Nokia Bluetooth Headset
(HS-36W)
User Guide
9239251
Issue 1 EN
HS-36W_en1.fm Page 1 Thursday, March 10, 2005 4:26 PM
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product
HS-36W is in conformity with the provisions of the following Council Directive:
1999/5/EC. A copy of the Declaration of Conformity can be found at http://
www.nokia.com/phones/declaration_of_conformity/.
Copyright © 2005 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other
product and company names mentioned herein may be trademarks or tradenames of their
respective owners.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document without prior
notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer
nearest to you.
Unauthorized changes or modifications to this device may void the user's authority to
operate the equipment.
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
9239251/Issue 1 EN
HS-36W_en1.fm Page 2 Thursday, March 10, 2005 4:26 PM
3
Contents
1. Introduction ......................... 4
Bluetooth wireless technology .......... 4
2. Get started............................ 5
Charge the battery................................ 5
Switch the headset on or off ............. 6
Pair the headset with a compatible
phone ........................................................ 6
3. Basic use ............................... 7
Wear the headset on either ear ........ 7
Call handling........................................... 7
Store the headset properly ................. 8
Troubleshooting ..................................... 8
4. Battery information ............. 9
Care and maintenance ........... 10
FCC notice—Nokia Bluetooth
Headset (HS-36W)................. 11
HS-36W_en1.fm Page 3 Thursday, March 10, 2005 4:26 PM
Introduction
4
1. Introduction
The Nokia Bluetooth Headset (HS-36W) can be used with compatible
phones that support Bluetooth wireless technology. This allows you
freedom to make and receive calls while on the move or in the office.
Read this user guide carefully before using the headset. Read also the
user guide for your phone, which provides important safety and
maintenance information. Keep the headset out of reach of small
children.
■Bluetooth wireless technology
Bluetooth wireless technology allows you to connect compatible
communication devices without cables. A Bluetooth connection does
not require that the phone and the headset be in line of sight, but both
devices should be within 10 meters of each other. Connections may be
subject to interference from obstructions, such as walls, or other
electronic devices.
The HS-36W headset is compliant with the Bluetooth Specification 1.2
supporting the following profiles: Headset profile and Handsfree profile.
Interoperability between the HS-36W headset and other products with
Bluetooth technology is not guaranteed. Check with the manufacturers
of other devices to determine their compatibility with this device.
HS-36W_en1.fm Page 4 Thursday, March 10, 2005 4:26 PM
Get started
5
2. Get started
There may be restrictions on using Bluetooth wireless technology in
some locations. Check with your local authorities or service provider.
The headset contains the following parts:
• Indicator light (1)
• Volume keys (2)
• Charging socket (3)
• Answer/end key (4)
• Earhook (5)
Before you can start to use the headset, you must charge the battery,
and pair a compatible phone with the headset.
■Charge the battery
The headset has an internal, nonremovable, rechargeable battery. Do
not attempt to remove the battery from the device, as you may damage
the device.
This device is intended for use only with the supplied charger. The use of
any other types may invalidate any approval or warranty, and may be
dangerous.
1. Connect the charger cable to the
headset.
2. Connect the charger to a wall outlet.
The blue indicator light is
continuously displayed during
charging.
The headset is switched off and cannot be used during charging.
3. When the battery is fully charged, the blue indicator light switches
off. Disconnect the charger from the wall outlet and the headset.
HS-36W_en1.fm Page 5 Thursday, March 10, 2005 4:26 PM
Get started
6
When you disconnect the power cord of the charger, grasp and pull
the plug, not the cord.
The fully charged battery has power for up to 6 hours of talk-time or up
to 110 hours of standby time. (In the standby mode, the headset is
switched on but no call is in progress.)
When the battery is running out of power, the red indicator light lights
up. Charge the battery.
■Switch the headset on or off
To switch on, press the answer/end key for about 1 second. To switch off,
press and hold the answer/end key for about 5 seconds.
■Pair the headset with a compatible phone
Make sure that the headset is on, and put it in pairing mode by pressing
the answer/end key and the volume up (+) key at the same time over 5
seconds until the blue indicator light lights up. The indicator light
remains on for 5 minutes, during which you can pair the headset with a
compatible mobile phone.
1. Set the phone to search for Bluetooth devices. See the user guide of
your phone for instructions.
2. When your phone finds the HS-36W headset, confirm the pairing
from your phone.
3. When prompted for the Bluetooth passcode of the headset, enter
0000.
If the pairing was unsuccessful, try to pair the devices again.
You only need to pair the headset with your phone once.
If the pairing was successful, the blue indicator light starts to flash. The
headset is now in the standby mode and ready for use.
