Microsoft RM-324H GSM/WCDMA Cellular Telephone w/ BT User Manual
Microsoft Mobile Oy GSM/WCDMA Cellular Telephone w/ BT
Manual
1
6650 User Guide
9206316
Draft
FCC Draft
Model: 6650d-1bH
21 February 2008
2
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-
324 product is in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC. A copy of the Declaration of
Conformity can be found at http://www.nokia.com/
phones/declaration_of_conformity/.
© 2008 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia Care, and Navi are trademarks or registered
trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other
product and company names mentioned herein may be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
This product includes software licensed from Symbian Software Ltd ©
1998-2007. Symbian and Symbian OS are trademarks of Symbian Ltd.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C)
1997-2007. Tegic Communications, Inc. All rights reserved.
Java™ and all Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and
noncommercial use in connection with information which has been encoded in compliance
with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial
activity and (ii) for use in connection with MPEG-4 video provided by a licensed video
provider. No license is granted or shall be implied for any other use. Additional information,
including that related to promotional, internal, and commercial uses, may be obtained from
MPEG LA, LLC. See <http://www.mpegla.com>.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes
and improvements to any of the products described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES
SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR
INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES
HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY
APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
0434
FCC Draft
Model: 6650d-1bH
21 February 2008
3
CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR
WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
The availability of particular products and applications and services for these products may
vary by region. Please check with your Nokia dealer for details, and availability of language
options.
This device complies with Directive 2002/95/EC on the restriction of the use of certain
hazardous substances in electrical and electronic equipment.
NO WARRANTY
The third-party applications provided with your device may have been created and may be
owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the
copyrights or intellectual property rights to the third-party applications. As such, Nokia does
not take any responsibility for end-user support, functionality of the applications, or the
information in the applications or these materials. Nokia does not provide any warranty for
the third-party applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED
AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR
ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-
PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
Export controls
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
FCC NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close
proximity to receiving equipment). The FCC can require you to stop using your telephone if
such interference cannot be eliminated. If you require assistance, contact your local service
facility. This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by Nokia could void the user's authority
to operate this equipment.
9206316 draft
FCC Draft
Model: 6650d-1bH
21 February 2008
4
Contents
Safety................................................ 6
Support ............................................. 8
Help ...................................................................... 8
Service settings ................................................. 8
Troubleshooting your phone.......................... 9
Gameplay ......................................................... 10
1. Get started.................................. 10
Insert a SIM card and battery.................... 10
MicroSD card slot .......................................... 12
Charge the battery ........................................ 13
Switch the phone on and off ..................... 14
Welcome application.................................... 14
Access codes ................................................... 14
2. Your phone ................................. 16
Keys and parts ................................................ 16
Standby mode................................................. 17
Indicators ......................................................... 18
Menu ................................................................. 19
Volume control............................................... 19
Keypad lock (keyguard)................................ 20
Normal operating position.......................... 20
Connect a compatible headset .................. 21
Connect a USB data cable .......................... 21
3. Call functions ............................. 21
Make a voice call ........................................... 21
Answer or reject a call ................................. 23
Video calls........................................................ 24
Call settings..................................................... 25
Video sharing .................................................. 27
Log ..................................................................... 29
4. Write text ................................... 29
Traditional and predictive text input ....... 29
Copy and delete text .................................... 30
5. Messaging................................... 31
Write and send messages............................ 31
Inbox.................................................................. 32
E-mail................................................................ 32
Outbox .............................................................. 34
View messages on the SIM card ................ 34
Cell broadcast ................................................. 34
Service commands ......................................... 34
Messaging settings........................................ 34
Instant messaging.......................................... 35
6. Push to Talk ............................... 35
Switch PTT on and off................................... 36
Add Contacts ................................................... 36
Make and receive a PTT call........................ 37
Change from PTT to mobile call................. 39
Call Me Alerts.................................................. 39
Voice Messages............................................... 39
PTT Settings ..................................................... 39
7. Address Book.............................. 40
Save and manage contact information ... 40
Add a ringing tone......................................... 41
8. Media.......................................... 41
Music player .................................................... 41
RealPlayer......................................................... 44
Flash Player...................................................... 45
Recorder............................................................ 45
9. Gallery ........................................ 45
Download files ................................................ 46
View videos and images ............................... 46
Edit images ...................................................... 46
Print images..................................................... 47
Transfer videos from PC ............................... 47
10.Camera ...................................... 47
Capture an image and record a video...... 48
Camera settings.............................................. 48
11.Positioning................................ 49
GPS data ........................................................... 49
Landmarks ........................................................ 49
Positioning settings....................................... 49
12.Internet ..................................... 49
Browse the web .............................................. 49
FCC Draft
Model: 6650d-1bH
21 February 2008
5
13.Personalisation.......................... 53
Themes.............................................................. 53
Profiles.............................................................. 53
14.Time management .................... 54
Clock.................................................................. 54
Calendar ........................................................... 55
15.Office applications ................... 55
Notes................................................................. 55
Calculator......................................................... 55
Converter.......................................................... 55
16.Settings ..................................... 56
Keypad lights .................................................. 56
Voice commands............................................ 56
Phone settings................................................ 57
Speech............................................................... 59
Settings wizard............................................... 59
17.Data management .................... 59
Install or remove applications ................... 59
File manager.................................................... 61
Licences............................................................. 61
Device manager .............................................. 63
18.Connectivity.............................. 64
PC Suite............................................................. 64
Bluetooth connectivity ................................. 64
USB connection .............................................. 66
Remote synchronisation............................... 67
Connection manager..................................... 67
19.Applications.............................. 68
Phone Inspector.............................................. 68
20.Battery information ................. 68
Charging and discharging............................ 68
Talk and standby times................................. 69
Nokia battery authentication guidelines. 70
Care and maintenance................... 70
Additional safety information...... 72
Index............................................... 76
FCC Draft
Model: 6650d-1bH
21 February 2008
SAFETY
6
SAFETY
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could
affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect
incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
■About your device
The wireless device described in this guide is approved for use on the UMTS 850
and 1900, EGSM 850 and 900, and GSM 1800 and 1900 networks. Contact your
service provider for more information about networks.
When using the features in this device, obey all laws and respect local customs,
privacy and legitimate rights of others, including copyrights.
Copyright protections may prevent some images, music (including ringing tones),
and other content from being copied, modified, transferred, or forwarded.
Your device supports internet connections and other methods of connectivity.
Like computers, your device may be exposed to viruses, malicious messages and
applications, and other harmful content. Exercise caution and open messages,
FCC Draft
Model: 6650d-1bH
21 February 2008
SAFETY
7
accept connectivity requests, download content, and accept installations only
from trustworthy sources. To increase the security of your device, consider
installing antivirus software with a regular update service and using a firewall
application.
Your device may have preinstalled bookmarks and links for third-party internet
sites. You may also access other third-party sites through your device. Third-
party sites are not affiliated with Nokia, and Nokia does not endorse or assume
liability for them. If you choose to access such sites, you should take precautions
for security or content.
Important: Your device can only support one antivirus application.
Having more than one application with antivirus functionality could
affect performance and operation or cause the device to stop
functioning.
Warning: To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on when
wireless device use may cause interference or danger.
When connecting to any other device, read its user guide for detailed safety
instructions. Do not connect incompatible products.
■Network services
To use the phone you must have service from a wireless service provider. Many of
the features require special network features. These features are not available on
all networks; other networks may require that you make specific arrangements
with your service provider before you can use the network services. Your service
provider can give you instructions and explain what charges will apply. Some
networks may have limitations that affect how you can use network services. For
instance, some networks may not support all language-dependent characters
and services.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, these features will not appear on your device
menu. Your device may also have a special configuration such as changes in
menu names, menu order, and icons. Contact your service provider for more
information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP
protocols. Some features of this device, such as web browsing, e-mail,
push to talk, instant messaging, and multimedia messaging, require network
support for these technologies.
FCC Draft
Model: 6650d-1bH
21 February 2008
Support
8
■Enhancements, batteries, and chargers
Check the model number of any charger before use with this device. This device is
intended for use when supplied with power from the AC-4 or AC-5 chargers.
Warning: Use only batteries, chargers, and enhancements approved by
Nokia for use with this particular model. The use of any other types may
invalidate any approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer. When
you disconnect the power cord of any enhancement, grasp and pull the plug, not
the cord.
Practical rules about accessories and enhancements
• Keep all accessories and enhancements out of the reach of small children.
• When you disconnect the power cord of any accessory or enhancement, grasp
and pull the plug, not the cord.
• Check regularly that enhancements installed in a vehicle are mounted and
are operating properly.
• Installation of any complex car enhancements must be made by qualified
personnel only.
Support
■Help
Your phone has context-sensitive help. To access help when an
application is open, select Options > Help. To switch between help and
the application that is open in the background, select and hold , and
select from the list of open applications.
To open help from the main menu, select > Tools > Help > Help.
Select an application to view a list of help topics, and select the related
help text. To open a keyword list, select Options > Search.
■Service settings
Before you can use multimedia messaging, instant messaging, push to
talk, e-mail, synchronisation, streaming, and the browser, you must
have the proper configuration settings on your phone. Your phone may
automatically configure browser, multimedia messaging, access point,
and streaming settings based on the SIM card used. Otherwise, you can
FCC Draft
Model: 6650d-1bH
21 February 2008
Support
9
use Sett. wizard application to configure the settings, or you may
receive the settings directly as a configuration message, which you save
to your phone. For more information on availability, contact your service
provider or nearest authorized Nokia dealer.
When you receive a configuration message, and the settings are not
automatically saved and activated, 1 new message is displayed. To save
the settings, select Show > Options > Save. You may need to enter a
PIN code provided by the service provider.
■Troubleshooting your phone
If you have problems with your phone, try the following before taking it
to a service point:
Reset the phone
Switch the phone off, remove the battery, reinsert it, and switch the
phone on.
Restore original factory settings
Select > Settings > General > Factory settings. Your documents and
files are not deleted.
Visit the Nokia support website
Visit www.nokia.com/support or your local Nokia website for product
support and FAQs. On this website, you can also find:
• The latest version of this guide, additional information, downloads
and services related to your Nokia product.
• List of local Nokia contact centers, if you need to contact customer
service.
• Your nearest Nokia service centers for maintenance services. Before
sending your phone for repair, always back up or make a record of
data in your phone.
Update your phone software
Nokia may produce software updates that may offer new features, enhanced
functions, or improved performance. You may be able to request these updates
through the Nokia Software Updater PC application. To update the device
FCC Draft
Model: 6650d-1bH
21 February 2008
Get started
10
software, you need the Nokia Software Updater application and a compatible PC
with Microsoft Windows 2000 or XP operating system, broadband internet
access, and a compatible data cable to connect your device to the PC.
To get more information and to download the Nokia Software Updater
application, visit www.nokia.com/softwareupdate or your local Nokia web site.
If software updates over the air are supported by your network, you may also be
able to request updates through the device. See "Update software," p. 63.
Downloading software updates may involve the transmission of large amounts of
data through your service provider's network. Contact your service provider for
information about data transmission charges.
Make sure that the device battery has enough power, or connect the charger
before starting the update.
■Gameplay
Your phone is compatible with the N-Gage™ gaming experience. With
N-Gage, you can download and play high-quality multiplayer games.
For more information, visit www.n-gage.com.
For the full N-Gage experience, you need internet access on your phone
through the cellular network. Contact your service provider for more
information on data services.
1. Get started
■Insert a SIM card and battery
Always switch the device off and disconnect the charger before removing the
battery.
This phone uses BP-4L batteries.
For availability and information on using SIM card services, contact your SIM
card vendor. This may be the service provider or other vendor.
FCC Draft
Model: 6650d-1bH
21 February 2008
Get started
11
1. To open the back cover, press teh black button on the lower part of
the back cover (1), slide the cover forward (2), and lift (3). To remove
the battery, lift it as shown (4).
2. To release the SIM card holder, slide it backwards (4), and lift it (5).
Insert the (U)SIM card in the SIM card holder (6). Make sure that the
gold colored contact area on the card is facing downwards, and the
beveled corner faces upwards.
Close the SIM card holder (7), and slide it forward to lock it (8).
