Microsoft RM-126H GSM 850/1800/1900 User Manual FCC 6126H 6133H en 1 FCC
Microsoft Mobile Oy GSM 850/1800/1900 FCC 6126H 6133H en 1 FCC
Contents
- 1. User Guide
- 2. Manual
User Guide
DRAFT
Nokia 6126H/6133H User Guide
FCC Draft
Issue 1
FCC_6126H_6133H_en_1_FCC.fm Page 1 Tuesday, June 27, 2006 1:35 PM
DRAFT
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION, declares that this product RM-126 is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
A copy of the Declaration of Conformity can be found from
http://www.nokia.com/phones/declaration_of_conformity/.
The crossed-out wheeled bin means that within the European Union the product
must be taken to separate collection at the product end-of life. This applies to
your device but also to any enhancements marked with this symbol. Do not
dispose of these products as unsorted municipal waste.
Copyright © 2006 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
Nokia, Visual Radio, Nokia Connecting People, Xpress-on, XpressPrint, and Pop-Port are
trademarks or registered trademarks of Nokia Corporation. Other product and company
names mentioned herein may be trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C)
1997-2006. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java is a trademark of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and
noncommercial use in connection with information which has been encoded in compliance
with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial
activity and (ii) for use in connection with MPEG-4 video provided by a licensed video
provider. No license is granted or shall be implied for any other use. Additional information
including that relating to promotional, internal and commercial uses may be obtained from
MPEG LA, LLC. See <http://www.mpegla.com>.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document without prior
notice.
0434
FCC_6126H_6133H_en_1_FCC.fm Page 2 Tuesday, June 27, 2006 1:35 PM
DRAFT
This Nokia device complies with Directive 2002/95/EC on the restriction of the use of certain
hazardous substances in electrical and electronic equipment.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer
nearest to you.
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close
proximity to receiving equipment). The FCC or Industry Canada can require you to stop using
your telephone if such interference cannot be eliminated. If you require assistance, contact
your local service facility. This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation. Any changes or modifications not expressly approved by Nokia
could void the user's authority to operate this equipment.
FCC Draft/Issue 1
FCC_6126H_6133H_en_1_FCC.fm Page 3 Tuesday, June 27, 2006 1:35 PM
4
DRAFT
Contents
For your safety.......................... 6
General information................. 9
Overview of functions........................... 9
Access codes............................................ 9
Configuration settings service ........ 10
Download content .............................. 11
Nokia support....................................... 11
1. Get started ......................... 12
Install SIM card and battery............ 12
Insert a microSD card ........................ 13
Remove the microSD card ................ 13
Charge the battery.............................. 13
Open and close the phone................ 14
Switch the phone on and off........... 14
Antenna ................................................. 15
Phone strap........................................... 15
2. Your phone......................... 16
Keys and parts...................................... 16
Standby mode...................................... 17
Keypad lock (keyguard) ..................... 20
Functions without a SIM card......... 20
3. Call functions..................... 21
Make a call ........................................... 21
Answer or reject a call....................... 22
Options during a call.......................... 23
4. Write text........................... 24
Predictive text input .......................... 24
Traditional text input......................... 25
5. Navigate the menus .......... 26
6. Messaging .......................... 27
Text messages (SMS).......................... 27
SIM messages....................................... 28
Multimedia messages (MMS).......... 29
Memory full.......................................... 31
Folders.................................................... 31
Postcards ............................................... 32
Flash messages .................................... 33
Nokia Xpress audio messaging........ 33
E-mail application .............................. 34
Instant messaging............................... 37
Voice messages.................................... 42
Info messages ...................................... 42
Service commands.............................. 42
Delete messages.................................. 43
Message settings................................. 43
7. Contacts.............................. 47
Search for a contact .......................... 47
Save names and phone numbers.... 47
Save details........................................... 47
Copy or move contacts...................... 48
Edit contact details ............................ 48
Synchronize all .................................... 48
Delete contacts.................................... 48
My presence ......................................... 49
Subscribed names ............................... 50
Business cards...................................... 51
Settings.................................................. 51
Groups.................................................... 52
Speed dials............................................ 52
Info, service, and my numbers ........ 52
8. Call log................................ 53
Positioning information .................... 53
9. Settings ............................. 54
Profiles ................................................... 54
Themes ................................................... 54
Tones....................................................... 54
Main display ......................................... 55
Mini display .......................................... 56
Time and date ...................................... 56
FCC_6126H_6133H_en_1_FCC.fm Page 4 Tuesday, June 27, 2006 1:35 PM
5
DRAFT
My shortcuts......................................... 57
Connectivity.......................................... 58
Call........................................................... 64
Phone ...................................................... 65
Enhancements...................................... 66
Configuration........................................ 66
Security .................................................. 67
Phone software updates.................... 68
Restore factory settings..................... 70
10.Operator menu.................. 70
11.Gallery ............................... 71
Print images.......................................... 71
Memory card......................................... 71
12.Media ................................ 73
Camera ................................................... 73
Media player ......................................... 74
Music player.......................................... 75
Radio ....................................................... 76
Voice recorder....................................... 78
Equalizer................................................. 78
Stereo widening................................... 79
13.Organizer........................... 80
Alarm clock............................................ 80
Calendar................................................. 80
To-do list................................................ 81
Notes....................................................... 82
Calculator .............................................. 82
Countdown timer ................................ 83
Stopwatch ............................................. 83
14.Push to talk....................... 84
Push to talk channels......................... 84
Switch PTT on and off ........................ 86
Make and receive a PTT call ............. 86
Callback requests................................. 88
Add a one-to-one contact................ 89
PTT settings ........................................... 89
Configuration settings ....................... 90
Web ......................................................... 90
15.Applications ...................... 91
Launch a game..................................... 91
Launch an application........................ 91
Some application options ................. 91
Download an application .................. 92
Presenter ................................................ 92
16.SIM services....................... 94
17.Web.................................... 95
Set up browsing................................... 95
Connect to a service........................... 95
Browse pages........................................ 96
Bookmarks ............................................. 97
Appearance settings ........................... 97
Security settings .................................. 98
Download settings .............................. 99
Service inbox ........................................ 99
Cache memory................................... 100
Browser security ............................... 100
18.PC connectivity .............. 102
Nokia PC Suite................................... 102
EGPRS, HSCSD, and CSD................. 102
Data communication applications 102
19.Battery information....... 103
Charging and discharging.............. 103
Nokia battery authentication ....... 104
20.Technical Information ... 106
Care and maintenance ........ 107
Additional safety information....
108
APPENDIX ............................ 113
Index..................................... 122
FCC_6126H_6133H_en_1_FCC.fm Page 5 Tuesday, June 27, 2006 1:35 PM
For your safety
6
DRAFT
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.
INTERFERENCE
All wireless phones may be susceptible to interference, which could
affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the phone off near medical
equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in
aircraft.
SWITCH OFF WHEN REFUELLING
Do not use the phone at a refuelling point. Do not use near fuel or
chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the phone where blasting is in
progress.
USE SENSIBLY
Use only in the normal position as explained in the product
documentation. Do not touch the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect
incompatible products.
FCC_6126H_6133H_en_1_FCC.fm Page 6 Tuesday, June 27, 2006 1:35 PM
For your safety
7
DRAFT
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a written record of all
important information stored in your phone.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed
safety instructions. Do not connect incompatible products.
EMERGENCY CALLS
Ensure the phone is switched on and in service. Press the end key as
many times as needed to clear the display and return to the start
screen. Enter the emergency number, then press the call key. Give
your location. Do not end the call until given permission to do so.
■About your device
The wireless device described in this guide is approved for use on the EGSM 850,
900, 1800 and 1900 networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and respect the privacy and
legitimate rights of others.
When taking and using images or video clips, obey all laws and respect local
customs as well as privacy and legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on when
wireless device use may cause interference or danger.
■Network services
To use the phone you must have service from a wireless service provider. Many of
the features in this device depend on features in the wireless network to
function. These network services may not be available on all networks or you may
have to make specific arrangements with your service provider before you can
utilize network services. Your service provider may need to give you additional
instructions for their use and explain what charges will apply. Some networks
may have limitations that affect how you can use network services. For instance,
some networks may not support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, they will not appear on your device menu. Your
FCC_6126H_6133H_en_1_FCC.fm Page 7 Tuesday, June 27, 2006 1:35 PM
For your safety
8
DRAFT
device may also have been specially configured for your network provider. This
configuration may include changes in menu names, menu order and icons.
Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP
protocols. Some features of this device, such as multimedia messaging (MMS),
browsing, e-mail application, instant messaging, presence enhanced contacts,
remote synchronization, and content downloading using the browser or MMS,
require network support for these technologies.
■Shared memory
The following features in this device may share memory: gallery, contacts, text
messages, multimedia messages, and instant messages, e-mail, calendar, to-do
notes, JavaTM games and applications, and note application. Use of one or more of
these features may reduce the memory available for the remaining features
sharing memory. For example, saving many Java applications may use all of the
available memory. Your device may display a message that the memory is full
when you try to use a shared memory feature. In this case, delete some of the
information or entries stored in the shared memory features before continuing.
Some of the features, such as text messages, may have a certain amount of
memory specially allotted to them in addition to the memory shared with other
features.
■Enhancements
A few practical rules about accessories and enhancements
• Keep all accessories and enhancements out of the reach of small children.
• When you disconnect the power cord of any accessory or enhancement, grasp
and pull the plug, not the cord.
• Check regularly that enhancements installed in a vehicle are mounted and
are operating properly.
• Installation of any complex car enhancements must be made by qualified
personnel only.
FCC_6126H_6133H_en_1_FCC.fm Page 8 Tuesday, June 27, 2006 1:35 PM
General information
9
DRAFT
General information
■Overview of functions
Your phone provides many functions that are practical for daily use,
such as a text and multimedia messaging, a calendar, a clock, an alarm
clock, a radio, a music player, and a built-in camera. Your phone also
supports the following functions:
• Plug and play online service to get the configuration settings. See
“Plug and play service,”p. 15, and “Configuration settings service,”
p. 10.
• Push to talk. See “Push to talk,” p. 84.
• A microSD memory card to extend the memory capacity of the
phone. See “Insert a microSD card,” p. 13 and “Memory card,” p. 71.
• Active standby. See “Active standby,” p. 17.
• Audio messaging. See “Nokia Xpress audio messaging,” p. 33.
• Instant messaging. See “Instant messaging,” p. 37.
• E-mail application. See “E-mail application,” p. 34.
• Enhanced voice dialing. See “Enhanced voice dialing,” p. 21 and
“Voice commands,” p. 58.
• Hearing aid coil. See “Activate the hearing aid mode,” p. 66 and
“Hearing Aid Compatibility,” p. 110.
• Presence-enhanced contacts. See “My presence,” p. 49.
• Java 2 Platform, Micro Edition (J2METM). See “Applications,” p. 91.
■Access codes
Security code
The security code (5 to 10 digits) helps to protect your phone against
unauthorized use. The preset code is 12345. To change the code, and to
set the phone to request the code, see “Security,” p. 67.
FCC_6126H_6133H_en_1_FCC.fm Page 9 Tuesday, June 27, 2006 1:35 PM
General information
10
DRAFT
PIN codes
The personal identification number (PIN) code and the universal
personal identification number (UPIN) code (4 to 8 digits) help to
protect your SIM card against unauthorized use. See “Security,” p. 67.
The PIN2 code (4 to 8 digits) may be supplied with the SIM card and is
required for some functions.
The module PIN is required to access the information in the security
module. See “Security module,” p. 100.
The signing PIN is required for the digital signature. See “Digital
signature,” p. 101.
PUK codes
The personal unblocking key (PUK) code and the universal personal
unblocking key (UPUK) code (8 digits) is required to change a blocked
PIN code and UPIN code, respectively. The PUK2 code (8 digits) is
required to change a blocked PIN2 code. If the codes are not supplied
with the SIM card, contact your local service provider for the codes.
Barring password
The barring password (4 digits) is required when using the Call barring
service. See “Security,” p. 67.
■Configuration settings service
To use some of the network services, such as mobile Internet services,
MMS, Nokia Xpress audio messaging, or remote Internet server
synchronization, your phone needs the correct configuration settings.
You may be able to receive the settings directly as a configuration
message. After receiving the settings you need to save them on your
phone. The service provider may provide a PIN that is needed to save the
settings. For more information on availability, contact your network
operator, service provider, nearest authorized Nokia dealer, or visit the
support area on the Nokia Web site, www.nokia.com/support.
When you have received the settings as a configuration message, and
the settings are not automatically saved and activated, Configuration
settings received is displayed.
FCC_6126H_6133H_en_1_FCC.fm Page 10 Tuesday, June 27, 2006 1:35 PM
General information
11
DRAFT
To save the settings, select Show > Save. If the phone requests Enter
settings' PIN:, enter the PIN code for the settings, and select OK. To
receive the PIN code, contact the service provider that supplies the
settings. If no settings are saved yet, these settings are saved and set as
default configuration settings. Otherwise, the phone asks Activate saved
configuration settings?.
To discard the received settings, select Exit or Show > Discard.
■Download content
You may be able to download new content (for example, themes) to the
phone (network service). Select the download function (for example, in
the Gallery menu). To access the download function, see the respective
menu descriptions.
You may also be able to download updates of phone software (network
service). See “Phone,” p. 65, Phone updates.
For the availability of different services, pricing, and tariffs, contact your
service provider.
Important: Use only services that you trust and that offer adequate
security and protection against harmful software.
■Nokia support
Check www.nokia.com/support or your local Nokia Web site for the
latest version of this guide, additional information, downloads, and
services related to your Nokia product.
On the Web site, you can get information on the use of Nokia products
and services. If you need to contact customer service, check the list of
local Nokia Care contact centers at www.nokia.com/customerservice.
For maintenance services, check your nearest Nokia service center at
www.nokia.com/repair.
FCC_6126H_6133H_en_1_FCC.fm Page 11 Tuesday, June 27, 2006 1:35 PM
Get started
12
DRAFT
1. Get started
■Install SIM card and battery
Always switch the device off and disconnect the charger before removing the
battery.
Keep all SIM cards out of the reach of small children.
For availability and information on using SIM card services, contact your SIM
card vendor. This may be the service provider, network operator, or other vendor.
This device is intended for use with BL-4C battery. Always use original
Nokia batteries. See “Nokia battery authentication,” p. 104.
The SIM card and its contacts can easily be damaged by scratches or
bending, so be careful when handling, inserting, or removing the card.
To remove the back
cover of the phone,
press sightly (1) and
slide the cover (2).
Remove the battery as
shown (3).
Open the SIM card
holder (4). and insert
the SIM card properly
into the holder (5).
Close the SIM card
holder (6).
Replace the battery (7).
Slide the back cover
into its place (8, 9).
FCC_6126H_6133H_en_1_FCC.fm Page 12 Tuesday, June 27, 2006 1:35 PM
Get started
13
DRAFT
■Insert a microSD card
Keep all microSD memory cards out of the reach of small children.
1. Remove the back cover of the phone.
2. Insert the card into the microSD card
slot with the golden contact surface
facing down, and press it until it locks
into place.
3. Close the back cover of the phone.
Use only compatible microSD cards with this device. Other memory cards, such as
Reduced Size MultiMedia cards, do not fit in the microSD card slot and are not
compatible with this device. Using an incompatible memory card may damage
the memory card as well as the device, and data stored on the incompatible card
may be corrupted.
Use only microSD cards approved by Nokia for use with this device. Nokia utilizes
the approved industry standards for memory cards but not all other brands may
function correctly or be fully compatible with this device.
■Remove the microSD card
Important: Do not remove the microSD card in the middle of an
operation when the card is being accessed. Removing the card in the
middle of an operation may damage the memory card as well as the
device, and data stored on the card may be corrupted.
You can remove or replace the microSD card during phone operation
without switching the phone off.
1. Make sure that no application is currently accessing the micro SD
memory card.
2. Remove the back cover of the phone.
3. Press the microSD card slightly in to release the locking.
4. Remove the microSD card from the slot.
■Charge the battery
Check the model number of any charger before use with this device. This device is
intended for use when supplied with power from an AC-3 or AC-4 charger.
FCC_6126H_6133H_en_1_FCC.fm Page 13 Tuesday, June 27, 2006 1:35 PM
Get started
14
DRAFT
Warning: Use only batteries, chargers, and enhancements approved by
Nokia for use with this particular model. The use of any other types may
invalidate any approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer. When
you disconnect the power cord of any enhancement, grasp and pull the plug, not
the cord.
1. Connect the charger to a wall socket.
2. Connect the lead from the charger to the socket
on the bottom of your phone.
If the battery is completely discharged, it may take a
few minutes before the charging indicator appears
on the display or before any calls can be made.
The charging time depends on the charger used. Charging a BL-4C
battery with the AC-3 charger takes approximately 2 hours and
20 minutes while the phone is in the standby mode.
■Open and close the phone
To open the phone press the fold
release button (1). The fold opens
automatically (2).
To close the phone turn the fold
manually in its closed position.
To switch off a tone that sounds
when you open and close the
phone, see “Tones,” p. 54.
■Switch the phone on and off
Warning: Do not switch the phone on when wireless phone use is
prohibited or when it may cause interference or danger.
To switch the phone on or off, press and hold the power key. See “Keys
and parts,” p. 16. If the phone asks for a PIN or a UPIN code, enter the
code (displayed as ****), and select OK.
FCC_6126H_6133H_en_1_FCC.fm Page 14 Tuesday, June 27, 2006 1:35 PM
Get started
15
DRAFT
Set the time, time zone, and date
Enter the local time, select the time zone of your location in terms of the
time difference with respect to Greenwich Mean Time (GMT), and enter
the date. See “Time and date,” p. 56.
Plug and play service
When you switch on your phone for the first time, and the phone is in
the standby mode, you are asked to get the configuration settings from
your service provider (network service). Confirm or decline the query.
See "Connect to serv. support," p. 67, and “Configuration settings
service,” p. 10.
■Antenna
Your device has an internal antenna.
Note: As with any other radio
transmitting device, do not touch
the antenna unnecessarily when the
device is switched on. Contact with
the antenna affects call quality and
may cause the device to operate at a
higher power level than otherwise
needed. Avoiding contact with the
antenna area when operating the
device optimizes the antenna
performance and the battery life.
■Phone strap
Thread the strap through the eyelet of the
phone as shown in the picture and tighten it.
FCC_6126H_6133H_en_1_FCC.fm Page 15 Tuesday, June 27, 2006 1:35 PM
Your phone
16
DRAFT
2. Your phone
■Keys and parts
1Earpiece
2Main display
3Left and right selection keys
4Middle selection key
5Call key
6Keypad
7Infrared window
8Fold release button
94-way navigation key
10 End key
11 Loudspeaker
12 Phone strap eyelet
13 Pop-PortTM connector flap
14 Charger connector
15 Camera lens
16 Volume keys (Volume up = PTT key)
17 Mini display
18 Camera key
19 Power key
Connector flap
To connect enhancements, open the Pop-PortTM
connector flap.
FCC_6126H_6133H_en_1_FCC.fm Page 16 Tuesday, June 27, 2006 1:35 PM
Your phone
17
DRAFT
■Standby mode
When the phone is ready for use, and you have not entered any
characters, the phone is in the standby mode.
Main display
1Signal strength of the cellular network
2Battery charge status
3Indicators
4Name of the network or the operator logo
5Clock
6Main screen
7Function of the left selection key is Go to
or a shortcut to another function.
See “Left selection key,”p. 57.
8Function of the middle selection key is Menu
9Function of the right selection key is Names or
a shortcut to another function. See “Right selection key,” p. 57.
Operator variants may have an operator-specific name to access an
operator-specific Web site.
Active standby
In the active standby mode there is a list of selected phone features and
information on the screen that you can directly access in the standby
mode. To switch on the mode, select Menu > Settings > Main display >
Standby mode settings >Active standby > My active standby. In the
standby mode, scroll up or down to activate the navigation in the list. To
start the feature, select Select; or to display the information, select
View. Left and right arrows at the beginning and end of a line indicate
that further information is available by scrolling left or right. To end the
active standby navigation mode, select Exit.
FCC_6126H_6133H_en_1_FCC.fm Page 17 Tuesday, June 27, 2006 1:35 PM
Your phone
18
DRAFT
To organize and change the active standby mode, activate the
navigation mode, and select Options > Active standby > My active
standby > Options and the following options:
Personalise — Assign or change phone features in the standby mode.
Organise — Move the position of features in the standby mode.
Enabling active standby — Select keys to activate the standby
navigation mode. To change the settings, see “Standby mode settings,”
p. 55.
To switch off the active standby mode select Options > Active
standby > Off; or select Menu > Settings > Main display > Standby
mode settings >Active standby > Off.
Shortcuts in the standby mode
• To access the list of dialed numbers, press the call key once. Scroll to
the number or name that you want; and to call the number, press the
call key.
• To open the web browser, press and hold 0.
• To call your voice mailbox, press and hold 1.
• Use the navigation key as a shortcut. See “My shortcuts,” p. 57.
• Press the camera key to start the camera (still photo).
• In camera mode press the volume keys to zoom in or out.
• Press a volume key to mute the ringing tone of an incoming call
when the phone is closed.
• Press the power key to access the profiles menu on the main display.
Indicators
You have unread messages in the Inbox folder.
You have unsent, canceled or failed messages in the Outbox
folder.
The phone registered a missed call.
FCC_6126H_6133H_en_1_FCC.fm Page 18 Tuesday, June 27, 2006 1:35 PM
Your phone
19
DRAFT
, Your phone is connected to the instant messaging service, and
the availability status is online or offline.
You received one or several instant messages, and you are
connected to the instant messaging service.
The keypad is locked.
The phone does not ring for an incoming call or text message.
The alarm clock is set to On.
The countdown timer is running.
The stopwatch is running in the background.
, The phone is registered to the GPRS or EGPRS network.
, A GPRS or EGPRS connection is established.
, The GPRS or EGPRS connection is suspended (on hold), for
example, if there is an incoming or outgoing call during an
EGPRS dial-up connection.
A Bluetooth connection is active.
,Push to talk connection is active or suspended. See “Push to
talk,” p. 84.
If you have two phone lines, the second phone line is selected.
All incoming calls are diverted to another number.
The loudspeaker is activated, or the music stand is connected to
the phone.
Calls are limited to a closed user group.
The timed profile is selected.
, , , or
A headset, hands-free, loopset, or music stand enhancement is
connected to the phone.
FCC_6126H_6133H_en_1_FCC.fm Page 19 Tuesday, June 27, 2006 1:35 PM
Your phone
20
DRAFT
■Keypad lock (keyguard)
To prevent the keys from being accidentally pressed, select Menu, and
press * within 3.5 seconds to lock the keypad.
