Manual part 2
49
English
Press Options and select an
option to move the function
in the list.
2. When you have made all the
changes, press Done. To save the
changes, press Yes or to discard
the changes, press No.
Time and date settings
Clock
Press Menu, and select Settings,
Time and date settings and Clock.
Select Show clock (or Hide clock) to
show (or hide) the time on the top
right of the display in standby
mode. Select Set the time to adjust
the clock to the correct time, and
Time format to select 12-hour or 24-
hour time format.
Date
Press Menu, and select Settings,
Time and date settings and Date.
Select Show date (or Hide date) and
the date is shown (or hidden) on the
display when the phone is in
standby mode. Select Set the date to
adjust the date. You can also select
the date format.
If the battery is flat or removed
from the phone for a long time, you
may need to set the date and time
again.
Auto update of date and time
Press Menu, and select Settings,
Time and date settings and Auto-
update of date & time (network
service). To set the phone to
automatically update the time and
date according to the current time
zone, select On. To set the phone to
ask for a confirmation before the
update, select Confirm first.
Note that the automatic update of
the date and time will affect other
time related features (for example
alarm clock). These features will
always follow the updated time.
Updating may cause some alarms
that you have set to expire.
Call settings
Call divert
Press Menu, and select Settings,
Call settings and Call divert
(network service). With call divert,
you can direct your incoming calls
to another number, for example, to
your voice mailbox number. For
details, contact your service
provider. Divert options not
supported by your SIM card or your
network operator may not be
shown.
Select the divert option you want,
for example, select Divert if busy to
divert the voice calls when your
number is busy or when you reject
an incoming call.
RH-4_FCC_2003-4-16.fm Page 49 Friday, April 18, 2003 4:34 PM
50
To set the divert setting to on, select
Activate and then select the timeout
after which the call is diverted, if
this is available for the divert
option. To set the divert setting to
off, select Cancel, or select Check
status to check whether call divert
is activated or not. Check status is
only available for certain options.
Several divert options may be
active at the same time.
To see the divert indicators in
standby mode, see ”Standby mode”
on page 3.
Anykey answer
Press Menu, and select Settings,
Call settings and then Anykey
answer. Select On and you can
answer an incoming call by briefly
pressing any key, except ,
selection keys and ,
and .
Flip call handling setting
Opening or closing the flip cover
may or may not affect voice call
handling. You can set this by
yourself.
1. Press Menu, and select Settings,
Call settings, Flip call handling
setting.
2. Three options are listed:
•Answer & end calls (default
setting):
• Opening the flip cover
answers a voice call.
• Closing the flip cover
ends a voice call.
•None: Opening or closing the
flip cover does not affect the
status of the voice call.
•Answer calls only:
• Opening the flip cover
answers a voice call.
• Closing the flip cover
does not end a voice call.
Automatic redial
Press Menu, and select Settings,
Call settings and Automatic redial.
Select On, and your phone will
make a maximum of ten attempts to
connect the call after an
unsuccessful call attempt
(Depending on the network
environment).
Speed dialling
Press Menu, and select Settings,
Call settings and Speed dialling.
Select On and the names and phone
numbers assigned to the speed
dialling keys, from to ,
can be dialled by pressing and
holding the corresponding number
key.
Call waiting
Press Menu, and select Settings,
Call settings and Call waiting.
Select Activate and the network will
notify you of an incoming call
while you have a call in progress
RH-4_FCC_2003-4-16.fm Page 50 Friday, April 18, 2003 4:34 PM
51
English
(network service). See ”Handle a
waiting call” on page 11.
Summary after call
Press Menu, and select Settings,
Call settings, and Summary after
call. Select On. After each call, the
phone briefly displays the
approximate duration and cost of
the call (network service).
Send my caller identity
Press Menu, and select Settings,
Call settings and Send my caller
identity. Select Yes and your phone
number will be displayed to the
person you are calling (network
service). Select Set by network and
the setting agreed upon with your
service provider is used.
Line for outgoing calls
Line for outgoing calls is a network
service to select the phone line 1 or
2, that is, the subscriber number, for
making calls.
Press Menu, and select Settings,
Call settings and Line for outgoing
calls. If you select Line 2 and have
not subscribed to this network
service, you will not be able to
make calls. However, calls on both
lines can be answered regardless of
the selected line.
If supported by your SIM card, you
can prevent the line selection by
selecting the option Lock.
For more information on
availability, contact your network
operator or service provider.
Tip: In standby mode, you
can switch from one line to
the other by pressing and
holding .
Phone settings
Language
Press Menu, and select Settings,
Phone settings and Language.
Select the language for the display
texts. If Automatic is selected, the
phone selects the language
according to the information on the
SIM card.
Memory info
Press Menu, and select Settings,
Phone settings and Memory status.
Scroll to view the free memory, the
total used memory and the used
memory for each function.
You may also find the memory
information in the menu of some of
those functions, for example in
gallery.
Automatic keyguard
Note: When Keyguard is
on, calls may be possible to
the emergency number
programmed into your
phone (e.g. 112, or other official
emergency number). Key in the
emergency number and press .
RH-4_FCC_2003-4-16.fm Page 51 Friday, April 18, 2003 4:34 PM
52
The number is displayed only after
you have keyed in its last digit.
You can set the keypad of your
phone to lock automatically after a
period of time. When the phone is
in standby mode with no function in
use, and the set time is reached, the
keypad locks automatically to
prevent accidental phone calls.
Press Menu, and select Settings,
Phone settings and Automatic
keyguard.
• To activate the automatic
keyguard, select On. The phone
prompts Set delay:. Input the
time and press OK. You can set
the time from 10 seconds up to
60 minutes.
• To deactivate the automatic
keyguard, select Off.
Refer also to ”Keypad lock
(Keyguard)” on page 9.
Recognition timeout
You can set how fast the phone
recognise the strokes you write on
the touch-board.
1. Press Menu, and select Settings,
Phone settings and Recognition
timeout.
2. A list of three options is
displayed:
•Fast: The recognition time is
0.2 second.
•Medium: The recognition
time is 0.5 second. This is the
default setting.
•Slow: The recognition time is
0.8 second.
3. Press if necessary to
highlight the option you want,
and press Select.
Cell info display (network
service)
Press Menu, and select Settings,
Phone settings and Cell info
display. Select On to set the phone
to indicate when it is used in a
cellular network based on Micro
Cellular Network (MCN)
technology.
If the GPRS connection is set to
Always online, the cell identity may
not be received. In that case, set the
GPRS connection to When needed
to enable it, see “GPRS
connection”, 73.
Welcome note
Press Menu, and select Settings,
Phone settings and Welcome note.
Enter the note you would like to be
shown briefly when the phone is
switched on. To save the note, press
Options, and select Save.
Network selection
Press Menu, and select Settings,
Phone settings and Network
selection. Select Automatic and the
phone automatically selects one of
RH-4_FCC_2003-4-16.fm Page 52 Friday, April 18, 2003 4:34 PM
53
English
the cellular networks available in
your area.
If you select Manual, you can select
a network that has a roaming
agreement with your home network
operator. If No access is displayed,
you must select another network.
The phone stays in manual mode
until the automatic mode is selected
or another SIM card is inserted into
the phone.
Confirm SIM service actions
See ”SIM services (Menu 14)” on
page 82.
Help text activation
To set the phone to show or not to
show the help texts, press Menu,
and select Settings, Phone settings
and Help text activation.
Start-up tone
To set the phone to play or not to
play a start-up tone when the phone
is switched on, press Menu, and
select Start-up tone, Phone settings
and Start-up tone.
Display settings
Wallpaper
You can set your phone to display a
background image, known as
wallpaper, when the phone is in
standby mode. Some images are
pre-saved in the Gallery menu. You
may also be able to receive images
via multimedia messages,
download them from WAP pages or
transfer them with PC Suite from
your compatible PC and then save
them in Gallery. Your phone offers
support to JPEG, GIF, BMP and
PNG formats.
Select a wallpaper
1. Press Menu, and select Settings,
Display settings and Wallpaper.
2. Select Change image and the
folder list in the Gallery menu
will be shown.
3. Open the image folder and scroll
to the desired image.
4. To set the image as wallpaper,
press Options and select Set as
wallpaper.
To activate or deactivate the
wallpaper
Press Menu, and select Settings,
Display settings and Wallpaper. To
activate/deactivate the wallpaper,
select On/Off, respectively.
Colour schemes
You can change the colour in some
display components, for example,
indicators and signal bars.
Press Menu, and select Settings,
Display settings and Colour
schemes. Select the desired colour
scheme.
Operator logo
To set your phone to display or hide
the operator logo, press Menu, and
select Settings, Display settings and
RH-4_FCC_2003-4-16.fm Page 53 Friday, April 18, 2003 4:34 PM
54
Operator logo. If you have not
saved any operator logo, this menu
is dimmed.
Note that the operator logo is not
displayed when the phone activates
the screen saver.
For more information on
availability of an operator logo via
test messages, MMS or WAP,
contact your network operator or
service provider. See also ”PC
Suite” on page 83.
Screen saver
The digital clock screen saver is
used for power saving in standby
mode. It is activated when no
function of the phone has been used
for a certain time. Press any key to
deactivate the screen saver. The
screen saver is also deactivated
when the phone is out of the
network coverage area.
Press Menu, and select Settings,
Display settings and Screen saver
timeout. Select the timeout after
which the digital clock display will
be activated. The length of the
timeout can vary from 5 seconds to
60 minutes.
Note that the screen saver overrides
all the graphics and texts on the
display in standby mode.
Display brightness
You can change the display
brightness level used on the phone
display.
Press Menu, and select Settings,
Display settings and Display
brightness. Scroll with and to
decrease and increase the
brightness level, and press OK to
accept it.
Tone settings
Press Menu, and select Settings and
then Tone settings. You can find the
same settings in the Profiles menu,
see ”Profiles (Menu 4)” on page 48.
Note that the settings you make,
will change the settings in the active
profile.
Select Incoming call alert to choose
how the phone notifies you of an
incoming voice call. The options
are Ringing, Ascending, Ring once,
Beep once and Off.
Select Ringing tone for incoming
voice calls. To select ringing tones
that have been saved in the Gallery,
select Open gallery from the
ringing tone list.
Select Ringing volume and
Vibrating alert for incoming voice
calls and messages. The vibrating
alert does not work when the phone
is connected to a charger.
Tip: If you receive a ringing
tone via infrared connection
or by downloading, you can
save the ringing tone in the Gallery.
Select Message alert tone to set the
alert tone for the incoming
messages, Keypad tones, or
RH-4_FCC_2003-4-16.fm Page 54 Friday, April 18, 2003 4:34 PM
55
English
Warning tones to set the phone to
sound tones for example, when the
battery is running out of power.
Select Alert for to set the phone to
ring only upon calls from phone
numbers that belong to a selected
caller group. Scroll to the caller
group you want or All calls and
press Mark.
Enhancement settings
The enhancement settings menu is
shown only if the phone is or has
been connected to a compatible
enhancement.
Press Menu, and select Settings and
Accessory settings. You can select
Headset, Handsfree,or Loopset, if
a corresponding compatible
enhancement is or has been
connected to the phone.
• Select Default profile to select
the profile that you want to be
automatically activated when
you connect to the selected
enhancement. You can select
another profile while the
enhancement is connected.
• Select Automatic answer to set
the phone to answer an
incoming call automatically
after five seconds. If the
Incoming call alert is set to Beep
once or Off, automatic answer
will not be in use.
• Select Lights to set the lights
permanently On. Select
Automatic to set the lights on for
15 seconds after a keypress. The
Lights option is available only
when Handsfree is selected.
