USERS MANUAL
X
X
I.CONTENTS/FEATURES
Vehicle
qSteering adjuster
w3 AA Try-me batteries
eBattery door
rON/OFF/Try-Me switch
*This switch has three positions:
IVehicle On: Vehicle runs with lights as you drive
OVehicle OFF
X Vehicle On: Activates 'try me' function with lights
tLights
yTry-Me button-with lights
Keep these instructions for future reference: they
contain important information. IMPORTANT: Please read
all “Consumer Information” before operating your vehicle.
6.0V R/C
CAUTION:
Surfaces may become hot and cause burns if
electronics get wet. Do not operate vehicle through water or snow.
Asst. H2377
J6834/35-0920G1
Hot Wheels
®
R/C SUPPORT
Questions or problems with your product?
DON’T RETURN IT TO THE STORE!
Just call us for help.
U.S. consumers may also register their products at this number.
1-888-557-8926
w
q
B
A
Transmitter
qAntenna
wLeft & Right controls
eForward & Reverse controls
rBattery door
wet
y
r
q
wer
q
r
e
®
y
t
III.BATTERY INSTALLATION
Requires 6 AA Alkaline Batteries (2AA for transmitter
and 4 AA for vehicle). Batteries included are for demon-
stration purposes only.
Vehicle
1. Use a screwdriver (not included) to unscrew the
battery door, open the battery door as shown.
2. Remove 3 "AA" batteries (included for Try-Me Lights
ONLY) and replace with 4 new "AA" alkaline batteries
(not included) with polarity (+/-) as shown inside the
battery compartment.
3. Replace the battery door.
Transmitter
1. Remove the battery cover as shown.
2. Install 2 AA alkaline batteries (not included) with polarity
(+/-) as shown inside the battery compartment.
3. Replace the battery door.
*Your transmitter is equipped with a special automatic
ON battery-saving feature. Just turn your vehicle
ON. Then push either transmitter control to run and
control your vehicle.
IV.CONSUMER INFORMATION
Note to Adults: To ensure that the child’s play is both
safe and fun, please review all operating instructions
and safety rules with your child.
Safety Tips
• NEVER drive your vehicle on streets! They’re for real
cars!
• DO NOT pick up vehicle while in motion.
• Keep fingers, hair and loose clothing away from the
tires and the wheel hubs while the vehicle is switched
ON.
XCAUTION: To prevent entanglement, keep hair away
from wheels.
• Adult supervision is recommended when this vehicle
is being operated.
• To avoid accidental operation, remove all batteries
when not in use. Always turn the vehicle OFF before
removing batteries.
BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids
that can cause a chemical burn injury or ruin your product.
To avoid battery leakage:
•
Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the product
before being charged (if designed to be removable).
• Rechargeable batteries are only to be charged under
adult supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc),
or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the product.
• The supply terminals are not to be short-circuited.
• Dispose of battery (ies) safely.
• Do not dispose of this product in a fire.
The batteries inside may explode or leak.
Battery Performance Note:
For best performance use regular or high-performance
alkaline batteries (where disposable batteries are called
for). If your vehicle is supplied with standard (carbon-zinc)
batteries for initial use and/or demonstration purposes, we
recommend replacing them with alkaline batteries when
necessary. Battery life may vary depending on battery
brand.
II.VEHICLE OPERATION
FORWARD
REVERSE
LEFT
RIGHT
1. When your vehicle starts to lose power, it may lose
functions or performance. It's time for fresh batteries
(or a recharge). Your vehicle's running time may
change depending on your driving style.
2. Radio interferance can effect your vehicle's perform-
ance. Interference can be caused by other R/C vehi-
cles running on the same frequency, electrical wires,
large buildings or CB radios. Try to stay away from
these!
3. Point your transmitter antenna up - not down toward
your vehicle. If your vehicle gets too far away, it
won't work properly. If your transmitter has an
antenna carry-loop feature, make sure the antenna is
removed from the holder and straightened before
operating.
4. Don’t drive your vehicle in sand or through water or
snow.
5. Don’t store your vehicle near heat or in direct
sunlight. Always turn switches OFF and remove all
batteries for storage.