To unlock the keypad, select Unlock, and press * within 1.5 seconds. If
the Security keyguard is set On, enter the security code if requested.
To answer a call when the keyguard is on, press the call key. When you
end or reject the call, the keypad automatically locks.
For Automatic keyguard and Security keyguard,, see “Phone,” p. 65.
When the keyguard is on, calls still may be possible to the official emergency
number programmed into your device.
■Functions without a SIM card
Several functions of your phone may be used without installing a SIM
card (for example the data transfer with a compatible PC or another
compatible device). Note that when you use the phone without a SIM
card, some functions appear dimmed in the menus and cannot be used.
Synchronizing with a remote Internet server is not possible without a
SIM card.
For an emergency call, some networks may require that a valid SIM card is
properly inserted in the device.
FCC_6126H_6133H_en_1_FCC.fm Page 20 Tuesday, June 27, 2006 1:35 PM
Call functions
21
DRAFT
3. Call functions
■Make a call
1. Enter the phone number, including the area code.
For international calls, press * twice for the international prefix (the
+ character replaces the international access code), enter the
country code, the area code without the leading 0, if necessary, and
the phone number.
2. To call the number, press the call key.
3. To end the call or to cancel the call attempt, press the end key, or
close the phone.
To search for a name or phone number that you have saved in Contacts,
see “Search for a contact,” p. 47. Press the call key to call the number.
To access the list of dialled numbers, press the call key once in the
standby mode. To call the number, select a number or name, and press
the call key.
Speed dialing
Assign a phone number to one of the speed-dialing keys, 2 to 9. See
“Speed dials,” p. 52. Call the number in either of the following ways:
• Press a speed-dialing key, then the call key.
•If Speed dialling is set to On, press and hold a speed-dialing key until
the call begins. See Speed dialling in “Call,” p. 64.
Enhanced voice dialing
You can make a phone call by saying the name that is saved in the
contact list of the phone. A voice command is added automatically to all
entries in the contact list of the phone.
If an application is sending or receiving data using a packet data
connection, end the application before you use voice dialing.
FCC_6126H_6133H_en_1_FCC.fm Page 21 Tuesday, June 27, 2006 1:35 PM
Call functions
22
DRAFT
Voice commands are language-dependent. To set the language, see
Voice playback language in “Phone,” p. 65.
Note: Using voice tags may be difficult in a noisy environment or
during an emergency, so you should not rely solely upon voice dialing in
all circumstances.
1. In the standby mode, press and hold the right selection key or press
and hold the volume down key. A short tone is played, and Speak now
is displayed.
If you are using a compatible headset with the headset key, press and
hold the headset key to start the voice dialing.
2. Say the voice command clearly. If the voice recognition was
successful, a list with matches is shown. The phone plays the voice
command of the match on the top of the list. After about
1.5 seconds, the phone dials the number; or if the result is not the
correct one, scroll to another entry, and select to dial the entry.
Using voice commands to carry out a selected phone function is
similar to voice dialing. See Voice commands in “My shortcuts,” p. 57.
■Answer or reject a call
To answer an incoming call, press the call key, or open the phone. To end
the call, press the end key or close the phone.
To reject an incoming call if the phone is open, press the end key. To
reject an incoming call when the phone is closed, press and hold a
volume key.
To mute the ringing tone, press a volume key when the phone is closed,
or select Silence when the phone is open.
Tip: If the Divert if busy function is activated to divert the calls
(for example, to your voice mailbox), rejecting an incoming call
also diverts the call. See “Call,” p. 64.
If a compatible headset supplied with the headset key is connected to
the phone, to answer and end a call, press the headset key.
FCC_6126H_6133H_en_1_FCC.fm Page 22 Tuesday, June 27, 2006 1:35 PM
Call functions
23
DRAFT
Call waiting
To answer the waiting call during an active call, press the call key. The
first call is put on hold. To end the active call, press the end key.
To activate the Call waiting function, see “Call,” p. 64.
■Options during a call
Many of the options that you can use during a call are network services.
For availability, contact your service provider.
During a call, select Options and from the following options:
Call options are Mute or Unmute, Contacts, Menu, Lock keypad, Record,
Loudspeaker or Handset.
Network services options are Answer or Reject, Hold or Unhold, New
call, Add to conference, End call, End all calls, and the following:
Send DTMF — to send tone strings
Swap — to switch between the active call and the call on hold
Transfer — to connect a call on hold to an active call and disconnect
yourself
Conference — to make a conference call that allows up to five persons to
take part in a conference call
Private call —to discuss privately in a conference call
Warning: Do not hold the device near your ear when the loudspeaker
is in use, because the volume may be extremely loud.
FCC_6126H_6133H_en_1_FCC.fm Page 23 Tuesday, June 27, 2006 1:35 PM
Write text
24
DRAFT
4. Write text
You can enter text (for example, when writing messages) using
traditional or predictive text input. When you write text, text input
indicators appear at the top of the display. indicates traditional text
input. indicates predictive text input. Predictive text input allows
you to write text quickly using the phone keypad and a built-in
dictionary. You can enter a letter with a single keypress. indicates
predictive text input with Word suggestions. The phone predicts and
completes the word before you enter all the characters.
, , or appears next to the text input indicator, indicating
the character case. To change the character case, press #.
indicates number mode. To change from the letter to number mode,
press and hold #, and select Number mode.
To set the writing language while writing text, select Options > Writing
language.
■Predictive text input
To set predictive text input on, select Options > Prediction on.
Tip: To quickly set predictive text input on or off when writing
text, press # twice, or select and hold Options.
1. Start writing a word using the 2 to 9 keys. Press each key only once
for one letter. The entered letters are displayed underlined.
To insert a special character, press and hold *, or select Options >
Insert symbol. Scroll to a character, and select Use.
To write compounds words, enter the first part of the word; to
confirm it, press the navigation key right. Write the next part of the
word and confirm the word.
To enter a full stop, press 1.
2. When you finish writing the word and it is correct, to confirm it,
press 0 to add space.
FCC_6126H_6133H_en_1_FCC.fm Page 24 Tuesday, June 27, 2006 1:35 PM
Write text
25
DRAFT
If the word is not correct, press * repeatedly, or select Options >
Matches. When the word that you want appears, select the word and
press the navigation key.
If the ? character is displayed after the word, the word you intended
to write is not in the dictionary. To add the word to the dictionary,
select Spell. Complete the word (traditional text input is used), and
select Save.
■Traditional text input
To set traditional text input on, select Options > Prediction off.
Press a number key, 1 to 9, repeatedly until the desired character
appears. Not all characters available under a number key are printed on
the key. The characters available depend on the selected writing
language.
If the next letter you want is located on the same key as the present one,
wait until the cursor appears, or briefly press any of the navigation keys
and enter the letter.
The most common punctuation marks and special characters are
available under the 1 key. For more characters, press *.
FCC_6126H_6133H_en_1_FCC.fm Page 25 Tuesday, June 27, 2006 1:35 PM
Navigate the menus
26
DRAFT
5. Navigate the menus
The phone offers you an extensive range of functions, which are
grouped into menus.
1. To access the menu, select Menu.
To change the menu view, select Options > Main menu view > List,
Grid, Grid with labels, or Tab.
To rearrange the menu, scroll to the menu you want to move, and
select Options > Organise > Move. Scroll to where you want to
move the menu, and select OK. To save the change, select Done >
Yes.
2. Scroll through the menu, and select an option (for example,
Settings).
3. If the selected menu contains further submenus, select the one that
you want (for example, Call).
4. If the selected menu contains further submenus, repeat step 3.
5. Select the setting of your choice.
6. To return to the previous menu level, select Back. To exit the menu,
select Exit.
FCC_6126H_6133H_en_1_FCC.fm Page 26 Tuesday, June 27, 2006 1:35 PM
Messaging
27
DRAFT
6. Messaging
You can read, write, send, and save text, multimedia, e-mail, audio, and
flash messages and postcards. All messages are organized into folders.
■Text messages (SMS)
With the short message service (SMS) you can send and receive text
messages, and receive messages that can contain pictures (network
service).
Before you can send any text or SMS e-mail message, you must save
your message center number. See “Message settings,” p. 43.
To check SMS e-mail service availability and to subscribe to the service,
contact your service provider. To save an e-mail address in Contacts, see
“Save details,” p. 47.
Your device supports the sending of text messages beyond the character limit for
a single message. Longer messages will be sent as a series of two or more
messages. Your service provider may charge accordingly. Characters that use
accents or other marks, and characters from some language options like Chinese,
take up more space limiting the number of characters that can be sent in a single
message.
The message length indicator at the top of the display shows the total
number of characters left and the number of messages needed for
sending. For example, 673/2 means that there are 673 characters left
and that the message will be sent as a series of two messages.
Write and send a SMS message
1. Select Menu > Messaging > Create message > Text message.
2. Enter the recipient’s phone number or e-mail address in the To: field.
To retrieve a phone number or e-mail address from Contacts, select
Add > Contact. To send the message to multiple recipients, add the
desired contacts one by one. To send the message to persons in a
group, select Contact group and the desired group. To retrieve the
contacts to which you recently sent messages, select Add > Recently
FCC_6126H_6133H_en_1_FCC.fm Page 27 Tuesday, June 27, 2006 1:35 PM
Messaging
28
DRAFT
used. To retrieve contacts from previously incoming calls, select
Add > Open Log.
3. For a SMS e-mail, enter a subject in the Subject: field.
4. Write your message in the Message: field. See “Write text,” p. 24. To
insert a template into the message, select Options > Use template.
To see how the message will look to the recipient, select Options >
Preview.
5. To send the message, select Send. See “Message sending,” p. 30.
Read and reply to an SMS message
When you have received a message, 1 message received or the number
of new messages with messages received are shown.
1. To view a new message, select Show. To view it later, select Exit.
To read the message later, select Menu > Messaging > Inbox. If more
than one message is received, select the message you want to read.
is shown if you have unread messages in Inbox.
2. To view the list of available options while reading a message, select
Options.
3. To reply to a message, select Reply > Text message, Multimedia,
Flash message, or Audio message.
To send a text message to an e-mail address, enter the e-mail
address in the To: field.
Scroll down, and write your message in the Message: field. See
“Write text,” p. 24.
If you want to change the message type for your reply message,
select Options > Change message type.
4. To send the message, select Send. See “Message sending,” p. 30.
■SIM messages
SIM messages are text messages that are saved to your SIM card. You
can copy or move those messages to the phone memory, but not vice
versa. Received messages are saved to the phone memory.
To read SIM messages, select Menu > Messaging > Options > SIM
messages.
FCC_6126H_6133H_en_1_FCC.fm Page 28 Tuesday, June 27, 2006 1:35 PM
Messaging
29
DRAFT
■Multimedia messages (MMS)
Note: Only devices that have compatible features can receive and
display multimedia messages. The appearance of a message may vary
depending on the receiving device.
To check availability and to subscribe to the multimedia messaging
network service, contact your service provider. See “Multimedia
messages,” p. 44.
A multimedia message can contain text, sound, images, video clips, a
business card, and a calendar note. If the message is too large, the
phone may not be able to receive it. Some networks allow text messages
that include an Internet address where you can view the multimedia
message.
You cannot receive multimedia messages during a call or an active
browsing session over GSM data. Because delivery of multimedia
messages can fail for various reasons, do not rely solely upon them for
essential communications.
Write and send a MMS message
The wireless network may limit the size of MMS messages. If the inserted image
exceeds this limit, the device may make it smaller so that it can be sent by MMS.
1. Select Menu > Messaging > Create message > Multimedia.
2. Enter your message.
Your phone supports multimedia messages that contain several
pages (slides). A message can contain a calendar note and a business
card as attachments. A slide can contain text, one image, and one
sound clip; or text and a video clip. To insert a slide in the message,
select New; or select Options > Insert > Slide.
To insert a file in the message, select Insert; or select Options >
Insert.
3. To view the message before sending it, select Options > Preview.
4. To send the message, select Send. See “Message sending,” p. 30.
5. Enter the recipient’s phone number in the To: field. To retrieve a
phone number from Contacts, select Add > Contact. To send the
FCC_6126H_6133H_en_1_FCC.fm Page 29 Tuesday, June 27, 2006 1:35 PM
Messaging
30
DRAFT
message to multiple recipients, add the desired contacts one by one.
To send the message to persons in a group, select Contact group and
the desired group. To retrieve the contacts to which you recently sent
messages, select Add > Recently used.
Message sending
Copyright protections may prevent some images, music (including ringing tones),
and other content from being copied, modified, transferred or forwarded.
When you finish writing your message, to send the message, select
Send. The phone saves the message in the Outbox folder, and the
sending starts. If you select Save sent messages > Yes, the sent message
is saved in the Sent items folder. See “General settings,” p. 43.
Note: When the phone is sending the message, the animated is
shown. This is an indication that the message has been sent by your
device to the message center number programmed into your device.
This is not an indication that the message has been received at the
intended destination. For more details about messaging services, check
with your service provider.
It takes more time to send a multimedia message than to send a text
message. While the message is being sent, you can use other functions
on the phone. If an interruption occurs while the message is being sent,
the phone tries to resend the message a few times. If these attempts fail,
the message remains in the Outbox folder. You can try to resend it later.
Cancel message sending
To cancel the sending of the messages in the Outbox folder, scroll to the
desired message, and select Options > Cancel sending.
Read and reply to a MMS message
Important: Exercise caution when opening messages. Multimedia
message objects may contain malicious software or otherwise be
harmful to your device or PC.
When you receive a new multimedia message, Multimedia message
received or the number of new messages with messages received is
shown.
FCC_6126H_6133H_en_1_FCC.fm Page 30 Tuesday, June 27, 2006 1:35 PM
Messaging
31
DRAFT
1. To read the message, select Show. To view it later, select Exit.
To read the message later, select Menu > Messaging > Inbox. Scroll
to the message that you want to view, and select it. is shown if
you have unread messages in Inbox.
2. To view the whole message if the received message contains a
presentation, select Play.
To view the files in the presentation or the attachments, select
Options > Objects or Attachments.
3. To reply to the message, select Options > Reply > Text message,
Multimedia, Postcard, Flash message, or Audio message. Write the
reply message.
If you want to change the message type for your reply message,
select Options > Change message type. The new message type may
not support all the content that you have added.
4. To send the message, select Send. See “Message sending,” p. 30.
■Memory full
When you receive a message, and the memory for the messages is full,
Memory full. Unable to receive messages. is shown. To first delete old
messages, select OK > Yes and the folder. Scroll to the desired message,
and select Delete. If more messages are to be deleted, select Mark. Mark
all the messages you want to delete, and select Options > Delete
marked.
■Folders
The phone saves received messages in the Inbox folder.
Messages that have not yet been sent are saved in the Outbox folder.
To set the phone to save the sent messages in the Sent items folder, see
Save sent messages in “General settings,” p. 43.
To save the message that you write and want to send later in the Drafts
folder, select Options > Save message > Drafts
FCC_6126H_6133H_en_1_FCC.fm Page 31 Tuesday, June 27, 2006 1:35 PM
Messaging
32
DRAFT
You can move your messages to the Saved items folder. To organize your
Saved items subfolders, select Menu > Messaging > Saved items. To add
a folder, select Options > Add folder. To delete or rename a folder, scroll
to the desired folder, and select Options > Delete folder or Rename
folder.
Your phone has templates. To create a new template, save a message as
a template. To access the template list, select Menu > Messaging >
Saved items > Templates.
■Postcards
With the postcard messaging service (network service), create and send
postcards that may contain an image and a greeting text. The postcard
is sent to the service provider using multimedia messaging. The service
provider prints the postcard and sends it to the postal address given
with the message. Multimedia messaging service must be activated
before this service can be used.
Before you can use the postcard service you must subscribe to the service. To
check the availability, and costs, and to subscribe to the service, contact your
network operator or service provider.
Send a postcard
Select Menu > Messaging > Create message > Postcard. Scroll to the
editor fields, enter the name, the postal address, and the city of the
recipient (mandatory editor fields, marked by a *).
Scroll to the image field and select Insert > Open Gallery to insert an
image from Gallery or New image to insert a recent photo; then write
your greeting text. Select Options to see the options available. To send
the postcard, select the graphical key or Options > Send.
FCC_6126H_6133H_en_1_FCC.fm Page 32 Tuesday, June 27, 2006 1:35 PM
Messaging
33
DRAFT
■Flash messages
Flash messages are text messages that are instantly displayed upon
reception. Flash messages are not automatically saved.
Write a flash message
Select Menu > Messaging > Create message > Flash message. Enter the
recipient’s phone number in the To: field. Scroll down, and write your
message in the Message: field. The maximum length of a flash message
is 70 characters. To insert a blinking text into the message, select
Options > Insert blink character to set a marker. The text behind the
marker blinks until a second marker is inserted.
Receive a flash message
A received flash message is indicated with Message: and a few words
from the beginning of the message. To read the message, select Read. To
extract phone numbers, e-mail addresses, and Web site addresses from
the current message, select Options > Use detail. To save the message,
select Save and the folder in which you want to save it.
■Nokia Xpress audio messaging
You can use the multimedia message service to create and send a audio
message in a convenient way. Multimedia messaging service must be
activated before you can use audio messages.
Create an audio message
1. Select Menu > Messaging > Create message > Audio message. The
recorder opens. To use the recorder, see “Voice recorder,” p. 78.
2. Speak your message.
3. Enter the recipient’s phone number in the To: field. To retrieve a
phone number from Contacts, select Add > Contact. To send the
message to multiple recipients, add the desired contacts one by one.
To send the message to persons in a group, select Contact group and
the desired group. To retrieve the contacts to which you recently sent
messages, select Add > Recently used.
4. To send the message, select Send.
FCC_6126H_6133H_en_1_FCC.fm Page 33 Tuesday, June 27, 2006 1:35 PM
Messaging
34
DRAFT
Receive an audio message
When your phone receives an audio message, 1 audio message received
is displayed. To open the message, select Play; or if more than one
message is received, select Show > Play. To listen to the message later,
select Exit. To see the available options, select Options.
■E-mail application
The e-mail application uses a packet data connection (network service)
to allow you to access your e-mail account from your phone when you
are not in the office or at home. This e-mail application is different from
the SMS e-mail function. To use the e-mail function on your phone, you
need a compatible e-mail system.
You can write, send, and read e-mail with your phone. You can also save
and delete the e-mail on a compatible PC. Your phone supports POP3
and IMAP4 e-mail servers.
Before you can send and retrieve any e-mail messages, you must do the
following:
• Obtain a new e-mail account or use your current account. To check
the availability of your e-mail account, contact your e-mail service
provider.
• Check your e-mail settings with your network operator or e-mail
service provider. You may receive the e-mail configuration settings
as a configuration message. See “Configuration settings service,”
p. 10. You can also enter the settings manually. See “Configuration,”
p. 66.
To activate the e-mail settings, select Menu > Messaging > Message
settings > E-mail messages. See “E-mail messages,” p. 45.
This application does not support keypad tones.
Setting Wizard
The setting wizard will start automatically if no e-mail settings are
defined in the phone. To enter the settings manually, select Menu >
Messaging > E-mail > Options > Manage accounts > Options > New.
FCC_6126H_6133H_en_1_FCC.fm Page 34 Tuesday, June 27, 2006 1:35 PM
Messaging
35
DRAFT
The Manage accounts options allow you to add, delete, and change the
e-mail settings. Make sure that you have defined the correct preferred
access point for your operator. See “Configuration,” p. 66.
The e-mail application requires an Internet access point without a
proxy. WAP access points normally include a proxy and do not work with
the e-mail application.
Write and send an e-mail
You can write your e-mail message before connecting to the e-mail
service; or connect to the service first, then write and send your e-mail.
1. Select Menu > Messaging > E-mail > Write new e-mail.
2. If more than one e-mail account is defined, select the account from
which you want to send the e-mail.
3. Enter the recipient’s e-mail address.
4. Write a subject for the e-mail.
5. Write the e-mail message. See “Write text,” p. 24.
To attach a file to the e-mail, select Options > Attach file and a file
from Gallery.
6. To send the e-mail message immediately, select Send > Send now.
To save the e-mail in the Outbox folder to be sent later, select
Send > Send later.
To edit or continue writing your e-mail later, select Options > Save
as draft. The e-mail is saved in Outboxes > Drafts.
To send the e-mail later, select Menu > Messaging > E-mail >
Options > Send now or Send and check for e-mail.
Download e-mail
1. To download e-mail messages that have been sent to your e-mail
account, select Menu > Messaging > E-mail > Check for new e-mail.
If more than one e-mail account is defined, select the account from
which you want to download the e-mail.
The e-mail application only downloads e-mail headers at first.
FCC_6126H_6133H_en_1_FCC.fm Page 35 Tuesday, June 27, 2006 1:35 PM
Messaging
36
DRAFT
2. Select Back.
3. Select Inboxes, the account name, and the new message, and select
Retrieve to download the complete e-mail message.
To download new e-mail messages and to send e-mail that has been
saved in the Outbox folder, select Options > Send and check for e-mail
Read and reply to e-mail
Important: Exercise caution when opening messages. E-mail messages
may contain malicious software or otherwise be harmful to your device
or PC.
1. Select Menu > Messaging > E-mail > Inboxes, the account name,
and the desired message.
2. While reading the message, select Options to view the available
options.
3. To reply to an e-mail, select Reply > Original text or Empty message.
To reply to many, select Options > Reply to all. Confirm or edit the
e-mail address and subject, then write your reply.
4. To send the message, select Send > Send now.
E-mail folders
Your phone saves e-mail that you have downloaded from your e-mail
account in the Inboxes folder. The Inboxes folder contains the following
folders: “Account name” for incoming e-mail, Archive for archiving
e-mail, Custom 1—Custom 3 for sorting e-mail, Junk where all spam e-
mail is stored, Drafts for saving unfinished e-mail, Outbox for saving
e-mail that has not been sent, and Sent items for saving e-mail that has
been sent.
To manage the folders and their e-mail content, select Options to view
the available options of each folder.
Spam filter
The e-mail application allows you to activate a built-in spam filter. To
activate and define this filter, select Options > Spam filter > Settings in
FCC_6126H_6133H_en_1_FCC.fm Page 36 Tuesday, June 27, 2006 1:35 PM
Messaging
37
DRAFT
the main e-mail idle screen. The spam filter allows the user to put
specific senders on a black or white list. Black list sender messages are
filtered to the Junk folder. Unknown and White list sender messages are
downloaded into the account inbox. To blacklist a sender, select the e-
mail message in the Inboxes folder and Options > Blacklist sender.
■Instant messaging
You can take text messaging to the next level by experiencing instant
messaging (IM) (network service) in a wireless environment. You can
engage in instant messaging with friends and family, regardless of the
mobile system or platform (like the Internet) they are using, as long as
you all use the same instant messaging service.
