Mattel Asia Pacific Sourcing K7238-07A4T DUNE DEVIL PRO User Manual USERS MANUAL
Mattel asia Pacific Sourcing Ltd. DUNE DEVIL PRO USERS MANUAL
USERS MANUAL
XCAUTION:Surfaces may become hot
and cause burns if electronics get wet. Do not
operate vehicle through water or snow.
Keep these instructions for future reference as they
contain important information. IMPORTANT: Please
read all “Consumer Information” before operating
your vehicle.
I. CONTENTS/ FEATURES
Vehicle
Transmitter
Vehicle
Antenna
*You will need to slip the loose antenna wire into the
provided tube (it looks like a straw). Then push the
straw (with wire already enclosed) firmly into the
cylindrical opening on the chassis.
Steering adjuster
*Turn with a screwdriver (not included) to keep
vehicle running straight.
ON(I)/OFF(O) switch
Battery door
!AA Battery adapter
Transmitter
LAntenna
RLED indicator(Light that indicates when your
transmitter is turned on or off).
@Steering knob: left / right control
MTrigger: forward / reverse control
OON(I)/OFF(O) switch
TBattery door
*Just turn your vehicle ON. Then pull the trigger and
you will be able to run and control your vehicle.
*Pull trigger all the way back for that extra punch of
power.
Asst.K9581
K7237/38-0920
L
R
@
M
®
XCAUTION:To prevent entanglement,
keep hair away from wheels.
I O
I O
O
T
I O
I O
!
Hot Wheels® R/C SUPPORT
Questions or problems with your product?
DON’T RETURN IT TO THE STORE!
Just call us for help.
U.S. consumers may also register their products at this number.
1-888-557-8926
1 2 3
I O
1 2 3
I O
II. VEHICLE OPERATION
*If your vehicle doesn’t move when you use the trans-
mitter there’s a good chance your vehicle’s battery is
ready for a recharge.
III. BATTERY INSTALLATION
Note: Your vehicle can be used with a Tyco® R/C 9.6V NiCd
battery pack or 6 AA alkaline batteries.
Requires a Tyco® R/C 9.6V NiCd battery pack or 6 AA
alkaline batteries for vehicle and 2 AA alkaline batteries
for transmitter.
*Though your vehicle can run on both 9.6V or
6 x AA batteries it will run up to 30% faster when
using a 9.6V rechargeable battery.
Vehicle
9.6V NiCd battery pack
1. Use a screwdriver (not included) to unscrew the battery
cover.
2. Unscrew and remove the AA battery adapter. Store in a
safe place for later usage.
3. Insert the 9.6V NiCd battery pack (not included), with
polarity (+/-) as shown inside the battery
compartment .
4. Plug the wire connector into the battery compartment
as shown.
5. Replace the battery cover.
6 AA alkaline batteries
1. Use a screwdriver (not included) to unscrew the battery
cover.
2. Make sure the AA battery adapter is firmly in place. If
it’s not, position the adapter in the box and fasten it with
the screw.
3. Insert the 6 AA batteries (not included), with polarity
(+/-) as shown inside the battery compartment .
4. Replace the battery cover.
Transmitter
1. Remove the battery cover as shown.
2. Install 2 AA batteries (not included), with polarity (+/-) as
shown inside the battery compartment.
3. Replace the battery cover.
*If the transmitter’s LED indicator does not light when
the transmitter is switched ON, it’s time to replace the
transmitter batteries. Simply install fresh batteries as
described above.
RIGHT
FORWARD REVERSE LEFT RIGHT
9.6V d.c. NiCd,
1 x 8 ”AA”,
700mAh
6 x AA
;IV. QUICK TIPS
1. The best jumps are the ones where the rear wheels hit
the ground first. It’s important to give your vehicle just
enough power as it leaves the ramp. Too much power
and your nose will rise abruptly, too little and you’ll land
on the front wheels. When you do land, make sure all
four wheels are on the ground before you accelerate.
If you don’t you may cause a wheelie, which may look
really cool, but you’ll lose time.
2. The vehicle was meant to fly high and land soft but just
because you can doesn’t mean you should – especially if
you’re in a race. Remember, the more time your vehicle
spends in the air, the less time you’ll have to accelerate.
So stay low to win big!
