1. Product Description
The DWPCIe83 USB module is a wireless audio module (30x26.8mm) with a PCI
Express interface based on the SMSC DARR83. This USB module can be used to build
an uncompressed wireless digital audio transceiver operating in the 2.4GHz, 5.2GHz and
5.8GHz bands.
The wireless audio link supports up to four stereo audio streams and comes together with
additional features such as: data encryption, pairing functionality, bi-directional control
data messages, low power audio snooze mode, WLAN detection and Automatic
Frequency Allocation.
The DARR83 chip itself provides the basic functions of Audio Processing and buffering, Data
Link Layer and Physical Layer. The DWPCIe83 USB module integrates all functionality for a
wireless digital audio connection, comprising:
DARR83 Wireless Audio Processor
2.4GHz/ 5.2GHz/ 5.8 GHz RF Transceiver
Dual antenna connectors
USB2.0 through a PCI Express Mini Card System Connector
Built-in SPI interface Flash
2. DWPCIe83 Module Usage Scenarios
2.1. Headset Mode
When the DWPCIe83 Module is configured into the headset mode the DWPCIe83 module is
able to have an audio input and audio output at the same time. The DWPCIe83 module can
stream audio to a DARR-enabled headset and simultaneously receive the voice channel from
this headset.
2.2. Multiple Stream Mode
In the multiple stream mode the DWPCIe83 Module will act as a multi stereo stream device
so that in Windows Vista and Windows 7 it is possible to play multiple audio sources (iTunes
and medial player) to different speakers.
2.3. Surround Mode
When the DWPCIe83 Module is configured in the surround mode it is possible to transfer
5.1/7.1 audio from a movie to wireless surround speakers.
SMSC CONFIDENTIAL
User Manual
Page 3 of 12
SMSC CONFIDENTIAL
Revision 0.5 (9.21.2011)
2.4. Customer Specific Applications
An SDK for the DARR83 USB dongle is available at SMSC. For more information on the SDK,
the features and support for application specific developments, please contact SMSC.
2.5. RF measurement
Conducted measurement is through IPEX connectors. For radiated measurements, suitable
external antennas have to be connected to the IPEX connectors.
SMSC CONFIDENTIAL
User Manual
Page 4 of 12
SMSC CONFIDENTIAL
Revision 0.5 (9.21.2011)
3. DWPCIe83 Module Specifications
System Specifications
ID
Parameter
Value
Unit
Remarks
RF Characteristics
RF frequency range1
2400 - 2483.5
5150 - 5250
5725 - 5875
MHz
MHz
MHz
Number of RF channels per
band
3
Air framing
Addressing
24
Bit
Data message size
32
Byte
Application dependent
CRC
16, 24 and 32
Bit
Hybrid
Control
USB 2.0
480
Mbps
Data
Data Bandwidth
100
Kbps
Bi-directional wireless
data channel
Data latency
5
ms
Minimum under good
RF link conditions for
applications that
support the 100kbps
data rate.
Interference Robustness
Fixed frequency devices (e.g.
WLAN, microwave oven)
Fully coexistent2
Frequency hopping devices
(e.g. 5.8GHz cordless phones)
Fully coexistent2
1 Country/ Region dependent, refer section 4.
2 Laboratory tests have verified coexistence with interference sources collocated. Exact ranges are scenario dependent
(function of latency, output power, audio compression, etc.). A mix of interference sources is allowed. Interference of fixed
frequency devices may result in the loss of one useable RF channel.
SMSC CONFIDENTIAL
User Manual
Page 5 of 12
SMSC CONFIDENTIAL
Revision 0.5 (9.21.2011)
Audio Interface
Available Interface Types
USB2.0
Number of stereo audio inputs or
outputs
1, 2, 3 or 4
Bidirectional, incl. audio
loop
Audio Quality
Sample rate
48
ksps
Sample width
16
bit
Latency
20
ms
Configurable from 10 to
23.6ms, depending on
the application.
Dynamic Range
TBD
16 bit 48ksps, A-
weighted
THD+N
TBD
16 bit 48ksps
Frequency response
0
dB
20Hz…22kHz 3
Dimensions
Board dimensions
30 x 26.8
mm
3.1. Absolute Maximum Ratings
Symbol
Parameter
Min.
