft) 3/8in 1.8m 10mm
Silver Locking Head With Black Bumper
8428DPS Keyed Different; 6ft (1.8m) x 3/8in
(10mm) Adjustable Locking Cable $29.85 6 72in (6') 3/8in 1.8m 10mm
General Use; Black Body & Bumper
8418D Keyed Different; 6ft (1.8m) x 5/16in
(8mm) Adjustable Locking Cable $20.00 4 72in (6ft) 5/16in 1.8m 8mm
8418KADCAMO-TMB
Keyed Alike; 6ft (1.8m) x 5/16in (8mm)
Adjustable Locking Cable; Camo Cover $24.33 4 72in (6ft) 5/16in 1.8m 8mm
8419DPF Keyed Different; 6ft (1.8m) x 5/16in
(8mm) Adjustable Locking Cable $20.00 4 72in (6ft) 5/16in 1.8m 8mm
8417D Keyed Different; 6ft (1.8m) x 3/16in
(5mm) Adjustable Locking Cable $14.39 4 72in (6ft) 3/16in 1.8m 5mm
42
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
High Security King Pin Locks
Secures the king pin of semi-trailers, RVs and other fifth wheel trailers
Renders bolt cutters useless
High grade aluminum is lightweight while providing high security
High visibility red body and durable flag alert drivers that lock is attached
Includes an integrated No 5, 25 or 6121 lock with all of its security and
keying flexibility
K7000
W7000
K81
W81
K27
W27
K17
W17
K15
W15
K2
W2
K1
W1
Exceeds ASTM F883-09
Grade 6
Example 388 KA W27 $138.25
Base Model
Description Price/ea.
387 High Security King Pin comes with #5 Padlock, 4-pin W1 cylinder - Shelf Pack = NA,
Master Carton = 1 $131.49
388 High Security King Pin comes with #25 Padlock, 5-pin W27 cylinder - Shelf Pack = NA,
Master Carton = 1 $137.20
3870 High Security King Pin comes with #6121 Padlock
(less top cover), 5-pin W6000 cylinder
-
Shelf Pack = NA, Master Carton = 1 $140.33
Note: Also available with Interchangeable Core (3871) and Key-In-Knob Cylinder (3872)
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology
(Not available with WO & WCS Option or UN & KZ Option)
$1.05
Keying
Standard: Keyed Different
UN Uncombinated (Zero bitted cylinder & no keys) - Available with WP6 & WP4 options
only (388 & 3870 option only) –$4.00
KZ Zero-Bitted (Not available with WP option or 387 model)
$0.00
KA
Keyed Alike $1.05
MK
Keyed Different; Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Function
Standard: Non-Key Retaining
NR Non-Removable Key (3870 Option Only)
$0.00
Cylinder
Standard:
See Base Model Description
WO King Pin Lock without cylinder (388 & 3870 Option Only) –$4.00
WL King Pin Only (387 Option Only) –$12.00
W1 4-pin W1 cylinder (388 & 3870 Option Only) $0.00
W2K 4-pin W2 cylinder (387 & 388 Option Only) $0.00
W15 5-pin W15 cylinder (388 & 3870 Option Only) $0.00
W17 5-pin W17 cylinder (388 & 3870 Option Only) $0.00
W27 5-pin W27 cylinder (388 & 3870 Option Only) $0.00
W81 5-pin W81 cylinder (388 & 3870 Option Only) $0.00
W7000 6-pin W7000 cylinder (3870 Option Only) $0.00
W7000NISI 6-pin W7000 cylinder (3870 Option Only) with Nickel Silver Key $1.00
W600A 5-pin American Lock® W600A cylinder (388 & 3870 Option Only) $0.00
W700A 6-pin American Lock® W700A cylinder (3870 Option Only) $0.00
WP4 Edge® Key Control 4-pin cylinder.
Standard: Nickel Silver Keys
$9.80
WP6
Edge
®
Key Control 6-pin cylinder. Standard: Nickel Silver Keys (3870 Option Only)
$9.80
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
387
Standard Products
43
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Standard Products
SAFESPACE® Storage Security
Nos. 7122 - 7130 have heavy duty steel construction with full length,
hinged door and built-in, slotted key racks
Durable, beige powder coated cabinet finish
Rekeyable wafer cylinder lock that utilizes our K1 Key with improved
pick resistance
Key retaining security insures key cannot be removed until cabinet is locked
2 keys, key holders, cross reference chart and installation hardware included
No. 7126D
Key Cabinets
Retail Carded Products
Product
Number Description List Price
(Each) Master Carton
Quantity
7122D Heavy Duty Key Cabinet holds 30 keys. 12in (30cm) x 8in (20.3cm) x 2.5in (6.4cm) $54.26 4
7123D Heavy Duty Key Cabinet holds 48 keys. 7-1/2in (19.1cm) x 28-3/4in (73cm) x 1-3/4in (4.4cm) $90.36 4
7125D Heavy Duty Key Cabinet holds 60 keys. 12-1/4in (31.1cm) x 10-3/4in (27.3cm) x 3in (7.6cm) $91.01 4
7126D Heavy Duty Key Cabinet holds 120 keys. 17in (43.2cm) x 13in (33cm) x 3-1/4in (8.3cm) $147.02 4
7127D Heavy Duty Key Cabinet holds 240 keys. 20in (50.8cm) x 16-1/2in (41.9cm) x 5in (12.7cm) $247.70 2
7128D Heavy Duty Key Cabinet holds 330 keys. 20in (50.8cm) x 16-1/2in (41.9cm) x 5in (12.7cm) $295.97 2
7129 Heavy Duty Key Cabinet holds 500 keys. 25-1/4in (64.1cm) x 18in (45.7cm) x 5.5in (14cm) $470.15 1
7130 Heavy Duty Key Cabinet holds 730 keys. 25-1/4in (64.1cm) x 18in (.cm) x 7in (17.8cm) $620.46 1
7131D Durable Key Cabinet holds 20 keys. 7-3/4in (19.7cm) x 6-1/4in (15.9cm) x 3in (7.6cm) $17.88 4
7132D Durable Key Cabinet holds 45 keys. 11-3/4in (29.8cm) x 9-3/8in (23.8cm) x 3in (7.6cm) $36.33 4
7101D Durable Key Cabinet holds 48 keys. 9-7/8in (25cm) x 7in (17.8cm) x 3in (7.6cm) $35.10 4
No. 7132D
Fits most key cabinets and key racks
Retail Carded Products
Product
Number Description List Price
(Each) Master Carton
Quantity
7116D Plastic Key Tags; 20 tags per bag. 1-1/4in (32mm) x 1-1/10in (28mm) x 1/2in (12mm) $6.90 10 bags
No. 7116D
Plastic Key Tags and Hangers
44
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Standard Products
SAFESPACE® Storage Security
SAFESPACE® Combination Dial Portable Lock Boxes
Retail Carded Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
5400D
Portable Lock Box; Set Your Own 4-digit
Combination; Holds up to 5 keys; 3-1/4in
(83mm) wide
$39.63* 4 13/32in 1-7/8in 1-13/32in 10mm 47mm 36mm
5406D
Compact Portable Lock Box; Set Your Own
3-digit Combination; Holds 2-3 keys; 2-3/4in
(70mm) wide
$24.53* 2 4 13/32in 1-7/8in 1-13/32in 10mm 47mm 36mm
5408D Mini Safe Preset Combination; For Keys,
Cash, Jewelry 1-3/4in (44mm) wide $13.34* 4 16 NA NA NA NA NA NA
The safest place for your key
Storage compartment holds multiple house, car
or padlock keys
No lockouts or schedule conicts
Locking combination convenience
Durable metal construction
No. 5400D No. 5406D No. 5408D
Large Easy to Read Light-Up Dials
Dials Light Up Automatically
Large Open Lever for more comfortable use
Durable Weather Cover prevents freezing and jamming
Vinyl Coated Shackle and Molded Bumper prevents
scratches to your door
Hidden Hinge and Recessed Compartment prevents door
from jamming
Set Your Own Combination for easy-to-use convenience
10,000 possible combinations
No. 5424D No. 5425D
SAFESPACE® Light-Up Dial Lock Boxes
Retail Carded Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
5424D Portable Light-Up Dial Lock Box $52.83 4 3/8in
1-11/16in
1-13/32in
9mm 43mm 36mm
5425D
Wall Mount Light-Up Dial Lock Box