FCC Draft
Model: 6650d-1bH
21 February 2008
Get started
12
3. Replace the battery (9). Replace the back cover (10, 11).
■MicroSD card slot
Use only compatible microSD cards approved by Nokia for
use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not be
fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored on the card.
Keep microSD cards out of the reach of small children.
You can extend the available memory with a microSD memory card. You
can insert or remove a microSD card without switching the phone off.
Important: Do not remove the memory card in the middle of an
operation when the card is being accessed. Removing the card in the
middle of an operation may damage the memory card as well as the
device, and data stored on the card may be corrupted.
Insert a microSD card
Note that the memory card may be supplied with the phone, and may
already be inserted.
FCC Draft
Model: 6650d-1bH
21 February 2008
Get started
13
Open the side door (1). Place the microSD card in the slot with the
gold colored area facing down (2). Push the card gently to lock it into
place. Close tight the side door (3).
Remove a microSD card
Open the side door. Push the card gently to release it. Remove memory
card and press 'OK' is displayed. Pull the card out, and select OK. Close
tight the side door.
■Charge the battery
1. Connect the charger to the
wall socket.
2. Open the side door (1), and
connect the charger plug to
the charger connector in the
phone (2).
3. After charging, close tight the side door.
If the battery is completely discharged, it may take a few minutes before
the charging indicator appears on the display or before any calls can be
made.
The charging time depends on the charger and the battery used.
Charging a BP-4L battery with the AC-5 charger takes approximately
80 minutes.
FCC Draft
Model: 6650d-1bH
21 February 2008
Get started
14
■Switch the phone on and off
Press and hold the power/call end key.
If the phone asks for a PIN code, enter the PIN
code, and select OK.
If the phone asks for the lock code, enter the lock
code, and select OK. The factory setting for the
lock code is 12345.
Set time and date
To set the correct time zone, time, and date,
select the country you are presently in, then enter the local time and
date.
■Welcome application
The Welcome application starts when you switch on your phone for the
first time.
With the Welcome application, you can access the following
applications:
Tutorial — Learn about the features of your phone and how to use them.
Sett. wizard — Configure connection settings. See "Settings wizard,"
p. 59.
Transfer — Copy or synchronize data from other compatible devices.
To open Welcome later, select > Help > Welcome.
■Access codes
Select > Settings > General > Security > Phone and SIM card to set
how your phone uses the access codes.
Lock code
The lock code (5 digits) helps to lock your phone. The preset code is
12345. Change the code, and set the phone to request the code.
When the device is locked, calls may be possible to the official emergency
number programmed into your device.
FCC Draft
Model: 6650d-1bH
21 February 2008
Get started
15
PIN codes
The personal identification number (PIN) code or the universal personal
identification number (UPIN) code (4 to 8 digits) help to protect your
SIM card. The (U)PIN code is usually supplied with the SIM card. Set the
phone to request the code each time the phone is switched on.
The PIN2 code may be supplied with the SIM card and is required for
some functions.
The module PIN is required to access the information in the security
module. The signing PIN is required for the digital signature. The module
PIN and the signing PIN are supplied with the SIM card if the SIM card
has a security module in it.
PUK codes
The personal unblocking key (PUK) code or the universal personal
unblocking key (UPUK) code (8 digits) are required to change a blocked
PIN code and UPIN code, respectively. The PUK2 code is required to
change a blocked PIN2 code.
If needed, contact your local service provider for the codes.
Call restriction password
The restriction password (4 digits) is required when using Call
restriction. You can obtain the password from your service provider. If
the password is blocked, contact your service provider.
FCC Draft
Model: 6650d-1bH
21 February 2008
Your phone
16
2. Your phone
■Keys and parts
Power key (1)
Loudspeaker (2)
Earpiece (3)
Volume keys (4)
Left and right selection keys (5)
Menu key (6),
hereafter described as "select "
Clear key (7)
Call key (8)
End key (9)
Navi™ scroll key (10),
hereafter referred to as scroll key
Number keys (11)
Microphone (12)
Nokia AV Connector (2.5 mm)
(13)
Loudspeaker (14)
Charger connector (15)
microSD card slot (16)
USB connector (17)
FCC Draft
Model: 6650d-1bH
21 February 2008
Your phone
17
Media keys:
Rewind, zoom out (19)
Play/Pause/Stop and
autofocus/capture key (20)
Fast forward, zoom in (21)
Camera lens (22)
Camera flash (23)
■Standby mode
When you have switched on the phone, and it is registered to a network,
the phone is in the standby mode and ready for use.
To open the list of last dialed numbers, press the call key.
To use the voice commands or voice dialing, press and hold the right
selection key.
To change the profile, press the power key, and select a profile.
To start a connection to the web, press and hold 0.
Active standby
When active standby is enabled, you can use the display for fast access
to frequently used applications. To select whether the active standby is
shown, select > Settings > General > Personalisation >
Standby mode > Active standby > On or Off.
In active standby the default applications are shown across the top of
the active standby area, and calendar, to-do, and player events are listed
below. To select an application or event, scroll to it, and select it.
Offline profile
To activate the Offline profile, press the power key, and select Offline.
When the Offline profile is active, the connection to the wireless
network is turned off. All wireless radio frequency signals to or from
your phone are prevented, and you can use your phone without a (U)SIM
card. Use the offline profile in radio sensitive environments—on board
FCC Draft
Model: 6650d-1bH
21 February 2008
Your phone
18
aircraft or in hospitals. You can listen to music using the music player
when the offline profile is active.
To leave the Offline profile, press the power key, and select another
profile.
Important: In the offline profile you cannot make or receive any calls,
or use other features that require cellular network coverage. Calls may
still be possible to the official emergency number programmed into
your device. To make calls, you must first activate the phone function by
changing profiles. If the device has been locked, enter the lock code.
■Indicators
or — The phone is connected to a UMTS or GSM network.
— HSDPA (network service) in the UMTS network is activated.
— The phone is in the offline mode and not connected to a cellular
network.
— A memory card is inserted in the phone.
— You received one or several messages to the Inbox folder in
Messaging.
— You received new e-mail in your remote mailbox.
— There are messages waiting to be sent in Outbox.
— You have missed calls.
— Ringing type is set to Silent and Message alert tone and E-mail
alert tone are set to Off.
— The phone keypad is locked.
— The loudspeaker is activated.
— An alarm is active.
— All calls to the phone are diverted to another number.
or — A headset or a loopset is connected to the phone.
or or — A GPRS packet data connection is active, the connection
is on hold, or a connection is available.
FCC Draft
Model: 6650d-1bH
21 February 2008
Your phone
19
or or — A packet data connection is active in a part of the
network that supports EGPRS, or the connection is on hold, a connection
is available. Your phone may not use EGPRS in the data transfer.
or or — A UMTS packet data connection is active, the
connection is on hold, or a connection is available.
or — Bluetooth is switched on, or data is being transmitted using
Bluetooth.
— A USB connection is active.
Other indicators may also be shown.
■Menu
In the menu you can access the functions in your phone. To access the
main menu, press .
To open an application or a folder, scroll to it, and press the scroll key.
To change the menu view, select > Options > Change Menu view and
a view type.
If you change the order of the functions in the menu, the order may
differ from the default order described in this user guide.
To close an application or a folder, select Back and Exit as many times as
needed to return to the standby mode, or select Options > Exit.
To display and switch between open applications, press and hold .
Scroll to an application, and select it.
To mark or unmark an item in applications, press #. To mark or unmark
several consecutive items, press and hold #, and scroll up or down.
Leaving applications running in the background increases the demand on battery
power and reduces the battery life.
■Volume control
To adjust the earpiece or loudspeaker volume during a call or when
listening to an audio file, press the volume keys. To activate or
deactivate the loudspeaker during a call, select Loudspeaker or
Handset.
Warning: Do not hold the device near your ear when the loudspeaker is
in use, because the volume may be extremely loud.
FCC Draft
Model: 6650d-1bH
21 February 2008
Your phone
20
■Keypad lock (keyguard)
To lock the keypad in the phone mode, press the left selection key and *
within 1.5 seconds. To set the phone to automatically lock the keypad
after a certain time, select > Settings > General > Security > Phone
and SIM card > Keypad autolock period > User defined and the desired
time.
To unlock the keypad in the phone mode, select Unlock, and press *
within 1.5 seconds.
To lock the keypad in the music mode, press the power key quickly, and
select Lock keypad. To unlock the keypad in the music mode, select
Unlock > OK.
When the keypad is locked, calls may be possible to the official emergency
number programmed into your device.
■Normal operating position
Your device has internal
antennas.
Cellular antenna (1)
Bluetooth antenna
(2)
Use the phone only in
its normal operating
position (3).
Note: As with any radio transmitting device, avoid touching an antenna
unnecessarily when the antenna is in use. For example, avoid touching
the cellular antenna during a phone call. Contact with a transmitting or
receiving antenna affects the quality of the radio communication, may
cause the device to operate at a higher power level than otherwise
needed, and may reduce the battery life.
FCC Draft
Model: 6650d-1bH
21 February 2008
Call functions
21
■Connect a compatible headset
Do not connect products that
create an output signal as this
may cause damage to the
device. Do not connect any
voltage source to the Nokia AV
Connector.
When connecting any external device or any headset, other than those approved
by Nokia for use with this device, to the Nokia AV Connector, pay special
attention to volume levels.
■Connect a USB data cable
To set the default USB
connection mode, select
> Settings >
Connectivity > USB >
USB mode and the
desired mode. To set
whether the default mode is activated automatically, select Ask on
connection > No.
3. Call functions
To adjust the volume during the call, press the volume keys.
■Make a voice call
1. In the standby mode, enter the phone number, including the area
code. Press the clear key to remove a number.
For international calls, press * twice for the international prefix
(the + character replaces the international access code), and enter
the country code, area code (omit the leading zero if necessary), and
phone number.
2. To call the number, press the call key.
3. To end the call, or to cancel the call attempt, press the end key.
FCC Draft
Model: 6650d-1bH
21 February 2008
Call functions
22
To make a call from Addr. Book, select > Contacts. Scroll to the
desired name; or enter the first letters of the name, and scroll to the
desired name. To call the number, press the call key.
To call a recently dialed number, press the call key in the standby mode.
Speed dialing
Speed dialing is a quick way to call frequently used numbers in the
standby mode. You need to assign a phone number to the speed dialing
keys 2 to 9 (the 1 key is reserved for the call mailbox), and set Speed
dialing to On.
To assing a phone number to a speed dialing key, select > Settings >
Speed dial. Scroll to a key icon, and select Options > Assign. Select the
contact and the number for the speed dial. To change the number, select
Options > Change.
To set Speed dialing to On, select > Settings > Phone > Call > Speed
dialing > On.
To call a speed dialing number, press and hold the speed dialing key until
the call begins.
Call mailbox
To call your call mailbox (network service), press and hold 1 in the
standby mode. You can have call mailboxes for voice calls, video calls,
and multiple phone lines.
To define the call mailbox number if no number is set, select >
Settings > Call mailbox. Scroll to Voice mailbox or Video mailbox, select
Define, and enter the corresponding mailbox number. To change the call
mailbox number, select Options > Change number. Contact your service
provider for the call mailbox number.
Voice dialing
A voice tag is added automatically to all entries in Addr. Book. Use long
names, and avoid similar names for different numbers.
Make a voice dialing call
Voice tags are sensitive to background noise. Use voice tags in a quiet
environment.
FCC Draft
Model: 6650d-1bH
21 February 2008
Call functions
23
Note: Using voice tags may be difficult in a noisy environment or
during an emergency, so you should not rely solely upon voice dialing in
all circumstances.
1. In the standby mode, press and hold the right selection key.
If you are using a compatible headset with the headset key, press
and hold the headset key.
2. When Speak now is displayed, speak the voice command clearly. The
phone plays the voice command of the best match. After 1.5 seconds,
the phone dials the number; if the result is not the correct one,
before dialing select Next and another entry.
Make a conference call
The phone supports conference calls (network service) between a
maximum of six participants, including yourself.
1. Make a call to the first participant.
2. To make a call to another participant, select Options > New call.
3. To create the conference call when the new call is answered, select
Options > Conference.
To add a new person to the conference call, repeat step 2, and select
Options > Conference > Add to conference.
4. To end the conference call, press the end key.
■Answer or reject a call
To answer a call, press the call key.
To mute the ringing tone, select Silence.
