Copyright Notice
We take every care in the preparation of this document, but no guarantee is given as to the
correctness of its contents. Our products are under continual improvement and we reserve
the right to make changes without notice.
Trademarks
All trademarks are the properties of their respective owners.
Revision History
▶Version: 1.2
▶ Date: 10, 2017
![](/img.php?id=3691235&img=bg4.png)
1-4 1-5
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and radiates radio frequency energy, and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
▶Reorient or relocate the receiving antenna.
▶Increase the separation between the equipment and receiver.
▶Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
▶Consult the dealer or an experienced radio TV technician for help.
NOTE
▶The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
▶Shield interface cables and AC power cord, if any, must be used in order to comply
with the emission limits.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
▶This device may not cause harmful interference.
▶This device must accept any interference received, including interference that may
cause undesired operation.
![](/img.php?id=3691235&img=bg5.png)
User's Manual
1-4 1-5
FCC RF Radiation Exposure and SAR Statements
FCC RF Radiation Exposure and SAR Statements SAR Statement. The MS-NB31 has
been tested for body-worn Specific Absorption Rate (SAR) compliance. The FCC has
established detailed SAR requirements and has established that these requirements. RF
Exposure Information The radio module has been evaluated under FCC Bulletin OET 65C
(01-01) and found to be compliant to RF Exposure from radio frequency devices. This
model meets the applicable government requirements for exposure to radio frequency
waves. The highest reported SAR level for usage near the body (0mm) is 1.30 W/kg, and
for the simultaneous transmission is 1.59W/kg.
▶ WiFi 5G indoor use only
▶Operations in the 5.15-5.25GHz band are restricted to indoor usage only
CE Conformity
This device is in compliance with the essential safety requirements
and other relevant provisions set out in the European Directive.
![](/img.php?id=3691235&img=bg6.png)
1-6 1-7
Battery Regulations
European Union: Batteries, battery packs, and accumulators should
not be disposed of as unsorted household waste. Please use the
public collection system to return, recycle, or treat them in compliance
with the local regulations.
廢電池請回收
Taiwan: For better environmental protection, waste batteries should
be collected separately for recycling or special disposal.
California, USA: The button cell battery may contain perchlorate material and requires
special handling when recycled or disposed of in California.
For further information please visit: http://www.dtsc.ca.gov/hazardouswaste/
perchlorate/
Safety Guideline for Using Lithium Battery
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the equipment manufacturer. Discard used batteries
according to manufacturer’s instructions.
WEEE Statement
European Union: Under the European Union ("EU") Directive on
Waste Electrical and Electronic Equipment, Directive 2002/96/EC,
which takes effect on August 13, 2005, products of "electrical and
electronic equipment" cannot be discarded as municipal waste
anymore and manufacturers of covered electronic equipment will be
obligated to take back such products at the end of their useful life.
![](/img.php?id=3691235&img=bg7.png)
User's Manual
1-6 1-7
Safety Instructions
Read the safety instructions carefully and thoroughly. All cautions and
warnings on the equipment or user’s manual should be noted.
Keep this equipment away from humidity and high temperature.
Lay this equipment on a stable surface before setting it up.
The openings on the enclosure are used for air convection and to
prevent the equipment from overheating. Do not cover the openings.
• Do not leave the equipment in an unconditioned environment with
a storage temperature above 60ºC (140ºF) or below -20ºC (-4ºF),
which may damage the equipment.
• This unit should be operation under maximum ambient temperature
of 50ºC (120ºF) or under 60ºC (140ºF) for light loading applications.
Followings are requirements of battery storage:
1. If the storage duration is within 3 months, please remain the
temperatureat-20℃ ~45℃ ; If the storage duration is above
3 months but within 1 year, please remain the temperature at
23℃± 2℃ .
