Mattel Asia Pacific Sourcing FBL83-16A5R HOTWHEELS Ai INTELLIENT RACE SYSTEM-CAR (2.4GHz TRANSCEIVER) User Manual PIYFBL83 16A5R 4390C FBL8316A5R
Mattel Asia Pacific Sourcing Ltd. HOTWHEELS Ai INTELLIENT RACE SYSTEM-CAR (2.4GHz TRANSCEIVER) PIYFBL83 16A5R 4390C FBL8316A5R
User manual_PIYFBL83-16A5R_4390C-FBL8316A5R
©2016 Mattel. All Rights Reserved. Mattel, Inc., 636 Girard Avenue, East Aurora, NY 14052, U.S.A. Consumer Services 1-800-524-8697. Mattel U.K.
Ltd., Vanwall Business Park, Maidenhead SL6 4UB. Helpline 01628 500303. Mattel Australia Pty., Ltd., Richmond, Victoria. 3121.Consumer Advisory
Service - 1300 135 312. Mattel East Asia Ltd., Room 503-09, North Tower, World Finance Centre, Harbour City, Tsimshatsui, HK, China. Tel.: (852)
3185-6500. Diimport & Diedarkan Oleh: Mattel Southeast Asia Pte. Ltd. , No 19-1, Tower 3 Avenue 7, Bangsar South City, No 8, Jalan Kerinchi, 59200
Kuala Lumpur, Malaysia. Tel: 03-78803817, Fax: 03-78803867.
REQUIRES 6 X AA & 6 X AAA
BATTERIES (NOT INCLUDED).
DISPOSE OF BATTERIES SAFELY.
20
8+
service.mattel.com
FBL83-0970-G2
CAUTION:
To prevent entanglement, keep all hair
away from the wheels.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE AS THEY CONTAIN IMPORTANT INFORMATION.
COLORS AND DECORATIONS MAY VARY.
• IF CONTROLLER IS ACCIDENTALLY DROPPED IN THE WATER, REMOVE BATTERY(S) AND ALLOW
CONTROLLER TO AIR DRY. REPLACE WITH FRESH BATTERY(S) BEFORE OPERATION.
• PLAY SAFELY! – DO NOT DRIVE VEHICLE ON COARSE SURFACES, OFF-ROAD OR IN THE STREET!
HINTS AND TIPS ON HOW TO OPERATE THE TOY SAFELY
2
THE FUTURE OF RACING IS HERE!
19
BATTERY SAFETY INFORMATION
Protect the environment by not disposing of this product with
household waste [2012/19/EU]. Check your local authority for recycling
advice and facilities.
In exceptional circumstances batteries may leak fluids that can cause a chemical burn
injury or ruin your product. To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the product before being charged.
• Rechargeable batteries are only to be charged under adult supervision.
•
Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries inside may explode or leak.
NOTE: Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the
user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
• This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FOR PRODUCT SOLD IN USA
“Let’s Race!”
1 2 Ai assist helps vehicles race around the track.
6
Careful on the bends, “Whoa!” Too Fast! Roar past the competition for the win!
5
Speed into the pit to reload your hazards.
4
Welcome thrill seekers, record breakers, and speed demons
to the most extreme Hot Wheels® racing experience EVER.
Welcome to 180mph scale speeds. Welcome to cut throat
competition. Welcome to hairpin turns, trading paint and
photo finishes. Welcome to tire blowouts, oils spills, engine
failures and pit stops. Welcome to the FUTURE of racing.
WELCOME TO HOT WHEELS® Ai. LET’S RACE!!
Launch virtual track hazards with the controller.
3
FAST FISH®
SPIN KING
™
“WARNING:
FACTORY RESET”
1. CONNECT THE VEHICLE AND PUSH
THE BUTTON.
2. TOGGLE THE STEERING STICK LEFT OR RIGHT
UNTIL YOU HEAR: “FACTORY RESET”.
3. PUSH THE BUTTON.
4. AFTER YOU HEAR THE “WARNING: FACTORY RESET”
VOICE PROMPT, PRESS THE BUTTON AGAIN TO CONFIRM.
5. A SERIES OF ‘BEEP’S WILL PLAY TO CONFIRM YOU HAVE RESET
YOUR CONTROLLER TO ORIGINAL FACTORY STATUS.
