Nokia Bluetooth Speakers MD-7W
9205873/1
5
2
4
9
87
6
3
MD-7W_UG_en1_with_FCC&IC_notice.fm Page 1 Friday, September 7, 2007 8:29 PM
ENGLISH
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that
this MD-7W product is in compliance with
the essential requirements and other
relevant provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity can be
found at http://www.nokia.com/phones/
declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Nokia and Nokia Connecting People are
registered trademarks of Nokia Corporation.
Other product and company names
mentioned herein may be trademarks or
tradenames of their respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in this
document in any form without the prior
written permission of Nokia is prohibited.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Nokia operates a policy of ongoing
development. Nokia reserves the right to
make changes and improvements to any of
the products described in this document
without prior notice.
To the maximum extent permitted by
applicable law, under no circumstances shall
Nokia or any of its licensors be responsible
for any loss of data or income or any special,
incidental, consequential or indirect
damages howsoever caused.
The contents of this document are provided
"as is". Except as required by applicable law,
no warranties of any kind, either express or
implied, including, but not limited to, the
implied warranties of merchantability and
fitness for a particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia reserves
the right to revise this document or
withdraw it at any time without prior notice.
The availability of particular products may
vary by region. Please check with your Nokia
dealer for details.
Unauthorized changes or modifications to
this device may void the user's authority to
operate the equipment.
Export Controls
This device may contain commodities,
technology or software subject to export
MD-7W_UG_en1_with_FCC&IC_notice.fm Page 2 Friday, September 7, 2007 8:29 PM
ENGLISH
laws and regulations from the US and other
countries. Diversion contrary to law is
prohibited.
Introduction
Congratulations on your purchase.
With Nokia Bluetooth Speakers
MD-7W, you can listen to music from
your compatible mobile or music
device and enjoy the high-quality
audio.
You can connect the speakers to a
compatible device using Bluetooth
wireless technology or the supplied
cable. The cable also serves as an FM
radio antenna that you can use with
the FM radio of your music device (if it
has one).
Read this user guide carefully before
using the speakers. Also read the user
guide for the device that you connect
to the speakers, which provides
important safety and maintenance
information. Keep all accessories and
enhancements out of the reach of
small children.
Bluetooth wireless technology
Bluetooth wireless technology allows
you to connect compatible devices
without cables. A Bluetooth
connection does not require that the
speakers and the other device be in
line of sight, but both devices should
be within 10 meters (33 feet) of each
other. Connections may be subject to
interference from obstructions, such
as walls, or other electronic devices.
The speakers comply with the
Bluetooth Specification 2.0 + EDR
that supports Advanced Audio
MD-7W_UG_en1_with_FCC&IC_notice.fm Page 3 Friday, September 7, 2007 8:29 PM
ENGLISH
Distribution Profile (A2DP) 1.0 and
Audio/Video Remote Control Profile
(AVRCP) 1.0. Check with the
manufacturers of other devices to
determine their compatibility with
this device.
Getting started
Parts
The speakers contain the parts shown
on the title page: power and
Bluetooth indicator light (1), power
key (2), speakers (3), volume key (4),
stereo widening key (5), indicator light
for stereo widening (6), power
connector (7), audio connector (8),
and speaker connection cord (9).
Parts of the speakers are magnetic.
Metallic materials may be attracted to
the speakers. Do not place credit cards or
other magnetic storage media near the
speakers, because information stored on
them may be erased.
Chargers
Check the model number of any charger
before use with this device. This device is
intended for use when supplied with
power from the AC-4 charger.
Warning: Use only chargers
approved by Nokia for use
with this particular device.
The use of any other types may invalidate
any approval or warranty and may be
dangerous.
When you disconnect the power cord of
any enhancement, grasp and pull the
plug, not the cord.
Connect to power
The speakers can be powered by the
supplied charger or four AA batteries.
MD-7W_UG_en1_with_FCC&IC_notice.fm Page 4 Friday, September 7, 2007 8:29 PM
ENGLISH
Connect to wall outlet
To use the speakers with the charger,
connect the charger to a wall outlet,
and plug the charger cable to the
power connector.
If you use rechargeable batteries with
the speakers, the batteries are not
charged by the charger.
Install AA batteries
To install the batteries, ensure that
the speakers are switched off, and
press the release switch of the battery
cover at the back of each speaker. Lift
the cover.
Place the batteries as indicated in the
compartment. To close the cover,
insert the catch at the top of the cover
into the corresponding slot on the
speaker, and push the cover against
the speaker until it snaps into place.
During long periods where the
speakers are not used, remove the
batteries to prevent damage from
battery leakage.
When battery power is low, the orange
indicator light starts to flash, and the
speakers beep.
Switch the speakers on or off
To switch on, press and hold the power
key until the white indicator light
turns on.
To switch off, press and hold the
power key until the white indicator
light turns off.