$49.53 4 NA NA NA NA NA NA
45
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Standard Products
Durable steel construction stands up to daily use
Multiple compartment trays for coins, bills or checks
Variety of sizes and locking options available
No. 7113D
No. 7143D No. 7147D
Portable lock box provides secure storage of keys or access cards
Convenient push button locking mechanism in familiar alpha / numeric
telephone keypad format
Set your own combination using up to 12 letters, numbers, or both
Large buttons for ease of use, even in low light conditions
Large internal cavity and removable key hook prevents jamming
Protective weather cover prevents freezing and jamminge
No. 5422D No. 5423D
The safest place for your key
Storage compartment holds multiple house, car or padlock keys
No lockouts or schedule conicts
Easy 2 Set & Reset locking combination convenience
No. 5401D
SAFESPACE® Storage Security
SAFESPACE® Combination Dial Wall Mount Lock Box
Retail Carded Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
5401D
Wall Mount Lock Box; Set Your Own Combination
Holds up to 5 keys; 3-1/4in (83mm) wide
$37.16 4 NA NA NA NA NA NA
SAFESPACE® Push Button Lock Boxes
Retail Carded Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Shackle
Dimensions
A B C
Shackle
Dimensions (Metric)
A B C
5422D 3-1/8in (79mm) Wide Set Your Own
Combination Push Button Portable Lock Box $42.10 4 13/32in 1-5/6in
1-13/32
in 10mm 46mm 36mm
5423D
3-1/8in (79mm) Wide Set Your Own
Combination Push Button Wall Mount Lock Box
$39.47 4 NA NA NA NA NA NA
SAFESPACE® Cash and Document Storage
Retail Carded Products
Product
Number Description List Price
(Each)
Master Carton
Quantity
7143D Locking Drawer Safe with 4 compartment tray. 2-1/4in (5.7cm) x 6-3/6in (17.14cm) x 7in (17.78cm) $15.88 4
7147D Combination Lock Cash Box with 6 compartment tray and bill clips. 3-1/4in (8.25cm) x 11-1/2in (29.21cm) x
7-1/2in (19.05cm) $35.10 3
7113D Locking Cash Box with 7 compartment tray. 11in (28cm) x 8in (20.3cm) x 4in (10.1cm) $14.81 4
46
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Protect important paperwork, documents, and other valuables at home or work
Durable steel construction
Key locking for security
Fire retardant insulation to protect contents
No. 7149D
Large internal capactity ts most keys, including keys with integrated FOB*
Rust free, durable plastic construction
Recessed magnet securely attaches and holds case to any steel surface
Improved sliding cover design with built-in stop to prevent cover from
being dropped or misplaced
New discreet design to conceal your keys
Retail Carded Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Product
Dimensions
A B C D E
Product
Dimensions (Metric)
A B C D E
207D
Large Magnetic Key Case
$2.53 4 24
4-11/16in 2in 1-3/16in 1-5/8in 3-7/8in 119mm 51mm 29mm 41mm 97mm
*This product is not intended to be waterproof and is not recommended for outdoor use with electronic items
No. 207D
SAFESPACE® Storage Security
Safely carry cash, jewelry and confidential documents
Water resistant nylon
Built in high security lock
Identification holder and card
No. 7120D
SAFESPACE® Storage Bag
Retail Carded Products
Product
Number Description List Price
(Each) Master Carton
Quantity
7120D Locking storage bag. 10in (25.4cm) H x 8-5/8in (21.9cm) W x 1-7/8in (4.8cm) D $25.18 6
SAFESPACE® Document Storage
Retail Carded Products
Product
Number Description List Price
(Each)
Master Carton
Quantity
7149D Locking security chest with re retardant insulation. 4in (10.2 cm) H X 13.5in W (34.3 cm) X 10-3/4in (27.3 cm) $42.33 2
SAFESPACE® Magnetic Key Case
47
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Zinc plated hardened steel for added strength and weatherability
Hardened steel staple resists cutting, sawing and hammering
Hasp body conceals mounting hardware
Mounting hardware included for easy installation
No. 730 is ideal for utility vans, trailers, gang boxes, vending machines
Combine No. 730 with Nos. 6271 hidden shackle locks for maximum security
Heavy Duty Hasps
Secure hard-to-lock property
Hardened steel body for added strength
Hardened boron alloy staples resist cutting and sawing
Single and double hinge styles with hidden hinge pins
Ideal for corners and angles
Hinged Hasps
No. 731
No. 730
Ideal for vans, trucks, gates and vending
Hardened solid steel hasp withstands forcible attacks
Defeats attempts to pry and cut
Designed for use with No. 6271 hidden shackle locks
(page 8)
No. 770
High Security Hidden Shackle Padlock Hasp
No. 732
Hasps
No. 720DPF
No. 722DPF
No. 721DPF
Commercial Boxed Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Hasp
Length
Accepts
Shackle
Dia. Up To:
Hasp
Length
(Metric)
Accepts
Shackle Dia.
(Metric)
Up To:
770 9in (23cm) wide x 4-1/2in (11cm) high $27.57 — 12 9in 23cm
770LHC
2-7/8in (73mm) Die Cast Padlock and Steel Hasp
$59.57 — 6 9in 23cm
NOTE: For additional hasps, see Retail Price Book.
Retail Carded Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Hasp
Length
Accepts
Shackle
Dia. Up To:
Hasp
Length
(Metric)
Accepts
Shackle Dia.
(Metric)
Up To:
720DPF
6-1/4in (16cm) Single-hinge; Series Packaging
$10.43 4 24 6-1/4in 7/16in 16cm 11mm
721DPF 8in (20cm) Single-hinge; Series Packaging $14.57 4 24 8in 7/16in 20cm 11mm
722DPF 7-3/4in (20cm) Double-hinge;
Series Packaging $11.86 4 24 7-3/4in 7/16in 20cm 11mm
Commercial Boxed Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Hasp
Length
Accepts
Shackle
Dia. Up To:
Hasp
Length
(Metric)
Accepts
Shackle Dia.
(Metric)
Up To:
730 7-1/4in (18cm) Straight Bar $10.93 6 24 7-1/4in 7/16in 18cm 11mm
731 90º Angle Bracket $10.49 6 24 5-3/16in 7/16in 13cm 11mm
732 90º Angle Bar $12.29 6 24 4-3/4in 7/16in 12cm 11mm
48
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Standard Products
Steel padlock eyes with large diameter shackle hole
Mount virtually anywhere
Ideal for gates and shed doors
Add safety lockout capabilities to older equipment
Padlock Eyes
Hasps with integral locking mechanisms for security and convenience
Hardened steel hasps with laminated steel lock body
4-pin tumbler cylinder helps prevent picking
Ribbed hasp plate for extra strength
Hardened steel locking eye for strong cut resistance
No. 450 Hasplock
Padlock Eyes
Hasplocks
No. 60R
No. 60
No. 475D
Commercial Boxed Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Hasp
Length
Accepts
Shackle
Dia. Up To:
Hasp
Length
(Metric)
Accepts
Shackle Dia.
(Metric)
Up To:
General-Use Hasplocks, Warded Mechanism
450D
Keyed Different; Retail Carded
$14.22 4 24 4-1/2in 1-3/4in 11cm 44mm
Commercial Boxed Products
Product
Number Description List
Price
(Each)
Shelf
Pack
Quantity
Master
Carton
Quantity
Accepts
Shackle Dia.