Before you can start using instant messaging, you must first subscribe
to your wireless service provider’s text messaging service and register
with the instant messaging service you want to use. You must also
obtain a user name and password before you can use instant messaging.
See “Register with an instant messaging service,” p. 37 for more
information.
Note: Depending on both your IM service provider and your
wireless service provider, you may not have access to all of the
features described in this guide.
To set the required settings for the instant messaging service, see
Connection settings in “Access,” p. 38. The icons and texts on the display
may vary, depending on the instant messaging service.
While you are connected to the instant messaging service, you can use
the other functions of the phone, and the instant messaging
conversation remains active in the background. Depending on the
network, the active instant messaging conversation may consume the
phone battery faster, and you may need to connect the phone to a
charger.
Register with an instant messaging service
You can do this by registering over the Internet with the IM service
provider you have selected to use. During the registration process, you
FCC_6126H_6133H_en_1_FCC.fm Page 37 Tuesday, June 27, 2006 1:35 PM
Messaging
38
DRAFT
will have the opportunity to create the user name and password of your
choice. For more information about signing up for instant messaging
services, contact your wireless service provider.
Access
To access the Instant messages menu while still offline, select Menu >
Messaging > Instant messages (Instant messages may be replaced by
another term depending on the service provider). If more than one set of
connection settings for instant messaging service is available, select the
one you want. If there is only one set defined, it is selected
automatically.
The following options are shown:
Login — to connect to the instant messaging service. To set the phone to
automatically connect to the instant messaging service when you
switch on the phone; in the login session, scroll to Automatic login: and
select Change >On, or select Menu > Messaging > Instant messages,
connect to the instant messaging service, and select Options >
Settings > Automatic login > On.
Saved conversations — to view, erase, or rename the conversations that
you saved during an instant messaging session
Connection settings — to edit the settings needed for messaging and
presence connection
Connect
To connect to the instant messaging service, access the Instant
messages menu, select the instant messaging service, if needed, and
select Login. When the phone has successfully connected, Logged in is
displayed.
To disconnect from the instant messaging service, select Options >
Logout.
FCC_6126H_6133H_en_1_FCC.fm Page 38 Tuesday, June 27, 2006 1:35 PM
Messaging
39
DRAFT
Sessions
When connected to the instant messaging service your status as seen by
others is shown in a status line: My status: Online, My status: Busy or
Status: Appear offline — to change own status, select Change.
Below the status line there are three folders containing your contacts
and showing their status: Conversations, Online and Offline. To expand
the folder highlight it and select Expand (or press scroll right), to
collapse the folder select Collapse (or press scroll left).
Conversations — shows the list of new and read instant messages or
invitations to instant messaging during the active instant messaging
session.
indicates a new group message.
indicates a read group message.
indicates a new instant message.
indicates a read instant message.
indicates an invitation.
The icons and texts on the display may vary, depending on the instant
messaging service you have selected.
Online — shows the number of contacts that are online.
Offline — shows the number of contacts that are offline
To start a conversation, expand the Online or the Offline folder and
scroll to the contact with whom you would like to chat and select Chat.
To answer an invitation or to reply to a message expand the
Conversations folder and scroll to the contact to whom you would like
to chat and select Open. To add contacts, see “Add IM contacts,” p. 41.
Groups > Public groups (not visible if groups are not supported by the
network) — the list of bookmarks to public groups provided by the
service provider is displayed. To start a instant messaging session with a
group, scroll to a group, and select Join. Enter the screen name that you
want to use as your nickname in the conversation. When you have
successfully joined the group conversation, you can start a group
conversation. You can create a private group. See “Groups,” p. 41.
FCC_6126H_6133H_en_1_FCC.fm Page 39 Tuesday, June 27, 2006 1:35 PM
Messaging
40
DRAFT
Search > Users or Groups — to search for other instant messaging users
or public groups on the network by phone number, screen name, e-mail
address, or name. If you select Groups, you can search for a group by a
member in the group, or by group name, topic, or ID.
Options > Chat or Join group — to start the conversation when you have
found the user or the group that you want.
Accept or reject an invitation
In the standby mode, when you are connected to the instant messaging
service and you receive a new invitation, New invitation received is
displayed. To read it, select Read. If more than one invitation is received,
scroll to the invitation you want, and select Open. To join the private
group conversation, select Accept, and enter the screen name you want
to use as your nickname. To reject or delete the invitation, select
Options > Reject or Delete.
Read an instant message
In the standby mode, when you are connected to the instant messaging
service, and you receive a new message that is not a message associated
with an active conversation, New instant message is displayed.To read
it, select Read.
If you receive more than one message, N new instant messages appears
in the display, where N is the number of new messages. Select Read,
scroll to a message, and select Open.
New messages received during an active conversation are held in
Instant messages > Conversations. If you receive a message from
someone who is not in IM contacts, the sender ID is displayed. To save a
new contact that is not in the phone memory, select Options > Save
contact.
Participate in a conversation
To join or start an IM session, write your message; and select Send, or
press the call key. Select Options to view the available options.
If you receive a new message during a conversation from a person who
is not taking part in the current conversation, is displayed, and the
phone sounds an alert tone.
FCC_6126H_6133H_en_1_FCC.fm Page 40 Tuesday, June 27, 2006 1:35 PM
Messaging
41
DRAFT
Write your message; and select Send, or press the call key. Your message
is displayed, and the reply message is displayed below your message.
Add IM contacts
When connected to the IM service, in the IM main menu select
Options > Add contact.
Select By mobile number, Enter ID manually, Search from server, or Copy
from server (depending on service provider). When the contact is
successfully added, the phone confirms it.
Scroll to a contact. To start a conversation, select Chat.
Block or unblock messages
When you are in a conversation and want to block messages, select
Options > Block contact. A confirmation query is shown, select OK to
block messages from this contact.
To block messages from a specific contact in your contacts list, scroll to
the contact in Conversations, Online or Offline and select Options >
Block contact > OK.
To unblock a contact, in the IM main menu select Options > Blocked list.
Scroll to the contact you want to unblock and select Unblock > OK.
Groups
You can create your own private groups for an IM conversation, or use
the public groups provided by the service provider. The private groups
exist only during an IM conversation, and the groups are saved on the
server of the service provider. If the server you are logged into does not
support group services, all group-related menus are dimmed.
Public
You can bookmark public groups that your service provider may
maintain. Connect to the IM service, and select Groups > Public groups.
Scroll to a group with which you want to chat, and select Join. If you are
not in the group, enter your screen name as your nickname for the
FCC_6126H_6133H_en_1_FCC.fm Page 41 Tuesday, June 27, 2006 1:35 PM
Messaging
42
DRAFT
group. To delete a group from your group list, select Options > Delete
group.
To search for a group, select Groups > Public groups > Search groups.
You can search for a group by a member in the group, by group name,
topic, or ID.
Private
Connect to the IM service, and from the main menu select Options >
Create group. Enter the name for the group and the screen name that
you want to use as your nickname. Mark the private group members in
the contacts list, and write an invitation.
■Voice messages
The voice mailbox is a network service and you may need to subscribe to
it. For more information and for your voice mailbox number, contact
your service provider.
To call your voice mailbox, select Menu > Messaging > Voice
messages > Listen to voice messages. To enter, search for, or edit your
voice mailbox number, select Voice mailbox number.
If supported by the network, indicates new voice messages. To call
your voice mailbox number, select Listen.
■Info messages
With Info messages (network service), you can receive messages on
various topics from your service provider. To check availability, topics,
and the relevant topic numbers, contact your service provider.
■Service commands
Select Menu > Messaging > Service commands. Write and send service
requests (also known as USSD commands), such as activation
commands for network services, to your service provider.
FCC_6126H_6133H_en_1_FCC.fm Page 42 Tuesday, June 27, 2006 1:35 PM
Messaging
43
DRAFT
■Delete messages
To delete messages, select Menu > Messaging > Delete messages > By
message to delete single messages, By folder to delete all messages from
a folder, or All messages. If a folder contains unread messages, the
phone asks whether you want to delete them also.
■Message settings
General settings
General settings are common for text and multimedia messages.
Select Menu > Messaging > Message settings > General settings and
from the following options:
Save sent messages > Yes — to set the phone to save the sent messages
in the Sent items folder
Overwriting in Sent items > Allowed — to set the phone to overwrite the
old sent messages with the new ones when the message memory is full.
This setting is shown only if you set Save sent messages > Yes.
Font size — to select the font size used in messages
Graphical smileys > Yes — to set the phone to replace character-based
smileys with graphical ones
Text messages
The text message settings affect the sending, receiving, and viewing of
text and SMS e-mail messages.
Select Menu > Messaging > Message settings > Text messages and
from the following options:
Delivery reports > Yes — to ask the network to send delivery reports
about your messages (network service)
Message centres > Add centre — to set the phone number and name of
the message center that is required for sending text messages. You
receive this number from your service provider.
Message centre in use — to select the message center in use
FCC_6126H_6133H_en_1_FCC.fm Page 43 Tuesday, June 27, 2006 1:35 PM
Messaging
44
DRAFT
E-mail message centres > Add centre — to set the phone numbers and
name of the e-mail center for sending SMS e-mails.
E-mail centre in use — to select the SMS e-mail message center in use
Message validity — to select the length of time for which the network
attempts to deliver your message
Messages sent via — to select the format of the messages to be sent:
Text, Paging, or Fax (network service)
Use packet data > Yes — to set GPRS as the preferred SMS bearer
Character support > Full — to select all characters in the messages to be
sent as viewed. If you select Reduced, characters with accents and other
marks may be converted to other characters. When writing a message,
you can preview it to see how the message will look to the recipient. See
“Write and send a SMS message,” p. 27.
Reply via same centre > Yes — to allow the recipient of your message to
send you a reply using your message center (network service)
Multimedia messages
The message settings affect the sending, receiving, and viewing of
multimedia messages.
You may receive the configuration settings for multimedia messaging as
a configuration message. See “Configuration settings service,” p. 10.
You can also enter the settings manually. See “Configuration,” p. 66.
Select Menu > Messaging > Message settings > Multimedia messages
and from the following options:
Delivery reports > Yes — to ask the network to send delivery reports
about your messages (network service)
Image size (multimedia) — to set the image size in multimedia messages.
Before sending, images will be reduced to the selected size.
Default slide timing — to define the default time between slides in
multimedia messages
Allow multimedia recept. — to receive or block the multimedia message,
select Yes or No. If you select In home network, you cannot receive
multimedia messages when outside your home network. The default
FCC_6126H_6133H_en_1_FCC.fm Page 44 Tuesday, June 27, 2006 1:35 PM
Messaging
45
DRAFT
setting of the multimedia message service is generally In home network.
The availability of this menu depends on your phone.
Incoming multim. msgs. — to allow the reception of multimedia
messages automatically, manually after being prompted, or to reject the
reception. This setting is not shown if Allow multimedia recept. is set to
No.
Allow adverts — to receive or reject advertisements. This setting is not
shown if Allow multimedia recept. is set to No, or Incoming multim.
msgs. is set to Reject.
Configuration settings > Configuration — only the configurations that
support multimedia messaging are shown. Select a service provider,
Default, or Personal configuration for multimedia messaging. Select
Account and a multimedia messaging service account contained in the
active configuration settings.
E-mail messages
The settings affect the sending, receiving, and viewing of e-mail.
You may receive the configuration settings for the e-mail application as
a configuration message. See “Configuration settings service,” p. 10.
You can also enter the settings manually. See “Configuration,” p. 66.
To activate the settings for the e-mail application, select Menu >
Messaging > Message settings > E-mail messages and from the
following options:
Configuration — to select the set that you want to activate
Account — to select an account provided by the service provider
My name — to enter your name or nickname
E-mail address — to enter your e-mail address
Include signature — to define a signature that is automatically added to
the end of your e-mail when you write your message
Reply-to address — to enter the e-mail address to which you want the
replies to be sent
SMTP user name — to enter the name that you want to use for outgoing
mail
FCC_6126H_6133H_en_1_FCC.fm Page 45 Tuesday, June 27, 2006 1:35 PM
Messaging
46
DRAFT
SMTP password — to enter the password that you want to use for
outgoing mail
Display terminal window > Yes — to perform manual user
authentication for intranet connections
Incoming server type > POP3 or IMAP4 — to select the type of e-mail
system that you are using. If both types are supported, select IMAP4
Incoming mail settings — to select available options for POP3 or IMAP4
FCC_6126H_6133H_en_1_FCC.fm Page 46 Tuesday, June 27, 2006 1:35 PM
Contacts
47
DRAFT
7. Contacts
You can save names and phone numbers (contacts) in the
phone memory and in the SIM card memory.
The phone memory may save contacts with additional details, such as
various phone numbers and text items. You can also save an image for a
limited number of contacts.
The SIM card memory can save names with one phone number attached
to them. The contacts saved in the SIM card memory are indicated by
.
■Search for a contact
Select Menu > Contacts > Names. Scroll through the list of contacts, or
enter the first characters of the name you are searching for.
■Save names and phone numbers
Names and numbers are saved in the used memory. To save a name and
phone number, select Menu > Contacts > Names > Options > Add new
contact. Enter the last name, first name, the phone number and select
Save.
■Save details
In the phone memory for contacts you can save different types of phone
numbers, and short text items per name. You can also select a tone or a
video clip for a contact.
The first number you save is automatically set as the default number,
and it is indicated with a frame around the number type indicator (for
example, ). When you select a name from contacts (for example, to
make a call), the default number is used unless you select another
number.
1. Make sure that the memory in use is Phone or Phone and SIM. See
“Settings,” p. 51.
FCC_6126H_6133H_en_1_FCC.fm Page 47 Tuesday, June 27, 2006 1:35 PM
Contacts
48
DRAFT
2. Search for the contact to which you want to add a detail, and select
Details > Options > Add detail. Select from the options available.
To search for an ID from the server of your service provider if you
have connected to the presence service, select User ID > Search. See
“My presence,” p. 49. If only one ID is found, it is automatically
saved. Otherwise, to save the ID, select Options > Save. To enter the
ID, select Enter ID manually. Enter the ID, and select OK to save it.
■Copy or move contacts
To copy names and phone numbers from the phone contact memory to
the SIM card memory, or vice versa, select Menu > Contacts > Names >
Options > Copy. Select One by one to copy single contacts or All to copy
all contacts. The SIM card memory can save names with one phone
number attached to them.
To copy or move all contacts from the phone contact memory to the SIM
card memory, or vice versa, select Menu > Contacts > Copy contacts or
Move contacts.
■Edit contact details
Search for the contact you want to edit, and select Details. To edit a
name, number, text item, or to change the image, select Options > Edit.
To change the number type, scroll to the desired number, and select
Options > Change type. To set the selected number as the default
number, select Set as default. You cannot edit an ID when it is on the IM
contacts or Subscribed names list.
■Synchronize all
Synchronize your calendar, contacts data, and notes with a remote
Internet server (network service). For details see “Synchronize from a
server,” p. 63.
■Delete contacts
To delete all the contacts and the details attached to them from the
phone or SIM card memory, select Menu > Contacts > Delete all
FCC_6126H_6133H_en_1_FCC.fm Page 48 Tuesday, June 27, 2006 1:35 PM
Contacts
49
DRAFT
contacts > From phone memory or From SIM card. Confirm with the
security code.
To delete a contact, search for the desired contact, and select Options >
Delete contact.
To delete a number, text item, or an image attached to the contact,
search for the contact, and select Details. Scroll to the desired detail,
and select Options > Delete and from the options available. Deleting an
image or video clip from contacts does not delete it from Gallery.
■My presence
With the presence service (network service), you can share your
presence status with other users with compatible devices and access to
the service, such as your family, friends, and colleagues. Presence status
includes your availability, status message, and personal logo. Other
users who have access to the service and who request your information
are able to see your status. The requested information is shown in
Subscribed names in the viewers’ Contacts menu. You can personalize
the information that you want to share with others and control who can
see your status.
Before you can use presence, you must subscribe to the service. To check
the availability and costs, and to subscribe to the service, contact your
network operator or service provider, from whom you also receive your
unique ID, password, and the settings for the service. See
“Configuration,” p. 66.
While you are connected to the presence service, you can use the other
functions of the phone, and the presence service is active in the
background. If you disconnect from the service, your presence status is
shown for a certain amount of time to viewers, depending on the service
provider.
Select Menu > Contacts > My presence and from the following options:
Connect to 'My presence' or Disconnect from service — to connect to or
disconnect from the service
View my presence > Private presence or Public presence — to view your
presence status
FCC_6126H_6133H_en_1_FCC.fm Page 49 Tuesday, June 27, 2006 1:35 PM
Contacts
50
DRAFT
Edit my presence > My availability, My presence message, My presence
logo, or Show to — to change your presence status
My viewers > Current viewers, Private list, or Blocked list — to view the
persons who are subscribed to or blocked from your presence
information
Settings > Show pres. in standby, Connection type, or Presence settings
■Subscribed names
You can create a list of contacts whose presence status information you
want to be aware of. You can view the information if it is allowed by the
contacts and the network. To view these subscribed names, scroll
through the contacts, or use the Subscribed names menu.
Ensure that the memory in use is Phone or Phone and SIM. See
“Settings,” page 51.
To connect to the presence service, select Menu > Contacts > My
presence > Connect to 'My presence'.
Add contacts to the subscribed names
1. Select Menu > Contacts > Subscribed names. If you have not
connected to the presence service, the phone asks if you want to
connect now.
2. If you have no contacts on your list, select Add. Otherwise, select
Options > Subscribe new. Your list of contacts is shown.
3. Select a contact from the list. If the contact has a saved ID, the
contact is added to the subscribed names list. If there is more than
one ID, select one of them. After subscription to the contact,
Subscription activated is shown.
Tip: To subscribe to a contact from the Contacts list, search for
the contact you want, and select Details > Options > Request
presence > As subscription.
If you only want to view the presence information but not to
subscribe to a contact, select Request presence > One time only.
FCC_6126H_6133H_en_1_FCC.fm Page 50 Tuesday, June 27, 2006 1:35 PM
Contacts
51
DRAFT
View the subscribed names
To view the presence information, see also “Search for a contact,” p. 47.
1. Select Menu > Contacts > Subscribed names.
The status information of the first contact on the subscribed names
list is displayed. The information that the person wants to make
available to others may include text and an icon.
, , or indicates that the person is available, not visible to
others, or not available.
indicates that the person’s presence information is not available.
2. Select Options > View details to view the details of the selected
contact or Options > Subscribe new, Send message, Send business
card, or Unsubscribe.
Unsubscribe a contact
To unsubscribe a contact from the Contacts list, select the contact and
Options > Unsubscribe > OK.
To unsubscribe from the Subscribed names menu, see “View the
subscribed names,” p. 51.
■Business cards
You can send and receive a person’s contact information from a
compatible device that supports the vCard standard as a business card.
To send a business card, search for the contact whose information you
want to send, and select Details > Options > Send business card > Via
multimedia, Via text message, via infrared, or Via Bluetooth.
When you have received a business card, select Show > Save to save the
business card in the phone memory. To discard the business card, select
Exit > Yes.
■Settings
Select Menu > Contacts > Settings and from the following options:
FCC_6126H_6133H_en_1_FCC.fm Page 51 Tuesday, June 27, 2006 1:35 PM
Contacts
52
DRAFT
Memory in use — to select the SIM card or phone memory for your
contacts. Select Phone and SIM to recall names and number from both
memories. In that case, when you save names and numbers, they are
saved in the phone memory.
Contacts view — to select how the names and numbers in Contacts are
displayed
Name display — to select whether the contact’s first or last name is
displayed first
Font size — to set the font size for the list of contacts
Memory status — to view the free and used memory capacity
■Groups
Select Menu > Contacts > Groups to arrange the names and phone
numbers saved in the memory into caller groups with different ringing
tones and group images.
■Speed dials
To assign a number to a speed-dialing key, select Menu > Contacts >
Speed dials, and scroll to the speed-dialing number that you want.
Select Assign, or if a number has already been assigned to the key,
select Options > Change. Select Search and the contact you want to
assign. If the Speed dialling function is off, the phone asks whether you
want to activate it. See also Speed dialling in “Call,” p. 64.
To make a call using the speed-dialing keys, see “Speed dialing,” p. 21.
■Info, service, and my numbers
Select Menu > Contacts and from one of these submenus:
Info numbers — to call the information numbers of your service provider
if the numbers are included on your SIM card (network service)
Service numbers — to call the service numbers of your service provider if
the numbers are included on your SIM card (network service)
My numbers — to view the phone numbers assigned to your SIM card, if
the numbers are included on your SIM card
FCC_6126H_6133H_en_1_FCC.fm Page 52 Tuesday, June 27, 2006 1:35 PM
Call log
53
DRAFT
8. Call log
The phone registers your missed, received, and dialed calls if the
network supports it and the phone is switched on and within the
network service area.
To view the information on your calls, select Menu > Log > Missed calls,
Received calls, or Dialled numbers. To view your recent missed and
received calls and the dialed numbers chronologically, select Call log. To
view the contacts to whom you most recently sent messages, select
Message recipients.
To view the approximate information on your recent communications,
select Menu > Log > Call duration, Packet data counter, or Packet data
timer.
To view how many text and multimedia messages you have sent and
received, select Menu > Log > Message log.
Note: The actual invoice for calls and services from your service
provider may vary, depending on network features, rounding off for
billing, taxes, and so forth.
Some timers may be reset during service or software upgrades.
■Positioning information
The network may send you a location request. You can ensure that the
network will deliver location information of your phone only if you
approve it (network service). Contact your service provider to subscribe
and to agree upon the delivery of location information.
To accept or reject the location request, select Accept or Reject. If you
miss the request, the phone automatically accepts or rejects it
according to what you have agreed with your network operator or
service provider. The phone displays 1 missed position request. To view
the missed location request, select Show.
To view the information on the 10 most recent privacy notifications and
requests or to delete them, select Menu > Log > Positioning > Position
log > Open folder or Delete all.
FCC_6126H_6133H_en_1_FCC.fm Page 53 Tuesday, June 27, 2006 1:35 PM
Settings
54
DRAFT
9. Settings
■Profiles
Your phone has various setting groups called profiles, for which you can
customize the phone tones for different events and environments.
Select Menu > Settings > Profiles, the desired profile and from the
following options:
Activate — to activate the selected profile
Personalise — to personalize the profile. Select the setting you want to
change, and make the changes.
Timed — to set the profile to be active until a certain time up to
24 hours, and set the end time. When the time set for the profile expires,
the previous profile that was not timed becomes active.
■Themes
A theme contains many elements for personalizing your phone, such as
wallpaper, screen saver, color scheme, and a ringing tone.