YOUR NEW RACE STARTER KIT
318 3
TROUBLESHOOTING
FACTORY RESET
Symptom Cause Solution
Batteries are low or faulty Replace old batteries with high quality
alkaline batteries
Vehicle and/or controller continually
switches off or restarts
Vehicle batteries are low Replace old batteries with high quality
alkaline batteries
Vehicle running slowly/controller
says "Vehicle Batteries Low"
Vehicle batteries low (likely) or
controller batteries low (possible) Replace vehicle batteries, if the problem persists,
replace controller batteries
Controller says "Connection Lost"
Vehicles were turned on
simultaneously Turn off all vehicles and controllers and then
turn each controller and vehicle on in turns
More than one vehicle pairs
with one controller
Dust or dirt on the track or vehicle
tires or direct sunlight on the track Clean track and tires gently with a clean damp cloth
and ensure there is no direct sunlight on the track
Vehicles slide off of the track at the
bends even at low speed
Vehicle will not pair with the controller Batteries in the vehicle or
controller are low on power Replace old batteries with high quality
alkaline batteries
Incorrect language set at
startup Switch on the controller while
holding down the 'X' button
The controller is not speaking
the language I require
Vehicle is set in Ai car mode Restart the raceVehicle is driving itself
during a championship race
Controller may be set to low volume Increase volume in the system settings menu
(see page 8)
Controller volume is low
Freeplay mode not engaged Push the RC button on ControllerVehicle won’t steer into the Pit
Dust on vehicle tires, sensor windows
or Smart Track™/track pieces separated
Wipe with a clean cloth/Check that track pieces are
joined correctly with no lumps underneath
Vehicle comes off track in
AutoDrive mode
Dust on sensor windows Wipe with a clean clothLaps not being counted
Steering out of alignment Adjust steering alignment (see page 17)Vehicle does not drive straight
in Freeplay mode
Vehicle tires/
body not fitting correctly Check tires are securely on the wheel rims/Check
body shell is properly attached to the chassis
Vehicle does not steer properly
Controller frequently says “Connection
Lost” after replacing all batteries Interference from other 2.4GHz
equipment including WiFi Turn off or move away from other
sources of 2.4GHz transmissions
2
2
SPIN KING
™
SMART TRACK™ PIECES
A
U E
B T
20
D
U
D
E
HOT WHEELS® Ai SMART CARS
GAMING CONTROLLERS
1x STARTING GRID
2x REVERSE 450 CORNER TRACK 1x PIT LANE OUT
5x STRAIGHT TRACK 10x 45º CORNER TRACK
1x PIT LANE IN
YOU CAN RETURN YOUR CONTROLLER TO THE ORIGINAL FACTORY SETTINGS AT ANY TIME. HERE’S HOW!
FAST FISH
®
HOT WHEELS
• No one tops the high speed drifting moves of
this ultimate speed machine as it carves the
fastest lines through the most twisted corners.
• Like a dangerous piranha, this race car
viciously darts around the track and is
always ready to attack its prey.
NOTE: KEEP SMART TRACK™ PIECES STORED
IN THE INCLUDED STORAGE CASE
AND ALWAYS PACK THE TRACK FLAT
AND ENSURE THERE ARE NO CREASES.
— ALWAYS PACK THE TRACK FLAT. DO NOT FOLD OR CREASE.
Ai SYSTEM CARE
— DO NOT STEP ON TRACK. — DO NOT LEAVE TRACK IN DIRECT SUNLIGHT
FOR PROLONGED PERIODS.
• OPEN AND CLOSE THE BATTERY COVER WITH A PHILLIPS HEAD SCREWDRIVER (NOT INCLUDED).
• EACH RACE VEHICLE REQUIRES THREE 1.5V AAA BATTERIES.
• BATTERIES NOT INCLUDED. DISPOSE OF BATTERIES SAFELY.
• OPEN AND CLOSE THE BATTERY COVER
WITH A PHILLIPS HEAD SCREWDRIVER
(NOT INCLUDED)
• EACH CONTROLLER REQUIRES THREE 1.5V AA BATTERIES.
• BATTERIES NOT INCLUDED. DISPOSE OF BATTERIES SAFELY.
17
4
PREP YOUR GAMING CONTROLLER
ADJUST STEERING ALIGNMENT
FROM TIME TO TIME (ESPECIALLY AFTER YOU CRASH), YOU MAY NEED TO ADJUST THE STEERING
ON YOUR HOT WHEELS® Ai VEHICLES. IT’S EASY!
• Once you are done, press the button to return to the main menu.