Up To:
Accepts
Shackle Dia.
(Metric)
Up To:
60 Flat Orientation, One pair $3.32 12 72 1/2in 13mm
60R Right-angle Orientation, One pair $3.75 6 72 1/2in 13mm
49
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Product Displays
1314 1315
Commercial Product Display Panels
Commercial Product Displays
Commercial Products
Product
Number Description Display
List Price
(Each)
Display
Carton
Quantity
Commercial Product Wall Displays
1314
Commercial Security Product Assortment (Small) Product Kit; (2) of each of the following products -
Master Lock: 1DLJCOM 2 1/2in laminated steel padlock - hardened steel shackle,
175D Four Digit Combination brass case padlock and 6121D Weather Tough® padlock
American Lock: A21D Solid Brass High Security padlock
Individual product header cards and (4) product hooks included.
$158.84 2
1315
Commercial Security Product Assortment (Medium) Product Kit; (2) of each of the following products -
Master Lock: 1DLJCOM 2 1/2in laminated steel padlock - hardened steel shackle, 5DCOM 2in laminated steel
padlock - boron shackle, 175D Four Digit Combination brass case padlock
and 6121D Weather Tough® padlock
American Lock: A875D Straight Bar Single Hinge hasp, A21D Solid Brass High Security padlock and A700D
Solid Steel High Security padlock - 1 1/16in Boron Alloy Steel Shackle
18in wide banner, individual product header cards and (8) product hooks included.
$277.68 2
1316
Commercial Security Product Assortment (Large) Product Kit; (2) of each of the following products -
Master Lock: 1DLJCOM 2 1/2in laminated steel padlock - hardened steel shackle, 5DCOM 2in laminated steel
padlock - boron shackle, 175D Four Digit Combination brass case padlock
1175D Pro Series® resettable combination padlock, 6121D Weather Tough® padlock,
6321D Pro Series® Rekeyable High Security padlock and 5422D Portable Lock Box
American Lock: A875D Straight Bar Single Hinge hasp, A21D Solid Brass High Security padlock, A700D Solid
Steel High Security padlock - 1 1/16in Boron Alloy Steel Shackle,
A5260D Solid Steel High Security Rekeyable padlock - 1 1/8in Boron Alloy Steel Shackle and
A800LHCD Hidden Shackle Padlock and Hasp
18in wide banner, individual product header cards and (15) product hooks included.
$654.18 2
1316
Attractive Displays generate impulse sales
Customers are able to handle real products
Illustrations and product feature copy help
make selection easy
Commercial Products
Product
Number Description List Price
(Each)
Display
List Price
(Each)
Display
Carton
Quantity
Showroom Signage
MLLOCKSIGN
Master Lock Security and Safety Sold Here,
Header Sign,
24in x 10in NA 0.00 1
MLLOCKSIGN
50
Government Locks
6001 6002 6004
M Where required Master Lock products are designed to stringent government standards,
CID-A-A-59486, CID-A-A-56487 and ASTM F883
M BumpStop® Advanced Cylinder Technology option exceeds ASTM Grade 6 resistance to
surreptitious attack
M Make-to-order capability – security products built and keyed to your requirements: shackle
options, keying flexibility, laser engraving, key control and custom sets available
M 5-pin tumbler cylinder for added security
M More than 10,000 key changes available for maximum pick resistance
M Dual locking for superior pry resistance
M Most models are stamped "US"; sets are stamped "US SET"
M Non-removable keys available for added security
As the world’s largest manufacturer of padlocks and portable security products, Master Lock has set the standard for
quality and selection for more than 90 years. Building on this tradition, Master Lock continues to expand its commercial
products and services to better meet our customers changing security requirements. Trust Master Lock for the
innovative products, security, support and service you need.
Over the past 50 years Master Lock, as a prime contractor and subcontractor, has supplied every segment of Defense,
Federal, State and Local Governments. Master Lock has over 85 National Stock Numbers (NSN) assigned to its product
line. Through distribution Master Lock has in aggregate over 550 line items in GSA Advantage and 31 NSN line items
referenced in DOD Emall. Master Lock also supplies retail product to AAFES, Navy, Marines and the U.S.Coast Guard.
See www.masterlock.com/government for complete listing of NSNs, Make-to-Order products and pricing.
51
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Services
Each Master Lock padlock has its own specific numbered key number. The products and appropriate key numbers are listed in the cut key listing, pages 54-55.
To order a specific key number, specify product number followed by a key number. If no key number is indicated, Master Lock will select a random key
number from the appropriate range.
Example: 12 No. 5KA = 12 No. 5 padlocks keyed alike to a randomly-selected key number in range A101-A2084
12 No. 5KA A101 = 12 No. 5 padlocks keyed alike to key number A101
Laser Engraving (LZ)
Laser Engraving allows for easy identification of padlocks that is a permanent mark on the padlock that cannot be removed. Some
applications are: Safety Lock-out, Employee locker identification, Company logos for brand identification. Four areas on an Master Lock solid body aluminum
and brass can be engraved for easy padlock identification. Numbers, letters, company logos, or alphanumeric characters can be added to a padlock. Logo
engraving available in Area 1 & 3 only. There are a variety of type styles and sizes for text to choose from, or a customer can send a copy of their company
logo and Master Lock can permanently engrave it on a padlock. Not recommended for clear locks. Contact Master Lock for order forms.
Key Number Range By Products
Keying Options
Padlock Options
KEY CHARTING
Customers can benefit fully from the large Master Lock change key ranges by having us chart your keying system for you. We will keep a complete record of the progressive
key codes assigned and manufactured into your padlocks for each order. You will be assured that there is no unwanted key duplication with the padlocks you purchase over
time. Be sure to request this special service with your next order so that all locks purchased from that point forward will be manufactured to comply with your key system
requirements. Any orders placed by an end user or distributor should note that they are on a key charting system or reference their End User I.D. Number.
Other Stamping Options Color Coding - Some padlocks are available with colored bumpers
or lock bodies for easy department identification. (List Price adder =
$.36/ea.)
Chain and Tag Attachments - Small chains may be attached to
padlock shackles in order to affix padlocks to truck doors, gates,
equipment, or other applications. Brass tags may be affixed to
padlocks for identification purposes. These items are available
separately. or can be attached at the factory.
Reserved Key System (RSV) List Price adder = $7.35/ea.
MKeyed Alike (KA) - This provides insame keyin convenience and eliminates the need for multiple keys where numerous
padlocks are used. All padlocks in the set are keyed the same. Most Master Lock padlocks can be ordered keyed alike.
Keyed alike padlocks are listed in this price book with a "KA" suffix in the product number.
Master Keyed (MK) - In a master keyed system, the master key opens all locks in the system although each
lock has its own unique key. Master keyed items are ideal for permitting supervisory or emergency access.
Master keyed padlocks are listed in this price book with an "MK" suffix in the product number.
Rekeyable Padlocks - Padlock cylinders can be removed and replaced to restore security quickly without
requiring a new padlock. This is ideal for situations where keys are lost or stolen due to theft or employee
turnover. Rekeyable padlocks are found on pages 25-28.
Reserved Key Systems (RSV) - Reserved key padlocks are not available to the general public and are
not listed in this price book. Key blanks and cut keys are supplied directly by Master Lock through
distributors and dealers when requested by registered end users. This adds security through the restricted
distribution of duplicate keys. This option requires a custom quotation (see page 1).
Edge® Key Control - Keys for this patent pending key control product offer the ultimate protection against
unauthorized duplicate keys. Blank keys are available to locksmiths only and controlled by contract.
These keys are recommended for all master keys applications. Contact your local locksmith for full details
.
Non-Removable Key (NR) - The key cannot be removed from the padlock when the padlock is open.