Select Menu > Settings > Themes and from the following options:
Select theme — to set a theme in your phone. A list of folders in Gallery
opens. Open the Themes folder, and select a theme.
Theme downloads — to open a list of links to download more themes
■Tones
You can change the tone settings of the selected active profile.
Select Menu > Settings > Tones. You can find the same settings in the
Profiles menu. See Personalise in “Profiles,” p. 54.
To set the phone to ring only for calls from phone numbers that belong
to a selected caller group, select Alert for. Scroll to the caller group you
want or All calls, and select Mark.
Select Options > Save to save the settings or Cancel to leave the
settings unchanged.
FCC_6126H_6133H_en_1_FCC.fm Page 54 Tuesday, June 27, 2006 1:35 PM
Settings
55
DRAFT
If you select the highest ringing tone level, the ringing tone reaches its highest
level after a few seconds.
A theme may contain a tone that sounds when you open and close the
phone. To switch off the tone, change the setting in Other tones:. Please
note that this setting also switches off the warning tones.
■Main display
Select Menu > Settings > Main display and from the available options.
Standby mode settings
Select Standby mode settings and from the following options:
Active standby — to switch the active standby mode on or off and to
organize and personalize the active standby mode. See “Active standby,”
p. 17.
Wallpaper — to add the background image to the display in the standby
mode
Fold animation — to set your phone to display an animation when you
open and close the phone
Standby font colour — to select the color for the texts on the display in
the standby mode
Navigation key icons — to display the icons of the current navigation key
shortcuts in the standby mode when active standby is off
Operator logo — to set your phone to display or hide the operator logo.
The menu is dimmed, if you have not saved the operator logo. For more
information on availability of an operator logo, contact your network
operator.
Cell info display > On — to display the cell identity, if available from the
network
Screensaver
Select Screen saver and from the following options:
On — to activate the screen saver for the main display
FCC_6126H_6133H_en_1_FCC.fm Page 55 Tuesday, June 27, 2006 1:35 PM
Settings
56
DRAFT
Screen savers > Image — to choose an image or a graphic from the
Gallery
Screen savers > Slide set and a folder in the Gallery — to use the images
in the folder as a slide set
Screen savers > Video clip and a video clip from the Gallery — to run a
video clip as screensaver (only on the main display)
Screen savers > Open camera — to take a new photo as screensaver
Screen savers > Analogue clock or Digital clock — to use a clock as
screensaver
Graphic downloads — to download more images for the screen saver
Time-out — to set the time after which the screen saver is activated
■Mini display
Select Menu > Settings > Mini display. You can change the settings for
Wallpaper, Screen saver, and Fold animation.
■Time and date
To change the time, time zone, and date settings, select Menu >
Settings > Time and date > Clock, Date, or Auto-update of date/time
(network service).
When traveling to a different time zone, select Menu > Settings > Time
and date > Clock > Time zone and the time zone of your location in
terms of the time difference with respect to Greenwich Mean Time
(GMT) or Universal Time Coordinated (UTC). The time and date are set
according to the time zone and enable your phone to display the correct
sending time of received text or multimedia messages. For example,
GMT -5 denotes the time zone for New York (USA), 5 hours west of
Greenwich/London (UK).
FCC_6126H_6133H_en_1_FCC.fm Page 56 Tuesday, June 27, 2006 1:35 PM
Settings
57
DRAFT
■My shortcuts
With personal shortcuts you get quick access to often used functions of
the phone.
Left selection key
To select a function from the list for the left selection key, select
Menu > Settings > My shortcuts > Left selection key. See also “Standby
mode,” p. 17.
If the left selection key is Go to to activate a function, in the standby
mode, select Go to > Options and from the following options:
Select options — to add a function to the shortcut list or to remove one.
Scroll to the function, and select Mark or Unmark.
Organise — to rearrange the functions on your personal shortcut list.
Scroll to the function you want to move, and select Move. Scroll to
where you want to move the function, and select OK.
Right selection key
To select a function from the list for the right selection key, select
Menu > Settings > My shortcuts > Right selection key. See also
“Standby mode,” p. 17.
Shortcut bar
To choose and reorder applications shown by the shortcut bar in the
active standby mode, select Menu > Settings > My shortcuts > Shortcut
bar.
Select Select links, and mark the desired application in the list or in a
folder. Select Done > Yes to confirm the selection.
Select Organise links to reorder the applications in the shortcut bar.
Select an application, Move, and move it to an other position. Select OK
to confirm. Select Done > Yes to save the shortcut sequence.
FCC_6126H_6133H_en_1_FCC.fm Page 57 Tuesday, June 27, 2006 1:35 PM
Settings
58
DRAFT
Navigation key
To select shortcut functions for the navigation keys, select Menu >
Settings > My shortcuts > Navigation key. Scroll to the desired key, and
select Change and a function from the list. To remove a shortcut
function from the key, select (empty). To reassign a function for the key,
select Assign. See “Shortcuts in the standby mode,” p. 18.
Voice commands
To call contacts and carry out phone functions, say the voice commands.
Voice commands are language-dependent. To set the language, see
Voice playback language in “Phone,” p. 65.
To select the phone functions to activate with a voice commands, select
Menu > Settings > My shortcuts > Voice commands and a folder. Scroll
to a function. indicates that the voice tag is activated. To activate
the voice tag, select Add. To play the activated voice command, select
Play. To use voice commands, see “Enhanced voice dialing,” p. 21.
To manage the voice commands, scroll to a phone function, and select
from the following options:
Edit or Remove — to change or deactivate the voice command of the
selected function
Add all or Remove all — to activate or deactivate voice commands to all
functions in the voice commands list
■Connectivity
You can connect the phone to a compatible device using a Bluetooth
wireless technology or a USB data cable connection. You can also define
the settings for EGPRS dial-up connections.
Bluetooth wireless technology
This device is compliant with Bluetooth Specification 2.0 + EDR supporting the
following profiles: generic access, generic object exchange, hands-free, headset,
object push, file transfer, dial-up networking, SIM access, and serial port. To
ensure interoperability between other devices supporting Bluetooth technology,
FCC_6126H_6133H_en_1_FCC.fm Page 58 Tuesday, June 27, 2006 1:35 PM
Settings
59
DRAFT
use Nokia approved enhancements for this model. Check with the manufacturers
of other devices to determine their compatibility with this device.
There may be restrictions on using Bluetooth technology in some locations.
Check with your local authorities or service provider.
Features using Bluetooth technology or allowing such features to run in the
background while using other features, increase the demand on battery power
and reduce the battery life.
Bluetooth technology allows you to connect the phone to a compatible
Bluetooth device within 10 meters (32 feet). Since devices using
Bluetooth technology communicate using radio waves, your phone and
the other devices do not need to be in direct line-of-sight, although the
connection can be subject to interference from obstructions such as
walls or from other electronic devices.
Set up a Bluetooth connection
Select Menu > Settings > Connectivity > Bluetooth and from the
following options:
Bluetooth > On or Off — to activate or deactivate the Bluetooth
function. indicates that Bluetooth is activated.
Search for audio enhanc. — to search for compatible Bluetooth audio
devices. Select the device that you want to connect to the phone.
Paired devices — to search for any Bluetooth device in range. Select New
to list any Bluetooth device in range. Scroll to a device, and select Pair.
Enter an agreed Bluetooth passcode of the device (up to 16 characters)
to associate (pair) the device to your phone. You must only give this
passcode when you connect to the device for the first time. Your phone
connects to the device, and you can start data transfer.
Bluetooth wireless connection
Select Menu > Settings > Connectivity > Bluetooth. To check which
Bluetooth connection is currently active, select Active devices. To view a
list of Bluetooth devices that are currently paired with the phone, select
Paired devices.
Select Options to access available options depending on the status of
the device and the Bluetooth connection.
FCC_6126H_6133H_en_1_FCC.fm Page 59 Tuesday, June 27, 2006 1:35 PM
Settings
60
DRAFT
Bluetooth settings
To define how your phone is shown to other Bluetooth devices, select
Menu > Settings > Connectivity > Bluetooth > Bluetooth settings > My
phone's visibility or My phone's name.
If you are concerned about security, turn off the Bluetooth function, or set My
phone's visibility to Hidden. Always accept only Bluetooth communication from
others with whom you agree.
Infrared
You can set up the phone to send and receive data through its infrared
(IR) port. To use an IR connection, the device with which you want to
establish a connection must be IrDA compliant. You can send or receive
data to or from a compatible phone or data device (for example, a
computer) through the IR port of your phone.
Do not point the IR (infrared) beam at anyone's eyes or allow it to interfere with
other IR devices. Infrared devices are Class 1 laser products.
When sending or receiving data, ensure that the IR ports of the sending
and receiving devices are pointing at each other and that there are no
obstructions between the devices.
To activate the IR port of your phone to receive data using IR, select
Menu > Settings > Connectivity > Infrared.
To deactivate the IR connection, select Menu > Settings >
Connectivity > Infrared. When the phone displays Deactivate infrared?,
select Yes.
If data transfer is not started within 2 minutes after the activation of
the IR port, the connection is cancelled and must be started again.
IR connection indicator
When is shown continuously, the IR connection is activated, and
your phone is ready to send or receive data through its IR port.
When blinks, your phone is trying to connect to the other device, or
a connection has been lost.
FCC_6126H_6133H_en_1_FCC.fm Page 60 Tuesday, June 27, 2006 1:35 PM
Settings
61
DRAFT
Packet data (GPRS)
General packet radio service (GPRS) is a network service that allows
mobile phones to send and receive data over an Internet protocol
(IP)-based network. It enables wireless access to data networks such as
the Internet.
The applications that may use packet data are MMS, video streaming,
browsing sessions, e-mail, Push to talk, remote SyncML, Java
application downloading, and the PC dial-up.
To define how to use the service, select Menu > Settings >
Connectivity > Packet data > Packet data connection and from the
following options:
When needed — to set the packet data connection to established when
an application needs it. The connection will be closed when the
application is terminated.
Always online — to set the phone to automatically connect to a packet
data network when you switch the phone on. or indicates that the
GPRS or EGPRS service is available. If you receive a call or a text
message or make a call during a packet data connection, or
indicates that the GPRS or EGPRS connection is suspended (on hold).
Modem settings
You can connect the phone using Bluetooth wireless technology or USB
data cable connection to a compatible PC and use the phone as a
modem to enable EGPRS connectivity from the PC.
To define the settings for EGPRS connections from your PC, select
Menu > Settings > Connectivity > Packet data > Packet data settings >
Active access point, and activate the access point you want to use.
Select Edit active access point > Alias for access point, enter a name to
change the access point settings, and select OK. Select Packet data
access point, enter the access point name (APN) to establish a
connection to an EGPRS network, and select OK.
You can also set the EGPRS dial-up service settings (access point name)
on your PC using the Nokia Modem Options software. See “Nokia PC
Suite,” p. 102. If you have set the settings both on your PC and on your
phone, the PC settings are used.
FCC_6126H_6133H_en_1_FCC.fm Page 61 Tuesday, June 27, 2006 1:35 PM
Settings
62
DRAFT
Data transfer
Synchronize your calendar, contacts data, and notes with another
compatible device (for example, a mobile phone), a compatible PC, or a
remote Internet server (network service).
Your phone allows data transfer with a compatible PC or another
compatible device when using the phone without a SIM card. Note that
when you use the phone without a SIM card, some functions appear
dimmed in the menus and cannot be used. Synchronizing with a remote
Internet server is not possible without a SIM card.
Transfer contact list
To copy or synchronize data from your phone, the name of the device
and the settings must be in the list of transfer contacts. If you receive
data from another device (for example, a compatible mobile phone), the
corresponding transfer contact is automatically added to the list, using
the contact data from the other device. Server synchronisation and PC
synchronisation are the original items in the list.
To add a new transfer contact to the list (for example a mobile phone),
select Menu > Settings > Connectivity > Data transfer > Options > Add
transfer contact > Phone synchronisation or Phone copy, and enter the
settings according to the transfer type.
To edit the copy and synchronize settings, select a contact from the
transfer contact list and Options > Edit.
Note: Every individual device must have its own entry in the
transfer contact list. Using one transfer contact for several
devices is not possible.
To delete a transfer contact, select it from the transfer contact list,
select Options > Delete, and confirm Delete transfer contact?. You
cannot delete Server synchronisation or PC synchronisation.
Data transfer with a compatible device
For synchronization, Bluetooth wireless technology or a cable
connection is used. The other device is in the standby mode.
To start data transfer, select Menu > Settings > Connectivity > Data
transfer and the transfer contact from the list, other than Server
FCC_6126H_6133H_en_1_FCC.fm Page 62 Tuesday, June 27, 2006 1:35 PM
Settings
63
DRAFT
synchronisation or PC synchronisation. According to the settings, the
selected data is copied or synchronized. The other device also must be
activated for receiving data.
Synchronize from a compatible PC
Before you synchronize data from calendar, notes, and contacts from a
compatible PC, you must install the Nokia PC Suite software of your
phone on the PC. Use Bluetooth wireless technology or a USB data cable
for the synchronization, and start the synchronization from the PC.
Synchronize from a server
To use a remote Internet server, you must subscribe to a synchronization
service. For more information and the settings required for this service,
contact your service provider. You may receive the settings as a
configuration message. See “Configuration settings service,” p. 10 and
“Configuration,” p. 66.
If you have saved data on the remote Internet server, to synchronize
your phone, start the synchronization from your phone.
Select Menu > Settings > Connectivity > Data transfer > Server
synchronisation. Depending on the settings, select Initialising
synchronisation or Initialising copy.
Synchronizing for the first time or after an interrupted synchronization
may take up to 30 minutes to complete, if the contacts or calendar are
full.
USB data cable
You can use the USB data cable to transfer data between the phone and
a compatible PC or a printer supporting PictBridge. You can also use the
USB data cable with Nokia PC Suite.
To activate the phone for data transfer or image printing, connect the
data cable; when the phone displays USB data cable connected. Select
mode., select OK. Select from the following modes:
Default mode — to use the cable for PC Suite
Printing — to print images directly from the phone using a compatible
printer
FCC_6126H_6133H_en_1_FCC.fm Page 63 Tuesday, June 27, 2006 1:35 PM
Settings
64
DRAFT
To change the USB mode, select Menu > Settings > Connectivity > USB
data cable > Default mode, Printing, or Data storage.
■Call
Select Menu > Settings > Call and from the following options:
Call divert — to divert your incoming calls (network service). You may
not be able to divert your calls if some call barring functions are active.
See Call barring service in “Security,” p. 67.
Anykey answer > On — to answer an incoming call by briefly pressing
any key, except the power key, the camera key, the left and right
selection keys, or the end key
Answ. when fold opened > On — to answer an incoming call by opening
the fold
Automatic redial > On — to make a maximum of 10 attempts to connect
the call after an unsuccessful call attempt
Speed dialling > On — to dial the names and phone numbers assigned to
the speed-dialing keys 2 to 9 by pressing and holding the corresponding
number key
Call waiting > Activate — to have the network notify you of an incoming
call while you have a call in progress (network service). See “Call
waiting,” p. 23.
Summary after call > On — to briefly display the approximate duration
and cost (network service) of the call after each call
Send my caller ID > Yes — to show your phone number to the person you
are calling (network service). To use the setting agreed upon with your
service provider, select Set by network.
Line for outgoing calls — to select the phone line 1 or 2 for making calls
if supported by your SIM card (network service).
FCC_6126H_6133H_en_1_FCC.fm Page 64 Tuesday, June 27, 2006 1:35 PM
Settings
65
DRAFT
■Phone
Select Menu > Settings > Phone and from the following options:
Language settings — to set the display language of your phone, select
Phone language. If you select Automatic, the phone selects the
language according to the information on the SIM card.
To select the USIM card language, select SIM language.
To set a language for the voice playback, select Voice playback language.
See “Enhanced voice dialing,” p. 21 and Voice commands in “My
shortcuts,” p. 57.
Security keyguard — to set the phone to ask for the security code when
you unlock the keyguard. Enter the security code, and select On.
Automatic keyguard — to lock the keypad automatically after a preset
time delay when the phone is in the standby mode and no function of
the phone has been used. Select On, and set the time.
Welcome note — to write the note you would like to be shown briefly
when the phone is switched on
Flight query > On— the phone asks every time when it is switched on
whether the flight profile shall be used. With flight profile all radio
connections are switched off. The flight profile should be used in areas
sensitive to radio emissions.
Phone updates — to receive phone software updates from your service
provider (network service). This option may not be available, depending
on your phone. See “Phone software updates,” p. 68.
Operator selection > Automatic — to set the phone to automatically
select one of the cellular networks available in your area. With Manual
you can select a network that has a roaming agreement with your
service provider.
Confirm SIM serv. actions — See “SIM services,” p. 94.
Help text activation — to select whether the phone shows help texts
Start-up tone > On— the phone plays a tone when it is switched on
FCC_6126H_6133H_en_1_FCC.fm Page 65 Tuesday, June 27, 2006 1:35 PM
Settings
66
DRAFT
■Enhancements
This menu or the following options are shown only if the phone is or has
been connected to a compatible mobile enhancement.
Select Menu > Settings > Enhancements. Select an enhancement, and
depending on the enhancement, from the following options:
Default profile — to select the profile that you want to be automatically
activated when you connect to the selected enhancement
Automatic answer — to set the phone to answer an incoming call
automatically after 5 seconds. If Incoming call alert is set to Beep once
or Off, automatic answer is off.
Lights — to set the lights permanently On. Select Automatic to set the
lights on for 15 seconds after a key press.
Text phone > Use text phone > Yes — to use the text phone settings
instead of headset or loopset settings
Activate the hearing aid mode
Select Hearing aid > T-coil hearing aid mode > On to optimise the sound
quality when using a t-coil hearing aid. The icon is shown when the
T-coil hearing aid mode is active.
If you make an emergency call to 911 while the phone is in the hearing
aid mode, the phone will use as much power as it needs (up to the
maximum available) to connect the call. More information on
accessibility can be found at www.nokiaaccessibility.com
■Configuration
You can configure your phone with settings that are required for certain
services to function correctly. The services are multimedia messaging,
IM, synchronization, e-mail application, streaming, and browser. Your
service provider may also send you these settings. See “Configuration
settings service,” p. 10.
Select Menu > Settings > Configuration and from the following
options:
FCC_6126H_6133H_en_1_FCC.fm Page 66 Tuesday, June 27, 2006 1:35 PM
Settings
67
DRAFT
Default config. settings — to view the service providers saved in the
phone. Scroll to a service provider, and select Details to view the
applications that the configuration settings of this service provider
support. To set the configuration settings of the service provider as
default settings, select Options > Set as default. To delete configuration
settings, select Delete.
Activ. default in all apps. — to activate the default configuration settings
for supported applications
Preferred access point — to view the saved access points. Scroll to an
access point, and select Options > Details to view the name of the
service provider, data bearer, and packet data access point or GSM
dial-up number.
Connect to serv. support — to download the configuration settings from
your service provider
Device manager settings — to allow or prevent the phone from receiving
phone software updates. This option may not be available, depending on
your phone. See “Phone software updates,” p. 68.
Personal config. settings — to add new personal accounts for various
services manually, and to activate or delete them. To add a new personal
account if you have not added any, select Add; otherwise, select
Options > Add new. Select the service type, and select and enter each of
the required parameters. The parameters differ according to the selected
service type. To delete or activate a personal account, scroll to it, and
select Options > Delete or Activate.
■Security
When security features that restrict calls are in use (such as call barring, closed
user group, and fixed dialling) calls still may be possible to the official emergency
number programmed into your device.
Select Menu > Settings > Security and from the following options:
PIN code request and UPIN code request — to set the phone to ask for
your PIN or UPIN code every time the phone is switched on. Some SIM
cards do not allow the code request to be turned off.
FCC_6126H_6133H_en_1_FCC.fm Page 67 Tuesday, June 27, 2006 1:35 PM
Settings
68
DRAFT
PIN2 code request — to select whether the PIN2 code is required when
using a specific phone feature which is protected by the PIN2 code.
Some SIM cards do not allow the code request to be turned off.
Call barring service — to restrict incoming calls to and outgoing calls
from your phone (network service). A barring password is required.
Fixed dialling — to restrict your outgoing calls to selected phone
numbers if this function is supported by your SIM card
Closed user group — to specify a group of people whom you can call and
who can call you (network service)
Security level > Phone — to set the phone to ask for the security code
whenever a new SIM card is inserted into the phone. If you select
Memory, the phone asks for the security code when the SIM card
memory is selected, and you want to change the memory in use.
Access codes — to change the security code, PIN code, UPIN code, PIN2
code, or barring password
Code in use — to select whether the PIN code or UPIN code should be
active
Authority certificates or User certificates — to view the list of the
authority or user certificates downloaded into your phone. See
“Certificates,” p. 100.
Security module settings — to view Security module details, activate
Module PIN request, or change the module PIN and signing PIN. See also
“Access codes,” p. 9.
■Phone software updates
Your service provider may send phone software updates over the air
directly to your device. This option may not be available, depending on
your phone.
Warning: If you install a software update, you cannot use the
device, even to make emergency calls, until the update is
completed and the device is restarted. Be sure to backup data
before accepting a software update.
FCC_6126H_6133H_en_1_FCC.fm Page 68 Tuesday, June 27, 2006 1:35 PM
Settings
69
DRAFT
Settings
To allowed or disallow phone software updates, select Menu >
Settings > Configuration > Device manager settings >
Service prov. sw updates and following options:
Always allow — to perform all software downloads and updates
automatically
Confirm first — to perform software downloads and updates only after
your confirmation (default setting)
Always reject — to reject all software updates
Depending on your settings you will be notified that a software update
is available for download or has been downloaded and installed
automatically.
Request a software update
Select Menu > Settings > Phone > Phone updates to request available
phone software updates from your service provider. Select Current
software details to display the current software version and check
whether an update is needed. Select Download phone softw. to
download and install a phone software update. Follow the instructions
on the display.
Install a software update
Select Install software update to start the installation, when the
installation was cancelled after the download.
The software update may take several minutes. If there are problems
with the installation, contact your service provider.
■Restore factory settings
To reset some of the menu settings to their original values, select
Menu > Settings > Restore factory sett.. Enter the security code. The
names and phone numbers saved in Contacts are not deleted.
FCC_6126H_6133H_en_1_FCC.fm Page 69 Tuesday, June 27, 2006 1:35 PM
Operator menu
70
DRAFT
10. Operator menu
This menu lets you access a portal to services provided by your network
operator. The name and the icon depend on the operator. For more
information contact your network operator. If this menu is not shown
the following menu numbers change accordingly.
The operator can update this menu with a service message. For more
information, see “Service inbox,” p. 99.
