Introduction
6
1. Introduction
The Wireless Headset HS-11W can be connected to a
compatible phone that supports Bluetooth technology.
This allows you freedom to make and receive calls while
on the move or in the office.
Read this user guide carefully before using the headset.
In addition to this user guide, read also the user guide for
your phone, which provides important safety and
maintenance information. Keep the headset out of reach
of small children.
■Bluetooth wireless technology
The Bluetooth technology makes it possible to connect
compatible communication devices without using cables.
A Bluetooth connection does not require that the phone
and the headset be in line of sight, but both devices
HS-11W_en1_draft_04.fm Page 6 Tuesday, August 10, 2004 3:43 PM
Introduction
7
should be within 10 metres of each other. Connections
can be subject to interference from obstructions, such as
walls, or other electronic devices.
The Wireless Headset HS-11W is specially designed for
compatible Nokia phones that support Bluetooth
technology. The headset can, however, be used with any
compatible Bluetooth devices that support the
compatible Handsfree or Headset profiles. (A profile is a
set of Bluetooth commands that the phone uses to
control the headset).
The Wireless Headset HS-11W is compliant with the
Bluetooth Specification 1.1 supporting the following
profiles: Headset Profile 1.1, Handsfree Profile 1.0.
However, interoperability between the Wireless Headset
HS-11W and other Bluetooth-enabled products is not
guaranteed because it depends on compatibility. Check
with the manufacturers of other devices to determine
their compatibility with this device.
HS-11W_en1_draft_04.fm Page 7 Tuesday, August 10, 2004 3:43 PM
Getting started
8
2. Getting started
Note: The use of wireless devices may be restricted in
some situations. Observe any restrictions and obey all
signs and instructions concerning use of wireless
devices.
■Overview
The headset contains the following parts, as shown in
Figure 1???.
Power key (1): Switches the headset on and off. You can
also mute or unmute the ongoing call by pressing the
power key briefly.
Earphone (2): Relays the caller’s voice.
Indicator light (3): Displays the current status of the
headset.
HS-11W_en1_draft_04.fm Page 8 Tuesday, August 10, 2004 3:43 PM
Getting started
9
Volume key (4): Increases or decreases the earphone
volume during a call.
Microphone (5): Picks up your voice.
Answer/end key (6): Answers or ends the call. This key
can also be used for voice dialling, redialling and
switching an active call between the headset and the
compatible phone.
Charger connector (7)
Before you can start using the headset, you must:
• Charge the battery
• Pair a compatible phone with the headset
■Chargers and batteries
Check the model number of any charger before using it with this
device. The Wireless Headset HS-11W is intended for use with
the following chargers: AC-1, ACP-12, and LCH-12.
HS-11W_en1_draft_04.fm Page 9 Tuesday, August 10, 2004 3:43 PM
Getting started
10
Warning: Use only batteries and chargers approved
by Nokia for use with this particular enhancement.
The use of any other types may invalidate any
approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with
your dealer. When you disconnect the power cord of any
enhancement, grasp and pull the plug, not the cord.
■Charging the battery
This device has an internal, nonremovable, rechargeable
battery. Do not attempt to remove the battery from the
device as you may damage the device. Nokia
recommends to take it to the nearest authorized service
facility for replacement of the battery.
1. Connect the charger cable to the headset as shown in
Figure 2???.
2. Connect the charger to a wall outlet. The red indicator
light is displayed during charging. Charging the
HS-11W_en1_draft_04.fm Page 10 Tuesday, August 10, 2004 3:43 PM
Getting started
11
battery fully may take up to 2 hours depending on the
charger.
3. When the battery is fully charged, the green indicator
light is displayed. Disconnect the charger from the
wall outlet and the headset.
When the battery charge falls low
The fully charged battery has power for up to 6 hours of
talk-time and up to 160 hours of standby time. (In the
standby mode, the headset is switched on but no call is in
progress.)
When the battery is running out of power, the headset
beeps and the red indicator light starts to blink. Charge
the battery as described above.
■Switching the headset on or off
To switch on: Press and hold the power key for 2
seconds. The headset beeps and the green indicator light
HS-11W_en1_draft_04.fm Page 11 Tuesday, August 10, 2004 3:43 PM
Getting started
12
starts blinking fast. The blinking continues slower after
the headset is connected to your phone.
To switch off: Press and hold the power key for 2
seconds. The headset beeps and the red indicator light is
displayed briefly.
■Pairing the headset with a compatible
phone
1. Make sure that your phone is switched on.
2. Switch on the headset.
3. Enter the Bluetooth menu of your phone and make
sure that the Bluetooth feature is activated.
4. Enter the submenu where you can set the phone to
search for Bluetooth devices, and start the search.