Security settings
Note: When security
features that restrict calls
are in use (call barring,
closed user group and fixed
dialling), calls may be possible to
certain emergency numbers in some
networks (e.g. 112, or other official
emergency numbers).
Press Menu, and select Settings and
Security settings. Select
•PIN code request to set the
phone to ask for your PIN code
every time the phone is switched
on. Some SIM cards do not
allow the PIN code request to be
turned off.
•Call barring service (network
service) to restrict incoming
calls to and outgoing calls from
your phone. A barring password
is required.
•Fixed dialling to restrict your
outgoing calls and text messages
to selected phone numbers if this
function is supported by your
SIM card. The PIN2 code is
required.
When the fixed dialling is on,
GPRS connections are not
possible except while sending
text messages over a GPRS
RH-4_FCC_2003-4-16.fm Page 55 Friday, April 18, 2003 4:34 PM
56
connection (network service). In
this case, the recipient’s phone
number and the message centre
number have to be included on
the fixed dialling list.
•Closed user group. Closed user
group is a network service that
specifies the group of people
whom you can call and who can
call you. For more information
contact your network operator or
service provider.
•Security level.
• If you select Phone, then the
phone asks for the Security
code when a new SIM card is
used.
• If you select Memory, then
the phone asks for the
Security code when memory
in use is going to be changed
from SIM card to others, (see
”Phone book settings” on
page 43), or entries in the
memory in use will be copied
to another memory (”Copy in
phone book” on page 45).
•Access codes to change the
security code, PIN code, PIN2
code or barring password. Codes
can only include numbers from
0 to 9.
Restore factory settings
To reset some of the menu settings
to their original values, press Menu,
and select Settings and Restore
factory settings. Key in the security
code and press OK.
■Gallery
(Menu 6)
Note: Your
phone must be switched on
to use this function. Do not
switch the phone on when wireless
phone use is prohibited or when it
may cause interference or danger.
In Gallery you can manage images,
photos and tones saved in your
phone.
The gallery uses shared memory,
see ”Shared memory” on page 0.
1. Press Menu and select Gallery.
The list of options is shown.
2. Select View folders to open the
list of folders.
Other available options are:
•Add folder to add a new
folder. Key in a name for the
folder and press OK.
•Delete folder to select the
folder you want to delete.
You cannot delete the
original folders on the phone.
•Rename folder to select the
folder you want to rename.
You cannot rename the
original folders on the phone.
•Gallery downloads to
download more images and
tones. Select Image
RH-4_FCC_2003-4-16.fm Page 56 Friday, April 18, 2003 4:34 PM
57
English
downloads or Tone
downloads, respectively. The
list of available browser
bookmarks is shown. Select
More bookmarks to access
the list of bookmarks in the
Services menu, see
”Bookmarks” on page 78.
Select the appropriate
bookmark to connect to the
desired page. If the
connection fails, you may not
be able to access the page
from the service whose
connection settings are
currently active. In this case,
enter the Services menu and
activate another set of service
settings, see ”Making a
connection to a service” on
page 75. Try again to connect
to the page.
For the availability of
different services, pricing
and tariffs, contact your
network operator and/or
service provider. Download
content only from the sources
you trust.
3. Open the folder you want and
the list of files in the folder is
shown. Photos, Graphics and
Tones are the original folders in
the phone.
Press Options and some of the
following options are available:
•Open to open the selected
file.
•Delete to delete the selected
file.
•Send to send the selected file
via MMS to compatible
devices.
•Move to move a file to
another folder.
•Rename to give a new name
to the file.
•Set as wallpaper to set the
selected image file as
wallpaper.
•Set as ring tone to set the
selected sound file as the
ringing tone.
•Details to see the details of
the file, for example the size
of the file.
•Sort to sort the files and
folders by date, type, name or
size.
•Delete all to delete all the
files in the selected folder.
•Edit image to insert text, a
frame or clip-art to the
selected picture.
4. Open the file you want. Press
Options and some of the
following options may be
available:
•Play (Pause) to listen to or to
view a sound or image file
RH-4_FCC_2003-4-16.fm Page 57 Friday, April 18, 2003 4:34 PM
58
that is contained in the
message.
•Zoom to increase the size of
the image that is contained in
the message.
•Mute audio (Unmute audio)
to mute (unmute) the sound
file.
•Set contrast to adjust the
contrast level of the image.
•Set as wallpaper to set the
selected image file as
wallpaper.
•Set as ring tone to set the
selected sound file as the
ringing tone.
•Edit image to insert text, a
frame or clip-art to the
selected picture.
•Details to see the details of
the file, for example the size
of the file.
•Delete to delete the selected
file.
•Send to send the selected file
via MMS.
•Rename to give a new name
to the file.
•View in sequence to view the
files in the folder
sequentially.
Note that copyright protections may
prevent some images, ringing tones
and other content from being
copied, modified, transferred or
forwarded.
■Organiser (Menu
7)
Note: Your phone must be
switched on to use the
functions in the Organiser
menu. Do not switch the
phone on when wireless phone use
is prohibited or when it may cause
interference or danger.
Alarm clock
The alarm clock uses the time
format set for the clock. Even when
the phone is switched off, the
previouly set alarm will still work
providing that there is enough
power in the battery.
Press Menu, and select Alarm
clock.
•Select Alarm time, enter the
alarm time and press OK.
To change the alarm time, select
On.
•Select Alarm tone and select the
default alarm tone.
When the alarm time expires
The phone will sound an alert tone,
and flash Alarm! and the current
time on the display.
Press Stop to stop the alarm. If you
let the phone continue to sound the
alarm for a minute or press Snooze,
RH-4_FCC_2003-4-16.fm Page 58 Friday, April 18, 2003 4:34 PM
59
English
the alarm stops for about ten
minutes and then resumes.
If the alarm time is reached while
the phone is switched off, the phone
switches itself on and starts
sounding the alarm tone. If you
press Stop, the phone asks whether
you want to activate the phone for
calls, Switch the phone on?. Press
No to switch off the phone or Yes to
make and receive calls.
Note: Do not press Yes
when wireless phone use is
prohibited or when it may
cause interference or danger.
Calendar
The calendar helps you to keep
track of reminders, calls that you
need to make, meetings, and
birthdays.
The calendar uses shared memory.
Refer to ”Shared memory” on page
0.
Press Menu, and select Organiser
and Calendar.
Tip: To quickly open the
Calendar menu, press in
standby mode.
Scroll to the day you want. The
current day is indicated by a frame
around the day. If there are any
notes set for the day, the day is in
bold type. To view the day notes,
press Options and select Day notes.
To view a single note, scroll to the
note you want to view, press
Options and select View. The note
view allows you to view the details
of the selected note. You can scroll
through the note.
The other options for the
calendar views may include:
• Options for making a note, or for
sending a note via IR, or as a
note directly to another
compatible device’s calendar or
as a text message.
• Options for deleting, editing,
moving and repeating a note and
for copying a note to another
day.
•Settings to set the date, time,
date or time format, or the first
day of the week. In the Auto-
delete option you can set the
phone to delete old notes
automatically after a specified
time. However, the repeat notes,
for example, birthday notes, will
not be deleted.
Making a calendar note
Press Menu, and select Organiser
and Calendar. Scroll to the date you
want, press Options and select
Make a note. Select one of the
following note types:
• Meeting - Enter the note (or
press Options and search for the
name in the phone book). Press
Options and select Save. Enter
RH-4_FCC_2003-4-16.fm Page 59 Friday, April 18, 2003 4:34 PM
60
the location for the meeting and
press Options and select Save.
Enter the start time for the
meeting and press OK, and then
the end time and press OK. To
set the alarm for the note, select
With tone or Silent (no alarm
tone) and then set the alarm
time.
• Call - Enter the phone
number, press Options and
select Save. Enter the name,
press Options and select Save.
(Instead of entering the phone
number, press Options to search
for the name and number in the
phone book.) Then enter the
time for the call and press OK.
To set the alarm for the note,
select With tone or Silent (no
alarm tone) and then set the
alarm time.
• Birthday - Enter the person’s
name (or press Options and
search for it in the phone book),
press Options and select Save.
Then enter the year of birth, and
press OK. To set the alarm for
the note, select With tone or
Silent (no alarm tone) and then
set the alarm time.
• Memo - Enter the note, press
Options and select Save. Enter
the end day for the note and
press OK. To set the alarm for
the note, select With tone or
Silent (no alarm tone) and then
set the alarm time.
• Reminder - Enter the subject
for the reminder, press Options
and select Save. To set the alarm
for the note, select Alarm on and
then set the alarm time.
When you have set the alarm, the
indicator is displayed when you
view the notes.
When the phone sounds an
alarm for a note
The phone beeps, and displays the
note. With a call note on the
display, you can call the displayed
number by pressing . To stop
the alarm and view the note, press
View. To stop the alarm without
viewing the note, press Exit. Note
the alarm you set here will not work
when the phone is switched off.
To-do list
You can save a note for a task that
you have to do, select a priority
level for the note and mark it as
done when you have completed it.
You can sort the notes by priority or
by date.
The to-do list uses shared memory.
Refer to ”Shared memory” on page
0.
Press Menu, select Organiser, then
To-do list. The list of notes is
shown. Press Options, or scroll to
the desired note and press Options.
• To add a new task, select Add.
Enter the subject for the note.
RH-4_FCC_2003-4-16.fm Page 60 Friday, April 18, 2003 4:34 PM
61
English
When you have keyed in the
maximum number of characters
for a task, no further characters
are accepted. Press Options and
select Save. Select the priority
for the task, High, Medium, or
Low. The phone automatically
sets the deadline without an
alarm for the task.
• You can also view and delete the
selected task and delete all the
tasks that you have marked as
done. You can sort the tasks by
priority or by deadline, send a
task to another phone, save a
task as a calendar note, or access
the calendar.
While viewing a task, you can
also, for example, select an
option to edit the selected task,
edit the deadline or priority for
the task, or mark the task as
done.
Notes
Note:
Your phone must be
switched on to use this
function. Do not switch the phone
on when wireless phone use is
prohibited or when it may cause
interference or danger.
You can use the Notes application
for writing and sending notes via
IR, SMS or MMS.
The Notes application uses shared
memory, see “Shared memory”, 0.
1. To access Notes, press Menu
and select Notes, or type any
character when the messaging
keyboard is open. The phone
will ask you to set the date and
time, if they have not already
been set when you start to write
a note.
2. Press Options and select Make a
note.
3. Write with the stylus or key in
the note, see “Handwriting input
method”, 14 or “Keypad input
methods”, 20, and select Save.
You can insert the current time
and date to the note. If there is
not enough space to insert them
to the note, the phone will ask
you to delete the appropriate
number of characters from your
note.
You can also send the note via
IR, MMS, or as a text message
(SMS). If the note is too long to
be sent as a text message, the
phone will ask you to delete the
appropiate number of characters
from your note.
The other options for notes
include options for viewing,
deleting, and editing a note.
While editing a note, you can
also exit the text editor without
saving the changes.
RH-4_FCC_2003-4-16.fm Page 61 Friday, April 18, 2003 4:34 PM
62
■Dictionary
(Menu 8)
In Dictionary, you can look up a
Chinese word for English
translation, and look up an English
word for Chinese translation.
Look up a word in the
Dictionary
1. In standby mode, press Menu,
scroll to Dictionary and press
Select.
2. If necessary, change the input
mode to Chinese if you want to
look up a Chinese word and
change the input mode to
English if you want to look up an
English word.
Refer to “Handwriting input
method”, 14 for handwriting
input method.
