DO NOT transmit for more than 50% of total radio use time (50% duty
cycle). Transmitting more than 50% of the time can cause FCC RF
exposure compliance requirements to be exceeded.
This radio is NOT approved for use by the general population in an
uncontrolled environment. This radio is restricted to occupational use,
work related operations only where radio operator must have the
knowledge to control the user's exposure conditions for satisfying the
higher exposure limit allowed for occupational use.
When transmitting, hold the radio in a vertical position with its
microphone 1 inches (2.5 cm) away from your mouth.
The radio is transmitting when the red LED on the front of the radio is
illuminated. You can cause the radio to transmit by pressing the PTT bar
on the radio.
These are required operating configurations for meeting FCC RF
exposure compliance. Failure to observe these restrictions mean
violation.
The Federal Communications Commission (FCC), with its action in
General Docket 93-62, November 7, 1997, has adopted a safety standard
for human exposure to Radio Frequency (RF) electromagnetic energy
emitted by FCC regulated equipment. Proper operation of this radio will
result in user exposure far below the Occupational Safety and Health Act
(OSHA) and Federal Communications Commission limits.
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) This devices may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Operating Instructions
Operating Instructions
About Your SP-1000 Series Radio
Maxon's SP-1000 Series radio feature up to 16 channels. Operation and
functions for these radios are described in this manual.
Application of some of the functions described in this manual is
determined by the system you use. Your Maxon Dealer will program your
radio so that you have the greatest number of functions possible
relative to your needs.
Should you have questions regarding the operation of the radio please
consult your Maxon Dealer.
SP-1000 Series Specification
About Your SP-1000 Series Radio
SP-1000 Series Specification
Safety Information
Safety Information
Unpacking Information
Unpacking Information
The Federal Communications Commission (FCC), with its action in
General Docket 79-144, March 13, 1985. Has adopted a safety standard
for human exposure to Radio Frequency (RF) electromagnetic energy
emitted by FCC regulated equipment. Maxon subscribes to the same
safety standard for the use of its products. Proper operation of this radio
will result in user exposure far below the Occupational Safety
and Health Act and Federal Communications Commission limits.
SP-1000 Series Features
Wideband frequency separation
1 or 5 W programmable output power
Programmable 12.5/25 kHz channel spacing
Channel scan
Priority channel scan
Look back channel
CTCSS/DCS tone signaling
2-Tone Decode
Busy channel lockout
Time-out timer
Priority Channel Edit
Description of Radio Components
SP-1000 Series Features
Description of Radio Components
Antenna Receptacle
Channel Selector Switch
On/Off - Volume Control
RX/TX Indicator
Battery Latch
Push-To-Talk (PTT)
Monitor Button
Option Button
Emergency Button
Microphone
Accessory Connector (EXT Jack)
Belt Clip
Battery
Battery Charge Contacts
Speaker
Attaching and Removing the Belt Clip
Attaching and Removing the Jack Cover
To Install:
Slide the Belt Clip downward until a click is heard.
To Remove:
Pinch the inside clip and then slide the belt Clip upward.
Battery Charging and Care
To ensure peak performance from your radio, the battery pack must
be fully charged. Proper care and charging will allow maximum
performance and life of your battery pack.
Desktop Charger provides 2 hours charging to one radio and/or one
battery.
Status Indicators and Audible Alert Tones
Your SP-1000 Series has a sophisticated microprocessor control which
provides a series of audible alert tones.
Upon initial power up, a quick melody indicates that the self-test of the
microprocessor functions has been completed satisfactorily. A series of
tones may be sounded with any of the following conditions:
Attempt to transmit on a channel set for receive only
Attempt to transmit on a channel that is already in use when busy
channel lockout has been programmed into the radio *
Transmitting time has exceeded time-out timer programmed length *
Low battery condition
Selecting a channel with no programmed frequency
NOTE: All audible tones can be programmed off for silent operation.