To reject the call, press the end key, or select Options > Reject. If you
have activated Call divert > If busy, rejecting the call diverts the call.
To send a text message as a reply to the caller instead of answering the
call, select Options > Send text message. To activate the text message
reply and edit the message, select > Settings > Phone > Call > Reject
call with SMS and Message text.
FCC Draft
Model: 6650d-1bH
21 February 2008
Call functions
24
Call waiting
During a call, to answer the waiting call, press the call key. The first call
is put on hold. To switch between the two calls, select Swap. To end the
active call, press the end key.
To activate the Call waiting function (network service), select >
Settings > Phone > Call > Call waiting > Activate.
Options during a call
Many of the options that you can use during a call are network services.
For availability, contact your service provider.
Select Options during a call for some of the following options:
Transfer—to connect a call on hold to an active call and disconnect
yourself
Send DTMF—to send DTMF tone strings (for example, a password). Enter
the DTMF string or search for it in Addr. Book. To enter a wait character
(w) or a pause character (p), press * repeatedly. To send the tone,
select OK.
■Video calls
To let the call recipient see your face during a video call, activate the
video call mode. Turn the lower part of the phone 90 degrees to the right
so that the camera lens is pointing toward you when you look at the
display.
Make a video call
To make a video call, you may need to have a USIM card and be in the
coverage of a UMTS network. For availability of and subscription to
video call services, contact your service provider. A video call can only be
made between two parties and when there are not other voice, video, or
data calls active. The video call can be made to a compatible mobile
phone or an ISDN client.
The recipient is not sending video or the network is not transmitting
it.
You have denied video sending from your phone.
FCC Draft
Model: 6650d-1bH
21 February 2008
Call functions
25
1. Enter the phone number in the standby mode; or select > Addr.
Book, and scroll to the desired contact.
2. Select Options > Call > Video call.
To change between showing video or only hearing sound, select
Options > Enable or Disable > Sending video, Sending audio, or
Sending aud. & video.
If you have denied video sending during a video call, the call is still
charged as a video call. Check the pricing with your network operator
or service provider.
3. To end the video call, press the end key.
Answer a video call
When a video call arrives, is displayed.
Press the call key to answer the video call. Allow video image to be sent
to caller? is shown. If you select Yes, the image captured by the camera
in your phone is shown to the caller. Otherwise, video sending is not
activated.
If you have denied video sending during a video call, the call is still
charged as a video call. Check the pricing with your service provider.
To end the video call, press the end key.
■Call settings
Call
Select > Settings > Phone > Call and from the following:
Send my caller ID (network service)—to display or hide your phone
number from the person whom you are calling
Call waiting (network service)—See "Call waiting," p. 24.
Reject call with SMS and Message text—See "Answer or reject a call,"
p. 23.
Image in video call—to select a still image to be shown when you deny a
video call
Automatic redial—to set the phone to make a maximum of 10 attempts
to connect the call after an unsuccessful call attempt
FCC Draft
Model: 6650d-1bH
21 February 2008
Call functions
26
Show call duration and Summary after call—to set the phone to display
the call duration during a call and the approximate duration of the last
call
Speed dialing—See "Speed dialing," p. 22.
Anykey answer—to answer an incoming call by briefly pressing any key,
except the left and right selection keys, volume keys, power key, and
end key.
Line in use (network service)—to select the phone lines for making calls
and sending short messages. Shown only if the SIM card supports two
subscriber numbers, that is, two phone lines.
Call forward
1. Select > Settings > Phone > Call forwarding (network service).
2. Select which calls you want to forward, for example, Voice calls.
3. Select the desired option. For example, to forward voice calls when
your number is busy or when you reject an incoming call, select If
busy.
4. Select Options > Activate and the phone number to which you want
to forward the calls. Several divert options can be active at the same
time.
Call restricting and call forwarding cannot be active at the same time.
Call restriction
1. Select > Settings > Phone > Call restriction (network service) to
restrict the calls that you make and receive with your phone.
2. Scroll to the desired barring option, and select Options > Activate. To
change the settings, you need the restriction password from your
service provider.
Call restricting and call forwarding cannot be active at the same time.
When calls are restricted, calls may be possible to the official emergency number
programmed into your device.
Network
Select > Settings > Phone > Network and from the following:
FCC Draft
Model: 6650d-1bH
21 February 2008
Call functions
27
Network mode—to select which network to use (shown only if supported
by the service provider). If you select Dual mode, the phone uses the
GSM or UMTS network automatically.
Operator selection—To set the phone to search for and automatically
select one of the available networks, select Automatic. To select the
desired network manually from a list of networks, select Manual. The
selected network must have a roaming agreement with your home
network.
Cell info display (network service)—to set the phone to indicate when it
is used in a cellular network based on microcellular network (MCN)
technology and to activate cell info reception
■Video sharing
Use Video sharing to send live video from your mobile phone to another
compatible mobile phone during a voice call.
Video sharing requirements
Video sharing requires a 3G universal mobile telecommunications
system (UMTS) connection. Contact your service provider for questions
about network availability and fees associated with this application.
To use Video sharing you must do the following:
• Ensure that your phone is set up for person-to-person connections.
• Ensure you have an active UMTS connection and are within UMTS
network coverage. If you start the sharing session while you are
within UMTS network coverage and a handover to GSM occurs, the
sharing session is discontinued, but your voice call continues.
• Ensure that both the sender and recipient are registered to the UMTS
network. Otherwise, they do not know that you are sending an
invitation. However, you receive an error message that the recipient
cannot accept the invitation.
Video sharing settings
A person-to-person connection is also known as a session initiation
protocol (SIP) connection. Before you can use Video sharing, ask your
FCC Draft
Model: 6650d-1bH
21 February 2008
Call functions
28
service provider for the SIP profile settings, and save them in your
phone.
If you know a recipient’s SIP address, you can enter it on your contact
card for that person. Select > Addr. Book, the contact, and Options >
Edit > Options > Add detail > SIP or Share view. Enter the SIP address in
the format sip:username@domainname (you can use an IP address
instead of a domain name).
To set your SIP profile settings manually, select > Settings >
Connection > Video sharing > SIP profile. To select whether the video
sharing is enabled, select Video sharing > Always on. To set whether the
live videos are automatically saved, select Video saving > Always save.
Share live video or video clip
1. Select Options > Share video > Live video when a voice call is active
to share live video you are recording with the phone camera.
Select Options > Share video > Recorded clip or Image to share a
saved video clip or an image. Select a clip or image you want to
share.
2. The phone sends the invitation to the SIP address you have added to
the contact card of the recipient.
If necessary, select the SIP address to which you want to send the
invitation. If the SIP address of the recipient is not available, enter a
SIP address. Select OK to send the invitation.
3. Sharing begins automatically when the recipient accepts the
invitation. The loudspeaker is active.
4. Use the toolbar buttons to control the video and image sharing.
5. Select Stop to end the sharing session. Press the end key to end the
voice call.
Accept an invitation
Your phone must be registered to the UMTS network to receive a share
invitation. The invitation shows the sender’s name or SIP address. If your
phone is not set to Silent, it rings when you receive an invitation.
FCC Draft
Model: 6650d-1bH
21 February 2008
Write text
29
When you receive an invitation, select Yes to begin the sharing session.
To decline the invitation and to return to the voice call, select No.
■Log
To view missed, received, or dialed calls; text messages; packet data
connections; and fax and data calls registered by the phone, select >
Log.
In the standby mode, you can use the call key as a shortcut to the Recent
calls log (a network service).
Note: The actual invoice for calls and services from your service
provider may vary, depending on network features, rounding off for
billing, taxes, and so forth.
Note: Some timers, including the life timer, may be reset during service
or software upgrades.
4. Write text
■Traditional and predictive text input
When you write text, on the display indicates predictive text input
and traditional text input. To set the predictive text input on or off,
press # repeatedly, or press *, and select Activate predictive text or
Predictive text > Off.
, , or next to the text input indicator indicates the
character case or number mode. To change the character case or
between letter and number mode, press # repeatedly.
Select > Settings > General > Personalisation > Language > Writing
language to change the writing language of your phone. The writing
language affects the characters available when writing text and the
predictive text dictionary used. Not all characters available under a
number key are printed on the key.
Write with traditional text input
Press a number key, 2 to 9, repeatedly until the desired character
appears. Press the 1key for the most common punctuation marks and
special characters.
FCC Draft
Model: 6650d-1bH
21 February 2008
Write text
30
If the next letter you want is on the same key as the present one, wait
until the cursor appears (or scroll forward to end the time-out period),
and enter the letter.
Write with predictive text input
1. Press a number key, 2–9, only once for one letter. The word changes
after every keypress. For the most common punctuation marks, press
1.
2. When you have finished the word and it is correct, to confirm it,
scroll forward or insert a space.
If the word is not correct, to view the matching words the dictionary
has found one by one, press * repeatedly.
If the ? character is shown after the word, the word you intended to
write is not in the dictionary. To add a word to the dictionary, select
Spell. Enter the word (up to 32 letters), and select OK. The word is
added to the dictionary. When the dictionary becomes full, a new
word replaces the oldest added word.
Common functions in traditional and predictive text input
To insert a number, press and hold the number key.
To enter punctuation marks and special characters, press and hold *.
To erase a character, press the clear key. To erase more characters, press
and hold the clear key.
To insert a space, press 0. To move the cursor to the next line, press 0
three times.
■Copy and delete text
1. To select letters and words, press and hold #, and at the same time
scroll left or right. To select lines of text, press and hold #, and at the
same time scroll up or down.
2. To copy the text, press and hold #, and at the same time select Copy.
To delete the selected text, press the clear key.
3. To insert the text, scroll to the insertion point, press and hold #, and
at the same time select Paste.
FCC Draft
Model: 6650d-1bH
21 February 2008
Messaging
31
5. Messaging
Before you can receive or send messages or e-mail, you must have the
necessary settings and access points defined. Contact your service
provider for the settings.
■Write and send messages
Your device supports the sending of text messages beyond the character limit for
a single message. Longer messages are sent as a series of two or more messages.
Your service provider may charge accordingly. Characters that use accents or
other marks, and characters from some language options, take up more space,
limiting the number of characters that can be sent in a single message.
The wireless network may limit the size of MMS messages. If the inserted picture
exceeds this limit, the device may make it smaller so that it can be sent by MMS.
Only devices that have compatible features can receive and display multimedia
messages. The appearance of a message may vary depending on the receiving
device.
1. Select > Messaging > New message and the message type. To
create a text message or multimedia message, select Message. The
message type changes automatically based on the content.
2. In the To field, enter the phone numbers or e-mail addresses of the
recipients, or to select recipients from Addr. Book, press the scroll
key. Separate recipients with a semicolon (;).
3. To enter the subject for a multimedia, or e-mail message, scroll down
to the Subject field. If the subject field is not visible for a multimedia
message, select Options > Message header fields, mark Subject, and
select OK.
4. Scroll down to the message field and enter the message content.
When you write a text message, the message length indicator shows
how many characters you can enter in the message. For example, 10
(2) means that you can still add 10 characters for the text to be sent
as a series of two text messages.
To insert an object, such as an image, video clip, note, or a business
card, to a multimedia, or e-mail message, press the scroll key, and
select Insert.
FCC Draft
Model: 6650d-1bH
21 February 2008
Messaging
32
To record a new sound clip for an audio message, select Record. To
use a previously recorded sound clip, select Options > Insert sound
clip > From Gallery.
5. To send the message, select Options > Send.
■Inbox
Inbox contains received messages except e-mail and cell broadcast
messages. To read received messages, select > Messaging > Inbox
and the message.
To view the list of media objects that are included in the multimedia
message, open the message, and select Options > Objects.
Important: Exercise caution when opening messages. Multimedia
message objects may contain malicious software or otherwise be
harmful to your device or PC.
Your phone can receive many kinds of messages, such as operator logos,
business cards, calendar entries, and ringing tones. You can save the
special message content to your phone. For example, to save a received
calendar entry to the calendar, select Options > Save to Calendar.
Note: The picture message function can be used only if it is supported
by your service provider. Only compatible devices that offer picture
message features can receive and display picture messages. The
appearance of a message may vary depending on the receiving device.
Service messages
Service messages (network service) are notifications that may contain a
text message or the address of a browser service.
To define whether service messages are enabled and whether the
messages are downloaded automatically, select > Messaging >
Options > Settings > Service message.
