Nokia Bluetooth Headset BH-607
10
11
1
3
2
8
7
69
4
5
12
14
13
ENGLISH
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that
this BH-607 product is in compliance with
the essential requirements and other
relevant provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity can be
found at http://www.nokia.com/phones/
declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People and the
Nokia Original Accessories logo are
trademarks or registered trademarks of
Nokia Corporation. Nokia tune is a sound
mark of Nokia Corporation. Other product
and company names mentioned herein may
be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in this
document in any form without the prior
written permission of Nokia is prohibited.
Nokia operates a policy of continuous
development. Nokia reserves the right to
make changes and improvements to any of
the products described in this document
without prior notice.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
To the maximum extent permitted by
applicable law, under no circumstances shall
Nokia or any of its licensors be responsible
for any loss of data or income or any special,
incidental, consequential or indirect
damages howsoever caused.
The contents of this document are provided
"as is". Except as required by applicable law,
no warranties of any kind, either express or
implied, including, but not limited to, the
implied warranties of merchantability and
fitness for a particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia reserves
the right to revise this document or
withdraw it at any time without prior notice.
The availability of particular products may
vary by region. Please check with your Nokia
dealer for details. This device may contain
commodities, technology or software
subject to export laws and regulations from
the US and other countries. Diversion
contrary to law is prohibited.
ENGLISH
Introduction
With the Nokia Bluetooth Headset
BH-607, you can make and answer
calls hands-free with your compatible
mobile device. The headset is provided
with noise cancellation that helps you
handle calls in noisy environments.
Read this user guide carefully before
using the headset. Also, read the user
guide for the device that you connect
to the headset.
This product may contain small parts.
Keep them out of the reach of small
children.
The surface of this device does not
contain nickel in the platings. The
surface of this device contains
stainless steel.
My own key
The headset has a shortcut key that
you can set to perform different
functions on a compatible Nokia
device using the Nokia Accessory
Configuration Application. With the
application, you can also view headset
information and define headset
settings. For details, read the built-in
help of the application.
If the application is not already
installed in your mobile device, check
the availability of the application for
your device from the support pages of
this headset at www.nokia.com/
support or your local Nokia website.
If the application is not available for
your Nokia device model, you can use
the shortcut key to mute the
microphone during a call.
Bluetooth wireless technology
Bluetooth wireless technology allows
you to connect compatible devices
ENGLISH
without cables. The headset and the
other device do not need to be in line
of sight, but they should be within 10
metres (33 feet) of each other.
Connections may be subject to
interference from obstructions, such
as walls, or other electronic devices.
The headset is compliant with the
Bluetooth Specification 2.1 + EDR
supporting the Headset Profile 1.1 and
Hands-Free Profile 1.5. Check with the
manufacturers of other devices to
determine their compatibility with
this device.
Get started
The headset contains the following
parts shown on the title page: power
key (1), volume key (2), My own key
(3), answer/end key (4), microphones
(5), indicator light (6), charger
connector (7), earloop (8), and
earpiece (9).
Before using the headset, you must
charge the battery and pair the
headset with a compatible device.
Parts of the device are magnetic. Metallic
materials may be attracted to the device.
Do not place credit cards or other
magnetic storage media near the device,
because information stored on them may
be erased.
Charge the battery
Before charging the battery, carefully
read “Battery and charger
information”.
Warning: Use only chargers
approved by Nokia for use
with this particular model.
The use of any other types may invalidate
any approval or warranty, and may be
dangerous. Use of unapproved chargers
ENGLISH
may present a risk of fire, explosion, or
other hazard.
When you disconnect the power cord of
any accessory, grasp and pull the plug,
not the cord.
1. Connect the charger to a wall
outlet.
2. Connect the charger cable to the
charger connector. The red
indicator light is displayed during
charging. Charging the battery
fully may take up to 1 hour.
3. When the battery is fully charged,
the green indicator light is
displayed. Disconnect the charger
from the headset, then from the
wall outlet.
The fully charged battery has power
for up to 7 hours of talk time or up to
160 hours of standby time.
To check the battery charge when the
headset is not connected to a charger,
press the power key when the headset
is connected to a mobile device. If the
indicator light is green, the charge
level is sufficient. If the light is yellow,
you may need to recharge the battery
soon. If the light is red, recharge the
battery.
When the battery charge is low, the
headset beeps every 5 minutes and
the red indicator light flashes.
Switch on or off
To switch on, press and hold the power
key for about 2 seconds. The headset
beeps, and the green indicator light
flashes slowly while the headset tries
to connect to one or two last
connected devices. When the headset
is connected to at least one device and
is ready for use, the blue indicator
light flashes slowly. If the headset has
not been paired with a device, it
automatically enters pairing mode.
