Mattel Asia Pacific Sourcing J2358-07A1T Radar Gun User Manual
Mattel asia Pacific Sourcing Ltd. Radar Gun
Users Manual
J2358-0920 G1 SIZE: 5.5x13” COLOR: 1C+1C Front J2358-0920 G1 SIZE: 5.5x13” COLOR: 1C+1C Back
1
4
2
3
6 5
CONTENTS / FEATURES
1. SCALE SWITCH
2. UNIT SWITCH
3. RESET BUTTON
4. LCD
5. TRIGGER (Activates radar)
6. BATTERY COVER
BATTERY INSTALLATION/REPLACEMENT
Unscrew the battery cover with a Phillips-head screwdriver (not included). Insert 4 "AAA" (LR03) alkaline batteries
(not included) in the orientation shown. Replace the battery cover and tighten screw. For best performance, use
only alkaline batteries.
If the unit does not function properly, a bent paper clip should be used (by an adult only) to depress the reset
button.
When the batteries are low, the digital readout screen will flash a broken battery symbol, indicating it is time to
change the batteries.
BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids that can cause a chemical burn injury
or ruin your product. To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the product before being charged (if designed to be removable).
• Rechargeable batteries are only to be charged under adult supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries inside may explode or leak.
B
TO OPERATE:
Your radar gun has a digital readout screen
which will show instantaneous real speed or
Hot Wheels® 1/64th scale speed of objects
coming toward you or moving away.
What does Hot Wheels® scale speed mean?
Hot Wheels® cars are 1/64th the size of a real car.
So if a Hot Wheels® car goes 10 MPH / 16 KPH
calculate:
10 MPH X 64 = 640 MPH or
16 KPH x 64 = 1024 KPH!
INSTRUCTIONS 7+
®
J2358-0920 G1
®
COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S.ONLY)
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: Changes or modifications not expressively approved by the manufacturer
responsible for compliance could void the user’s authority to operate the equipment.
© 2006 Mattel, Inc. All Rights Reserved. Mattel, Inc.,
333 Continental Blvd.,El Segundo, CA 90245 U.S.A.
Consumer Relations 1-800-524-8697
service.mattel.com. Mattel U.K. Ltd., Vanwall Business
Park, Maidenhead SL6 4UB. Helpline 01628500303.
Mattel Australia Pty., Ltd., Richmond, Victoria.
3121.Consumer Advisory Service - 1300 135 312.
Mattel East Asia Ltd., Room 1106, South Tower, World
Finance Centre, Harbour City, Tsimshatsui, HK, China.
Diimport & Diedarkan Oleh: Mattel SEA Ptd
Ltd.(993532-P) Lot 13.5, 13th Floor, Menara Lien Hoe,
Persiaran Tropicana Golf Country Resort, 47410 PJ.
Tel:03-78803817, Fax:03-78803867.
1:1
KPH
MPH
Reset
A
Please note: For most accurate read, objects must be moving directly towards or away from the radar gun.
Point the radar gun at a 25-45 degree angle to either the front or rear of the vehicle as it is traveling on the track.
Make sure the radar gun is no more than 1.5 feet (.45 m) away from the Hot Wheels® car being measured.
Protect the environment by not
disposing of this product with
household waste [2002/96/EC].
Check your local authority for
recycling advice and facilities.
Hot Wheels®
1:64
1:64 HOT WHEELS
®
SCALE MODE
1:1 SCALE MODE
• Do NOT use in or near the street.
• The MAXIMUM measuring/responding distance is
approximately 39 feet (12 m).
Please keep these instructions for future reference as they contain important information.
• Pressing and holding the trigger will show the
current speed on the screen.
• Releasing the trigger will show the MAX detected
speed on the screen for approximately 30
seconds.
• Pressing and holding the trigger again will reset
the digital readout to 0 and the speed of the next
object will be measured.
• Pressing and holding the trigger will show the
current speed on the screen.
• Releasing the trigger will show the MAX detected
speed on the screen for approximately 30 seconds.
• Pressing and holding the trigger again will reset the
digital readout to 0 and the speed of the next object
will be measured.