5. Select the headset from the list.
6. Enter the passcode 0000 to associate ("pair") and
connect the headset to your phone.
HS-11W_en1_draft_04.fm Page 12 Tuesday, August 10, 2004 3:43 PM
Getting started
13
Once you have entered the passcode, your phone
becomes the default phone for the headset, if the
headset has not been previously paired with another
phone. See also Using the headset with several
phones on page 20.
The headset beeps and appears in the phone menu
where you can view the Bluetooth devices that are
currently paired with your phone.
7. Start using the headset (see page 17).
Disconnecting the headset from the
phone
You can disconnect the headset from your phone when,
for example, you want to use another Bluetooth device
with your phone.
The headset can be disconnected in the following ways:
• Switch off the headset.
HS-11W_en1_draft_04.fm Page 13 Tuesday, August 10, 2004 3:43 PM
Getting started
14
• Disconnect the headset in the Bluetooth menu of your
phone.
• Move the headset more than 10 meters away from the
phone.
The headset is also disconnected if its battery becomes
discharged.
Note that you do not need to delete the pairing with the
headset to disconnect it. When you reconnect a paired
headset, you are not asked for its passcode.
Connecting the paired headset to your
phone
To connect the headset to your phone, switch on the
headset or make the connection in the Bluetooth menu
of your phone.
You can set your phone to accept Bluetooth connection
requests from your paired headset. In this case, the
headset can connect to your phone automatically when
HS-11W_en1_draft_04.fm Page 14 Tuesday, August 10, 2004 3:43 PM
Getting started
15
it is switched on. In Nokia phones this can be done by
changing your paired devices settings in the Bluetooth
menu.
■Troubleshooting
If you cannot connect the headset to your phone, do as
follows:
• Make sure that the headset is switched on and paired
with your phone.
• Make sure that the Bluetooth feature is activated on
your phone.
• Check that the headset is within 10 metres of your
phone and that there are no obstructions between the
headset and the phone, such as walls or other
electronic devices.
• The pairing information list of the headset may be full.
The headset can store the information of up to eight
HS-11W_en1_draft_04.fm Page 15 Tuesday, August 10, 2004 3:43 PM
Getting started
16
phones at a time. If the list becomes full, reset the
headset to the original settings (see page 21).
• If the headset does not automatically reconnect to
the default or last used phone, press and hold the
answer/end key for 1 second.
HS-11W_en1_draft_04.fm Page 16 Tuesday, August 10, 2004 3:43 PM
Using the headset
17
3. Using the headset
Note: The use of wireless devices may be restricted in
some situations. Observe any restrictions, and obey all
signs and instructions concerning use of wireless
devices.
■Placing the headset on the ear
Slide the headset onto your ear as shown in Figure 3???.
■Making a call
When the headset is connected to your phone, make the
call by using your phone in the normal way.
■Redialling the last dialled number
Press the answer/end key twice briefly while no call is in
progress.
HS-11W_en1_draft_04.fm Page 17 Tuesday, August 10, 2004 3:43 PM
Using the headset
18
■Voice dialling
This functionality is only available if your phone supports
voice dialling. When no call is in progress, press and hold
the answer/end key for 1 second, and proceed as
described in the user guide of your phone.
■Answering and ending a call
Press the answer/end key to answer the call or to end the
currently active call.
You can also answer or end the call by using your phone
in the normal way.
■Rejecting a call
If you do not want to answer a call, briefly press the
answer/end key twice.
HS-11W_en1_draft_04.fm Page 18 Tuesday, August 10, 2004 3:43 PM
Using the headset
19
■Automatic answer
If the Automatic answer function is set on in your phone,
the phone automatically answers the incoming call after
one ring.
■Adjusting the earphone volume
Press the volume up key to increase or the volume down
key to decrease the volume. To adjust the volume quickly,
press and hold either of these keys for 1 second.
■Muting an ongoing call
You can mute or unmute the ongoing call by pressing the
power key briefly.
HS-11W_en1_draft_04.fm Page 19 Tuesday, August 10, 2004 3:43 PM
Using the headset
20
■Switching the call between phone and
headset
You can switch the active call between the headset and a
compatible Nokia phone.
To switch the call from the headset to a phone and vice
versa, press and hold the answer/end key for 1 second or
use the respective function in your phone.
■Using the headset with several phones
The headset can be paired with up to eight phones but
connected to only one phone at a time.
The phone that was first paired with the headset is called
the "default phone". The phone that was last used with
the headset is called the "last used phone".
If the headset is switched on within 10 metres of several
paired phones, the headset will try to connect to the
"default phone" within a few seconds.