Refer to “Keypad input
methods”, 20 for keypad input
method. Note that the next
Chinese character prediction is
not available.
3. Input the Chinese or English
word.
A list of words is shown after
you input the first character or
letter. If you input more
characters and letters, the list of
words changes accordingly.
4. If necessary, press and to
move the highlight to the desired
English or Chinese word.
Press Select. If you look up fa
Chinese word, the word and its
English translation is shown. If
you look up an English word, the
word, its pronunciation, gender
and Chinese translation is
shown.
5. If you wish, you can press and
to see the translation of other
Chinese or English words on the
list.
Look up the synonym or
antonym of an English
word
After you find the translation of an
English word, you can also look up
the synonym or antonym of the
English word if you wish.
1. First find the English word in the
Dictionary. Refer to “Look up a
word in the Dictionary”, 62.
2. When the translation of the word
is displayed, press Options.
3. If the synonym and/or antonym
of the word exits, Synonyms and/
or Antonyms is displayed in the
option’s list.
Press to highlight Synonyms
or Antonyms, and press Select.
4. A list of synonyms or antonyms
is displayed.
To see more about the words in
the list, operate according to
steps 4 and 5 in “Look up a word
in the Dictionary”, 62.
RH-4_FCC_2003-4-16.fm Page 62 Friday, April 18, 2003 4:34 PM
63
English
■Games (Menu 9)
Note: Your phone
must be switched on to use
this function. Do not switch
the phone on when wireless phone
use is prohibited or when it may
cause interference or danger.
Launching a game
1. Press Menu, and select Games
and Select game.
2. Scroll to a game or a game set
(the name depends on the game).
3. Press Options and select Open
or press . If the selection is a
single game it will be launched.
Otherwise, a list of games in the
selected game set is displayed.
To launch a single game, scroll
to the desired game and press
Options and select Open, or
press .
Note that running some games
may consume the phone’s
battery faster (and you may need
to connect the phone to the
charger).
Other options available for a
game or game set
Options for games, see ”Other
options available for an application
or application set” on page 64.
Game services
Press Menu, and select Games and
Game downloads. The list of
available WAP bookmarks is
shown. Select More bookmarks to
access the list of WAP bookmarks
in the Services menu, see
”Bookmarks” on page 78.
Note that your phone may have
some pre-installed bookmarks for
sites not affiliated to Nokia. Nokia
does not warrant or endorse these
sites. If you choose to access them,
you should take the same
precautions, for security or content,
as you would with any Internet site.
Select the appropriate bookmark to
connect to the desired WAP page. If
the connection fails, you may not be
able to access the WAP page from
the WAP service whose connection
settings are currently active. In this
case, enter the Services menu and
activate another set of service
settings, see ”Making a connection
to a service” on page 75. Try again
to connect to the WAP page.
For the availability of different
WAP services, pricing and tariffs,
contact your network operator and/
or the WAP service provider.
Note that when downloading a
game, it may be saved in the
Applications menu instead of the
Games menu.
Note that after you have
downloaded a game, the WAP
connection is still on. You need to
end the connection before
RH-4_FCC_2003-4-16.fm Page 63 Friday, April 18, 2003 4:34 PM
64
launching the game, otherwise you
may be charged for the connection.
Memory status for games
To view the amount of memory
available for game and application
installations, press Menu, and select
Games and Memory. See also
”Memory status for applications”
on page 66.
The games use shared memory.
Refer to ”Shared memory” on page
0.
Game settings
Press Menu, and select Games and
Settings to set sounds, lights and
shakes for the game. You can save
your Club Nokia membership
number, Club Nokia ID. For more
information on Club Nokia and the
game services, visit
www.club.nokia.com. Availability
may vary by country.
■Applications
(Menu 10)
Note: The phone must be
switched on to use this
function. Do not switch
on the phone when the use of a
wireless phone is prohibited or
when it may cause interference or
danger.
Note that after you have
downloaded an application, the
WAP connection is still on. You
need to end the connection before
launching the application,
otherwise you may be charged for
the connection.
Launching an application
1. Press Menu, and select
Applications and Select
application.
2. Scroll to an application or an
application set (the name
depends on the application).
3. Press Options and select Open
or press . If the selection is a
single application it will be
launched.
Otherwise, a list of applications
in the selected application set is
displayed. To launch a single
application, scroll to the desired
application and press Options
and select Open, or press .
Note that running some
applications may consume the
phone’s battery faster (and you
may need to connect the phone
to the charger).
Other options available for
an application or
application set
•Delete to delete the application
or application set from the
phone.
RH-4_FCC_2003-4-16.fm Page 64 Friday, April 18, 2003 4:34 PM
65
English
Note that if you delete a pre-
installed application or an
application set from your phone,
you may be able to download it
again to your phone from the
Nokia Software Market,
www.softwaremarket.nokia.co
m/wap. Note the availability
may vary in different markets.
•Web access to restrict the
application from accessing the
network. Select Ask first and the
phone asks for net access,
Allowed to allow the net access,
or Not allowed not to allow the
net access.
•Update version to check if a new
version of the application is
available for download from the
WAP service s .
•Web page to provide further
information or additional data
for the application from an
Internet page. This feature needs
to be supported by the network.
It is only shown if an Internet
address has been provided with
the application.
•Details to give additional
information about the
application.
Download an application
You can download new JavaTM
applications in different ways:
• Press Menu, and select
Applications and App.
downloads and the list of
available WAP bookmarks is
shown. Select More bookmarks
to access the list of WAP
bookmarks in the Services
menu, see ”Bookmarks” on page
78.
Select the appropriate bookmark
to connect to the desired WAP
page. If the connection fails, you
may not be able to access the
WAP page from the WAP
service whose connection
settings are currently active. In
this case, enter the Services
menu and activate another set of
service settings, see ”Making a
connection to a service” on page
75. Try again to connect to the
WAP page.
For the availability of different
WAP services, pricing and
tariffs, contact your network
operator and/or the WAP service
provider.
• Press Menu, and select Services
to find a WAP page to download
an appropriate Java application.
See ”Browsing the pages of a
service” on page 76.
• Use the game download
functionality, see ”Game
services” on page 63.
• Use the Nokia Application
installer from PC Suite to
download the applications in
your phone (network service).
RH-4_FCC_2003-4-16.fm Page 65 Friday, April 18, 2003 4:34 PM
66
Note that Nokia does not
warrant for applications
from non-Nokia sites. If
you choose to download
Java applications from them, you
should take the same precautions,
for security or content, as you
would with any site.
Note that when downloading an
application, it may be saved in
Games menu instead of the
Applications menu.
Memory status for
applications
To view the amount of memory
available for game and application
installations, press Menu, and select
Applications and Memory.
The applications use shared
memory. Refer to ”Shared
memory” on page 0.
■Extras (Menu
11)
Note: Your phone must be
switched on to use the
functions in Extras menu.
Do not switch the phone on when
wireless phone use is prohibited or
when it may cause interference or
danger.
Calculator
The calculator in your phone adds,
subtracts, multiplies, divides,
calculates the square and the square
root and converts currency values.
This calculator has a limited
accuracy and rounding errors may
occur, especially in long divisions.
1. Press Menu, and select Extras
and Calculator.
2. When ’0’ is displayed on the
screen, enter the first number in
the calculation, press for a
decimal point.
3. Press Options and select Add,
Subtract, Multiply, Divide,
Square, Square root or Change
sign.
Tip: Alternatively, press
once to add, twice to
subtract, three times to
multiply or four times to divide.
4. Enter the second number.
5. For a total, press Options and
select Equals. Repeat steps 3 to
5 as many times as is necessary.
6. To start a new calculation, first
press and hold Clear.
Performing a currency
conversion
1. Press Menu, and select Extras
and Calculator.
2. To save the exchange rate, press
Options and select Exchange
rate. Select either of the
displayed options. Enter the
exchange rate, press for a
decimal point, and press OK.
RH-4_FCC_2003-4-16.fm Page 66 Friday, April 18, 2003 4:34 PM
67
English
The exchange rate remains in
the memory until you replace it
with another one.
3. To perform the currency
conversion, enter the amount to
be converted, press Options and
select In domestic or In foreign.
Tip: You can also perform
the currency conversion in
standby mode. Key in the
amount to be converted,
press Options and select In
domestic or In foreign.
Countdown timer
Press Menu, and select Extras and
Countdown timer. Enter the time to
be counted in hours and minutes
and press OK. If you wish, enter
your own note text which is
displayed when the time expires,
and press OK to start the
countdown timer.
• To change the countdown time,
select Change time, or to stop
the timer, select Stop timer.
If the alarm time is reached when
the phone is in standby mode, the
phone sounds a tone and flashes the
note text if it is set or else
Countdown time up. Stop the alarm
by pressing any key. If no key is
pressed, the alarm automatically
stops within 30 seconds. To stop the
alarm and to delete the note text,
press OK.
Stopwatch
You can measure time, take
intermediate times or lap times
using the stopwatch. During timing,
the other functions of the phone can
be used. To set the stopwatch timing
in the background, press .
Using the stopwatch consumes the
battery and the phone's operating
time will be reduced. Be careful not
to let it run in the background when
performing other operations with
your phone.
Time observation and time
splitting
1. Press Menu, and select Extras,
Stopwatch and Split timing. You
can select Continue if you have
set the timing in the background.
2. Press Start to start the time
observation. Press Split every
time you want to take an
intermediate time. The
intermediate times are listed
below the running time on the
display. Scroll to view the times.
3. Press Stop to stop the time
observation.
4. Press Options and select
Start to start the time
observation again. The new time
is added to the previous time.
Save to save the time. Enter a
name for the measured time and
press OK. If no name is keyed
RH-4_FCC_2003-4-16.fm Page 67 Friday, April 18, 2003 4:34 PM
68
in, the total time is used as the
title.
Reset to reset the time without
saving it.
Lap times
Press Menu, and select Extras,
Stopwatch and Lap timing. Press
Start to start the time observation
and Lap to take a lap time. Press
Stop to stop the lap timing. Press
Options and you can save or reset
the lap times. Refer to ”Time
observation and time splitting”
above.
Viewing and deleting times
Press Menu, and select Extras, and
Stopwatch.
If the stopwatch is not reset, you
can select Show last to view the
most recent measured time. Select
View times and a list of names or
final times of the time sets is shown,
select the time set you want to view.
To delete the saved times, select
Delete times. Select Delete all and
press OK, or select One by one,
scroll to the times you want to
delete, press Delete and press OK.
Wallet
In Wallet you can save personal
information, for example, credit
card numbers and make purchases
with your phone where the
functionality is supported (network
servie).
You can access wallet via the Wallet
menu or via the WAP browser, see
”Options while browsing” on page
76.
When you access wallet for the first
time, you need to create your own
wallet code. At Create wallet code:
key in the code and press OK to
confirm it and at Verify wallet code:
key in the code again and press OK.
If you want to delete all the content
of the wallet and the wallet code,
key in *#7370925538#
(*#res0wallet# in letters) in standby
mode. You also need the phone’s
security code.
See also ”Access codes” on page -1.
Saving and changing personal
card information
To access the wallet, press Menu,
select Extras and Wallet . If
required, key in your wallet code
and press OK, see ”Wallet settings”
on page 69. Select Cards to view
the list of cards. The maximum
number of cards is five. Scroll to the
desired card.
• To save information on a card,
press Options and select View.
Select
•Card info to enter, for
example, card holder’s name,
card type, number and expiry
information.
•User info to save user name
and password.
RH-4_FCC_2003-4-16.fm Page 68 Friday, April 18, 2003 4:34 PM
69
English
•Shipping info to save your
contact information.