PREP YOUR RACE VEHICLE
1. CONNECT THE VEHICLE AND PUSH THE BUTTON.
2. TOGGLE THE STEERING STICK LEFT OR RIGHT UNTIL YOU HEAR: "ADJUST STEERING".
3. PUSH THE BUTTON AND FOLLOW THE VOICE PROMPTS.
4. DRIVE YOUR SMART CAR SLOWLY BACKWARD AND FORWARD WITHOUT STEERING TO SEE IF
IT RUNS TOWARDS THE LEFT OR RIGHT.
5. CORRECT THE STEERING BY PUSHING THE STEERING STICK IN THE OPPOSITE DIRECTION OF
THE WAY THE SMART CAR RUNS TOWARDS.
6. EACH TIME YOU TURN THE STEERING STICK LEFT OR RIGHT, YOU WILL HEAR A ‘BEEP’ THAT
CONFIRMS YOU HAVE ADJUSTED THE STEERING ONE NOTCH IN THAT DIRECTION.
LIGHTLY DAMP CLOTH
LIGHTLY DAMP CLOTH
For the best Hot Wheels® Ai performance, always keep your Ai Race System in prime operating condition.
— Use a clean damp cloth when cleaning the vehicle body and tires.
• Keep your SMART CARS tires and chassis clean.
VEHICLE CARE
• Clean SMART TRACK™ with a lightly damp cloth.
— Do not build track on a slippery surface.
SMART TRACK
TM
CARE
— Use a clean dry cloth when wiping down your chassis and track sensors.
DAMP CLOTH
DRY CLOTH
Hot Wheels® Ai comes with 20 pieces of SMART TRACK™ so you can create and customize your own
unique raceway. Place the Start / Finish line ANYWHERE you want and build an EPIC race with the additional
track sections. Straight tracks add bursts of speed to the race while bends help slow things down.
SET UP
Setting up SMART TRACK™ is easy. Simply connect track
pieces by inserting the tabs on one piece of track to
the slots on another piece of track as shown below.
5
BUILD YOUR SMART TRACK
™
16
Ai SYSTEM CARE
1
2
ADDING THE PIT LANE
For the Pit Lane, look for the additional slots
on the sides of the straight track pieces and
attach both Pit Lane pieces. Then connect the
Pit Lane In and Pit Lane Out pieces together
as shown.
CONNECT
SLOT
TAB
1
1
2
3
1x STARTING GRID
A
2x REVERSE 450 CORNER TRACK
U
1x PIT LANE OUT
E
5x STRAIGHT TRACK
B
10x 45º CORNER TRACK
T
1x PIT LANE IN
D
DISCONNECTING THE TRACK
Take track apart by pulling tabs out of the slots as shown.
Be careful not to pull the tabs at an angle as this
may cause the tab or slot to tear or split.
1x PIT LANE IN
1x PIT LANE IN
!
DETACH ATTACH
DETACH ATTACH
VEHICLE CUSTOMIZATION
6 15
OVER 40 DIFFERENT TRACK CONFIGURATIONS
Hot Wheels® Ai lets you customize your race vehicle by swapping SMART CAR frames and wheel rims.
CHANGING VEHICLE WHEEL RIMS
Build any of the SMART TRACK
™
layouts below, visit:
HotWheels.com/Ai
for additional
track layouts, or get creative and make your very own unique Hot Wheels
®
Ai race!
U U
U U
U U
U
U
U
U
T T
T
T
T T
T
T
T
TT
T
B
B
B
B
B
BB
B
B
BB
B
B
B
B
B
BB
T
T
T
T T
T
T
TT
T
T
T
T
T
T
TTT
T
T
T
T
T
TT
T
T
T
T
T
T
T
T
T
T T
TT
T
T
TT
T
T
T
T
B
B
B
B
B
B
B
B
B
B
B
B
D
A
A
A
A
AA
E
D
E D
ED
E
ED
NEVER RACE THE SAME WAY TWICE!
0678
0678
E
D
1
2
3
4
“VEHICLE AND
CONTROLLER
CONNECTED”
NOTE: Make sure you have correctly installed the batteries in both your vehicle and controller (see page 4).
THE ACTION STARTS ONCE YOU POWER ON YOUR CAR AND CONTROLLER.
The car that completes all the race laps first,
WINS! All other positions and lap times are
announced after all player-controlled cars
finish their current lap.
WINNING THE RACE
Turn the vehicle power switch to I.