■E-mail
When you create a new mailbox, the name you give to the mailbox
replaces New mailbox. You can have up to six mailboxes.
FCC Draft
Model: 6650d-1bH
21 February 2008
Messaging
33
IMAP4 and POP3 mailboxes
Select > Messaging and the mailbox. Connect to mailbox? is
displayed. Select Yes to connect to your mailbox (network service) or No
to view previously retrieved e-mail messages offline.
To connect to the mailbox afterwards, select Options > Connect. When
you are online, to end the data connection to the remote mailbox, select
Options > Disconnect.
Retrieve and read e-mail messages
Important: Exercise caution when opening messages. E-mail messages
may contain malicious software or otherwise be harmful to your device
or PC.
1. Select Options > Retrieve e-mail and whether you want to retrieve
new, selected, or all messages.
2. To open an e-mail message, select it.
To view e-mail attachments, indicated with , select Options >
Attachments. You can retrieve, open, or save attachments in
supported formats.
Delete e-mail messages
To delete an e-mail message from the phone and retain it in the remote
mailbox, select Options > Delete > Phone only. To delete an e-mail from
both the phone and the remote mailbox, select Options > Delete >
Phone and server.
To cancel deletion of an e-mail from both the phone and server, scroll to
an e-mail that has been marked to be deleted during the next
connection, and select Options > Restore.
Sync mailboxes
Select > Messaging and the sync mailbox.
To synchronize your phone with the remote mailbox, select Options >
Synchronisation > Start.
To view received messages, select Inbox and the message.
FCC Draft
Model: 6650d-1bH
21 February 2008
Messaging
34
■Outbox
The outbox folder is a temporary storage place for messages that are
waiting to be sent. To access the outbox folder, select > Messaging >
Outbox.
To retry sending a message, scroll to the message and select Options >
Send.
To postpone sending a message, scroll to a message, and select
Options > Defer sending.
■View messages on the SIM card
Before you can view SIM messages, you need to copy them to a folder in
your phone. Select > Messaging > Options > SIM messages, mark the
messages you want to copy, and select Options > Copy and the folder to
which you want to copy the messages.
■Cell broadcast
Check with your service provider whether cell broadcast (network
service) is available and what the available topics and related topic
numbers are.
Select > Messaging > Options > Cell broadcast. To activate the
service, select Options > Settings > Reception > On.
■Service commands
To enter and send service commands (also known as USSD commands)
such as activation commands for network services to your service
provider, select > Messaging > Options > Service command. To send
the command, select Options > Send.
■Messaging settings
Text message settings
To define text message settings, such as the message center and
character encoding used, select > Messaging > Options > Settings >
Text message.
FCC Draft
Model: 6650d-1bH
21 February 2008
Push to Talk
35
Multimedia messaging settings
To define multimedia message settings, such as which access point is
used and whether multimedia messages are retrieved automatically,
select > Messaging > Options > Settings > Multimedia message.
E-mail settings
Select > Messaging > Options > Settings > E-mail > Mailboxes, the
mailbox and from the following:
Connection settings — to define the connection settings such as the
servers and protocol used
User settings — to define user settings such as when messages are sent
and whether to include a signature
Retrieval settings — to define retrieval settings such as which parts of
the messages are retrieved and how many messages are retrieved
Automatic retrieval — to define settings for retrieving messages
automatically at set intervals or when an e-mail notification is received
from the server
Other settings
To define whether a specified number of sent messages are saved to the
Sent folder and whether to store the messages in the phone memory or
memory card, select > Messaging > Options > Settings > Other.
■Instant messaging
Instant messaging (IM, network service) allows you to converse with
others and join discussion forums (IM groups) with specific topics.
Check the availability of IM services, pricing, and tariffs with your
service provider.
Select > Applications > IM.
6. Push to Talk
Select Menu > PTT.
FCC Draft
Model: 6650d-1bH
21 February 2008
Push to Talk
36
Push to Talk (PTT) is a two-way radio service available over a GSM
cellular network (network service).
You can use PTT to have a conversation with one person or with a group
of people having compatible devices and service. While you are
connected to the PTT service, you can use the other functions of the
phone.
To check availability and costs, and to subscribe to the service, contact
your network operator. Service availability may differ from that for
normal calls. Visit wireless.att.com/ptt for additional information.
Before you can use the PTT service, you must define the required PTT
service settings. See "PTT Settings," p. 39.
Always switch PTT off before switching the phone off or removing the
battery.
■Switch PTT on and off
To disconnect from the PTT service, select Menu > PTT > PTT settings >
PTT Service > Off.
To connect to the PTT service, select Menu > PTT. If you have added
groups to the phone, you are automatically joined to the active groups.
There may be a brief delay while PTT connects.
Connection Indicators
These indicators appear on the standby screen next to the clock.
PTT is connected; your status is Available
Service is disconnected
Information is waiting
Your status is Do Not Disturb
■Add Contacts
You can add individual contacts or create contact groups to call several
people at once.
FCC Draft
Model: 6650d-1bH
21 February 2008
Push to Talk
37
Add a one-to-one contact
To add a contact to the PTT contacts list, select Menu > PTT > Add
Contact. Enter the name and telephone number of the new contact. An
invitation is sent to the person.
Add a contact group
You can save a group of contacts so you can call them collectively.
To add a PTT contact group, select Menu > PTT > Add Group and name
the group.
To add an existing contact to the group, select From PTT contacts and
mark the contacts you want added to the new group.
To add a new contact to the group, select Enter Manually. Enter the
name and telephone number of the new contact. An invitation is sent to
the person.
■Make and receive a PTT call
Warning: Do not hold the device near your ear when the loudspeaker is
in use, because the volume may be extremely loud.
To make a group call, a one-to-one call, or a call to multiple recipients,
you must hold the PTT key as long as you talk. To listen to the response,
release the PTT key.
You can check the login status of your contacts in Menu > PTT > PTT
Contacts. To add a contact, select Menu > PTT > Add Contact. See "Add
a one-to-one contact," p. 37 for more information.
Contact status indicators
These indicators appear next to your contacts and provide information
about their connection status.
Contact is available
Contact is available with phone set to vibrate or silent
Do not disturb; you cannot contact this person
Invitation is in progress; you cannot contact this person
Contact has PTT switched off; you cannot contact this person
FCC Draft
Model: 6650d-1bH
21 February 2008
Push to Talk
38
Make a one-to-one call
To start a one-to-one call from the list of contacts to which you have
added the PTT telephone number, select Menu > PTT > PTT Contacts.
Scroll to a contact, and press and hold the PTT key while talking.
Remember that you must release the PTT key to receive their reply.
To start a one-to-one call from the list of PTT groups, select PTT
Contacts, scroll to the desired group, and select View. Scroll to the
desired contact, and press and hold the PTT key while talking.
Make a group call
To make a call to a group, select PTT Contacts in the PTT menu, scroll to
the desired group, and press and hold the PTT key while talking.
Make a PTT call to multiple recipients
To select multiple PTT contacts from the contact list, create a Quick
Group. The recipients receive an incoming call. If a recipients phone is
set to silent or vibrate, they must accept the call in order to participate.
1. Select Menu > PTT > PTT Contacts and mark the desired contacts.
The Quick Group is automatically created.
2. Press and hold the PTT key to start the call. The group name is shown
on the display, as soon as members join the call.
3. Press and hold the PTT key to talk to them. Release the PTT key to
hear the response.
4. Press the end key to terminate the call.
Receive a PTT call
A short tone notifies you of an incoming PTT call. Information, such as
the group, the phone number, or the nickname of the caller are
displayed.
You can either accept or reject an incoming one-to-one call if you have
set the phone to silent or vibrate.
When you press and hold the PTT key while the caller is talking, you hear
a queuing tone. Release the PTT key, and wait for the other person to
finish; then you can press and hold the PTT key and begin talking.
FCC Draft
Model: 6650d-1bH
21 February 2008
Push to Talk
39
■Change from PTT to mobile call
You can convert a one-to-one or group PTT call to a standard mobile call
if you initiated the PTT call. Anytime during the PTT call select Options >
Convert to Cellular . The call recipient(s) can then join your mobile call
by pressing the PTT key.
■Call Me Alerts
If you make a one-to-one call and do not get a response, you can send a
request for the person to call you back.
Send a Call Me Alert
You can send a Call Me Alert in the following ways:
To send a Call Me Alert from the contacts list in the PTT menu, select PTT
contacts. Scroll to a contact, and select Options > Call Me Alert.
To send a Call Me Alert from the group list in the PTT menu, select PTT
contacts, and scroll to the desired group. Select View, scroll to the
desired contact, and select Options > Call Me Alert.
Respond to a Call Me Alert
When someone sends you a Call Me Alert, Please call (sender’s name) is
displayed in the standby mode.
To call the sender, press and hold the PTT key.
To send a Call Me Alert to the sender, select Options > Call Me Alert .
■Voice Messages
You can send a voice message to one of your PTT contacts or groups.
From the PTT contacts menu, select the individual or group to receive
the voice message. Select Options > Voice Messages. Push and hold the
PTT key while speaking. Release the PTT key to deliver the message.
■PTT Settings
Select Menu >PTT > PTT Settings.
My Availability — to set your PTT status to Available or Do Not Disturb
Contact Alerts — to set a notification for when a contact becomes
available
FCC Draft
Model: 6650d-1bH
21 February 2008
Address Book
40
Set My Name — to set how your PTT name appears to your contacts and
groups
Auto Accept Invites — to set the phone to automatically accept
invitations from other PTT users
PTT Service — to switch the PTT service on or off
7. Address Book
■Save and manage contact information
To save and manage contact information, such as names, phone
numbers, and addresses, select > Addr. Book.
To add a new contact, select Options > New contact. Fill in the fields
you want, and select Done.
To copy names and numbers from a SIM card to your phone or vice
versa, scroll to the contact (or mark the desired contacts), and select
Options > Copy > Phone memory or SmartChip memory.
To assign default numbers and addresses to a contact, select it, and
select Options > Defaults. Scroll to the desired default option, and
select Assign.
To view the list of fixed dialing numbers, select Options > SIM
contacts > Fixed dial contacts. This setting is only shown if supported by
your SIM card.
When fixed dialing is activated, calls may be possible to the official emergency
number programmed into your device.
To view information about the memory consumption of contacts, select
Options > Contacts info.
To create a contact group so that you can send text or e-mail messages
to several recipients at the same time, select > Addr. Book. Scroll to
the right, and select Options > New group. Enter a name for the group,
and select the group. Select Options > Add members. Mark the contacts
you want to add to the group, and select OK.
FCC Draft
Model: 6650d-1bH
21 February 2008
Media
41
■Add a ringing tone
To set a ringing tone (also a video ringing tone) for each contact and
group, select > Addr. Book.
To add a ringing tone to a contact, select the contact and Options >
Ringing tone, and the desired ringing tone.
To add a ringing tone to a group, scroll right to the groups list, and scroll
to a contact group. Select Options > Ringing tone and the ringing tone
for the group.
To remove the personal or group ringing tone, select Default tone as a
ringing tone.
8. Media
■Music player
Warning: Listen to music at a moderate level. Continuous exposure to
high volume may damage your hearing. Do not hold the device near
your ear when the loudspeaker is in use, because the volume may be
extremely loud.
To start Music player, turn the lower part of the phone to the right so
that the playback control keys are on the same side as the display.
You can listen to music when the Offline profile is activated. See
"Offline profile," p. 17.
For more information about copyright protection, see "Licences," p. 61.
Listen to music
In Music player, select Music. Select the category, such as All songs and
a song to listen to.
Playback control
To play or pause a song, press the play/pause/stop key.
To stop the playback, press and hold the play/pause/stop key to stop the
playback.
To rewind or skip backwards, press the rewind key.
FCC Draft
Model: 6650d-1bH
21 February 2008
Media
42
To fast forward or to skip forward, press the fast forward key.
To control the player, you can also use the scroll key.
To adjust the volume, use the volume key.
To switch random play ( ) on, select Options > Shuffle > On.
To repeat a song ( ) or all songs ( ), select Options > Repeat >
Repeat song or Repeat all.
To modify the tone of the music playback, select Options > Equalizer.
To modify the balance loudness or stereo widening, select Options >
Audio settings.
To view a visualisation during playback, select Options > Start
visualisation.