Typ
Max
Unit
VCC
Supply Voltage
3.8
V
Tstorage
Storage Temperature
-25
85
°C
VESD
ESD Contact Discharge
-2
+2
kV
3.2. Recommended Operating Conditions
Symbol
Parameter
Min.
Typ
Max
Unit
VCC
Supply Voltage
3.3
V
VCC Ripple
Peak to Peak Ripple (in circuit)
0
100
mV
Tamb
Operating Temperature
0
25
60
°C
3 In applications where Digital Clock Sync is not used.
SMSC CONFIDENTIAL
User Manual
Page 6 of 12
SMSC CONFIDENTIAL
Revision 0.5 (9.21.2011)
3.3. Pin out at PCI Express interface connector
The pin listing is shown here below:
Pin Number
Pin Name
I/O
Description
2, 24, 39, 41, 52
+3V3_PCIE
PWR
3.3V Regulated input from PCIe
4, 9, 15, 18, 21,
26, 27, 29, 34, 35,
37, 40, 43, 50
GND
GND
Ground
3
GPIO_12_COEX1
I/O
Configurable. Please refer to the DARR83
datasheet
5
GPIO_13_COEX2
I/O
Configurable. Please refer to the DARR83
datasheet
20
GPIO_5_W_DISABLEN
I/O
Configurable. Please refer to the DARR83
datasheet
22
NC
NOT CONNECTED
36
DM
ANA
USB D-
38
DP
ANA
USB D+
42
GPIO_7_LED_WWAN#
I/O
Configurable. Please refer to the DARR83
datasheet
46
GPIO_6_LED_WPAN#
I/O
Configurable. Please refer to the DARR83
datasheet
1, 6, 7, 8, 10, 11,
12, 13, 14, 16, 17,
19, 23, 25, 28, 30,
31, 32, 33, 44, 45,
47, 48, 49, 51
NC
NOT CONNECTED
3.4. RF Connections
The module provides RF connectors (Hirose U.FL-R-SMT (CL No. 331-0471-0) or equivalent)
for use with external antennas. RX and TX diversity antennas are used to avoid dropouts due to
multipath fading.
Antenna A (Main) RF Connector J1 on the module
Antenna B (AUX) RF Connector J2 on the module
Only „one‟ antenna is selected for use at any one time, through the on-board Transmit-Receive/
Diversity RF switch.
Coaxial Antenna Connector dimensions
SMSC CONFIDENTIAL
User Manual
Page 7 of 12
SMSC CONFIDENTIAL
Revision 0.5 (9.21.2011)
3.5. DWPCIe83 Module Dimensions
PCB-size: 30 x 26.8 mm (±0.15)
SMSC CONFIDENTIAL
User Manual
Page 8 of 12
SMSC CONFIDENTIAL
Revision 0.5 (9.21.2011)
4. Regulatory Statements for DWPCIe83
USA-Federal Communications Commission (FCC)
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy. If not installed and used in accordance with the instructions, it may cause
harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by tuning the equipment off and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the distance between the equipment and the receiver.
- Connect the equipment to outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly approved by the party
responsible for compliance could void the user‟s authority to operate the equipment.
Caution: Exposure to Radio Frequency Radiation.
To comply with FCC RF exposure compliance requirements, for mobile configurations, a
separation distance of at least 20 cm must be maintained between the antenna of this device and
all persons. This device must not be co-located or operating in conjunction with any other antenna or
transmitter.
CAUTION (this is only applicable to UNII device)
This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency
range. FCC requires this product to be used indoors for frequency range 5.15 to 5.25 GHz to reduce
the potential for harmful interference to co-channel Mobile Satellite systems.
Host product must be labeled with "Contains FCC ID: ZQO-DWPCIE83".
Canada Industry Canada (IC)
This Device complies with RSS-210 of the IC Rules; Operation is subject to the following two
conditions:
(1). This device may not cause interference and
(2). This device must accept any interference received,, including interference that may cause
undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Caution - Exposure 部分
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS102 and users
can obtain Canadian information on RF exposure and compliance.