To switch off, press and hold the
power key for about 2 seconds. The
ENGLISH
headset beeps, and the red indicator
light is briefly displayed. If the headset
is not connected to a device within
about 30 minutes, it switches off
automatically.
Pair and connect the headset
Before using the headset, you must
pair and connect it to a compatible
device.
You can pair the headset with up to
eight devices, but you can connect it
to only up to two devices at a time.
1. Ensure that your mobile device is
switched on and the headset is off.
2. If the headset has not been
previously paired with a device,
switch on the headset. The headset
enters pairing mode, and the blue
indicator light starts to flash
quickly.
If the headset has been previously
paired with a device, ensure that
the headset is switched off, and
press and hold the power key for
about 5 seconds until the blue
indicator light starts to flash
quickly.
3. Within about 3 minutes, activate
the Bluetooth feature on your
device, and set it to search for
Bluetooth devices. For details, see
the user guide of your mobile
device.
4. Select the headset from the list of
found devices.
5. If necessary, enter the passcode
0000 to pair and connect the
headset to your device.
In some devices, you may need to
make the connection separately
after pairing.
When the headset is connected to at
least one device and is ready for use,
the blue indicator light flashes slowly.
ENGLISH
To manually connect the headset to
one or two last used devices, press and
hold the answer/end key for about 2
seconds (when no devices are
connected), or make the connection in
the Bluetooth menu of the desired
device. If you have a device connected
to the headset and want to connect a
second device, make the connection in
the Bluetooth menu of the device.
You may be able to set your device so
that the headset connects to it
automatically. To activate this feature
in a Nokia device, change the paired
device settings in the Bluetooth menu.
Basic use
Change the earpad
The headset may be provided with
different sized earpads. Select the
earpad that fits the best and is the
most comfortable for your ear.
To change the earpad, pull the current
earpad from the earpiece, and push
the new earpad into place (13).
Place the headset on the ear
Gently push the earpiece against your
ear.
You can rotate the earpad to keep the
headset securely in the ear (14). For
example, if you use the headset on the
right ear, you may need to rotate the
earpad to the right for the best fit. If
you wear an earring, ensure that it is
not accidentally attached to the
earpad.
To use the headset with the earloop,
attach the earloop to it (12). To detach
the earloop, gently pull it from the
headset. Slide the earloop behind your
ENGLISH
ear (10), and point the headset
towards your mouth (11). Push or pull
the earloop to set its length.
Adjust volume
The headset automatically adjusts the
volume according to ambient noise.
Slide the volume key up to increase or
down to decrease the volume. To
adjust the volume quickly, slide and
hold the key.
The selected volume level is saved for
the device that you currently use with
the headset.
Calls
To make a call, use your mobile device
in the normal way when the headset is
connected to it.
To redial the number you last called (if
your mobile device supports this
feature with the headset), when no
call is in progress, press the answer/
end key twice.
To activate voice dialling (if your
mobile device supports this feature
with the headset), when no call is in
progress, press and hold the answer/
end key for about 2 seconds. Proceed
as described in the user guide of the
mobile device.
To answer or end a call, press the
answer/end key. To reject a call, press
this key twice.
To mute or unmute the microphone
during a call, press the volume key. The
headset beeps, and a related icon is
displayed on your compatible mobile
device.
To switch a call between the headset
and a compatible connected device,
press and hold the answer/end key for
about 2 seconds.
Manage two calls
To manage two calls at the same time,
your mobile device must support the
ENGLISH
Bluetooth Hands-Free Profile 1.5, and
call waiting must be activated in the
device. Call waiting is a network
service and is available when the
headset is connected to only one
device.
To answer a waiting call and end the
active call, press the answer/end key.
To answer a waiting call and put the
active call on hold, press and hold the
answer/end key for about 2 seconds.
To end the active call and make the
call on hold active, press the answer/
end key.
To switch between the active call and
the call on hold, press and hold the
answer/end key for about 2 seconds.
Turn lights on or off
By default, the indicator lights are
shown in all situations. To turn the
lights off in some situations (for
example, during a call or when the
headset is connected to a mobile
device) or back on, press and hold the
answer/end key and the volume key
for about 5 seconds when the headset
is connected to a device.
Connect to two devices
You can have the headset connected
to two devices at the same time.
