Mattel asia Pacific Sourcing Ltd. TURBO PRO WHEELIE CYCLE USERS MANUAL
USERS MANUAL
GET STARTED!
Your Turbo Pro Wheelie Cycle™ is a high performance
motorcyle that allows you to pull off outrageous “one touch”
stunts like wheelies and Turbo boost action. Plus, your
Turbo Pro Wheelie Cycle™ has a specialized stabilizer that
that allows for maximum stability for your most radical
stunts.
1.GET SET!
Hold the Turbo Pro Wheelie Cycle™ off the ground and
rotate the right throttle control all the way.
*Be sure to keep your fingers clear of the wheels at all
times.
2.LAUNCH IT!
Gently hand-launch your vehicle. Set it on the ground and
give it a gentle push while rotating the right throttle control.
I. CONTENTS/ FEATURES
• Turbo Pro Wheelie Cycle™ Vehicle
• TYCO® R/C NiMH Charger
• TYCO® R/C 9.6V d.c. NiMH Battery Pack
• 2 x AA Battery for controller
• Controller
• 2 x Skid Pad
VEHICLE
q Rider Figure (not removable)
w ON/OFF Switch
e Battery Latches
r Battery Compartment
TURBOTILT™ CONTROLLER
NOTE: Your Turbo Pro Wheelie Cycle™ uses a unique
controller with a sophisticated gravity switch to control
your steering. Just turn your vehicle ON. Then tilt the
Turbotilt™ controller to steer. Tilt the Turbotilt™ to the left
to turn left, Tilt right to turn right.
q Forward Control (throttle)
w Wheelie Button
e Turbo Button
r ON/OFF Switch
t Brakes
y Battery Compartment
u Antenna
i ON/OFF Light
Keep these instructions for
future reference as they
contain important information.
IMPORTANT: Please read
all “Consumer Information”
before operating your vehicle.
TYCO R/C SUPPORT
Questions or problems with your product?
DON’T RETURN IT TO THE STORE!
Just call us for help.
U.S. consumers may also register their products at this number.
1 888 557-TYCO (8926)
®
tycorc.com
NOT RECOMMENDED
FOR CHILDREN UNDER
8 YEARS OF AGE. AS WITH ALL ELECTRICAL PRODUCTS, PRECAUTIONS SHOULD BE
OBSERVED DURING HANDLING AND USE TO REDUCE THE RISK OF ELECTRIC SHOCK.
INPUT: 120VAC, 60Hz, 6W. OUTPUT: 11.2VDC, 230mA.
CAUTION-ELECTRIC TOY:
4
3
2
6
81
5
7
1
2 3 4
ASST. M0678
N1919/N1920-0920
8+
CAUTION:Surfaces may become hot
and cause burns if electronics get wet. Do not
operate vehicle through water or snow.
FRONT BACK
A
B
C
II. QUICK START
Please read this Owner’s Manual thoroughly.
1.Start with a full charge.
2.Turn the vehicle and the transmitter switches to on. Rotate
the Turbotilt™ forward “throttle” control to run and control
your vehicle.
3.When you’re done driving, turn vehicle and transmitter ON/
OFF to the OFF position. Remove all batteries for storage.
III. BASIC OPERATION
IV. COOL STUNTS
This is a high-performance stunt vehicle...challenging and fun
to drive. You’ll need to PRACTICE to perfect your stunt tech-
nique. Test your skill and challenge your friends!
WHEELIES
Press the left button as shown while driving the vehicle straight,
it will stand up with one wheel as shown and move forward.
To come out of your wheelie gently tap on the brakes and
continue driving.
*Your vehicle will do wheelies on command! It also does
great stunts like jumps, rolls, and spin outs, and just
keeps on going. The Turbo Pro Wheelie Cycle™ gives you
amazing stunt cycle action with realistic tilt-motion con-
trols that feel and respond like the real thing.
WHEELIE TIP:
Drive for 8 seconds in a straight line to get the gyro stabilizer
up to super fast speed, then press the wheelie button to pop
a wheelie. Make sure cycle is going straight when you pop a
wheelie.
TURBO BOOST
Press the TURBO BOOST button on the right to add some extra
punch to your wicked fast speed!
Tip: Wheelie Cycle performs stunts best when the gyro is
running at full speed. The gyro automatically revs up as you
drive the vehicle. For best stunts, drive the vehicle around for 8
seconds or more to rev up the gyro before attempting a stunt.
Replace the worn down skid pad
1. If you see that the skid pad has been worn down it’s time to
replace it.
2. Unscrew the pad from the top of the skid bar with a phillips-
head screw driver (not included).