2. Thebatterycapacityshouldremainat30 ± 5%.
3. Thestoragehumidityshouldremainat65 ± 25%RH.
4. Thebatterychargingtemperatureshouldbe10℃ ~45℃ ,the
dischargingtemperatureshouldbe-20℃ ~60℃ .
5. For the maximum battery discharging performance, please
remainthestoragetemperatureat25℃ .
![](/img.php?id=3691235&img=bg8.png)
1-8 1-8
• Make sure the power voltage is within safety range and has been
adjustedproperly tothevalueof100~240V beforeconnecting the
equipment to the power outlet.
• Always unplug the AC power cord before installing any add-on card
or module to the equipment.
• Always disconnect the AC power cord or uninstall the battery pack
or switch off the wall socket if the equipment would be left unused
for a certain time to achieve zero energy consumption.
Place the power cord in a way that people are unlikely to step on it. Do
not place anything on top of the power cord.
Always keep the strong magnetic or electrical objects away from the
tablet.
Never pour liquid into the opening that could damage the equipment
or cause an electrical shock.
If any of the following situations arises, get the equipment checked by
a service personnel:
• The power cord or plug is damaged.
• Liquid has penetrated into the equipment.
• The equipment has been exposed to moisture.
• The equipment has not worked well or you can not get it work
according to User’s Manual.
• The equipment was dropped and damaged.
• The equipment has obvious signs of breakage.
Green Product Features
• Reduced energy consumption during use and stand-by
• Limited use of substances harmful to the environment and health
• Easily dismantled and recycled
• Reduced use of natural resources by encouraging recycling
• Extended product lifetime through easy upgrades
• Reduced solid waste production through take-back policy
Environmental Policy
• The product has been designed to enable proper reuse of parts
and recycling and should not be thrown away at its end of life.
• Users should contact the local authorized point of collection for
recycling and disposing of their end-of-life products.
![](/img.php?id=3691235&img=bg9.png)
Introductions
Part No.G52-17A12X8
User's Manual
TABLET PC
![](/img.php?id=3691235&img=bga.png)
Introductions
2-2 2-3
Congratulations on becoming an user of this product, the finely designed Tablet PC. You
will have a delightful and professional experience in using this exquisite Tablet PC. We are
proud to tell users that this Tablet PC is thoroughly tested and certified by our reputation
for unsurpassed dependability and customer satisfaction.
Unpacking
First, unpack the shipping carton and check all items carefully. If any item contained is
damaged or missing, please contact your local dealer immediately. Also, keep the box
and packing materials in case you need to ship the unit in the future. The package should
contain the following items:
▶Tablet PC
▶AC/DC adapter and AC power cord
▶String (optional)
▶Hand strap (optional)
▶Brief case handle (optional)
▶Stylus (optional)
▶Stylus holder (optional)
▶Quick Start Manual(optional)
![](/img.php?id=3691235&img=bgb.png)
User's Manual
2-2 2-3
Product Overview
This section provides the description of basic aspects of the Tablet PC. It will help you to
know more about the appearance of this tablet before using it. Please be aware that the
figures shown here are for reference only.
Open View
The figure of open view and description shown below will lead you to browse the main
operating area of your Tablet PC.
![](/img.php?id=3691235&img=bgc.png)
Introductions
2-4 2-5
1. Front Camera
This built-in front camera can be used for picture taking, video recording or
conferencing, and any other interactive applications.
2. Internal Microphone
This is the built-in microphone and its function is the same with microphone.
3. Touch Screen
Whenever the display is rotated, the touch screen will be rotated and expanded to fit
the display automatically.
(NOTE: This function will be changed depends on the user’s settings.)
![](/img.php?id=3691235&img=bgd.png)
User's Manual
2-4 2-5
Top Side View
1. Kensington Lock
This Tablet PC provides a Kensington lock hole, which allows users to secure the
Tablet PC in place.
2. Barcode scanner (optional)
Easy handheld device for tracking goods from production to loading in the warehouse
to ensure shipping and Real-time order status.
