Microlab Electronics T1 Bluetooth Headphone User Manual 80 T1 97 0001 03x4
Microlab Electronics Co.,Ltd. Bluetooth Headphone 80 T1 97 0001 03x4
Users Manual
T1
Bluetooth Headphone
FCC ID:OR8-T1
Important Safety Instructions
Caution:
To reduce the risk of electric shock, do not dismantle the product and do not expose the apparatus to rain or moisture. No user-serviceable parts inside. Refer servicing to qualified personnel only.
The lightning flash within an equilateral triangle is intended to alert you to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient
magnitude to constitute an electric shock to a person or persons.
The exclamation point within an equilateral triangle is intended to alert you to the presence of important operating and maintenance (servicing) instructions in the literature
accompanying the product.
Explanation of Graphical Symbols:
WARNINGS:
1. Read Instructions - All the safety and operating instructions must be read before the product is operated.
2. Retain Instructions - The safety and operating instructions should be kept product for future reference.
3. Heed warnings - All warnings on the product and in the operating instructions should be adhered to.
4. Follow instructions - All operating and users’ instructions should be followed.
5. Installation - Install in accordance with the manufacturers’ instructions.
6. Power sources - This product should be operated only from the type of power source indicated by the marking adjacent to the power cord entry. If you are not sure of the type of power supply to
your home, consult your product dealer or local power company.
7. Grounding or polarization - the product is not required to be grounded. Ensure the plug is fully inserted into the wall outlet or extension cord receptacle to prevent blade or pin exposure. Some
versions of the product are equipped with a power cord fitted with a polarized alternating line plug (a plug having one blade wide than the other). This plug will fit onto the power outlet only one
way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug. When using an extension power-supply cord or a power-supply cord other than that supplied with the appliance, it should be fitted with
the appropriate molded plugs and carry safety approval appropriate to the country of use.
8. Power cord protection - Power-supply cords should be routed so that they are not likely to be walked on, kinked or pinched by items placed on or against them, paying particular attention to
cords from plugs, receptacles and the point where they exit from the appliance.
9. Overloading - Do not overload wall outlets, extension cords or multiple sockets, as this can result in a risk of fire or electric shock.
10. Ventilation - The product must be properly ventilated. Do not place the product on a bed, sofa, or other similar surface. Do not cover the product with any items such as tablecloths, newspapers,
etc.
11. Heat - The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products including amplifiers that produce heat. No naked flame sources, such as
lighted candles, should be placed on the apparatus.
12. Water and moisture - To reduce the risk of fire or electric shock, do not expose the product to train, dripping, splashing or excessive moisture such as in a sauna or bathroom. Do not use this
product near water for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool and the like.
EN
1
13. Object and Liquid Entry - Never push objects of any kind into this product through openings, as they may touch dangerous voltage points or short-circuit parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product. Do not place any object containing liquid on top of the product.
14. Cleaning - Unplug the product from the wall outlet before cleaning. The cabinet of the subwoofer may be cleaned by dusting with a dry cloth. If you wish to use an aerosol cleaning spray, do not
spray directly on the cabinet; spray onto the cloth. Be careful not to damage the drive units.
15. Attachments - Do not use attachments not recommended by the product manufacturers, as they may cause hazards.
16. Accessories - Do not place this product on an unstable cart, stand, tripod, bracket or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use
only with a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. Any mounting of the product should follow the manufacturer's instructions and
should use a mounting accessory recommended by the manufacturer.
17. Moving the product - A product and cart combination should be moved with care. Quick stops, excessive force and uneven surfaces may cause the product and cart combination to overturn.
18. Unused periods - The power cord of the appliance should be unplugged from the outlet during lightning storms or when the apparatus is left unused for a long period of time.
19. Servicing - Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service
personnel.
20. Please remove the power plug form the main power source or wall power source when not in use. When plugged in to a power source, the system is in standby mode, so the power is not entirely
cut off.
21. Replacement parts - When replacement parts are required, ensure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire, electric shock or other hazards.
22. Mains fuses - For continued protection against fire hazard, use fuses only of the correct type and rating. The correct fuse specification for each voltage range is marked on the product.
23. Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you do, the speaker may be damaged when a peak level section is suddenly played.
24. The only means of completely disconnecting the product from the power supply is by removing the power cord from the wall outlet or the product. The wall outlet or the power cord entry to the
product must remain freely accessible at all times while the product is in use.
25. Try to install the product near a wall socket or extension cord and shall be easily accessible.
26. The highest environmental temperature suitable for this product is 40°C.
EN
2
80-T1-97-0001-03 2013-09-12 (New format 22.8 x 130 mm)
EN
3
EN
4
Introduction
Incorporating latest Bluetooth® wireless technology, this headset lets you connect to your mobile phone or media player without cables. Using A2DP profile, it lets you listen to stereo music by
connecting to any Bluetooth® wireless technology enabled products.
