Users Manual
GET STARTED!
Your Turbo Street Wheelie Cycle™ is a high performance
motorcyle that allows you to pull off outrageous “one touch”
stunts like wheelies and Turbo boost action. Plus, your
Turbo Street Wheelie Cycle™ has a specialized stabilizer that that
allows for maximum stability for your most radical stunts.
1.GET SET!
Hold the Turbo Street Wheelie Cycle™ off the ground and rotate
the right throttle control all the way.
*Be sure to keep your fingers clear of the wheels at all times.
2.LAUNCH IT!
Gently hand-launch your vehicle. Set it on the ground and give it
a gentle push while rotating the right throttle control.
I. CONTENTS/ FEATURES
• Turbo Street Wheelie Cycle™ Vehicle
• Transmitter
VEHICLE
q Rider Figure (not removable)
w ON/OFF Switch
e Battery Latches
r Battery Compartment
TRANSMITTER
NOTE: Your Turbo Street Wheelie Cycle™ uses a unique
transmitter with a sophisticated gravity switch to control your
steering. Just turn your vehicle ON. Then tilt the Ttransmitter
to steer. Tilt the transmitter to the left to turn left, Tilt right to
turn right.
q Forward Control (throttle)
w cool stunts button
e Forward / Light Flash Effects
r Battery Compartment
t Left / Light Flash Effects
y Right / Light Flash Effects
u Antenna
II. QUICK START
Please read this Owner’s Manual thoroughly.
1.Start with a full charge.
2.Turn the vehicle switches to on. Rotate the Transmitter
forward control to run and control your vehicle.
3.When you’re done driving, turn vehicle ON/OFF to the OFF
position. Remove all batteries for storage.
Keep these instructions for future reference as they contain important information.
IMPORTANT: Please read all “Consumer Information” before operating your vehicle.
ASST. N4054
P2804/P2805-0920
6+
CAUTION:Surfaces may become hot
and cause burns if electronics get wet. Do not
operate vehicle through water or snow.
FRONT BACK
A
B
C
4
3
2
1
5
6
7
1
2
3
4
III. OPERATION
FORWARD COOL STUNTS
LEFT TURN RIGHT TURN
G
IV. QUICK TIPS
1. When your vehicle starts to lose power, it may
lose functions or performance. It’s time for fresh
batteries
(or a recharge). Your vehicle’s running time may
change depending on your driving style.
2. Radio interference can make your vehicle run
poorly. Interference can be caused by other R/C
vehicles running on the same frequency, electrical
wires, large buildings, CB radios or other wireless
gear. Try to stay away from these!
3. Point your transmitter antenna toward your vehicle.
If your vehicle gets too far away, it won’t work
properly.
4. Don’t drive your vehicle through water or snow.
If your vehicle does get wet, wipe it with a towel
and allow it to dry completely.
5. Don’t store your vehicle near heat or in direct
sunlight. Always turn switches OFF and remove all
batteries for storage.
r
q
t
ew
V. BATTERY INSTALLATION
Requires 4 AA alkaline batteries for the vehicle and 2
AA alkaline batteries for the transmitter. Batteries not
included.
VEHICLE
1. Rotate the battery latches to open position. Open the battery door.
2.
Plug the wire connector into the battery compartment as shown.
3.
Insert the battery pack into the battery compartment as shown.
4. Close the battery door. Rotate the battery latches to the locked
position.
5. To remove the battery pack: first turn the vehicle off, turn the
latches on the battery compartment, open the battery door,
unplug the wire connector and lift out the battery pack.
TRANSMITTER
1. Open the battery door as shown.
2. Install 2 “AA” batteries inside the battery compartment as
shown.
3. Close the battery door.
Ä Your transmitter is equipped with a special automatic
ON battery-saving feature. Just turn your vehicle ON.
Then push either transmitter control to run and con-
trol your vehicle.
2 x AA
1
2
ì CONSUMER INFORMATION
Adults, this toy is recommended for children 8 years of age and
older. To ensure that the child’s play is both safe and fun, please
review the operating instructions and these general safety rules
with the child.
Safety Tips
• NEVER drive your vehicle on streets! They’re for real cars!
• DO NOT pick up vehicle while in motion.
• Keep fingers, hair and loose clothing away from the tires and the
wheel hubs while the vehicle is switched ON.
