Nokia Bluetooth Headset BH-101
9206519/1
ENGLISH
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that
this HS-94W product is in compliance with
the essential requirements and other
relevant provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity can be
found at http://www.nokia.com/phones/
declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Nokia and Nokia Connecting People are
registered trademarks of Nokia Corporation.
Other product and company names
mentioned herein may be trademarks or
tradenames of their respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in this
document in any form without the prior
written permission of Nokia is prohibited.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Nokia operates a policy of ongoing
development. Nokia reserves the right to
make changes and improvements to any of
the products described in this document
without prior notice.
To the maximum extent permitted by
applicable law, under no circumstances shall
Nokia or any of its licensors be responsible
for any loss of data or income or any special,
incidental, consequential or indirect
damages howsoever caused.
The contents of this document are provided
"as is". Except as required by applicable law,
no warranties of any kind, either express or
implied, including, but not limited to, the
implied warranties of merchantability and
fitness for a particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia reserves
the right to revise this document or
withdraw it at any time without prior notice.
The availability of particular products may
vary by region. Please check with your Nokia
dealer for details.
Export Controls
This device may contain commodities,
technology or software subject to export
laws and regulations from the US and other
countries. Diversion contrary to law is
prohibited.
ENGLISH
Introduction
The Nokia Bluetooth Headset BH-101
allows you to make and receive calls
while on the move. You can use the
headset with compatible phones that
support Bluetooth wireless
technology.
Read this user guide carefully before
using the headset. Also, read the user
guide for your phone, which provides
important safety and maintenance
information. Keep the headset out of
the reach of small children.
Bluetooth wireless technology
Bluetooth wireless technology allows
you to connect compatible devices
without cables. The phone and the
headset do not need to be in line of
sight, but they should be within
10 metres (33 feet) of each other.
Connections may be subject to
interference from obstructions, such
as walls, or other electronic devices.
The headset complies with the
Bluetooth Specification 2.0 + EDR
that supports the Headset Profile 1.1
and Hands-Free Profile 1.5. Check
with the manufacturers of other
devices to determine their
compatibility with this device.
Get started
The headset contains the following
parts shown on the title page:
indicator light (1), charger connector
(2), multifunction key (3), microphone
(4), volume keys (5), earloop (6), and
earpiece (7).
ENGLISH
Before using the headset, you must
charge the battery and pair the
headset with a compatible phone.
Parts of the device are magnetic. Metallic
materials may be attracted to the device.
Do not place credit cards or other
magnetic storage media near the device,
because information stored on them may
be erased.
Chargers
This device is intended for use when
supplied with power from the following
chargers: AC-3, AC-4, and DC-4.
Warning: Use only chargers
approved by Nokia for use
with this particular
enhancement. The use of any other types
may invalidate any approval or warranty,
and may be dangerous.
When you disconnect the power cord of
any enhancement, grasp and pull the
plug, not the cord.
Charge the battery
Before charging the battery, carefully
read “Battery information”.
1. Connect the charger to a wall
outlet.
2. Connect the charger cable to the
charger connector. The indicator
light is red during charging. It may
take a while before charging starts.
Charging the battery fully may take
up to 2 hours.
3. When the battery is fully charged,
the indicator light turns green.
Disconnect the charger from the
headset and the wall outlet.
The fully charged battery has power
for up to 8 hours of talk time or up to
180 hours of standby time. However,
the talk and standby times may vary
with different compatible Bluetooth
devices, usage settings, usage styles,
and environments.
ENGLISH
When battery power is low, the
headset beeps once every minute and
the red indicator light flashes slowly.
Switch on or off
To switch on, press and hold the
multifunction key for about 5 seconds.
The headset beeps, and the green
indicator light starts to flash. The
headset tries to connect to the most
recently used device.
To switch off, press and hold the
multifunction key (for about 5
seconds) until the headset beeps and
the red indicator light flashes once.
Pair the headset
1. Ensure that your phone is switched
on and the headset is switched off.
2. Press and hold the multifunction
key (for about 8 seconds) until the
green indicator light starts to flash
quickly.
3. Activate the Bluetooth feature on
the phone, and set the phone to
search for Bluetooth devices.
4. Select the headset from the list of
found devices.
5. Enter the passcode 0000 to pair
and connect the headset to your
phone. In some phones, you may
need to make the connection
separately after pairing. You only
need to pair the headset with your
phone once.
If the pairing is successful, the
headset appears in the phone menu
where you can view the currently
paired Bluetooth devices.
When the headset is connected to
your device and is ready for use, the
green indicator light flashes slowly.