Listen for the voice prompt from the
controller to confirm:
714
CHAMPIONSHIP MODE FEATURES
CONNECT YOUR GAMING CONTROLLER AND VEHICLE
NOTE: You can reset the language at any time by powering off the controller and turning it
back on while pressing down on the button.
Use the STEERING STICK to toggle left and right
until you hear the language you want to play in.
If playing for the first time (or after loading a new set of batteries)
you will be asked to select a language.
Press the button to POWER ON your controller.
Press the button to select.
I O
RACING OFF TRACK
If you get hit by a hazard or take a turn
too fast and race off the track, activate the
RC ASSIST mode to disengage the track
sensors and steer back to the track.
(See below for more info on RC ASSIST)
• In PRACTICE and CHAMPIONSHIP modes, if at any time
you drive off-track, or want to temporarily disable track
assistance, you can push the RC button to
activate RC ASSIST.
This mode allows you to navigate back to track with FREEPLAY
controls. A slow BEEP will alert you that you are in RC ASSIST
mode, press the RC button again to deactivate and re-engage
the sensors once you are back on track.
RC ASSIST
you drive off-track, or want to temporarily disable track
assistance, you can push the
RC button
PIT STOP
After you successfully PIT the gaming controller will let you know, “You’re good to Go!”
and hazards will now be refilled.
IMPORTANT: You need to switch on RC ASSIST mode to allow the car to steer into
the pit. Once inside the pit, you can switch off RC ASSIST mode.
(see below for info on RC ASSIST)
— Steer to the pit lane and carefully drive IN and OUT of the pit.
When you run out of Hazards you will need to make a PIT STOP to refill them.
!1
2
3
4
5 6
FREEPLAY
“BEEP!”
The GAMING CONTROLLER gives you the power to control your vehicle and set up the race!
CHAMPIONSHIP MODE has 3 SKILL LEVELS, each with its own unique set of gameplay features.
8 13
USE YOUR GAMING CONTROLLER CHAMPIONSHIP MODE FEATURES
Your
GAMING CONTROLLERS
and
SMART CARs
come ready to race right out
of the box — use them the way they are or tweak their performance.
• Press the button.
• Use the STEERING STICK to toggle left and right through the editable settings.
The following features are only available in ADVANCED and EXPERT modes:
Use hazards wisely as you only get 3 per race and you will need to pit to reload them.
NOTE: AUTODRIVE cars will not fire hazards unless you fire first. Once you do, it’s battle on!
Each time you pit and reload your hazards, all AUTODRIVE cars will reload automatically.
So plan your attacks wisely because they can battle with no pit stop time penalty.
HAZARD ATTACKS:
Press the Hazard trigger to launch an attack at the player ranked ahead
of you. If you are in 1st place, your attack will hit the 2nd place-ranked car.
!
!
POWER
STEERING STICK /
TOGGLE SETTINGS
AUTODRIVE MODE*
*
*
*
*
SETTINGS
CHOOSE SKILL LEVEL
FREEPLAY MODE
PRACTICE MODE
*
CHAMPIONSHIP MODE
These controls can only be used when racing on HOT WHEELS® SMART TRACKTM.
HAZARD TRIGGER
EXIT /
RETURN SELECTION CONFIRM SELECTION
THROTTLE
ADJUST STEERING
See page 17
o
§
FACTORY RESET
See page 18
o
§
There are four different hazards in Hot Wheels® Ai.
Each one affects your SMART CAR performance differently:
ENGINE FAILURE – Slows your vehicle to a crawl.
MISSED GEAR –Temporarily impacts vehicle speed.
OIL SPILL – (EXPERT MODE ONLY) – SPIN OUT!
TIRE BLOWOUT – (EXPERT MODE ONLY) – Vehicle slows and swerves to the side of the track.
SPEAKER VOLUME
o
§
§
§
§
Press the button to enter.
Toggle left and right to adjust the controller volume from 1 to 5.
Then press the button to confirm.
o
§
§
§
ENGINE SOUNDS
Press the button to enter.
Toggle left and right to turn engine sounds ON and OFF.
Then press the button to confirm.
CUSTOMIZE GAMING CONTROLLER SETTINGS
For more skilled players, ADVANCED mode offers:
MEDIUM track assistance.
MODERATE acceleration and steering.
Two race hazards (Engine Failures and Missed Gears).
