Mattel Asia Pacific Sourcing R1512-10A2T RC BATTLE FORCE 5 SABER User Manual
Mattel asia Pacific Sourcing Ltd. RC BATTLE FORCE 5 SABER
USER MANUAL
OI
I. CONTENTS / FEATURES
Vehicle
Transmitter
Vehicle
ON(I)/OFF(O) switch
Steering adjuster
R1512-0920
Transmitter
Forward / Reverse
2 Left / Right
3Switch
Battery door
Keep these instructions for future reference as
they contain important information. IMPORTANT:
Please read all “Consumer Information” before
operating your vehicle.
6+
1
1
1
1
2
2
3
4
2
3
CAUTION:
Surfaces may become hot and cause
burns if electronics get wet. Do not operate vehicle
through water or snow.
AB
2
O I
4
III. BATTERY INSTALLATION
Requires 4
AA Alkaline batteries
for the vehicle and
2 AAA Alkaline batteries for the transmitter. Batteries
not included.
Vehicle
1. Use a screwdriver (not included) to unscrew the
power clip cover screw, remove the
battery cover.
2. Install
4 AA Alkaline
batteries (not included), with
polarity (+/-) as shown inside the battery
compartment.
3. Replace the battery door and tighten screw.
Transmitter
1. Remove the battery cover as shown.
2. Install 2
AAA Alkaline
batteries (not included), with
polarity (+/-) as shown inside the battery
compartment.
3. Replace the battery cover.
Once the batteries are installed the transmitter will
always be “ON” and will work automatically the
moment you use it.
1.Forward
II. VEHICLE OPERATION
Reverse 3.LEFT RIGHT
Right
1
3
2
Reveal the hidden weapons
If the bumper hits an obstacle while driving on Side A, the panels will
open to reveal the hidden secret weapons!
Side A
4 x AA
2 x AAA
2.Left
SIDE A
IV. QUICK TIPS
1. When your vehicle starts to lose power, it may
lose functionality or performance. It’s time for
fresh batteries.
2. Your vehicle’s running time may vary
depending on your driving style.
3. Radio interference can affect your vehicle’s
performance. Interference can be caused
by other R/C vehicles running on the same
frequency, electrical wires, large buildings, CB
radios or other wireless gear. Try to stay away
from these!
4. Point your transmitter up - not down toward
your vehicle. If your vehicle gets too far away,
it won’t work properly.
5. Don’t drive your vehicle through water or
snow. If your vehicle does get wet, wipe it
with a towel and allow it to dry completely.
6. Don’t store your vehicle near heat or in direct
sunlight. Always turn switches OFF and
remove all batteries for storage.
V. CONSUMER INFORMATION
Note to adults: To ensure that the child’s play is
both safe and fun, please review all operating
instructions and safety rules with your child.
Safety Tips
• NEVER drive your vehicle on streets! They’re
for real cars!
• DO NOT pick up vehicle while in motion.
CAUTION: To prevent entanglement,
keep hair away from wheels.
• Keep fingers, hair and loose clothing away from
the tires and the wheel hubs while the vehicle
is switched ON.
• Adult supervision is recommended when this
vehicle is being operated.
• To avoid accidental operation, remove all
batteries when not
in use. Always turn the
vehicle OFF before removing batteries.
BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak
fluids that can cause a chemical burn injury or
ruin your product. To avoid battery leakage:
• Non-rechargeable batteries are not to be
recharged.
• Rechargeable batteries are to be removed from
the product before being charged (if designed
to be removable).
• Rechargeable batteries are only to be charged
under adult supervision (if designed to be
removable).
• Do not mix alkaline, standard (carbon-zinc),
or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Batteries are to be inserted with the correct
polarity.
• Exhausted batteries are to be removed from the
product.
• The supply terminals are not to be short-
circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire.
The batteries inside may explode or leak.
WARNING: Inserting or changing batteries are
actions that must be done to Note to Adults: –
using the appropriate tool to open and close
battery compartment.
Battery Performance Note:
For best performance use regular or high-
performance alkaline batteries (where
disposable batteries are called for). If your
vehicle is supplied with standard (carbon-zinc)
batteries for initial use and/or demonstration
purposes, we recommend replacing them with
alkaline batteries when necessary. Battery life
may vary depending on battery brand.
Protect the environment by not
disposing of this product with
household waste [2002/96/EC]. Check
your local authority for recycling
advice and facilities.
1
2
3
4
6
5
© 2010 Mattel, Inc. 636 Girard Avenue, East Aurora, NY 14052, U.S.A.
Consumer Relations 1-800-524-8697. • Mattel Canada Inc., Mississauga,
Ontario L5R 3W2. You may call us free at 1-800-524-8697. • Mattel U.K.
Ltd., Vanwall Business Park, Maidenhead SL6 4UB. Helpline 01628 500303.
• Mattel Australia Pty., Ltd., Richmond, Victoria. 3121.Consumer Advisory
Service - 1300 135 312 Mattel East Asia Ltd., Room 1106, South Tower,
World Finance Centre, Harbour City, Tsimshatsui, HK, China. • Diimport
& Diedarkan Oleh: Mattel SEA Ptd Ltd.(993532-P) Lot 13.5, 13th Floor,
Menara Lien Hoe, Persiaran Tropicana Golf Country Resort, 47410 PJ.
Tel:03-78803817, Fax:03-78803867. service.mattel.com
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
• This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user’s authority to
operate the equipment.