3. Remove the pad and replace it with a new one.
4. Use the screwdriver to fasten the new pad firmly into place.
TURBO
WHEELIES
FORWARD
LEFT TURN
BRAKING
RIGHT TURN
USE EITHER BRAKE
TILT
TILT
D E
F G
H
I
2.
3.
4.
1.
J
V. BATTERY CHARGING/CARE
Use only Tyco® R/C 9.6V NiMH battery packs. Other batteries may
leak or rupture, causing personal injury and damage.
1. Plug the wall pack charger into a standard wall outlet.
2. Connect the wires leading from the battery pack to the wall pack
charger connector. Make certain the two connectors are tightly
snapped together.
3. To disconnect the wires, push down on the connector clip and
pull apart.
4. After charging, the battery will feel warm. Have no fear, that’s
normal for fully charged batteries.
5. New battery packs must be charged for 5 1/2 hours the first two
times. After that you’re looking at 4 hours per charge. Charging
the battery pack for more than 4 hours won’t extend your
running time but if it makes you happy, charge away.
6. Unlike alkaline batteries, which lose power gradually, a NiMH
battery will operate for its normal running time and then lose
most of its power at once. When that starts to happen, recharge
the battery pack.
7. After use, the battery pack will be hot! Wait at least 20 minutes
until the battery pack cools down before recharging. Recharging
a hot battery will greatly reduce the number of times your
battery pack can be recharged.
8. The Charger must be disconnected from the electric supply.
X CAUTION: Use only the charger supplied with this toy. Do not
use any other charging source.
VI. BATTERY INSTALLATION
Your vehicle will only operate with the TYCO® R/C 9.6V NiMH
Battery Pack and Charger. For detailed information regarding
rechargeable battery charging and safety, please refer to “Battery
Charging/Care” Section.
VEHICLE
1. Rotate the battery latches to open position. Open the battery
door.
2. Plug the wire connector into the battery compartment as shown.
3. Insert the battery pack into the battery compartment as shown.
4. Close the battery door. Rotate the battery latches to the locked
position.
5. To remove the battery pack: first turn the vehicle off, turn the
latches on the battery compartment, open the battery door,
unplug the wire connector and lift out the battery pack.
CONTROLLER
1. Open the battery door as shown.
2. Install 2 “AA” batteries inside the battery compartment as
shown.
3. Close the battery door.
VII. QUICK TIPS
1. When your vehicle starts to lose power, it may lose functions or
performance. It’s time for fresh batteries
(or a recharge). Your vehicle’s running time may change
depending on your driving style.
2. Radio interference can make your vehicle run poorly.
Interference can be caused by other R/C vehicles running on the
same frequency, electrical wires, large buildings, CB radios or
other wireless gear. Try to stay away from these!
3. Point your transmitter antenna toward your vehicle. If your
vehicle gets too far away, it won’t work properly.
4. Don’t drive your vehicle through water or snow.
If your vehicle does get wet, wipe it with a towel and allow it to
dry completely.
5. Don’t store your vehicle near heat or in direct sunlight. Always
turn switches OFF and remove all batteries for storage.
RECHARGEABLE BATTERY INFORMATION:
• DO NOT RECHARGE BATTERY PACK IF IT’S HOT. ALLOW IT TO
COOL BEFORE RECHARGING.
• DO NOT RECHARGE A BATTERY PACK THAT SHOWS LEAKAGE
OR CORROSION.
• DO NOT DISASSEMBLE THE BATTERY PACK. THE BATTERY
PACK IS A SEALED RECHARGEABLE NICKEL-METAL HYDRIDE
BATTERY PACK.
• EXERCISE CAUTION IN HANDLING A HOT BATTERY PACK.
• IF BATTERY PACK AND/OR CHARGER ARE WET, THOROUGHLY DRY
BEFORE CHARGING.
• DO NOT RECHARGE NON-RECHARGEABLE BATTERIES.
1
2
2 x AA
1.
2.
3.
4.
5.
9.6V d.c. NiMH,
1 x 8 AA,
850 mAh
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
NOTE: Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user’s
authority to operate the equipment.
