Installation and Operation Instructions for the Wireless Counter/Temperature.
Point Six, Inc.
Wireless Counter/Temperature Sensor
Model Point Sensor Counter/Temperature
Installation and Operation Instructions
The Point Sensor Counter/Temperature sensor transmits a digital temperature, relative-
humidity (or light level) and a unique serial number to a 418 MHz receiver. The Point
Sensor Counter/Temperature is enclosed in a high impact ABS enclosure for direct
surface mounting in the environment to be measured. The Point Sensor
Counter/Temperature is battery operated.
Application: Apply the sensor to the surface to be monitored with double-sided
adhesive tape. Make sure that the side labeled with FCC ID is visible and away from any
metal surfaces.
Service Function: The wireless sensor has an installation mode switch. A momentary
push of this switch will start the convert/transmit cycles. When new and until this button
is pushed the Point Sensor Counter/Temperature will not transmit. The Point Sensor
Counter/Temperature will transmit a special installation status mark in the data packet
immediately after the installation/start switch is pushed. After the start a push of the
installation switch will result in the immediate transmission of temperature, counter, ID
and installation status mark.
Battery: A 3.6 Volt lithium battery powers the Point Sensor Counter/Temperature
wireless sensor. The battery will last for more than 10 years in the idle state (as shipped
from the manufacturer). The Point Sensor Counter/Temperature will transmit data for as
long as 5 years at a rate of once each minute once started. The Point Sensor
Counter/Temperature is completely covered with a water resistant conformal coating to
protect the electronics from the environment and condensation. The user can replace the
battery. The Point Sensor Counter/Temperature may be placed in a quiescent state
(battery life greater than 10 years) by holding the installation switch closed for more than
4 seconds.
FCC ID: M5ZCNT
Wireless Sensor Data Format
The Point Six, Inc. 418 MHz wireless analog transmitters require a compatible receiver
with the ability to receive, error check and provide RS232 and RS422/485 interface. This
document describes the data format provided by the Point Host 418 MHz. Receiver.
The transmit packet from a receiver is approximately 15 milliseconds in duration and
consists of 13 bytes of data:
1-byte ID/Mode field
8-byte serial number
12-bit analog in a 16 bit word
2-byte CRC-16 error check
The Point Host receiver receives and processes this packet. The receiver performs a
CRC-16 error check on the packet. If the data is not accurate it is discarded. When a
packet is received that is error free it is converted to a 29-character packet and
transmitted out the serial port at 19,200 Baud. The data is transmitted serially in ASCII
Hex format and terminated with a CR character. This format requires two bytes for each
byte of data; 14 data bytes x 2=28 plus the CR is 29 characters
The resulting binary data format of the packet is:
1-byte ID field this field will contain a byte whose LSBit indicates the service
state of the transmitter, 0=normal, 1=service mode. Note that the
CRC-16 is calculated with the MSBit of the ID field set low, the
data is received with the MSBit of the ID field set high. Proper
CRC-16 calculation requires that the MSBit be assumed to be low
even though it is received set high.
8-byte serial# this field contains the serial number of the 1-Wire sensor.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES, OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY
NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT
ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESERED OPERATION
FCC ID: M5ZCNT
MADE IN USA
FCC ID: M5ZCNT
16-bit data field this field contains 12-bit analog data stored in stored MSByte first
in 12-bit form
this field is unsigned and has a range of 0 to 4095 (0000-0FFF)
hex.
2-byte CRC-16 this is the originally received data packet CRC-16 as described
above.
1-byte checksum the checksum is a mod 256 sum of all the ASCII character values
in the response but does not include the CR; the checksum is added
by the HA8 and is not a part
of the transmitted data.
Form: “CountTemp” Wireless Counter/Temperature Transmitter
IDSSSSSSSSoooooottttLLCCCCKK<CR>
Note: All fields are in ASCII Hex
“ID”
The device type field: CountTemp has device type 61 hex. A 60 hex when in service
mode.
“SSSSSSSS”
The MS-30 bits of these 4-bytes are the serial number of the CountTemp. The LS-2 bits
are the status flags for the open and closed switch input status. The LS bit (bit-0) is
the Open status flag and the next most significant bit (bit-1) is the Closed status flag.
“oooooo”
This 24-bit field is the Open counter stored LS-byte first. Count of switch openings.
“tttt”
This top 16 bit of this 24-bit field is Temperature in two’s compliment 16-bit data stored
MSB first in 1/16 deg. C units. The least significant 8 bits of the 24-bit field are zero.
“LL”
This field is unused and will always read zero.
“CCCC”
This field is the CRC-16 error check as was originally received and checked. This CRC
is over the first 11 bytes of the packet starting with the device type and ending with
inclusion of the “cccccc” data.
FCC ID: M5ZCNT
“KK”
This field is the mod 256 sum of all the binary data values as represented by the ASCII
hex values in the response but does not include the <CR>.
