Users Manual
Nokia Bluetooth Headset BH-108
8
2
7
1
4
3
5
6
9
ENGLISH
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that
this BH-108 product is in compliance with
the essential requirements and other
relevant provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity can be
found at http://www.nokia.com/phones/
declaration_of_conformity/.
© 2010 Nokia. All rights reserved.
Nokia, Nokia Connecting People and the
Nokia Original Accessories logo are
trademarks or registered trademarks of
Nokia Corporation. Nokia tune is a sound
mark of Nokia Corporation. Other product
and company names mentioned herein may
be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in this
document in any form without the prior
written permission of Nokia is prohibited.
Nokia operates a policy of continuous
development. Nokia reserves the right to
make changes and improvements to any of
the products described in this document
without prior notice.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
To the maximum extent permitted by
applicable law, under no circumstances shall
Nokia or any of its licensors be responsible
for any loss of data or income or any special,
incidental, consequential or indirect
damages howsoever caused.
The contents of this document are provided
"as is". Except as required by applicable law,
no warranties of any kind, either express or
implied, including, but not limited to, the
implied warranties of merchantability and
fitness for a particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia reserves
the right to revise this document or
withdraw it at any time without prior notice.
The availability of particular products may
vary by region. Please check with your Nokia
dealer for details. This device may contain
commodities, technology or software
subject to export laws and regulations from
ENGLISH
the US and other countries. Diversion
contrary to law is prohibited.
Introduction
With the Nokia Bluetooth Headset
BH-108, you can make and answer
calls hands-free with your compatible
mobile device.
Read this user guide carefully before
using the headset. Also, read the user
guide for the device that you connect
to the headset.
This product may contain small parts.
Keep them out of the reach of small
children.
The surface of this device is nickel-
free.
Bluetooth wireless technology
Bluetooth wireless technology allows
you to connect compatible devices
without cables. The headset and the
other device do not need to be in line
of sight, but they should be within 10
metres (33 feet) of each other.
Connections may be subject to
interference from obstructions, such
as walls, or other electronic devices.
The headset is compliant with
Bluetooth Specification 2.0 + EDR
supporting the Headset Profile 1.1 and
Hands-Free Profile 1.5. Check with the
manufacturers of other devices to
determine their compatibility with
this device.
ENGLISH
Get started
The headset contains the following
parts shown on the title page:
earpiece (1), indicator light (2),
multifunction key (3), earloop (4),
charger connector (5), and
microphone (6).
Before using the headset, you must
charge the battery and pair the
headset with a compatible device.
Parts of the device are magnetic. Metallic
materials may be attracted to the device.
Do not place credit cards or other
magnetic storage media near the device,
because information stored on them may
be erased.
Charge the battery
Before charging the battery, carefully
read “Battery and charger
information”.
Warning: Use only chargers
approved by Nokia for use
with this particular model. The use of any
other types may invalidate any approval
or warranty, and may be dangerous. Use
of unapproved chargers may present a
risk of fire, explosion, or other hazard.
When you disconnect the power cord of
any accessory, grasp and pull the plug,
not the cord.
1. Connect the charger to a wall
outlet.
2. Connect the charger cable to the
charger connector. The red
indicator light is displayed during
charging. Charging the battery
fully may take up to 2 hours.
3. When the battery is fully charged,
the green indicator light is
displayed. Disconnect the charger
from the headset, then from the
wall outlet.
ENGLISH
The fully charged battery has power
for up to 4 hours and 30 minutes of
talk time or up to 120 hours of
standby time.
To check the battery charge when the
headset is not connected to a charger,
press the multifunction key when the
headset is connected to a mobile
device. If the indicator light is green,
the charge level is sufficient. If the
light is yellow, you may need to
recharge the battery soon. If the light
is red, recharge the battery.
When the battery charge is low, the
headset beeps every 5 minutes and
the red indicator light flashes.
Switch on or off
To switch on, press and hold the
multifunction key for about 2 seconds.
The headset beeps, and the green
indicator light is displayed. The
headset tries to connect to the last
used device. When the headset is
connected to a device and is ready for
use, the green indicator light flashes
slowly. If the headset has not been
paired with a device, it automatically
enters pairing mode.
To switch off, press and hold the
multifunction key for about 5 seconds.
The headset beeps, and the red
indicator light is briefly displayed. If
the headset is not connected to a
device within about 30 minutes, it
switches off automatically.
Pair and connect the headset
Before using the headset, you must
pair and connect it to a compatible
device.
You can pair the headset with up to
eight devices, but you can connect it
to only one device at a time.
1. Ensure that your mobile device is
switched on and the headset is off.
ENGLISH
2. If the headset has not been
previously paired with a device,
switch on the headset. The headset
enters pairing mode, and the green
indicator light starts to flash
quickly.
If the headset has been previously
paired with a device, ensure that
the headset is switched off, and
press and hold the multifunction
key for about 5 seconds until the
green indicator light starts to flash
quickly.
3. Within about 3 minutes, activate
the Bluetooth feature on your
device, and set it to search for
Bluetooth devices. For details, see
the user guide of your mobile
device.
4. Select the headset from the list of
found devices.
5. Enter the passcode 0000 to pair
and connect the headset to your
device. In some devices, you may
need to make the connection
separately after pairing.
When the headset is connected to
your device and is ready for use, the
green indicator light flashes slowly.
To manually connect the headset to
the last used device, press and hold
the multifunction key for about 2
seconds, or make the connection in
the Bluetooth menu of your device.