• Adult supervision is recommended when this vehicle is being
operated.
• To avoid accidental operation, remove all batteries when not
in
use. Always turn the vehicle OFF before removing batteries.
In exceptional circumstances batteries may leak fluids that can
cause a chemical burn injury or ruin your product. To avoid battery
leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the product before
being charged (if designed to be removable).
• Rechargeable batteries are only to be charged under adult
supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc), or rechargeable
(NiMH) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries inside may
explode or leak.
Battery Performance Note:
For best performance use regular or high-performance alkaline
batteries (where disposable batteries are called for). If your vehicle
is supplied with standard (carbon-zinc) batteries for initial use and/
or demonstration purposes, we recommend replacing them with
alkaline batteries when necessary. Battery life may vary depending
on battery brand.
Vi. BATTERY SAFETY INFORMATION
Protect the environment by not disposing of this product
with household waste (2002/96/EC). Check your local
authority for recycling advice and facilities.
XCAUTION: To prevent entanglement, keep hair away
from wheels.
Hereby, Mattel declares that this toy is in compliance with the essential requirements
and other relevant provisions of Directives 1999/5/EC, 2004/108/EC, 88/378/EEC.
Suitable for use in all EU member states. A copy of the Declaration of Conformity
may be obtained from Mattel UK Ltd.
0979 27/49 MHz
COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S. ONLY).
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
• This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: Changes or modifi cations not expressly approved by the manufacturer
responsible for compliance could void the user’s authority to operate the
equipment.
©
2008 Mattel, Inc. All Rights Reserved. Mattel, Inc., 333 Continental Blvd.,
El Segundo, CA 90245 U.S.A. Consumer Relations 1-888-557-8926. Retain
this address for future reference: • Mattel U.K. Ltd., Vanwall Business Park,
Maidenhead SL6 4UB. Helpline 01628 500303. • Mattel Australia Pty Ltd.,
Richmond, Victoria 3121 - Consumer Advisory Service: 1300 135 312. • Mattel
East Asia Ltd, Room 1106, South Tower, World Finance Centre, Harbour City,
Tsimshatsui, HK, China. • Diimport & Diedarkan Oleh: Mattel SEA Ptd Ltd.
(993532-P) Lot 13.5, Menara Lien Hoe, Persiaran Tropicana Golf Country
Resort, 47410 PJ. Tel: 03-78803817, Fax: 03-78803867. service.mattel.com
Mattel, Inc. warrants to the original consumer purchaser that this product
will be free of defects in material and workmanship for ninety (90) days
(unless specifi ed in alternate warranties) from the date of purchase. Mattel
will repair or replace the product, at our sole option, in the event of such a
defect within the warranty period.
In the event of a defect covered under this warranty, fi rst call the toll-free
number listed below. Many problems can be solved in this manner. If
necessary, you will be instructed to return the product, postage prepaid and
insured, to the address below. Enclose your name, address, dated sales
receipt, and a brief explanation of the defect. Repair or replacement, and
return shipment, will be free of charge. Please return only the defective part
or unit, packed securely.
This warranty does not cover damage resulting from unauthorized
modifi cation, accident, misuse or abuse. If the product is returned without
a dated sales receipt, the product may be excluded from coverage under
this warranty.
90 DAY LIMITED WARRANTY – Tyco® R/C PRODUCTS
Mattel’s liability for defects in material and workmanship under this
warranty shall be limited to repair or replacement, at our sole option,
and in no event shall we be responsible for incidental, consequential, or
contingent damages (except in those states that do not allow this exclusion
or limitation). This warranty is exclusive, and is made in lieu of any express
or implied warranty. This warranty gives you specifi c legal rights and you
may have other rights, which vary from state to state. Some states do not
allow the exclusion of incidental or consequential damages, so the above
exclusions or limitations may not apply to you.
TOLL-FREE NUMBER: 1-888-557-8926 - Valid only in U.S.A.
Hours: 8:00 A.M.-5:00 P.M. Eastern Time; Monday - Friday.
Expect some delay in January following the holiday season.
Please be patient and keep trying the toll-free number.
ADDRESS FOR RETURNS:
CONSUMER RELATIONS
636 GIRARD AVENUE
EAST AURORA, NY 14052
Valid only in U.S.A.
