Manual
Nokia Wireless Plug-in Car
Handsfree HF-33W
9252955/1
1
23
5
6
7
4
9252955_en1.fm Page 1 Monday, August 28, 2006 1:10 PM
ENGLISH
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that
this HF-33W product is in compliance with
the essential requirements and other
relevant provisions of Directive 1999/5/EC.
The product is in conformity with the limits
defined in Directive 2004/104/EC (amending
Directive 72/245/EEC), Annex I, paragraph
6.5, 6.6, 6.8 and 6.9.
A copy of the Declaration of Conformity can
be found at: http://www.nokia.com/phones/
declaration_of_conformity/.
The crossed-out wheeled bin
means that within the European
Union the product must be taken
to separate collection at the
product end-of-life. Do not dispose
of these products as unsorted municipal
waste.
© 2006 Nokia. All rights reserved.
Reproduction, transfer, distribution or
storage of part or all of the contents in this
document in any form without the prior
written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are
registered trademarks of Nokia Corporation.
Other product and company names
mentioned herein may be trademarks or
tradenames of their respective owners.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Nokia operates a policy of continuous
development. Nokia reserves the right to
make changes and improvements to any of
the products described in this document
without prior notice.
Under no circumstances shall Nokia be
responsible for any loss of data or income or
any special, incidental, consequential or
indirect damages howsoever caused.
The contents of this document are provided
"as is". Except as required by applicable law,
no warranties of any kind, either express or
implied, including, but not limited to, the
implied warranties of merchantability and
fitness for a particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia reserves
9252955_en1.fm Page 2 Monday, August 28, 2006 1:10 PM
ENGLISH
the right to revise this document or
withdraw it at any time without prior notice.
The availability of particular products may
vary by region. Please check with the Nokia
dealer nearest to you.
Unauthorized changes or modifications to
this device may void the user's authority to
operate the equipment.
Export Controls
This device may contain commodities,
technology or software subject to export
laws and regulations from the US and other
countries. Diversion contrary to law is
prohibited.
For your safety
Read these simple guidelines. Not
following them may be dangerous or
illegal.
ROAD SAFETY COMES
FIRST
Obey all local laws. Always
keep your hands free to operate
the vehicle while driving. Your
first consideration while driving should
be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
Introduction
The Nokia Wireless Plug-in Car
Handsfree HF-33W allows you to
make and receive hands-free calls in
your car. You can connect the
9252955_en1.fm Page 3 Monday, August 28, 2006 1:10 PM
ENGLISH
handsfree to a compatible phone that
supports Bluetooth wireless
technology.
Read this user guide carefully before
using the handsfree. Also read the
user guide for your phone, which
provides important safety and
maintenance information. Keep the
handsfree out of reach of small
children.
Bluetooth wireless technology
Bluetooth wireless technology allows
you to connect compatible devices
without cables. In a Bluetooth
connection, the phone and the
handsfree should be within 10 meters
(30 feet) of each other. Connections
can be subject to interference from
obstructions, such as other electronic
devices.
The handsfree is compliant with the
Bluetooth Specification 1.2
supporting the Handsfree Profile 1.5.
Check with the manufacturers of
other devices to determine their
compatibility with this device.
There may be restrictions on using
Bluetooth technology in some
locations. Check with your local
authorities or service provider.
Get started
Before using the handsfree, you must
install it in the car, and pair it with a
compatible phone.
The handsfree contains the following
parts shown at the start of this guide:
tiltable cigarette lighter plug (1),
microphone (2), indicator light (3),
volume up key (4), volume down key
(5), call key (6), and speaker (7).
9252955_en1.fm Page 4 Monday, August 28, 2006 1:10 PM
ENGLISH
Install the handsfree
To function properly, the handsfree
must be connected to the cigarette
lighter socket of the car, and power
must be supplied by the 12-volt car
battery.
Insert the handsfree into the cigarette
lighter socket. The cigarette lighter
plug is provided with a removable cap.
If the plug does not fit in the socket,
remove the cap by sliding it from the
plug. You can tilt the cigarette lighter
plug to the desired angle (up to 100
degrees). Do not try to force the plug
to tilt more.
Ensure that the handsfree is properly
inserted in the cigarette lighter
socket, and does not interfere with the
normal operation of the car.
In some car models, the cigarette
lighter socket is powered by the car
battery even when you remove the
ignition key. In those cases, the car
battery might be discharged even if
the handsfree is not used. Contact the
vehicle manufacturer for more
information.
Switch on or off
To switch on, plug the handsfree into
the cigarette lighter socket. The
indicator light turns on.
To switch off, pull the handsfree out
from the cigarette lighter socket.