You may be able to set your device so
that the headset connects to it
automatically. To activate this feature
in a Nokia device, change the paired
device settings in the Bluetooth menu.
ENGLISH
Basic use
Place the headset on the ear
The headset is ready to be used on the
right ear. To use the headset on the
left ear, attach the earloop to the
headset so that it is to the left of the
Nokia logo (9).
Slide the earloop behind your ear (7),
and gently push the earpiece against
your ear. Push or pull the earloop to
set its length. Point the headset
towards your mouth (8).
Calls
To make a call, use your mobile device
in the normal way when the headset is
connected to it.
To redial the number you last called (if
your mobile device supports this
feature with the headset), when no
call is in progress, press the
multifunction key twice.
To activate voice dialling (if your
mobile device supports this feature
with the headset), when no call is in
progress, press and hold the
multifunction key for about 2 seconds.
Proceed as described in the user guide
of the mobile device.
To answer or end a call, press the
multifunction key. To reject a call,
press this key twice.
To adjust the volume, use the volume
controls on the connected device.
To switch a call from the headset to a
compatible device, press and hold the
multifunction key for about 2 seconds,
or switch off the headset. To switch
the call back to the headset, press and
hold the multifunction key for about 2
seconds, or switch on the headset.
ENGLISH
Clear settings or reset
To clear all the settings from the
headset, switch off the headset, and
press and hold the multifunction key
for about 8 seconds. The headset
beeps twice, and the red and green
indicator lights alternate. After the
settings are cleared, the headset
enters pairing mode.
To reset the headset if it stops
functioning, even though it is charged,
connect the headset to a charger
while you press and hold the
multifunction key.
Troubleshooting
If you cannot connect the headset to
your compatible device, check that
the headset is charged, switched on,
and paired with your device.
Battery and charger information
This device has an internal,
nonremovable, rechargeable battery. Do
not attempt to remove the battery from
the device as you may damage the
device. This device is intended for use
when supplied with power from the
following chargers: AC-3, AC-4, AC-5,
AC-8, DC-4, and DC-9. The exact charger
model number may vary depending on
the type of plug. The plug variant is
identified by one of the following: E, EB,
X, AR, U, A, C, K, B, or UB. The battery can
be charged and discharged hundreds of
times, but it will eventually wear out.
Recharge your battery only with Nokia
approved chargers designated for this
device.
If a battery is being used for the first time
or if the battery has not been used for a
prolonged period, it may be necessary to
connect the charger, then disconnect and
reconnect it to begin charging the
ENGLISH
battery. If the battery is completely
discharged, it may take several minutes
before the charging indicator light is
displayed.
Unplug the charger from the electrical
plug and the device when not in use. Do
not leave a fully charged battery
connected to a charger, since
overcharging may shorten its lifetime. If
left unused, a fully charged battery will
lose its charge over time.
Always try to keep the battery between
15°C and 25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and
lifetime of the battery. A device with a
hot or cold battery may not work
temporarily. Battery performance is
particularly limited in temperatures well
below freezing.
Do not dispose of batteries in a fire as
they may explode. Dispose of batteries
according to local regulations. Please
recycle when possible. Do not dispose as
household waste.
Never use any charger that is damaged.
Operating times are estimates only.
Actual performance depends on many
factors such as device settings selected,
device features being used (or running in
the background), battery condition and
ambient temperature.
Taking care of your device
Your device is a product of superior
design and craftsmanship and should be
treated with care. The following
suggestions will help you protect your
warranty coverage.
• Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If your
device does get wet, allow it to dry
completely.
ENGLISH
• Do not use or store the device in
dusty, dirty areas. Its moving parts
and electronic components can be
damaged.
• Do not store the device in high or cold
temperature. High temperatures can
shorten the life of electronic devices,
damage batteries, and warp or melt
certain plastics. When the device
warms to its normal temperature
from a cold temperature, moisture
can form inside the device and
damage electronic circuit boards.
• Do not attempt to open the device.
• Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and fine
mechanics.
• Do not use harsh chemicals, cleaning
solvents, or strong detergents to
clean the device. Only use a soft,
clean, dry cloth to clean the surface of
the device.
• Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
These suggestions apply equally to your
device, charger, or any accessory.
Recycle
Always return your used electronic
products, batteries, and packaging
materials to dedicated collection points.
This way you help prevent uncontrolled
waste disposal and promote the recycling
of materials. Check product
environmental information and how to
recycle your Nokia products at
www.nokia.com/werecycle, or
nokia.mobi/werecycle.
The crossed-out wheeled-bin
symbol on your product, battery,
literature, or packaging reminds
you that all electrical and
electronic products, batteries,
and accumulators must be taken to
separate collection at the end of their
working life. This requirement applies in
the European Union. Do not dispose of
ENGLISH
these products as unsorted municipal
waste. For more environmental
information, see the product Eco-
Declarations at www.nokia.com/
environment.
FCC/Industry Canada notice
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: 1. This device may not cause
harmful interference; and 2. This device
must accept any interference received,
including interference that may cause
undesired operation. This equipment has
been tested and found to comply with the
limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and,
if not installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver. Connect the
equipment into an outlet on a circuit
different from that to which the receiver is
connected. Consult the dealer or an
experienced radio/TV technician for help.
NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be
co-located or operating in conjunction with
any other antenna or transmitter. NOTE:
Changes or modifications not expressly
approved by Nokia could void the user's
authority to operate the equipment.
