Mattel Asia Pacific Sourcing K8880-06A4R JEEP HURRICANE RE-DECO User Manual USERS MANUAL
Mattel asia Pacific Sourcing Ltd. JEEP HURRICANE RE-DECO USERS MANUAL
USERS MANUAL
Keep these instructions for future reference: they
contain important information.
I. CONTENTS
• Vehicle
• Transmitter
• 2 AA Batteries (if supplied)
• 4.8V Jet Turbo® Battery Pack (if supplied)
• 4.8V Jet Turbo® Charger (if supplied)
Please check the package for the specific power system
for this vehicle:
Vehicles use the Tyco® R/C 4.8V Jet Turbo® rechargeable
NiCd Battery Pack & Charger.
You’ll find detailed information about all these power
systems in this Owner’s Manual.
For information about the 4.8V Jet Turbo® NiCd power
system, please refer to Section VI.
II. CHASSIS
Your vehicle’s chassis will look like one of the chassis
shown, depending on the vehicle’s design.
❶ Battery latch
❷ ON/OFF switch
❸ Steering adjuster
Refer to label on transmitter and vehicle for frequency.
Do not race vehicles with the same frequency.
III. VEHICLE OPERATION
❶ FORWARD
❷ REVERSE
❸ LEFT
❹ RIGHT
CAUTION:
Surfaces may become hot and cause burns if
electronics get wet. Do not operate vehicle through water or
snow.
FORWARD REVERSE
LEFT
RIGHT
w
r
y
e
q
t
❶
❷
❸
®
Hot Wheels
®
R/C SUPPORT
Questions or problems with your product?
DON’T RETURN IT TO THE STORE!
Just call us for help.
U.S. consumers may also register their products at this number.
1-888-557-8926
ASST.K8517
K7231/32/33/34-0920
IV. TRANSMITTER
Transmitters are equipped with a special automatic ON
battery-saving feature. Just turn your vehicle ON. Then
push either transmitter stick and you will be able to run and
control your vehicle.
TRANSMITTER
1. To install the transmitter battery, open the battery cover as
shown.
2.
Install 2 AA batteries with polarity (+/-) as shown inside the
battery compartment.
3. Replace the battery cover.
V. POWER CLIP
Please check the package for the specific power system for this
vehicle:
Vehicles use the Tyco® R/C 4.8V Jet Turbo® rechargeable NiCd
Battery Pack & Charger.
For detailed information regarding NiCd battery charging and
safety, please follow the specific instructions that came with your
battery pack and charger.
VEHICLE BATTERY INSTALLATION
These instructions apply to the 4.8V Jet Turbo® rechargeable NiCd
Battery Pack.
1. Rotate the battery latch to the open position.
2. Insert the rechargeable NiCd battery pack) into the battery
compartment and slide it away from the latch.
3. Make sure the rechargeable NiCd battery pack) snaps securely
in place. Rotate the latch to the locked position.
4. To remove: turn the latch, slide it toward the latch and lift it out.
VI. 4.8V JET TURBO® NiCd
1. Rotate the battery latch to the open position.
2. Insert the battery pack into the battery compartment and slide it away
from the latch.
3. Make sure the battery pack snaps securely in place and rotate
the latch to the locked position.
4. To remove the battery pack: turn the latch, slide the battery pack
toward the latch and lift it out.
BATTERY CHARGING/CARE – 4.8V JET TURBO® BATTERY
X CAUTION: Use only the charger supplied with this toy. Do not
use any other charging source.
1. Plug the wall pack charger into a standard wall outlet.
2. Click the battery pack into the charger. Make certain the battery
pack is secure in the charger.
3. To disconnect, push the red button on the side of charger and
simultaneously slide the battery pack out.
4. After charging, the battery will feel warm. This condition is
normal for fully charged batteries.
5. New battery packs must be charged for 10 hours the first
two times charged. Subsequent charges will require 6 hours.
