Mattel Asia Pacific Sourcing J4031-05A2T CHRYSLER 300C User Manual G3474 0920 new 7 2v 1L
Mattel asia Pacific Sourcing Ltd. CHRYSLER 300C G3474 0920 new 7 2v 1L
USERS MANUAL
TYCO R/C SUPPORT
Questions or problems with your product?
DON’T RETURN IT TO THE STORE!
Just call us for help.
U.S. consumers may also register their products at this number.
1 888 557-TYCO (8926)
®
tycorc.com
Keep these instructions for future reference: they
contain important information. IMPORTANT: Please
read all “Consumer Information” before operating your
vehicle.
NOT RECOMMENDED
FOR CHILDREN UNDER
8 YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS,PRECAUTIONS SHOULD BE
OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC SHOCK. INPUT:
120VAC, 60Hz, 12VA. OUTPUT:8.5VDC, 420mA, 3.6W.
CAUTION-ELECTRIC TOY:
G3474-0920
G3474-S1
I.CONTENTS/FEATURES
Vehicle
Transmitter
7.2v Battery pack
7.2v wall charger
6AA Batteries
Vehicle
q Steering adjuster control
*For when your vehicle appears to veer to either the right or
left. use screwdriver (not included) to turn the knob in the
direction necessary to correct the vehicle's alignment.
w Try-Me button to activate lights and sounds
e 4AA battery door
r 7.2v battery latch
t 7.2v battery door
y ON/Fender lights/OFF/Try-Me (lights and music) switch
*This switch has 4 positions:
I Vehicle On: Vehicle runs with music effects
and lights as you drive (In this mode vehicle will
perform at low speed)
ÄFender lights "on" only (Vehicle no movement forward)
OVehicle OFF
Ä/FTry-Me On: Activates 'try me' function with lights and
music effects(In this mode vehicle cannot be
driven)
u Media player music(MP3/CD’s)/OFF/Cruise music switch
*This switch has 3 positions:
ß Vehicle runs with internally stored music (In this mode
vehicle will perform at low speed)
O Vehicle runs with no music (In this mode vehicle
will perform at maximum speed)
H
Vehicle runs with your MP3 or CD music player (In this
mode vehicle will perform at low speed)
*Note: Both the switches turn to "0" position after run your
vehicle or your MP3/CD music end.
i Fender lights
o
Trunk lock-use coin (not included) to open trunk after trunk lock
aMedia player plug (for direct input into most media players)
*Media player should first be placed into the the protective
sleeve and then plugged in. (The music player is not included)
*Adjust the volume of the music using the volume control on
your music player.
s Protective media player sleeve
Transmitter
q Antenna
w Left & Right controls
e Forward & Reverse controls
r Battery door
7.2V R/C
7.2V R/C
XCAUTION: Surfaces may become hot and cause burns if
electronics get wet. Do not operate vehicle through
water or snow.
IO
O
ßH
I
O
O
ß
H
S Q
u
y
e
r
t
w
q
ii
o
a
w
e
q
r
s
7.2 v d.c. 7.2 v d.c.
III. BATTERY INSTALLATION
There are two power sources: a 7.2v SubC NiCd rechargeable
battery pack (which powers all the driving and turning)
and a 4 AA alkaline battery pack (which powers the lights
and sounds).
For detailed information regarding rechargeable battery
charging and safety, please refer to the “Battery
Charging/Care” section.
Vehicle
For lights and music sounds position battery installation:
1. Use a screwdriver (not included) to unscrew the power
clip cover screw, open the battery cover as shown.
2. Install 4 AA alkaline batteries with polarity (+/-) as shown
inside the battery compartment.
3. Replace the battery door.
For driving battery installation:
1. Rotate the battery door latch to the unlocked position
and open the battery door.
2. Insert the charged battery pack into the battery
compartment as shown.
3. Connect the battery pack’s wire connector to the vehicle’s
charging jack as shown. Make certain the connector is
securely connected.
4. Close the battery door and rotate the battery door latch
to the locked position.
Transmitter
1. Remove the battery cover as shown.
2. Install 2 AA alkaline batteries with polarity (+/-) as shown
inside the battery compartment.
3. Replace the battery door.
II. VEHICLE OPERATION
FORWARD
Slam steering control: Left & Right turn activation
turning motion activates turn signal lights.
Throttle control: Forward & Reverse motion activation
Forward & Reverse motion activates headlights & fender lights
Forward & Reverse motion activates cruise tune (from internally
stored music). Vehicle drives in low speed when a music player
is pluged in.