Le dispositif répond à l'exemption des limites d'évaluation de routine dans la section 2.5 de RSS102
et les utilisateurs peuvent obtenir des renseignements canadiens sur l'exposition aux RF et le respect.
SMSC CONFIDENTIAL
User Manual
Page 9 of 12
SMSC CONFIDENTIAL
Revision 0.5 (9.21.2011)
This equipment should be installed and operated with a minimum distance of 20 centimeters between
the radiator and your body.
Cet équipement doit être installé et utilisé avec une distance minimale de 20 centimètres entre le
radiateur et votre corps.
Caution: (this is only applicable to LE-LAN device)
This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range.
Industry Canada requires this product to be used indoors for frequency range 5.15 to 5.25 GHz to
reduce the potential for harmful interference to co-channel Mobile Satellite systems.
Ce dispositif est limité à une utilisation en intérieur à cause de son fonctionnement dans la gamme
5.15 à 5.25 GHz. Industrie Canada exige que ce produit est utilisé à l'intérieur pour la gamme de
fréquence de 5,15 à 5,25 GHz pour réduire les risques d'interférence nuisible à la co-canal systèmes
mobiles par satellite.
Host product must be labeled with "Contains IC: 2581A-DWPCIE83”.
EuropeEU Declaration of Conformity and Restrictions
Hereby, Standard Microsystems Corporation, declares that this equipment complies with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
This equipment needs to be marked with the symbol and can be used throughout the
European community.
Marking by the symbol indicates that usage restrictions apply.
France - 2.4GHz for Metropolitan France :
In all Metropolitan departments, wireless LAN frequencies can be used under the following
conditions, either for public or private use:
· Indoor use: maximum power (EIRP*) of 100 mW for the entire 2400-2483.5 MHz frequency band
· Outdoor use: maximum power (EIRP*) of 100 mW for the 2400-2454 MHz band and with maximum
power (EIRP*) of 10 mW for the 2454-2483 MHz band
This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range.
To ensure compliance with local regulations, be sure to select the country in which the end product is
used.
Caution: Exposure to Radio Frequency Radiation.
To comply with RF exposure compliance requirements, for mobile configurations, a
separation distance of at least 20 cm must be maintained between the antenna of this device and
all persons. This device must not be co-located or operating in conjunction with any other antenna or
transmitter.
Taiwan - NCC Statement
根據交通部低功率管理辦法規定:
第十二條
經型式認證合格之低功率射頻電機,非經許可,公司、商號或使用者均不得擅自
變更頻率、加大功率或變更原設計之特性及功能。
第十四條
低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用,並改善
至無干擾時方得繼續使用。
前項合法通信,指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法
通信或工業、科學及醫療用電波輻射性電機設備之干擾。
SMSC CONFIDENTIAL
User Manual
Page 10 of 12
SMSC CONFIDENTIAL
Revision 0.5 (9.21.2011)
Korea
Include the following statement either on the label or in the User Guide.
해당 무선설비는 전파혼신 가능성 있으므로 인명안전과 관련된 서비스는 없음
(Translation: the service related to human safety is not allowed because this device may have the
possibility of the radio interference.)
Japan
This device operation in the 5.15 to 5.25 GHz frequency range is restricted to indoor use. Final
product shall be labelled "For Indoor use only".
This device has been designed to operate with the antenna listed below, and having a peak gain of
3.65dBi @ 2.4GHz, 4.8dBi @ 5.2GHz and 5.21dBi @ 5.8GHz. Antennas not of the same type and
having a higher gain specified above are strictly prohibited for use with this device. The required
antenna impedance is 50 ohms.