Charging the battery pack for more than 6 hours will not give you
a longer running time. 6 hours is all that is required for a fully
charged battery pack.
6. Unlike alkaline batteries, where the power loss is gradual, a NiCd
battery will run for its normal running time and then lose most of
its power at once. That's when you'll know it is time to recharge
the battery pack.
2 xAA/LR6
7. After use, the battery pack will be hot! Wait at
least 20 minutes until the battery pack cools before
recharging. Recharging a warm or hot battery pack
will greatly reduce the number of times your battery
pack can be recharged. Charge only TYCO® R/C
Jet Turbo® 4.8V NiCd 700 or 800mAh rechargeable
battery packs. Other types of batteries may burst
and causing injury to persons and damage.
8. The charger must be disconnected
from the electric supply.
w
r
y
e
q
t
4.8V d.c.
NiCd
1X4 "AA"
w
r
y
e
q
t
w
r
y
e
q
t
CONSUMER INFORMATION
Note to Adults: To ensure that the child’s play is both
safe and fun, please review all operating instructions
and safety rules with your child.
SAFETY TIPS
• NEVER drive your vehicle on streets!
They’re for real cars!
• DO NOT pick up vehicle while in motion.
• Keep fingers, hair and loose clothing away from the
tires and the wheel hubs while the vehicle is switched
ON.
X CAUTION: To prevent entanglement, keep hair away
from wheels.
• Adult supervision is recommended when this vehicle is
being operated.
• To avoid accidental operation, remove all batteries
when not in use. Always turn the vehicle OFF before
removing batteries.
BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids
that can cause a chemical burn injury or ruin your toy
(product). To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the toy
before being charged (if designed to be removable).
• Rechargeable batteries are only to be charged under
adult supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the toy.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this toy in a fire. The batteries inside
may explode or leak.
Battery Performance Note:
For best performance use regular or high-performance
alkaline batteries (where disposable batteries are called
for). If your vehicle is supplied with standard (carbon-
zinc) batteries for initial use and/or demonstration
purposes, we recommend replacing them with alkaline
batteries when necessary.
Battery life may vary depending on battery brand.
QUICK TIPS
1. When your vehicle starts to lose power, it may lose
functions or performance. It's time for a recharge.
For best stunt performance, always start with a
fully-charged battery.
2. Your vehicle's running time may change depending on
your driving style.
3. Radio interference can make your vehicle run badly.
Interference can be caused by other R/C vehicles
running on the same frequency; electrical wires; large
buildings; CB radios; or other wireless gear. Try to
stay away from these!
4. Point your transmitter antenna up - not down toward
your vehicle. If your vehicle gets too far away, it won't
work properly.
5. Don’t drive your vehicle in sand or through water or
snow. f your vehicle does get wet, wipe with a towel
and allow to dry completely.
6. Don’t store your vehicle near heat or in direct
sunlight. Always turn switches OFF and remove all
batteries for storage.
RECHARGEABLE BATTERY INFORMATION:
• DO NOT RECHARGE BATTERY PACK IF IT’S HOT. ALLOW IT TO
COOL BEFORE RECHARGING.
• DO NOT RECHARGE A BATTERY PACK THAT SHOWS LEAKAGE
OR CORROSION.
• DO NOT DISASSEMBLE THE BATTERY PACK. THE BATTERY
PACK IS A SEALED
RECHARGEABLE NiCd BATTERY PACK.
• EXERCISE CAUTION IN HANDLING A HOT BATTERY PACK.
• IF BATTERY PACK AND/OR CHARGER ARE WET, THOROUGHLY
DRY BEFORE
CHARGING.
• DO NOT RECHARGE NON-RECHARGEABLE
BATTERIES.
• THIS POWER UNIT IS INTENDED TO BE CORRECTLY
ORIENTATED IN A VERTICAL OR FLOOR MOUNT POSITION.
Note to Adults:
• Remove rechargeable batteries before recharging.
