MAYTAG® COMMERCIAL

ENERGY ADVANTAGE™

SOFT-MOUNT, HIGH-SPEED

EXTRACTOR

NEW CHEMICAL INJECTION SYSTEM

Designed to make chemical installation faster,

simpler and more precise, the new Maytag®

Commercial Laundry Chemical Injection

System features easy-access connections on

the outside of the machine. This eliminates

the need for having to open up the washer

on routine visits. The new system also

provides chemical supply companies and

the machine’s users with clear visibility on

how detergent, bleach, softener and other

chemicals are being dispersed.

MFS50/80PNF

CLP751

Model MFS80PNF shown.

MICROPROCESSOR CONTROLS

Maytag® microprocessor controls offer 15

preprogrammed cycles, plus the capability

to create multiple unique cycles. Also,

one-touch cycle selection and multilingual

readouts make these controls easy for

everyone to operate.

BIG-LOAD PERFORMANCE,

FLEXIBLE INSTALLATION

Maytag® soft-mount, high-speed extractors

feature a suspension system that allows for

more flexibility and does not require special

foundations for installations.

FOR YOUR OPERATION:

• Inverter Drive Technology For Longer Life

• Up to 365 G’s In Final Spin*, Reducing

Dry Time

• Easy-To-Operate Microprocessor

Controls

• Adjustable Water Temperatures

And Levels

• Manual 5-Bay Detergent And

Softener Dispenser

• Ability To Use Powdered Or Liquid

Chemical Supply

• 8 Chemical Supply Signals

• Two Extra-Large Drain Valves On MFS80

For Faster Draining

• Extra-Large Door And Handle

BUILT-TO-LAST™ FEATURES:

• Heavy-Duty Latch And Door Handle

• Durable Sealed Bearings

• Rugged Frame And Cabinet

• Easy Service Access

* Model MFS80PNF only. Model MFS50PNF

spins up to 310 G’s.

SPINS

UP TO 350G’s

TO EXTRACT MORE WATER

E

A

S

Y

T

O

U

S

E

NEW

EXTERNAL

HOOKUPS

FOR CHEMICAL

INJECTION

MG-06079_CLP751_SpecSheet.indd 1 7/11/07 9:25:24 AM

#

$

3)$%6)%7

!

"

&2/.46)%7

%,%#42)#!,

0/7%2

#/..%#4)/.

$2!).

/54,%43

"!#+6)%7

7!4%2

#/..%#4)/.3

#(%-)#!,

3500,9

3)'.!,3

#(%-)#!,

3500,9

(//+50

www.maytagcommerciallaundry.com

7/07

MAYTAG® LIMITED

WARRANTY

2 YEARS — ALL PARTS

5 YEARS — SHELL,

WELDED FRAME ASSEMBLY,

BASKET, SHAFT ASSEMBLY,

BEARINGS AND SEALS

For a period from the date of original purchase

through the times listed above, the designated

parts that fail in normal commercial use will be

repaired or replaced free of charge for the part

itself, with the owner paying all other costs,

including labor, transportation and customs duty.

Chemical damage is excluded from all warranty

coverage. See complete warranty for details.

*Single Outlet: MFS50PNF

Maytag® Energy Advantage™

Soft-Mount, High-Speed Extractor

MICROPROCESSOR CONTROL

Energy Advantage™

Soft-Mount, High-Speed Extractor

WASHER SPECIFICATIONS

MODEL MFS50PNF MFS80PNF

MOTOR

Inverter drive • •

Variable speed • •

HP (kw) 3 (2.2) 5.5 (4)

Voltage 208 – 240V

Three-Phase

208 – 240V

Three-Phase

BREAKER SIZE — amps 15 30

SPEED

Wash speed — rpm 42 38

Extract speed — maximum rpm 860 830

Extract speed — maximum g-force 310 350

WATER INLET/HOSE

Water inlet — in. (mm) .75 (19) 1 (25.4)

Operating pressure — psi (mpa) 43 – 73 (0.3 – 0.5) 43 – 73 (0.3 – 0.5)

Drain size — in. (mm) 3.0 (76) O.D. 2x3.0 (76)O.D.

CAPACITY

Lbs. (kg) 50 (22) 80 (33)

Cylinder volume — cu. ft. (liters) 7.8 (221) 11.8 (334)

Cylinder diameter — in. (mm) 29.5 (750) 36 (914)

Cylinder depth — in. (mm) 19.7 (498) 20 (510)

CABINET

Stainless Steel • •

APPROXIMATE WEIGHT

Crated — lbs. (kg) 1829 (830) 3020 (1370)

Uncrated — lbs. (kg) 1631 (740) 2712 (1230)

DIMENSIONS

A) Height — in. (mm) 64.57 (1640) 75 (1905)

B) Width — in. (mm) 38.78 (985) 47.04 (1195)

C) Depth — in. (mm) 36.10 (917) 48.11 (1222)

D) Depth including door handle and air vent

on back — in. (mm)

45.66 (1160) 52.4 (1330)

Door Opening — in. (mm) 16.1 (410) 21.3 (540)

See specific instructions for proper installation. Because of continuous product improvement,

Maytag reserves the right to change specifications without notice.