This helps prevent users from accidentally leaving
the padlock in the open position. Only selected padlocks offer this option.
Price/ea.
Key Stamping: Alpha numeric characters (HSK)* $1.00
I.D. Tag
Tag Stamping: Alpha numeric characters (HST) $2.05
$1.00
Interchangeable Core Stamping Bottom of Cylinder (VKC)
Concealed Side of Cylinder (CKC) $1.10
$1.10
Ink Stamp Key Number on Bottom Plate (INK) $0.35
Hard Stamp Key Number on Bottom Plate (HSTP) $1.15
*Note: Key Stamping: (HSK) Alpha numeric characters (Priced PER KEY)
52
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Commercial Product Components
Service Parts — Padlock Cylinders
Base Model
Description Price/ea.
297 Cylinder for Pro Series® Hockey Puck (Models 6270 & 6271) 1 unit/package,
Shelf Pack = 6, Master Carton = 120 $11.55
296 Cylinder for Pro Series® Padlocks (6121, 6125, 6127, 6321, 6325, 6327, 6830, 6835,
6840, 6850, 7030, 7040, 7045 & 7050 padlocks) 1 unit/package, Shelf Pack = 12,
Master Carton = 240 $5.28
295 5-pin Cylinders for Rekeyable Padlocks (21, 24, 25, 27, 101, 220 & 230 padlocks)
1 unit/package, Shelf Pack = 12, Master Carton = 240 $4.62
294 4-pin Cylinders for Rekeyable Padlocks (21, 24, 25, 27, 101, 220 & 230 padlocks*) -
includes special plug extension 1 unit/package, Shelf Pack = 12, Master Carton = 240 $3.80
*220 & 230 padlocks require a 0230-0334 plug extension, order separately.
Example 296 KA W6000 $6.33
K6000
W6000
K81
W81
K27
W27
K17
W17
K15
W15
K2
W2
K1
W1
K7000
W7000
Exceeds ASTM F883-09
Grade 6
BumpStop® Cylinder Technology
N
Anti-Bump Cylinder Technology
(Not available with UN or KZ option)
$1.05
Keying
Standard: Keyed Different
UN Uncombinated (Zero bitted cylinder & no keys) -
(Used exclusively with WP6 or WP4 options only) –$4.00
KZ Zero-Bitted
$0.00
KA
Keyed Alike $1.05
MK
Master Keyed $4.95
KAMK
Keyed Alike; Master Keyed $6.00
Cylinder REQUIRED
CHOICE
W1 4-pin W1 cylinder (296 & 294 Option Only) $0.00
W1RSV 4-pin W1RSV cylinder (294 Option Only) $7.35
W2K 4-pin W2 cylinder (294 Option Only) $0.00
W15 5-pin W15 cylinder (296 & 295 Option Only) $0.00
W17 5-pin W17 cylinder (296 & 295 Option Only) $0.00
W27 5-pin W27 cylinder (296 & 295 Option Only) $0.00
W81 5-pin W81 cylinder (296 & 295 Option Only) $0.00
W81KM 5-pin W81KM cylinder (295 & 296 Option Only) $0.00
W81RSV 5-pin W81RSV cylinder (295 & 296 Option Only) $7.35
W6000 5-pin W6000 cylinder (297 & 296 Option Only) $0.00
W7000 6-pin W7000 cylinder (297 & 296 Option Only) $0.00
W7000NISI 6-pin W7000 cylinder (297 & 296 Option Only) with Nickel Silver Key $1.00
W600A 5-pin American Lock® W600A cylinder (297, 296 & 295 Option Only) (Available with
KA & KZ option only) $0.00
W700A 6-pin American Lock® W700A cylinder (297 & 296 Option Only) (Available with KA &
KZ option only) $0.00
WP4
Edge
®
Key Control 4-pin cylinder. Standard: Nickel Silver Keys (297, 296 & 294 Option Only)
$9.80
WP6
Edge
®
Key Control 6-pin cylinder. Standard: Nickel Silver Keys (297 & 296 Option Only)
$9.80
Hard Stamp
HSK Hard Stamp Key $1.00/Key
Number of Keys
Standard: 2 keys per lock WP Option Keys Standard Keys
1KEY
1 key per lock –$2.00 $0.00
3KEY
3 keys per lock $5.00 $1.50
4KEY
4 keys per lock $10.00 $3.00
NOKEY
0 keys per lock –$4.00 $0.00
53
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Commercial Product Components
Pin
Tumbler
MSpecify key code when ordering
Duplicate Cut Keys
Description Key
Lock Models Cylinders Key Numbers
OBSOLETE
Cut Key Product Number Cut Key
Product
Number
List
Price
(Each)
Units /
Package
(Each)
Cut Regular Cut Master
Pin Tumbler Cut Keys
Nos. 1, 2, 187, 475, 1803 and 1805 W1
2001 - 2997 X2000 -
X2998
K1CR K1CM K1 3.88 1
Nos. 3, 4, 11, 34, 35, 36, 37, 39, 40, 190,
311, 312, 315, 317, 430, 443, 631 and 1317
W1
0301 - 0950 3030 -
3999
K1CR K1CM K1 3.88 1
Nos. 5 and 6 W1
A101 - A2084
K1CR K1CM K1 3.88 1
Nos. 1MK2K, 2MK2K, 3MK2K, 4MK2K,
5MK2K, 6MK2Kand 11MK2K W2K
Customer Provided
N/A K2CM K2 3.88 1
Nos. 1RSV, 2RSV, 3RSV, 4RSV, 5RSV
and 6RSV W1RSV
1C001 - 2C367
K1CRRSV K1RSVCM K1RSV 3.88 1
Nos. 7, 8, 90, 176, 185, 189, 716, 719 and
1807 W7
P104 - P851 K1973 -
K2924
K7CR K7CM K7 3.88 1
Nos. 7RSV and 8RSV W7RSV
7P001 - 7P672
K7CRRSV K7RSVCM K7RSV 3.88 1
No. 15, 220, and 230 W15
10N001 - 19N950
K15CR K15CM K15 3.88 1
No. 17 W17
10T001 - 19T599
K17CR K17CM K17 3.88 1
Nos. 21, 24, 25, 27, 31 and 101 W27
10L001 - 19L616
K27CR K27CM K27 3.88 1
Nos. 81, 82, 530, 532, 533, 570, 571, 991,
992 and 996 W81
10R01 - 109R10
K81KRCR K81KMCM K81 3.88 1
Nos. 81RSV and 82RSV W81RSV
W81KM
10X01 - 109X10
K81CRRSV K81RSVCM K81RSV 3.88 1
Customer Provided
K81KM 3.88 1
Nos. 911, 930 and 931 W900
10Z001 – 19Z950
K900CR K900CM K900 3.88 1
Pro Series® 5-pin standard cylinders W6000
10G001 - 34G157
K6000CR K6000CM K6000 3.88 1
Pro Series® 6-pin standard cylinders W7000
400K001 - 594K569
K7000CR K7000CM K7000 3.88 1
American Lock® 5-pin standard cylinders W600A
Random
K600ACR K600ACM K600A 3.88 1
American Lock® 6-pin standard cylinders W700A
Random
K700ACR K700ACM K700A 3.88 1
Edge
®
Key Control Products 6-pin cylinders
WP6
400XX001 - 594XX569
KWP6CR KWP6CM KWP6 5.50 1
Edge
®
Key Control Products 4-pin cylinders
WP4
2001XX - 2997XX
X2000XX - X2998XX
KWP4CR KWP4CM KWP4 5.50 1
Key-In-Knob Duplicate Cut Keys (Please specify number when ordering)
Falcon® (composite) Key - 5 Pin D13
13T1001 – 13T9999
KD13CR KD13CM KD135 $3.88 1
Kwikset® (composite) Key - 5 Pin D12
12T1001 – 12T3422
KD12CR KD12CM KD125 $3.88 1
Schlage® C Key - 5 Pin D04
04T1001 – 04T9999
KD04CR KD04CM KD045 $3.88 1
Schlage® C Key - 6 Pin D04
04V10001 – 04V65536
KD04CR KD04CM KD046 $3.88 1
Schlage® P Key - 5 Pin D28 04T1001 – 04T9999 KD04CR KD04CM KD045 $3.88 1
Schlage® P Key - 6 Pin D28
04V10001 – 04V65536
KD04CR KD04CM KD046 $3.88 1
Weiser® (composite) Key - 5 Pin D13
13T1001 – 13T9999
KD13CR KD13CM KD135 $3.88 1
Yale® 8 Key - 5 Pin D03
03T1001 – 03T9999
KD03CR KD03CM KD035 $3.88 1
Yale® 8 Key - 6 Pin D03
03V10001 – 03V65536
KD03CR KD03CM KD036 $3.88 1
Description Key
Lock Models Cylinders Key Numbers
OBSOLETE
Cut Key Product Number Cut Key
Product
Number
List
Price
(Each)
Units /
Package
(Each)
Cut Regular Cut Master Control Keys
Interchangeable Core: Duplicate Cut Keys & Control Keys
Best® Lock “A” Keyway CA Customer provided
Key number stamped
on original key.