•Billing info to save the
contact information in case
the invoicing address differs
from your own, for example,
with company credit cards.
•Receipt info to save phone
numbers and e-mail
addresses where you want
the service provider to send a
receipt of your purchase.
• To make a copy of the card,
press Options and select Copy
card.
• To delete all the information on
the card, press Options and
select Clear card.
• To rename the card, press
Options and select Rename card.
Personal notes
You can save up to 30 personal
notes, for example, passwords,
codes or notations.
Press Menu, select Extras, Wa llet
and Personal notes. Press Options
and you can view, add, edit a
selected note and sort notes either
by name or date. Send as text copies
the note as a text message. Copy to
calendar copies the note to the
calendar as a memo. Use number
extracts numbers from a note.
Wallet settings
Press Menu, select Extras, Walle t
and Settings. Select
•Code request to set the wallet
code request to on or off. You
need to key in the correct wallet
code before you can set the code
request to on or off. Note that if
if you set it to off the
information in the wallet is
accessible without the password
•Change code to change the
wallet code.
Guidelines for paying for your
purchases with wallet
1. Access the desired WAP site
supporting this functionality to
do your shopping, see ”Making
a connection to a service” on
page 75, and choose the product
you want to buy.
2. Read all the provided
information carefully. Note that
the information provided by the
site may not fit into one page in
your screen, you may need to
scroll pages to completely read
them.
3. To pay for the items you wish to
purchase, press Options and
select Use wallet info. See
”Options while browsing” on
page 76.
4. Select the card you want to pay
with. Fill in the data form you
receive from the service
RH-4_FCC_2003-4-16.fm Page 69 Friday, April 18, 2003 4:34 PM
70
provider by transferring the
credit card details from the
wallet. If you want to fill in all
the fields automatically, select
Fill in all fields. The option is
shown only when the WAP
service supports the Electronic
Commerce Modeling Language
standard. You can also fill the
form by selecting information
fields from the card one by one.
The phone displays the filled
form.
5. Approve the purchase, and the
information is sent forward.
6. You may receive a sign-in
document from the WAP service
that you need to sign to make the
purchase binding, see ”Digital
signature” on page 81.
7. To close the wallet, select Close
wallet. See ”Options while
browsing” on page 76.
Synchronisation
You can save your compatible
calendar and phone book data on a
remote Internet server (network
service) or on a compatible PC. If
you have saved data on the remote
Internet server, you can synchronise
your phone by starting the
synchronisation from your phone.
You can also synchronise the data in
your phone’s phone book and
calendar to correspond with the
data of your compatible PC by
starting the synchronisation from
your PC. The phone book in your
SIM card will not be synchronised.
Note that answering an incoming
call during synchronisation will end
the synchronisation and you need to
start it again.
Synchronising from your phone
Before synchronising from your
phone, you may need to do the
following:
• Subscribe to a synchronisation
service. For more information
on availability and the
synchronisation service settings,
contact your network operator or
service provider.
• Retrieve the synchronisation
settings from your network
operator or service provider.
You may receive the
synchronisation settings as a text
message, see ”Save the
synchronisation settings
received as a text message” on
page 71 or you may have to enter
the settings manually, see ”Enter
the synchronisation settings
manually” on page 71.
To start the synchronisation from
your phone:
1. Press Menu, and select Services,
Active service settings and select
the connection settings you need
for synchronisation.
RH-4_FCC_2003-4-16.fm Page 70 Friday, April 18, 2003 4:34 PM
71
English
The synchronisation settings
may differ from the service
settings required for WAP
browsing. After synchronising,
change your Active service
settings back to the previous
ones if you want to use other
WAP services later.
2. Mark the data to be
synchronised. See Data to be
synchronised in ”Enter the
synchronisation settings
manually” on page 71.
3. Press Menu, and select Extras,
Synchronisation and
Synchronise.
4. The marked data of the active set
will be synchronised after
confirmation.
Note that synchronising for the
first time or after an interrupted
synchronisation may take up to
30 minutes, if the phone book or
calendar are full.
Save the synchronisation
settings received as a text
message
You may be able to receive the
synchronisation settings as a text
message. When you receive it,
Synchronisation settings received is
displayed.
Press Options and select Details to
view the received settings first,
Save to save the synchronisation
settings, or Discard to discard them.
Enter the synchronisation
settings manually
Press Menu, select Extras,
Synchronisation and Settings.
Select Active Internet sync. settings.
You need to activate the set where
you want to save the
synchronisation settings. A set is a
collection of settings required to
make a connection to a service.
Scroll to the set you wish to activate
and press Activate.
Select Edit active Internet sync.
settings. Select each setting one by
one and enter all the required
settings.
•Settings' name. Enter the name
for the set and press OK.
•Data to be synchronised. Mark
the data you want to
synchronise, Contacts or/and
Calendar, and press Done.
•Database addresses. Select
Contacts database or/and
Calendar database to be edited.
Enter the name of the database
and press OK.
•User name. Enter the user name
and press OK.
•Password. Key in the password
and press OK.
•Synchronisation server. Enter
the name of the server and press
OK.
RH-4_FCC_2003-4-16.fm Page 71 Friday, April 18, 2003 4:34 PM
72
Synchronising from your
compatible PC
To synchronise the compatible
phone book and calendar from your
compatible PC, use either an IR
connection or a data cable. You also
need the PC Suite software of your
phone installed on your PC. Start
the synchronisation from your PC
using PC suite. After
synchronising, the synchronised
data in the phone, which is
supported by the phone, is the same
as it’s counterpart in the PC.
■Connectivity
(Menu 12)
Infrared
You can set up the phone to receive
data through its infrared (IR) port.
To use an IR connection, the device
with which you want to establish a
connection must be IrDA
compliant. You can send or receive
data such as business cards and
calendar notes to or from a
compatible phone or data device
(for example, a computer) via the
IR port of your phone.
Do not point the IR (infrared) beam
at anyone's eye or allow it to
interfere with other IR devices. This
device is a Class 1 Laser product.
Note: Your phone must be
switched on to use this
function. Do not switch the
phone on when wireless phone use
is prohibited or when it may cause
interference or danger.
Send and receive data via IR
• Ensure that the IR ports of the
sending and receiving devices
are pointing at each other and
that there are no obstructions
between the devices. The
preferable distance between the
two devices in an infrared
connection is one metre at most.
• To activate the IR port of your
phone to receive data via IR,
press Menu, and select
Connectivity and Infrared.
• The user of the sending phone
selects the desired IR function to
start data transfer.
If data transfer is not started within
two minutes after the activation of
the IR port, the connection is
cancelled and has to be started
again.
IR connection indicator
• When is shown
continuously, the IR connection
is activated and your phone is
ready to send or receive data via
its IR port.
• When blinks, your phone is
trying to connect to the other
device or a connection has been
lost.
RH-4_FCC_2003-4-16.fm Page 72 Friday, April 18, 2003 4:34 PM
73
English
GPRS
GPRS connection
You can set the phone to
automatically register to a GPRS
network when you switch the phone
on (network service). Press Menu,
and select Connectivity, GPRS,
GPRS connection and Always
online. When you start an
application using GPRS, the
connection between your phone and
the network is established, and data
transfer is possible. When you end
the application, GPRS connection
is ended but the registration to the
GPRS network remains.
If you select When needed, the
GPRS registration and connection
are established when an application
using GPRS needs it and closed
when you end the application.
GPRS modem settings
You can connect the phone via an
infrared or a data cable connection
to a compatible PC and use the
phone as a modem to enable GPRS
connectivity from the PC (network
service).
Press Menu, and select
Connectivity, GPRS and GPRS
modem settings. Select Active
access point and activate the access
point you want to use. Select Edit
active access point to change the
access point settings.
•Select Alias for access point.
Enter the name you would like
for the activated access point
and press OK.
•Select GPRS access point. Enter
the Access Point Name (APN)
to establish a connection to a
GPRS network and press OK.
Contact your network operator
or service provider for the
access point name.
You can also set the GPRS dial-up
service settings (Access Point
Name) on your PC using the Nokia
Modem Options software, see ”PC
Suite” on page 83. If you have set
the settings both on your PC and on
your phone, note that the PC’s
settings will be used.
■Services
(Menu 13)
Note: Your
phone must be switched on
to use this function. Do not
switch the phone on when wireless
phone use is prohibited or when it
may cause interference or danger.
You can access various services on
the Internet. For example, these
services may include weather
reports, news or flight times and
financial information.
Check the availability of these
services, pricing and tariffs with
your network operator and/or
service providers whose service
RH-4_FCC_2003-4-16.fm Page 73 Friday, April 18, 2003 4:34 PM
74
you wish to use. Service provider
will also give you instructions on
how to use their services.
Note that your phone may have
some pre-installed bookmarks for
sites not affiliated to Nokia. Nokia
does not warrant or endorse these
sites. If you choose to access them,
you should take the same
precautions, for security or content,
as you would with any Internet site.
With your phone’s multi-mode
browser you can view the services
that use Wireless Mark-up
Language (WML) or extensible
HyperText Markup Language
(xHTML) on their pages. Since the
phone’s display and the memory
capacity are much smaller than in a
computer, Internet content is
displayed differently on the phone’s
display. Note that you may not be
able to view all pages or all details
on the Internet pages.
Basic steps for accessing
and using services
1. Save the service settings that are
required to access the service
that you want to use. See page
74.
2. Make a connection to the given
service. See page 75.
3. Start browsing the pages of the
service. See page 76.
4. Once you are finished browsing,
end the connection to the
service. See page 77.
Setting up the phone for a
service
You may receive the service
settings as an OTA message from
the network operator or service
provider that offers the service that
you want to use. You can also key in
the settings manually or add and
edit the settings with PC Suite.
For more information and for
appropriate settings, contact your
network operator or service
provider that offers the service that
you want to use. The settings may
be available, for example, on their
website. You can also visit Club
Nokia’s website
(www.club.nokia.com).
Saving the service settings
received as an OTA message
When you receive the service
settings as an OTA message,
Service settings received is
displayed.
• To save the received settings,
press Options and select Save.
If no settings are saved in Active
service settings, the settings are
saved under the first free
connection set and are also
activated.
RH-4_FCC_2003-4-16.fm Page 74 Friday, April 18, 2003 4:34 PM
75
English
If there are settings saved in
Active service settings, Activate
saved service settings? will be
displayed. To activate the saved
settings, press Yes, or to save
them only, press No.
• To view the received settings
first, press Options and select
View. To save the settings, press
Save.
• To discard the received settings,
press Options and select
Discard.
Keying in the service settings
manually
1. Press Menu, and select Services,
Settings and Connection
settings.
2. Select Active service settings.
3. Scroll to the connection set you
would like to activate and press
Activate.
You need to activate the
connection set where you want
to save the service settings. A
connection set is a collection of
settings required to make a
connection to a service.
4. Select Edit active service
settings.
Select each of the settings one
by one and key in all the
required settings according to
the information you have
received from your network
operator or service provider.
Note that all the bearer-related
settings are in the Bearer
settings menu.
Making a connection to a
service
1. Firstly, make sure that the
service settings of the service
you want to use are activated. To
activate the settings:
•Press Menu, and select
Services, Settings and
Connection settings. Select
Active service settings and
scroll to the connection set
you want to activate and
press Activate.
2. Secondly, make a connection to
the service. There are three ways
to connect:
• Open the startpage, for
example, the homepage of
the service provider:
Press Menu, and select
Services and Home, or in
standby mode press and hold
.
• Select a bookmark of the
service:
Press Menu, and select
Services, Bookmarks, and
select a bookmark.