By default, the headset can only be
connected to one device at a time. To
allow the headset to connect to two
devices or to only one device, switch
off the headset, and press and hold
the power key and the volume key for
about 5 seconds. When you allow
connection to two devices, the green
indicator light flashes once; when you
allow connection to only one device,
the yellow indicator light flashes once.
If the headset can connect to two
devices at the same time and you use
redialling or voice dialling, the call is
made on the device that you last used
ENGLISH
to make a call when the headset was
connected to it.
Clear settings or reset
To clear all the pairing settings from
the headset (including settings you
have defined with the Nokia Accessory
Configuration Application), switch off
the headset, and press and hold the
power key and the answer/end key at
the same time for about 8 seconds.
The headset beeps twice, and the red
and green indicator lights alternate.
After the settings are cleared, the
headset enters pairing mode.
To reset the headset if it stops
functioning, even though it is charged,
connect the headset to a charger
while you press and hold the power
key.
Troubleshooting
If you cannot connect the headset to
your compatible device, check that
the headset is charged, switched on,
and paired with the device.
Battery and charger information
This device has an internal,
nonremovable, rechargeable battery. Do
not attempt to remove the battery from
the device as you may damage the
device. This device is intended for use
when supplied with power from the
following chargers: AC-3, AC-4, AC-5,
and DC-4. The exact charger model
number may vary depending on the type
of plug. The plug variant is identified by
one of the following: E, EB, X, AR, U, A,C,
K, or UB. The battery can be charged and
discharged hundreds of times, but it will
eventually wear out. Recharge your
battery only with Nokia approved
chargers designated for this device.
ENGLISH
If a battery is being used for the first time
or if the battery has not been used for a
prolonged period, it may be necessary to
connect the charger, then disconnect and
reconnect it to begin charging the
battery. If the battery is completely
discharged, it may take several minutes
before the charging indicator light is
displayed.
Unplug the charger from the electrical
plug and the device when not in use. Do
not leave a fully charged battery
connected to a charger, since
overcharging may shorten its lifetime. If
left unused, a fully charged battery will
lose its charge over time.
Always try to keep the battery between
15°C and 25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and
lifetime of the battery. A device with a
hot or cold battery may not work
temporarily. Battery performance is
particularly limited in temperatures well
below freezing.
Do not dispose of batteries in a fire as
they may explode. Dispose of batteries
according to local regulations. Please
recycle when possible. Do not dispose as
household waste.
Never use any charger that is damaged.
Operating times are estimates only.
Actual performance depends on many
factors such as device settings selected,
device features being used (or running in
the background), battery condition and
ambient temperature.
Taking care of your device
Your device is a product of superior
design and craftsmanship and should be
treated with care. The following
suggestions will help you protect your
warranty coverage.
ENGLISH
Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If your
device does get wet, allow it to dry
completely.
Do not use or store the device in
dusty, dirty areas. Its moving parts
and electronic components can be
damaged.
Do not store the device in high or cold
temperature. High temperatures can
shorten the life of electronic devices,
damage batteries, and warp or melt
certain plastics. When the device
warms to its normal temperature
from a cold temperature, moisture
can form inside the device and
damage electronic circuit boards.
Do not attempt to open the device.
Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and fine
mechanics.
Do not use harsh chemicals, cleaning
solvents, or strong detergents to
clean the device. Only use a soft,
clean, dry cloth to clean the surface of
the device.
Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
These suggestions apply equally to your
device, charger, or any accessory.
Recycle
Always return your used electronic
products, batteries, and packaging
materials to dedicated collection points.
This way you help prevent uncontrolled
waste disposal and promote the recycling
of materials. Check product
environmental information and how to
recycle your Nokia products at
www.nokia.com/werecycle, or
nokia.mobi/werecycle.
The crossed-out wheeled-bin
symbol on your product, battery,
literature, or packaging reminds
you that all electrical and
ENGLISH
electronic products, batteries, and
accumulators must be taken to separate
collection at the end of their working life.
This requirement applies in the European
Union. Do not dispose of these products
as unsorted municipal waste. For more
environmental information, see the
product Eco-Declarations at
www.nokia.com/environment.
FCC/Industry Canada notice
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: 1. This device may not cause
harmful interference; and 2. This device
must accept any interference received,
including interference that may cause
undesired operation. This equipment has
been tested and found to comply with the
limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and,
if not installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver. Connect the
equipment into an outlet on a circuit
different from that to which the receiver is
connected. Consult the dealer or an
experienced radio/TV technician for help.
NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be
co-located or operating in conjunction with
any other antenna or transmitter. NOTE:
ENGLISH
Changes or modifications not expressly
approved by Nokia could void the user's
authority to operate the equipment.

Navigation menu