To return to the standby mode and leave the player in the background,
press the end key. In Active standby, the currently playing song is
displayed. To return to the music player, select the currently playing
song.
Music menu
To select more music to play in Now playing view, select Options > Go to
Music menu. To return to the Now playing view, select Options > Go to
Now playing.
The music menu shows the music available in the phone and compatible
memory card (if inserted).
To refresh the library after you have updated the song selection in your
phone, select Options > Refresh Music library.
Playlists
In the music menu, select Playlists.
To view details of the playlist, select Options > Playlist details.
Create a playlist
1. Select Options > Create playlist.
2. Enter a name for the playlist, and select OK.
FCC Draft
Model: 6650d-1bH
21 February 2008
Media
43
3. To add songs now, select Yes. To show the song list under an artist
title, scroll to the artist, and scroll right. To hide the song list, scroll
left. Select the songs to be added, and to add the songs, select Add.
4. When you have made your selections, select Done. If a compatible
memory card is inserted, the playlist is saved to the memory card.
To add more songs later, when viewing the playlist, select Options >
Add songs.
To reorder songs in a playlist, scroll to the song you want to move, select
Options > Reorder list > Grab, scroll to a new position, and select Drop.
Music shop
To go to the music shop, in the Music player, select Options > Go to
Music shop.
In the music shop (network service) you can search, browse, and
purchase music for downloading to your phone. You must have music
shop settings and valid internet connections to use this service.
The variety and appearance of music shop services and the music shop
settings may vary. For more information and availability of the music
shop, contact your service provider.
The settings may also be predefined in your phone. You may be able to
edit the settings; select Options > Settings.
Transfer music
You can buy music protected with WMDRM from online music shops,
and transfer the music to your phone.
To transfer music from a compatible PC or other compatible devices, use
a compatible USB cable or Bluetooth connectivity. You cannot transfer
WMDRM protected music files using Bluetooth.
To refresh the library after you have updated the song selection in your
phone, in the Music menu, select Options > Refresh Music library.
The requirements of the PC for music purchase and transfer:
• Microsoft Windows XP operating system (or later)
• Compatible version of Windows Media Player application
FCC Draft
Model: 6650d-1bH
21 February 2008
Media
44
• Compatible version of Nokia PC Suite
Transfer music from PC
You can use three different methods to transfer music:
• To use Nokia Music Manager in Nokia PC Suite, connect the
compatible USB cable or activate Bluetooth connection, and select
PC Suite as the connection mode.
• To synchronize music with Windows Media Player, connect the
compatible USB cable and select Media player as the connection
mode. A compatible memory card needs to be inserted in the phone.
You can transfer WMDRM protected music files only using Data
transfer.
• To view your phone on a PC as an external hard drive where you can
transfer any data files, make the connection with a compatible USB
cable, or with Bluetooth connectivity using PC Suite file manager.
If you are using the USB cable, select Data transfer as the connection
mode. A compatible memory card needs to be inserted in the phone.
To change the default USB connection mode, select > Settings >
Connectivity > USB > USB mode.
Both Windows Media Player and Nokia Music Manager in Nokia PC
Suite have been optimized for transferring music files. For information
about transferring music with Nokia Music Manager, see the Nokia PC
Suite user guide.
Music transfer with Windows Media Player
Music synchronisation functions may vary between different versions of
the Windows Media Player application. For more information, see the
corresponding Windows Media Player guides and helps.
■RealPlayer
Select > Applications > RealPlayer.
With RealPlayer, you can play media files such as video clips saved in the
phone memory or memory card, or stream media files over the air by
opening a streaming link. RealPlayer does not support all file formats or
all the variations of file formats.
FCC Draft
Model: 6650d-1bH
21 February 2008
Gallery
45
To play, select a media file or a streaming link in Video clips, Streaming
links, or Recently played.
To stream live content, you must first configure your default access
point. Select > Applications > RealPlayer > Options > Settings >
Streaming > Network. Contact your service provider for more
information.
Warning: Do not hold the device near your ear when the loudspeaker is
in use, because the volume may be extremely loud.
■Flash Player
Select > Applications > Flash Player.
With Flash Player, you can view, play, and interact with flash files made
for mobile devices.
To open a folder or play a flash file, select it.
■Recorder
The voice recorder allows you to record voice call conversations and
voice memos. If you record a phone conversation, all parties hear a
beeping sound during recording.
Recorded files are saved in the Sound clips folder in Gallery.
Select > Applications > Recorder. To record a sound clip, select
Options > Record sound clip, or select . To listen to the recording,
select .
9. Gallery
Select > Gallery.
Use Gallery to save and organize your images, videos, music tracks,
sound clips, playlists, streaming links, .ram files, and presentations.
To copy files to phone memory or to the memory card, select the folder
(such as Images), scroll to the file or mark the files, and select Options >
Organize > Copy to phone mem. or Copy to memory card.
To set an image as a wallpaper or to be shown during a call, select
Images, and scroll to the image. Select Options > Use image > Set as
FCC Draft
Model: 6650d-1bH
21 February 2008
Gallery
46
wallpaper or Set as call image. To assign the image to a contact, select
Assign to contact.
To set a video as a video ringing tone, select Video clips, and scroll to the
video. Select Options > Use video > Set as ringing tone. To assign the
video for a contact, select Assign to contact.
To create image or video folders and move files to them, select Images or
Videos, and scroll to a file. Select Options > Organize > New folder and
the memory, and enter a name for the folder. Mark the files you want to
move to the folder, and select Options > Organize > Move to folder and
the folder.
■Download files
Select > Gallery, the folder for the file type you want to download,
and the download function (for example, Images > Downl. graphics).
The browser opens. Choose a bookmark for the site to download from.
■View videos and images
When you are viewing videos or still images in the phone mode, you can
activate the video view mode. Turn the lower part of the phone 90
degrees to the left so that the camera lens is pointing away from you.
The display changes to landscape, and you can put the phone on the
table while viewing.
To view the next or previous still images, press the fast forward or
rewind key.
To fast forward or rewind the video, press the fast forward or
rewind key. To play or pause the video, press the play/pause/stop key. To
stop the video, press and hold the play/pause/stop key.
■Edit images
To edit images in Gallery, scroll to the image, and select Options > Edit.
Select Options > Apply effect to crop or rotate the image; adjust the
brightness, color, contrast, and resolution; and add effects, text, clip art,
or a frame to the picture.
Shortcuts in the image editor:
FCC Draft
Model: 6650d-1bH
21 February 2008
Camera
47
• To view an image in the full screen, and to return to the normal view,
press *.
• To rotate an image clockwise or counterclockwise, press 3 or 1.
• To zoom in or out, press 5 or 0.
• To move on a zoomed image, scroll up, down, left, or right.
■Print images
You can use the phone with a PictBridge-compatible printer using USB
cable.
To print images in Gallery, scroll to the image, and select Options >
Print.
■Transfer videos from PC
To transfer videos from a compatible PC, use a compatible USB cable or
Bluetooth connectivity.
The requirements of the PC for video transfer:
• Microsoft Windows XP operating system (or later)
• Compatible version of Nokia PC Suite
• Nokia Video Manager application (add-on application to PC Suite)
To transfer videos with Nokia Video Manager, connect the compatible
USB cable or activate Bluetooth connection, and select PC Suite as the
connection mode.
To change the default USB connection mode, select > Settings >
Connectivity > USB > USB mode.
Nokia Video Manager is optimized for transcoding and transferring
video files. For information about transferring video with Nokia Video
Manager, see the Nokia Video Manager help.
10. Camera
To activate the camera mode while in the phone mode, turn the lower
part of the phone 90 degrees to the left so that the camera lens is
pointing away from you when you look at the display. The display
FCC Draft
Model: 6650d-1bH
21 February 2008
Camera
48
functions as a viewfinder. To take a self portrait, turn the lower part of
the phone 90 degrees to the right so that the camera lens is pointing
toward you. on the upper left of the display indicates the still
image mode.
■Capture an image and record a video
To lock the focus on an object, press the capture key halfway down. To
capture an image, press the capture key. The image is saved to Images in
Gallery. To return to the viewfinder, select Back. To delete the image,
press the clear key.
To zoom in or out, press the fast forward or rewind key.
To capture images sequentially, select Options > Sequence mode > On.
When you press the capture key, the camera captures six images in
short intervals.
To turn the flash on automatically when necessary, select Options >
Flash > Automatic.
Keep a safe distance when using the flash. Do not use the flash on people or
animals at close range. Do not cover the flash while taking a picture.
In dim lighting, to use night mode, select Options > Night mode > On.
To adjust the white balance or color tone, select Options > Adjust >
White balance or Color tone.
To record a video, select Options > Video mode, or scroll right.
indicates the video mode. To start the recording, press the capture key.
To pause the recording, press the capture key. To stop the recording,
press and hold the capture key.
To use the panorama mode, select Options > Panorama mode, or scroll
right. indicates the panorama mode. Press the capture key to start
capturing a panorama image. Turn slowly to the right or left. You cannot
change the direction. You turn too fast if the arrow on the display is red.
To stop the panorama, press the capture key again.
■Camera settings
Your device supports an image capture resolution of 1200 x 1600 pixels.
FCC Draft
Model: 6650d-1bH
21 February 2008
Positioning
49
To change camera settings for still images or videos when in the camera
mode, select Options > Settings > Image or Video and the desired
setting.
11. Positioning
In GPS data and Landmarks, coordinates are expressed in degrees and
decimal degrees format using the WGS-84 coordinate system.
■GPS data
GPS data is a GPS application that enables you to view your current
location, find your way to a desired location, and track distance. GPS
data requires an external GPS receiver with Bluetooth connectivity to
operate and you must have the Bluetooth GPS positioning method
enabled in Positioning methods.
Select > Applications > GPS data.
■Landmarks
Landmarks are coordinates to geographic locations that you can save to
your phone for later use in different location-based services. You can
create landmarks using a Bluetooth GPS enhancement or network
(network service).
Select > Applications > Landmarks.
■Positioning settings
To enable or disable positioning methods, define the positioning server
and access point used, or define notation settings, select > Settings >
General > Positioning.
12. Internet
■Browse the web
To browse web pages, select > Web, or press and hold 0 in the
standby mode.
FCC Draft
Model: 6650d-1bH
21 February 2008
Internet
50
Check the availability of services, pricing, and tariffs with your service
provider.
Important: Use only services that you trust and that offer adequate
security and protection against harmful software.
To access web pages, do one of the following:
• Select a bookmark from the bookmarks view.
• In the bookmarks view, enter the address of the web page, and select
Go to.
Bookmarks
Your device may have preinstalled bookmarks and links for third-party internet
sites. You may also access other third-party sites through your device.
Third-party sites are not affiliated with Nokia, and Nokia does not endorse or
assume liability for them. If you choose to access such sites, you should take
precautions for security or content.
The starting page is indicated with . The automatic bookmarks
folder ( ) contains bookmarks that are collected automatically when
you browse pages.
To add a bookmark manually, in the bookmarks view, select Options >
Bookmark manager > Add bookmark, fill in the fields, and select
Options > Save.
Connection security
If the security indicator is displayed during a connection, the data
transmission between the device and the internet gateway or server is
encrypted.
The security icon does not indicate that the data transmission between the
gateway and the content server (or place where the requested resource is stored)
is secure. The service provider secures the data transmission between the
gateway and the content server.
To view details about the connection, encryption status, and
information about server authentication, select Options > Tools > Page
info.
FCC Draft
Model: 6650d-1bH
21 February 2008
Internet
51
Keys and commands for browsing
To open a link, make selections, or check boxes, press the scroll key.
To go to the previous page while browsing, select Back. If Back is not
available, select Options > Navigation options > History to view a
chronological list of the pages visited during a browsing session. To
choose the desired page, scroll left or right, and select it. The history list
is cleared each time a session is closed.
To save a bookmark while browsing, select Options > Save as bookmark.
To retrieve the latest content from the server, select Options >
Navigation options > Reload.
To open the browser toolbar, scroll to an empty part of the page, and
press the scroll key.
To end the connection and view the browser page offline, select
Options > Tools > Disconnect. To quit browsing, select Options > Exit.
Keypad shortcuts while browsing
1 — Open your bookmarks.
2 — Search for keywords in the current page.
3 — Return to the previous page.
5 — List all open windows.