ENGLISH
Basic use
Place the headset on the ear
The headset is ready to be used on the
right ear. Slide the earloop over your
ear (???), and gently push the earpiece
into your ear. You can bend the
earloop to make it fit the shape of
your ear. Point the headset towards
your mouth (???). To use the headset
on the left ear, flip the earloop so that
the loop is to the left of the “Nokia“
logo (???).
Call handling
To make a call, use your phone in the
normal way when the headset is
connected to your phone.
If your phone supports last number
redialling with the headset, press the
multifunction key twice while no call
is in progress.
If your phone supports voice dialling
with the headset, press and hold the
multifunction key for about 2 to 3
seconds until the phone start voice
dialling, and proceed as described in
the user guide of the phone. Voice
dialling cannot be used during a call.
To answer or end a call, press the
multifunction key. To reject an
incoming call, press this key twice.
To adjust the headset volume during a
call, press either volume key.
To switch the call between the
headset and a compatible phone,
press and hold the multifunction key
for about 2 to 3 seconds.
Clear settings or reset
To delete the pairings from the
headset, switch on the headset, and
press and hold the multifunction key
ENGLISH
and the volume up key for about 5
seconds until the indicator light
alternates between red and green.
To reset the headset if it stops
functioning, although it is charged,
press and hold the multifunction key,
and plug the headset into a charger.
Troubleshooting
If you cannot connect the headset to
your compatible device, check that
the headset is charged, switched on,
and paired with your device.
Battery information
Your device is powered by a rechargeable
battery. The battery can be charged and
discharged hundreds of times, but it will
eventually wear out. Recharge your
battery only with Nokia approved
chargers designated for this device. Use
of an unapproved charger may present a
risk of fire, explosion, leakage, or other
hazard.
If a battery is being used for the first time
or if the battery has not been used for a
prolonged period, it may be necessary to
connect the charger, then disconnect and
reconnect it to begin charging the
battery. If the battery is completely
discharged, it may take several minutes
before the charging indicator light is
displayed.
Unplug the charger from the electrical
plug and the device when not in use. Do
not leave a fully charged battery
connected to a charger, since
overcharging may shorten its lifetime. If
left unused, a fully charged battery will
lose its charge over time.
Always try to keep the battery between
15°C and 25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and
ENGLISH
lifetime of the battery. A device with a
hot or cold battery may not work
temporarily. Battery performance is
particularly limited in temperatures well
below freezing.
Do not dispose of batteries in a fire as
they may explode. Batteries may also
explode if damaged.
Never use any charger that is damaged.
Care and maintenance
Your device is a product of superior
design and craftsmanship and should be
treated with care. The following
suggestions will help you protect your
warranty coverage.
• Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If your
device does get wet, allow it to dry
completely.
• Do not use or store the device in
dusty, dirty areas. Its moving parts
and electronic components can be
damaged.
• Do not store the device in hot areas.
High temperatures can shorten the
life of electronic devices, damage
batteries, and warp or melt certain
plastics.
• Do not store the device in cold areas.
When the device returns to its normal
temperature, moisture can form
inside the device and damage
electronic circuit boards.
• Do not attempt to open the device.
• Do not drop, knock, or shake the device.
Rough handling can break internal
circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning
solvents, or strong detergents to
clean the device.
ENGLISH
• Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
If the product is not working properly,
take it to the nearest authorised service
facility for service.
Disposal
The crossed-out wheeled-bin
symbol on your product,
literature, or packaging reminds
you that all electrical and
electronic products, batteries, and
accumulators must be taken to separate
collection at the end of their working life.
This requirement applies to the European
Union and other locations where
separate collection systems are available.
Do not dispose of these products as
unsorted municipal waste.
By returning the products to collection
you help prevent uncontrolled waste
disposal and promote the reuse of
material resources. More detailed
information is available from the product
retailer, local waste authorities, national
producer responsibility organizations, or
your local Nokia representative. For the
product Eco-Declaration or instructions
for returning your obsolete product, go to
country-specific information at
www.nokia.com.
FCC/Industry
Canada notice
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: 1. This device may not cause
harmful interference; and 2. This device
must accept any interference received,
including interference that may cause
undesired operation. This equipment has
been tested and found to comply with the
limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and,
if not installed and used in accordance with
ENGLISH
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver. Connect the
equipment into an outlet on a circuit
different from that to which the receiver is
connected. Consult the dealer or an
experienced radio/TV technician for help.
NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be
co-located or operating in conjunction with
any other antenna or transmitter. NOTE:
Changes or modifications not expressly
approved by Nokia could void the user's
authority to operate the equipment.