3. Volume Up / Volume Down Button
Press the Volume Up or Volume Down button to adjust the sound volume.
4. Headphone Jack
Used for connecting the speakers or headphones.
5. Power Button
Power
Power Button
• Before powering on the Tablet PC for the very first time, you
must connect it with AC power.
• Press and hold the power button for 4 seconds can shut
down the Tablet.
![](/img.php?id=3691235&img=bge.png)
Introductions
2-6 2-7
Right Side View
![](/img.php?id=3691235&img=bgf.png)
User's Manual
2-6 2-7
1. Reset Hole
If the Tablet PC cannot be turned off normally or no respond by pressing the power
button for 4 seconds, insert a straightened paperclip to the hole.
(NOTE: In this case, AC power must be connected before restarting the Tablet PC.)
2. DC-in Jack
It is an electrical connector for supplying direct current (DC) power.
3. Micro HDMI Port
Micro HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) equipment.
4. USB 2.0 Port
The USB 2.0 port allows you to connect USB-interface peripheral devices, such as the
mouse, keyboard, modem, portable hard disk module, printer, etc.
5. USB 3.0 Port
USB 3.0, the SuperSpeed USB, delivers the higher interface speeds for connecting
various devices, such as storage devices, hard drives, or video cameras, and offers
more advantages over high-speed data transferring.
![](/img.php?id=3691235&img=bg10.png)
Introductions
2-8 2-9
Left Side View
![](/img.php?id=3691235&img=bg11.png)
User's Manual
2-8 2-9
Rear Side View
The figure of open view and description shown below will lead you to browse the main
operating area of your Tablet PC.
![](/img.php?id=3691235&img=bg12.png)
Introductions
2-10 2-11
1. Rear Camera
This built-in rear camera can be used for picture taking, video recording or
conferencing, and any other interactive applications.
2. Speaker
Support high quality sound.
3. Finger print (optional)
To access the tablet authority by scanning users’ fingerprint.
4. LTE Card Slot (optional)
To surf Internet with LTE high-speed wireless communication.
5. Battery latch
To lock/unlock battery.
6. NFC (optional)
To transfer information and files by point-to-point through two device with NFC
function.
![](/img.php?id=3691235&img=bg13.png)
User's Manual
2-10 2-11
Bottom Side View
1. Dock Connector
Connect with external Docking Station to increase more I/O functions.
2. Boss Hole
Used for locking the boss hole of the dock.
![](/img.php?id=3691235&img=bg14.png)
Introductions
2-12 2-13
Specifications
The specifications listed here is reference only, and may change without notice. The actual
products sold are different from areas.
Physical Characteristic
Dimension 232.6 (W) x 22.0 (D) x 150.0 (H) mm
Weight < 850 g
CPU
Supported Processor Intel® Quad Core processor
Processor Type Intel® Atom ™ Processor
Memory
Technology LPDDR3 1600
Memory 4GB/8GB on board
Power
AC/DC Adapter
65W, 19V
Input:100~240V,50~60Hz
Output: 19V 3.42A
The supported AC/DC adapter may vary without notice.
Storage (Note: items listed below may vary without notice)
EMMC 64GB/128GB
I/O Port
USB x 1 (USB 3.0)
x 1 (USB 2.0)
Internal Microphone x 1
Headphone Jack x 1
DC-in Jack x 1
Micro HDMI x 1
Pogo Pin x 1
Kingston Lock x 1
![](/img.php?id=3691235&img=bg15.png)
User's Manual
2-12 2-13
Sim Card x 1
SD Card reader x 1
Communication Port
Wireless LAN Supported
Bluetooth Supported
Display
LCD Type 8" IPS display
Resolution 1280 x 800
Multi Touch 10-Point Touch Supported
Brightness Brightness controlled by setting
Video
Graphics UMA
Webcam
Front Camera 2.0MP
Rear Camera 8.0MP
Audio
Internal Speakers x 2
Sound Volume Adjust by volume button & SW
Internal Speakers
(optional)
x 2
x 4
Optional Function
3D camera Supported
Barcode scanner Supported
NFC Supported
LTE Supported
The actual function preinstalled in this product depends on the model you purchased,
and may vary without notice.