8 — Show the page overview of the current page. Press 8 again to zoom
in and view the desired section of the page.
9 — Enter a new web address.
0 — Go to the start page.
* or # — Zoom the page in or out.
Mini map
Mini map helps you navigate web pages that contain large amount of
information. When Mini map is on in browser settings and you scroll
through a large web page, Mini map opens and displays an overview of
the web page you are browsing. To move in Mini map, scroll. When you
stop scrolling, Mini map disappears and the area outlined in Mini map is
displayed.
FCC Draft
Model: 6650d-1bH
21 February 2008
Internet
52
Page overview
With Page overview, you can move more quickly to the desired part of a
web page. Page overview may not be available on all pages.
To show the page overview of the current page, press 8. To find the
desired spot on the page, scroll up or down. Press 8 again to zoom in and
view the desired section of the page.
Web feeds
Web feeds are widely used to share the latest headlines or recent news.
The browser automatically detects if a web page contains web feeds. To
subscribe to a web feed, select Options > Subscribe and a feed, or click
on the link. To view the web feeds you have subscribed to, in the
bookmarks view, select Web feeds.
To update a web feed, select it, and Options > Refresh.
To define how the web feeds are updated, select Options > Settings >
Web feeds.
Saved pages
To save a page while browsing to be able to view it offline, select
Options > Tools > Save page.
To view saved pages, in the bookmarks view, select Saved pages. To open
a page, select it.
Clear privacy data
A cache is a memory location that is used to store data temporarily. If you have
tried to access or have accessed confidential information requiring passwords,
empty the cache after each use. The information or services you have accessed
are stored in the cache. To empty the cache, select Options > Clear privacy
data > Cache.
To clear all privacy data, select Options > Clear privacy data > All.
FCC Draft
Model: 6650d-1bH
21 February 2008
Personalisation
53
13. Personalisation
■Themes
To change the look of your phone display, activate a theme.
Select > Settings > Personalis. > Themes. To see a list of the available
themes, select General. The active theme is indicated by a check mark.
To preview a theme, scroll to the theme, and select Options > Preview.
To activate the previewed theme, select Set.
To apply or edit an audio theme, select > Settings > Personalis. >
Themes > Audio themes.
In Themes, you can also set the menu view type, set a theme for the
standby mode, set a custom wallpaper, personalize the look of the
power saver, and select an image shown during a call.
■Profiles
In Profiles, you can adjust and personalize the phone tones for different
events, environments, or caller groups. You can see the currently
selected profile at the top of the display in the standby mode. If the
General profile is in use, only the current date is shown.
Select > Settings > Personalis. > Profiles.
To activate the profile, select the profile and Activate.
Tip: To quickly change to Silent profile from any other profile, in
the standby mode, press and hold #.
To personalize a profile, select the profile, Personalize, and the desired
settings.
To set the profile to be active until a certain time within the next 24
hours, select Timed and the time.
When using the Offline profile, the phone is not connected to the
cellular network. If no SIM card is installed, to use some functions of the
phone, start the phone in Offline.
FCC Draft
Model: 6650d-1bH
21 February 2008
Time management
54
Important: In the offline profile you cannot make or receive any calls,
or use other features that require cellular network coverage. Calls may
still be possible to the official emergency number programmed into
your device. To make calls, you must first activate the phone function by
changing profiles. If the device has been locked, enter the lock code.
14. Time management
■Clock
Select > Office > Clock. To change the clock settings, and to set the
time and date, select Options > Settings.
Alarm clock
To set a new alarm, scroll right to Alarm, and select Options > New
alarm. Enter the alarm time, select whether and when the alarm is
repeated, and select Done.
To cancel an alarm, scroll to the alarm, and select Options > Remove
alarm. To deactivate a repeated alarm, select Options > Deactivate
alarm.
Select Stop to turn off the alarm.
Select Snooze to stop the alarm for 5 minutes, after which it resumes.
You can do this a maximum of five times.
If the alarm time is reached while the device is switched off, the device switches
itself on and starts sounding the alarm tone. If you select Stop, the device asks
whether you want to activate the device for calls. Select No to switch off the
device or Yes to make and receive calls. Do not select Yes when wireless phone
use may cause interference or danger.
World clock
To set the phone to show the time in other locations, scroll right to
World. To add a location, select Options > Add location.
To set your current location, scroll to a location, and select Options >
Set as current location. The location is displayed in the clock main view,
and the time in your phone is changed according to the location
selected. Check that the time is correct and matches your time zone.
FCC Draft
Model: 6650d-1bH
21 February 2008
Office applications
55
■Calendar
Select > Office > Calendar. Press # in month, week, or day views to
automatically highlight the current date.
To add a new calendar entry, select Options > New entry and an entry
type. Anniversary entries are repeated every year. To-do entries help you
to keep a list of tasks that you need to do. Fill in the fields, and select
Done.
15. Office applications
■Notes
Select > Office > Notes. To write a new note, start writing. To save the
note, select Done. You can save plain text files (.txt format) you receive
to Notes.
■Calculator
Select > Office > Calculator. When entering numbers, press # to add
a decimal.
Note: This calculator has limited accuracy and is designed for simple
calculations.
■Converter
Select > Office > Converter. You can convert measurement
parameters such as Length from one unit to another, for example, Yards
to Metres.
The converter has limited accuracy and rounding errors may occur.
Before you can convert currency, you need to choose a base currency
(usually your domestic currency) and add exchange rates. The rate of the
base currency is always 1. Select Currency as the measurement type,
and select Options > Currency rates. To change the base currency, scroll
to the currency, and select Options > Set as base currency. Add
exchange rates, scroll to the currency, and enter a new rate.
FCC Draft
Model: 6650d-1bH
21 February 2008
Settings
56
After you insert all the required exchange rates, you can convert
currency. In the first Amount field, enter the value to be converted. The
other Amount field changes automatically.
Note: When you change base currency, you must enter new exchange
rates because all previously set exchange rates are cleared.
16. Settings
■Keypad lights
To view or edit keypad light and notification settings, select Menu >
>Settings >General > Personalization > Keypad lights
•Keypad light color to select the keypad light color. To preview a
color, scroll to the color and wait a moment.
•Notification time-out to select for how long keypad light notifica-
tions of events are displayed. New events reset the time-out period.
To disable the notification time-out, scroll left to Off. Notifications
are displayed for incoming calls, alarms, missed calls and new text
and multimedia messages. During an incoming call or an alarm the
keypad lights flash more quickly.
•Notification color to select the keypad light color for notifications. To
preview a color, scroll to the color and wait a moment. To cycle all
colors sequentially, select Cycle all colors. To use a random color,
select Random color.
■Voice commands
To select the functions to use by voice command, select > Settings >
Voice comm.. The voice commands for changing profiles are in the
Profiles folder.
To activate a new voice command for an application, select Options >
New application and the application. To play the activated voice
command, select Options > Playback.
To use voice commands, see "Voice dialing," p. 22.
FCC Draft
Model: 6650d-1bH
21 February 2008
Settings
57
■Phone settings
General
Select > Settings > General and from the following:
Personalisation—to adjust the display, standby mode, tones (such as
ringing tone), language, themes, and voice command settings.
Date and time—to set the time and date and the display format
Enhancement—to change the settings for an enhancement. Select an
enhancement and the desired setting.
Security—to change the phone and SIM card settings, such as PIN and
lock codes; view certificate details and check authenticity; and view and
edit security modules
When security features that restrict calls are in use (such as call barring, closed
user group, and fixed dialing), calls may be possible to the official emergency
number programmed into your device.
Factory settings—to reset some of the settings to their original values.
You need the lock code.
Positioning (network service)—to change positioning settings. See
"Positioning settings," p. 49.
Phone
See "Call settings," p. 25.
Connection
Select > Settings > Connection and from the following:
Bluetooth—to switch Bluetooth on or off, and edit Bluetooth settings.
See "Bluetooth connection settings," p. 65.
USB—to edit USB settings. See "USB connection," p. 66.
Destinations—to define the connection methods used for reaching a
particular destination
Packet data—to select the packet data connection settings. The packet
data settings affect all access points using a packet data connection.
FCC Draft
Model: 6650d-1bH
21 February 2008
Settings
58
• Select Packet data connection > When available to set the phone
to register to the packet data network when you are in a network
that supports packet data. If you select When needed, the phone
uses a packet data connection only if you start an application or
function that needs it.
• Select Access point to set the access point name to use your
phone as a modem with your computer.
• Select High speed packet access—to enable the use of HSDPA
(network service) in UMTS networks. When HSDPA support is
activated, downloading data such as messages, e-mail, and
browser pages through the cellular network may be faster.
Data call—to set the online time for the data call connection. The data
call settings affect all access points that use a GSM data call.
Video sharing—to set your SIP profile settings manually. See "Video
sharing settings," p. 27.
Presence (network service)—to view and edit the presence settings.
Connection applications, such as instant messaging and push to talk,
use the presence settings. You may receive the settings from your
service provider.
SIP settings—to view and edit session initiation protocol (SIP) profiles.
See "Video sharing," p. 27.
XDM porfile—to create or edit an XDM profile. Settings are for
communication applications, such as instant messaging, presence and
push to talk. These enable the service provider to access some user
information that is saved in the network servers but managed by the
user, for example push to talk groups. You may receive the settings from
your service provider. See Service settings p. 8.
Configurations—to view and delete configuration contexts. Certain
functions, such as web browsing and multimedia messaging, may
require configuration settings. You may receive the settings from your
service provider. See "Service settings," p. 8.
FCC Draft
Model: 6650d-1bH
21 February 2008
Data management
59
Applications
To view and edit settings of applications installed to your phone, select
> Settings > Applications.
■Speech
In Speech, you can select the default language and voice used for
reading text messages and adjust the voice properties, such as rate and
volume. Select > Settings > Speech.
To view details of a voice, scroll right, scroll to the voice, and select
Options > Voice details. To test a voice, scroll to the voice, and select
Options > Play voice.
■Settings wizard
Sett. wizard configures your phone for operator (MMS, GPRS, and
internet) and e-mail settings based on your service provider.
Configuring other settings may also be possible.
To use these services, you may have to contact your service provider to
activate a data connection or other services.
Select > Settings > Sett. wizard.
17. Data management
■Install or remove applications
You can install two types of applications to your phone:
• J2METM applications based on JavaTM technology with the extension
.jad or .jar. PersonalJavaTM applications cannot be installed on your
phone.
• Other applications and software suitable for the Symbian operating
system. The installation files have the .sis or .sisx extension. Only
install software specifically designed for your phone.
Important: Only install and use applications and other software from
trusted sources, such as applications that are Symbian Signed or have
passed the Java VerifiedTM testing.
FCC Draft
Model: 6650d-1bH
21 February 2008
Data management
60
Installation files may be transferred to your phone from a compatible
computer, downloaded during browsing, or sent to you in a multimedia
message, as an e-mail attachment or by using Bluetooth. You can use
Nokia Application Installer in Nokia PC Suite to install an application to
your phone or a memory card.
Installed applications are placed in > Applications > My own.
To open Application manager, select > Settings > App. mgr..
Install an application
The .jar file is required for installing Java applications. If it is missing, the
phone may ask you to download it.
To install an application or software package:
1. Select Not installed, and scroll to an installation file. Applications on
the memory card are indicated with .
2. Select Options > Install.
Alternatively, search the phone memory or the memory card, select
the application, and press the scroll key to start the installation.
During the installation, the phone shows information about the
progress of the installation. If you are installing an application
without a digital signature or certification, the phone displays a
warning. Continue installation only if you are sure of the origins and
contents of the application.
Java applications may attempt to, for example, establish a data
connection or send a message. To edit the permissions of an installed
Java application and define which access point the application will use,
select Installed, scroll to the application, and select Open.
After you install applications to a compatible memory card, installation files (.sis)
remain in the device memory. The files may use large amounts of memory and
prevent you from storing other files. To maintain sufficient memory, use Nokia PC
Suite to back up installation files to a compatible PC, then use the file manager to
remove the installation files from the device memory. See File manager p. 61. If
the .sis file is a message attachment, delete the message from the Messaging
inbox.
FCC Draft
Model: 6650d-1bH
21 February 2008
Data management
61
Remove an application
In the Application manager main view, select Installed, scroll to the
software package, and select Options > Remove.