KCACR KCACM KCACONTROLKEY KCA $4.68 1
Standard “Y” Keyway CY KCYCR KCYCR KCYCONTROLKEY KCY $4.68 1
54
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Commercial Product Components
K600A K700A K900 K6000 K7000
MExact replacement blanks for genuine Master Lock keys
MBest choice for Universal Pin applications
MBlanks with black covered key heads also available
MSolid brass blanks are easy to cut and resist corrosion
MBlanks for American W600A and W700A cylinders available
K150 K8186
K15 K1 K7 K500 K105 K22 K10
Pin
Tumbler Warded Corrugation
Left-Hand Right-Hand
(as viewed on locks)
Key Blanks
Commercial Products
Product
Number Description List Price
(Per Box) Units
(Per Box)
Standard Padlock Key Blanks
K1BOX
For Nos. 1, 2, 3, 4, 5, 6, 11, 34, 35, 36, 37, 39, 40, 238, 255, 311, 312, 315, 317, 380 430, 443, 475, 613,
1317, 1377, 1472, 1473, 1474, 1479, 1480, 1481, 1803, 1805, 2848, 2866, 3774, 8401, 8413 and 8423
locks and Pro Series® locks with W1 cylinder option $22.11 50
K1RSVBOX
For Nos. 1, 2, 3, 4, 5, 6, 11, 311, 312, 317, 430 and 443 locks and Pro-Series
®
locks with W1RSV cylinder option
$29.61 50
K2BOX For Master Lock 5-pin, W2K cylinders in Nos. 1, 2, 3, 4, 5, 6 and 11 locks $22.11 50
K7BOX For Nos. 7, 8, 90, 97, 716, 719, 1807, 8417, 8418 and 8419 locks $22.11 50
K7RSVBOX For Nos. 7 and 8 locks $29.61 50
K15BOX For No. 15, 220, and 230 locks and Pro Series® locks with W15 cylinder option $22.11 50
K17BOX For No. 17 locks and Pro Series® locks with W17 cylinder option $22.11 50
K27BOX For Nos. 21, 24, 25, 27, 31, 101, 220 and 230 locks and Pro Series® locks with W27 cylinder option $22.11 50
K81BOX For Nos. 81, 82, 530, 532, 533, 570, 571, 575, 576, 751, 991, 992, 996, 1710 and 1714 locks and Pro
Series® locks with W81 cylinder option $22.11 50
K81KMBOX For Nos. 81 & 82 locks and Pro-Series® locks with 5-pin W81KM cylinder option $22.11 50
K81RSVBOX For Nos. 81, 82 locks and Pro-Series® locks with 5-pin W81RSV cylinder option $29.61 50
K120BOX For Nos. 120, 121, 1820, 1825 and 4120 locks $22.11 50
K130BOX For Nos. 130, 131, 132, 133, 134, 135, 136, 140, 141, 142, 143, 144, 145, 146, 372, 605, 614, 631, 635,
645, 1830, 1840, 4130 and 4140 locks $22.11 50
K150BOX For Nos. 150, 151, 160, 373, 527, 590, 640 and 4150 locks $22.11 50
K600BOX For Master Lock products only utilizing a 5-pin, W600A standard American Lock cylinder $22.11 50
K700BOX For Master Lock products only utilizing a 6-pin, W700A standard American Lock cylinder $29.10 50
K900BOX For Nos. 911, 930, 931 and 937 locks $22.11 50
K6000BOX For Master Lock 5-pin, W6000 cylinders $29.10 50
K7000BOX For Master Lock 6-pin, W7000 cylinders $29.10 50
K7000NISIBOX For Master Lock 6-pin, W7000 cylinders, Nickel Silver $54.60 50
KWP6BOX For 6-pin Nickel Silver, Edge® Key Control.
Please specify Dimple Pattern & Identification Code
$112.20 50
KWP4BOX For 4-pin Nickel Silver, Edge® Key Control.
Please specify Dimple Pattern & Identification Code
$112.20 50
K8109BOX For No. 8109 locks $26.78 25
K8121BOX For No. 8118 locks $26.78 25
K8154BOX For No. 8154 locks $26.78 25
Warded Key Blanks
K22LBOX For No. 22 locks with left-hand corrugation $11.40 50
K22RBOX For No. 22 locks with right-hand corrugation $11.40 50
K105BOX For Nos. 105, 116 and 119 locks $11.40 50
K500LBOX For Nos. 450 and 500 locks with left-hand corrugation $11.40 50
K500RBOX For Nos. 450 and 500 locks with right-hand corrugation $11.40 50
K510BOX For Nos. 510, 517 and 518 locks $11.40 50
Combination Change Keys
K175BAG For Nos. 175, 176, 177 and 178 locks $2.60 10
Small Format Interchangeable Core Blanks
KCABOX Best® Lock “A” Keyway $38.71 50
KCYBOX Standard “Y” Keyway $38.71 50
55
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Commercial Product Components
Contains extensive assortment of the most frequently used pin tumbler service components
New case with deep storage compartments and sealing cover keeps parts in their place
Convenient reference chart included
Rekeying part refills may be ordered separately
Pin Tumbler Rekeying Kit
)
Designed specifically for padlocks, door locks, automotive, marine, and multipurpose applications!
Keep your locks operating like new in any environment – Snow, rain, freezing temperatures,
marine, extreme heat.
Designed specifically for precision lock components – prevents rust, corrosion, and loosens
stuck parts.
Precision Nozzle – Designed specifically for precise application inside locking devices.
Synthetic oil with PTFE formula – Provides a long lasting protective shield against dust, dirt, salt
and moisture.
Outstanding temperature range – Synthetic formula operates in cold weather (-45ºF) when mineral
based aerosols won’t. Prevents water build up & freezing lock components.
Non-toxic & biodegradable – Better for the environment.
Prolong the life of your lock – Apply 2-3 drops in key hole and shackle openings every three to six
months for trouble free operation.
