Mattel Asia Pacific Sourcing W5748-12A4R RC HW BATMAN SIMPLE FUNCTION TUMBLER User Manual W5747 0920 indd
Mattel asia Pacific Sourcing Ltd. RC HW BATMAN SIMPLE FUNCTION TUMBLER W5747 0920 indd
Users Manual
Keep these instructions for future reference as they contain
important information. IMPORTANT: Please read all
“Consumer Information” before operating your vehicle.
CAUTION:
Surfaces may become hot and cause
burns if electronics get wet. Do not operate vehicle
through water or snow.
CAUTION:
To prevent entanglement, keep all hair
away from the wheels.
1 Forward
2 Reverse left
3 Battery cover
4 ON(I) / OFF(O)
W5748 TUMBLER
W5749 BAT-POD X3723 THE BAT
This set includes: 1 vehicle, 1 transmitter, 1 antenna tube.
I. CONTENTS/ FEATURES
Asst.W5747
W5748/W5749/X3723-0920
3+
®
A. Insert fl exible antenna wire through
antenna tube, then insert end of tube
fi rmly into transmitter hole.
B. Tie a knot at the end of the fl exible
antenna wire to keep the tube in place.
Antenna tube
1
2
3
3
3
3
4
4
4
OI
OI
OI
II. BATTERY INSTALLATION
(Transmitter & Vehicle)
Requires 2 AAA alkaline batteries for the vehicle and 2 AA
alkaline batteries for the transmitter. Batteries not included.
Vehicle
1. Unscrew the battery cover with a Phillips head
screwdriver (not included).
2. Your vehicle requires 2 AAA alkaline batteries.
Install with polarity (+/-) as shown inside the
battery compartment.
3. Replace battery cover and tighten screw.
Transmitter
1. Remove battery cover as shown.
2. Transmitter requires 2 AA alkaline batteries. Install with
polarity (+/-) as shown inside the battery compartment.
3. Replace battery cover and push shut.
NOTE: Once the batteries are installed the transmitter
will always be “ON” and will work automatically the
moment you use it.
III. OPERATION
FORWARD REVERSE LEFT
2 x AAA
2 x AA
2 x AAA
IV. QUICK TIPS
1 When your vehicle starts to lose power, it may lose
functionality or performance. It’s time for fresh
batteries. Your vehicle’s running time may change
depending on your driving style.
2 Radio interference can affect your vehicle's
performance. Interference can be caused by other
R/C vehicles running on the same frequency,
electrical wires, large buildings or CB radios. Try to
stay away from these!
3 Point your transmitter up - not down toward your
vehicle. If your vehicle gets too far away, it won’t
work properly.
4 Don't drive your vehicle in sand or through water
or snow. If your vehicle does get wet, wipe it with a
towel and allow to dry completely overnight.
5 Don’t store your vehicle near heat or in direct
sunlight. Always turn switches OFF and remove all
batteries for storage.
6 If the vehicle malfunctions, please turn the vehicle
and transmitter's power OFF and ON again. This
should reset your vehicle and let you resume normal
operation.
V. BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids that
can cause a chemical burn injury or ruin your product.
To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the
product before being charged.
• Rechargeable batteries are only to be charged under
adult supervision.
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the
product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries
inside may explode or leak.
Battery Performance Note:
For best performance use regular or high-performance
alkaline batteries (where disposable batteries are called
for). If your vehicle is supplied with standard (carbon-
zinc) batteries for initial use and/or demonstration
purposes, we recommend replacing them with alkaline
batteries when necessary. Battery life may vary
depending on battery brand.
VI. CONSUMER INFORMATION
Note to Adults: To ensure that the child’s play is both
safe and fun, please review all operating instructions
and safety rules with your child.
Safety Tips
• NEVER drive your vehicle on streets!
They’re for real cars!
• DO NOT pick up the vehicle while in motion.
• Keep fingers, hair and loose clothing away from
the tires and the wheel hubs while the vehicle is
switched ON.
• Adult supervision is recommended when this vehicle
is being operated.
• To avoid accidental operation, remove all batteries
when not in use.
Protect the environment by not disposing
of this product with household waste
(2002/96/EC). Check your local authority
for recycling advice and facilities.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
• This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
NOTE: Changes or modifi cations not expressly approved by the
manufacturer responsible for compliance could void the user’s
authority to operate the equipment.
©2011 Mattel. All Rights Reserved. Mattel, Inc., 636 Girard
Avenue, East Aurora, NY 14052, U.S.A. Consumer Relations
1-800-524-8697. Mattel U.K. Ltd., Vanwall Business Park,
Maidenhead SL6 4UB. Helpline 01628 500303. Mattel
Australia Pty., Ltd., Richmond, Victoria. 3121.Consumer
Advisory Service - 1300 135 312. Mattel East Asia Ltd.,
Room 1106, South Tower, World Finance Centre, Harbour
City, Tsimshatsui, HK, China. Diimport & Diedarkan Oleh:
Mattel SEA Ptd Ltd.(993532-P) Lot 13.5, 13th Floor, Menara
Lien Hoe, Persiaran Tropicana Golf Country Resort, 47410
PJ. Tel:03-78803817, Fax:03-78803867. service.mattel.com
Based on DC Comics Characters.
BATMAN and all related characters and
elements are trademarks of and © DC Comics.