■File manager
To browse, open, and manage files and folders in the phone memory or
on a memory card, select > Office > File mgr..
Back up and restore phone memory
To back up information from phone memory to the memory card or
restore information from the memory card, in File manager, select
Options > Back up phone memory or Restore from card. You can only
back up the phone memory and restore it to the same phone.
Format a memory card
When a memory card is formatted, all data on the card is permanently
lost. Some memory cards are supplied preformatted and others require
formatting.
1. In the File manager view, select the memory card.
2. Select Options > Memory card options > Format.
3. When formatting is complete, enter a name for the memory card.
Lock or unlock a memory card
To set a password to help prevent unauthorized use, in the File manager
view, select the memory card and Options > Memory card password >
Set. You are asked to enter and confirm your password. The password
can be up to eight characters long.
If you insert another password-protected memory card into your phone,
you are prompted to enter the password of the card. To unlock the card,
select Options > Unlock memory card.
■Licences
Digital rights management
Content owners may use different types of digital rights management (DRM)
technologies to protect their intellectual property, including copyrights. This
FCC Draft
Model: 6650d-1bH
21 February 2008
Data management
62
device uses various types of DRM software to access DRM-protected content.
With this device you can access content protected with WMDRM, OMA DRM 1.0,
and OMA DRM 2.0. If certain DRM software fails to protect the content, content
owners may ask that such DRM software's ability to access new DRM-protected
content be revoked. Revocation may also prevent renewal of such DRM-
protected content already in your device. Revocation of such DRM software does
not affect the use of content protected with other types of DRM or the use of
non-DRM-protected content.
Digital rights management (DRM) protected content comes with an associated
activation key that defines your rights to use the content.
If your device has OMA DRM protected content, to back up both the activation
keys and the content, use the backup feature of Nokia PC Suite. Other transfer
methods may not transfer the activation keys which need to be restored with the
content for you to be able to continue the use of OMA DRM protected content
after the device memory is formatted. You may also need to restore the
activation keys in case the files on your device get corrupted.
If your device has WMDRM protected content, both the activation keys and the
content will be lost if the device memory is formatted. You may also lose the
activation keys and the content in case the files on your device get corrupted.
Losing the activation keys or the content may limit your ability to use the same
content on your device again. For more information, contact your service
provider.
Some activation keys may be connected to a specific SIM card, and the protected
content can be accessed only if the SIM card is inserted in the device.
Select > Settings > Data mgr. > Licences to view the licences saved in
your phone.
To view valid licences that are connected to one or more media files,
select Valid licences. Group licences, which contain several licences, are
indicated with . To view the licences contained in the group licence,
select the group licence.
To view invalid licences with which the time period for using the file is
exceeded, select Invalid licences. To buy more usage time or extend the
usage period for a media file, select an invalid licence and Options > Get
new licence. It may not be possible to update licences if service message
reception is disabled.
FCC Draft
Model: 6650d-1bH
21 February 2008
Data management
63
To view licences that are not in use, select Not in use. Unused licenses
have no media files connected to them.
To view detailed information such as the validity status and the ability
to send the file, scroll to a licence, and select it.
■Device manager
To open the device manager, select > Settings > Data mgr. > Device
mgr..
Update software
The current software version is displayed in the Updates view.
Warning: If you install a software update, you cannot use the
device, even to make emergency calls, until the installation is
completed and the device is restarted. Be sure to back up data
before accepting installation of an update.
Downloading software updates may involve the transmission of large amounts of
data through your service provider's network. Contact your service provider for
information about data transmission charges.
Make sure that the device battery has enough power, or connect the charger
before starting the update.
1. In the Updates view, select Options > Check for updates.
If an update is available, the phone starts downloading it.
2. After a successful download, to install the update, select Now. To
start the installation later, select Later.
To start the installation process later, select Options > Install update.
If no server profile has been defined, the phone asks you to create one,
or if there are several, to select from a list of servers.
Contact your service provider for server profile settings.
Configure your phone
You may receive configuration settings from your service provider or
company information management department.
FCC Draft
Model: 6650d-1bH
21 February 2008
Connectivity
64
To connect to a server and receive configuration settings for your phone,
scroll right to Profiles, scroll to the server profile, and select Options >
Start configuration.
To edit a server profile, scroll to the profile, and select Options > Edit
profile.
Contact your service provider or company information management
department for the server profile settings.
18. Connectivity
■PC Suite
With PC Suite you can synchronize contacts, calendar entries, and notes
between your phone and a compatible PC.
You may find more information about PC Suite and the download link in
the support area on the Nokia website, www.nokia.com/pcsuite.
■Bluetooth connectivity
Bluetooth wireless technology enables wireless connections between
electronic devices within a maximum range of 10 metres (33 feet).
This device is compliant with Bluetooth Specification 2.0 supporting the
following profiles: Advanced Audio Distribution, Audio/Video Remote Control,
Basic Imaging, Basic Printing, Device Identification, Dial Up Networking, File
Transfer, Hands-free, Headset, Human Interface Device, Object Push, Serial Port,
SIM Access, Phonebook Access, Generic Audio/Video Distribution, Generic
Access, and Generic Object Exchange. To ensure interoperability between other
devices supporting Bluetooth technology, use Nokia approved enhancements for
this model. Check with the manufacturers of other devices to determine their
compatibility with this device.
There may be restrictions on using Bluetooth technology in some locations.
Check with your local authorities or service provider.
Features using Bluetooth technology, or allowing such features to run in the
background while using other features, increase the demand on battery power
and reduce the battery life.
Do not accept Bluetooth connections from sources you do not trust.
FCC Draft
Model: 6650d-1bH
21 February 2008
Connectivity
65
A Bluetooth connection is disconnected automatically after sending or
receiving data.
Bluetooth connection settings
Select > Settings > Connectivity > Bluetooth.
Bluetooth—to switch Bluetooth connectivity on or off
My phone's visibility > Shown to all—to allow your phone to be found by
other devices with Bluetooth connectivity at all times. To allow your
phone to be found for a defined time period, select Define period. For
security reasons it is advisable to use the Hidden setting whenever
possible.
My phone's name—to define a name for your phone
Remote SIM mode > On—to enable the usage of the SIM card of the
phone by another device (for example, a car kit) by Bluetooth
technology (SIM access profile)
When the wireless device is in the remote SIM mode, you can only use a
compatible connected enhancement, such as a car kit, to make or receive calls.
Your wireless device will not make any calls, except to the emergency numbers
programmed into your device, while in this mode. To make calls from your device,
you must first leave the remote SIM mode. If the device has been locked, enter
the lock code to unlock it first.
Send data
1. Open the application where the item you wish to send is saved.
2. Scroll to the item you want to send, and select Options > Send > Via
Bluetooth.
3. The phone starts to search for devices within range. Paired devices
are shown with . Some devices may show only the unique device
addresses. To find out the unique address of your phone, enter the
code *#2820# in the standby mode.
If you have searched for devices earlier, a list of devices found
previously is shown. To start a new search, select More devices.
4. Select the device with which you want to connect.
FCC Draft
Model: 6650d-1bH
21 February 2008
Connectivity
66
5. If the other device requires pairing before data can be transmitted, a
tone sounds and you are asked to enter a passcode. Create your own
passcode and share the passcode with the owner of the other device.
You do not have to memorize the passcode.
Pair and block devices
To open a list of paired devices, in the Bluetooth view, scroll right.
To pair with a device, select Options > New paired device, select the
device with which to pair, and exchange passcodes.
To cancel pairing, scroll to the device whose pairing you want to cancel,
and press the clear key. If you want to cancel all pairings, select
Options > Delete all.
To set a device to be authorized, scroll to the device, and select
Options > Set as authorized. Connections between your phone and an
authorized device can be made without your knowledge. Use this status
only for your own devices to which others do not have access, for
example, your PC or devices that belong to someone you trust. is
added next to authorized devices in the Paired devices view.
To block connections from a device, in the paired devices view, select
the device and Block.
To view a list of blocked devices, scroll right to Blocked devices. To
unblock a device, scroll to the device, and select Delete.
Receive data
When you receive data using Bluetooth technology, you are asked if you
want to accept the message. If you accept, the item is placed in Inbox in
Messaging.
■USB connection
You can use the USB data cable to establish a data connection between
the phone and a compatible PC.
Select > Settings > Connectivity > USB. To select the default USB
connection mode or change the active mode, select USB connection
mode and the desired mode. To have the device ask the purpose of the
FCC Draft
Model: 6650d-1bH
21 February 2008
Connectivity
67
connection each time the cable is connected, select Ask on connection >
Yes.
To use the phone with Nokia PC Suite, select PC Suite. To synchronize
media files, such as music, with a compatible version of Windows Media
Player, select Media transfer. To use the phone with a PictBridge-
compatible printer, select Image transfer. To access files on the inserted
memory card as a mass storage device, select Mass storage.
After transferring data, ensure that it is safe to unplug the USB data
cable from the PC.
■Remote synchronisation
Sync enables you to synchronize data such as your calendar entries,
contacts, and notes with a compatible computer or a remote internet
server.
Select > Settings > Connectivity > Sync.
To create a new profile, select Options > New sync profile and enter the
required settings.
To synchronize data, in the main view, mark the data to be synchronized,
and select Options > Synchronize.
■Connection manager
In the connection manager, you can identify the status of data
connections, view details on the amount of data sent and received, and
end unused connections.
Select > Settings > Connectivity > Conn. mgr..
Note: The actual invoice for calls and services from your service
provider may vary, depending on network features, rounding off for
billing, taxes, and so forth.
To view connection details, scroll to a connection, and select Options >
Details.
To end a connection, scroll to the connection, and select Options >
Disconnect. To end all connections, select Options > Disconnect all.
FCC Draft
Model: 6650d-1bH
21 February 2008
Applications
68
19. Applications
■Phone Inspector
Use Phone Inspector to check parts of your phone and the voice
network.
Note: To run tests on the phone, the SmartChip card must be inserted,
and the battery must be charged
Start tests
To run diagnostic tests on your phone, select Menu > Tools > Phone
Inspector > Tests.
Select all tests or from the list including: Internal Memory, External
Memory, Internal Display, External Display, Vibrate, Camera,
Speakerphone, Earpiece, Battery Charge, USB Data Cable, Headset
Cable, and Voice Network. Follow the prompts from the pop-up
messages.
To end a test, select Cancel.
When tests are finished, a colored screen displays results and stores
them in the Test Log.
20. Battery information
■Charging and discharging
Your device is powered by a rechargeable battery. The battery can be charged and
discharged hundreds of times, but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal, replace the battery. Use only
Nokia approved batteries, and recharge your battery only with Nokia approved
chargers designated for this device.
If a replacement battery is being used for the first time or if the battery has not
been used for a prolonged period, it may be necessary to connect the charger,
then disconnect and reconnect it to begin charging the battery.
Unplug the charger from the electrical plug and the device when not in use. Do
not leave a fully charged battery connected to a charger, since overcharging may
FCC Draft
Model: 6650d-1bH
21 February 2008
Battery information
69
shorten its lifetime. If left unused, a fully charged battery will lose its charge over
time.
If the battery is completely discharged, it may take several minutes before the
charging indicator appears on the display or before any calls can be made.
Use the battery only for its intended purpose. Never use any charger or battery
that is damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a
metallic object such as a coin, clip, or pen causes direct connection of the
positive (+) and negative (-) terminals of the battery. (These look like metal strips
on the battery.) This might happen, for example, when you carry a spare battery
in your pocket or purse. Short-circuiting the terminals may damage the battery
or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer or
winter conditions, will reduce the capacity and lifetime of the battery. Always try
to keep the battery between 15°C and 25°C (59°F and 77°F). A device with a hot
or cold battery may not work temporarily, even when the battery is fully charged.
Battery performance is particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also
explode if damaged. Dispose of batteries according to local regulations. Please
recycle when possible. Do not dispose as household waste.
Do not dismantle or shred cells or batteries. In the event of a battery leak, do not
allow the liquid to come in contact with the skin or eyes. In the event of such a
leak, flush your skin or eyes immediately with water, or seek medical help.
■Talk and standby times
Talk time (ECTEL): up to XXX minutes
Standby time(ECTEL): up to XXX hours
Important: Battery talk and standby times are estimates only and
depend on signal strength, network conditions, features used, battery
age and condition, temperatures to which battery is exposed, use in
digital mode, and many other factors. The amount of time a device is
used for calls will affect its standby time. Likewise, the amount of time
that the device is turned on and in the standby mode will affect its talk
time.