If the bookmark does not
work with the current active
service settings, activate
RH-4_FCC_2003-4-16.fm Page 75 Friday, April 18, 2003 4:34 PM
76
another set of service settings
and try again.
• Key in the address of the
service:
Press Menu, and select
Services and then Go to
address. Key in the address
of the service and press OK.
Note that it is not necessary
to add the prefix http:// in
front of the address since it
will be added automatically.
Browsing the pages of a
service
After you have made a connection
to the service, you can start
browsing its pages. The function of
the phone keys may vary in
different services. Follow the text
guides on the phone display. For
more information, contact your
service provider.
Note that if GPRS is selected as the
data bearer, the indicator is
shown on the top left of the display
during browsing. If you receive a
call or a text message, or make a
call during a GPRS connection, the
indicator will be shown on the
top right of the display to indicate
that the GPRS connection is
suspended (on hold). After the call,
for example, the phone tries to
reconnect the GPRS connection.
Using the phone keys while
browsing
• Use any of the scroll keys to
browse through the page.
• To select a highlighted item,
press .
• To enter letters and numbers,
press the keys - and
to enter special characters, press
the key .
Options while browsing
Press Options and the following
options may be available. The
service provider may also offer
other options. Select
•Home to return to the homepage.
•Bookmarks. See ”Bookmarks”
on page 78.
•View image or View images to
view images and animations
from the page.
•Call / Edit / Open row / Open /
Open list to call, to key in text or
to select a highlighted item on
the page.
•Add bookmark to save the page
as a bookmark.
•Go to address to key in the
address of the service you want
to access.
•Service inbox. See ”Service
inbox” on page 79.
•Use wallet info to fetch
information from wallet (or
RH-4_FCC_2003-4-16.fm Page 76 Friday, April 18, 2003 4:34 PM
77
English
wallet personal notes
application) to the browser.
•Close wallet to close the wallet.
•Appear. settings. See
”Appearance settings of the
multi-mode browser” on page
77.
•Cookie settings. See ”Cookies”
on page 78.
•Use detail to extract numbers, e-
mail addresses and website
addresses from the current page.
•Reload to reload and update the
current page.
•Clear the cache. See ”The cache
memory” on page 79.
•Security info to view security
information about the current
connection and the server.
•Quit. See ”Disconnect from a
service” on page 77.
Note: The information or
services you have accessed
are stored in the cache of
your phone. A cache is a
buffer memory, which is
used to store data
temporarily. If you have
tried to access or have
accessed confidential
information requiring
passwords (for example,
your bank account), empty
the cache of your phone
after each use.
To empty the cache, see ”The cache
memory” on page 79.
Direct calling
The multi-mode browser supports
functions that you can access while
browsing. You can make a voice
call, send DTMF tones while a
voice call is in progress, and save a
name and a phone number from a
page in contacts.
Disconnect from a service
To quit browsing and to end the
connection, press Options and
select Quit. When Quit browsing?
is shown, press Ye s.
Alternatively, press . If GSM
data is the selected data bearer,
press twice. The phone ends
the connection to the service.
Appearance settings of the
multi-mode browser
1. While browsing, press Options
and select Appear. settings,
or in standby mode, press Menu,
and select Services, Settings and
Appearance settings.
2. Select Text wrapping. Select On
and the text continues on the
next line if it cannot be shown on
one line. If you select Off, the
text is abbreviated if it is too
long to be shown on one line.
Select Show images. Select No
and any pictures appearing on
RH-4_FCC_2003-4-16.fm Page 77 Friday, April 18, 2003 4:34 PM
78
the page are not shown. This can
speed up the browsing of pages
that contain a lot of pictures.
Cookies
A cookie is data that a site saves in
your phone’s browser cache
memory. The data can be, for
example, your user information or
your browsing preferences.
Cookies will be saved until you
clear the cache memory, see ”The
cache memory” on page 79.
1. While browsing, press Options
and select Cookie settings,
or in standby mode, press Menu,
and select Services, Settings,
Security settings and Cookies.
2. Select Allow or Reject to allow
or prevent the phone receiving
cookies.
Bookmarks
You can save page addresses as
bookmarks in the phone’s memory.
1. While browsing, press Options
and select Bookmarks,
or in standby mode, press Menu,
and select Services and
Bookmarks.
2. Scroll to the bookmark you want
to use and press Options.
3. Select Go to to make a
connection to the page
associated with the bookmark.
You can also view the title and
the address of the selected
bookmark, edit or delete the
selected bookmark, or send it
directly to another phone as a
bookmark, or as an OTA
message, or create a new
bookmark.
Note that your phone may have
some pre-installed bookmarks for
sites not affiliated to Nokia. Nokia
does not warrant or endorse these
sites. If you choose to access them,
you should take the same
precautions, for security or content,
as you would with any Internet site.
Receiving a bookmark
When you have received a
bookmark (sent as a bookmark
from a compatible device) 1
bookmark received is displayed.
Press View, then press Options and
select View to view the bookmark,
Save to save the bookmark, or
Discard to discard it.
Downloading
1. To download more tones,
images, games or applications to
your phone, press Menu, and
select Services and Download
links.
2. Select Tone downloads, Image
downloads, Game downloads or
App. downloads to download
tones, images, games or
applications, respectively.
RH-4_FCC_2003-4-16.fm Page 78 Friday, April 18, 2003 4:34 PM
79
English
Download content only from the
sources you trust.
Note that copyright protections may
prevent some images, ringing tones
and other content from being
copied, modified, transferred or
forwarded.
Service inbox
The phone is able to receive service
messages (pushed messages) sent
by your service provider (network
service). Service messages are
notifications of, for example, news
headlines, and they may contain a
text message or an address of a
service.
To access the Service inbox in
standby mode, when you have
received a service message, press
Show.
• If you press Exit the message is
moved to the Service inbox. To
access the Service inbox later,
press Menu, and select Services,
Settings and Service inbox.
To access the Service inbox while
browsing, press Options and select
Service inbox. Scroll to the message
you want, press Options. Select
Retrieve to activate the multi-mode
browser and download the marked
content, or Details to display
detailed information on the service
notification, or select Delete to
delete it.
Service inbox settings
Press Menu, and select Services,
Settings and Service inbox settings.
•Select Service messages and On
(or Off) to set the phone to
receive (or not to receive)
service message.
•Select Automatic connection. If
you have set the phone to
receive service messages and
select Automatic connection on,
the phone will automatically
activate the browser when the
phone has received a service
message.
If you select Automatic
connection off, the phone will
activate the browser only after
you have selected Retrieve when
the phone has received a service
message.
The cache memory
The information or services you
have accessed are stored in the
cache of your phone. A cache is a
buffer memory, which is used to
store data temporarily. To empty the
cache:
• while browsing, press Options
and select Clear the cache, or
• in standby mode, press Menu,
and select Services, and Clear
the cache.
RH-4_FCC_2003-4-16.fm Page 79 Friday, April 18, 2003 4:34 PM
80
Browser security
Security features may be required
for some services, such as banking
services or shopping on a site. For
such connections you need security
certificates and possibly a security
module which may be available on
your SIM card. For more
information, contact your service
provider.
Security module
The security module can contain
certificates as well as private and
public keys. The security module
may improve the security services
for applications requiring browser
connection, and allows you to use a
digital signature. The certificates
are saved in the security module by
the service provider.
Press Menu and select Services,
Settings, Security settings and
Security module settings. Select
•Security module details to show
the security module title, its
status, manufacturer and serial
number.
•Module PIN request to set the
phone to ask for the module PIN
when using services provided by
security module. Key in the code
and select On. To disable the
module PIN request, select Off.
•Change module PIN to change
the module PIN, if allowed by
the security module. Enter the
current module PIN code, then
enter the new code twice.
•Change signing PIN. Select the
signing PIN you want to change.
Enter the current PIN code, then
enter the new code twice.
See also ”General information” on
page -1.
Certificates
There are three kinds of certificates:
server certificates, authority
certificates and user certificates.
• The phone uses a server
certificate to improve security in
connection between the phone
and the gateway. The phone
receives the server certificate
from the service provider before
the connection is established and
its validity is checked using the
authority certificates saved in
the phone. Server certificates are
not saved.
The security indicator is
displayed during a connection, if
the data transmission between
the phone and the gateway
(identified by the IP address in
the Edit active service settings -
Bearer settings) is encrypted.
However, the security indicator
does not indicate that the data
transmission between the
gateway and the content server
(place where the requested
RH-4_FCC_2003-4-16.fm Page 80 Friday, April 18, 2003 4:34 PM
81
English
resource is saved) is secure. It is
up to the service provider to
secure the data transmission
between the gateway and the
content server.
• Authority certificates are used
by some services, such as
banking services, for checking
the validity of other certificates.
Authority certificates can either
be saved in the security module
by the service provider, or they
can be downloaded from the
network, if the service supports
the use of authority certificates.
• User certificates are issued to
users by a Certifying Authority.
User certificates are required,
for example, to make a digital
signature and they associate the
user with a specific private key
in a security module.
Important: Note, however,
that even if the use of
certificates makes the risks
involved in remote
connections and software
installation considerably
smaller, they must be used
correctly in order to benefit
from increased security.
The existence of a
certificate does not offer
any protection by itself; the
certificate manager must
contain correct, authentic,
or trusted certificates for
increased security to be available.
Important: Certificates have a
restricted lifetime. If Expired
certificate or Certificate not valid
yet is shown even if the certificate
should be valid, check that the
current date and time in your phone
are correct.
Important: Before changing these
settings, you must make sure that
you really trust the owner of the
certificate and that the certificate
really belongs to the listed owner.
Digital signature
You can make digital signatures
with your phone (network service).
The signature can be traced back to
you via the private key on the
security module and the user
certificate that was used to perform
the signature. Using the digital
signature can be the same as signing
your name to a paper bill, contract
or other document.
To make a digital signature, select a
link on a page, for example, the title
of the book you want to buy and its
price. The text to sign (possibly
including amount, date, etc.) will be
shown.
Check that the header text is Read
and that the digital signature icon
is shown.
Note: If the digital
signature icon does not
appear, there is a security
RH-4_FCC_2003-4-16.fm Page 81 Friday, April 18, 2003 4:34 PM
82
breach, and you should not enter
any personal data such as your
signing PIN.
To sign the text, read all of the text
first and then you can select Sign.
Note: The text may not fit
within a single screen.
Therefore, make sure to
scroll through and read all of the
text before signing.
Select the user certificate you want
to use. Key in the signing PIN (see
”General information” on page -1)
and press OK. The digital signature
icon will disappear, and the service
may display a confirmation of your
purchase.
■SIM services
(Menu 14)
In addition to the functions
available in the phone, your SIM
card may provide additional
services that you can access in
Menu 15. Menu 15 is shown only if
it is supported by your SIM card.
The name and contents of the menu
depend entirely on the service
available.
Note: For availability, rates
and information on using
SIM services, contact your
SIM card vendor, e.g. network
operator, service provider or other
vendor.
You can set the phone to show you
the confirmation messages sent
between your phone and the
network when you are using the
SIM services by selecting the
option Yes in the menu Confirm
SIM service actions in Phone
settings.
Note that accessing these services
may involve sending a text message
(SMS) or making a phone call for
which you may be charged.
RH-4_FCC_2003-4-16.fm Page 82 Friday, April 18, 2003 4:34 PM
83
English
7. PC connectivity
You can send and receive e-mails,
and access the Internet when your
phone is connected to a compatible
PC via an IR connection or a data
cable. You can use your phone with
a variety of PC connectivity and
data communications applications.