© 2008 Mattel, Inc., 333 Continental Blvd., El Segundo, CA 90245 U.S.A. All Rights Reserved. Consumer Relations 1-888-557-8926 PRINTED IN CHINA.
service.mattel.com. • Mattel Canada Inc., Mississauga, Ontario L5R 3W2. • Mattel U.K. Ltd., Vanwall Business Park, Maidenhead SL6 4UB. Helpline
01628500303. • Mattel Australia Pty., Ltd., Richmond, Victoria. 3121.Consumer Advisory Service - 1300 135 312. • Mattel East Asia Ltd., Room 1106,
South Tower, World Finance Centre, Harbour City, Tsimshatsui, HK, China. • Diimport & Diedarkan Oleh: Mattel SEA Ptd Ltd.(993532-P) Lot 13.5, 13th
Floor, Menara Lien Hoe, Persiaran Tropicana Golf Country Resort, 47410 PJ. Tel:03-78803817, Fax:03-78803867.
Note to Adults:
• Use only Tyco® R/C 9.6V NiMH battery packs. Other batteries may
leak or rupture, causing personal injury and damage.
• Remove rechargeable batteries before recharging.
• The battery charger is for adult use only.
• Periodically examine this product for damage to the plug, housing,
or other parts that may result in the risk of fire, electric shock or
injury. If the product is damaged, do not use it.
• The charger is not a toy.
THIS PRODUCT USES A NiMH RECHARGEABLE BATTERY PACK.
THE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.
FOR FURTHER INFORMATION REGARDING BATTERIES OR THEIR
DISPOSAL PLEASE CONTACT THE APPROPRIATE LOCAL OFFICE
BATTERY DISPOSAL
Unlike NiMH rechargeable batteries, your NiMH battery pack requires
no special procedures or precautions for disposal. However, as with
all products, you should dispose of your battery pack in an environ-
mentally responsible and considerate manner.
CONSUMER INFORMATION
Adults, this toy is recommended for children 8 years of age and
older. To ensure that the child’s play is both safe and fun, please
review the operating instructions and these general safety rules
with the child.
Safety Tips
• NEVER drive your vehicle on streets! They’re for real cars!
• DO NOT pick up vehicle while in motion.
• Keep fingers, hair and loose clothing away from the tires and
the wheel hubs while the vehicle is switched ON.
• Adult supervision is recommended when this vehicle is being
operated.
• To avoid accidental operation, remove all batteries when not
in
use. Always turn the vehicle OFF before removing batteries.
XCAUTION: To prevent entanglement, keep hair away from
wheels.
BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids that can
cause a chemical burn injury or ruin your product. To avoid
battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the product
before being charged (if designed to be removable).
• Rechargeable batteries are only to be charged under adult
supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc), or rechargeable
(NiMH) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
Protect the environment by not disposing of this product
with household waste (2002/96/EC). Check your local
authority for recycling advice and facilities.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries inside
may explode or leak.
Battery Performance Note:
For best performance use regular or high-performance alkaline
batteries (where disposable batteries are called for). If your
vehicle is supplied with standard (carbon-zinc) batteries for
initial use and/or demonstration purposes, we recommend
replacing them with alkaline batteries when necessary. Battery
life may vary depending on battery brand.
Mattel, Inc. warrants to the original consumer purchaser that this product will be free of
defects in material and workmanship for ninety (90) days (unless specified in alternate
warranties) from the date of purchase. Mattel will repair or replace the product, at our sole
option, in the event of such a defect within the warranty period.
In the event of a defect covered under this warranty, first call the toll-free number listed below.
Many problems can be solved in this manner. If necessary, you will be instructed to return
the product, postage prepaid and insured, to the address below. Enclose your name, address,
dated sales receipt, and a brief explanation of the defect. Repair or replacement, and return
shipment, will be free of charge. Please return only the defective part or unit, packed securely.
This warranty does not cover damage resulting from unauthorized modification, accident,
misuse or abuse. If the product is returned without a dated sales receipt, the product may be
excluded from coverage under this warranty.
90 DAY LIMITED WARRANTY – TYCO® R/C PRODUCTS
Mattel’s liability for defects in material and workmanship under this warranty shall be limited
to repair or replacement, at our sole option, and in no event shall we be responsible for
incidental, consequential, or contingent damages (except in those states that do not allow
this exclusion or limitation). This warranty is exclusive, and is made in lieu of any express
or implied warranty. This warranty gives you specific legal rights and you may have other
rights, which vary from state to state. Some states do not allow the exclusion of incidental or
consequential damages, so the above exclusions or limitations may not apply to you.
TOLL-FREE NUMBER: 1-888-557-8926 - Valid only in U.S.A.
Hours: 8:00 A.M.-5:00 P.M. Eastern Time; Monday - Friday.
Expect some delay in January following the holiday season.
Please be patient and keep trying the toll-free number.
ADDRESS FOR RETURNS:
CONSUMER RELATIONS
636 GIRARD AVENUE
EAST AURORA, NY 14052
Valid only in U.S.A.