Lock Lubricant
Commercial Products
Product
Number Description List Price
(Per Kit
or Bag)
Units
(Per Kit
or Bag)
Rekeying Kit
291 Rekeying Kit $87.99 1
Commercial Boxed Products
Product
Number Description List Price
(Each)
Master
Carton
Quantity
2305 5.25 oz. Aerosol Can, PTFE Dry Formula $10.57 12
2311 11 oz. Aerosol Can, PTFE Dry Formula $13.74 12
2300D 0.25 oz. Pen, PTFE Oiler, Retail Carded Package $5.47 12
56
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Commercial Product Components
Rekeying Parts
(continued)
Commercial Products
Product
Number Description List Price
(Per Kit
or Bag)
Units
(Per Kit
or Bag)
Cylinder Pins - Regular
0001-0360 #0 Pin (Black) $4.04 200
0001-0361 #1 Pin (Violet) $4.04 200
0001-0362 #2 Pin (Red) $4.04 200
0001-0363 #3 Pin (Blue) $4.04 200
0001-0364 #4 Pin (Yellow) $4.04 200
0001-0365 #5 Pin (Green) $4.04 200
0001-0366 #6 Pin (Brown) $4.04 200
0001-0367 #7 Pin (Black) $4.04 200
Cylinder Pins - Master
0001-0391 #1 Master Pin (Violet) $4.04 200
0001-0392 #2 Master Pin (Red) $4.04 200
0001-0393 #3 Master Pin (Blue) $4.04 200
0001-0394 #4 Master Pin (Yellow) $4.04 200
0001-0395 #5 Master Pin (Green) $4.04 200
0001-0396 #6 Master Pin (Brown) $4.04 200
0001-0397 #7 Master Pin (Black) $4.04 200
Driver Pins & Tumbler Springs
0296-0322 Spool Pins For 6000B and 7000B cylinders $4.04 200
0296-0323 Driver Pin For 6000B and 7000B cylinders $4.04 200
6121-0419 Driver Pins - Spool Design (Regular) $4.04 200
0001-0368 Driver Pins (Regular) $4.04 200
0007-0368 Driver Pins - Non Spool Design (Master) $4.04 200
0001-0369 Tumbler Springs, Stainless Steel $4.04 200
Miscellaneous Cylinder Parts
0296-0324 E Clip for 6000B and 7000B $2.49 12
0296-0200 Edge® Cylinder Ball Bearings, 3/32in Diameter $4.84 200
APKG0049816 Edge® Cylinder Set screw, 5-40 x 1/8in Socket $15.05 100
Plug Extension for W1 Cylinder
0027-0334 For 4-pin W1 cylinders in Nos. 21, 24, 25, 27, and 101 locks $3.03 10
Pro Series® Shells & Plugs
6121-0390
Cylinder Shells For Pro Series® W1, W15, W17, W27, W81KR, W81MK, and W6000 cylinders only
$18.68 12
6121-0391 Cylinder Shells For Pro Series® W600A and W700A cylinders only $18.68 12
6121-0400 Cylinder Plugs For Pro Series® W1 cylinders only $18.68 12
6121-0401 Cylinder Plugs For Pro Series® W15 cylinders only $18.68 12
6121-0402 Cylinder Plugs For Pro Series® W17 cylinders only $18.68 12
6121-0403 Cylinder Plugs For Pro Series® W27 cylinders only $18.68 12
6121-0404 Cylinder Plugs For Pro Series® W81 cylinders only $18.68 12
6121-0405 Cylinder Plugs For Pro Series® W81KM cylinders only $18.68 12
6121-0406 Cylinder Plugs For Pro Series® W600A and W700A cylinders only $18.68 12
6121-0407 Cylinder Plugs For Pro Series® W6000 and W7000 cylinders only $18.68 12
Stainless Steel Ball Bearings
0220-0302 For Pro Series® locks Nos. 6830, 6831, and 6835 (Curved Body) locks $4.07 10
6121-0427 For all Pro Series® locks except Nos. 6830, 6831, and 6835 (Curved Body) locks $2.97 12
APKG1806010 Stainless Steel ¼in (6mm) Diameter, for No 6835 (Rectangular Body) $2.42 12
57
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Commercial Product Components
Rekeying Parts
(continued)
Commercial Products
Product
Number Description List Price
(Per Kit
or Bag)
Units
(Per Kit
or Bag)
Actuators
6121-0423 Non-Key Retaining Actuator For Nos. 6100, 6300, 6400, 6500, 6600, 6700, 7042, 7047 & 7052 series locks $10.79 6
6121-0424 Non-Removable Key Actuator For Nos. 6100, 6300, 6400, 6500, 6600, 6700, 6841, 6842, 6851, 6852,
7040, 7041, 7042, 7045, 7046, 7047, 7050, 7051 & 7052 series locks $10.49 6
6121-0425 Non-Key Retaining Actuator For No. 6230 lock $11.20 6
6121-0426 Non-Removable Key Actuator For No. 6230 lock $10.89 6
6421-0451 SFIC Throw Member For Pro Series® Small Format Interchangeable Core (SFIC) Series 6421, 6427, 6521,
6527, 6831, 6836, 6841, 6851, 7031, 7036, 7041, 7046 and 7051 locks $14.84 6
6421-0452 SFIC Actuator Retainer For Pro Series® Small Format Interchangeable Core (SFIC) Series 6421, 6427,
6521, 6527, 6831, 6836, 6841, 6851, 7031, 7036, 7041, 7046 and 7051 locks $1.47 6
6421-0453 SFIC Retainer Clip For Pro Series® Small Format Interchangeable Core (SFIC) Series 6421, 6427, 6521,
6527, 6831, 6836, 6841, 6851, 7031, 7036, 7041, 7046 and 7051 locks $1.47 6
6830-0421 Non-Key Retaining Actuator For Nos. 6830 locks $10.79 6
6831-0421 Non-Key Retaining Actuator For Nos. 6831, 6835 (Curved Body), 6836, 7030, 7031, 7035 and 7036 locks $10.79 6
6830-0422
Non-Removable Key Actuator For Nos. 6830, 6831, 6835 (
Curved
Body), 6836, 7030, 7031, 7035 & 7036 locks
$10.79 6
6841-0421
Non-Key Retaining Actuator For Nos. 6840, 6841, 6842, 6850, 6851, 6852, 7040, 7041, 7045, 7050 and 7051 locks
$11.20 6
APKG0001669 Non-Key Retaining Actuator, For No. 6835 (Rectangular body) $14.50 6
APKG0001670 Non-Removable Key Actuator, For No. 6835 (Rectangular body) $14.50 6
Cylinder Retaining Trap Doors, Covers, Nuts & Screws
Pro Series®
6121-0420 Retainer Trap Door For Nos. 6121, 6125, 6127, 6230, 6321, 6325, 6327, 6840, 6850, 7035, 7040, 7045
and 7050 locks $6.75 12
6830-0420 Retainer Trap Door For Nos. 6830, 6835 (Curved Body) and 7030 locks $6.75 12
6121-0421 Locking Nut For Nos. 6121, 6125, 6127, 6230, 6321, 6325, 6327, 6830, 6835 (Curved Body), 6840, 6850,
7030, 7035, 7040, 7045 and 7050 locks $4.94 12
6121-0422 Retainer Screw For Nos. 6121, 6125, 6127, 6230, 6321, 6325, 6327, 6830, 6835 (Curved Body), 6840,
6850, 7030, 7035, 7040, 7045 and 7050 locks $4.68 12
APKG4680210
Trap Door for No. 6835 (Rectangular Body) for W2K, W17, W81, W81KM, W417, W427, W481, W600A, W700A
$13.96 10
APKG4680220 Trap Door for No. 6835 (Rectangular Body) for keyways W1, W1RSV, W15, W81RSV, W400, W401, W410,
W6000, W7000, WP4, WP6 $13.96 10
APKG4746010 Nut, Security, For No. 6835 (Rectangular Body) $7.26 25
APKG4761010 Screw, Security, For No. 6835 (Rectangular Body) $3.32 25
Rekeyable Laminated
0021-0372 Cylinder Retaining Trap Door For No. 21 locks $3.63 10