With PC Suite you can, for
example, send text and picture
messages, synchronise contacts,
calendar and to-do notes between
your phone and the PC, and manage
your WAP bookmarks and
connection sets.
You may find more information and
downloadable files on the Nokia
website, www.nokia.com.
■PC Suite
The PC Suite contains the
following applications:
•Nokia Application Installer to
install Java applications from a
compatible PC to the phone.
•Nokia Image Converter to
make images usable for
multimedia messages, wallpaper
or operator logos and to transfer
them to your phone.
•Nokia Sound Converter to edit
polyphonic ringing tones to be
compatible with your phone and
to transfer them to your phone.
•Nokia Content Copier to copy
information or back-up
information from your phone to
a compatible PC or to another
compatible Nokia phone.
•Nokia PC WAP Manager to
edit and send your WAP
bookmarks or update the
connection sets to your phone.
•Nokia Phone Editor to send
text messages and edit the phone
book and message settings of
your phone.
•Nokia Phone Browser to view
the contents of the Gallery
folder of your phone on the PC.
•Nokia PC Sync to synchronise
the compatible phone book,
calendar and to-do notes
between your phone and PC.
•Nokia PC Graphics to create
and edit picture messages for
previous compatible Nokia
phone models, for example, the
Nokia 8310 phone.
•Nokia PC Composer to create
monophonic ringing tones for
previous compatible Nokia
phone models, for example, the
Nokia 8310 phone.
• Nokia 6108 data modem drivers
enable you to use your phone as
a modem.
RH-4_FCC_2003-4-16.fm Page 83 Friday, April 18, 2003 4:34 PM
84
•Nokia Modem Options
contains settings for HSCSD
and GPRS connections.
•Nokia Connection Manager to
select the connection type
between the PC and the phone.
Note that copyright protections may
prevent some images, ringing tones
and other content from being
copied, modified, transferred or
forwarded.
GPRS, HSCSD and CSD
With your phone you can use GPRS
(General Packet Radio Service),
HSCSD (High Speed Circuit
Switched Data), and CSD (Circuit
Switched Data, GSM data) data
services.
For availability and subscription to
data services, contact your network
operator or service provider.
Note that the use of HSCSD service
consumes the phone’s battery faster
than normal voice or data calls. You
may need to connect the phone to a
charger for the duration of data
transfer.
See ”GPRS modem settings” on
page 73.
■Use data
communication
applications
For information on using a data
communication application, refer to
the documentation provided with it.
1. If you use an IR connection:
• Activate the IR connection in
the phone, see ”Infrared” on
page 72. Make sure that the
connection is active in your
PC.
If you use the cable DKU-5:
• Connect the cable to the USB
port on the back of your
computer and to the
connector on your phone.
2. Start using the data
communications application on
the computer.
Note that making or answering
phone calls during a computer
connection is not recommended as
it might disrupt the operation.
For a better performance during
data calls, place the phone on a
stationary surface with the keypad
facing downward. Do not move the
phone or hold it in your hand during
a data call.
RH-4_FCC_2003-4-16.fm Page 84 Friday, April 18, 2003 4:34 PM
85
English
8. Battery information
■Charging and
Discharging
Your phone is powered by a
rechargeable battery.
Note that a new battery's full
performance is achieved only after
two or three complete charge and
discharge cycles!
The battery can be charged and
discharged hundreds of times but it
will eventually wear out. When the
operating time (talk-time and
standby time) is noticeably shorter
than normal, it is time to buy a new
battery.
Use only batteries approved by the
phone manufacturer and recharge
your battery only with the chargers
approved by the manufacturer.
Unplug the charger when not in use.
Do not leave the battery connected
to a charger for longer than a week,
since overcharging may shorten its
lifetime. If left unused a fully
charged battery will discharge itself
over time.
Temperature extremes can affect
the ability of your battery to charge;
allow it to cool down or warm up
first.
Use the battery only for its intended
purpose.
Never use any charger or battery
which is damaged or worn out.
Do not short-circuit the battery.
Accidental short-circuiting can
occur when a metallic object (coin,
clip or pen) causes direct
connection of the + and - terminals
of the battery (metal strips on the
battery) for example when you
carry a spare battery in your pocket
or purse. Short-circuiting the
terminals may damage the battery
or the connecting object.
Leaving the battery in hot or cold
places, such as in a closed car in
summer or winter conditions, will
reduce the capacity and lifetime of
the battery. Always try to keep the
battery between 15°C and 25°C
(59°F and 77°F). A phone with a
hot or cold battery may temporarily
not work, even when the battery is
fully charged. Batteries'
performance is particularly limited
in temperatures well below
freezing.
Do not dispose of batteries in a fire!
Dispose of batteries according to
applicable local regulations (e.g.
recycling). Do not dispose of as
household waste.
RH-4_FCC_2003-4-16.fm Page 85 Friday, April 18, 2003 4:34 PM
86
9. Nokia Original Enhancements
A new extensive range of enhancements is available for
your phone. Select the enhancements which accommodate
your specific communication needs.
Some of the enhancements are described in detail below.
For availability of the enhancements, please check with
your local dealer. A few practical rules for enhancements operation:
• Keep all accessories out of the reach of small children.
• When you disconnect the power cord of any enhancement, grasp and pull
the plug, not the cord.
• Check regularly that any vehicle-installed accessories are mounted and
are operating properly.
• Installation of any complex car accessories must be made by qualified
personnel only.
• Use only batteries, chargers and accessories approved by the phone
manufacturer. The use of any other types may invalidate any approval or
warranty applying to the phone, and may be dangerous.
■Battery
* Variation in operation times may occur depending on SIM card, network
and usage settings, usage style and environments. Use of the Loudspeaker
feature will affect talktime and standby time.
Type Tech Capacity Talktime * Standby *
BL-5C Li-lon up to 850
mAh
3-7 hours 170-330
hours
RH-4_FCC_2003-4-16.fm Page 86 Friday, April 18, 2003 4:34 PM
87
English
■Travel Charger (ACP-12)
Small, lightweight travel charger with multi voltage (100 - 240V) switcher
technology. Provides easy and convenient way to charge the phone.
Note: The plug types vary according to different markets.
■Boom Headset (HDB-4)
This small and lightweight headset has a beautiful and distinctive Nokia
design. Gives you excellent audio quality and you can answer or end calls
by pressing the button on the microphone part of the headset.
■Mobile Charger (LCH-9)
The multi-voltage Mobile Charger, LCH-9, ensures your phone is always
ready for use whenever you travel. This small charger's functional design
fits most car lighters and interiors.
A green light indicates that the Mobile Charger is ready for charging. Check
the charging status on the phone display. The input voltage can be 12 or 24
V DC, negative grounding.
RH-4_FCC_2003-4-16.fm Page 87 Friday, April 18, 2003 4:34 PM
88
Avoid prolonged charging with the Mobile Charger when the car engine is
not running; this may cause the battery of your car to drain. Note also that in
some cars the cigarette lighter plug is not provided with electricity if the
ignition is switched off. Verify that the green LED light is on.
RH-4_FCC_2003-4-16.fm Page 88 Friday, April 18, 2003 4:34 PM
89
English
10.Technical Information
Feature Specification
Weight 8.1 ounces (98.4 grams) with BL-5C 850 mAh Li-
polymer Battery
Networks Wireless networks GSM 900,1800 and1900
Size (volume) 5.20 cubic inches (85 cc)
Frequency
range (Tx)
GSM 900: 880 - 915 Mhz
GSM 1800: 1710 - 1785 Mhz
GSM1900: 1850 - 1910 Mhz
Frequency
range (Rx)
GSM 900: 925 - 960 Mhz
GSM1800: - 1805 - 1880 Mhz
GSM1900: - 1930 - 1990 Mhz
Tx output
power
EGSM 900: 2W (peak)
GSM1800: 1W (peak)
GSM1900: 1W(peak)
Battery voltage 3.7 v DC
Number of
channels
EGSM 900: 174
GSM1800: 374
GSM1900: 299
Memory
locations
up to 500 in phone memory
RH-4_FCC_2003-4-16.fm Page 89 Friday, April 18, 2003 5:07 PM
90
11. Patents
Manufactured or sold under one or more of the following US Patents:
4558302
4868846
4969192
5001372
5045973
5061928
5101175
5212834
5230091
5233634
5241284
5241583
5303404
5311179
5331638
5335362
5353328
5384782
5390223
5396657
5400949
5416435
5442521
5444816
5446364
5479476
5487084
5493255
5519885
5526366
5553125
5557639
5581244
5625274
5640395
5664053
5669069
5677620
5692032
5699406
5699482
5701392
5729534
5729541
5734683
5754976
5760568
5782646
5794142
5802465
5805084
5805301
5818437
5827082
5835889
5839101
5844884
5845219
5857151
5862178
5870683
5887266
5889770
5892475
5898925
5907823
5914796
5915440
5917868
5920826
5926138
5926769
5930233
5946651
5953541
5956625
5956633
5960389
5963901
5966374
5966378
5969192
5970059
5987137
5991716
5991857
5999523
6005857
6011554
6011853
6014573
6026161
6028567
6029128
6038238
6043760
6047196
6049796
6055439
6060193
6069923
6081534
6084962
6088746
6094587
6097964
6112099
6115617
6118775
6122498
6128322
6128509
6138091
6144243
6144676
6151485
6151507
6163609
6164547
6167248
6170073
6185295
6188909
6195338
6199035
6201876
6219560
6240076
6240079
6249584
6266330
6282373
6289205
6292668
6295286
6310609
6324412
D406261
D425480
D426830
D445415
RE32580
CN03109865.7
(a patent
application,
based on the
same technical
contents of
patent
application
CN03109865.7
will be made to
the US Patent
and Trademark
Office before
April 14 of
2004.)
RH-4_FCC_2003-4-16.fm Page 90 Friday, April 18, 2003 4:34 PM
91
English
12. CARE AND MAINTENANCE
Your phone is a product of superior design and craftsmanship and should be treated
with care. The suggestions below will help you to fulfill any warranty obligations and to
enjoy this product for many years.
• Keep the phone and all its parts and accessories out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and all types of liquids or moisture can
contain minerals that will corrode electronic circuits.
• Do not use or store the phone in dusty, dirty areas. Its moving parts can be damaged.
• Do not store the phone in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
• Do not store the phone in cold areas. When it warms up (to its normal temperature),
moisture can form inside, which may damage electronic circuit boards.
• Do not attempt to open the phone. Non-expert handling may damage it.
• Do not drop, knock or shake the phone. Rough handling can break internal circuit
boards.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the
phone.
• Do not paint the phone. Paint can clog the moving parts and prevent proper
operation.
• Use only the supplied or an approved replacement antenna. Unauthorised antennas,
modifications or attachments could damage the phone and may violate regulations
governing radio devices.
All of the above suggestions apply equally to your phone, battery, charger or any
enhancement. If any of them are not working properly, take them to your nearest
qualified service facility. The personnel there will assist you and, if necessary, arrange
for service.
RH-4_FCC_2003-4-16.fm Page 91 Friday, April 18, 2003 4:34 PM
92
13. IMPORTANT SAFETY INFORMATION
■Traffic safety
Don’t use a hand-held telephone while driving a vehicle. Always secure the
phone in its holder and don’t place the phone on the passenger seat or where
it can break loose in a collision or sudden stop. Remember road safety always
comes first!
■Operating environment
Remember to follow any special regulations in force in any area and always
switch off your phone whenever it is forbidden to use it, or when it may cause
interference or danger.
Use the phone only in its normal operating positions. When connecting the
phone or accessory to another device, read its user’s guide for safety
instructions. Don’t connect incompatible products. As with other mobile radio
transmitting equipment, users are advised to operate this equipment only in
the normal operating position (held to your ear with the antenna pointing
over your shoulder).
