MeiDong Acoustics MD-01 Bluetooth Speaker User Manual
Shenzhen MeiDong Acoustics Co., Ltd. Bluetooth Speaker
User manual
User’s Guide
1. Introduction
2. Battery Precautions
3. Getting Started
4. Bluetooth Connection
5. Function Guidance
6. LED Display Status
7. Microphone Usage
8. Battery Charging
9. Product Care
Please read the following safety warning and precaution before using your device.
Contents
-1-
Power supply: Li-ion battery or USB cable
Audio source: iPhone, iPad, Smartphone, Notebook, MP3, MP4, etc
Function spec: Bluetooth, Microphone, Line-in
Size: 89.5mm x 74mm x 27mm
Rechargeable battery with charging from USB cable
-2-
1. Introduction
Thank you for purchasing the MD-01, this device can be easily connected
with smartphone, Tablet PC and other devices via Bluetooth during your
outdoor activities or other daily use. It will bring you an easy lifestyle.
Specifications
MD-01
Output Power: 3W
Frequency range: 2402MHz-2480MHz
2. Battery Precautions
The device can be powered by a built-in rechargeable lithium battery. Please
charge the battery for at least 8 hours before your first use of device.
If the device is not used for a long period of time, the battery may be out of
power. Please charge the battery.
Rechargeable battery is only to be charged under adult supervision.
Only use the supplied USB cable to charge the battery. Improper charging
may damage the battery and the device.
Do not attempt to open the rechargeable battery or battery pack. There
aren't serviceable parts inside.
Should a battery leak, the device may become damaged. Clean the battery
compartment immediately, avoiding touching your skin.
Keep the battery out of reach from children. If swallowed, consult a
physician immediately.
Avoid storing the battery in extremely hot or cold environment. A device
with a hot or cold battery may not work temporarily, even when the battery
is fully charged.
Do not dispose battery in a fire as it may explode. Battery may also explode
if damaged. Please dispose it according to local regulation. Do not dispose
it as household waste.
-3-
3. Getting Started
-4-
Long Press/Volume Down
Short Press/Previous
Short Press/Next
Long Press/Volume Up
Play/Pause/
LED
MIC
AUX/BT button
USB port
Answer/End a call
-5-
Notice:
4. Bluetooth Connection
Pair MD-01 to your tablet or smartphone.
1.
2.
3.
4.
5.
6.
7.
Activate pairing mode on MD-01 by switching”AUX/BT” button to “BT”.The
LED will flash in blue color.
On your device, navigate to the Bluetooth function (refer to the tablet
owner’s manual to locate Bluetooth function).
Select “Set Up” Bluetooth and turn “ON” Bluetooth.
Select “Search” and “Discover” devices.
Select “MD-01”.
If requested, type the password 0000.
Press the Enter key.
After completing the steps above, a message on your tablet will appear to
confirming that your device is now paired/connected.
In case of unsuccessful pairing, turn off it and restart it to "BT", then do as
steps above.
1.If you turn off the device, but the Bluetooth on your smart phone remains
open, when you restart the device, the Bluetooth will be connected
automatically.
2.When your smartphone and this speaker are apart beyond bluetooth
receiving range, after 10 minutes, this speaker will disconnect with your
smartphone and turn into pairing mode. If within 10 minutes your smartphone
is back, will connect with this speaker automatically.
3.If long press “ ” buttom, the speaker will be disconnected and ready to
pair with other smartphones.
-6-
6. LED Display Status
7. Microphone Usage
5. Function Guidance
Function
Volume up/ Next song
Play music from your MD-01.
Volume down/ Previous song
Play/Pause/Answer/End a call
Button
When a phone call comes in, you could talk through the microphone on
speaker.
Two short press the pause button, you could call the last number you called
on your call records.
LED Display
Flash slowly
Stay solid
Stay solid
OFF
Light indication
It’s ready to pair
It's paired
charging in process
Fully charged
Blue
Light
Red
Light
8. Battery Charging
9. Product care
-7-
The device has a built-in rechargeable lithium battery that can be charged by
connecting to the USB port of your computer. When it’s charging, the light will
turn to red.
After charging, the device can be used without the power connection.
Your device is designed to be light, compact and durable. As an electronic
device, it must be treated carefully. Putting unnecessary pressure on it or
striking the device against other objects may cause damage. To avoid
damage to your device please
Do not drop, crush, bend or apply excessive force to the device.
Do not expose your device to moisture, extreme or prolonged heat, cold,
humidity, or other adverse conditions. Avoid storing it in damp, humid or
wet places, as it is not waterproof.
Clean the unit with a soft cloth or damp chamois leather. Never use
solvents.
The Unit can Only be opened by qualified personnel.
This device contains magnets. Keep magnetic field sensitive products
such as credit cards and video screen away from this device to avoid
damage or malfunction.
FCC Warning:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device c
an be used in portable exposure condition without restriction.
