Mattel Asia Pacific Sourcing P3093-08A2T RC Chevy Avalance Blue User Manual P2073 0920 indd
Mattel asia Pacific Sourcing Ltd. RC Chevy Avalance Blue P2073 0920 indd
Users Manual
I.CONTENTS/FEATURES
• Vehicle
• Transmitter
Vehicle
q Steering adjuster
w Battery door
e ON/OFF switch
Keep these instructions for future reference: they
contain important information. IMPORTANT: Please read
all “Consumer Information” before operating your vehicle.
Asst. P2073
N9586/87/88/89/90/91-0920
Transmitter
q Antenna
w Driving controls
e Battery door
q
w
®5+
e
q
e
w
CAUTION:
Surfaces may become hot and cause
burns if electronics get wet. Do not operate vehicle
through water or snow.
CAUTION:
To prevent entanglement, keep all hair
away from the wheels.
III.BATTERY INSTALLATION
Requires 4 AA alkaline batteries for the vehicle and 2
AAA alkaline batteries for the transmitter. Batteries not
included.
Vehicle
1. Use a screwdriver (not included) to unscrew the bat-
tery door, remove the battery door.
2. Install 4 AA batteries (not included), with polarity (+/-)
as shown inside the battery compartment.
3. Replace the battery door.
Transmitter
1. Open the battery door as shown.
2. Install 2 AAA alkaline batteries with polarity (+/-) as shown
inside the battery compartment.
3. Close the battery door.
Ä Your transmitter is equipped with a special automatic
ON battery-saving feature. Just turn your vehicle
ON. Then push either transmitter control to run and
control your vehicle.
ì CONSUMER INFORMATION
Note to Adults: To ensure that the child’s play is both
safe and fun, please review all operating instructions and
safety rules with your child.
SAFETY TIPS
• NEVER drive your vehicle on streets! They’re for real
cars!
• DO NOT pick up the vehicle while in motion.
• Keep fingers, hair and loose clothing away from the tires
and the wheel hubs while the vehicle is switched ON.
XCAUTION: To prevent entanglement, keep hair away
from wheels.
• Adult supervision is recommended when this vehicle is
being operated.
• To avoid accidental operation, remove all batteries
when not in use. Always turn the vehicle OFF before
removing the batteries.
II.VEHICLE OPERATION
FORWARD REVERSE LEFT RIGHT
A
B
C
SYMPTOM
Vehicle runs slowly or will not run.
Power indicator light on transmitter does not light.
Erratic operation or only short range possible.
Vehicle doesn’t work after going through water or snow.
• PROBABLE CAUSE
• Loose battery connection or vehicle switch not ON.
• Weak or uncharged rechargeable NiCd battery.
• Weak AA batteries (Power Clip) or
transmitter battery.
• Transmitter battery weak or not connected.
• Radio interference likely.
• Water in the electronics area.
• CORRECTION
• Check battery connector and vehicle switch.
• Charge battery or replace.
• Replace with fresh alkaline battery.
• Check connections and replace battery if required.
• Change location - see Point 2, “Quick Tips.”
• Vehicle will take several hours to dry. Allow to dry
thoroughly overnight before trying again.
• Avoid driving in water or snow.
TROUBLESHOOTING - PROBLEM? - SOLUTIONS
Battery Performance Note:
For best performance use regular or high-performance alka-
line batteries (where disposable batteries are called for). If
your vehicle is supplied with standard (carbon-zinc) batteries
for initial use and/or demonstration purposes, we recom-
mend replacing them with alkaline batteries when necessary.
Battery life may vary depending on battery brand.
BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids that
can cause a chemical burn injury or ruin your product.
To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the
product before being charged (if designed to be
removable).
• Rechargeable batteries are only to be charged under
adult supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type
as recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the
product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries
inside may explode or leak.
Protect the environment by not dispos-
ing of this product with household waste
(2002/96/EC). Check your local authority for
recycling advice and facilities.
1. When your vehicle starts to lose power, it may lose
functions or performance. It's time for fresh batteries
(or a recharge). Your vehicle's running time may
change depending on your driving style.
2. Radio interference can effect your vehicle’s
performance. Interference can be caused by other R/C
vehicles running on the same frequency, electrical wires,
large buildings or CB radios. Try to stay away from these!
3. Point your transmitter antenna up - not down toward
your vehicle. If your vehicle gets too far away, it
won't work properly. If your transmitter has an
antenna carry-loop feature, make sure the antenna
is removed from the holder and straightened before
operating.
4. Don’t drive your vehicle in sand or through water or
snow.
5. Don’t store your vehicle near heat or in direct
sunlight. Always turn switches OFF and remove all
batteries for storage.
IV.QUICK TIPS
2
1
5
4
3
COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S. ONLY).
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
• This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: Changes or modifi cations not expressly approved by the manufacturer
responsible for compliance could void the user’s authority to operate the
equipment.
Mattel, Inc. warrants to the original consumer purchaser that this product
will be free of defects in material and workmanship for ninety (90) days
(unless specifi ed in alternate warranties) from the date of purchase. Mattel
will repair or replace the product, at our sole option, in the event of such a
defect within the warranty period.
In the event of a defect covered under this warranty, fi rst call the toll-free
number listed below. Many problems can be solved in this manner. If
necessary, you will be instructed to return the product, postage prepaid and
insured, to the address below. Enclose your name, address, dated sales
receipt, and a brief explanation of the defect. Repair or replacement, and
return shipment, will be free of charge. Please return only the defective part
or unit, packed securely.
This warranty does not cover damage resulting from unauthorized
modifi cation, accident, misuse or abuse. If the product is returned without
a dated sales receipt, the product may be excluded from coverage under
this warranty.
90 DAY LIMITED WARRANTY – Tyco® R/C PRODUCTS
Mattel’s liability for defects in material and workmanship under this
warranty shall be limited to repair or replacement, at our sole option,
and in no event shall we be responsible for incidental, consequential, or
contingent damages (except in those states that do not allow this exclusion
or limitation). This warranty is exclusive, and is made in lieu of any express
or implied warranty. This warranty gives you specifi c legal rights and you
may have other rights, which vary from state to state. Some states do not
allow the exclusion of incidental or consequential damages, so the above
exclusions or limitations may not apply to you.
TOLL-FREE NUMBER: 1-888-557-8926 - Valid only in U.S.A.
Hours: 8:00 A.M.-5:00 P.M. Eastern Time; Monday - Friday.
Expect some delay in January following the holiday season.
Please be patient and keep trying the toll-free number.
ADDRESS FOR RETURNS:
CONSUMER RELATIONS
636 GIRARD AVENUE
EAST AURORA, NY 14052
Valid only in U.S.A.
©
2008 Mattel, Inc. All Rights Reserved. Mattel, Inc., 333 Continental Blvd.,
El Segundo, CA 90245 U.S.A. Consumer Relations 1-888-557-8926. Retain
this address for future reference: • Mattel U.K. Ltd., Vanwall Business Park,
Maidenhead SL6 4UB. Helpline 01628 500303. • Mattel Australia Pty Ltd.,
Richmond, Victoria 3121 - Consumer Advisory Service: 1300 135 312. • Mattel
East Asia Ltd, Room 1106, South Tower, World Finance Centre, Harbour City,
Tsimshatsui, HK, China. • Diimport & Diedarkan Oleh: Mattel SEA Ptd Ltd.
(993532-P) Lot 13.5, Menara Lien Hoe, Persiaran Tropicana Golf Country
Resort, 47410 PJ. Tel: 03-78803817, Fax: 03-78803867. service.mattel.com