V.QUICK TIPS
SYMPTOM
Vehicle runs slowly or will not run.
Power indicator light on transmitter does not light.
Erratic operation or only short range possible.
Vehicle doesn’t work after going through water or snow.
• PROBABLE CAUSE
• Loose battery connection or vehicle switch not ON.
• Weak or uncharged rechargeable NiCd battery.
• Weak AA batteries (Power Clip) or
transmitter battery.
• Transmitter battery weak or not connected.
• Radio interference likely.
• Water in the electronics area.
• CORRECTION
• Check battery connector and vehicle switch.
• Charge battery or replace.
• Replace with fresh alkaline battery.
• Check connections and replace battery if required.
• Change location - see Point 2, “Quick Tips.”
• Vehicle will take several hours to dry. Allow to dry
thoroughly overnight before trying again.
• Avoid driving in water or snow.
TROUBLESHOOTING - PROBLEM? - SOLUTIONS
2
1
3
45
90-DAY LIMITED WARRANTY
Mattel, Inc. warrants to the original consumer purchaser that this product will be free of defects in material and
workmanship for ninety (90) days (unless specified in alternate warranties) from the date of purchase. Mattel will
replace the product in the event of such a defect within the warranty period.
In the event of a defect covered under this warranty, first call the toll-free number listed below. Many problems
can be solved in this manner. If necessary, you will be instructed to return the product, postage prepaid and
insured, to the address below. Enclose your name, address, dated sales receipt, and a brief explanation of the
defect. Replacement and return shipment will be free of charge.
This warranty does not cover damage resulting from unauthorized modification, accident, misuse or abuse. If the
product is returned without a dated sales receipt the product may be excluded from coverage under this warranty.
Mattel’s liability for defects in material and workmanship under this warranty shall be limited to replacement, and
in no event shall we be responsible for incidental, consequential, or contingent damages (except in those states
that do not allow this exclusion or limitation). This warranty is exclusive, and is made in lieu of any express or
implied warranty. Valid only in U.S.A. This warranty gives you specific legal rights and you may have other rights,
which vary from state to state. Some states do not allow the exclusion of incidental or consequential damages, so
the above exclusions or limitations may not apply to you.
TOLL-FREE NUMBER: 1-888-557-8926 (valid only in U.S.A.) Hours: 8:00 A.M. - 5:00 P.M. Eastern Time; Monday -
Friday. Expect some delay in January following the holiday season. Please be patient and keep trying the toll-free
number.ADDRESS FOR RETURNS: CONSUMER RELATIONS, 636 GIRARD AVENUE, EAST AURORA,
NY 14052
© 2005 Mattel, Inc., 333 Continental Blvd., El Segundo, CA 90245
U.S.A. Consumer Affairs: 1-888-557-8926. PRINTED IN CHINA. All
Rights Reserved. MATTEL, HOT WHEELS and associated trade-
marks and trade dress are owned by Mattel, Inc. Retain this
address for future reference: Mattel U.K. Ltd., Vanwall Business
Park, Maidenhead SL6 4UB. Helpline 01628 500303. Mattel
Australia Pty Ltd., Richmond, Victoria 3121 - Consumer Advisory
Service: 1300 135 312. Mattel East Asia Ltd, Room 1106, South
Tower, World Finance Centre, Harbour City, Tsimshatsui, HK,
China. Diimport & Diedarkan Oleh: Mattel SEA Ptd Ltd. (993532-
P) Lot 13.5, Menara Lien Hoe, Persiaran Tropicana Golf Country
Resort, 47410 PJ. Tel: 03-78803817, Fax: 03-78803867.
Dropstars is a trademark of DUB Industries, LLC. and used under
license by Mattel, Inc.
MERCEDES-BENZ trademarks used under license. Intellectual
Property Rights licensed by DaimlerChrysler AG.
COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S.
ONLY)
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation.
This device generates and uses radio frequency energy
and if not used properly may cause interference to radio
and television reception. It has been tested and found to
comply with the limits set by the FCC which are
designed to provide reasonable protection against such
interference.
NOTE: Changes or modifications not expressively
approved by the manufacturer responsible for compli-
ance could void the user’s authority to operate the
equipment.