Model: WNC_ANT_WIMAX_3D-2_2300-5850MHz, PIFA Antenna, Vendor: WNC
Model: 81.EDG15.GCP, PIFA Antenna, Vendor: WNC
Model: 81.EDG15.GCN, PIFA Antenna, Vendor: WNC
Model: 81.EDG15.GCU, PIFA Antenna, Vendor: WNC
Model: 81.EDG15.GCT, PIFA Antenna, Vendor: WNC
Model: 81.EDG15.GCW, PIFA Antenna, Vendor: WNC
Model: 81.EDG15.GCV, PIFA Antenna, Vendor: WNC
Model: CAN43131LMVT05631, PIFA Antenna, Vendor: Yageo
Model: CAN43131LMVT05632, PIFA Antenna, Vendor: Yageo
Model: CAN43131WLVT05643, PIFA Antenna, Vendor: Yageo
Model: CAN43131WLVT05644, PIFA Antenna, Vendor: Yageo
Model: CAN43131WLQU05831 Tx1, PIFA Antenna, Vendor: Yageo
Model: CAN43131WLQU05831 Tx2, PIFA Antenna, Vendor: Yageo
Model: SE-EQSTA-003 Tx1/Rx1, PIFA Antenna, Vendor: Smart Approach
Model: SE-EQSTA-003 Tx2/Rx2, PIFA Antenna, Vendor: Smart Approach
Frequency Band Information
Country/Region
Frequency Band Usable
USA, Brazil, Argentina,
Canada, Hong Kong,
Thailand, Singapore
2400-2483.5MHz, 5150-5250MHz, 5725-5850MHz
Korea, Indonesia
2400-2483.5MHz, 5725-5825MHz
Taiwan, Mexico, Australia,
New Zealand
2400-2483.5MHz, 5725-5850MHz
Europe, Saudi Arabia
2400-2483.5MHz, 5150-5250MHz, 5725-5875MHz
India
2400-2483.5MHz, 5150-5250MHz, 5725-5825MHz
China
2400-2483.5MHz
Japan, Russia, South Africa
2400-2483.5MHz, 5150-5250MHz
Note: Range of channels is limited by firmware.
SMSC CONFIDENTIAL
User Manual
Page 11 of 12
SMSC CONFIDENTIAL
Revision 0.5 (9.21.2011)
5. Installation Requirements
The DWPCIe83 must be installed in a device that contains a 52-pin PCIE slot for mini-PCie cards.
The DWPCIe83 has FCC single modular approval, which can eliminate the need for you to obtain
FCC Part 15 Subpart C and E (intentional radiation) approvals for your device. In order to use this
FCC/IC single modular approval for the DWPCIe83, OEM integrators must:
1. include “Contains FCC ID: ZQO-DWPCIE83, IC: 2581A-DWPCIE83” on the exterior label of
your device.
2. ensure that its “END” product is electrically identical to the SMSC reference designs
3. use an antenna as approved with the DWPCIe83 module or an equivalent type antenna with
equal or lower gain and provide antenna reports to SMSC.
4. include all required statements in your final product user‟s manual and final product labeling
as required by the applicable law in all respects. Refer to FCC/IC Information in previous
chapter (for illustration purposes only).
5. not provide Instructions on how to remove or install the DWPCIe83 module to your end users.
6. provide regulated +3.3 VDC power to the DWPCIe83 module.
Additional items (CE):
1. the module is tested to comply with the requirement of the R&TTE Directive. System
integrators are responsible for compliance of the final device with the R&TTE Directive.
2. Packaging: CE Marking must also be on the outer packaging of the product. The outer
packaging must also provide an indication as to where the device is intended to be used and
OR conversely, where there may be restrictions to use.
IMPORTANT NOTE:
In the event that these conditions cannot be met (for example certain laptop configurations or co-
location with another transmitter), then the FCC authorization is no longer considered valid and FCC
ID cannot be used on the final product. In these circumstances, the OEM integrator will be
responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC
authorization.
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to
install or remove this RF module in the user manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/ warning as shown in this
manual (for illustration purpose only).
SMSC CONFIDENTIAL
User Manual
Page 12 of 12
SMSC CONFIDENTIAL
Revision 0.5 (9.21.2011)
6. Revision History
Revision
Author
Date
Detail
0.0
SM
22-08-2011
First Release
0.1
SM
26-08-2011
Antenna Updates
0.2
SM
30-08-2011
IC and Frequency Band Updates
0.3
SM
02-09-2011
Antenna Updates
0.4
PC
06-09-2011
Antenna Updates
0.5
PC
08-09-2011
Antenna Updates
SMSC CONFIDENTIAL

Navigation menu