■Electronic devices
Most modern electronic equipment is shielded from radio frequency (RF)
signals. However, certain electronic equipment may not be shielded against
the RF signals emanating from your wireless phone.
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of 6 inches
(20 cm ) be maintained between a hand-held wireless phone and a pacemaker
to avoid potential interference with the pacemaker. These recommendations
are consistent with independent research and recommendations of Wireless
Technology Research.
PERSONS WITH A PACEMAKER:
• Should always keep the phone more than 6 inches (20 cm ) from their
pacemaker when the phone is switched on.
• Should not carry the phone in a breast pocket.
RH-4_FCC_2003-4-16.fm Page 92 Friday, April 18, 2003 4:34 PM
93
English
• Should use the ear opposite the pacemaker to minimize the potential for
interference.
• Should switch off the phone immediately if there is any reason to suspect
that interference is taking place.
Hearing aids
Some digital wireless phones may interfere with hearing aids. In the event of
such interference, consult your wireless provider.
Other medical devices
Operation of any radio transmitting equipment, including cellular phones,
may interfere with the functionality of inadequately protected medical
devices. Consult a physician or the manufacturer of the medical device to
determine if it is adequately shielded from external RF energy, or if you have
any questions.
Switch off your phone in health care facilities when any regulations posted in
these areas instruct you to do so. Hospitals or health care facilities may be
using equipment that could be sensitive to RF energy.
■Vehicles
RF signals may affect improperly installed or inadequately shielded electronic
systems in motor vehicles (for example, electronic fuel injection systems,
electronic anti-skid (anti-lock) braking systems, electronic speed control
systems, air bag systems). Check with the manufacturer or its representative
regarding your vehicle.
You should also consult the manufacturer of any equipment that has been
added to your vehicle.
■Posted facilities
Switch your phone off in any facility where posted notices so require.
■Potentially explosive atmospheres
Switch off your phone when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily injury or even death. Users are
advised to switch off the phone when at a refuelling point (service station).
RH-4_FCC_2003-4-16.fm Page 93 Friday, April 18, 2003 4:34 PM
94
Users are reminded of the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution areas), chemical
plants, or where blasting operations are in progress.
Areas with a potentially explosive atmosphere are often but not always clearly
marked. They include below deck on boats, chemical transfer/storage
facilities, vehicles using liquefied petroleum gas (such as propane or butane),
areas where the air contains chemicals or particles, such as grain, dust or
metal powders, and any other area where you normally be advised to turn off
your vehicle engine.
■Vehicles
Only qualified personnel should install or service the phone in a vehicle. Faulty
installation or service may be dangerous and invalidate the warranty. Check
regularly that all wireless phone equipment in your vehicle is mounted and
operating properly. Don’t store or carry or store flammable liquids, gases or
explosive materials in the same compartment as the phone or its accessories.
For vehicles equipped with an air bag, remember that an air bag inflates with
great force. Don’t place any objects, including both installed or portable
wireless equipment in the area over the air bag or in the air bag deployment
area. If in-vehicle wireless equipment is improperly installed and the air bag
inflates, serious injury could result.
■Aircraft
FCC regulations prohibit using your phone while in the air. Switch off your
phone before boarding an aircraft. The use of wireless telephones in an
aircraft may be dangerous to the operation of the aircraft, disrupt the wireless
telephone network, and may be illegal. Failure to observe these instructions
may lead to suspension or denial of telephone services to the offender, legal
action, or both.
■Emergency calls
Important: This phone, like any wireless phone, operates using radio
signals, wireless, and landline networks as well as userprogrammed
functions. Because of this, connections in all conditions cannot be
guaranteed.Therefore you should never rely solely upon any wireless
phone for essential communications (for example, medical
RH-4_FCC_2003-4-16.fm Page 94 Friday, April 18, 2003 4:34 PM
95
English
emergencies).
Emergency calls may not be possible on all wireless phone networks or
when certain network services and/or phone features are in use. Check
with local service providers.
MAKING AN EMERGENCY CALL
Note: Some networks may require that a valid SIM card be properly
inserted in the phone. Official emergency numbers vary by location
(for example, 911 or other official emergency number).
1. If the phone is not on, switch it on. Check for adequate signal strength.
2. Press as many times as needed (for example, to exit a call, to exit a
menu, etc.) to clear the display and ready the phone for calls.
3. Enter the emergency number for your present location (for example, 911
or other official emergency number). Emergency numbers vary by
location.
4. Press .
If certain features are in use, you may first need to turn those features off
before you can make an emergency call. Consult this user guide and your local
cellular service provider.When making an emergency call, remember to
provide all the necessary information as accurately as possible. Remember
that your wireless phone may be the only means of communication at the
scene of an accident - don’t end the call until given permission to do so.
RH-4_FCC_2003-4-16.fm Page 95 Friday, April 18, 2003 4:34 PM
96
■CERTIFICATION INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT'S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission of the U.S. Government.
These limits are part of comprehensive guidelines and establish permitted levels of
RF energy for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health. The
exposure standard for wireless mobile phones employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.*
Tests for SAR are conducted using standard operating positions accepted by the FCC
with the phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest certified power
level, the actual SAR level of the phone while operating can be well below the
maximum value. This is because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the network. In general, the
closer you are to a wireless base station antenna, the lower the power output. Before
a phone model is available for sale to the public, it must be tested and certified to the
FCC that it does not exceed the limit established by the government-adopted
requirement for safe exposure. The tests are performed in positions and locations (for
example, at the ear and worn on the body) as required by the FCC for each model. The
highest SAR value for this model phone as reported to the FCC when tested for use at
the ear is 0.55 W/kg and when worn on the body, as described in this user guide, is
0.8 W/kg. (Body-worn measurements differ among phone models, depending upon
available accessories and FCC requirements). While there may be differences
between the SAR levels of various phones and at various positions, they all meet the
government requirement. The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this model phone is on file with the FCC and
can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after
searching on FCC ID PPINPL-2.
For body worn operation, this phone has been tested and meets the FCC RF exposure
guidelines for use with an accessory that contains no metal and that positions the
handset a minimum of 5/8 inch (1.5 cm) from the body. Use of other accessories may
RH-4_FCC_2003-4-16.fm Page 96 Friday, April 18, 2003 4:34 PM
97
English
not ensure compliance with FCC RF exposure guidelines. If you do not use a body
worn accessory, and are not holding the phone at the ear, position the handset a
minimum of 5/8 inch (1.5 cm) from your body when the phone is switched on.
*In the United States and Canada, the SAR limit for mobile phones used by the public
is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give additional protection for the
public and to account for any variations in measurements. SAR values may vary
depending on national reporting equirements and the network band. For SAR
information in other regions please look under product information at
www.nokia.com. For body worn operation, this phone has been tested and meets the
FCC RF exposure guidelines when used with the Nokia accessories supplied or
designated for this product. Use of other accessories may not ensure compliance
with FCC RF exposure guidelines.
RH-4_FCC_2003-4-16.fm Page 97 Friday, April 18, 2003 4:34 PM
98
APPENDIX
■A message from the CTIA
(Cellular Telecommunications and Internet
Association)
© 2001 Cellular Telecommunications & Internet Association.
All Rights Reserved.
1250 Connecticut Avenue, NW Suite 800, Washington, DC 20036.
Phone: (202) 785-0081
RH-4_FCC_2003-4-16.fm Page 98 Friday, April 18, 2003 4:34 PM
99
English
Safety is the most important call you will ever make.
A Guide to Safe and Responsible Wireless Phone Use
Tens of millions of people in the u.s. today take advantage of the unique
combination of convenience, safety and value delivered by the wireless
telephone. Quite simply, the wireless phone gives people the powerful ability
to communicate by voice--almost anywhere, anytime--with the boss, with a
client, with the kids, with emergency personnel or even with the police. each
year, americans make billions of calls from their wireless phones, and the
numbers are rapidly growing.
But an important responsibility accompanies those benefits, one that every
wireless phone user must uphold. When driving a car, driving is your first
responsibility. A wireless phone can be an invaluable tool, but good judgment
must be exercised at all times while driving a motor vehicle--whether on the
phone or not.
The basic lessons are ones we all learned as teenagers. Driving requires
alertness, caution and courtesy. It requires a heavy dose of basic common
sense---keep your head up, keep your eyes on the road, check your mirrors
frequently and watch out for other drivers. It requires obeying all traffic signs
and signals and staying within the speed limit. It means using seatbelts and
requiring other passengers to do the same.
But with wireless phone use, driving safely means a little more. This brochure
is a call to wireless phone users everywhere to make safety their first priority
when behind the wheel of a car. Wireless telecommunications is keeping us in
touch, simplifying our lives, protecting us in emergencies and providing
opportunities to help others in need.
When it comes to the use of wireless phones, safety is your most important
call.
Wireless Phone “Safety Tips”
Below are safety tips to follow while driving and using a wireless phone which
should be easy to remember.
1. Get to know your wireless phone and its features such as speed dial and
redial. Carefully read your instruction manual and learn to take advantage
of valuable features most phones offer, including automatic redial and
memory. Also, work to memorize the phone keypad so you can use the
speed dial function without taking your attention off the road.
RH-4_FCC_2003-4-16.fm Page 99 Friday, April 18, 2003 4:34 PM
100
2. When available, use a hands free device. A number of hands free wireless
phone accessories are readily available today. Whether you choose an
installed mounted device for your wireless phone or a speaker phone
accessory, take advantage of these devices if available to you.
3. Position your wireless phone within easy reach. Make sure you place your
wireless phone within easy reach and where you can grab it without
removing your eyes from the road. If you get an incoming call at an
inconvenient time, if possible, let your voice mail answer it for you.
4. Suspend conversations during hazardous driving conditions or situations.
Let the person you are speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather conditions. Rain,
sleet, snow and ice can be hazardous, but so is heavy traffic. As a driver,
your first responsibility is to pay attention to the road.
5. Do not take notes or look up phone numbers while driving. If you are
reading an address book or business card, or writing a “to do” list while
driving a car, you are not watching where you are going. It’s common
sense. Don’t get caught in a dangerous situation because you are reading
or writing and not paying attention to the road or nearby vehicles.
6. Dial sensibly and assess the traffic; if possible, place calls when you are
not moving or before pulling into traffic. Try to plan your calls before you
begin your trip or attempt to coincide your calls with times you may be
stopped at a stop sign, red light or otherwise stationary. But if you need to
dial while driving, follow this simple tip--dial only a few numbers, check
the road and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations that may be
distracting. Stressful or emotional conversations and driving do not mix--
they are distracting and even dangerous when you are behind the wheel
of a car. Make people you are talking with aware you are driving and if
necessary, suspend conversations which have the potential to divert your
attention from the road.
8. Use your wireless phone to call for help. Your wireless phone is one of the
greatest tools you can own to protect yourself and your family in
dangerous situations--with your phone at your side, help is only three
numbers away. Dial 9-1-1 or other local emergency number in the case of
fire, traffic accident, road hazard or medical emergency. Remember, it is a
free call on your wireless phone!
RH-4_FCC_2003-4-16.fm Page 100 Friday, April 18, 2003 4:34 PM
101
English
9. Use your wireless phone to help others in emergencies. Your wireless
phone provides you a perfect opportunity to be a “Good Samaritan” in
your community. If you see an auto accident, crime in progress or other
serious emergency where lives are in danger, call 9-1-1 or other local
emergency number, as you would want others to do for you.