Brake lights activate when the trigger switch returns to the
neutral position.
REVERSE
LEFT
RIGHT
V. BATTERY CHARGING/CARE
XCAUTION: Use only the charger supplied with this
toy. Do not use any other charging source.
Use only Tyco® R/C 7.2v NiCd battery packs. Other batteries
may leak or rupture, causing personal injury and damage.
1. Plug the wall pack charger into a standard wall outlet.
2. Connect the battery pack’s wire connector to the wall pack
charger connector. Make certain the two connectors are
tightly snapped together.
3. To disconnect the wires, push down on the connector clip
and pull apart.
4. After charging, the battery will feel warm. This condition is
normal for fully charged batteries.
5. New battery packs must be charged for 5 1/2 hours the first
two times charged. Subsequent charges will require 4
hours. Charging the battery pack for more than 5 1/2 hours
will not give you a longer running time. 5 1/2 hours is all that
is required for a fully charged battery pack.
6. Unlike alkaline batteries, which lose power gradually, a NiCd
(Nickel-Cadmium) battery will run for its normal running time
and then lose most of its power at once. That’s how you’ll
know it’s time to recharge the battery pack.
7. After use, the battery pack will be hot! Wait at least 20
minutes until the battery pack cools before recharging.
Recharging a warm or hot battery pack will greatly reduce
the number of times your battery pack can be recharged.
RECHARGEABLE BATTERY INFORMATION:
DO NOT RECHARGE BATTERY PACK IF IT’S HOT.
ALLOW IT TO COOL BEFORE RECHARGING.
DO NOT RECHARGE A BATTERY PACK THAT SHOWS
LEAKAGE OR CORROSION.
DO NOT DISASSEMBLE THE BATTERY PACK.
THE BATTERY PACK IS A SEALED RECHARGEABLE
NICKEL-CADMIUM BATTERY.
EXERCISE CAUTION IN HANDLING A HOT BATTERY PACK.
IF BATTERY PACK AND/OR CHARGER ARE WET,
THOROUGHLY DRY BEFORE CHARGING.
DO NOT RECHARGE NON-RECHARGEABLE BATTERIES.
Note to Adults:
• Remove rechargeable batteries before recharging. Recharge
batteries only under adult supervision.
• Regularly examine for damage to the cord, plug, enclosure
and other parts.
•In the event of any damage, the toy must not be used with
the battery charger until the damage has been repaired.
• This toy is not intended for children under 3 years old. The
battery charger is not a toy.
THIS PRODUCT USES A NICKEL-CADMIUM RECHARGEABLE
BATTERY PACK. BATTERY MUST BE RECYCLED OR DISPOSED
OF PROPERLY. FOR FURTHER INFORMATION REGARDING
BATTERIES OR THEIR DISPOSAL PLEASE CALL 1-800-348-075.
VI. CONSUMER INFORMATION:
QUICK TIPS
qWhen the 4AA batteries in the vehicle are running low the
sound effects and motor will cut off. You'll then hear a
10-second beep. Turn the vehicle OFF before changing new
AA batteries and 7.2V battery pack. When the 7.2v SubC NiCd
is low or encounters a stall, the unit will cut the motors and
turn off the sound effects. The unit will beep as long as the
user continues to press the remote control.
wYour vehicle's running time may change depending on your
driving style.
eRadio interference can make your vehicle run badly.
Interference can be caused by other R/C vehicles running
on the same frequency; electrical wires; large buildings;
CB radios; or other wireless gear. Try to stay away from
these!
rPoint your transmitter antenna up - not down toward your
vehicle. If your vehicle gets too far away, it won't work
properly.
tDon’t drive your vehicle in sand or through water or snow.
If your vehicle does get wet, wipe with a towel and allow it
to dry completely.
yDon’t store your vehicle near heat or in direct sunlight.
Always turn switches OFF and remove all batteries for storage.
q
w
e
r
t
y
7.2v d.c. NiCd,
6 x Sub-C
1600mAh
Mattel, Inc. warrants to the original consumer purchaser that this product will be free of defects in
material and workmanship for ninety (90) days (unless specified in alternate warranties) from the date of
purchase. Mattel will replace the product in the event of such a defect within the warranty period.
In the event of a defect covered under this warranty, first call the toll-free number listed below.
Many problems can be solved in this manner. If necessary, you will be instructed to return the product,
postage prepaid and insured, to the address below. Enclose your name, address, dated sales receipt,
and a brief explanation of the defect. Replacement and return shipment will be free of charge.
