Mattel Asia Pacific Sourcing J6850-05A4T 1:18 HURRICANE User Manual J6849 0920 Asst H9305 indd
Mattel asia Pacific Sourcing Ltd. 1:18 HURRICANE J6849 0920 Asst H9305 indd
USERS MANUAL
Hot Wheels® R/C SUPPORT
Questions or problems with your product?
DON’T RETURN IT TO THE STORE!
Just call us for help.
U.S. consumers may also register their products at this number.
1-888-557-8926
XCAUTION:Surfaces may become hot
and cause burns if electronics get wet. Do not
operate vehicle through water or snow.
Keep these instructions for future reference as they
contain important information. IMPORTANT: Please
read all “Consumer Information” before operating
your vehicle.
I. CONTENTS/ FEATURES
Vehicle
Transmitter
Vehicle
A Antenna
*You will need to slip the loose antenna wire into the
provided tube (it looks like a straw). Then push the
straw (with wire already enclosed) firmly into the
cylindrical opening on the chassis.
B Multi-channel selector switch
* Please see the “Multi-channel Feature” Section for
more information.
C Steering adjuster
* Turn with a screwdriver (not included) to keep
vehicle running straight.
D ON(I)/OFF(O) switch
E Battery door
F AA Battery adapter
Transmitter
q Antenna
w LED indicator(Light that indicates when your
transmitter is turned on or off).
e Steering knob: left / right control
r Trigger: forward / reverse control
t Multi-channel selector switch
Please see the “Multi-channel Feature” Section for more
information.
y ON(I)/OFF(O) switch
u Battery door
* Just turn your vehicle ON. Then pull the trigger and
you will be able to run and control your vehicle.
* Pull trigger all the way back for that extra punch of
power.
1 2 3
I O
I O
1 2 3
1 2 3
I O
1 2 3
I O
A
Asst.H9305
J6849-0920
1 2 3
I O
I O
1 2 3
1 2 3
I O
1 2 3
I O
q
w
e
r
®
XCAUTION:To prevent entanglement,
keep hair away from wheels.
1 2 3
I O
I O
1 2 3
1 2 3
I O
1 2 3
I O
t
y
u
1 2 3
I O
I O
1 2 3
1 2 3
I O
1 2 3
I O
D
C
B
E
F
II. VEHICLE OPERATION
* If your vehicle doesn’t move when you use the trans-
mitter there’s a good chance your vehicle’s battery is
ready for a recharge.
III. MULTI-CHANNEL FEATURE
• Your vehicle features the advanced Multi-channel
system. This system lets you race your vehicle head-to-
head – against up to two of your friends with the same
vehicle (up to 6 drivers total with vehicles of the same
assortment) – without any radio interference from your
friends’ transmitters or vehicles. You must be racing
against another Multi-channel-equipped vehicle for this
feature to work.
• There’s one Multi-channel selector switch on your
vehicle chassis, and another one on your transmitter.
The vehicle switch has 3 positions: one for each Multi-
channel setting.
The transmitter switch has 3 positions: one for each Multi-
channel setting, plus an OFF position.
• For successful operation, the vehicle switch and the
transmitter switch must be set to the same Multi-channel
setting. When you’re driving by yourself, you can set the
switches to any of the 3 Multi-channel settings (as long
as they match).
• When you want to race head-to-head, just make sure
that each driver (up to 6 drivers total) has a vehicle and
transmitter set to a different Multi-channel setting.
* To operate your vehicle, just turn the vehicle ON; then
set the transmitter switch to the desired Multi-chan-
nel setting. Push any transmitter control and you will
be able to run and control your vehicle.
*You must be racing against another Multi-channel-
equipped vehicle for this feature to work. A non-
Multi-channel vehicle, running on the same frequency
as your vehicle, may interfere with operation of your
vehicle. If you are racing against a non-Multi-channel
vehicle, make sure that vehicle operates on a fre-
quency different from yours.
* If you need to change the Multi-channel setting,
first make sure that your vehicle is turned OFF.
Change the Multi-channel switch position as desired
on both the transmitter AND the vehicle. Then turn
your vehicle back ON for more racing action.
NOTE: Make certain you’re not pressing a transmitter
control while changing selector switch position.
1 2 3
1 2 3
RIGHT
RIGHT
RIGHT
RIGHT
FORWARD REVERSE LEFT RIGHT
IV. BATTERY INSTALLATION
Note: Your vehicle can be used with a Tyco® R/C 9.6V NiCd
battery pack or 6 AA alkaline batteries.
Requires a Tyco® R/C 9.6V NiCd battery pack or 6 AA
alkaline batteries for vehicle and 2 AA alkaline batteries
for transmitter.
*Though your Fury FTXTM can run on both 9.6V or
6 x AA batteries it will run up to 30% faster when
using a 9.6V rechargeable battery.
Vehicle
9.6V NiCd battery pack
1. Use a screwdriver (not included) to unscrew the battery
cover.
2. Unscrew and remove the AA battery adapter. Store in a
safe place for later usage.
3. Insert the 9.6V NiCd battery pack (not included), with
polarity (+/-) as shown inside the battery
compartment .
4. Plug the wire connector into the battery compartment
as shown.
5. Replace the battery cover.
6 AA alkaline batteries
1. Use a screwdriver (not included) to unscrew the battery
cover.
2. Make sure the AA battery adapter is firmly in place. If
it’s not, position the adapter in the box and fasten it with
the screw.
3. Insert the 6 AA batteries (not included), with polarity
(+/-) as shown inside the battery compartment .
4. Replace the battery cover.
Transmitter
1. Remove the battery cover as shown.
2. Install 2 AA batteries (not included), with polarity (+/-) as
shown inside the battery compartment.