FCC_6126H_6133H_en_1_FCC.fm Page 70 Tuesday, June 27, 2006 1:35 PM
Gallery
71
DRAFT
11. Gallery
In this menu you can manage images, video clips, music
files, themes, graphics, tones, recordings, and received files. These files
are stored in the phone memory or a attached microSD memory card
and may be arranged in folders.
Your phone supports an activation key system to protect acquired
content. Always check the delivery terms of any content and activation
key before acquiring them, as they may be subject to a fee.
Copyright protections may prevent some images, music (including ringing tones),
and other content from being copied, modified, transferred or forwarded.
To see the list of folders, select Menu > Gallery.
To see the available options of a folder, select a folder > Options.
To view the list of files in a folder, select a folder > Open.
To see the available options of a file, select a file > Options.
■Print images
Your device supports Nokia XPressPrint. To connect it to a compatible
printer use a data cable or send the image via Bluetooth to a printer
supporting Bluetooth technology. See “Connectivity,” p. 58.
You can print images that are in the JPEG format. The images taken with
the camera are automatically saved in the JPEG format.
Select the image you want to print and Options > Print.
■Memory card
Keep all memory cards out of the reach of small children.
You can use the microSD memory card to store your multimedia files
such as video clips, music tracks, and sound files, photos, and messaging
data, and to back up information from phone memory.
Details of how you can use the memory card with other features and
applications of your phone are given in the sections describing these
features and applications. To insert and remove the microSD memory
FCC_6126H_6133H_en_1_FCC.fm Page 71 Tuesday, June 27, 2006 1:35 PM
Gallery
72
DRAFT
card see “Insert a microSD card,” p. 13 and “Remove the microSD card,”
p. 13. The following options may can also be accessed from the Gallery.
Format the memory card
When a memory card is formatted, all data on the card is permanently
lost. Some memory cards are supplied preformatted and others require
formatting. Consult your retailer to find out if you must format the
memory card before you can use it.
1. Select Menu > Applications and the memory card folder .
2. Select Options > Format memory card.
3. Select Yes to confirm.
4. When formatting is complete, enter a name for the memory card (up
to 11 letters or numbers).
Lock the memory card
To set a password to lock your memory card to help prevent
unauthorized use, select Options > Set password.
You are asked to enter and confirm your password. The password can be
up to eight characters long. The password is stored in your phone and
you do not have to enter it again while you are using the memory card
on the same phone. If you want to use the memory card on another
phone, you are asked for the password.
Unlock a memory card
If you insert another password-protected memory card into your phone,
you are prompted to enter the password of the card. To unlock the card,
select Options > Delete password.
Once the password is removed, the memory card is unlocked and can be
used on another phone without a password.
Check memory consumption
To check the memory consumption of different data groups and the
available memory for installing new applications or software on your
memory card, select Options > Details.
FCC_6126H_6133H_en_1_FCC.fm Page 72 Tuesday, June 27, 2006 1:35 PM
Media
73
DRAFT
12. Media
When taking and using images or video clips, obey all laws and respect local
customs as well as privacy and legitimate rights of others.
■Camera
You can take photos or record video clips with the built-in camera.
Take a photo
To start the camera, press the camera key in the standby mode, or select
Menu > Media > Camera.
To take an image in landscape
format, hold the phone in a
horizontal position. Press the
navigation key left or right to
change between camera (still
image) and video mode.
To zoom in and out in the camera mode, press the navigation key up and
down, or the volume keys.
To take a photo, select Capture, or press the camera key. The phone
saves the photo in Gallery > Images.
To take a self-portrait, close the fold and use the mini display as a view
finder. Press the camera key.
Select Options to set Night mode on if the lighting is dim, Self-timer on
to activate the self-timer, Img. sequence on to take photos in a fast
sequence. With the highest image size setting 3 photos are taken in a
sequence, with other size settings 5 photos are taken.
Select Options > Settings >Image preview time and a preview time to
display the taken photo on the display. During the preview time, select
Back to take another photo or Send to send the photo as a multimedia
message.
Your device supports an image capture resolution of 1280 x 960 pixels. The
image resolution in these materials may appear different.
FCC_6126H_6133H_en_1_FCC.fm Page 73 Tuesday, June 27, 2006 1:35 PM
Media
74
DRAFT
Record a video clip
To select the video mode, scroll left or right, or select Options > Video.
To start the video recording, select Record. To pause the recording,
select Pause; to resume the recording, select Continue. To stop the
recording, select Stop. The phone saves the recording in Gallery > Video
clips.
Camera options
To use a filter with the camera, select Options > Effects >False colours,
Greyscale, Sepia, Negative, or Solarise.
To change the camera settings, select Options > Settings.
■Media player
With the media player you can view, play, and download files, such as
images, audio, video, and animated images. You can also view
compatible streaming videos from a network server (network service).
Select Menu > Media > Media player > Open gallery, Bookmarks, Go to
address, or Media downloads to select or download media.
Select Menu > Media > Media player > FF/Rew interval to set the step
width for fast forward or rewind.
Configuration for a streaming service
You may receive the configuration settings required for streaming as a
configuration message from the service provider. See “Configuration
settings service,” p. 10. You can also enter the settings manually. See
“Configuration,” p. 66. To activate the settings, do the following:
1. Select Menu > Media > Media player > Streaming settings >
Configuration. Only the configurations that support streaming are
shown.
2. Select a service provider, Default, or Personal configuration for
streaming.
3. Select Account and a streaming service account contained in the
active configuration settings.
FCC_6126H_6133H_en_1_FCC.fm Page 74 Tuesday, June 27, 2006 1:35 PM
Media
75
DRAFT
■Music player
Your phone includes a music player for listening to music tracks,
recordings or other MP3 or AAC sound files that you have transferred to
the phone with the Nokia Audio Manager application, which is part of
Nokia PC Suite. See “Nokia PC Suite,” p. 102.
Music files stored in a folder in the phone memory or in a folder of the
multimedia card, will automatically be detected and added to the
default track list.
To open the music player, select Menu > Media > Music player.
Playing the music tracks
Warning! Listen to music at a moderate level. Continuous exposure to
high volume may damage your hearing.
When you open the Music player menu, the details of the first track on
the default track list are shown. To play, select .
To adjust the volume level, use the volume keys on the side of the phone.
To stop the playing, select .
To skip to the next track, select . To skip to the beginning of the
previous track, select .
To rewind the current track, select and hold . To fast forward the
current track, select and hold . Release the key at the position you
want.
Settings for the music player
In the Music player menu the following options may be available:
Track list — View all the tracks available on the track list and play the
desired track. To play a track, scroll to the desired track, and select Play.
If you select Options, you can refresh the track list (for example, after
adding new tracks to the list) and change the track list that is shown
when you open the Music player menu if several track lists are available
in the phone. You also my send a track to another phone.
FCC_6126H_6133H_en_1_FCC.fm Page 75 Tuesday, June 27, 2006 1:35 PM
Media
76
DRAFT
Play options — Select Random to play the tracks on the track list in
random order. Select Repeat to play the current track or the entire track
list repeatedly. Select Music source to select a folder with music tracks.
Media equaliser — Select or define an equalizer setting. See “Equalizer,”
p. 78.
Loudspeaker/Headset— Listen to the music player using the phone
loudspeaker or headset. (Only if a headset is attached)
Tip: When using a headset, press the headset key to skip to the
next track.
Web page — to access a Web page associated with the currently played
track. Dimmed if no Web page is available.
Music downloads— to connect to a browser service related to the
current track. This function is only available when the address of the
service is included in the track.
■Radio
The FM radio depends on an antenna other than the wireless device’s antenna. A
compatible headset or enhancement needs to be attached to the device for the
FM radio to function properly.
Warning: Listen to music at a moderate level. Continuous exposure to
high volume may damage your hearing. Do not hold the device near
your ear when the loudspeaker is in use, because the volume may be
extremely loud.
Select Menu > Media > Radio.
To use the graphical keys , , , or on the display, scroll left or
right to the desired key, and select it.
Save radio frequencies
1. To start the search, select and hold or . To change the radio
frequency in 0.05 MHz steps, briefly press or .
2. To save a frequency to a memory location, 1 to 9, press and hold the
corresponding number key. To save a frequency to a memory location
FCC_6126H_6133H_en_1_FCC.fm Page 76 Tuesday, June 27, 2006 1:35 PM
Media
77
DRAFT
from 10 to 20, press briefly 1 or 2, and press and hold the desired
number key, 0 to 9.
3. Enter the name of the radio station.
Listen to the radio
Select Menu > Media > Radio. To scroll to the desired frequency, select
or , or press the headset key. To select a radio station, briefly
press the corresponding number keys. To adjust the volume, press the
volume keys.
Select from the following options:
Switch off — to turn off the radio
Save station — to save a new radio station
Visual Radio — to set whether the Visual Radio application is used
(network service). To check the availability and costs, contact your
network operator or service provider. Some radio stations may send text
or graphical information that you can view using the Visual Radio
application.
Visual Radio settings — to select the options for Visual Radio. To set
whether the application starts automatically when you turn on the
radio, select Enable visual service > Automatically. To access a Web site
with a list of radio stations, select Station directory. If available, their
visual radio ID is shown.
Stations — to select the list of saved stations. To delete or rename a
station, scroll to the desired station, and select Options > Delete station
or Rename.
Mono output or Stereo output — to listen to the radio in monophonic
sound or in stereo
Loudspeaker or Headset — to listen to the radio using the loudspeaker or
headset. Keep the headset connected to the phone. The lead of the
headset functions as the radio antenna.
Set frequency — to enter the frequency of the desired radio station
You can normally make a call or answer an incoming call while listening
to the radio. During the call, the volume of the radio is muted.
FCC_6126H_6133H_en_1_FCC.fm Page 77 Tuesday, June 27, 2006 1:35 PM
Media
78
DRAFT
When an application using a packet data or HSCSD connection is
sending or receiving data, it may interfere with the radio.
■Voice recorder
You can record pieces of speech, sound, or an active call, and save them
in Gallery. This is useful when recording a name and phone number to
write down later.
The recorder cannot be used when a data call or GPRS connection is active.
Record sound
1. Select Menu > Media > Voice recorder.
To use the graphical keys , , or on the display, scroll left or
right to the desired key, and select it.
2. To start the recording, select . To start the recording during a call,
select Options > Record. While recording a call, all parties to the call
hear a faint beeping sound. When recording a call, hold the phone in
the normal position near to your ear. To pause the recording, select
.
3. To end the recording, select . The recording is saved in Gallery >
Recordings.
To listen to the latest recording, select Options > Play last recorded.
To send the last recording, select Options > Send last recorded.
To see the list of recordings in Gallery, select Options > Recordings
list > Recordings.
■Equalizer
You can control the sound quality when using the music player by
amplifying or diminishing frequency bands.
Select Menu > Media > Equaliser.
To activate a set, scroll to one of the equalizer sets, and select Activate.
To view, edit, or rename a selected set, select Options > View, Edit, or
Rename. Not all sets can be edited or renamed.
FCC_6126H_6133H_en_1_FCC.fm Page 78 Tuesday, June 27, 2006 1:35 PM
Media
79
DRAFT
■Stereo widening
Stereo widening enhances the audio output of the music player by
enabling a wider stereo sound effect. To change the setting, select
Menu > Media > Stereo widening.
FCC_6126H_6133H_en_1_FCC.fm Page 79 Tuesday, June 27, 2006 1:35 PM
Organizer
80
DRAFT
13. Organizer
■Alarm clock
You can set the phone to alarm at a desired time. Select Menu >
Organiser > Alarm clock.
To set the alarm, select Alarm time, and enter the alarm time. To change
the alarm time when the alarm time is set, select On.
To set the phone to alert you on selected days of the week, select Repeat
alarm.
To select the alarm tone or set the radio as the alarm tone, select Alarm
tone. If you select the radio as an alarm tone, connect the headset to the
phone. The phone uses the last radio station you listened to as the
alarm, and the alarm plays through the loudspeaker. If you remove the
headset or switch off the phone, the default alarm tone replaces the
radio.
To set a snooze time-out, select Snooze time-out and the time.
Stop the alarm
The phone sounds an alert tone, and flashes Alarm! and the current time
on the display, even if the phone was switched off. To stop the alarm,
select Stop. If you let the phone continue to sound the alarm for a
minute or select Snooze, the alarm stops for the time you set in Snooze
time-out, then resumes.
If the alarm time is reached while the device is switched off, the device switches
itself on and starts sounding the alarm tone. If you select Stop, the device asks
whether you want to activate the device for calls. Select No to switch off the
device or Yes to make and receive calls. Do not select Yes when wireless phone
use may cause interference or danger.
■Calendar
Select Menu > Organiser > Calendar.
The current day is indicated by a frame. If there are any notes set for the
day, the day is in bold type, and the beginning of the note is shown
FCC_6126H_6133H_en_1_FCC.fm Page 80 Tuesday, June 27, 2006 1:35 PM
Organizer
81
DRAFT
below the calendar. To view the day notes, select View. To view a week,
select Options > Week view. To delete all notes in the calendar, select
the month or week view, and select Options > Delete all notes.
Other options for the day view may be to make a note; delete, edit,
move, or repeat a note; copy a note to another day; send a note with
Bluetooth technology; or send a note to the calendar of another
compatible phone as a text message or multimedia message. In Settings
you can set the date, time, time zone, date or time format, date
separator, default view, or the first day of the week. In Auto-delete
notes you can set the phone to delete old notes automatically after a
specified time.
Make a calendar note
Select Menu > Organiser > Calendar. Scroll to the date, and select
Options > Make a note and one of the following note types:
Meeting, Call, Birthday, Memo, or Reminder. Fill in
the fields.
Note alarm
The phone displays the note and if set, sounds a tone. With a call note
on the display, to call the displayed number, press the call key. To
stop the alarm and to view the note, select View. To stop the alarm for
10 minutes, select Snooze.
To stop the alarm without viewing the note, select Exit.
■To-do list
To save a note for a task that you must do, select Menu > Organiser >
To-do list.
To make a note if no note is added, select Add; otherwise, select
Options > Add. Fill in the fields, and select Save.
To view a note, scroll to it, and select View. While viewing a note, you
can also select an option to edit the attributes. You can also select an
option to delete the selected note and delete all the notes that you have
marked as done.
FCC_6126H_6133H_en_1_FCC.fm Page 81 Tuesday, June 27, 2006 1:35 PM
Organizer
82
DRAFT
You can sort the notes by priority or by deadline, send a note to another
phone as a text message or a multimedia message, save a note as a
calendar note, or access the calendar.
■Notes
To write and send notes, select Menu > Organiser > Notes.
To make a note if no note is added, select Add; otherwise, select
Options > Make a note. Write the note, and select Save.
Other options include deleting and editing a note. While editing a note,
you can also exit the text editor without saving the changes. You can
send the note to compatible devices by Bluetooth wireless technology,
text message, or a multimedia message.
■Calculator
The calculator in your phone provides basic arithmetic and
trigonometric functions, calculates the square and the square root, the
inverse of a number, and converts currency values.
Note: This calculator has limited accuracy and is designed for simple
calculations.
Select Menu > Organiser > Calculator. When 0 is displayed on the
screen, enter the first number in the calculation. Press # for a decimal
point. Scroll to the desired operation or function or select it from the
Options. Enter the second number. Repeat this sequence as many times
as it is necessary. To start a new calculation, first select and hold Clear.
To perform a currency conversion, select Menu > Organiser >
Calculator. To save the exchange rate, select Options > Exchange rate.
Select either of the displayed options. Enter the exchange rate, press #
for a decimal point, and select OK. The exchange rate remains in the
memory until you replace it with another one. To perform the currency
conversion, enter the amount to be converted, and select Options > In
domestic or In foreign.
Note: When you change base currency, you must enter new exchange
rates because all previously set exchange rates are cleared.
FCC_6126H_6133H_en_1_FCC.fm Page 82 Tuesday, June 27, 2006 1:35 PM
Organizer
83
DRAFT
■Countdown timer
Select Menu > Organiser > Countdown timer. Enter the alarm time in
hours, minutes, and seconds, and select OK. If you wish, write your own
note text that is displayed when the time expires. To start the
countdown timer, select Start. To change the countdown time, select
Change time. To stop the timer, select Stop timer.
If the alarm time is reached when the phone is in the standby mode, the
phone sounds a tone and flashes the note text if it is set or Countdown
time up. To stop the alarm, press any key. If no key is pressed, the alarm
automatically stops within 60 seconds. To stop the alarm and delete the
note text, select Exit. To restart the countdown timer, select Restart.
■Stopwatch
You can measure time, take intermediate times, or take lap times using
the stopwatch. During timing, the other functions of the phone can be
used. To set the stopwatch timing in the background, press the end key.
Using the stopwatch or allowing it to run in the background when using other
features increases the demand on battery power and reduces the battery life.
Select Menu > Organiser > Stopwatch and from the following options:
Split timing — to take intermediate times. To start the time observation,
select Start. Select Split every time that you want to take an
intermediate time. To stop the time observation, select Stop.
To save the measured time, select Save.
To start the time observation again, select Options > Start. The new
time is added to the previous time. To reset the time without saving it,
select Reset.
Lap timing — to take lap times
Continue — to view the timing that you have set in the background
Show last — to view the most recently measured time if the stopwatch is
not reset
View times or Delete times — to view or delete the saved times
FCC_6126H_6133H_en_1_FCC.fm Page 83 Tuesday, June 27, 2006 1:35 PM
Push to talk
84
DRAFT
14. Push to talk
Select Menu > Push to talk.
Push to talk (PTT) over cellular is a two-way radio service available over
a GPRS cellular network (network service).
You can use PTT to have a conversation with one person or with a group
of people (channel) having compatible devices. While you are connected
to the PTT service, you can use the other functions of the phone.
To check availability and costs, and to subscribe to the service, contact
your network operator. Roaming services may be more limited than for
normal calls.
Before you can use the PTT service, you must define the required PTT
service settings. See “PTT settings,” p. 89 and “Configuration settings,”
p. 90.
■Push to talk channels
A PTT channel comprises a group of people (for example, friends or a
workteam) who joined the channel after they where invited to. When
you call a channel, all members joined to the channel hear the call
simultaneously.
There are different types of PTT channels:
Public channel — Every channel member can invite other persons.
Private channel — Only persons which receive an invitation by the
channel creator can join in.
Provisioned channel — A permanent channel is created by the service
provider.
You can set the status of each channel to Active or Inactive.
The number of active channels and the number of members per channel
is limited. Contact your service provider for details.
FCC_6126H_6133H_en_1_FCC.fm Page 84 Tuesday, June 27, 2006 1:35 PM
Push to talk
85
DRAFT
Create a channel
To add a channel, select Menu > Push to talk > Add channel and enter
the settings in the form fields:
Channel name: — Enter a name for the new channel.
Channel status: — Select Active to set the channel active, or Inactive to
disable the channel.
Nickname in channel: — Enter your nick name to be shown the new
channel.
Channel security: > Public channel or Private channel
Image: — Select Change and an image from the Gallery or the Default
graphic to set a graphic for the new channel.
To send an invitation to the channel, select Yes when the phone requests
it. The recipient of the invitation is added to the member list of the
channel when the invitation is accepted. To send further invitations
select Menu > Push to talk > Channel list, a channel, and Options >
Send invitation. To send the invitation use a text message or IR.
To add a provisioned channel, select Menu > Push to talk > Add
channel > Options > Edit address manually. Enter the Channel address:
provided by your service provider.
Receive an invitation
1. When you receive a text message invitation to a channel, Channel
invitation received: is displayed.
2. To view the nickname of the person who sent the invitation and the
channel address if the channel is not a private channel, select View.
3. To add the channel to your phone, select Save.
4. To set the status for the channel, select Active or Inactive.
To reject the invitation, select Exit > Yes, or select View > Discard > Yes.
FCC_6126H_6133H_en_1_FCC.fm Page 85 Tuesday, June 27, 2006 1:35 PM
Push to talk
86
DRAFT
■Switch PTT on and off
To connect to the PTT service, select Menu > Push to talk > Switch PTT
on, or press and hold the PTT (volume up) key. indicates the PTT
connection. indicates that the service is temporarily unavailable. If
you have added channels to the phone, you are automatically joined to
the active channels.
You may assign a default function to the PTT (volume up) key to open
the channel list, the contacts list or a single channel or contact. See “PTT
settings,” p. 89.
To disconnect from the PTT service, select Switch PTT off.
■Make and receive a PTT call
Warning: Do not hold the device near your ear when the loudspeaker is
in use, because the volume may be extremely loud.
To make a channel call, a one-to-one call, or a call to multiple
recipients, you must hold the PTT (volume up) key as long as you talk. To
listen to the response, release the PTT (volume up) key. Talking is allowed
on a first-come, first-served basis. When you stop talking, the first
person to press and hold the PTT key can talk next.
You may be able to check the login status of your contacts in Menu >
Push to talk > Contacts list. This service depends on your network
operator and is only available for subscribed contacts. To subscribe a
contact, select Options >Subscribe contact, or if one or more contacts
are already marked Subscribe marked.
or indicate that the person is either available or unknown.
indicates that the person wants not to be disturbed, but can receive
callback requests. indicates that the person has PTT not switched
on.
Make a channel call
To make a call to a channel, select Channel list in the PTT menu, scroll to
the desired channel, and press and hold the PTT (volume up) key. A tone
indicates that the access is granted, and the phone displays your
nickname and channel name.
FCC_6126H_6133H_en_1_FCC.fm Page 86 Tuesday, June 27, 2006 1:35 PM
Push to talk
87
DRAFT
Make a one-to-one call
To start a one-to-one call from the list of contacts to which you have
added the PTT address, select Contacts > Names or Menu > Push to
talk > Contacts list. Scroll to a contact, and press and hold the PTT
(volume up) key.
To start a one-to-one call from the list of PTT channels, select Channel
list, scroll to the desired channel, and select Members. Scroll to the
desired contact, and press and hold the PTT (volume up) key.
To start a one-to-one call from the list of callback requests you have
received, select Callback inbox. Scroll to the desired nickname, and press
and hold the PTT (volume up) key.
Make a PTT call to multiple recipients
You can select multiple PTT contacts from the contact list. The recipients
receive an incoming call and need to accept the call in order to
participate. If supported by your network operator, you also may select
contacts with a phone number but without PTT number. For details,
contact your network operator.
1. Select Menu > Push to talk > Contacts list, and mark the desired
contacts.
2. Press and hold the PTT (volume up) key to start the call. The
participating contacts are shown on the display, as soon as they join
the call.
3. Press and hold the PTT (volume up) key to talk to them. Release the
PTT (volume up) key to hear the response.
4. Press the end key to terminate the call.
Receive a PTT call
A short tone notifies you of an incoming PTT call. Informations, such as
the channel, the phone number, or the nickname (network service) of
the caller are displayed.