HS-11W_en1_draft_04.fm Page 20 Tuesday, August 10, 2004 3:43 PM
Using the headset
21
If the headset cannot connect to the "default phone" (for
example, when it is switched off or its user rejects the
connection), the headset tries to connect to the "last
used phone" within a few seconds. If the headset cannot
connect to either of the phones, it remains discoverable
for other phones.
If you want to use the headset with a paired phone that is
not a "default phone" or "last used phone", make the
connection in the Bluetooth menu of your phone.
■Resetting the headset
You can reset the headset to its original settings, for
example, to change the default user of the headset.
When you reset the headset, all of its settings, including
pairing information, are cleared.
To reset the headset, press and hold the power key and
the volume up key for 10 seconds. After the headset has
HS-11W_en1_draft_04.fm Page 21 Tuesday, August 10, 2004 3:43 PM
Using the headset
22
been reset, it beeps twice, and the red and the green
indicator lights alternate for several seconds.
HS-11W_en1_draft_04.fm Page 22 Tuesday, August 10, 2004 3:43 PM
Battery information
23
4. Battery information
Your device is powered by a rechargeable battery. Take
good care of the battery and follow the guidelines below.
■Charging and Discharging
Your device is powered by a rechargeable battery. The full
performance of a new battery is achieved only after two or three
complete charge and discharge cycles. The battery can be
charged and discharged hundreds of times but it will eventually
wear out. When the talk and standby times are noticeably
shorter than normal despite the battery being fully charged,
contact your nearest qualified service facility for replacement of
the battery with Nokia approved batteries. Recharge your
battery only with Nokia approved chargers designated for this
device.
Unplug the charger from the electrical plug and the device when
not in use. Do not leave the battery connected to a charger.
Overcharging may shorten its lifetime. If left unused, a fully
HS-11W_en1_draft_04.fm Page 23 Tuesday, August 10, 2004 3:43 PM
Battery information
24
charged battery will lose its charge over time. Temperature
extremes can affect the ability of your battery to charge.
Use the battery only for its intended purpose. Never use any
charger or battery that is damaged.
Leaving the device in hot or cold places, such as in aclosed car in
summer or winter conditions, will reduce the capacity and
lifetime of the battery. Always try to keep the battery between
15°C and 25°C (59°F and 77°F). A device with a hot or cold
battery may not work temporarily, even when the battery is fully
charged. Battery performance is particularly limited in
temperatures well below freezing.
Do not dispose of batteries in a fire! Dispose of batteries
according to local regulations. Please recycle when possible. Do
not dispose as household waste.
HS-11W_en1_draft_04.fm Page 24 Tuesday, August 10, 2004 3:43 PM
Care and maintenance
25
Care and maintenance
Your device is a product of superior design and craftsmanship
and should be treated with care. The suggestions below will help
you protect your warranty coverage.
• Keep all accessories and enhancements out of the reach of
small children.
• Keep the device dry. Precipitation, humidity and all types of
liquids or moisture can contain minerals that will corrode
electronic circuits. If your device does get wet, remove the
battery, and allow the device to dry completely before
replacing it.
• Do not use or store the device in dusty, dirty areas. Its
moving parts and electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can
shorten the life of electronic devices, damage batteries, and
warp or melt certain plastics.
HS-11W_en1_draft_04.fm Page 25 Tuesday, August 10, 2004 3:43 PM
Care and maintenance
26
• Do not store the device in cold areas. When the device
returns to its normal temperature, moisture can form inside
the device and damage electronic circuit boards.
• Do not attempt to open the device other than as instructed
in this guide.
• Do not drop, knock, or shake the device. Rough handling can
break internal circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the device.
• Do not paint the device. Paint can clog the moving parts and
prevent proper operation.
All of the above suggestions apply equally to your device,
battery, charger, or any enhancement. If any device is not
working properly, take it to the nearest authorized service
facility for service.
HS-11W_en1_draft_04.fm Page 26 Tuesday, August 10, 2004 3:43 PM
FCC Notice—Nokia Wireless Headset HS-
11W
27
FCC Notice—Nokia Wireless
Headset HS-11W
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: 1.
This device may not cause harmful interference; and 2.
This device must accept any interference received,
including interference that may cause undesired
operation. This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
HS-11W_en1_draft_04.fm Page 27 Tuesday, August 10, 2004 3:43 PM
FCC Notice—Nokia Wireless Headset HS-
11W
28
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the
separation between the equipment and receiver. Connect
the equipment into an outlet on a circuit different from
that to which the receiver is connected. Consult the
dealer or an experienced radio/TV technician for help.
NOTE: FCC Radiation Exposure Statement: This
equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. This
transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
NOTE: Modifications not expressly approved by Nokia
could void the user's authority to operate the equipment.
HS-11W_en1_draft_04.fm Page 28 Tuesday, August 10, 2004 3:43 PM
