Maytronics 99956BT BLE communication Transceiver Module User Manual Users manual

Users manual

User’sinstructionstousetheBluetooth®communicationinordertooperateMyDolphin™applicationfeatures.

“ContainsFCCID:WCH99956BT“.

 Connecttherobot’spower‐supplytothemains.

 ConnectyourSmartphonetotheinternet,anddownloadMaytronicsMyDolphin™applicationfromAppleor

AndroidAppStore,accordingtotherelevantSmartphone.

 “Userauthenticationprocedure”:

Pleaseentertheapplication,clickontherobotthatappearsontheSmartphonescreen(serialnumber)

 ProceedtoBluetooth®pairingonyourSmartphone.

TheSmartphoneIdentifiestherobotandinitiatesapairingsequence.

NowthestrongsignaltransmittercommunicatesremotelywiththepowersupplyviaBluetooth®.

 Mainscreenwindowshowsoperationalstatusandinformation,includingremainingcycletimeandselected

cleaningmode.

 Buttonsonlowerhalfofthescreenrepresenttheavailableoperationalmodes:cleaningmode,manualdrive,cycle

time,weeklytimer,info/links,anddelaymode.

Choosethemodeyouwanttooperate.

 Cleaningmode:

Youcanchoosebetweendifferentoperationoptionssuchas:

FloorOnly,Regularmodeorothers.

 ManualMode:

Tomanuallycleanspecificareasofyourpool.

YoucanalsoswitchtoTiltmodeforarealisticexperience.

 CleaningCycleTime:

Youcanchoosebetweendifferentcleaningcycletimes.

 WeeklyTimer:

Usethismodetochoosethedaysandhoursduringtheweekthattherobotwilloperate.

 DelayMode:

Usethismodetodelaythestartoftherobotoperation.

 YoucanexittheapplicationbytouchingtheXontheSmartphoneupper‐leftscreenandchoosingOKtoclose

“MyDolpin™”



 User’sinstructionstousetheRFcommunicationinordertooperatefeatures.

 “ContainsFCCID:WCH99956BTRF“.

 “ContainsFCCID:WCH99956BT“.

 Connecttherobot’spower‐supplytothemains.

 PowerONtheRCU.UsingtheRCUwillactivatetheRFcommunication.

 ChoosefromtheRCUmenupertheuser'smanualthefunctionsyouwanttooperate