3. Radio interference can affect your vehicle’s perfor-
mance. Interference can be caused by other R/C vehicles
running on the same frequency, electrical wires, large
buildings, CB radios or other wireless gear. Try to stay
away from these!
4. Point your transmitter antenna up - not down toward
your vehicle. If your vehicle gets too far away, it won’t
work properly.
5. Don’t drive your vehicle through water or snow. If your
vehicle does get wet, wipe it with a towel and allow it to
dry completely.
6. Don’t store your vehicle near heat or in direct sunlight.
Always turn switches OFF and remove all batteries for
storage.
XV.
CONSUMER INFORMATION
Note to adults: To ensure that the child’s play is both safe
and fun, please review all operating instructions and
safety rules with your child.
Safety Tips
• NEVER drive your vehicle on streets! They’re for real
cars!
• DO NOT pick up vehicle while in motion.
• Take your fingers off the transmitter trigger and then pick
it up.
• Keep fingers, hair and loose clothing away from the tires
and the wheel hubs while the vehicle is switched ON.
• Adult supervision is recommended when this vehicle is
being operated.
• To avoid accidental operation, remove all batteries when
not
in use. Always turn the vehicle OFF before removing
batteries.
BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids that
can cause a chemical burn injury or ruin your product.
To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the product
before being charged (if designed to be removable).
• Rechargeable batteries are only to be charged under
adult supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc), or rechargeable
(nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries
inside may explode or leak.
Battery Performance Note:
For the best possible performance use a 9.6V NiCd battery
and get up to a 30% more speed. You can also use regular
or high-performance alkaline batteries (where disposable
batteries are called for). If your vehicle is supplied with
standard (carbon-zinc) batteries for initial use and/or dem-
onstration purposes, we recommend replacing them with
alkaline batteries when necessary. Battery life may vary
depending on battery brand.
Protect the environment by not disposing of
this product with household waste (2002/96/
EC). Check your local authority for recycling
advice and facilities.
1
2
3
6
5
4
COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S. ONLY)
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device generates and uses radio frequency energy and if not used
properly may cause interference to radio and television reception. It has
been tested and found to comply with the limits set by the FCC which are
designed to provide reasonable protection against such interference.
NOTE: Changes or modifications not expressively approved by the
manufacturer responsible for compliance could void the user’s authority to
operate the equipment.
Mattel, Inc. warrants to the original consumer purchaser that this product
will be free of defects in material and workmanship for ninety (90) days
(unless specified in alternate warranties) from the date of purchase.
Mattel will repair or replace the product, at our sole option, in the event of
such a defect within the warranty period.
In the event of a defect covered under this warranty, first call the toll-free
number listed below. Many problems can be solved in this manner. If nec-
essary, you will be instructed to return the product, postage prepaid and
insured, to the address below. Enclose your name, address, dated sales
receipt, and a brief explanation of the defect. Repair or replacement, and
return shipment, will be free of charge. Please return only the defective
part or unit, packed securely.
This warranty does not cover damage resulting from unauthorized
modification, accident, misuse or abuse. If the product is returned without
a dated sales receipt, the product may be excluded from coverage under
this warranty.
90 DAY LIMITED WARRANTY – Hot Wheels®R/C PRODUCTS
Mattel’s liability for defects in material and workmanship under this war-
ranty shall be limited to repair or replacement, at our sole option, and in no
event shall we be responsible for incidental, consequential, or contingent
damages (except in those states that do not allow this exclusion or
limitation). This warranty is exclusive, and is made in lieu of any express
or implied warranty. This warranty gives you specific legal rights and you
may have other rights, which vary from state to state. Some states do not
allow the exclusion of incidental or consequential damages, so the above
exclusions or limitations may not apply to you.
TOLL-FREE NUMBER: 1-888-557-8926 - Valid only in U.S.A.
Hours: 8:00 A.M.-5:00 P.M. Eastern Time; Monday - Friday. Expect some
delay in January following the holiday season. Please be patient and keep
trying the toll-free number.
ADDRESS FOR RETURNS:
CONSUMER RELATIONS
636 GIRARD AVENUE
EAST AURORA, NY 14052
Valid only in U.S.A.
© 2006 Mattel, Inc., 333 Continental Blvd., El Segundo, CA 90245 U.S.A.
Consumer Relations 1-888-557-8926 PRINTED IN CHINA. service.mattel.com.
