Mattel Asia Pacific Sourcing R3045-09A4R STUNT PSYCHO User Manual
Mattel asia Pacific Sourcing Ltd. STUNT PSYCHO
Users Manual
I.CONTENTS/FEATURES
• Vehicle
• Transmitter
Vehicle
1 ON/OFF switch
2 Battery door
3 Battery door latch
4 AA Battery adapter
5 Light-up eyes
Transmitter
A Antenna
B Battery door
C Driving controls(left button)
D Driving controls(right button)
E Turbo button
Keep these instructions for future reference: as they
contain important information. IMPORTANT: Please read
all “Consumer Information” before operating your vehicle.
CAUTION:
Surfaces may become hot and cause burns
if electronics get wet. Do not operate vehicle through water
or snow.
Asst.N4097
R3044/R3045-0920
8+
CAUTION:
To prevent entanglement,
keep hair away from wheels.
a
I
O
A
1
B
2
C
3
D
4
E
5
II.BATTERY INSTALLATION
Note: Your vehicle can be used with a Tyco® R/C 9.6V NiMH
battery pack or 6 AA alkaline batteries.
Requires a Tyco® R/C 9.6V NiMH battery pack or 6 AA
alkaline batteries for vehicle and 2 AA alkaline batteries for
transmitter.
Though your vehicle can run on both 9.6V or 6 x AA
batteries, it will run up to 30% faster when using a
9.6V rechargeable battery.
Vehicle
9.6V NiMH battery pack
1.
Rotate the battery latches, as shown, to unlock the battery
cover. Swing the battery cover up and away from the vehicle.
2. Use a screwdriver (not included) to unscrew and remove
the AA battery adapter. Store in a safe place for later usage.
3. Insert the 9.6V NiMH battery pack (not included), with
polarity (+/-) as shown inside the battery compartment .
4. Plug the wire connector into the battery compartment as
shown.
5. Replace the battery cover.
6. Turn "ON" the Power Switch.
6 AA alkaline batteries
1.
Rotate the battery latches, as shown, to unlock the battery
cover. Swing the battery cover up and away from the vehicle.
2. Make sure the AA battery adapter is firmly in place. If it’s
not, position the adapter in the box and fasten it with the
screw.
3. Insert the 6 AA batteries (not included), with polarity (+/-)
as shown inside the battery compartment .
4. Replace the battery cover.
5. Turn "ON" the Power Switch.
Transmitter
1. Remove the battery cover as shown.
2. Install 2 AA batteries (not included), with polarity (+/-) as
shown inside the battery compartment.
3. Replace the battery cover.
Your transmitter is equipped with a special
automatic ON battery-saving feature. Just turn your
vehicle ON. Then push either transmitter control to
run and control your vehicle.
9.6V d.c. NiMH, 9,6V
6XAA
It is recommended that you use at minimum
a 700mAh rechargeable battery for best
performance.
III.VEHICLE OPERATION
Eye lights are OFF when vehicle unit is switched OFF. Eye lights are ON when vehicle unit is
switched ON. Eye lights will blink when vehicle unit is in Low Voltage condition. This signal alerts
to change fresh batteries.
If your vehicle doesn't move when you use the transmitter there's a good chance your vehicle's
battery is ready for a recharge.
Pushing the two buttons forwards makes vehicle move forwards; pushing the two buttons backwards
makes vehicle move backwards.
The left and right buttons on the TX control the left and right wheels of the vehicle.
FORWARD REVERSE
LEFTRIGHT
IV.CRAZY SPINS
Pushing one button forwards while pushing the other backwards makes the vehicle spin.
V.USING TURBO
The TURBO button allows you to boost your speed but you'll need to push both controller buttons in the
same direction in order for the TURBO to be activated.
Pushing two buttons forwards or backwards and pressing turbo button at the same time can make your
vehicle fl ip over!
Please use the turbo button on the TX to guarantee the ability to perform the fl ip-over stunts. AA
battery power makes the turbo button more necessary for these high-performance stunts.
CONSUMER INFORMATION
Note to Adults: To ensure that the child’s play is both
safe and fun, please review all operating instructions
and safety rules with your child.
Safety Tips
• NEVER drive your vehicle on streets! They’re for real
cars!
• DO NOT pick up the vehicle while in motion.
• Keep fingers, hair and loose clothing away from the
tires and the wheel hubs while the vehicle is switched
ON.
• Adult supervision is recommended when this vehicle
is being operated.
• To avoid accidental operation, remove all batteries
when not in use.
Battery Performance Note:
For best performance use regular or high-performance
alkaline batteries (where disposable batteries are
called for). If your vehicle is supplied with standard
(carbon-zinc) batteries for initial use and/or
demonstration purposes, we recommend replacing
them with alkaline batteries when necessary. Battery
life may vary depending on battery brand.
VII.BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids
that can cause a chemical burn injury or ruin your
product. To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the
product before being charged (if designed to be
removable).
• Rechargeable batteries are only to be charged under
adult supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type
as recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the
product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries
inside may explode or leak.
1. When your vehicle starts to lose power, it may lose functionality or performance. It's time for fresh batteries (or
a recharge). Your vehicle's running time may change depending on your driving style.
2. Radio interference can affect your vehicle’s performance. Interference can be caused by other R/C vehicles
running on the same frequency, electrical wires, large buildings or CB radios. Try to stay away from these!
3. Point your transmitter antenna up - not down toward your vehicle. If your vehicle gets too far away, it won't
work properly. If your transmitter has an antenna carry-loop feature, make sure the antenna is removed from the
holder and straightened before operating.
4. Don’t drive your vehicle in sand or through water or snow.
5. Don’t store your vehicle near heat or in direct sunlight. Always turn switches OFF and remove all
batteries for storage.
6. After extra rough play, one or both stability bars may be knocked too far forward and out of position. To correct
this, carefully push the stability bar back down towards the rear wheel until it makes contact with the rear axle.
VI.QUICK TIPS
1 2 3
4 5 6
© 2008 Mattel, Inc., 636 Girard Avenue, East Aurora, NY 14052
U.S.A. All Rights Reserved. Consumer Relations 1-888-557-8926
service.mattel.com. • Mattel Canada Inc., Mississauga, Ontario
L5R 3W2. Retain this address for future reference Mattel U.K.
Ltd., Vanwall Business Park, Maidenhead SL6 4UB. Helpline
01628500303 • Mattel Australia Pty., Ltd., Richmond, Victoria.
3121.Consumer Advisory Service - 1300 135 312. • Mattel
East Asia Ltd., Room 1106, South Tower, World Finance Centre,
Harbour City, Tsimshatsui, HK, China. • Diimport & Diedarkan
Oleh: Mattel SEA Ptd Ltd.(993532-P) Lot 13.5, 13th Floor, Menara
Lien Hoe, Persiaran Tropicana Golf Country Resort, 47410 PJ.
Tel:03-78803817, Fax:03-78803867. service.mattel.com
Protect the environment by not dispos-
ing of this product with household waste
(2002/96/EC). Check your local authority for
recycling advice and facilities.
COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S. ONLY).
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
• This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: Changes or modifi cations not expressly approved by the manufacturer
responsible for compliance could void the user’s authority to operate the
equipment.