You can either accept or reject an incoming one-to-one call if you have
set the phone to first notify you of the one-to-one calls.
FCC_6126H_6133H_en_1_FCC.fm Page 87 Tuesday, June 27, 2006 1:35 PM
Push to talk
88
DRAFT
When you press and hold the PTT (volume up) key while the caller is
talking, you hear a queuing tone, and Queuing is displayed. Press and
hold the PTT (volume up) key, and wait for the other person to finish;
then you can talk immediately.
■Callback requests
If you make a one-to-one call and do not get a response, you can send a
request for the person to call you back.
Send a callback request
You can send a callback request in the following ways:
To send a callback request from the contacts list in the Push to talk
menu, select Contacts list. Scroll to a contact, and select Options >
Send callback.
To send a callback request from Contacts, search for the desired contact,
and select Details. Scroll to the PTT address, and select Options > Send
callback.
To send a callback request from the channel list in the PTT menu, select
Channel list, and scroll to the desired channel. Select Members, scroll to
the desired contact, and select Options > Send callback.
To send a callback request from the callback request list in the Push to
talk menu, select Callback inbox. Scroll to a contact, and select
Options > Send callback.
Respond to a callback request
When someone sends you a callback request, Callback request received
is displayed in the standby mode.
To open the Callback inbox, select View. The list of nicknames of the
persons who have sent you callback requests is shown.
To make a one-to-one call, select the desired request and press and hold
the PTT (volume up) key.
To send a call request back to the sender, select Options > Send
callback.
FCC_6126H_6133H_en_1_FCC.fm Page 88 Tuesday, June 27, 2006 1:35 PM
Push to talk
89
DRAFT
To delete the request, select Delete.
To save a new contact or to add the PTT address to a contact from a
received callback request, select Options > Save as or Add to contact.
■Add a one-to-one contact
You can save the names of persons to whom you often make one-to-one
calls in the following ways:
To add a PTT address to a name in Contacts, search for the desired
contact, select Details > Options > Add detail > Push to talk address. A
contact will only appear in the PTT contact list, if the PTT address is
entered.
To add a contact to the PTT contacts list, select Menu > Push to talk >
Contacts list > Options > Add contact.
To add a contact from the channel list, connect to the PTT service, select
Channel list, and scroll to the desired channel. Select Members, scroll to
the member whose contact information you want to save, and select
Options. To add a new contact, select Save as. To add a PTT address to a
name in Contacts, select Add to contact.
■PTT settings
Select Menu >Push to talk > Push to talk settings.
1 to 1 calls > On — to select the phone to allow the reception of
incoming one-to-one calls. To make but not receive one-to-one calls,
select Off. The service provider may offer some services that override
these settings. To set the phone to first notify you of incoming
one-to-one calls with a ringing tone, select Notify.
PTT key default function — to set the PTT (volume up) key to following
functions: Open contact list, Open channel list, Call contact or group.
Select a contact, a group, or Call PTT channel and select a channel.
When you press and hold the PTT (volume up) key, the selected function
will be performed.
Show my login status — to enable or disable the sending of the login
status
FCC_6126H_6133H_en_1_FCC.fm Page 89 Tuesday, June 27, 2006 1:35 PM
Push to talk
90
DRAFT
PTT status in startup > Yes or Ask first— to set the phone to
automatically connect to the PTT service when you switch the phone on
Push to talk when abroad — to switch the PTT service on or off when the
phone is used outside of the home network
Send my PTT address > No — to hide your PTT address from channel and
one-to-one calls
■Configuration settings
You may receive the settings for connecting to the service from your
service provider. See “Configuration settings service,” p. 10. You can
enter the settings manually. See “Configuration,” p. 66.
To select the settings for connecting to the service, select Menu > Push
to talk > Configuration sett.. Select from the following options:
Configuration — to select a service provider, Default, or Personal
configuration for PTT service. Only the configurations that support the
PTT service are shown.
Account — to select a PTT service account contained in the active
configuration settings
Other parameters are Push to talk user name, Default nickname, Push to
talk password, Domain, and Server address.
■Web
Select Menu > Push to talk > Web to access the Internet site of your PTT
provider.
FCC_6126H_6133H_en_1_FCC.fm Page 90 Tuesday, June 27, 2006 1:35 PM
Applications
91
DRAFT
15. Applications
In this menu you can manage applications and games. These files are
stored in the phone memory or a attached microSD memory card and
may be arranged in folders.
For options to format or lock and unlock the memory card see “Memory
card,” p. 71.
■Launch a game
Your phone software includes some games.
Select Menu > Applications > Games. Scroll to the desired game, and
select Open.
To set sounds, lights, and shakes for the game, select Menu >
Applications > Options > Application settings.
For more options related to a game, see “Some application options,”
p. 91.
■Launch an application
Your phone software includes some Java applications.
Select Menu > Applications > Collection. Scroll to an application, and
select Open.
■Some application options
Delete — to delete the application from the phone
Details — to give additional information about the application
Update version — to check if a new version of the application is available
for download from Web (network service)
Application access — to restrict the application from accessing the
network. Different categories are shown. Select in each category one of
the available permissions.
FCC_6126H_6133H_en_1_FCC.fm Page 91 Tuesday, June 27, 2006 1:35 PM
Applications
92
DRAFT
Web page — to provide further information or additional data for the
application from an Internet page (network service). It is only shown if
an Internet address has been provided with the application.
■Download an application
Your phone supports J2ME Java applications. Make sure that the
application is compatible with your phone before downloading it.
Important: Only install and use applications and other software from
sources that offer adequate security and protection against harmful
software.
You can download new Java applications and games in different ways.
Use the Nokia Application Installer from PC Suite to download the
applications to your phone, or select Menu > Applications > Options >
Downloads > Application downloads; the list of available bookmarks is
shown. See “Bookmarks,” p. 97.
For the availability of different services, pricing, and tariffs, contact your
service provider.
Your device may have some bookmarks loaded for sites not affiliated with Nokia.
Nokia does not warrant or endorse these sites. If you choose to access them, you
should take the same precautions, for security or content, as you would with any
Internet site.
■Presenter
The Presenter enables you to control slide presentations (compatible
with Microsoft Office PowerPoint), a software DVD, an MP3 player, or
other PC applications remotely from your device.
To use applications other than slide presentations and desktop mode,
you must create a corresponding custom profile on the PC application.
Before you can use the application you must do the following:
1. Install the Nokia Presenter PC application on your PC.
This component is available for download on the Nokia Web site. See
“Nokia support,” p. 11.
FCC_6126H_6133H_en_1_FCC.fm Page 92 Tuesday, June 27, 2006 1:35 PM
Applications
93
DRAFT
2. Launch and configure the PC component. Make sure that the
selected incoming Bluetooth serial port (COM port) corresponds to
the one defined in the Bluetooth software settings on the Bluetooth
device of your PC. For details, refer to the PC component
documentation and “Set up a Bluetooth connection,” p. 59.
3. Open the slide presentation, or start the application you want to
control remotely from your phone.
Select Applications > Collection > Presenter > Connect and the device
you want to connect to.
When the Bluetooth Connection Successful dialog appears on your PC
screen, you must click on it to confirm the Bluetooth connection.
The list of available application types is displayed. Select Open to access
the desired application. Select Options > Settings to set the Font size
for the speaker notes, and Timer (in minutes) to optimize the slide
presentation time available. To save the settings, select Options > Back.
After you have select the slide presentation you browse or skip slides, or
jump ahead, by using the 4-way navigation key. To view your speaker
notes, select Notes. To point things out on the slides, select Pointer to
activate a small black round marker, that you control with the 4-way
navigation key. Select Options > Slide list to return to the slide list.
Select Options > Applications list to return to the list of applications.
To control the mouse pointer (the cursor) remotely from the phone,
select the desktop mode. After you open the desktop, the phone
automatically controls your mouse pointer. To return to the list of
applications, select Options > Applications list.
To quit the Presenter, select Options > Exit.
FCC_6126H_6133H_en_1_FCC.fm Page 93 Tuesday, June 27, 2006 1:35 PM
SIM services
94
DRAFT
16. SIM services
Your SIM card may provide additional services. You can
access this menu only if it is supported by your SIM card. The name and
contents of the menu depend on the available services.
For availability and information on using SIM card services, contact your SIM
card vendor. This may be the service provider, network operator, or other vendor.
To set the phone to show you the confirmation messages sent between
your phone and the network when you are using the SIM services, select
Menu > Settings > Phone > Confirm SIM serv. actions > Yes.
Accessing these services may involve sending messages or making a
phone call for which you may be charged.
FCC_6126H_6133H_en_1_FCC.fm Page 94 Tuesday, June 27, 2006 1:35 PM
Web
95
DRAFT
17. Web
You can access various mobile Internet services with your
phone browser.
Important: Use only services that you trust and that offer adequate
security and protection against harmful software.
Check the availability of these services, pricing, tariffs, and instructions
with your service provider.
With the phone browser you can view the services that use wireless
markup language (WML) or extensible hypertext markup language
(XHTML) on their pages. Appearance may vary due to screen size. You
may not be able to view all details of the Internet pages.
■Set up browsing
You may receive the configuration settings required for browsing as a
configuration message from the service provider that offers the service
that you want to use. See “Configuration settings service,” p. 10. You
can also enter all the configuration settings manually. See
“Configuration,” p. 66.
■Connect to a service
Ensure that the correct configuration settings of the service are
activated.
1. To select the settings for connecting to the service, select Menu >
Web > Settings > Configuration settings.
2. Select Configuration. Only the configurations that support browsing
service are shown. Select a service provider, Default, or Personal
configuration for browsing. See “Set up browsing,” p. 95.
3. Select Account and a browsing service account contained in the
active configuration settings.
4. Select Display terminal window > Yes to perform manual user
authentication for intranet connections.
FCC_6126H_6133H_en_1_FCC.fm Page 95 Tuesday, June 27, 2006 1:35 PM
Web
96
DRAFT
Make a connection to the service in one of the following ways:
• Select Menu > Web > Home; or in the standby mode, press and hold
0.
• To select a bookmark of the service, select Menu > Web >
Bookmarks.
• To select the last URL, select Menu > Web > Last web address.
• To enter the address of the service, select Menu > Web > Go to
address. Enter the address of the service, and select OK.
■Browse pages
After you make a connection to the service, you can start browsing its
pages. The function of the phone keys may vary in different services.
Follow the text guides on the phone display. For more information,
contact your service provider.
Browse with phone keys
To browse through the page, scroll in any direction.
To select a highlighted item, press the call key, or select Select.
To enter letters and numbers, press the 0 to 9 keys. To enter special
characters, press *.
Options while browsing
Select from the following options:
Home — to return to your start page
Shortcuts — to open a new list of options that are specific to the page.
This option is only available if the page contains shortcuts.
Add bookmark — to save the page as a bookmark
Bookmarks — to access the list of bookmarks. See “Bookmarks,” p. 97.
Page options — to show the list of options for the active page
History — to get a list showing the last visited URLs
Downloads — to show the list of bookmarks for downloading
FCC_6126H_6133H_en_1_FCC.fm Page 96 Tuesday, June 27, 2006 1:35 PM
Web
97
DRAFT
Other options — to show a list of other options
Reload — to reload and update the current page
The service provider may also offer other options.
Direct calling
While browsing, you can make a phone call, and save a name and a
phone number from a page.
■Bookmarks
You can save page addresses as bookmarks in the phone memory.
1. While browsing, select Options > Bookmarks; or in the standby
mode, select Menu > Web > Bookmarks.
2. Scroll to a bookmark, and select it, or press the call key to make a
connection to the page associated with the bookmark.
3. Select Options to view, edit, delete, or send the bookmark; to create
a new bookmark; or to save the bookmark to a folder.
Your device may have some bookmarks loaded for sites not affiliated with Nokia.
Nokia does not warrant or endorse these sites. If you choose to access them, you
should take the same precautions, for security or content, as you would with any
Internet site.
Receive a bookmark
When you have received a bookmark that is sent as a bookmark, 1
bookmark received is displayed. To view the bookmark, select Show.
■Appearance settings
While browsing, select Options > Other options > Appearance settings;
or in the standby mode, select Menu > Web > Settings > Appearance
settings and from the following options:
Text wrapping > On — to set the text to continue on the next line on the
display. If you select Off, the text is abbreviated.
Font size — to set the font size
FCC_6126H_6133H_en_1_FCC.fm Page 97 Tuesday, June 27, 2006 1:35 PM
Web
98
DRAFT
Show images > No — to hide images on the page. This can speed up the
browsing of pages that contain a lot of images.
Alerts > Alert for unsecure conn. > Yes — to set the phone to alert when
a secure connection changes to an unsecure one during browsing
Alerts > Alert for unsecure items > Yes — to set the phone to alert when
a secure page contains an unsecure item. These alerts do not guarantee
a secure connection. For more information, see “Browser security,”
p. 100.
Character encoding > Content encoding — to select the encoding for the
browser page content
Character encoding > Unicode (UTF-8) web add. > On — to set the
phone to send a URL as a UTF-8 encoding. You may need this setting
when you access a Web page created in foreign language.
Screen size > Full or Small— to set the screen layout
JavaScript > Enable — to enable the Java scripts
■Security settings
Cookies
A cookie is data that a site saves in the cache memory of your phone.
Cookies are saved until you clear the cache memory. See “Cache
memory,” p. 100.
While browsing, select Options > Other options > Security > Cookie
settings; or in the standby mode, select Menu > Web > Settings >
Security settings > Cookies. To allow or prevent the phone from
receiving cookies, select Allow or Reject.
Scripts over secure connection
You can select whether to allow the running of scripts from a secure
page. The phone supports WML scripts.
While browsing, to allow the scripts, select Options > Other options >
Security > WMLScript settings; or in the standby mode, select Menu >
Web > Settings > Security settings > WMLScripts in sec. conn. > Allow.
FCC_6126H_6133H_en_1_FCC.fm Page 98 Tuesday, June 27, 2006 1:35 PM
Web
99
DRAFT
■Download settings
To automatically save all downloaded files in Gallery, select Menu >
Web > Settings > Downloading settings > Automatic saving > On.
■Service inbox
The phone is able to receive service messages sent by your service
provider (network service). Service messages are notifications (for
example, news headlines), and they may contain a text message or an
address of a service.
To access the Service inbox in the standby mode, when you have
received a service message, select Show. If you select Exit, the message
is moved to the Service inbox. To access the Service inbox later, select
Menu > Web > Service inbox.
To access the Service inbox while browsing, select Options > Other
options > Service inbox. Scroll to the message you want, and to activate
the browser and download the marked content, select Retrieve. To
display detailed information on the service notification or to delete the
message, select Options > Details or Delete.
Service inbox settings
Select Menu > Web > Settings > Service inbox settings.
To set whether you want to receive service messages, select Service
messages > On or Off.
To set the phone to receive service messages only from content authors
approved by the service provider, select Message filter > On. To view the
list of the approved content authors, select Trusted channels.
To set the phone to automatically activate the browser from the standby
mode when the phone has received a service message, select Automatic
connection > On. If you select Off, the phone activates the browser only
after you select Retrieve when the phone has received a service
message.
FCC_6126H_6133H_en_1_FCC.fm Page 99 Tuesday, June 27, 2006 1:35 PM
Web
100
DRAFT
■Cache memory
A cache is a memory location that is used to store data temporarily. If you have
tried to access or have accessed confidential information requiring passwords,
empty the cache after each use. The information or services you have accessed is
stored in the cache.
To empty the cache while browsing, select Options > Other options >
Clear the cache; in the standby mode, select Menu > Web > Clear the
cache.
■Browser security
Security features may be required for some services, such as online
banking or shopping. For such connections you need security
certificates and possibly a security module, which may be available on
your SIM card. For more information, contact your service provider.
Security module
The security module improves security services for applications
requiring a browser connection, and allows you to use a digital
signature. The security module may contain certificates as well as
private and public keys. The certificates are saved in the security module
by the service provider.
To view or change the security module settings, select Menu >
Settings > Security > Security module settings.
Certificates
Important: Even if the use of certificates makes the risks involved in
remote connections and software installation considerably smaller,
they must be used correctly in order to benefit from increased security.
The existence of a certificate does not offer any protection by itself; the
certificate manager must contain correct, authentic, or trusted certificates for
increased security to be available. Certificates have a restricted lifetime. If
Expired certificate or Certificate not valid yet is shown even if the certificate
should be valid, check that the current date and time in your device are correct.
Before changing any certificate settings, you must make sure that you really trust
FCC_6126H_6133H_en_1_FCC.fm Page 100 Tuesday, June 27, 2006 1:35 PM
Web
101
DRAFT
the owner of the certificate and that the certificate really belongs to the listed
owner.
There are three kinds of certificates: server certificates, authority
certificates, and user certificates. You may receive these certificates
from your service provider. Authority certificates and user certificates
may also be saved in the security module by the service provider.
To view the list of the authority or user certificates downloaded into
your phone, select Menu > Settings > Security > Authority certificates
or User certificates.
is displayed during a connection, if the data transmission between
the phone and the content server is encrypted.
The security icon does not indicate that the data transmission between the
gateway and the content server (or place where the requested resource is stored)
is secure. The service provider secures the data transmission between the
gateway and the content server.
Digital signature
You can make digital signatures with your phone if your SIM card has a
security module. Using the digital signature can be the same as signing
your name to a paper bill, contract, or other document.
To make a digital signature, select a link on a page, for example, the title
of the book you want to buy and its price. The text to sign, which may
include the amount and date, is shown.
Check that the header text is Read and that the digital signature icon
is shown.
If the digital signature icon does not appear, there is a security breach,
and you should not enter any personal data such as your signing PIN.
To sign the text, read all of the text first, and select Sign.
The text may not fit within a single screen. Therefore, make sure to scroll
through and read all of the text before signing.
Select the user certificate you want to use. Enter the signing PIN (see
“Access codes,” p. 9), and select OK. The digital signature icon
disappears, and the service may display a confirmation of your purchase.
FCC_6126H_6133H_en_1_FCC.fm Page 101 Tuesday, June 27, 2006 1:35 PM
PC connectivity
102
DRAFT
18. PC connectivity
You can send and receive e-mail, and access the Internet when your
phone is connected to a compatible PC through a Bluetooth or a data
cable connection. You can use your phone with a variety of PC
connectivity and data communications applications.
■Nokia PC Suite
With Nokia PC Suite you can synchronize contacts, calendar, notes, and
to-do notes between your phone and the compatible PC or a remote
Internet server (network service). You may find more information and PC
Suite on the Nokia Web site at www.nokia.com/support.
■EGPRS, HSCSD, and CSD
With your phone you can use the enhanced GPRS (EGPRS), general
packet radio service (GPRS), high-speed circuit switched data (HSCSD),
and circuit switched data (CSD, GSM data) data services.
For availability and subscription to data services, contact your network
operator or service provider.
The use of HSCSD services consumes the phone battery faster than
normal voice or data calls. You may need to connect the phone to a
charger for the duration of data transfer.
See “Modem settings,” p. 61.
■Data communication applications
For information on using a data communication application, refer to the
documentation provided with it.
Making or answering phone calls during a computer connection is not
recommended, as it might disrupt the operation.
For better performance during data calls, place the phone on a
stationary surface with the keypad facing downward. Do not move the
phone by holding it in your hand during a data call.
FCC_6126H_6133H_en_1_FCC.fm Page 102 Tuesday, June 27, 2006 1:35 PM
Battery information
103
DRAFT
19. Battery information
■Charging and discharging
Your device is powered by a rechargeable battery. The full performance of a new
battery is achieved only after two or three complete charge and discharge cycles.
The battery can be charged and discharged hundreds of times, but it will
eventually wear out. When the talk and standby times are noticeably shorter
than normal, replace the battery. Use only Nokia approved batteries, and
recharge your battery only with Nokia approved chargers designated for this
device.
If a replacement battery is being used for the first time or if the battery has not
been used for a prolonged period, it may be necessary to connect the charger and
then disconnect and reconnect it to start the charging.
Unplug the charger from the electrical plug and the device when not in use. Do
not leave fully charged battery connected to a charger, since overcharging may
shorten its lifetime. If left unused, a fully charged battery will lose its charge over
time.
If the battery is completely discharged, it may take a few minutes before the
charging indicator appears on the display or before any calls can be made.
Use the battery only for its intended purpose. Never use any charger or battery
that is damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a
metallic object such as a coin, clip, or pen causes direct connection of the
positive (+) and negative (-) terminals of the battery. (These look like metal strips
on the battery.) This might happen, for example, when you carry a spare battery
in your pocket or purse. Short-circuiting the terminals may damage the battery
or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer or
winter conditions, will reduce the capacity and lifetime of the battery. Always try
to keep the battery between 15°C and 25°C (59°F and 77°F). A device with a hot
or cold battery may not work temporarily, even when the battery is fully charged.
Battery performance is particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also
explode if damaged. Dispose of batteries according to local regulations. Please
recycle when possible. Do not dispose as household waste.
FCC_6126H_6133H_en_1_FCC.fm Page 103 Tuesday, June 27, 2006 1:35 PM
Battery information
104
DRAFT
■Nokia battery authentication
Always use original Nokia batteries for your safety. To check that you are getting
an original Nokia battery, purchase it from an authorized Nokia dealer, look for
the Nokia Original Enhancements logo on the packaging, and inspect the
hologram label using the following steps:
Successful completion of the four steps is not a total assurance of the
authenticity of the battery. If you have any reason to believe that your battery is
not an authentic original Nokia battery, you should refrain from using it, and take
it to the nearest authorized Nokia service point or dealer for assistance. Your
authorized Nokia service point or dealer will inspect the battery for authenticity.
If authenticity cannot be verified, return the battery to the place of purchase.
Authenticate hologram
1. When looking at the hologram on the label, you
should see the Nokia connecting hands symbol from
one angle and the Nokia Original Enhancements
logo when looking from another angle.
2. When you angle the hologram left, right, down, and
up, you should see 1, 2, 3, and 4 dots on each side
respectively.
3. Scratch the side of the label to reveal a 20-digit
code, for example, 12345678919876543210. Turn
the battery so that the numbers are facing upwards.
The 20-digit code reads starting from the number at
the top row followed by the bottom row.
FCC_6126H_6133H_en_1_FCC.fm Page 104 Tuesday, June 27, 2006 1:35 PM
Battery information
105
DRAFT
4. Confirm that the 20-digit code is valid by following
the instructions at www.nokia.com/batterycheck.
To create a text message enter the 20-digit code, for example,
12345678919876543210, and send to +44 7786 200276.
To create a text message,
• For countries in Asia Pacific, excluding India: Enter the 20-digit code, for
example, 12345678919876543210, and send to +61 427151515.