HS-36W_en1.fm Page 6 Thursday, March 10, 2005 4:26 PM
Basic use
7
3. Basic use
■Wear the headset on either ear
The HS-36W headset is ready to wear on the right ear. If you want to use
it on the left ear, gently flip (1) and rotate the earhook (2).
■Call handling
To answer a call, press the answer key on your mobile phone, or press the
answer/end key on the headset briefly. If you do not want to answer a
call, press and hold the answer/end key on the headset for about 1
second.
To make a call, dial the number with your mobile phone, and press the
answer key on your phone. The call is automatically transferred to the
headset.
To redial the last called number, press and hold the answer/end key on
your headset for about 1 second when no call is in progress.
If your phone supports voice dialing and there is no call in progress,
press the answer/end key on the headset briefly, and proceed with voice
dialing as described in the user guide of your phone. For the best result,
record the voice tag through your headset.
To increase or decrease the volume of the headset, press either volume
key until the satisfactory volume level is reached.
To end a call, press the end key on your mobile phone, or press the
answer/end key on your headset briefly.
HS-36W_en1.fm Page 7 Thursday, March 10, 2005 4:26 PM
Basic use
8
■Store the headset properly
Always store the headset with the power off and safely protected.
Avoid storage in high temperatures (above 60°C/134°F), such as in a hot
vehicle or in direct sunlight. Storage in high temperatures can degrade
performance and reduce the battery life. Low temperatures (down to -
10°C/14°F) shorten the battery life and may affect operation.
Do not expose the headset to rain or other liquids.
■Troubleshooting
The audio quality is poor.
For optimal performance, wear the headset and your mobile phone on
the same side of your body or in line of sight.
I have pairing problems even though my phone indicates otherwise.
You may have deleted the headset pairing in your mobile phone. Pair the
devices again.
There is no audio in the headset. Do the following:
• Increase the volume on the headset by pressing the volume up (+)
key.
• Ensure that the headset is paired with the phone.
• Make sure that the phone is connected to the headset. If not, try to
pair the devices again.
HS-36W_en1.fm Page 8 Thursday, March 10, 2005 4:26 PM
Battery information
9
4. Battery information
Your device is powered by a rechargeable battery. The full performance
of a new battery is achieved only after two or three complete charge
and discharge cycles. The battery can be charged and discharged
hundreds of times but it will eventually wear out. Recharge your battery
only with the charger supplied with this device.
Unplug the charger from the electrical plug and the device when not in
use. Do not leave the battery connected to a charger. Overcharging may
shorten its lifetime. If left unused, a fully charged battery will lose its
charge over time. Temperature extremes can affect the ability of your
battery to charge.
Use the battery only for its intended purpose. Never use any charger or
battery that is damaged.
Leaving the device in hot or cold places, such as in aclosed car in
summer or winter conditions, will reduce the capacity and lifetime of
the battery. Always try to keep the battery between 15°C and 25°C (59°F
and 77°F). A device with a hot or cold battery may not work temporarily,
even when the battery is fully charged. Battery performance is
particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire! Dispose of batteries according to
local regulations. Please recycle when possible. Do not dispose as
household waste.
HS-36W_en1.fm Page 9 Thursday, March 10, 2005 4:26 PM
Care and maintenance
10
Care and maintenance
Your device is a product of superior design and craftsmanship and should be
treated with care. The suggestions below will help you protect your warranty
coverage.
• Keep all accessories and enhancements out of the reach of small children.
• Keep the device dry. Precipitation, humidity and all types of liquids or
moisture can contain minerals that will corrode electronic circuits. If your
device does get wet, remove the battery and allow the device to dry
completely before replacing it.
• Do not use or store the device in dusty, dirty areas. Its moving parts and
electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic
circuit boards.
• Do not attempt to open the device other than as instructed in this guide.
• Do not drop, knock, or shake the device. Rough handling can break internal
circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean
the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper
operation.
All of the above suggestions apply equally to your device, battery, charger, or any
enhancement. If any device is not working properly, take it to the nearest
authorized service facility for service.
HS-36W_en1.fm Page 10 Thursday, March 10, 2005 4:26 PM
FCC notice—Nokia Bluetooth Headset (HS-36W)
11
FCC notice—Nokia Bluetooth Headset
(HS-36W)
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: 1. This device may not cause harmful
interference; and 2. This device must accept any interference received,
including interference that may cause undesired operation. This
equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures: Reorient or relocate the receiving antenna. Increase the
separation between the equipment and receiver. Connect the
equipment into an outlet on a circuit different from that to which the
receiver is connected. Consult the dealer or an experienced radio/TV
technician for help. NOTE: FCC Radiation Exposure Statement: This
equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
HS-36W_en1.fm Page 11 Thursday, March 10, 2005 4:26 PM
