Installation and Operation Instructions for the IR Point Sensor
Point Six, Inc.
IR Point Sensor
Installation and Operation Instructions
Description
The IR Point Sensor is a battery operated infrared beam People Counter with a 418 MHz radio transmitter. The
sensor consists of two parts; the IR transmitter and the IR receiver. The IR receiver has an integrated 6-digit LCD
counter and a radio transmitter for truly wireless installation and operation. The IR transmitter produces 16 pulses of
high intensity IR each second across a distance of up to 20 feet. The nature of these IR pulses is such that the IR
receiver can distinguish them from any other source of IR. This characteristic allows the IR sensor to operate in
almost any environment without interference from ambient lighting.
The IR Point Sensor is designed to require very little energy; the internal 3.6 Volt Lithium batteries will operate the IR
counters for up to 2.5 years in normal operation.
The service switch on the IR People provides several user functions. A momentary press of the service button on the
IR People will turn the display on to allow reading the counts. Pressing and holding the service button on the IR
People will reset the counts to zero. Pressing and holding the service button for 8 seconds will reset the battery fuel
gauge.
The IR Transmitter and IR Receiver are powered on by an On/Off switch. There is an additional switch that allows the
user to the put IR Point Sensor in either front-firing or side-firing mode of operation.
Point Six, Inc. 161 Prosperous Place - Lexington, KY - 40509- http://www.pointsix.com - 859-266-3606 - Fax 859-266-0702
2
Packet Description
X2 Object Counter” (11/10)
IDSSSSSSSSooooooffggggCCCCKK<CR>
Note: All fields are in ASCII Hex
“ID”
The x2 object counter device type field: “DualCounter” has device type 11 hex. A 10 hex when in
service mode.
“SSSSSSSS”
The MS-30 bits of these 4-bytes are the serial number of the sensor. The LS-2 bits are the status
flags for the open and closed beam status. An Open beam exists whenever the beam cannot be
seen. A Closed beam exists whenever the beam can be seen. The LS bit (bit-0) is the Open beam
state flag and the next most significant bit (bit-1) is the Closed beam state flag. Whenever both these
bits are low a BLOCKED state exists. Blocked occurs whenever the IR beam is blocked (Open) for
more than 6.5 seconds.
“oooooo”
This 24-bit field is the Object Counter stored LS-byte first.
“ff”
This 8-bit field is the Fringe Performance Event Counter. A non-zero value in this field indicates that
fringe IR reception exists and should be corrected for proper performance of the counter. This count
returns to zero when proper alignment exists.
“gggg”
This 16-bit field is the Total-Blocked-Time in accumulated seconds stored LS-byte first.
This counter accumulates the total time the beam has been blocked in seconds and is cleared
To zero when the object counter is cleared.
“CCCC”
This field is the CRC-16 error check as was originally received and checked. This CRC is over the
first 11 bytes of the packet starting with the device type and ending with but not including CRC-16.
“KK”
This field is the mod 256 sum of all the binary data values as represented by the ASCII hex values in
the response but does not include the <CR>.