Status Description LED color Audible Tone
Normal
Scanning
Power On - Ready
Call Received
Correct Call
Busy Channel
Transmit
Transmit not allowed
N/A
Orange
Green
Orange
Orange
Red
Red Flashing
Red Flashing
Melody
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Two beeps
Two beeps
Normal Scan mode Green Flashing
Warning Low Battery 2 beeps repeated
Busy Channel lockout 2 beeps repeated
TX Inhibit
Time-out-timer Single beep/3 beeps
repeated
Error Unlock Two beeps
Operation Mode
This section provides general descriptions of the operating modes of
the SP-1000 Series Radio.
Power Off Mode
The SP-1000 Series shall enter Off mode when the On/Off Volume
knob is rotated to the most counter-clockwise position beyond the
detent. Upon entering Off mode, the radio shall store its current
channel (if Power On Channel function is disabled via PC programmer).
Power On Mode
The SP-1000 Series shall enter Power-On mode when the On/Off
Volume knob is rotated clockwise beyond the detent. Upon entry of
the Power-On mode, the radio shall perform the 1 time power-on
alert to indicate that it has been turned on
High / Low Power
The radio shall be capable of programmable output power.
Each channel can be programmed via pc programmer to have either
high or low power. It can also be set by pressing the option button.
Cloning
Frequencies and functions can be programmed from radio to radio by
using a cloning cable.
If the password function is enabled, the user must enter a password for
the radio to become operational.
You can enable the password and set the password code by using the
PC programmer. You can also set the password enable/disable by a
programmable key (password and menu option). At this time you can
enter the password code by using the EMG/PTT/MON/OPTION button
in the correct sequence. Four button presses are required to enter the
code. If the code is not correct, the LED will blink red and there will be
a double beep repeated. To disable the password function, you can
select On/Off by using the PC programmer. The default is disabled.
Password
Fixed Key
PTT
Press and Hold to transmit. Release to receive mode.
Power on with press and holding PTT Key to see software version
MONITOR
Releases the squelch and tone circuit to check whether the channel is
busy.
(OPTION)
Short pressing: Enable/Disable Scan
Look Back channel edit
Tx power H/L
EMG
Transmit EMG ID 5 times and generate warning audio alert during
seven seconds
Licensing and Service Information
FCC Licensing
The Federal Communications Commission requires that the operator of
this radio be properly licensed under the applicable Part and/or Parts
of the FCC Rules and Regulations.
Consult with your Maxon Dealer, or contact the nearest FCC Field Office
for information about obtaining a license.
Service
Do not tamper with internal adjustments. Damage to the equipment
and/or improper operation may result. There are no user serviceable
items inside the radio. It is recommended that you return your radio to
a qualified Maxon Dealer for any service or repairs.
Recycling/Disposal of Batteries
The battery should be recycled at the end of its useful life. Under
various state or local laws, such batteries must be recycled or disposed
of properly and cannot be dumped in landfills or incinerators.
For further information on how to safely dispose of your used batteries
,contact your Maxon Dealer.
Software Copyrights
The Maxon products described in this operating instruction manual
may include copyrighted Maxon software programs stored in semi-
conductor memories or other media. Laws in the United States and
other countries preserve for Maxon certain exclusive rights for copy-
righted software programs, including the exclusive right to copy or
reproduce in any form the copyrighted software program. Accordingly,
the copyrighted Maxon software programs contained in the Maxon
products described in this operating instruction manual may not be
copied or reproduced without the express written permission of
Maxon. Furthermore, the purchase of Maxon products shall not be
deemed to grant either directly or by implication , estoppel, or
otherwise, any license under the copyrights, patents or patent
applications of Maxon, except for normal non-exclusive royalty free
license to use that arises by operation of law in the sale of a product.
Maintenance
Your SP-1000 Series Radio is designed to be maintenance free. To
keep your radio in good working condition:
Clean external surfaces with a clean cloth dampened in a solution of
dishwasher detergent diluted in water. Apply the solution sparingly to
avoid any moisture leaking into cracks and crevices. Do not submerge
the radio. Use a non-metallic brush to dislodge stubborn particles, if
necessary. Dry the surface thoroughly with a soft, lint free cloth.