Connect the speakers
You can connect the speakers to a
compatible music device (such as a
music player or mobile phone with a
music player feature) using Bluetooth
wireless technology or the supplied
cable. To use a Bluetooth connection,
the music device must support the
A2DP Bluetooth profile.
MD-7W_UG_en1_with_FCC&IC_notice.fm Page 5 Friday, September 7, 2007 8:29 PM
ENGLISH
Pair and connect using Bluetooth
wireless technology
The following instructions apply for a
mobile phone but the procedure is the
same for a music player, except that
you may not need to give the
Bluetooth passcode.
1. Ensure that the speakers are off
and that the phone is on.
2. Press and hold the power key for
about 5 seconds until the white
indicator light starts to flash.
3. Activate the Bluetooth feature on
the phone, and set it to search for
Bluetooth devices.
4. Select the speakers from the list of
found devices.
5. Enter the Bluetooth passcode
0000 to pair and connect the
speakers to the phone. In some
phones you may need to make the
connection separately after
pairing.
If the pairing is successful and the
speakers are in a Bluetooth
connection with the music device, the
white indicator light flashes about
every 5 seconds.
Connect using a cable
You can connect the speakers to a
compatible device with the supplied
CA-63U cable.
To connect the speakers to a device
that has a standard 3.5 mm audio
connector, plug the cable into the
audio connector on the speakers and
the other device.
When the speakers are connected to
the other device using the cable, the
white indicator is continuously on.
MD-7W_UG_en1_with_FCC&IC_notice.fm Page 6 Friday, September 7, 2007 8:29 PM
ENGLISH
Basic use
Listen to music
When the speakers are connected to a
compatible music device, start the
music playback on the device.
Warning: Listen to music at a
moderate level. Continuous
exposure to high volume may
damage your hearing.
To widen the stereo image of the
sound, check that this feature is off in
your music device, and press the
stereo widening key. The white
indicator light for stereo widening
turns on.
Adjust the volume
To set the volume of the speakers,
press either volume key. If the sound
level of the speakers becomes too low
when using battery power, change the
batteries.
Carry the speakers
To take the speakers with you, press
the speaker elements against each
other, and use the speaker connection
cord as a carrying strap.
Clear settings
To clear the volume and stereo
widening settings, switch off the
speakers. Press and hold the power
key, stereo widening key, and volume
up key at the same time.
MD-7W_UG_en1_with_FCC&IC_notice.fm Page 7 Friday, September 7, 2007 8:29 PM
ENGLISH
Care and maintenance
Your device is a product of superior
design and craftsmanship and should be
treated with care. The following
suggestions will help you protect your
warranty coverage.
• Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If your
device does get wet, allow it to dry
completely.
• Do not use or store the device in
dusty, dirty areas. Its moving parts
and electronic components can be
damaged.
• Do not store the device in hot areas.
High temperatures can shorten the
life of electronic devices, damage
batteries, and warp or melt certain
plastics.
• Do not store the device in cold areas.
When the device returns to its normal
temperature, moisture can form
inside the device and damage
electronic circuit boards.
• Do not drop, knock, or shake the device.
Rough handling can break internal
circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning
solvents, or strong detergents to
clean the device.
• Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
If the product is not working properly,
take it to the nearest authorised service
facility for service.
Disposal
The crossed-out wheeled-bin
symbol on your product,
literature, or packaging reminds
you that all electrical and
electronic products, batteries, and
accumulators must be taken to separate
collection at the end of their working life.
MD-7W_UG_en1_with_FCC&IC_notice.fm Page 8 Friday, September 7, 2007 8:29 PM
ENGLISH
This requirement applies to the European
Union and other locations where
separate collection systems are available.
Do not dispose of these products as
unsorted municipal waste.
By returning the products to collection
you help prevent uncontrolled waste
disposal and promote the reuse of
material resources. More detailed
information is available from the product
retailer, local waste authorities, national
producer responsibility organizations, or
your local Nokia representative. For the
product Eco-Declaration or instructions
for returning your obsolete product, go to
country-specific information at
www.nokia.com.
FCC/Industry
Canada notice
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: 1. This device may not cause
harmful interference; and 2. This device
must accept any interference received,
including interference that may cause
undesired operation. This equipment has
been tested and found to comply with the
limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and,
if not installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver. Connect the
equipment into an outlet on a circuit
different from that to which the receiver is
connected. Consult the dealer or an
MD-7W_UG_en1_with_FCC&IC_notice.fm Page 9 Friday, September 7, 2007 8:29 PM
ENGLISH
experienced radio/TV technician for help.
NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be
co-located or operating in conjunction with
any other antenna or transmitter. NOTE:
Changes or modifications not expressly
approved by Nokia could void the user's
authority to operate the equipment.
MD-7W_UG_en1_with_FCC&IC_notice.fm Page 10 Friday, September 7, 2007 8:29 PM