• The battery charger is for adult use only.
• Regularly examine for damage to the plug, enclosure
and other parts. In the event of any damage, the toy
must not be used with the charger until the damage
has been repaired.
• The charger is not a toy.
M
THIS PRODUCT USES A NICKEL-CADMIUM
RECHARGEABLE BATTERY PACK. BATTERY
MUST BE RECYCLED OR DISPOSED OF
PROPERLY. FOR FURTHER INFORMATION
REGARDING BATTERIES OR THEIR DISPOSAL
PLEASE CALL 1-888-557-8926.
w
r
y
e
q
t
Protect the environment by not disposing of
this product with household waste (2002/96/EC).
Check your local authority for recycling advice
and facilities.
Mattel, Inc. warrants to the original consumer purchaser that this product
will be free of defects in material and workmanship for ninety (90) days
(unless specified in alternate warranties) from the date of purchase.
Mattel will repair or replace the product, at our sole option, in the event of
such a defect within the warranty period.
In the event of a defect covered under this warranty, first call the toll-free
number listed below. Many problems can be solved in this manner. If nec-
essary, you will be instructed to return the product, postage prepaid and
insured, to the address below. Enclose your name, address, dated sales
receipt, and a brief explanation of the defect. Repair or replacement, and
return shipment, will be free of charge. Please return only the defective
part or unit, packed securely.
This warranty does not cover damage resulting from unauthorized
modification, accident, misuse or abuse. If the product is returned without
a dated sales receipt, the product may be excluded from coverage under
this warranty.
90 DAY LIMITED WARRANTY – Hot Wheels® R/C PRODUCTS
Mattel’s liability for defects in material and workmanship under this war-
ranty shall be limited to repair or replacement, at our sole option, and in no
event shall we be responsible for incidental, consequential, or contingent
damages (except in those states that do not allow this exclusion or
limitation). This warranty is exclusive, and is made in lieu of any express
or implied warranty. This warranty gives you specific legal rights and you
may have other rights, which vary from state to state. Some states do not
allow the exclusion of incidental or consequential damages, so the above
exclusions or limitations may not apply to you.
TOLL-FREE NUMBER: 1-888-557-8926 - Valid only in U.S.A.
Hours: 8:00 A.M.-5:00 P.M. Eastern Time; Monday - Friday. Expect some
delay in January following the holiday season. Please be patient and keep
trying the toll-free number.
ADDRESS FOR RETURNS:
CONSUMER RELATIONS
636 GIRARD AVENUE
EAST AURORA, NY 14052
Valid only in U.S.A.
COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S. ONLY)
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
This device generates and uses radio frequency energy and if
not used properly may cause interference to radio and televi-
sion reception. It has been tested and found to comply with the
limits set by the FCC which are designed to provide reasonable
protection against such interference.
NOTE: Changes or modifications not expressively approved by
the manufacturer responsible for compliance could void the
user’s authority to operate the equipment.
© 2006 Mattel, Inc., 333 Continental Blvd., El Segundo, CA 90245 U.S.A.
Consumer Relations 1-888-557-8926 PRINTED IN CHINA. service.mattel.
com. • Mattel Canada Inc., Mississauga, Ontario L5R 3W2.
• Mattel U.K. Ltd., Vanwall Business Park, Maidenhead SL6 4UB.
Helpline 01628500303 • Mattel Australia Pty., Ltd., Richmond, Victoria.
3121.Consumer Advisory Service - 1300 135 312. • Mattel East Asia
Ltd., Room 1106, South Tower, World Finance Centre, Harbour City,
Tsimshatsui, HK, China. • Diimport & Diedarkan Oleh: Mattel SEA Ptd
Ltd.(993532-P) Lot 13.5, 13th Floor, Menara Lien Hoe, Persiaran Tropi-
cana Golf Country Resort, 47410 PJ. Tel:03-78803817, Fax:03-78803867.