• EXPERT MODE:
For experienced players, EXPERT mode offers:
This is the ultimate Hot Wheels® Ai race experience, GAME ON!
Watch your speed on the turns or you may race off-track.
There’s no chance of driving off-track, so go ahead and step on the gas!
• ADVANCED MODE:
HIGH track assistance.
Limited acceleration and steering.
No race hazards.
• BEGINNER MODE:
For Hot Wheels® Ai newbies, BEGINNER mode provides:
LOW track assistance.
FULL acceleration and steering.
All four race hazards
(Engine Failures, Missed Gears, Oils Spills and Tire Blowouts).
Connect gaming controller and vehicle in turns (see page 7).
Press the button.
Wait to hear prompt, “Player X, you’ve joined the race!”.
Press the button for
a fully Ai driven car!
Press the button for
9
CHAMPIONSHIP MODE
12
FREEPLAY MODE
Want to watch the Ai SMART CARS race around your custom track entirely on their own? Place your
vehicle on the starting line and then choose the AUTODRIVE mode for the ultimate hands-free race.
Connect gaming controller and vehicle in turns
Press the button.
Wait to hear prompt, “Player X, you’ve joined the race!”.
•To add Ai-controlled vehicles.
2
Choose after joining the race, but BEFORE placing vehicle on the track.
• You can exit CHAMPIONSHIP MODE at ANY time, simply press the button to Exit.
• Press the button at any time to hear your player number and fastest lap time.
• In CHAMPIONSHIP MODE the gaming controller will give you updates on lap number,
race position, hazard impacts if any (see page 13) and alert you when you need to Pit.
Place the Ai vehicle on the starting grid and press the button.
NOTE: Ai cars will automatically be set to the same SKILL LEVEL as Player 1 (the race host).
Choose after joining the race, but BEFORE placing vehicle on the track.
When asked to EXIT, press the button. If you are Player 1, this will end the race
for all Players.
NOTE: During the race, any Players except Player 1 can drop out at any time while
others continue to race.
•
• When all vehicles are ready behind the starting line, player 1 must press the button
and wait for the race start command “3… 2… 1… GO!!!”.
SETTING UP A RACE (CONT.)
AUTODRIVE MODE
With
Hot Wheels® Ai
you can race how YOU want, on-track or off. You’re in control!
•
Press the RC button to engage Freeplay mode.
RACE ON WOODEN FLOORS!
RACE ON TILE FLOORS!
• You can exit Freeplay mode at ANY time, simply press the button to Exit.
When asked if you want to EXIT mode, press the button.
• Race wherever you like without the Ai track assistance.
NOTE: Hot Wheels
®
Ai vehicles contain advanced sensors that read the SMART TRACK
™
pieces.
Vehicles are not recommended for rough terrain or outdoor play.
RC button
to engage Freeplay mode.
10 11
PRACTICE MODE CHAMPIONSHIP MODE
1
2
Want to hit the track fast and go for your fastest lap time? Then PRACTICE MODE is for you!
• CAREFUL: Even though Hot Wheels® Ai uses Artificial Intelligence to keep your car on
track, in Expert mode the Track Assistance is turned way down, so turn your racing
skills way up. Watch your speed on the turns or you WILL spin out and race off track.
BEGINNER – High track assistance and limited acceleration for Hot Wheels® Ai newbies.
ADVANCED – More power and more control for experienced players.
EXPERT – Low track assistance and HIGH power for real speed demons.
• Press the button to choose your SKILL LEVEL.
• Press the button.
• Place your vehicle behind the starting line.
NOTE: Always place vehicles on track so they race in a clockwise direction. Racing the
wrong direction will severely affect the steering and performance of your Ai vehicles.
•
Press the button and wait for the race start command “3… 2… 1… GO!!!”.
•
In PRACTICE MODE the gaming controller will give you updates on lap times and your
FASTEST LAP. Drive carefully and try to beat your best time.
•
Press the button at any time to hear your FASTEST LAP time again.
•
You can exit PRACTICE MODE at ANY time, simply press the button to Exit.
•
When asked if you want to EXIT mode,
press the button again.
In PRACTICE and CHAMPIONSHIP modes, if at any time you drive off-track, or you want to temporarily
disable track assistance, you can push the RC button to activate RC ASSIST. This mode allows you to
navigate back to track with FREEPLAY controls. A slow BEEP will alert you that you are in RC ASSIST
mode, press the RC button again to deactivate and re-engage the sensors once you are back on track.
