Installation and Operation Instructions for the IR Proximity Counter.
Point Six, Inc.
Wireless IR Proximity Counter Model IRPROX2
Installation and Operation Instructions
Description
The new IRPROX2 people counter has a battery life of >2years. The pushbutton on the sensor has the following
functions:
Power Down:Press and hold the button for > 8 Seconds.
Test power state:Press briefly; LED comes on to indicate power down state.
Power Up : Press for >2 seconds and <8 seconds, LED goes out.
Transmit service packet:Briefly press while powered up.
IR Program:Press and hold the button for >8 seconds while sending IR program parameter commands from IR
transmitter attached to the serial port of a PC running Prox-Programmer software. When an IR command is properly
received and processed the LED will flash to indicate success.
This model has IR ranges of 6,4,3 and 2 feet, switch selectable.
The IR programmability includes:
In-beam time in ¼ second steps to 255 steps. Default: ¼ second.
Out-of-beam time in ¼ second steps to 255 steps. Default: 1 second.
Blocked beam time in ¼ second steps to 255 steps. Default: 16 seconds.
LED flash enable/disable during count. Default: LED flash.
Packet type enable/disable for automatic inclusion of the switch data in a new device type, type "09" the standard
people counter is type "11"
Note: IR programmed parameters are stored in EEPROM and are not lost when replacing the battery.
Note: the LED flashes at other times as normal even if disabled to flash during count.
Note: The packets are micro-randomized for 10 seconds +- 7 (1/4) second intervals.
Point Six, Inc. 2333 Alumni Park Plaza - Lexington, KY - 40517- http://www.pointsix.com - 859-266-3606 - Fax 859-266-0702
2
Packet Description
IDSSSSSSSSooooooccccccCCCCKK<CR>
Note: All fields are in ASCII Hex
“ID”
The device type field: “2CountRange” has device type 9 hex. A 8 hex when in service mode.
“SSSSSSSS”
The MS-30 bits of these 4-bytes are the serial number of the sensor. The LS-2 bits are the status flags for the open and
closed limit switches. The LS bit (bit-0) is the Open switch flag and the next most significant bit (bit-1) is the Closed switch
flag.
For the Point Sensor IR Counter(Old) and Point Sensor IR Proximity Counter,the status bits have the following meaning:
Bit 1 Bit 0 State
0 0 Blocked
0 1 Open
1 0 Closed
1 1 Error
“oooooo”
This 24-bit field is the Open counter stored LS-byte first.
“cccccc”
THE LOWER 22-BITS OF THE 24 BITS IS A DURATION COUNTER STORED LS-BYTE FIRST.
THE DURATION COUNTER COUNTS THE NUMBER OF SECONDS THE BEAM IS OPEN (IN
SECONDS). THE TOP 2 BITS (BITS 23 & 24) ARE USED IN INDICATE THE TYPE OF RANGE.
Bit 1 Bit 0 State
0 0 Range1
0 1 Range2
1 0 Range3
1 1 Range4
“CCCC”
This field is the CRC-16 error check as was originally received and checked. This CRC is over the first 11 bytes of the
packet starting with the device type and ending with but not including CRC-16.
“KK”
This field is the mod 256 sum of all the binary data values as represented by the ASCII hex values in the response but
does not include the <CR>.
Point Six, Inc. 2333 Alumni Park Plaza - Lexington, KY - 40517- http://www.pointsix.com - 859-266-3606 - Fax 859-266-0702
3
In Beam :
Select the desired in beam time requirement in ¼ second units to a max of 255 units.
Out of Beam :
Select the desired out of beam time requirement in ¼ second units to a max of 255 units.
Blocked Time:
Select the desired blocked time requirement in ¼ second units to a max of 255 units.
Include Switch Data:
Packet type enable/disable for automatic inclusion of the switch data.
YES= type "09", NO=type “11” (see packed definition above).
Note: changing device type will result in a changed serial number; two devices cannot be allowed to exist with identical
serial numbers so when the device type is reprogrammed the serial number will be automatically changed as well.
Allow LED to Flash on Count:
Yes= LED will flash when people count advances. No= LED will not flash when people counter advances.
IR Program:
Press and hold the proximity sensor pushbutton for >8 seconds, aim the IR program transmitter at the Proximity IR sensor
while clicking on the IR Program button. The LED on the proximity will flash to indicate success. Note: the proximity
sensor will be in power down mode after an IR programming event.
FCC ID: M5ZIRPROX2
MADE IN USA
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES, OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY
NOT CAUSE HARMFUL INT
ERFERENCE AND (2) THIS DEVICE MUST ACCEPT
ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESERED OPERATION