0021-0373 Locking Nuts For Nos. 21 and 101 locks $3.63 10
0024-0372 Cylinder Retaining Trap Door For No. 24 locks $4.21 10
0024-0373 Locking Nuts For No. 24 locks $4.21 10
0021-0305 Retainer Screw For Nos. 21, 24, and 101 locks $3.63 10
0027-0371 Cylinder Retaining Trap Door For No. 27 locks $5.42 10
0027-0373 Locking Nuts For Nos. 25 and 27 locks $5.42 10
0027-0305 Retainer Screw For Nos. 25 and 27 locks $4.04 10
0101-0372 Cylinder Retaining Trap Door For No. 101 locks $6.06 10
Tools & Gauges
0021-0374 Hex Wrenches (3/32in) $4.07 10
0027-0374 Hex Wrenches (7/64in) $4.04 10
0290-0371 Key Cut Gauge For Flat Back Keys $19.75 10
0290-0373 Key Cut Gauge For 6000B and 7000B Round Back Keys $19.75 10
0290-0372 Cylinder Assembly Tool $22.76 10
0290-0630 Set of Depth Keys For Nos. 1, 2, 3, 4, 5, 6, 15, 17, 21, 24, 25, and 27 locks $85.03 5
0290-0631 Set of Depth Keys For Nos. 81 and 82 locks $85.03 5
0290-60612 Edge® Follower $6.50 1
APKG0062260
1/16in Allen Wrench $4.07 1
58
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Commercial Product Components
Padlock Chains, Tags & Collars
Commercial Products
Product
Number Description List Price
(Per Kit
or Bag)
Units
(Per Kit
or Bag)
Padlock Chains & Identification Tags
71CS 9in (23cm) long lightweight zinc plated steel chain with chain holder attached. Fits all Master Lock shackles
& shackle collars. Shackle collars must be ordered separately. $21.84 12
71CH 9in (23cm) long heavy-duty zinc plated steel chain with chain holder attached. Fits all Master Lock shackles
& shackle collars. Shackle collars must be ordered separately. $32.09 12
71SHKS Chains with "S" Hooks, 9in (23cm) chain with pair of mounting "S" hooks. $16.59 12
71TAG Brass Identification Tags, 1/2in x 1-3/4in (13mm x 44mm) brass tag with ring for attaching to shackle collars
listed below $18.96 12
Shackle Collars
71SC7
Fits 7/32
in
(6mm) diameter shackles and smaller For Nos. 7, 7LF, 7LF, 8, 8LF, 105 and 105LF locks; includes rivets
$11.94 12
71SC8
Fits 1/4
in
(6mm) diameter shackles and smaller For Nos. 22 and 22LF, 410, 411, 6830, 6831, 6835, 6836,
7030
& 7031 locks, Also for American Lock® Nos. A1105, A1106, A1107,A1165, A1166, A1167 locks; includes rivets
$11.94 12
71SC9 Fits 9/32in (7mm) diameter shackles and smaller For Nos. 3, 3LF, 3LH, 4, 4LF, 4LH, 11, 500, 500LF, 1500
series & 1525 locks; includes rivets $11.94 12
71SC10
Fits 5/16
in
(8mm) diameter shackles and smaller For Nos. 1, 1LF, 1LJ, 1LN, 2, 2LF, 2LJ, 21, 21LF, 21LJ, 21LN,
24, 24LF, 24LJ, 24LN, 81, 81LF, 81LJ, 81LN, 82, 82LF, 82LJ, 101, 175, 175LH, 2001, 2002, 2010, 6121, 6840,
6841, 6842, 7040, 7041 and 7042 locks; includes rivets.
$11.94 12
71SC12 Fits 3/8in (10mm) diameter shackles and smaller For Nos. 5, 5LF, 5LJ, 6, 6LF, 6LJ, 25, 25LF, 25LJ, 6125,
6850, 6851, 6852, 7050, 7051 and 7052 locks; includes rivets $11.94 12
71SC14 Fits 7/16in (11mm) diameter shackles and smaller For Nos. 15, 17, 220, 220LH, 230, 230LH, 27, 27LH,
6230 and 6327 locks; includes rivets. $11.94 12
Shackles for Rekeyable Padlocks
Commercial Products
Product
Number Description List Price
(Each) Units/
Package
Pro Series® Padlock Shackles & Shackle Springs
1/4in (6mm) Diameter
293S6830 Boron, 1-1/8in (29mm) vertical clearance shackles For Nos. 6830, 6831, 6835 (Curved Body), 6836, 7030,
7031 Pro Series® padlocks $23.35 6
293LFS6830 Boron, 1-9/16in (40mm) vertical clearance shackles For Nos. 6830, 6831, 6835 (Curved Body), 6836, 7030,
7031 Pro Series® padlocks $32.69 6
293LTS6830 Boron, 3in (76mm) vertical clearance shackles For Nos. 6830, 6831, 6835 (Curved Body), 6836, 7030, 7031
Pro Series® padlocks $37.35 6
293BS6830 Brass, 1-1/16in (27mm) vertical clearance shackles For Nos. 6830, 6831, 6835 (Curved Body), 6836, 7030,
7031 Pro Series® padlocks $38.76 6
293BS6850 Brass, 1-1/2in (38mm) vertical clearance shackles For Nos. 6830, 6831, 6835 (Curved Body), 6836, 7030,
7031 Pro Series® padlocks $44.19 6
APKG1582980 Boron, Chrome Plated, 1in (25mm) vertical clearance For No. 6835 (Rectangular Body) $15.06 6
APKG1583180 Boron, Chrome Plated, 1-1/2in (38mm) vertical clearance For No. 6835 (Rectangular Body) $20.06 6
APKG1583210 Boron, Chrome Plated, 3in (75mm) vertical clearance For No. 6835 (Rectangular Body) $21.74 6
APKG1583240 Brass, 1in (25mm) vertical clearance For No. 6835 (Rectangular Body) $14.22 6
5/16in (8mm) Diameter
293S6121 Boron, 1-1/8in (29mm) vertical clearance shackles For Nos. 6121, 6421, 6621, 6840, 6841, 6842, 7040,
7041, 7042 Pro Series® padlocks $25.67 6
293LFS6121 Boron, 1-1/2in (38mm) vertical clearance shackles For Nos. 6121, 6421, 6621, 6840, 6841, 6842, 7040,
7041, 7042 Pro Series® padlocks $31.79 6
293LJS6121 Boron, 2-3/8in (60mm) vertical clearance shackles For Nos. 6121, 6421, 6621, 6840, 6841, 6842, 7040,
7041, 7042 Pro Series® padlocks $34.53 6
293LNS6121 Boron, 5-5/8in (14cm) vertical clearance shackles For Nos. 6121, 6421, 6621, 6840, 6841, 6842, 7040,
7041, 7042 Pro Series® padlocks $51.94 6
59
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Commercial Product Components
Shackles for Rekeyable Padlocks
(continued)
Commercial Products
Product
Number Description List Price
(Each) Units/
Package
Pro Series® Padlock Shackles & Shackle Springs (continued)
5/16in (8mm) Diameter (continued)
293LFS6121 Brass, 1-1/2in (38mm) vertical clearance shackles For Nos. 6121, 6421, 6621, 6840, 6841, 6842, 7040,
7041, 7042 Pro Series® padlocks $49.94 6
293LJBS6121
Brass, 2-1/2in (64mm) vertical clearance shackles For Nos. 6121, 6421, 6621, 6840, 6841, 6842, 7040,
7041, 7042 Pro Series® padlocks $49.94 6
293S6321
Boron, 3/4in (19mm) vertical clearance shackles for Nos. 6321, 6521, 6721 Pro Series® padlocks $25.67 6
3/8in (10mm) Diameter
293S6125 Boron, 1-3/8in (35mm) vertical clearance shackles For Nos. 6125, 6850, 6851, 6852, 7050, 7051, 7052
Pro Series® padlocks $28.78 6
293LJS6125 Boron, 2-3/8in (60mm) vertical clearance shackles For Nos. 6125, 6850, 6851, 6852, 7050, 7051, 7052