This warranty does not cover damage resulting from unauthorized modification, accident, misuse or
abuse. If the product is returned without a dated sales receipt the product may be excluded from
coverage under this warranty.
Mattel’s liability for defects in material and workmanship under this warranty shall be limited to repair or
replacement, at our sole option, and in no event shall we be responsible for incidental, consequential, or
contingent damages (except in those states that do not allow this exclusion or limitation). This warranty
is exclusive, and is made in lieu of any express or implied warranty. Valid only in U.S.A. This warranty
gives you specific legal rights and you may have other rights, which vary from state to state. Some states
do not allow the exclusion of incidental or consequential damages, so the above exclusions or limitations
may not apply to you.
TOLL-FREE NUMBER: 1-888-557-TYCO (8926) (valid only in U.S.A.)
Hours: 8:00 A.M. - 5:00 P.M. Eastern Time; Monday - Friday. Expect some delay in January following the
holiday season. Please be patient and keep trying the toll-free number.
ADDRESS FOR RETURNS:
CONSUMER RELATIONS
636 GIRARD AVENUE
EAST AURORA, NY 14052
90 DAY LIMITED WARRANTY – TYCO® R/C PRODUCTS
Note to Adults: To ensure that the child’s play is both safe and
fun, please review all the operating instructions and safety
rules with your child.
Safety Tips
• NEVER drive your vehicle on streets! They’re for real cars!
• DO NOT pick up the vehicle while it's in motion.
• Keep fingers, hair and loose clothing away from the tires and
the wheel hubs while the vehicle is switched ON.
XCAUTION: To prevent entanglement, keep hair away from
wheels.
• Adult supervision is recommended when this vehicle is being
operated.
• To avoid accidental operation, remove all batteries when not
in use. Always turn all switches OFF before removing batteries.
BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids that
can cause a chemical burn injury or ruin your product.
To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the product
before being charged (if designed to be removable).
• Rechargeable batteries are only to be charged under adult
supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc),
or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the product.
•
The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries inside
may explode or leak.
Battery Performance Note:
For best performance use regular or high-performance alkaline
batteries (where disposable batteries are called for). If your vehicle
is supplied with standard (carbon-zinc) batteries for initial use
and/or demonstration purposes, we recommend replacing them
with alkaline batteries when necessary. Battery life may vary
depending on battery brand.
© 2005 Mattel, Inc., 333 Continental Blvd., El Segundo, CA 90245 U.S.A. Consumer Affairs: 1 (800) 524-TOYS.
PRINTED IN CHINA. All Rights Reserved. MATTEL, TYCO and associated trademarks and trade dress are
owned by Mattel, Inc. Retain this address for future reference: Mattel U.K. Ltd., Vanwall Business Park,
Maidenhead SL6 4UB. Helpline 01628 500303. Mattel Australia Pty Ltd., Richmond, Victoria 3121 -
Consumer Advisory Service: 1300 135 312. Mattel East Asia Ltd, Room 1106, South Tower, World Finance
Centre, Harbour City, Tsimshatsui, HK, China. Diimport & Diedarkan Oleh: Mattel SEA Ptd Ltd. (993532-P)
Lot 13.5, Menara Lien Hoe, Persiaran Tropicana Golf Country Resort, 47410 PJ. Tel: 03-78803817,
Fax: 03-78803867.
COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S. ONLY)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This device generates and uses radio frequency energy and if not used properly may cause
interference to radio and television reception. It has been tested and found to comply with the
limits set by the FCC which are designed to provide reasonable protection against such interference.
NOTE: Changes or modifications not expressively approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
SYMPTOM
Vehicle runs slowly or will not run.
Power indicator light on transmitter does not light.
Erratic operation or only short range possible.
Vehicle doesn’t work after going through water or snow.
• PROBABLE CAUSE
• Loose battery connection or vehicle switch not ON.
• Weak or uncharged rechargeable NiCd battery.
• Weak AA batteries (Power Clip) or
transmitter battery.
• Transmitter battery weak or not connected.
• Radio interference likely.
• Water in the electronics area.
• CORRECTION
• Check battery connector and vehicle switch.
• Charge battery or replace.
• Replace with fresh alkaline battery.
• Check connections and replace battery if required.
• Change location - see Point 3, “Quick Tips.”
• Vehicle will take several hours to dry. Allow to dry
thoroughly overnight before trying again. Avoid driving
in water or snow.
TROUBLESHOOTING - PROBLEM? - SOLUTIONS