• For India only: Enter Battery followed by the 20-digit battery code, for
example, Battery 12345678919876543210, and send to 5555.
National and international operator charges will apply.
You should receive a message indicating whether the code can be authenticated.
What if your battery is not authentic?
If you cannot confirm that your Nokia battery with the hologram on the label is
an authentic Nokia battery, please do not use the battery. Take it to the nearest
authorized Nokia service point or dealer for assistance. The use of a battery that
is not approved by the manufacturer may be dangerous and may result in poor
performance and damage to your device and its enhancements. It may also
invalidate any approval or warranty applying to the device.
To find out more about original Nokia batteries, visit www.nokia.com/battery.
FCC_6126H_6133H_en_1_FCC.fm Page 105 Tuesday, June 27, 2006 1:35 PM
Technical Information
106
DRAFT
20. Technical Information
Weight 110 grams (3.1 ounces) incl. BL-4C battery
Battery 820 mAh Li-Ion Battery
Networks Wireless networks GSM 850, 900,
1800 and 1900
Size Volume: 4.45 cubic inches (75 ccm)
Length: 3.6 in (92 mm)
Width: 1.9 in (48 mm)
Thickness: 0.8 in (20 mm)
Frequency range (Rx) GSM 850: 869 - 894 MHz
GSM 900: 925 - 960 MHz
GSM 1800: 1805 - 1880 MHz
GSM 1900: 1930 - 1990 MHz
Frequency range (Tx) GSM 850: 824 - 849 MHz
GSM 900: 880 - 915 MHz
GSM 1800: 1710 - 1785 MHz
GSM 1900: 1850 - 1910 MHz
Tx output power 2 W (max)
Battery voltage 3.7 V DC
Number of channels GSM 850: 124
GSM 900: 174
GSM 1800: 374
GSM1900: 299
Phone memory size 32 MB flash memory
16 MB RAM
Operating temperature 59 °F to 77 °F
(15 °C to 25 °C)
FCC_6126H_6133H_en_1_FCC.fm Page 106 Tuesday, June 27, 2006 1:35 PM
Care and maintenance
107
DRAFT
Care and maintenance
Your device is a product of superior design and craftsmanship and should be
treated with care. The suggestions below will help you protect your warranty
coverage.
• Keep the device dry. Precipitation, humidity and all types of liquids or
moisture can contain minerals that will corrode electronic circuits. If your
device does get wet, remove the battery and allow the device to dry
completely before replacing it.
• Do not use or store the device in dusty, dirty areas. Its moving parts and
electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic
circuit boards.
• Do not attempt to open the device other than as instructed in this guide.
• Do not drop, knock, or shake the device. Rough handling can break internal
circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean
the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper
operation.
• Do not touch the main display with hard or angular materials. Objects like
earrings or jewellery may scratch the display.
• Use a soft, clean, dry cloth to clean any lenses (such as camera, proximity
sensor, and light sensor lenses).
• Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the device and may
violate regulations governing radio devices.
• Use chargers indoors.
• Always create a backup of data you want to keep (such as contacts and
calendar notes) before sending your device to a service facility.
All of the above suggestions apply equally to your device, battery, charger, or any
enhancement. If any device is not working properly, take it to the nearest
authorized service facility for service.
FCC_6126H_6133H_en_1_FCC.fm Page 107 Tuesday, June 27, 2006 1:35 PM
Additional safety information
108
DRAFT
Additional safety information
Your device and its enhancements may contain small parts. Keep them out of the
reach of small children.
■Operating environment
Remember to follow any special regulations in force in any area, and always
switch off your device when its use is prohibited or when it may cause
interference or danger. Use the device only in its normal operating positions. This
device meets RF exposure guidelines when used either in the normal use position
against the ear or when positioned at least 2.2 centimeters (7/8 inch) away from
the body. When a carry case, belt clip or holder is used for body-worn operation,
it should not contain metal and should position the device the above-stated
distance from your body.
To transmit data files or messages, this device requires a quality connection to
the network. In some cases, transmission of data files or messages may be
delayed until such a connection is available. Ensure that the above separation
distance instructions are followed until the transmission is completed.
Parts of the device are magnetic. Metallic materials may be attracted to the
device. Do not place credit cards or other magnetic storage media near the
device, because information stored on them may be erased.
■Medical devices
Operation of any radio transmitting equipment, including wireless phones, may
interfere with the functionality of inadequately protected medical devices.
Consult a physician or the manufacturer of the medical device to determine if
they are adequately shielded from external RF energy or if you have any
questions. Switch off your device in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or health care facilities may
be using equipment that could be sensitive to external RF energy.
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of
15.3 centimeters (6 inches) be maintained between a wireless phone and a
pacemaker to avoid potential interference with the pacemaker. These
recommendations are consistent with the independent research by and
recommendations of Wireless Technology Research. Persons with pacemakers
should do the following:
FCC_6126H_6133H_en_1_FCC.fm Page 108 Tuesday, June 27, 2006 1:35 PM
Additional safety information
109
DRAFT
• Always keep the device more than 15.3 centimeters (6 inches) from the
pacemaker
• Not carry the device in a breast pocket
• Hold the device to the ear opposite the pacemaker to minimize the potential
for interference.
If you suspect interference, switch off your device, and move the device away.
Hearing aids
Some digital wireless devices may interfere with some hearing aids. If
interference occurs, consult your service provider.
■Vehicles
RF signals may affect improperly installed or inadequately shielded electronic
systems in motor vehicles such as electronic fuel injection systems, electronic
antiskid (antilock) braking systems, electronic speed control systems, and air bag
systems. For more information, check with the manufacturer or its representative
of your vehicle or any equipment that has been added.
Only qualified personnel should service the device, or install the device in a
vehicle. Faulty installation or service may be dangerous and may invalidate any
warranty that may apply to the device. Check regularly that all wireless device
equipment in your vehicle is mounted and operating properly. Do not store or
carry flammable liquids, gases, or explosive materials in the same compartment
as the device, its parts, or enhancements. For vehicles equipped with an air bag,
remember that air bags inflate with great force. Do not place objects, including
installed or portable wireless equipment in the area over the air bag or in the air
bag deployment area. If in-vehicle wireless equipment is improperly installed and
the air bag inflates, serious injury could result.
Using your device while flying in aircraft is prohibited. Switch off your device
before boarding an aircraft. The use of wireless teledevices in an aircraft may be
dangerous to the operation of the aircraft, disrupt the wireless telephone
network, and may be illegal.
■Potentially explosive environments
Switch off your device when in any area with a potentially explosive atmosphere
and obey all signs and instructions. Potentially explosive atmospheres include
areas where you would normally be advised to turn off your vehicle engine.
Sparks in such areas could cause an explosion or fire resulting in bodily injury or
even death. Switch off the device at refueling points such as near gas pumps at
service stations. Observe restrictions on the use of radio equipment in fuel
FCC_6126H_6133H_en_1_FCC.fm Page 109 Tuesday, June 27, 2006 1:35 PM
Additional safety information
110
DRAFT
depots, storage, and distribution areas; chemical plants; or where blasting
operations are in progress. Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include below deck on boats, chemical
transfer or storage facilities, vehicles using liquefied petroleum gas (such as
propane or butane), and areas where the air contains chemicals or particles such
as grain, dust, or metal powders.
■Emergency calls
Important: Wireless phones, including this device, operate using radio
signals, wireless networks, landline networks, and user-programmed
functions. Because of this, connections in all conditions cannot be
guaranteed. You should never rely solely on any wireless device for
essential communications like medical emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for adequate signal strength.
Some networks may require that a valid SIM card is properly inserted in the
device.
2. Press the end key as many times as needed to clear the display and ready the
device for calls.
3. Enter the official emergency number for your present location. Emergency
numbers vary by location.
4. Press the call key.
If certain features are in use, you may first need to turn those features off before
you can make an emergency call. Consult this guide or your service provider for
more information.
When making an emergency call, give all the necessary information as accurately
as possible. Your wireless device may be the only means of communication at the
scene of an accident. Do not end the call until given permission to do so.
■Hearing Aid Compatibility
Your mobile device model complies with FCC rules governing hearing aid
compatibility with hearing aids operating in microphone mode. These rules
require phone models to fulfil the telephone near field category M3 or higher
category. The M-value, shown on the device box, refers to lower radio frequency
(RF) emissions. A higher M-value generally indicates that a device model has a
lower RF emissions level, which may improve the likelihood that the device will
operate with certain hearing aids. Some hearing aids are more immune than
FCC_6126H_6133H_en_1_FCC.fm Page 110 Tuesday, June 27, 2006 1:35 PM
Additional safety information
111
DRAFT
others are to interference. Please consult your hearing health professional to
determine the M rating of your hearing aid and whether your hearing aid will
work with this device.
GSM networks in the United States utilize 850 and 1900 MHz bands. Your phone
operates on both bands, and is enhanced with a "hearing aid mode" to activate if
needed. There is no benefit to using the hearing aid mode if you do not wear
hearing aids.
The type of hearing aid and how far the phone is from a network base station
both contribute to whether the hearing aid mode is beneficial. Hearing aid users
should experiment with use of the hearing aid mode to determine whether it
affects the operation of their hearing aids while using the mobile phone.
■Certification information (SAR)
THIS MODEL PHONE MEETS GUIDELINES FOR EXPOSURE TO RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It is designed and
manufactured not to exceed the limits for exposure to radio frequency (RF)
energy recommended by international guidelines (ICNIRP). These limits establish
permitted levels of RF energy for the general population. The guidelines are based
on standards that were developed by independent scientific organizations
through periodic and thorough evaluation of scientific studies. The standards and
guidelines include a substantial safety margin designed to assure the safety of
the public, regardless of age and health and to account for any variations in
measurements.
The exposure guidelines for mobile devices employ a unit of measurement known
as the Specific Absorption Rate or SAR. The SAR limit stated in the international
guidelines is 2.0 watts/kilogram (W/kg) averaged over 10 grams of tissue. Tests
for SAR are conducted using standard operating positions with the device
transmitting at its highest certified power level in all tested frequency bands. The
actual SAR level of an operating device can be well below the maximum value
because the device is designed to use only the power required to reach the
network. That amount changes depending on a number of factors such as how
close you are to a network base station. The highest SAR value when tested
according to international testing procedures for use at the ear is 0.70 W/kg.
SAR values may vary depending on national reporting and testing requirements
and the network band. Use of device accessories and enhancements may result in
different SAR values. Additional SAR information may be provided under product
information at www.nokia.com.
USA and Canada: The SAR limit of USA (FCC) and Canada (IC) is 1.6 W/kg
averaged over 1 gram of tissue. This device model has also been tested against
FCC_6126H_6133H_en_1_FCC.fm Page 111 Tuesday, June 27, 2006 1:35 PM
Additional safety information
112
DRAFT
this SAR limit. The highest SAR value reported under this standard during product
certification for use at the ear is 0.89 W/kg and when properly worn on the body
is 0.84 W/kg. Information about this device can be found on the FCC's website at
http://www.fcc.gov/oet/fccid by searching the equipment authorization system
using FCC ID: PPIRM-126H.
FCC_6126H_6133H_en_1_FCC.fm Page 112 Tuesday, June 27, 2006 1:35 PM
APPENDIX
113
DRAFT
APPENDIX
■A message from the CTIA
© 2001 Cellular Telecommunications & Internet Association. All Rights
Reserved. 1250 Connecticut Avenue, NW Suite 800, Washington, DC
20036. Phone: (202) 785-0081
Safety is the most important call you will ever make.
A Guide to Safe and Responsible Wireless Phone Use
Tens of millions of people in the U.S. today take advantage of the unique
combination of convenience, safety and value delivered by the wireless
telephone. Quite simply, the wireless phone gives people the powerful
ability to communicate by voice--almost anywhere, anytime--with the
boss, with a client, with the kids, with emergency personnel or even with
the police. Each year, Americans make billions of calls from their
wireless phones, and the numbers are rapidly growing.
But an important responsibility accompanies those benefits, one that
every wireless phone user must uphold. When driving a car, driving is
your first responsibility. A wireless phone can be an invaluable tool, but
good judgment must be exercised at all times while driving a motor
vehicle--whether on the phone or not.
The basic lessons are ones we all learned as teenagers. Driving requires
alertness, caution and courtesy. It requires a heavy dose of basic
common sense---keep your head up, keep your eyes on the road, check
your mirrors frequently and watch out for other drivers. It requires
obeying all traffic signs and signals and staying within the speed limit. It
means using seatbelts and requiring other passengers to do the same.
But with wireless phone use, driving safely means a little more. This
brochure is a call to wireless phone users everywhere to make safety
their first priority when behind the wheel of a car. Wireless
telecommunications is keeping us in touch, simplifying our lives,
protecting us in emergencies and providing opportunities to help others
in need.
FCC_6126H_6133H_en_1_FCC.fm Page 113 Tuesday, June 27, 2006 1:35 PM
APPENDIX
114
DRAFT
When it comes to the use of wireless phones, safety is your most
important call.
Wireless phone "Safety Tips"
1. Get to know your wireless phone and its features such as speed dial
and redial. Carefully read your instruction manual and learn to take
advantage of valuable features most phones offer, including
automatic redial and memory. Also, work to memorize the phone
keypad so you can use the speed dial function without taking your
attention off the road.
2. When available, use a hands free device. A number of hands free
wireless phone accessories are readily available today. Whether you
choose an installed mounted device for your wireless phone or a
speaker phone accessory, take advantage of these devices if available
to you.
3. Position your wireless phone within easy reach. Make sure you place
your wireless phone within easy reach and where you can grab it
without removing your eyes from the road. If you get an incoming
call at an inconvenient time, if possible, let your voice mail answer it
for you.
4. .Suspend conversations during hazardous driving conditions or
situations. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic or hazardous
weather conditions. Rain, sleet, snow and ice can be hazardous, but
so is heavy traffic. As a driver, your first responsibility is to pay
attention to the road.
5. Do not take notes or look up phone numbers while driving. If you are
reading an address book or business card, or writing a “to do” list
while driving a car, you are not watching where you are going. It’s
common sense. Don’t get caught in a dangerous situation because
you are reading or writing and not paying attention to the road or
nearby vehicles.
6. Dial sensibly and assess the traffic; if possible, place calls when you
are not moving or before pulling into traffic. Try to plan your calls
before you begin your trip or attempt to coincide your calls with
FCC_6126H_6133H_en_1_FCC.fm Page 114 Tuesday, June 27, 2006 1:35 PM
APPENDIX
115
DRAFT
times you may be stopped at a stop sign, red light or otherwise
stationary. But if you need to dial while driving, follow this simple
tip--dial only a few numbers, check the road and your mirrors, then
continue.
7. Do not engage in stressful or emotional conversations that may be
distracting. Stressful or emotional conversations and driving do not
mix--they are distracting and even dangerous when you are behind
the wheel of a car. Make people you are talking with aware you are
driving and if necessary, suspend conversations which have the
potential to divert your attention from the road.
8. Use your wireless phone to help others in emergencies. Your wireless
phone provides you a perfect opportunity to be a “Good Samaritan”
in your community. If you see an auto accident, crime in progress or
other serious emergency where lives are in danger, call 9-1-1 or
other local emergency number, as you would want others to do for
you.
9. Use your wireless phone to call for help. Your wireless phone is one of
the greatest tools you can own to protect yourself and your family in
dangerous situations--with your phone at your side, help is only
three numbers away. Dial 9-1-1 or other local emergency number in
the case of fire, traffic accident, road hazard or medical emergency.
Remember, it is a free call on your wireless phone!
10.Use your wireless phone to help others in emergencies. Your wireless
phone provides you a perfect opportunity to be a “Good Samaritan”
in your community. If you see an auto accident, crime in progress or
other serious emergency where lives are in danger, call 9-1-1 or
other local emergency number, as you would want others to do for
you.
11.Call roadside assistance or a special wireless non-emergency
assistance number when necessary. Certain situations you encounter
while driving may require attention, but are not urgent enough to
merit a call for emergency services. But you still can use your
wireless phone to lend a hand. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a minor traffic
accident where no one appears injured or a vehicle you know to be
FCC_6126H_6133H_en_1_FCC.fm Page 115 Tuesday, June 27, 2006 1:35 PM
APPENDIX
116
DRAFT
stolen, call roadside assistance or other special non-emergency
wireless number.
Careless, distracted individuals and people driving irresponsibly
represent a hazard to everyone on the road. Since 1984, the Cellular
Telecommunications Industry Association and the wireless industry
have conducted educational outreach to inform wireless phone users of
their responsibilities as safe drivers and good citizens. As we approach a
new century, more and more of us will take advantage of the benefits of
wireless telephones. And, as we take to the roads, we all have a
responsibility to drive safely.
The wireless industry reminds you to use your phone safely when
driving.
For more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/issues/driving/
articles.cfm?ID=85
■Message from the FDA
The U.S. Food and Drug Administration (FDA) provides the following
consumer information about wireless phones.
See http://www.fda.gov/cellphones/ for updated information.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health
problems are associated with using wireless phones. There is no proof,
however, that wireless phones are absolutely safe. Wireless phones emit
low levels of radiofrequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in the stand-by
mode. Whereas high levels of RF can produce health effects (by heating
tissue), exposure to low level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low level RF
exposures have not found any biological effects. Some studies have
suggested that some biological effects may occur, but such findings
have not been confirmed by additional research. In some cases, other
researchers have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
FCC_6126H_6133H_en_1_FCC.fm Page 116 Tuesday, June 27, 2006 1:35 PM
APPENDIX
117
DRAFT
What is FDA's role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting
consumer products such as wireless phones before they can be sold, as it
does with new drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown to emit
radiofrequency energy (RF) at a level that is hazardous to the user. In
such a case, FDA could require the manufacturers of wireless phones to
notify users of the health hazard and to repair, replace or recall the
phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory
actions, FDA has urged the wireless phone industry to take a number of
steps, including the following:
• Support needed research into possible biological effects of RF of the
type emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF exposure to
the user that is not necessary for device function; and
• Cooperate in providing users of wireless phones with the best
possible information on possible effects of wireless phone use on
human health.
FDA belongs to an interagency working group of the federal agencies
that have responsibility for different aspects of RF safety to ensure
coordinated efforts at the federal level. The following agencies belong
to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency
working group activities, as well.
FDA shares regulatory responsibilities for wireless phones with the
Federal Communications Commission (FCC). All phones that are sold in
the United States must comply with FCC safety guidelines that limit RF
FCC_6126H_6133H_en_1_FCC.fm Page 117 Tuesday, June 27, 2006 1:35 PM
APPENDIX
118
DRAFT
exposure. FCC relies on FDA and other health agencies for safety
questions about wireless phones.
FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than do
the wireless phones themselves, the RF exposures that people get from
these base stations are typically thousands of times lower than those
they can get from wireless phones. Base stations are thus not the
primary subject of the safety questions discussed in this document.
What is FDA doing to find out more about the possible health effects
of wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with
groups of investigators around the world to ensure that high priority
animal studies are conducted to address important questions about the
effects of exposure to radiofrequency energy (RF). FDA has been a
leading participant in the World Health Organization International
Electromagnetic Fields (EMF) Project since its inception in 1996. An
influential result of this work has been the development of a detailed
agenda of research needs that has driven the establishment of new
research programs around the world. The Project has also helped
develop a series of public information documents on EMF issues. FDA
and the Cellular Telecommunications & Internet Association (CTIA) have
a formal Cooperative Research and Development Agreement (CRADA) to
do research on wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government, industry, and
academic organizations. CTIA-funded research is conducted through
contracts to independent investigators. The initial research will include
both laboratory studies and studies of wireless phone users. The CRADA
will also include a broad assessment of additional research needs in the
context of the latest research developments around the world.
What steps can I take to reduce my exposure to radiofrequency
energy from my wireless phone?
If there is a risk from these products--and at this point we do not know
that there is--it is probably very small. But if you are concerned about
avoiding even potential risks, you can take a few simple steps to
minimize your exposure to radiofrequency energy (RF). Since time is a
FCC_6126H_6133H_en_1_FCC.fm Page 118 Tuesday, June 27, 2006 1:35 PM
APPENDIX
119
DRAFT
key factor in how much exposure a person receives, reducing the
amount of time spent using a wireless phone will reduce RF exposure.
If you must conduct extended conversations by wireless phone every
day, you could place more distance between your body and the source of
the RF, since the exposure level drops off dramatically with distance. For
example, you could use a headset and carry the wireless phone away
from your body or use a wireless phone connected to a remote antenna
Again, the scientific data do not demonstrate that wireless phones are
harmful. But if you are concerned about the RF exposure from these
products, you can use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless
phones, including children and teenagers. If you want to take steps to
lower exposure to radiofrequency energy (RF), the measures described
above would apply to children and teenagers using wireless phones.
Reducing the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF exposure. Some
groups sponsored by other national governments have advised that
children be discouraged from using wireless phones at all. For example,
the government in the United Kingdom distributed leaflets containing
such a recommendation in December 2000. They noted that no evidence
exists that using a wireless phone causes brain tumors or other ill
effects. Their recommendation to limit wireless phone use by children
was strictly precautionary; it was not based on scientific evidence that
any health hazard exists.
Do hands-free kits for wireless phones reduce risks from exposure to
RF emissions?
Since there are no known risks from exposure to RF emissions from
wireless phones, there is no reason to believe that hands-free kits
reduce risks. Hands-free kits can be used with wireless phones for
convenience and comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source of the RF
emissions, will not be placed against the head. On the other hand, if the
phone is mounted against the waist or other part of the body during use,
FCC_6126H_6133H_en_1_FCC.fm Page 119 Tuesday, June 27, 2006 1:35 PM
APPENDIX
120
DRAFT
then that part of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety requirements regardless
of whether they are used against the head or against the body. Either
configuration should result in compliance with the safety limit.
Do wireless phone accessories that claim to shield the head from RF
radiation work?
Since there are no known risks from exposure to RF emissions from
wireless phones, there is no reason to believe that accessories that claim
to shield the head from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use special phone cases,
while others involve nothing more than a metallic accessory attached to
the phone. Studies have shown that these products generally do not
work as advertised. Unlike "hand-free" kits, these so-called "shields"
may interfere with proper operation of the phone. The phone may be
forced to boost its power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade Commission (FTC)
charged two companies that sold devices that claimed to protect
wireless phone users from radiation with making false and
unsubstantiated claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
How does FCC Audit Cell Phone RF?