DO NOT use solvents or spirits for cleaning - they may permanently
damage the housing.
Clean the battery contacts on the back of the radio with a lint free
cloth to remove dirt, grease, or other foreign material that may impede
good electrical contact.
Limited Warranty
Maxon shall have no obligation to make repairs or to cause replacement
required which result from normal wear and tear or necessitated in
whole or in part by catastrophe, fault or negligence of the user,
improper or unauthorized alterations, repairs to the Product, use of the
Product in a manner for which it was not designed, or by causes
external to the Product. This warranty is void if the serial number is
altered, defaced or removed.
The CHL-100L is Regular Charger for Maxon's SP-1000 Series Two-way
radio batteries.
The charger has been designed to fully charge only the Li-Ion, 1500mAh
battery, the front charging slot charges a battery while connected to the
radio, the back charging slot charges a battery that has been removed
from the radio.
Plug the AC adapter cable into the adapter jack locked on the rear of
charger.
Plug the AC adapter into an AC outlet
Charging starts automatically when the radio equipped with battery is
in place. The charging time is approx 10 hours or less, depending upon
the leftover capacity, current charge status of the battery
NOTE: If your battery seems to have no capacity even after being fully
charged, completely discharge them, then fully charge them again. If
they still do not retain a charge, new batteries must be purchased.
Charger.
To reduce the risk of shock or injury, familiarizes you with the proper
and safe operating procedures defines in this manual. Only charge
Maxon's battery in this charger - other battery types may burst causing
personal injury/or damage to the charger, battery or radio.
The CHL-100L desktop charger is rated for indoor use only.
Do not disassemble the charger, incorrect reassembly can cause fire or
electric shock.
Do not pull output plug with excessive force.
Do not use the charger when it is covered by objects which impede
heat dispersal.
Connect the supplied Maxon adapter only to the voltage supply as
specified on its label.
Unplug the AC adapter from wall outlet before attempting inspection
or cleaning of the charger.
Do not use solvents such as benzene or paint thinner to clean the
charger.
THE EXPRESS WARRANTIES CONTAINED HEREIN ARE IN
LIEU OF ALL OTHER WARRANTIES, EITHER EXPRESSED OR
IMPLIED OR STATUTORY, INCLUDING, WITHOUT LIMITATION,
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
FOR ANY PRODUCT WHICH DOES NOT COMPLY WITH THE
WARRANTY SPECIFIED, THE SOLE REMEDY WILL BE
REPAIRED OR REPLACEMENT. IN NO EVENT WILL MAXON BE
LIABLE TO THE BUYER OR ITS CUSTOMERS FOR ANY
DAMAGES, INCLUDING ANY SPECIAL, INCIDENTAL, INDIRECT
OR CONSEQUENTIAL DAMAGES, OR FOR THE LOSS OF
PROFIT, REVENUE OR DATA ARISING OUT OF THE USE OF OR
THE INABILITY TO USE THE PRODUCT.
User Instruction Manual
User Manual
User Instruction Manual User Instruction Manual User Instruction Manual User Instruction Manual User Instruction Manual
User Instruction Manual User Instruction Manual User Instruction Manual User Instruction Manual User Instruction Manual User Instruction Manual User Instruction Manual User Instruction Manual
2 3 4 5 6 7
10 11 12 13 14 15 16 17
User Instruction Manual
18
User Instruction Manual
19
User Instruction Manual
20
1
FCC Notice
FCC RF EXPOSURE COMPLIANCE REQUIREMENTS FOR
OCCUPATIONAL USE ONLY
We urge you to thoroughly read this manual before operating the
radio.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
!
!
1 12 13 142 3
4 10
11
15
5
6
7
8
9
To Install:
Affix the jack cover by a screw until the screw is fully tightened.