Designed with beautiful finishes, this headset system is ideal for your personal entertainment. Ideal for digital movies, TV, PC/notebook, CD/DVD and multimedia application.
With its built-in microphone, this system functions as an headset for your video conferencing and communication application.
Comes with rechargeable battery for longer lasting use, and easy charging via USB interface. Includes additional 3.5 mm stereo jack for traditional analog audio input.
ŸBluetooth® wireless music transfer lets you play from your mobile and any Bluetooth® from your mobile and any Bluetooth® product with Bluetooth® headset protocol
ŸBluetooth® 4.0 with HFP 1.6 A2DP 1.2 and AVRCP 1.4
ŸBluetooth® stereo audio using A2DP for wireless music streaming
ŸQuality headset with depth and full range audio performances
ŸCD sound quality with aptX function
ŸClear sound with strong bass sound effects
ŸCircum-aural Headset type for personal entertainment
ŸUSB charge and play function for longer use
Ÿ10 m wireless operating radius - connects and use with Bluetooth enabled device in larger area
ŸLarge ear pads to reduce external noise (passive noise cancellation function)
ŸMicrophone/answering phone call - handsfree communication
Ÿ3.5 mm stereo jack - connects to most media players such as Mp3/Mp4 player or notebook
ŸQuality ear-cups for comfortable wear
Features
Turn on / Play / pause/
Turn off / Answer call/
End call/ Reject call/
Transfer call voice/
Activate pairing mode
Charging
port
Volume
down
Volume
up
Microphone
Previous Next 3.5mm stereo jack
Activate pairing
mode
-
+
<
<
Foldable headband
Right pad
Right side
Control pad 3.5mm stereo
jack
Headband
Extendable arms
Folding joints
Ear cups
80-T1-97-0001-03 2013-09-12 (New format 22.8 x 130 mm)
Bluetooth Headphone
Bluetooth
Wireless
connection
Smartphone
Notebook
Tablet
Analog 3.5 mm stereo
connection to media players
Analog options
Smartphone / Tablet /
Mp3 / Mp4 Media player
LCD TV PC or Notebook
Media
player
CD / VCD / DVD
Blu-Ray player
Connections
EN
5
Power off Depress the “ ” button for 3 seconds to turn off the system.
(The Red LED will glows for 1 - 2 seconds before turning off,
and a tone beeps)
Low battery warning The red LED flash
Charging Insert the micro-USB plug (included USB cable) to the
headset’s micro-USB jack. Insert the other end to the PC’s USB
port or USB Hub to commence charging. (Red LED is on)
Please pre-charge the headset prior to initial use.
Answer call Depress once the “ ” button to answer incoming call.
End call Depress once the “ ” button to end the call.
Transfer call voice Double depress the “ ” button to transfer the call voice
between the mobile phone and device while on going call
Reject call Depress the “ ” button for 1~2 seconds to reject call when
the call is ringing
Volume up Depress once the “+” button for volume level increase
Power on
Activate pairing mode
Pairing
Desired Result Required Action
Depress the “ ” button for 3 seconds to power on the
headset. (Red LED double flash every 3 seconds, and a tone
beeps)
Press the “ +” and “ -” buttons together and hold for 6 seconds.
(White and Red LED quick flash alternately with 2 beep tones).
or depress “ “ for several seconds after power on.
In pairing mode, use a mobile phone with Bluetooth® function,
or other Bluetooth® Master Device to perform pairing action
(detail refer to the paragraph on “pairing”)
Volume Down Depress once the “-” button for volume level decrease
Next Depress once the “>” button for next music track on your
Bluetooth® enabled device via AVRCP function
Previous Depress once the “<” button for previous music track on your
Bluetooth® enabled device via AVRCP function
Battery power indication After pairing this device to iPhone. The battery power will be
displayed on your iPhone.
Play/pause Depress once on the “ “ button to play, or pause the music
to commence playback or pause the music respectively.
Multi-point connection In pairing mode, depress once the “ “ to enable the
“Multi-point” and double depress the “ “ again to disable
the “Multi-point”.
Factory default setting Long depress “>” and “<” during pairing mode to reset and
clear the paired device list
EN
6
Fold the ear cups
by bending inwards
Folding options
80-T1-97-0001-03 2013-09-12 (New format 22.8 x 130 mm)
EN
7
EN
8
80-T1-97-0001-03 2013-09-12 (New format 22.8 x 130 mm)
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