After FCC grants permission for a particular cellular telephone to be
marketed, FCC will occasionally conduct “post-grant” testing to
determine whether production versions of the phone are being produced
to conform with FCC regulatory requirements. The manufacturer of a
cell phone that does not meet FCC’s regulatory requirements may be
required to remove the cell phone from use and to refund the purchase
price or provide a replacement phone, and may be subject to civil or
criminal penalties. In addition, if the cell phone presents a risk of injury
to the user, FDA may also take regulatory action. The most important
post-grant test, from a consumer’s perspective, is testing of the RF
emissions of the phone. FCC measures the Specific Absorption Rate
(SAR) of the phone, following a very rigorous testing protocol. As is true
for nearly any scientific measurement, there is a possibility that the test
measurement may be less than or greater than the actual RF emitted by
FCC_6126H_6133H_en_1_FCC.fm Page 120 Tuesday, June 27, 2006 1:35 PM
APPENDIX
121
DRAFT
the phone. This difference between the RF test measurement and actual
RF emission is because test measurements are limited by instrument
accuracy, because test measurement and actual use environments are
different, and other variable factors. This inherent variability is known as
“measurement uncertainty.” When FCC conducts post-grant testing of a
cell phone, FCC takes into account any measurement uncertainty to
determine whether regulatory action is appropriate. This approach
ensures that when FCC takes regulatory action, it will have a sound,
defensible scientific basis.
FDA scientific staff reviewed the methodology used by FCC to measure
cell phone RF, and agreed it is an acceptable approach, given our current
understanding of the risks presented by cellular phone RF emissions. RF
emissions from cellular phones have not been shown to present a risk of
injury to the user when the measured SAR is less than the safety limits
set by FCC (an SAR of 1.6 w/kg). Even in a case where the maximum
measurement uncertainty permitted by current measurement standards
was added to the maximum permissible SAR, the resulting SAR value
would be well below any level known to produce an acute effect.
Consequently, FCC’s approach with measurement uncertainty will not
result in consumers being exposed to any known risk from the RF
emitted by cellular telephones.
FDA will continue to monitor studies and literature reports concerning
acute effects of cell phone RF, and concerning chronic effects of long-
term exposure to cellular telephone RF (that is, the risks from using a
cell phone for many years). If new information leads FDA to believe that
a change to FCC’s measurement policy may be appropriate, FDA will
contact FCC and both agencies will work together to develop a
mutually-acceptable approach.
Updated July 29, 2003
FCC_6126H_6133H_en_1_FCC.fm Page 121 Tuesday, June 27, 2006 1:35 PM
Index
122
DRAFT
Index
A
access codes . . . . . . . . . . . . . . . . . . . .9
accessories. See enhancements.
active standby . . . . . . . . . . . . . 17, 55
alarm clock . . . . . . . . . . . . . . . . . . . .80
antenna . . . . . . . . . . . . . . . . . . . . . .15
applications
collection . . . . . . . . . . . . . . . . . .91
download . . . . . . . . . . . . . . . . . .11
audio messages . . . . . . . . . . . . . . . .33
B
barring password . . . . . . . . . . . . . . .10
battery
authentication . . . . . . . . . . . . 104
charging . . . . . . . . . . . . . . 13, 103
discharging . . . . . . . . . . . . . . . 103
installation . . . . . . . . . . . . . . . . .12
blacklist . . . . . . . . . . . . . . . . . . . . . .36
Bluetooth . . . . . . . . . . . . . . . . . . . . .58
bookmarks . . . . . . . . . . . . . . . . . . . .97
browser
appearance settings . . . . . . . . .97
bookmarks . . . . . . . . . . . . . . . . .97
browsing pages . . . . . . . . . . . . .96
cache memory . . . . . . . . . . . . 100
certificates . . . . . . . . . . . . . . . 100
cookies . . . . . . . . . . . . . . . . . . . .98
digital signature . . . . . . . . . . . 101
security . . . . . . . . . . . . . . . . . . . .98
security module . . . . . . . . . . . 100
set up . . . . . . . . . . . . . . . . . . . . .95
business cards . . . . . . . . . . . . . . . . .51
C
cache memory . . . . . . . . . . . . . . . 100
calculator . . . . . . . . . . . . . . . . . . . . .82
calendar . . . . . . . . . . . . . . . . . . . . . .80
note . . . . . . . . . . . . . . . . . . . . . . .81
call
functions . . . . . . . . . . . . . . . . . .21
key . . . . . . . . . . . . . . . . . . . . . . . .16
log . . . . . . . . . . . . . . . . . . . . . . . .53
options . . . . . . . . . . . . . . . . . . . 23
settings . . . . . . . . . . . . . . . . . . . 64
waiting . . . . . . . . . . . . . . . . . . . 23
call log . . . . . . . . . . . . . . . . . . . . . . 53
call register. See call log.
callback request . . . . . . . . . . . . . . . 88
calls
answer . . . . . . . . . . . . . . . . . . . 22
international . . . . . . . . . . . . . . . 21
making of . . . . . . . . . . . . . . . . . 21
reject . . . . . . . . . . . . . . . . . . . . . 22
speed dialing . . . . . . . . . . . . . . 21
voice dialing . . . . . . . . . . . . . . . 21
camera
effects . . . . . . . . . . . . . . . . . . . . 74
filter . . . . . . . . . . . . . . . . . . . . . 74
key . . . . . . . . . . . . . . . . . . . . . . . 16
record a video clip . . . . . . . . . . 74
settings . . . . . . . . . . . . . . . . . . . 74
take a photo . . . . . . . . . . . . . . . 73
care . . . . . . . . . . . . . . . . . . . . . . . . 107
certificates . . . . . . . . . . . . . . . . . . 100
character case . . . . . . . . . . . . . . . . 24
charge the battery . . . . . . . . . . . . . 13
charger connector . . . . . . . . . . . . . 16
circuit switched data . . . . . . . . . . 102
clock settings . . . . . . . . . . . . . . . . . 56
codes . . . . . . . . . . . . . . . . . . . . . . 9, 10
configuration . . . . . . . . . . . . . . . . . 66
setting service . . . . . . . . . . . . . 10
settings . . . . . . . . . . . . . . . . . . . 15
contact information . . . . . . . . . . . . 11
contacts
copy . . . . . . . . . . . . . . . . . . . . . . 48
delete . . . . . . . . . . . . . . . . . . . . 48
edit . . . . . . . . . . . . . . . . . . . . . . 48
groups . . . . . . . . . . . . . . . . . . . . 52
my numbers . . . . . . . . . . . . . . . 52
my presence . . . . . . . . . . . . . . . 49
save . . . . . . . . . . . . . . . . . . . . . . 47
search . . . . . . . . . . . . . . . . . . . . 47
service numbers . . . . . . . . . . . . 52
settings . . . . . . . . . . . . . . . . . . . 51
speed dialing . . . . . . . . . . . . . . 52
subscribed names . . . . . . . . . . . 50
FCC_6126H_6133H_en_1_FCC.fm Page 122 Tuesday, June 27, 2006 1:35 PM
Index
123
DRAFT
cookies . . . . . . . . . . . . . . . . . . . . . . . 98
countdown timer . . . . . . . . . . . . . . 83
CSD. See circuit switched data.
customer service . . . . . . . . . . . . . . . 11
D
data
communication . . . . . . . . . . . . 102
transfer . . . . . . . . . . . . . . . . . . . 62
data cable . . . . . . . . . . . . . . . . . . . . 63
date settings . . . . . . . . . . . . . . . . . . 56
delete
messages . . . . . . . . . . . . . . . . . . 43
digital signature . . . . . . . . . . . . . . 101
display . . . . . . . . . . . . . . . . . . . . 16, 17
downloads
applications . . . . . . . . . . . . . . . . 11
content . . . . . . . . . . . . . . . . . . . 11
settings . . . . . . . . . . . . . . . . . . . 99
E
earpiece . . . . . . . . . . . . . . . . . . . . . . 16
EGPRS . . . . . . . . . . . . . . . . . . . . . . . 61
EGPRS. See packet data.
e-mail application . . . . . . . . . . . . . 34
setting wizard . . . . . . . . . . . . . . 34
emergency calls . . . . . . . . . . . . . . 110
end
call . . . . . . . . . . . . . . . . . . . . . . . 21
key . . . . . . . . . . . . . . . . . . . . . . . 16
enhancements . . . . . . . . . . . . . . . 8, 66
equalizer . . . . . . . . . . . . . . . . . . . . . 78
explosive environments . . . . . . . . 109
F
factory settings . . . . . . . . . . . . . . . . 70
flash messages . . . . . . . . . . . . . . . . 33
FM radio . . . . . . . . . . . . . . . . . . . . . 76
G
gallery . . . . . . . . . . . . . . . . . . . . . . . 71
games . . . . . . . . . . . . . . . . . . . . . . . 91
GPRS . . . . . . . . . . . . . . . . . . . . . . . . 61
H
handsfree. See loudspeaker.
hearing aid . . . . . . . . . . . . . . . .66, 109
high-speed circuit switched data 102
HSCSD. See high-speed circuit
switched data.
I
IM. See instant messaging.
IMAP4 . . . . . . . . . . . . . . . . . . . . . . . 34
indicators . . . . . . . . . . . . . . . . . . . . . 18
info messages . . . . . . . . . . . . . . . . . 42
infrared connection . . . . . . . . . . . . 60
installation
battery . . . . . . . . . . . . . . . . . . . . 12
SIM card . . . . . . . . . . . . . . . . . . 12
instant messaging . . . . . . . . . . . . . . 37
Internet
IR . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
J
junk folder . . . . . . . . . . . . . . . . . . . . 36
K
keyguard . . . . . . . . . . . . . . . . . . . . . 20
keypad . . . . . . . . . . . . . . . . . . . . . . . 16
keypad lock . . . . . . . . . . . . . . . . . . . 20
keys
call key . . . . . . . . . . . . . . . . . . . . 16
end key . . . . . . . . . . . . . . . . . . . . 16
keyguard . . . . . . . . . . . . . . . . . . 20
keypad . . . . . . . . . . . . . . . . . . . . 16
keypad lock . . . . . . . . . . . . . . . . 20
navigation key . . . . . . . . . . . . . . 16
power on/off . . . . . . . . . . . . . . . 16
selection keys . . . . . . . . . . .16, 17
L
language settings . . . . . . . . . . . . . . 65
lights . . . . . . . . . . . . . . . . . . . . . . . . 66
location information . . . . . . . . . . . . 53
log . . . . . . . . . . . . . . . . . . . . . . . . . . 53
loudspeaker . . . . . . . . . . . . . . . .16, 23
M
main display . . . . . . . . . . . 16, 17, 55
maintenance . . . . . . . . . . . . . . . . . 107
media player . . . . . . . . . . . . . . . . . . 74
FCC_6126H_6133H_en_1_FCC.fm Page 123 Tuesday, June 27, 2006 1:35 PM
Index
124
DRAFT
medical devices . . . . . . . . . . . . . . 108
memory card . . . . . . . . . . . . . . . . . .71
formatting . . . . . . . . . . . . . . . . .72
locking . . . . . . . . . . . . . . . . . . . .72
memory consumption . . . . . . . .72
memory full . . . . . . . . . . . . . . . . . . .31
menu . . . . . . . . . . . . . . . . . . . . . . . . .26
message
folder . . . . . . . . . . . . . . . . . . . . .31
message center number . . . . . . . . .27
message settings
e-mail . . . . . . . . . . . . . . . . . . . . .45
general settings . . . . . . . . . . . . .43
multimedia messages . . . . . . . .44
text messages . . . . . . . . . . . . . .43
messages
audio message . . . . . . . . . . . . . .33
cancel sending . . . . . . . . . . . . . .30
delete . . . . . . . . . . . . . . . . . . . . .43
flash message . . . . . . . . . . . . . . .33
info messages . . . . . . . . . . . . . .42
length indicator . . . . . . . . . . . . .27
message settings . . . . . . . . . . . .43
postcards . . . . . . . . . . . . . . . . . .32
sending . . . . . . . . . . . . . . . . . . . .30
service commands . . . . . . . . . . .42
text . . . . . . . . . . . . . . . . . . . . . . .27
voice message . . . . . . . . . . . . . .42
write text message . . . . . . . . . .27
microphone . . . . . . . . . . . . . . . . . . .16
mini display . . . . . . . . . . . . . . . . . . .56
MMS. See multimedia messages.
multimedia messages
create . . . . . . . . . . . . . . . . . . . . .29
read . . . . . . . . . . . . . . . . . . . . . . .30
reply . . . . . . . . . . . . . . . . . . . . . .30
send . . . . . . . . . . . . . . . . . . . . . .29
write . . . . . . . . . . . . . . . . . . . . . .29
music player . . . . . . . . . . . . . . . . . . .75
N
navigation . . . . . . . . . . . . . . . . . . . .26
navigation key . . . . . . . . . . . . . 16, 58
network
name on display . . . . . . . . . . . . .17
services . . . . . . . . . . . . . . . . . . . . .7
Nokia contact information . . . . . . .11
notes . . . . . . . . . . . . . . . . . . . . . . . . .82
calendar . . . . . . . . . . . . . . . . . . .81
numbers . . . . . . . . . . . . . . . . . . . . . 52
O
offline mode . . . . . . . . . . . . . . . . . . 20
one-to-one contact . . . . . . . . . . . . 89
operator menu . . . . . . . . . . . . . . . . 70
organizer . . . . . . . . . . . . . . . . . . . . . 80
overview functions . . . . . . . . . . . . . . 9
P
pacemakers . . . . . . . . . . . . . . . . . . 108
packet data . . . . . . . . . . . . . . . 61, 102
parts . . . . . . . . . . . . . . . . . . . . . . . . 16
PC connectivity . . . . . . . . . . . . . . 102
PC Suite . . . . . . . . . . . . . . . . . . . . 102
phone
care . . . . . . . . . . . . . . . . . . . . . 107
configuration . . . . . . . . . . . . . . 66
keys . . . . . . . . . . . . . . . . . . . . . . 16
maintenance . . . . . . . . . . . . . . 107
open . . . . . . . . . . . . . . . . . . . . . 14
parts . . . . . . . . . . . . . . . . . . . . . 16
settings . . . . . . . . . . . . . . . . . . . 65
updates . . . . . . . . . . . . . . . . 65, 69
phone lock. See keypad lock.
photo . . . . . . . . . . . . . . . . . . . . . . . . 73
PictBridge . . . . . . . . . . . . . . . . . . . . 63
PIN codes . . . . . . . . . . . . . . . . . 10, 14
plug and play service . . . . . . . . . . . 15
POP3 . . . . . . . . . . . . . . . . . . . . . . . . 34
Pop-Port connector . . . . . . . . . . . . 16
positioning . . . . . . . . . . . . . . . . . . . 53
postcards . . . . . . . . . . . . . . . . . . . . . 32
power
key . . . . . . . . . . . . . . . . . . . . . . . 16
predictive text input . . . . . . . . . . . 24
presence . . . . . . . . . . . . . . . . . . . . . 49
presenter . . . . . . . . . . . . . . . . . . . . . 92
print images . . . . . . . . . . . . . . . . . . 71
profiles . . . . . . . . . . . . . . . . . . . . . . 54
PTT . . . . . . . . . . . . . . . . . . . . . . . . . . 84
add channel . . . . . . . . . . . . . . . 85
call to multiple recipients . . . . 87
callback request . . . . . . . . . . . . 88
channel . . . . . . . . . . . . . . . . . . . 84
channel call . . . . . . . . . . . . . . . 86
configuration settings . . . . . . . 90
invitation . . . . . . . . . . . . . . . . . 85
FCC_6126H_6133H_en_1_FCC.fm Page 124 Tuesday, June 27, 2006 1:35 PM
Index
125
DRAFT
login status . . . . . . . . . . . . . . . . 86
make call . . . . . . . . . . . . . . . . . . 86
one-to-one call . . . . . . . . . . . . . 87
one-to-one contact . . . . . . . . . 89
receive call . . . . . . . . . . . . . 86, 87
settings . . . . . . . . . . . . . . . . . . . 89
switch on/off . . . . . . . . . . . . . . . 86
PUK codes . . . . . . . . . . . . . . . . . . . . 10
Push to talk
see PTT
pushed messages . . . . . . . . . . . . . . 99
R
radio . . . . . . . . . . . . . . . . . . . . . . . . . 76
record sound . . . . . . . . . . . . . . . . . . 78
recorder . . . . . . . . . . . . . . . . . . . . . . 78
repair service . . . . . . . . . . . . . . . . . . 11
ringing tones . . . . . . . . . . . . . . . . . . 54
S
safety
additional information . . . . . . 108
emergency calls . . . . . . . . . . . 110
explosive environments . . . . . 109
guidelines . . . . . . . . . . . . . . . . . . 6
hearing aid . . . . . . . . . . . . . . . 109
medical devices . . . . . . . . . . . . 108
operating environment . . . . . . 108
pacemakers . . . . . . . . . . . . . . . 108
vehicles . . . . . . . . . . . . . . . . . . 109
screen saver . . . . . . . . . . . . . . . . . . . 55
scroll key. See navigation key.
scrolling . . . . . . . . . . . . . . . . . . . . . . 26
security
codes . . . . . . . . . . . . . . . . . . . . . . 9
module . . . . . . . . . . . . . . . . . . . 100
settings . . . . . . . . . . . . . . . . . . . 67
selection keys . . . . . . . . . . . . . . 16, 17
service
commands . . . . . . . . . . . . . . . . . 42
inbox . . . . . . . . . . . . . . . . . . . . . 99
messages . . . . . . . . . . . . . . . . . . 99
numbers . . . . . . . . . . . . . . . . . . . 52
services
settings
active standby . . . . . . . . . . . . . . 55
call . . . . . . . . . . . . . . . . . . . . . . . 64
camera . . . . . . . . . . . . . . . . . . . . 74
clock . . . . . . . . . . . . . . . . . . . . . . 56
configuration . . . . . . . . . . . . . . . 66
connectivity . . . . . . . . . . . . . . . . 58
data transfer . . . . . . . . . . . . . . . 62
date . . . . . . . . . . . . . . . . . . . . . . 56
downloads . . . . . . . . . . . . . . . . . 99
enhancements . . . . . . . . . . . . . . 66
fold animation . . . . . . . . . . . . . . 55
GPRS, EGPRS . . . . . . . . . . . . . . . 61
infrared . . . . . . . . . . . . . . . . . . . 60
IR . . . . . . . . . . . . . . . . . . . . . . . . 60
main display . . . . . . . . . . . . . . . 55
messages . . . . . . . . . . . . . . . . . . 43
mini display . . . . . . . . . . . . . . . . 56
my shortcuts . . . . . . . . . . . . . . . 57
phone . . . . . . . . . . . . . . . . . . . . . 65
profiles . . . . . . . . . . . . . . . . . . . . 54
PTT . . . . . . . . . . . . . . . . . . . . . . . 89
PTT configuration . . . . . . . . . . . 90
restore factory settings . . . . . . 70
screen saver . . . . . . . . . . . . . . . . 55
security . . . . . . . . . . . . . . . . . . . 67
service inbox . . . . . . . . . . . . . . . 99
standby mode . . . . . . . . . . . . . . 55
themes . . . . . . . . . . . . . . . . . . . . 54
time . . . . . . . . . . . . . . . . . . . . . . 56
tones . . . . . . . . . . . . . . . . . . . . . 54
USB data cable . . . . . . . . . . . . . 63
wallpaper . . . . . . . . . . . . . . . . . . 55
shared memory . . . . . . . . . . . . . . . . . 8
shortcuts . . . . . . . . . . . . . . . . . .18, 57
signal strength . . . . . . . . . . . . . . . . 17
SIM
card . . . . . . . . . . . . . . . . . . . . . . 20
card installation . . . . . . . . . . . . 12
messages . . . . . . . . . . . . . . . . . . 28
services . . . . . . . . . . . . . . . . . . . 94
size . . . . . . . . . . . . . . . . . . . . . . . . . 106
SMS. See text messages
software updates . . . . . . . . . . .65, 69
spam filter . . . . . . . . . . . . . . . . . . . . 36
speed dialing . . . . . . . . . . . . . . .21, 52
standby mode . . . . . . . . . . . . . .17, 57
status indicators . . . . . . . . . . . . . . . 17
stereo widening . . . . . . . . . . . . . . . . 79
stopwatch . . . . . . . . . . . . . . . . . . . . 83
strap . . . . . . . . . . . . . . . . . . . . . . . . . 15
streaming service . . . . . . . . . . . . . . 74
subscribed names . . . . . . . . . . . . . . 50
support . . . . . . . . . . . . . . . . . . . . . . . 11
FCC_6126H_6133H_en_1_FCC.fm Page 125 Tuesday, June 27, 2006 1:35 PM
Index
126
DRAFT
switch on and off . . . . . . . . . . . . . . .14
swivel . . . . . . . . . . . . . . . . . . . . . . . .55
synchronisation . . . . . . . . . . . . . . . .62
T
take a photo . . . . . . . . . . . . . . . . . . .73
technical information . . . . . . . . . 106
text
character case . . . . . . . . . . . . . .24
message . . . . . . . . . . . . . . . . . . .27
predictive text input . . . . . . . . .24
traditional text input . . . . . . . . .25
writing . . . . . . . . . . . . . . . . . . . .24
text phone . . . . . . . . . . . . . . . . . . . .66
themes . . . . . . . . . . . . . . . . . . . . . . .54
time settings . . . . . . . . . . . . . . . . . .56
to-do list . . . . . . . . . . . . . . . . . . . . . .81
tones . . . . . . . . . . . . . . . . . . . . . . . . .54
traditional text input . . . . . . . . . . . .25
U
unlock keypad . . . . . . . . . . . . . . . . .20
UPIN . . . . . . . . . . . . . . . . . . . . . . . . .14
V
vehicles . . . . . . . . . . . . . . . . . . . . . 109
video clip . . . . . . . . . . . . . . . . . . . . . 74
voice
commands . . . . . . . . . . . . . . . . 58
dialing . . . . . . . . . . . . . . . . . . . . 21
messages . . . . . . . . . . . . . . . . . . 42
recorder . . . . . . . . . . . . . . . . . . . 78
volume key . . . . . . . . . . . . . . . . . . . 16
W
wallpaper . . . . . . . . . . . . . . . . . . . . 55
Web
bookmarks . . . . . . . . . . . . . . . . 97
connect . . . . . . . . . . . . . . . . . . . 95
weight . . . . . . . . . . . . . . . . . . . . . . 106
wireless markup language . . . . . . . 95
wrist strap . . . . . . . . . . . . . . . . . . . . 15
write text . . . . . . . . . . . . . . . . . . . . 24
X
XHTML . . . . . . . . . . . . . . . . . . . . . . . 95
XpressPrint . . . . . . . . . . . . . . . . . . . 71
Y
zoom key . . . . . . . . . . . . . . . . . . . . . 16
FCC_6126H_6133H_en_1_FCC.fm Page 126 Tuesday, June 27, 2006 1:35 PM