Pro Series® padlocks $37.65 6
293S6325 Boron, 3/4in (19mm) vertical clearance shackles For No. 6325 Pro Series® padlocks $25.67 6
7/16in (11mm) Diameter
293S6127 Boron, 1-3/8in (35mm) vertical clearance shackles For Nos. 6127, 6427, 6627 Pro Series® padlocks $28.78 6
293LHS6127 Boron, 1-7/8in (48mm) vertical clearance shackles For Nos. 6127, 6427, 6627 Pro Series® padlocks $33.26 6
293LJS6127 Boron, 2-3/8in (60mm) vertical clearance shackles For Nos. 6127, 6427, 6627 Pro Series® padlocks $37.65 6
293S6327 Boron, 3/4in (19mm) vertical clearance shackles For Nos. 6327, 6527, 6727 Pro Series® padlocks $25.67 6
293S6230 Boron, 1-1/8in (29mm) vertical clearance shackles For No. 6230 Pro Series® padlocks $28.78 6
293LHS6230 Boron, 2in (51mm) vertical clearance shackles For No. 6230 Pro Series® padlocks $33.26 6
Shackle Springs
6835-0306 For No. 6835 locks $2.33 6
APKG1613010
Spring, Shackle, 1/4in (6mm) Diameter, For No. 6835 (Rectangular Body) $2.30 25
Rekeyable Laminated Padlock Shackles
5/16in (8mm) Diameter for Nos. 21 and 24 Locks
292S21 Steel, 15/16in (24mm) vertical clearance shackles $14.99 5
292LFS21 Steel, 1-1/2in (38mm) vertical clearance shackles $20.69 5
292LJS21 Steel, 2-1/2in (64mm) vertical clearance shackles $22.42 5
292LNS21 Steel, 5-3/4in (15cm) vertical clearance shackles $36.89 5
292S21AST Steel, Assortment of Shackles; Two each of Nos. 292S21 and 292LNS21; Three each of Nos. 292LFS21
and 292LJS21; Shackle springs included $46.61 10
3/8in (10mm) Diameter for No. 25 Locks
292S25
Boron, 1
in
(25mm) vertical clearance shackles (Shackle springs preassembled
on 25WCS lock bodies) $17.92 5
292LFS25 Boron, 1-1/2in (38mm) vertical clearance shackles (Shackle springs preassembled on 25WCS lock bodies) $23.57 5
292LJS25 Boron, 2-1/2in (64mm) vertical clearance shackles (Shackle springs preassembled on 25WCS lock bodies) $25.30 5
7/16in (11mm) Diameter for No. 27 Locks
292S27
Boron, 1
in
(25mm) vertical clearance shackles (Shackle springs preassembled
on 27WCS lock bodies) $23.11 5
292LHS27
Boron, 2
in
(51mm) vertical clearance shackles (Shackle springs preassembled
on 27WCS lock bodies) $34.30 5
No. 443 Shackles
292S443 Steel, 5/8in (16mm) vertical clearance shackles $15.00 5
292LES443 Steel, 7/8in (22mm) vertical clearance shackles $15.49 5
292LKS443 Steel, 3-1/2in (89mm) vertical clearance shackles $26.18 5
60
KEY BLANKS: See pages 53-54 for respective key blanks or cut key information.
HH
Unless otherwise specied, Shelf Pack = 6, Master Carton = 24
HH
Commercial Product Components
Nos. 220 & 230 Service Parts
Commercial Products
Product
Number Description List Price
(Per Kit
or Bag)
Units
(Per Kit
or Bag)
General Parts for Nos. 220 and 230 Locks
0230-0304 Key Return Springs $3.03 10
0230-0306 Shackle Springs $3.03 10
0230-0334 Plug Extension For W1 cylinders $3.03 10
0230-1325 Non Key Retaining Actuator for a 4 pin cylinder $1.10 1
0230-1326 Non Removable Key Actuator for a 4 pin cylinder $1.10 1
0021-0374 Hex Wrenches (3/32in) $4.07 10
No. 220 Specic Service Parts
0220-0300 Deadbolt Pins $3.03 10
0220-0301 Anti-Saw Pins $3.03 10
0220-0302 Locking Balls $4.07 10
0220-0303 Shackle Stop Pins $2.42 10
0220-0305 Retainer Screws $4.07 10
292S220 Boron, 7/16in (11mm) Diameter Shackles, 1in (25mm) vertical shackle clearance $24.34 5
292LHS220 Boron, 7/16in (11mm) Diameter Shackles, 2in (51mm) vertical shackle clearance $35.52 5
No. 230 Specic Service Parts
0230-0300 Deadbolt Pins $3.03 10
0230-0301 Anti-Saw Pins $3.03 10
0230-0302 Locking Balls $4.07 10
0230-0303 Shackle Stop Pins $2.42 10
0230-0305 Retainer Screws $4.07 10
292S230 Boron, 7/16in (11mm) Diameter Shackles, 1in (25mm) vertical shackle clearance $28.92 5
292LHS230 Boron, 7/16in (11mm) Diameter Shackles, 2in (51mm) vertical shackle clearance $40.13 5
Door Key Compatible Parts
No. D200 Edge™ Tailpieces & Clips
APKG0049966 Tailpiece, Medium Door Knob Cylinder $4.57 10
APKG0056302 Tailpiece, Long Door Knob Cylinder $4.57 10
APKG0056303 Tailpiece, Short Door Knob Cylinder $4.57 10
APKG0049965 Clip, Tailpiece, Door Knob $2.82 10
Cylinder Drivers
0298-0625 For Lockwood® Australia Cylinder $10.26 6
0298-0626 For Lori® Cylinder #1539 6-pin cylinder for inAin series knob sets $10.26 6
0298-0627 For Medeco® Cylinder #20W200 6-pin cylinder for inAin series knob sets $10.26 6
0298-0628 For Schlage® 6-pin cylinder for inAin series knob sets $10.26 6
0298-0630 Assortment Pack; six each of Lori® 1539, Medeco® & Schlage® drivers $21.68 18
Cylinder Retainer Plugs & Screws
0298-0629 Cylinder Retainer Plugs $15.57 6
6621-0450 Retainer Screw For Series 6600 and 6700 and No. 6852 locks $2.97 12
Interested in more security products?
Explore Master Lock’s wide range of innovative products across all categories.
From industrial safety solutions to locker security, to door entry security there’s a solution
for every customer need – on the jobsite, at the ofce or in the eld.
SAFETY SOLUTIONS
PRODUCTS
Safety Padlocks, Lockout Devices,
Safety Identication Signs and Tags.
COMMERCIAL CARDED
PRODUCTS
ProSeries® Padlocks, ProSeries® Resettable
Combination Padlocks, ProSeries® Recodable
Solid Steel Padlocks, Commercial Laminated
Steel Padlocks.
DOOR HARDWARE PRODUCTS
Residential Door Hardware, Commercial Door
Hardware, Multi-Family Door Hardware,
Electronic Door Hardware.
CONSUMER SECURITY
RETAIL CARDED PRODUCTS
Laminated Padlocks, Brass Laminated Padlocks,
Shrouded Padlocks, Solid Body Padlocks,
Combination Padlocks, Carabiners, TSA Accepted
Luggage Locks, Gun Locks.
LOCKER AND STORAGE SECURITY
PRODUCTS
ADA Solutions, Multi-User Combination Locks,
Built-In Combination Locks, Built-In Keyed
Locks, Portable Combination Locks.
www.masterlock.com
www.masterlock.com
Master Lock Company LLC, Milwaukee, WI 53154 U.S.A. | 800-308-9244
Master Lock Canada, Mississauga, Ontario L5L 5Z9 Canada | 800-227-9599
© 2017 Master Lock Company | All Rights Reserved.
7000-0575 | MC/PRD 30M | Printed in the USA 12/16

Navigation menu