Pair the handsfree
1. Switch on your phone.
2. Ensure that the handsfree is
plugged properly into the cigarette
lighter socket.
3. Activate the Bluetooth feature on
the phone, and set the phone to
search for Bluetooth devices.
4. Select the handsfree from the list
of found devices.
9252955_en1.fm Page 5 Monday, August 28, 2006 1:10 PM
ENGLISH
5. Enter the Bluetooth passcode
0000 to pair and connect the
handsfree to your phone. In some
phones you may need to make the
connection separately after
pairing.
If the pairing is successful, the
handsfree sounds a beep and appears
in the phone menu where you can
view the currently paired Bluetooth
devices. When the handsfree is
connected with your phone, the blue
indicator light is displayed.
You can set your phone to connect
with the handsfree automatically
when the handsfree is switched on. To
do this in Nokia phones, change your
paired device settings in the Bluetooth
menu.
To disconnect the handsfree from your
phone, pull the handsfree out from the
cigarette lighter socket, or disconnect
the handsfree in the Bluetooth menu
of the phone.
To reconnect the paired handsfree to
your phone, plug the handsfree into
the cigarette lighter socket.
To pair and connect the handsfree
with a new phone, first disconnect the
handsfree in the Bluetooth menu of
the currently connected phone, and
then pair and connect the new phone.
Call handling
To adjust the volume during a call, use
the volume keys on the handsfree.
To make a call, use your phone in the
normal way when the handsfree is
connected to your phone. Speak
9252955_en1.fm Page 6 Monday, August 28, 2006 1:10 PM
ENGLISH
toward the handsfree microphone. For
optimal performance, check that there
are no objects in front of the
microphone and that the microphone
is in front of the user, not beneath or
behind. The green indicator light is
displayed during a call.
If your phone supports last number
redial with the handsfree, press the
call key twice when no call is in
progress.
If your phone supports voice dialing
with the handsfree, press and hold the
call key when no call is in progress,
and proceed as described in the user
guide of your phone.
When you receive a call, you hear a
ringing tone through the handsfree
speaker and the green indicator light
flashes. To answer the call, press the
call key, or use the phone keys. To
reject the call, press the call key twice.
To transfer the active call between the
handsfree and your phone, press and
hold the call key.
To end a call, press the call key, or use
the phone keys.
Care and maintenance
Your device is a product of superior
design and craftsmanship and should be
treated with care. The suggestions below
will help you protect your warranty
coverage.
• Keep all accessories and
enhancements out of the reach of
small children.
• Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If your
9252955_en1.fm Page 7 Monday, August 28, 2006 1:10 PM
ENGLISH
device does get wet, allow it to dry
completely.
• Do not use or store the device in
dusty, dirty areas. Its moving parts
and electronic components can be
damaged.
• Do not store the device in hot areas.
High temperatures can shorten the
life of electronic devices, damage
batteries, and warp or melt certain
plastics.
• Do not store the device in cold areas.
When the device returns to its normal
temperature, moisture can form
inside the device and damage
electronic circuit boards.
• Do not attempt to open the device.
• Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and fine
mechanics.
• Do not use harsh chemicals, cleaning
solvents, or strong detergents to
clean the device.
• Do not paint the device. Paint can
clog the moving parts, microphone, or
speaker, and prevent proper
operation.
If the device is not working properly, take
it to the nearest authorized service
facility for service.
Additional safety information
■Vehicles
RF signals may affect improperly
installed or inadequately shielded
electronic systems in motor vehicles such
as electronic fuel injection systems,
electronic antiskid (antilock) braking
systems, electronic speed control
systems, and air bag systems. For more
9252955_en1.fm Page 8 Monday, August 28, 2006 1:10 PM
ENGLISH
information, check with the
manufacturer or its representative of
your vehicle or any equipment that has
been added.
Faulty installation or service may be
dangerous and may invalidate any
warranty that may apply to the device.
Check regularly that all wireless device
equipment in your vehicle is mounted
and operating properly. Do not store or
carry flammable liquids, gases, or
explosive materials in the same
compartment as the device, its parts, or
enhancements. For vehicles equipped
with an air bag, remember that air bags
inflate with great force. Do not place
objects, including installed or portable
wireless equipment in the area over the
air bag or in the air bag deployment area.
If in-vehicle wireless equipment is
improperly installed and the air bag
inflates, serious injury could result.
FCC/Industry
Canada notice
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: 1. This device may not cause
harmful interference; and 2. This device
must accept any interference received,
including interference that may cause
undesired operation. NOTE: Changes or
modifications not expressly approved by
Nokia could void the user's authority to
operate the equipment.
9252955_en1.fm Page 9 Monday, August 28, 2006 1:10 PM
