Maytel TELME-IT Tour Guide Transceiver(Wireless Digital Microphone) User Manual
Maytel Co., Ltd Tour Guide Transceiver(Wireless Digital Microphone) Users Manual
Maytel >
Users Manual
Radio Frequency Type
ISM 2405~2477MHz
Type
Wireless Microphone/Receiver Unit
Radio Interface
ISM 2.4GHz FSK Modulation with
Frequency Hopping
Voice Codec
16bit/24KHz
RX Sensitivity
-95dBm
Voice Latency
<30ms
Number of Frequency Channel
145ch
Channel Spacing
500KHz
Data Rate
2Mbps
Frequency Bandwidth
2MHz
Battery
Li-ion Battery @3.7V/TBD 1100mA
Antenna
Internal Chip Antenna (Gain: 0dBi)
Talk Time for Microphone
10hr Typ.
Power Consumption
Avg. 100mA
Distance Range(LOS)
100M
Frequency Response
50Hz~4KHz
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
Operation is subject to the following two conditions; (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
CAUTION : Changes or modifications not expressly approved
bythe party responsible for compliance could void the user’s
authority to operate the equipment.
FCC Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rul es. These limits are de signed to pro vide reasonable
protection against harmful interference in a re sidential installation. This equip ment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will n ot occur in a particular installation. If this equipme nt does
cause harmful interference to radio or televi sion reception, which can be det ermined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receive r is
con-nected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution
Modifications not expressl y approved b y the p arty responsible for compliance could void the
user’s authority to operate the equipment.
FCC Compliance Information : This device complies with Part 15 of the FCC Rul es.
Operation is subject to the following t wo conditions: (1) Thi s device may n ot cause harmful
interference, and (2) this device mu st accept any interfere nce received, including interference
that may cause undesired operation
IMPORTANT NOTE:
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation e xposure limits set forth fo r an un controlled
environment.
The antennas used for thi s transmitter must be installed to provide a separation distance of at
least 5mm from all perso ns and must not be co-located or operating in conjunction with any
other antenna or transmitter.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this equipment near water.
6) Do not u sing near any heat sources su ch as radiators, heat resi sters, stove, or other
equipment that produce heat.
European CE notice to users and product statements
This product is CE marked accordi ng to the provis ions of the R&TT E
Directive(2014/53/EU). Hereby, Maytel Co., Lt d declares that this product
is in com pliance with the essentia l requirements and other relevant
provisions of Directive 2014/53/EU.
For further information, please contact http:// www.maytel.com
Maytel Co., Ltd
#417 Doosan Venture Digm 126-1, Pyeongc hon-dong, Dongan-gu, Anyang- si,
Gyeonggi-do, Republic of Korea
Tel: +82-31-478-5508
Fax: +82-31-440-9331
URL: www.maytel.com
CONTACT INFORMATION
Manufacturer Address #417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si,
Gyeonggi-do, Republic of Korea
To locate in-country MAYTEL CO., LTD., distributors of the Tour Guide Transceiver(Wireless Digital
Microphone) please refer to the MAYTEL CO., LTD. Website http:// www.maytel.com
These distributor(s) represent local contacts for this product.
CORPORATE HEADQUARTERS:
MAYTEL CO., LTD.
#417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea
Tel: +82-31-478-5508
Fax: +82-31-440-9331
Web: http:// www.maytel.com
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is Subject to the following two condition: (1) this device may not cause interference
,and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
EUROPEAN UNION “DECLARATION OF CONFORMITY”
DECLARATION OF CONFORMITY
MAYTEL CO., LTD.
#417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea
declare under our sole responsibility that the product(s)
Tour Guide Transceiver(Wireless Digital Microphone) – TelMe-IT
to which this declaration relate(s) is in conformance with the following standards:
EN 301 489-1 V1.9.2:2011
EN 301 489-17 V2.2.1:2012
EN 60950-1:2006/A2:2013
EN 300 328 V1.9.1:2015
following the provisions of the 2014/53/EU Directives.