FCC Draft
Model: 6650d-1bH
21 February 2008
Care and maintenance
70
■Nokia battery authentication guidelines
Always use original Nokia batteries for your safety. To check that you are getting
an original Nokia battery, purchase it from an authorized Nokia dealer, and
inspect the hologram label using the following steps:
Successful completion of the steps is not a total assurance of the authenticity of
the battery. If you have any reason to believe that your battery is not an
authentic, original Nokia battery, you should refrain from using it, and take it to
the nearest authorized Nokia service point or dealer for assistance. Your
authorized Nokia service point or dealer will inspect the battery for authenticity.
If authenticity cannot be verified, return the battery to the place of purchase.
Authenticate hologram
1. When you look at the hologram on the label, you
should see the Nokia connecting hands symbol from
one angle and the Nokia Original Enhancements
logo when looking from another angle.
2. When you angle the hologram left, right, down and
up, you should see 1, 2, 3 and 4 dots on each side
respectively.
What if your battery is not authentic?
If you cannot confirm that your Nokia battery with the
hologram on the label is an authentic Nokia battery,
please do not use the battery. Take it to the nearest
authorized Nokia service point or dealer for assistance. The use of a battery that
is not approved by the manufacturer may be dangerous and may result in poor
performance and damage to your device and its enhancements. It may also
invalidate any approval or warranty applying to the device.
To find out more about original Nokia batteries, visit www.nokia.com/battery.
Care and maintenance
Your device is a product of superior design and craftsmanship and should be
treated with care. The following suggestions will help you protect your warranty
coverage.
FCC Draft
Model: 6650d-1bH
21 February 2008
Care and maintenance
71
• Keep the device dry. Precipitation, humidity, and all types of liquids or
moisture can contain minerals that will corrode electronic circuits. If your
device does get wet, remove the battery, and allow the device to dry
completely before replacing it.
• Do not use or store the device in dusty, dirty areas. Its moving parts and
electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic
circuit boards.
• Do not attempt to open the device other than as instructed in this guide.
• Do not drop, knock, or shake the device. Rough handling can break internal
circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean
the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper
operation.
• Use a soft, clean, dry cloth to clean any lenses, such as camera, proximity
sensor, and light sensor lenses.
• Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the device and may
violate regulations governing radio devices.
• Use chargers indoors.
• Always create a backup of data you want to keep, such as contacts and
calendar notes.
• To reset the device from time to time for optimum performance, power off
the device and remove the battery.
These suggestions apply equally to your device, battery, charger, or any
enhancement. If any device is not working properly, take it to the nearest
authorized service facility for service.
FCC Draft
Model: 6650d-1bH
21 February 2008
Additional safety information
72
Disposal
The crossed-out wheeled-bin symbol on your product, literature, or
packaging reminds you that in the European Union all electrical and
electronic products, batteries, and accumulators must be taken to
separate collection at the end of their working life. Do not dispose of
these products as unsorted municipal waste.
Return the products to collection to prevent possible harm to the
environment or human health from uncontrolled waste disposal and to
promote the sustainable reuse of material resources. Collection
information is available from the product retailer, local waste authorities,
national producer responsibility organizations, or your local Nokia
representative. For more information, see product Eco-Declaration or
country-specific information at www.nokia.com.
Additional safety information
■Small children
Your device and its enhancements may contain small parts. Keep them out of the
reach of small children.
■Operating environment
This device meets RF exposure guidelines when used either in the normal use
position against the ear or when positioned at least 2.2centimeters (7/8inches)
away from the body. When a carry case, belt clip, or holder is used for body-worn
operation, it should not contain metal and should position the device the above-
stated distance from your body.To transmit data files or messages, this device
requires a quality connection to the network. In some cases, transmission of data
files or messages may be delayed until such a connection is available. Ensure the
above separation distance instructions are followed until the transmission is
completed.
Parts of the device are magnetic. Metallic materials may be attracted to the
device. Do not place credit cards or other magnetic storage media near the
device, because information stored on them may be erased.
■Medical devices
Operation of any radio transmitting equipment, including wireless phones, may
interfere with the functionality of inadequately protected medical devices.
Consult a physician or the manufacturer of the medical device to determine if
they are adequately shielded from external RF energy or if you have any
FCC Draft
Model: 6650d-1bH
21 February 2008
Additional safety information
73
questions. Switch off your device in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or health care facilities may
be using equipment that could be sensitive to external RF energy.
Implanted medical devices
Manufacturers of medical devices recommend that a minimum separation of
15.3 centimeters (6 inches) should be maintained between a wireless device and
an implanted medical device, such as a pacemaker or implanted cardioverter
defibrillator, to avoid potential interference with the medical device. Persons
who have such devices should:
• Always keep the wireless device more than 15.3 centimeters (6 inches) from
the medical device when the wireless device is turned on.
• Not carry the wireless device in a breast pocket.
• Hold the wireless device to the ear opposite the medical device to minimize
the potential for interference.
• Turn the wireless device off immediately if there is any reason to suspect that
interference is taking place.
• Read and follow the directions from the manufacturer of their implanted
medical device.
If you have any questions about using your wireless device with an implanted
medical device, consult your health care provider.
■Vehicles
RF signals may affect improperly installed or inadequately shielded electronic
systems in motor vehicles such as electronic fuel injection systems, electronic
antiskid (antilock) braking systems, electronic speed control systems, and air bag
systems. For more information, check with the manufacturer, or its
representative, of your vehicle or any equipment that has been added.
Only qualified personnel should service the device or install the device in a
vehicle. Faulty installation or service may be dangerous and may invalidate any
warranty that may apply to the device. Check regularly that all wireless device
equipment in your vehicle is mounted and operating properly. Do not store or
carry flammable liquids, gases, or explosive materials in the same compartment
as the device, its parts, or enhancements. For vehicles equipped with an air bag,
remember that air bags inflate with great force. Do not place objects, including
installed or portable wireless equipment in the area over the air bag or in the air
bag deployment area. If in-vehicle wireless equipment is improperly installed and
the air bag inflates, serious injury could result.
FCC Draft
Model: 6650d-1bH
21 February 2008
Additional safety information
74
Using your device while flying in aircraft is prohibited. Switch off your device
before boarding an aircraft. The use of wireless teledevices in an aircraft may be
dangerous to the operation of the aircraft, disrupt the wireless telephone
network, and may be illegal.
■Potentially explosive environments
Switch off your device when in any area with a potentially explosive atmosphere,
and obey all signs and instructions. Potentially explosive atmospheres include
areas where you would normally be advised to turn off your vehicle engine.
Sparks in such areas could cause an explosion or fire resulting in bodily injury or
even death. Switch off the device at refueling points such as near gas pumps at
service stations. Observe restrictions on the use of radio equipment in fuel
depots, storage, and distribution areas; chemical plants; or where blasting
operations are in progress. Areas with a potentially explosive atmosphere are
often, but not always, clearly marked. They include below deck on boats,
chemical transfer or storage facilities and areas where the air contains chemicals
or particles such as grain, dust, or metal powders. You should check with the
manufacturers of vehicles using liquefied petroleum gas (such as propane or
butane) to determine if this device can be safely used in their vicinity.
■Emergency calls
Important: Wireless phones, including this device, operate using radio
signals, wireless networks, landline networks, and user-programmed
functions. Because of this, connections in all conditions cannot be
guaranteed. You should never rely solely on any wireless device for
essential communications like medical emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for adequate signal strength.
Some networks may require that a valid SIM card is properly inserted in the
device.
2. Press the end key as many times as needed to clear the display and ready the
device for calls.
3. Enter the official emergency number for your present location. Emergency
numbers vary by location.
4. Press the call key.
If certain features are in use, you may first need to turn those features off before
you can make an emergency call. In the offline or flight profiles, you may need to
unlock the device and change to the calling profile before making a call. Consult
this guide or your service provider for more information.
FCC Draft
Model: 6650d-1bH
21 February 2008
Additional safety information
75
When making an emergency call, give all the necessary information as accurately
as possible. Your wireless device may be the only means of communication at the
scene of an accident. Do not end the call until given permission to do so.
■Certification information (SAR)
This mobile device meets guidelines for exposure to radio waves.
Your mobile device is a radio transmitter and receiver. It is designed not to
exceed the limits for exposure to radio waves recommended by international
guidelines. These guidelines were developed by the independent scientific
organization ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.
The exposure guidelines for mobile devices employ a unit of measurement known
as the Specific Absorption Rate or SAR. The SAR limit stated in the ICNIRP
guidelines is 2.0 watts/kilogram (W/kg) averaged over 10 grams of tissue. Tests
for SAR are conducted using standard operating positions with the device
transmitting at its highest certified power level in all tested frequency bands. The
actual SAR level of an operating device can be below the maximum value
because the device is designed to use only the power required to reach the
network. That amount changes depending on a number of factors such as how
close you are to a network base station. The highest SAR value under the ICNIRP
guidelines for use of the device at the ear is 0.66 W/kg.
Use of device accessories and enhancements may result in different SAR values.
SAR values may vary depending on national reporting and testing requirements
and the network band. Additional SAR information may be provided under
product information at www.nokiausa.com.
Your mobile device is also designed to meet the requirements for exposure to
radio waves established by the Federal Communications Commission (USA).
These requirements set a SAR limit of 1.6 W/kg averaged over one gram of tissue.
The highest SAR value reported under this standard during product certification
for use at the ear is 0.92 W/kg and when properly worn on the body is 0..68 W/kg.
FCC Draft
Model: 6650d-1bH
21 February 2008
76
Index
A
access codes
lock code 14
module PIN 15
PIN 14, 15
PIN2 15
PUK 15
PUK2 15
restriction password 15
signing PIN 15
UPIN 15
UPUK 15
active standby 17
alarm clock. See clock.
assigning a number 22
B
battery
charging 13
Bluetooth
connection settings 65
receiving data 66
sending data 65
bookmarks 50–??
C
cache 52
calculator 55
calendar 55
call register. See log.
calls
answering 23
conference call 23
ending 21
forward 26
forwarding 26
international 21
making 21
options during a call 24
rejecting 23
rejecting with SMS 23
speed dial 22
swapping 24
voice dial 22
voice mailbox 22
waiting 24
camera 47
clock 54
connection manager 67
connectivity 64
contacts 40
memory consumption 40
converter 55
D
data cable 66
data connection indicators 18
E
e-mail messages
deleting 33
retrieving 33
F
Flash Player 45
G
gallery 45
transferring videos 47
GPS data 49
H
help 8
I
indicators 18
instant messaging 35
K
keyguard. See keypad lock.
keypad lights 56
keypad lock 20
L
landmarks 49
light settings 56
listening to music 41
log 29
FCC Draft
Model: 6650d-1bH
21 February 2008
77
M
media player. See RealPlayer.
menu 19
messages
outbox 34
service commands 34
service messages 32
SIM messages 34
music player
downloading music 43
music shop 43
playlists 42
transferring music 43
music.See music player.
N
notes 55
O
one-touch dial. See speed dial.
P
paired devices 66
phone inspector 68
phonebook. See contacts.
positioning 49
profiles 53
PTT 35
Push to Talk 35
Push to Talk. See PTT.
R
RealPlayer
recorder 45
restriction password. See access codes
ringing tones
add to contacts 41
add to groups 41
video ringing tones 46
S
settings
connection 57
data call 58
messaging 34
packet data 57
phone 57
positioning 49
PTT 39
Setting wizard 59
speech 59
writing language 29
SIM card
using phone without a SIM card 17
songs
transferring 43
speed dial
calling 22
speed dialing 22
standby mode 17
synchronization 67
T
text input
copying text 30
deleting text 30
themes 53
transferring music 43
transferring videos 47
U
updating software 63
USB 66
V
video call 24, 25
video sharing
settings 27
videos
transferring 47
voice commands 56
voice dialing 22
voice mailbox 22
voice recorder. See recorder.
volume 19
W
web
connection security 50
feeds 52
saving a page 52
viewing a saved page 52
viewing bookmarks 50
writing text. See text input.
FCC Draft
Model: 6650d-1bH
21 February 2008
78
FCC Draft
Model: 6650d-1bH
21 February 2008