3. Replace the battery cover.
* If the transmitter’s LED indicator does not light when
the transmitter is switched ON, it’s time to replace the
transmitter batteries. Simply install fresh batteries as
described above.
; V. QUICK TIPS
1. The best jumps are the ones where the rear wheels hit
the ground first. It’s important to give your Fury FTXTM
vehicle just enough power as it leaves the ramp. Too
much power and your nose will rise abruptly, too little
and you’ll land on the front wheels. When you do land,
make sure all four wheels are on the ground before you
accelerate. If you don’t you may cause a wheelie, which
may look really cool, but you’ll lose time.
2. The Fury FTXTM was meant to fly high and land soft but
just because you can doesn’t mean you should – espe-
cially if you’re in a race. Remember, the more time your
vehicle spends in the air, the less time you’ll have to
accelerate. So stay low to win big!
3. Radio interference can affect your vehicle’s perfor-
mance. Interference can be caused by other R/C vehicles
running on the same frequency, electrical wires, large
buildings, CB radios or other wireless gear. Try to stay
away from these!
4. Point your transmitter antenna up - not down toward
your vehicle. If your vehicle gets too far away, it won’t
work properly.
5. Don’t drive your vehicle through water or snow. If your
vehicle does get wet, wipe it with a towel and allow it to
dry completely.
6. Don’t store your vehicle near heat or in direct sunlight.
Always turn switches OFF and remove all batteries for
storage.
1
2
3
6
5
4
9.6V d.c. NiCd,
1 x 6 ”AA”,
700mAh
COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S. ONLY)
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device generates and uses radio frequency energy and if not used
properly may cause interference to radio and television reception. It has
been tested and found to comply with the limits set by the FCC which are
designed to provide reasonable protection against such interference.
NOTE: Changes or modifications not expressively approved by the
manufacturer responsible for compliance could void the user’s authority to
operate the equipment.
© 2005 Mattel, Inc., 333 Continental Blvd., El Segundo, CA 90245 U.S.A.
Consumer Affairs: 1-888-557-8926. PRINTED IN CHINA. All Rights Reserved.
MATTEL, Hot Wheels and associated trademarks and trade dress are
owned by Mattel, Inc. Retain this address for future reference: Mattel U.K.
Ltd., Vanwall Business Park, Maidenhead SL6 4UB. Helpline 01628 500303.
Mattel Australia Pty Ltd., Richmond, Victoria 3121 - Consumer Advisory
Service: 1300 135 312. Mattel East Asia Ltd, Room 1106, South Tower, World
Finance Centre, Harbour City, Tsimshatsui, HK, China. Diimport & Diedarkan
Oleh: Mattel SEA Ptd Ltd. (993532-P) Lot 13.5, Menara Lien Hoe, Persiaran
Tropicana Golf Country Resort, 47410 PJ. Tel: 03-78803817,
Fax: 03-78803867.
Mattel, Inc. warrants to the original consumer purchaser that this product
will be free of defects in material and workmanship for ninety (90) days
(unless specified in alternate warranties) from the date of purchase.
Mattel will replace the product in the event of such a defect within the
warranty period.
In the event of a defect covered under this warranty, first call the toll-free
number listed below. Many problems can be solved in this manner.
If necessary, you will be instructed to return the product, postage prepaid
and insured, to the address below. Enclose your name, address, dated
sales receipt, and a brief explanation of the defect. Replacement and
return shipment will be free of charge.
This warranty does not cover damage resulting from unauthorized
modification, accident, misuse or abuse. If the product is returned without
a dated sales receipt the product may be excluded from
coverage under this warranty.
Mattel’s liability for defects in material and workmanship under this
warranty shall be limited to repair or replacement, at our sole option, and in
no event shall we be responsible for incidental, consequential, or
contingent damages (except in those states that do not allow this exclusion
or limitation). This warranty is exclusive, and is made in lieu of any express
or implied warranty. Valid only in U.S.A. This warranty gives you specific
legal rights and you may have other rights, which vary from state to state.
Some states do not allow the exclusion of incidental or consequential
damages, so the above exclusions or limitations may not apply to you.
TOLL-FREE NUMBER: 1-888-557-TYCO (8926) (valid only in U.S.A.)
Hours: 8:00 A.M. - 5:00 P.M. Eastern Time; Monday - Friday. Expect some
delay in January following the holiday season. Please be patient and keep
trying the toll-free number.
ADDRESS FOR RETURNS:
CONSUMER RELATIONS
636 GIRARD AVENUE
EAST AURORA, NY 14052.
90 DAY LIMITED WARRANTY – Hot Wheels® R/C PRODUCTS
ì
CONSUMER INFORMATION
Note to adults: To ensure that the child’s play is both safe
and fun, please review all operating instructions and
safety rules with your child.
Safety Tips
• NEVER drive your vehicle on streets! They’re for real
cars!
• DO NOT pick up vehicle while in motion.
• Take your fingers off the transmitter trigger and then pick
it up.
• Keep fingers, hair and loose clothing away from the tires
and the wheel hubs while the vehicle is switched ON.
• Adult supervision is recommended when this vehicle is
being operated.
• To avoid accidental operation, remove all batteries when
not
in use. Always turn the vehicle OFF before removing
batteries.
BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids that
can cause a chemical burn injury or ruin your product.
To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the product
before being charged (if designed to be removable).
• Rechargeable batteries are only to be charged under
adult supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc), or rechargeable
(nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries
inside may explode or leak.
Battery Performance Note:
For best performance use regular or high-performance
alkaline batteries (where disposable batteries are called
for). If your vehicle is supplied with standard (carbon-zinc)
batteries for initial use and/or demonstration purposes, we
recommend replacing them with alkaline batteries when
necessary. Battery life may vary depending on battery
brand.