10. Call roadside assistance or a special wireless non-emergency assistance
number when necessary. Certain situations you encounter while driving
may require attention, but are not urgent enough to merit a call for
emergency services. But you still can use your wireless phone to lend a
hand. If you see a broken-down vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where no one appears injured or a
vehicle you know to be stolen, call roadside assistance or other special
non-emergency wireless number.
Careless, distracted individuals and people driving irresponsibly represent a
hazard to everyone on the road. Since 1984, the Cellular Telecommunications
Industry Association and the wireless industry have conducted educational
outreach to inform wireless phone users of their responsibilities as safe drivers
and good citizens. As we approach a new century, more and more of us will
take advantage of the benefits of wireless telephones. And, as we take to the
roads, we all have a responsibility to drive safely.
The wireless industry reminds you to use your phone safely when driving.
For more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/issues/driving/
articles.cfm?ID=85
© 2001 Cellular Telecommunications & Internet Association.
All Rights Reserved.1250
Connecticut Avenue, NW Suite 800, Washington, DC 20036.
Phone: (202) 785-0081
RH-4_FCC_2003-4-16.fm Page 101 Friday, April 18, 2003 4:34 PM
102
■A message from the U.S. Food and Drug
Administration
July 18, 2001 For updates: http://www.fda.gov/cdrh/phones
RH-4_FCC_2003-4-16.fm Page 102 Friday, April 18, 2003 4:34 PM
103
English
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems are
associated with using wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones emit low levels of
radiofrequency energy (RF) in the microwave range while being used. They
also emit very low levels of RF when in the stand-by mode. Whereas high
levels of RF can produce health effects (by heating tissue), exposure to low
level RF that does not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures have not found any
biological effects. Some studies have suggested that some biological effects
may occur, but such findings have not been confirmed by additional research.
In some cases, other researchers have had difficulty in reproducing those
studies, or in determining the reasons for inconsistent results.
2. What is FDA's role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting
consumer products such as wireless phones before they can be sold, as it does
with new drugs or medical devices. However, the agency has authority to take
action if wireless phones are shown to emit radiofrequency energy (RF) at a
level that is hazardous to the user. In such a case, FDA could require the
manufacturers of wireless phones to notify users of the health hazard and to
repair, replace or recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory actions,
FDA has urged the wireless phone industry to take a number of steps,
including the following:
• Support needed research into possible biological effects of RF of the type
emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF exposure to the user
that is not necessary for device function; and
• Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health.
FDA belongs to an interagency working group of the federal agencies that
have responsibility for different aspects of RF safety to ensure coordinated
efforts at the federal level. The following agencies belong to this working
group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
RH-4_FCC_2003-4-16.fm Page 103 Friday, April 18, 2003 4:34 PM
104
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency working
group activities, as well.
FDA shares regulatory responsibilities for wireless phones with the Federal
Communications Commission (FCC). All phones that are sold in the United
States must comply with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety questions about wireless
phones.
FCC also regulates the base stations that the wireless phone networks rely
upon. While these base stations operate at higher power than do the wireless
phones themselves, the RF exposures that people get from these base stations
are typically thousands of times lower than those they can get from wireless
phones. Base stations are thus not the subject of the safety questions
discussed in this document.
3. What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held wireless phones with built-
in antennas, often called cell mobile or PCS phones. These types of wireless
phones can expose the user to measurable radiofrequency energy (RF)
because of the short distance between the phone and the user’s head. These
RF exposures are limited by Federal Communications Commission safety
guidelines that were developed with the advice of FDA and other federal
health and safety agencies. When the phone is located at greater distances
from the user, the exposure to RF is drastically lower because a person's RF
exposure decreases rapidly with increasing distance from the source. The so-
called cordless phones; which have a base unit connected to the telephone
wiring in a house, typically operate at far lower power levels, and thus
produce RF exposures far below the FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many studies
have suffered from flaws in their research methods. Animal experiments
investigating the effects of radiofrequency energy (RF) exposures
characteristic of wireless phones have yielded conflicting results that often
cannot be repeated in other laboratories. A few animal studies, however, have
suggested that low levels of RF could accelerate the development of cancer in
RH-4_FCC_2003-4-16.fm Page 104 Friday, April 18, 2003 4:34 PM
105
English
laboratory animals. However, many of the studies that showed increased
tumor development used animals that had been genetically engineered or
treated with cancer-causing chemicals so as to be pre-disposed to develop
cancer in the absence of RF exposure. Other studies exposed the animals to RF
for up to 22 hours per day. These conditions are not similar to the conditions
under which people use wireless phones, so we don’t know with certainty
what the results of such studies mean for human health.
Three large epidemiology studies have been published since December 2000.
Between them, the studies investigated any possible association between the
use of wireless phones and primary brain cancer, glioma, meningioma, or
acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other
cancers. None of the studies demonstrated the existence of any harmful
health effects from wireless phone RF exposures. However, none of the
studies can answer questions about long-term exposures, since the average
period of phone use in these studies was around three years.
5. What research is needed to decide whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people
actually using wireless phones would provide some of the data that are
needed. Lifetime animal exposure studies could be completed in a few years.
However, very large numbers of animals would be needed to provide reliable
proof of a cancer promoting effect if one exists. Epidemiological studies can
provide data that is directly applicable to human populations, but 10 or more
years follow-up may be needed to provide answers about some health effects,
such as cancer. This is because the interval between the time of exposure to a
cancer-causing agent and the time tumors develop - if they do - may be
many, many years. The interpretation of epidemiological studies is hampered
by difficulties in measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement, such as the angle at
which the phone is held, or which model of phone is used.
6. What is FDA doing to find out more about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of
investigators around the world to ensure that high priority animal studies are
conducted to address important questions about the effects of exposure to
radiofrequency energy (RF). FDA has been a leading participant in the World
Health Organization International Electromagnetic Fields (EMF) Project since
RH-4_FCC_2003-4-16.fm Page 105 Friday, April 18, 2003 4:34 PM
106
its inception in 1996. An influential result of this work has been the
development of a detailed agenda of research needs that has driven the
establishment of new research programs around the world. The Project has
also helped develop a series of public information documents on EMF issues.
FDA and the Cellular Telecommunications & Internet Association (CTIA) have
a formal Cooperative Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the scientific oversight,
obtaining input from experts in government, industry, and academic
organizations. CTIA-funded research is conducted through contracts to
independent investigators. The initial research will include both laboratory
studies and studies of wireless phone users. The CRADA will also include a
broad assessment of additional research needs in the context of the latest
research developments around the world.
7. How can I find out how much radiofrequency energy exposure I can get
by using my wireless phone?
All phones sold in the United States must comply with Federal
Communications Commission (FCC) guidelines that limit radiofrequency
energy (RF) exposures. FCC established these guidelines in consultation with
FDA and the other federal health and safety agencies. The FCC limit for RF
exposure from wireless telephones is set at a Specific Absorption Rate (SAR)
of 1.6 watts per kilogram (1.6 W/kg). The FCC limit is consistent with the
safety standards developed by the Institute of Electrical and Electronic
Engineering (IEEE) and the National Council on Radiation Protection and
Measurement. The exposure limit takes into consideration the body’s ability to
remove heat from the tissues that absorb energy from the wireless phone and
is set well below levels known to have effects.
Manufacturers of wireless phones must report the RF exposure level for each
model of phone to the FCC. The FCC website (http://www.fcc.gov/oet/rfsafety)
gives directions for locating the FCC identification number on your phone so
you can find your phone’s RF exposure level in the online listing.
8. What has FDA done to measure the radiofrequency energy coming from
wireless phones?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a
technical standard for measuring the radiofrequency energy (RF) exposure
from wireless phones and other wireless handsets with the participation and
leadership of FDA scientists and engineers. The standard, Recommended
Practice for Determining the Spatial-Peak Specific Absorption Rate (SAR) in
RH-4_FCC_2003-4-16.fm Page 106 Friday, April 18, 2003 4:34 PM
107
English
the Human Body Due to Wireless Communications Devices: Experimental
Techniques, sets forth the first consistent test methodology for measuring the
rate at which RF is deposited in the heads of wireless phone users. The test
method uses a tissue-simulating model of the human head. Standardized SAR
test methodology is expected to greatly improve the consistency of
measurements made at different laboratories on the same phone. SAR is the
measurement of the amount of energy absorbed in tissue, either by the whole
body or a small part of the body. It is measured in watts/kg (or milliwatts/g) of
matter. This measurement is used to determine whether a wireless phone
complies with safety guidelines.
9. What steps can I take to reduce my exposure to radiofrequency energy
from my wireless phone?
If there is a risk from these products--and at this point we do not know that
there is--it is probably very small. But if you are concerned about avoiding
even potential risks, you can take a few simple steps to minimize your
exposure to radiofrequency energy (RF). Since time is a key factor in how
much exposure a person receives, reducing the amount of time spent using a
wireless phone will reduce RF exposure.
If you must conduct extended conversations by wireless phone every day, you
could place more distance between your body and the source of the RF, since
the exposure level drops off dramatically with distance. For example, you
could use a headset and carry the wireless phone away from your body or use
a wireless phone connected to a remote antenna. Again, the scientific data do
not demonstrate that wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can use measures like those
described above to reduce your RF exposure from wireless phone use.
10. What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless phones,
including children and teenagers. If you want to take steps to lower exposure
to radiofrequency energy (RF), the measures described above would apply to
children and teenagers using wireless phones. Reducing the time of wireless
phone use and increasing the distance between the user and the RF source
will reduce RF exposure.Some groups sponsored by other national
governments have advised that children be discouraged from using wireless
phones at all. For example, the government in the United Kingdom distributed
leaflets containing such a recommendation in December 2000. They noted
that no evidence exists that using a wireless phone causes brain tumors or
RH-4_FCC_2003-4-16.fm Page 107 Friday, April 18, 2003 4:34 PM
108
other ill effects. Their recommendation to limit wireless phone use by children
was strictly precautionary; it was not based on scientific evidence that any
health hazard exists.
11. What about wireless phone interference with medical equipment?
Radiofrequency energy (RF) from wireless phones can interact with some
electronic devices. For this reason, FDA helped develop a detailed test method
to measure electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones. This test method is
now part of a standard sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint effort by FDA, medical
device manufacturers, and many other groups, was completed in late 2000.
This standard will allow manufacturers to ensure that cardiac pacemakers and
defibrillators are safe from wireless phone EMI. FDA has tested hearing aids
for interference from handheld wireless phones and helped develop a
voluntary standard sponsored by the Institute of Electrical and Electronic
Engineers (IEEE). This standard specifies test methods and performance
requirements for hearing aids and wireless phones so that no interference
occurs when a person uses a compatible phone and a accompanied hearing
aid at the same time. This standard was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones for possible interactions
with other medical devices. Should harmful interference be found to occur,
FDA will conduct testing to assess the interference and work to resolve the
problem.
12. Where can I find additional information?
For additional information, please refer to the following resources:
FDA web page on wireless phones
http://www.fda.gov/cdrh/phones/index.html
Federal Communications Commission (FCC) RF Safety Program
http://www.fcc.gov/oet/rfsafety
International Commission on Non-Ionizing Radiation Protection
http://www.icnirp.de
World Health Organization (WHO) International EMF Project
http://www.who.int/emf
National Radiological Protection Board (UK)
http://www.nrpb.org.uk/
RH-4_FCC_2003-4-16.fm Page 108 Friday, April 18, 2003 4:34 PM
109
English
July 18, 2001 For updates: http://www.fda.gov/cdrh/phones
RH-4_FCC_2003-4-16.fm Page 109 Friday, April 18, 2003 4:34 PM