![](/img.php?id=3691235&img=bg16.png)
Introductions
2-14 2-14
![](/img.php?id=3691235&img=bg17.png)
Getting Started
User's Manual
TABLET PC
![](/img.php?id=3691235&img=bg18.png)
Getting Started
3-2 3-3
Begin to Use the Tablet PC
For a new user of this Tablet PC, we would like to suggest you follow the illustrations
below to begin to use the Tablet PC.
![](/img.php?id=3691235&img=bg19.png)
3-2 3-3
User's Manual
How to Manage Power Supply
This section provides users basic safety precautions to take when using an AC/DC adapter
and battery power properly.
AC/DC Adapter
Ensure that your notebook is connected to an AC power source via the AC adapter before
turning it on for the first time. If the notebook automatically shuts down due to low battery
power, it is likely to cause system failure. Below are some Dos and Don'ts of an AC/DC
adapter.
▶Dos
• Use the adapter that shipped with your notebook only.
• Always be aware of heat coming from the in use AC/DC adapter.
• Unplug the AC power cord before disassembly the notebook.
▶Don'ts
• Cover an in-use adapter since it can generate heat.
• Have the AC power cord plugged after powering off the system when the
notebook is going to be left unused for a longer time.
1. Take up the interchangeable plug and look for the groove on the interchangeable
plug which can be used for locking on the AC/DC adapter. Then align the groove of
the interchangeable plug on the tenon of the AC/DC adapter with correct orientation.
Next, rotate the interchangeable plug 90 degrees clockwise until it is fixed on the
AC/DC adapter.
2. Plug the DC end of the AC/DC adapter into the DC-in jack of the Tablet PC.
3. Then plug the AC/DC adapter into the power outlet.
4. When remove, please follow the steps 3 2 1.
(NOTE:The interchangeable plug may vary depending on countries or regions.)
![](/img.php?id=3691235&img=bg1a.png)
Getting Started
3-4 3-5
Battery
Please follow your local laws and regulations to recycle the Tablet and battery pack.
▶Conserving Battery Power
Efficient battery power is critical to maintain a normal operation. If the battery power is not
managed well, the saved data and customized settings may be lost.
To optimize battery life and avoid a sudden power loss, read the tips below:
• Suspend system operation if the system will be idle for a while or shorten the
suspend time period.
• Turn off the system if you won’t be using it for a period of time.
• Disable unnecessary settings or remove idle peripherals.
• Connect an AC/DC adapter to the system whenever possible.
▶Charging the Battery Pack
The battery pack can be recharged when the Tablet PC is connected to the AC power.
Please pay attention to the following tips before recharging the battery:
• You can use the system, suspend system operation or shut down and turn off the
system without interrupting the charging process.
• The battery pack uses Lithium-ion Polymer battery cells that have no “memory
effect.” It is unnecessary to discharge the battery before recharging. However,
to optimize the life of battery, we suggest that consuming the battery power
completely once a month is necessary.
• The actual charging time will be determined by the applications in use.
▶Safety guidelines
• Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type recommended by the manufacturer. Discard used batteries
according to manufacturer's instruction.
• Always keep the Tablet PC and its battery away from excessive moisture and
extreme temperatures.
• Always unplug the AC power cord before installing any module to the Tablet PC.
(NOTE:Pleasedonotcharge batteryintemperaturebelow0 ℃orabove45 ℃ , itmay
cause safety issue.)
![](/img.php?id=3691235&img=bg1b.png)
3-4 3-5
User's Manual
Power On
Long press the Power Button to power on the Tablet PC.
![](/img.php?id=3691235&img=bg1c.png)
Getting Started
3-6 3-6