RC ASSIST
Ready to compete against friends or challenge Hot Wheels® Ai vehicles controlled by Artificial
Intelligence? Then it’s time for CHAMPIONSHIP MODE!
When asked if you want to EXIT mode,
press the button again.
1
• Press the button.
NOTE: See more about each SKILL LEVEL on page 13.
BEGINNER
ADVANCED
EXPERT
• Choose your SKILL LEVEL. Press the button to toggle between three difficulty modes.
IMPORTANT! The first controller to select CHAMPIONSHIP MODE will automatically
become Player 1 and control the race and all race settings.
• Press the button.
• Choose your SKILL LEVEL. Press the button to toggle between three difficulty modes.
become Player 1 and control the race and all race settings.
BEGINNER
ADVANCED
EXPERT
• Press the button.
Other players can join the race too, either vehicles controlled by friends or vehicles
controlled by Hot Wheels® Ai.
— Use the STEERING STICK to toggle left and right to set the number of laps.
— When you hear the number of laps you want, press the button.
— Place your vehicle on the starting grid and wait for other players.
• Choose the number of laps.
• To add friend-controlled vehicles.
— Connect your gaming controller and vehicle in turns (see page 7).
— Press the button.
— Wait to hear prompt, “Player X, you’ve joined the race!”.
— Place your vehicle on the starting grid.
Connect your gaming controller and vehicle in turns
Press the button.
Wait to hear prompt, “Player X, you’ve joined the race!”.
SETTING UP A RACE
(see page 14 for more detailed info)
NOTE:
Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the
user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
• This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
size: 138 x 175 (mm)
Cet appareil est conforme à l'article 15 de la réglementation de la FCC.
L'utilisation de ce dispositif est autorisée seulement aux deux conditions suivantes :
(1) il ne doit pas produire de brouillage nuisible, et (2) l'utilisateur du dispositif doit être prêt à accepter tout brouillag e
radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
• Cet appareil a été testé et jugé conforme aux limites de la classe B pour un appareil numérique en vertu de l'article 15 de la
réglementation de la FCC. Ces limites ont été instaurées pour fournir une protection raisonnable contre toute interférence
nuisible dans une installation résidentielle. Cet appareil génère, utilise et peut émettre de l'énergie radiofréquence. S'il n' est
pas installé et utilisé conformément aux instructions, il peut provoquer des interférences sur les communications radio.
Cependant, il n'est pas garanti que des interférences ne se produiront pas dans certaines installations. Si cet appareil
cause des interférences à la réception radio ou télévisée (ce qui peut être vérifié en éteignant l'appareil puis en le remettan t
sous tension), l'utilisateur peut tenter de les résoudre en suivant une ou plusieurs des mesures ci-après :
• Réorienter ou déplacer l'antenne réceptrice.
• Augmenter l'espace entre l'appareil et le récepteur.
• Brancher l'appareil sur une prise de courant différente de celle sur laquelle le récepteur est branché.
• Pour obtenir de l'aide, contacter le vendeur ou un technicien radio/télévision expérimenté.
REMARQUE : Tout changement ou modification de cet appareil n'ayant pas été expressément approuvé par les parties
responsables de sa conformité peut entraîner l'annulation du droit d'exploitation de l'équipement par l'utilisateur.
FOR PRODUCT SOLD IN USA • POUR LES PRODUITS VENDUS AUX ÉTATS-UNIS
This equipment complies with FCC & Canada radiation exposure limits set forth for uncontrolled environments.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Cet équipement est conforme aux limites d’exposition aux radiations définies par le Canada pour des environnements non contrôlés.
Cet émetteur ne doit pas être installé au même endroit ni utilisé avec une autre antenne ou un autre émetteur.
THIS DEVICE COMPLIES WITH INDUSTRY CANADA LICENCE-EXEMPT RSSs.
CET APPAREIL EXEMPT DE LICENCE EST CONFORME AU RSSs D'INDUSTRIE CANADA.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
L’utilisation de ce dispositif est autorisée seulement aux conditions suivantes :
(1) il ne doit pas produire de brouillage et (2) il doit pouvoir tolérer tout brouillage radioélectrique reçu, même si ce
brouillage est susceptible de compromettre son fonctionnement.
FOR PRODUCT SOLD IN CANADA • POUR LES PRODUITS VENDUS AU CANADA
00007-1850 FCC flyer for
2.4 GHz RC item only
00007-1850