To Remove:
Loosen the screw until the jack cover is detached from the radio in
order to use any accessory for SP-1000
1
1
1
2
2
WARNING -
WARNING -
CAUTION -
CAUTION -
DO NOT hold the radio in such a manner that the
antenna is next to, or touching, exposed parts of the
body, especially the face or eyes, while transmitting.
DO NOT allow children to operate transmitter -
equipped radio equipment.
DO NOT operate the radio near unshielded electrical
blasting caps or in an explosive atmosphere unless it is
a type especially designed and qualified for such use.
DO NOT press and hold the transmit switch (P-T-T)
when not actually wishing to transmit
NOTE: This radio operates in FCC regulated frequency bands. All radios
must be licensed by the FCC before use. Because this radio contains a
transmitter, federal law prohibits unauthorized use or adjustments of
this radio.
Operating instruction
Safety information
Orientation
Product description
MODEL SP-1402SP-1102
EQUIPMENT TYPE Hand-portable
PERFORMANCE SPECIFICATIONS TIA/EIA-603
BAND UHF(440~470MHz)VHF(148~174MHz)
CHANNEL SPACINGS 12.5kHz / 25kHz PROGRAMMBLE
RF OUTPUT POWER 5 / 1 WATT
MODULATION TYPE F3E
AUDIO POWER 500mW ( EXT WITH 8 OHM)
1W ( INT WITH 4 OHM)
INTERMEDIATE FREQUENCIES 45.1MHz
455kHz
CHANNELS 16 Channel
FREQUENCY SOURCE SYNTHESIZER
POWER SUPPLY Li-Ion(1500mA)
7.5 VDC NOMIN
+/- 10% VDC EXTRE
BATTERY ONLY
Indicates a function that is initially programmed into the radio by
your Maxon Dealer.
2
2
PUSH
Antenna Installation
Fasten the antenna to the radio by turning the antenna clockwise into
the receptacle on top of the radio
Installing and Removing the Battery Pack
To Install:
Connect the bottom of the battery to the rear and bottom of radio and
fold it into the radio until a click is heard.
To Remove:
Press the button on the top of the battery and pull the battery out from
the Radio.
User Instruction Manual User Instruction Manual
8 9
1
11
1
2
2
2
2
NEVER HOLD by the antenna when carrying the transceiver.
Transmitting without an antenna may damage the transceiver.
!CAUTION
PUSH
PUSH
1
Antenna Installation
Installing and Removing the Battery Pack
Attaching and Removing the Belt Clip
Attaching and Removing the Jack Cover
Battery Charging and Care
Status Indicators and Audible Alert Tones
Operation Mode
Power Off Mode
Power On Mode
High / Low Power
Cloning
Password
Fixed Key
PTT
MONITOR
EMG
Licensing and Service Information
FCC Licensing
Service
Recycling/Disposal of Batteries
Software Copyrights
Maintenance
Limited Warranty
3
3
3
4
5
6
7
8
9
10
10
11
12
13
13
13
13
13
13
13
14
14
14
15~17
CHL-100L Desktop Regular Charger 18~20
15
15
15
16
16
17
2
CHL-100L Desktop Regular Charger
Lighting color
Plug the AC adapter cable into the adapter jack located on the rear of the
Plug the AC adapter into an AC outlet.
Your charger is now ready to begin charging
Remove the charger base and AC adapter from packaging.
Description
Red
Green
Blinking orange
During charging
Fully charged
Error
Extreme cold(under -10 C; 14 F)
Extreme heat(over +60 C; 140 F)
Blinking red
MEMO
Remove and carefully inspect the contents of your package(s) for the
following items:
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
Battery Pack
Battery Charger
Spring Belt Clip
Antenna
Battery Charger Power Supply
Operating Instructions
8Jack Cover
If any items are missing, please contact your Dealer or Maxon.
Radio
LED
SP-1000 Series
MAXONCIC Corp.
Chongho Bldg, #7-6, Yangjae-Dong,
Seocho-Ku, Seoul, Korea
Tel : +82-2-3498-3114
Fax : +82-2-3498-3113
www.maxoncic.com
"Professional Radio Products"
