MetroTel of Minnesota MT9103CTM Cellular Tank Monitor User Manual
MetroTel Corp of Minnesota Cellular Tank Monitor
User Manual
72-70-165, Rev. A 02/09/2014
WESROC
®
RMS Cellular Tank Monitor (CTM)
Models MT-9100CTM and MT-9103CTM - Quick Installation Guide
1] Complete the CTM Installation Information Worksheet on the reverse side of this document and send it to your
WESROC host administrator. You MUST record the CTM serial number on the worksheet to match the
installation location to the monitoring hardware.
2] If not already present, install the correct Rochester remote ready dial or ITC large dial assembly on the tank
gauge. Remote ready dials and large dial assemblies are available for a wide variety of gauge types.
3] Remove the CTM from the box and make sure the small round programming magnet is secured in the OFF
position on the CTM enclosure. (Off mode.)
4] Mount the CTM on or near the tank to be monitored using the attached mounting magnets or a mounting
bracket. Try not to place the CTM right next to a vertical metal object such as a tank dome or hood. Cellular signal
reception will be affected by distance and by obstructions such trees, mountainous terrain, buildings, metal
structures, large vehicles parked nearby, etc. The best signal reception will be achieved with a line of sight path
between the CTM and the cell tower. This is rarely the case in the real world, but should be kept in mind when
selecting a mounting location for the CTM. Versions of the CTM with a longer sensor cable allow for mounting the
CTM a few feet away from the tank to improve cellular reception.
5] Connect the CTM sensor cable to the remote ready dial. Large dial installations use an in-line connector to
attach the CTM to the dial. When attaching the connector, make sure the connector is fully seated and that the
locking ring has been fully turned to ensure a weather tight seal.
6] (Option A) Force a configuration report to Host using the default CTM configuration settings.
o Remove the programming magnet from the OFF position on the CTM and step away. (Normal mode.)
Do not block the cellular signal with your body while the CTM is reporting to the Host.
6] (Option B) Make CTM configuration settings changes and force a configuration report to Host.
o Place programming magnets in the OFF and INIT positions on the CTM. (Configuration mode.)
o Make system and application configuration changes using a WESROC Portable Diagnostic Unit (PDU).
o Remove both programming magnets from the CTM at the same time and step away. (Normal mode.)
Do not block the cellular signal with your body while the CTM is reporting to the Host.
The CTM will now perform a configuration report to the Host. A report is typically completed in less than a minute,
but can take up to 3 minutes under weak cellular signal conditions. The CTM does not provide any direct
feedback regarding report success or failure; therefore it is recommended to use a handheld PDU when
performing CTM installations.
7] Once a successful report has been completed, secure the sensor cable using the appropriate fasteners (cable
ties, etc.). Route the sensor cable to make sure the cable will not be damaged by a moving object such as a tank
dome or hood.
8] (Optional) Initialize the CTM to a WESROC Base Unit if you are using the local display feature.
o Place a programming magnet in the INIT position on the CTM. (Initialization mode.)
o Place the Base Unit into Initialization mode.
o Wait for the CTM tank level to appear on the Base Unit display.
o Remove programming magnet from the CTM, and return the Base Unit to normal operation.
Remove all programming magnets from the CTM enclosure before leaving the installation site.
Refer to the WESROC Cellular Tank Monitor Operation Manual for more detailed operating instructions.
Independent Technologies, Inc.
Blair, NE - www.IndependentTech.com - (402) 426-3700
Compliance Information
Changes or modifications not expressly approved by the manufacturer could void the user’s
authority to operate this equipment.
This product meets the applicable FCC Part 15 rules and Industry Canada's license exempt
RSSs. Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent materiel est conforme aux CNRexempts de licence d'Industrie Canada. Son
fonctionnement est soumis aux deux conditions suivantes: (1) cet appareil ne peut pas
provoquer d'interférences, et (2) cet appareil doit accepter toute interférence, y compris celles
susceptibles de provoquer le fonctionnement du dispositif
WESROC
®
RMS Cellular Tank Monitor (CTM)
Installation Information Worksheet
REQUIRED INSTALLATION INFORMATION!!!
CTM Serial Number
(S/N can be found on bottom of CTM enclosure.)
Customer Name / Location
Street Address
City / State / Zip
/ /
Tank Capacity
__________ Gallons (or total manifolded gallons)
Optional Information:
Time Zone
(Circle One)
EST / CNT / MNT / PAC
Route / Stop
/
Tank Serial Number
Tank Access/ Description
(Ex. Generator/Diesel/South)
Tank Event Settings
Default Setting / Or Specify Value
Tank Critical Low Alarm 15% /
Tank Warn Low Alarm 30% /
Tank Draw Event Alert 10%/hr /
Tank Fill Event Alert 10%/hr /
Contact Information Your Company
(If blank we will copy from last install or matching route)
Corporate Email List
Configuration Text Alert
Yes / No
(If yes include 10 digit cell number & carrier)
Technician Contact Information
Fuel Company Name
Tech Name / Phone #
Complete and Fax this Worksheet to (402)426-3705 or email elisha.garcia@itcmail.net
